INSTRUCTION BOOK
Condenser Tumble Dryer
GCC 5813 NB
English
2
Introduction
Delivery Information
Safety Reminders
Use Installation The Laundry
Ventilation
Environmental Issues Gias Service
Installation
Electrical Requirements Adjusting the Feet
Drain Hose Kit: Fitting Instructions
Preparing the Load
Clothes Preparation Do Not Tumble Dry Energy Saving Sorting the Load
Drying Guide
Controls and Indicators Selecting the Programme Door and Filter
Opening the Door Filter Filter Care Indicator
Water Container
To Remove the Container
Condenser
To Remove the Condenser
Operation
Delay Start Function Cancelling and Resetting the Programme
Cleaning and Routine Maintenance
Cleaning the Dryer Technical Specifications
Troubleshooting Customer Service
Spares Gias Service
INDEX
3 3 3
5
5
6 7 7 7 7 7 8 9 9 9 9 9 9
10
11
12 12 12 12 12 12
13 13 13 14 14 14 14 14 15 15 15 15
EN 2
INTRODUCTION
Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important guidelines for safe use, installation, maintenance and some useful advice for best results when using your machine.
Keep all documentation in a safe place for future reference or for any future owners.
Delivery Information
Please check that the following items are delivered with the appliance:
Check that no damage has occurred to the machine during transit. If it has, call for service by GIAS.
Instruction manual
Guarantee card
Energy label
SAFETY REMINDERS
Use
Failure to comply with the above can compromise the safety of the appliance. You may be charged for a service call if a problem with your machine is caused by misuse.
This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.Children of less than 3 years should be kept away unless continuously supervised.
WARNING Misuse of a tumble dryer may create a fire hazard
.
This appliances is intended to be used in household and similar
applications such as:
- Staff kitchen areas in shops , offices and other working environments;
- Farm houses
- By clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance from household environment or from typical housekeeping functions,as commercial use by expert or trained users, is excluded even in the above applications.
EN 3
EN 3
INTRODUCTION
SAFETY REMINDERS
Use
If the appliance is used in a manner inconsistent with this it may reduce the life of the appliance and may void the manufacturer’s warranty. Any damage to the appliance or other damage or loss arising through use that is not consistent with domestic or household use ( even if located in a domestic or household environment) shall not be accepted by the manufacturer to the fullest extent permitted by law.'›
●This machine should only be used for its intended purpose as described in this manual. Ensure that the instructions for installation and use are fully
understood before operating the appliance.
Do not touch the appliance when hands or feet are damp or wet.
Do not lean on the door when loading the machine or use the door to lift or
move the machine.
Do not allow children to play with the machine or its controls.
WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
●WARNING Where the hot surface symbol is located the temperature rise during operation of the tumble dryer may be in excess of 60 degrees C.
● Remove the plug from the electricity supply. Always remove the plug before cleaning the appliance.
Do not continue to use this machine if it appears to be faulty.
Lint and fluff must not be allowed to collect on the floor around the outside
of the machine.
The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures that the items will not be damaged.
Maximum load drying weight : 8 kg
The tumble dryer is not to be used if industrial chemicals have been used
for cleaning.
WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
EN
4
SAFETY REMINDERS
Installation
INTRODUCTION
Check that the product has no visible signs of damage before use. If damaged do not use and please call GIAS Service.
Do not use adapters, multiple connectors and/or extensions.
Never install the dryer against curtains and be sure to prevent items from falling or collecting behind the dryer.
The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the tumble dryer.
The Laundry
Do not dry unwashed items in the tumble dryer.
● WARNING Do not tumble dry fabrics treated with dry cleaning
fluids.
●WARNING Foam rubber materials can, under certain circumstances,
when heated become ignited by
spontaneous combustion. Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads MUST NOT be dried in the tumble dryer.
● Always refer to the laundry care labels for directions on suitability for drying.
● Clothes should be spin dried or thoroughly wrung before they are put into the tumble dryer. Clothes
that are dripping wet should not be put into the dryer.
● Lighters and matches must not be left in pockets and NEVER use flammabl e liquids near the
machine.
● Glass fibre curtains should NEVER be put in this machine. Skin
irritation may occur if other
garments are contaminated with the glass fibres.
● Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
● Fabric softeners, or similar products, should be used as
specified by the fabric softener
instructions.
EN 5
SAFETY REMINDERS
Ventilation
• Adequate ventilation must be provided in the room where the tumble dryer is located to prevent gases from appliances burning other fuels, including open fires, being drawn into the room during operation of the tumble dryer.
• Installing the rear of the appliance close to a wall or vertical surface.
•There should be a gap of at least 12 mm between the machine and any obstrubtions.The inlet and outlet s h o u l d b e k e p t c l e a r o f obstruction.To ensure adequate ventilation the space between the bottom of the machine and the floor must not be obstructed.
• Check regularly that the air flowing through the dryer is not restricted.
• Check frequently the fluff filter after use, and clean, if necessary.
•Prevent items from falling or collecting behind the dryer as these may obstruct the air inlet and outlet
• NEVER install the dryer up against curtains.
• In cases where the dryer is installed on top of a washing machine, a suitable stacking kit must be used according to the follow configuration.
-Stacking kit Mod 35100019: for minimum washing machine depth 49 cm
-Stacking kit Mod 35900120: for minimum washing machine depth 51 cm
6
EN
INTRODUCTION
The stacking kit shall be one of that above, obtainable from our spare service. The instructions for installation and
any fixing attachments, are provided with the staking kit.
Do not install the product in a low temperature room or in a room where there is a risk of frost occurring. At temperature around freezing point the product may not be able to operate properly: there is a risk of damage if the water is allowed to freeze in the hydraulic circuit (valves, hoses, pumps). For a better product performance the ambient room temperature must be between +2°C and +35°C. Please note that operating in cold condition (between +2 and +15°C) might simply some water condensation and water drops on floor.
INSTALLATION
Environmental Issues
All pa cka gin g mate ria ls use d are environmentally-frien dl y and recyclable. Please help dispose of the packaging via environmentally-friendly means. Your local council will be able to give you details of current means of disposal.
To ensure safety when disposing of an old tumble dryer disconnect the mains plug from the socket, cut the mains power cable and destroy this together with the plug. To prevent children shutting themselves in the machine break the door hinges or the door lock.
European Directive 2012/19/EU
This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).
WEEE contains both polluting substances (which can cause negative consequences for the environment) and basic components (which can be re-used). It is important to have WEEE subjected to specific treatments, in order to remove and dispose properly all pollutants, and recover and recycle all materials. Individuals can play an important role in ensuring that WEEE does not become an environmental issue; it is essential to follow some basic rules:
- WEEE should not be treated as household waste.
- WEEE should be handed over to the relevant collection points managed by the municipality or by registered companies. In many countries, for large WEEE, home collection could be present.
In many countries, when you buy a new appliance, the old one may be returned to the retailer who has to collect it free of charge on a one-to-one basis, as long as the equipment is of equivalent type and has the same functions as the supplied equipment.
GIAS Service
To ensure the continued safe and efficient operation of this appliance we recommend that any servicing or repairs are only carried out by an authorised GIAS service engineer.
Electrical Requirements
Tumble dryers are supplied to operate at a voltage of 220-240V, 50 Hz single phase. Check that the supply circuit is rated to at least 13A.
Electricity can be extremely dangerous.
This appliance must be earthed. The socket outlet and the plug on the appliance must be of the same type. Do not use multiple adapters and/or extension leads.
Th e plu g s hould be a cce ssibl e f or disconnection after the appliance has been installed.
CE Appliance complies with European Directive 2004/108/EC, 2006/95/EC and subsequent amendments.
If the appliance is not running properly or
breaks down, switch it off and disconnect the plug from the socket. Consult GIAS Service for possible repair.
You may be charged for a service call if a problem with your machine is caused by incorrect installation.
If the mains cord on this appliance is
damaged, it must be replaced by a special cord
which is ONLY obtainable from the spares service. It must be installed by a competent person.
Do not plug the machine in and switch it
on at the mains until the installation is completed.For your safety, this dryer must be correctly installed. If there is any doubt about installation, call GIAS Service for advice.
Adjusting the Feet
Once the machine is in place the feet should be adjusted to e n s u r e t h a t t h e machine is level.
7
EN
DRAIN HOSE : FITTING INSTRUCTIONS
To avoid emptying the water container after each drying cycle, the water can be discharged directly to a waste water drain pipe (the same drainage system as household sinks). Water Bye-Laws prohibit connection to a surface water drain. The waste water drain pipe should be located adjacent to the tumble dryer.
5. Pl a c e t h e t a p supplied by the kit to cl ose the re main g hose.
The kit consists of:1 hose and 1 tap.
WARNING! Switch off and remove the tumble dryer plug from the electricity supply before carrying out any work.
Fit the Hose as Follows:
1. Ti lt the mac hin e backwards.
2. The waste water
pipe is situated at the right-hand side of the machi n e (see t h e picture). A grey hose connects to the bridge
at the left hand side of the machine. Using
pliers, remove the pipe retaining clip from the bridge.
3. Pull the hose off the bridge connection.
6. Once the machine is in place the feet should be adjusted to ensure that the new hose does
not kink when pushing the tumble dryer into position.
7. Connect the new drain hose to the waste Water pipe.
8. Connect to the m a in s e l e c t r ic i ty supply.
4. Attach the black hose from the kit, (using the connector a n d p i p e c l i p s supplied), to the hose rem o ved from the bridge connection.
EN 8
PREPARING THE LOAD
Before using the tumble dryer for the first time:
Please read this instruction book thoroughly.
Remove all items packed inside drum.
Wipe the inside of the drum and door with a
damp cloth to remove any dust which may have settled in transit.
Clothes Preparation
Make sure that the laundry you are going to dry is suitable for drying in a tumble dryer, as shown by the care symbols on each item. Check that all fastenings are closed and that pockets are empty. Turn the articles inside out. Place clothes loosely in the drum to make sure that they don't get tangled.
Do Not Tumble Dry:
Woollens, silk, delicate fabrics, nylon stockings, delicate embroidery, fabrics with metallic dec­orations, garments with PVC or leather trimmings, training shoes, bulky items such as sleeping bags, etc.
IMPORTANT: Do not dry articles which have been treated with a dry cleaning fluid or rubber clothes (danger of fire or explosion).
During the last 15 minutes the load is always tumbled in cool air.
Energy Saving
Only put into the tumble dryer laundry which has been thoroughly wrung or spin-dried. The drier the laundry the shorter the drying time thus saving electricity.
ALWAYS
Try to dry the maximum weight of laundry, this will save time and electricity.
Check that the filter is clean before every drying cycle.
NEVER
Exceed the maximum weight, this will waste time and electricity.
Put dripping wet items into the tumble dryer, this may damage the appliance.
Do not overload the drum, large items when wet can exceed the maximum admissible clothes load (for example: sleeping bags, duvets).
Maximum Drying Weight
Cottons Max. 8 kg
Synthetics Max. 4 kg
Sort the Load as Follows
By care symbols
These can be found on the collar or inside seam:
Suitable for tumble drying.
. .
Tumble drying at high temperature.
.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it must be assumed that it is not suitable for tumble drying.
By amount and thickness
Whenever the load is bigger than the dryer capacity, separate clothes according to thickness (e.g. towels from thin underwear).
By type of fabric
Cottons/linen: Towels, cotton jersey, bed and table linen.
Synthetics: Blouses, shirts, overalls, etc. made of polyester or polyamid, as well as for cot­ton/synthetic mixes.
By drying level
Sort into: iron dry, cupboard dry, etc. For delicate articles press the Delicates button to select low drying temperature.
Drying Guide
The standard cycle CUPBOARD DRY ( ) is the most energy efficient and best suited for drying normal wet cotton laundry. The table below shows the approximate time and energy consumption of the main drying programmes.
CYCLE
Perfect Home Extra Dry Cupboard Dry Cupboard Dry Iron Dry
Power consumption of "left on-mode"
Power consumption of "off-mode"
LOAD
FULL FULL FULL HALF FULL
ENERGY
(kWh)
5,64 5,31 4,70 2,56 3,76
TIME
(Min)
214 185 157
91
129
0,80 W
0,20 W
EN
9
CONTROLS AND INDICATORS
Water Tank
Indicator
Start/Pause
Button
Filter Care
Indicator
Progress
Display
Acrylic Synthetic
Button
Programme
Delay Start
Button
Selector
Control Panel and Indicator Lights
Programme Selector – Select the required programme. Time Selection Button – Allows the user to change duration of the programme selected by
Programme Selector. It can be used only with the selection of: Mix&Dry, Shirts and Time Programmes. Delay Start Button – Allows the user to delay the start of the drying cycle (see details of Operation ). Acrylic and Synthetic Button –Press to select the type of fabrics to dry Acrylic and synthetics, when pressed Acrylic Synthetics option is activated and the indicator lights up.
Anti- Crease Button – Allows the user to select a post drying anti-crease cycle. Start/Pause Button – Press to commence/ to pause the selected drying programme. Filter Care indicator – Lights when the filter needs cleaning. Empty Water indicator – Lights when the water container is full. Program Display – Related indicator lights when a auto programme has been selected. Refresh – The indicator lights up when the programme starts the cool down stage.
SELECTING THE PROGRAMME
10
EN
The Candy Sensor Dry machine gives many options for drying the laundry to suit all circumstances. The table on the next page lists the programmes and the function of each programme.
Note: The sensor may not detect a small load of small articles. For small loads and separate items or pre-dried fabrics with low moisture content, use the timed programmes. If the sensor does not detect the item the dryer will only operate for 10 minutes before going into cooldown. If the load is too large or too wet to tumble dry the dryer will automatically go into cooldown after approximately 3 hours.
In these cases we advise to use a time cycles between 30 and 75minutes depending on the load size and dryness required, and
select high or low heat depending upon the fabric type.
SELECTING THE PROGRAMME
PROGRAMME
Extra Dry
Cupboard Dry
Iron Dry
Wool Finish
No Crease
Rapid 40
DESCRIPTION
Select the degree of dryness that you require. This ranges from
for bath towels and bathrobes, through for items that will be put away without ironing, to the programme that leaves the laundry suitable for ironing.
A gentle programme specially created to get woollens softer after air-drying.This delicate warm air cycle, lasting 12 minutes, can also be used to get woollens 'refreshed' after being stored in the wardrobe.
The programme provides a conditioning and anticrease function. The dryer will heat the load for 9 minutes followed by a 3 minute cool down period and is especially good for garments which may have been left for some time prior to ironing, in a linen basket for example. Garments may also become stiffened when dried outside on a washing line or inside on radiators. This programme relaxes the creases in the fabric making ironing quicker and easier.
The 40’ Rapid programme allows a drying cycle to be completed quickly. This is an ideal programme for having dry, refreshed and ready-to-wear clothes in less than 40'. This special programme constantly monitors the dryness and temperature in the drum thanks to the sensor using, using the exact time and energy you need! The machine finishes the cycle when the cupboard dry level is reached. The stated cycle length could vary according to fabric types, load size and residual moisture in the garments.The maximum load is 2kg and the programme is suitable for all types of fabric where tumble drying is appropriate.
150'
120'
90'
75'
60'
45'
30'
Refresh
150' minutes of drying
120' minutes of drying
90' minutes of drying
75' minutes of drying
60' minutes of drying
45' minutes of drying
30' minutes of drying
Tumbling the laundry in cool air for 20 minutes
EN
11
DOOR and FILTER
Opening the Door
Pull on handle to open the door.
To restart the dryer, close the door and press .
WARNING! When the tumble dryer is in use the drum and door may be VERY HOT. Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
Filter
IMPORTANT: To maintain the efficiency of the dryer check that the fluff filter is clean before each drying cycle.
1 . P u l l t h e f i l t e r upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or your fingertips.
4 . S n a p t h e f il te r to get her an d p ush back into place.
Filter Care Indicator
Lights when the filter needs cleaning.
If the laundry is not drying check that the filter is not clogged.
DO NOT USE WATER TO CLEAN THE FILTER.
WATER CONTAINER
The water removed from the laundry during the drying cycle is collected in a container inside the door of the dryer. When the container is full the
indicator on the control panel will light, and the container MUST be emptied. However, we recommend that the container is emptied after each drying cycle. NOTE: Very little water will collect during the first few cycles of a new machine as an internal reservoir is filled first.
To Remove the Container
1. Gently pull out the w a t e r c o n t a i n e r holding the handle.
When it is full the water container will weigh about 6 kg.
2 . Ti l t t h e wa t e r container to empty the water out through the spout. When empty, replace the water container back as shown; first
insert the base of the container into position as shown then gentle pus h th e to p in to position.
3. Press Button to restart the cycle.
NOTE: If you have the option of drainage near to the dryer you can use the discharge kit to provide a permanent drainage for the water c o l l e ct e d i n t h e container of the dryer. This means that you
don't have to empty the
1
water container.
WARNING! If you open the door mid cycle, before the cool-down cycle has completed,the handle may be hot. Please use extreme caution when attempting to empty the water reservoir during the cycle.
EN 12
CONDENSER
Important: Always switch off and remove the plug from the electricity supply before cleaning the condenser.
To maintain the efficiency of the dryer regularly check that the condenser is clean.
To Remove the Condenser
1.Remove the kickplate.
2. Turn the two locking levers anti-clockwise and pull out the condenser.
3.Pull out the condenser
unit.
4. Gently remove any dust or fluff with a cloth, then wash
the unit by holding it under a running tap turning it so that water flows between the plates, to remove any dust or fluff.
5.Check the gasket position after cleaning.Fit the gasket in to the groove if it is misaligned.
6.Refit the condenser ensuring
it is in the correct way (as indicated by the arrow) and pushed firmly into place. Lock the two levers by turning them c l o ck w i se . B e s u r e t h a t condenser unit fixed to the basement tightly.
7. Refit the kickplate.
OPERATION
1. Open the door and load the drum with laundry. Ensure that garments do not hinder closure of the door.
2. Gently close the door pushing it slowly until you hear the door 'click' shut.
3. Turn the Programme Selector dial to select the req u ired dry ing p rogr amme (se e Programme Guide).
4. If drying synthetics, acrylics or delicate items, press the button to reduce the heat level. The indicator will light up when the machine is in low heat setting. To deselect in the first few minutes of the programme, press the button , after this time reset the machine to change the setting.
5. Press the button. The dryer will start automatically and the indicator above the button will be continuously lit.
6. If the door is opened during the programme to check the laundry, it is necessary to press to recommence drying after the door has been closed.
7. When the cycle is nearing completion the machine will enter the cool down phase, the clothes will be tumbled in cool air allowing the load to cool down.
8. Following the completion of the cycle the drum will rotate intermittently to minimize creasing. This will continue until the machine is switched OFF or the door is opened.
Do not open the door during the automatic programs in order to obtain a proper drying.
EN 13
OPERATION
Delay Start Function
The Delay Start Function allows the user to delay the start of the drying cycle by 3, 6 or 9 hours.
When the function is first selected the display will show a delay of 3 hours, subsequent presses of the button will increase the delay to 6 or 9 hours.
To commence the programme press Start/Pause and the appliance will complete the drying cycle at the end of this time. The 3, 6 or 9 hour indicator light will flash to indicate that the start delay is in progress.
Cancelling and Resetting the Programme
To cancel a programme press the Start/Pause button for 3 seconds. The DRY light will flash to indicate that it has been reset.
CLEANING AND ROUTINE MAINTENANCE
Cleaning the Dryer
Clean the filter and empty the water container after every drying cycle.
● Regularly clean the condenser.
● After each period of use, wipe the inside of
the drum and leave the door open for a while to allow circulation of air to dry it.
Wipe the outside of the machine and the door with a soft cloth.
DO NOT use abrasive pads or cleaning agents.
To prevent the door sticking or the build up of fluff, clean the inner door and gasket with a damp cloth after every drying cycle.
WARNING! The Drum, door and load may
be very hot.
Technical Specifications
Drum capacity 115 litres Maximum load 8kg Height 85 cm Width 60 cm Depth 60 cm Energy Label Band B
Information for Test Laboratory
EN 61121 Programme Programme To Use
-DRY COTTON
-IRON DRY COTTON
-EASY-CARE TEXTILE
IMPORTANT Always switch off and remove the plug from the electricity supply before cleaning this appliance.
For electrical data refer to the rating label on the front of the dryer cabinet (with the door open).
-Cupboard dry
-Iron dry
-Cupboard dry + Synthetic
EN 14
What Might be the Cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run through the following checklist. A charge will be made if the machine is found to be working or has been installed incorrectly or used incorrectly. If the problem persists after completing the recommended checks, please call GIAS Service, they may be able to assist you over the telephone.
Time display to end could change during dr ying cy cle . The t ime to end is continuously checked during the drying cycle and the time is adjusted to give the best estimation time. The displayed time may increase or decrease during the cycle and this is normal.
Drying time is too long/clothes are not dry enough…
Have you selected the correct drying time/programme?
Were the clothes too wet? Were the clothes thoroughly wrung or spindried?
Does the filter need cleaning?
Is the dryer overloaded?
Has the option been selected from a
previous cycle?
TROUBLESHOOTING
The dryer is noisy…
Switch off the dryer and contact GIAS Service for advice.
The Indicator is on…
Does the filter need cleaning?
The Indicator is on…
Does the water container need emptying?
CUSTOMER SERVICE
Should there still be a problem with your dryer after completing all the recommended checks, please call GIAS Service for advice. They may be able to assist you over the telephone or arrange for a suitable appointment for an engineer to call under the terms of your guarantee. However, a charge may be made if any of the following applies to your machine:
Is found to be in working order.
Has not been installed in accordance with the
installation instructions.
Has been used incorrectly.
The dryer does not operate…
Is there a working electricity supply to the dryer? Check using another appliance such as a table lamp.
Is the plug properly connected to the mains supply?
Is there a power failure?
Has the fuse blown?
Is the door fully closed?
Is the dryer switched on, both at the mains
supply and at the machine?
Has the drying time or the programme been selected?
Has the machine been switched on again after opening the door?
Spares
Always use genuine spares, available direct from GIAS Service.
GIAS Service
For service and repairs call your local GIAS Service engineer.
The manufacturer declines all responsibility in the event of any printing mistakes in this booklet. The manufacturer also reserves the right to make appropriate modifications to its products without changing the essential characteristics.
EN 15
40008769
Loading...
