USER MANUAL
WINE COOLER
Please read this instruction booklet carefully before using your Candy Wine Cooler
19
Thank you for purchasing this product.
Before using your refrigerator, please carefully
read this instruction manual in order to
maximize its performance. Store all
documentation for subsequent use or for other
owners. This product is intended solely for
household use or similar applications such as:
- the kitchen area for personnel in shops,
offices and other working environments
- on farms, by clientele of hotels, motels and
other environments of a residential type
- at bed and breakfasts (B & B)
- for catering services and similar applications
not for retail sale.
This appliance must be used only for purposes
of storage of food, any other use is considered
dangerous and the manufacturer will not be
responsible for any omissions. Also, it is
recommended that you take note of the
warranty conditions. Please, to obtain the best
possible performance and trouble free
operation from your appliance it is very
important to carefully read these instructions.
Failure to observe these instructions may
invalidate your right to free service during the
guarantee period.
SAFETY INFORMATION
This guide contains many
important safety
information. Please, we
suggest you keep these
instructions in a safe
place for easy reference
and a good experience
with the appliance.
The refrigerator contains
a refrigerant gas (R600a:
isobutane) and insulating
gas (cyclopentane), with
high compatibility with
the environment, that
are, however,
inflammable.
Caution: risk of
fire
If the refrigerant circuit
should be damaged:
• Avoid opening flames
and sources of
ignition.
Thoroughly ventilate the
room in which the
appliance is situated.
WARNING!
• Care must be taken
while
cleaning/carrying the
appliance to avoid
touching the
condenser metal wires
at the back of the
appliance, as you
might injure your
fingers and hands or
damage your product.
20
• This appliance is not
designed for stacking
with any other
appliance. Do not
attempt to sit or stand
on top of your
appliance as it is not
designed for such use.
You could injure
yourself or damage
the appliance.
• Make sure that mains
cable is not caught
under the appliance
during and after
carrying/moving the
appliance, to avoid
the mains cable
becoming cut or
damaged.
• When positioning your
appliance take care
not to damage your
flooring, pipes, wall
coverings etc. Do not
move the appliance by
pulling by the lid or
handle. Do not allow
children to play with
the appliance or
tamper with the
controls. Our
company declines to
accept any liability
should the
instructions not be
followed.
• Do not install the
appliance in humid,
oily or dusty places,
nor expose it to direct
sunlight and to water.
• Do not install the
appliance near
heaters or
inflammable
materials.
• If there is a power
failure do not open
the lid. Frozen food
should not be affected
if the failure lasts for
less than 20 hours. If
the failure is longer,
then the food should
be checked and eaten
immediately or
cooked and then
refrozen.
21
• If you find that the lid
of the chest freezer is
difficult to open just
after you have closed
it, don’t worry. This is
due to the pressure
difference which will
equalize and allow the
lid to be opened
normally after a few
minutes.
• Do not connect the
appliance to the
electricity supply until
all packing and transit
protectors have been
removed.
• Leave to stand for at
least 4 hours before
switching on to allow
compressor oil to
settle if transported
horizontally.
• This freezer must only
be used for its
intended purpose (i.e.
storing and freezing of
edible foodstuff).
• Do not store medicine
or research materials
in the Wine Coolers.
When the material
that requires a strict
control of storage
temperatures is to be
stored, it is possible
that it will deteriorate
or an uncontrolled
reaction may occur
that can cause risks.
• Before performing any
operation, unplug the
power cord from the
power socket.
• On delivery, check to
make sure that the
product is not
damaged and that all
the parts and
accessories are in
perfect condition.
• If in the refrigeration
system a leak is noted,
do not touch the wall
outlet and do not use
open flames. Open
the window and let air
into the room. Then
call a service center to
ask for repair.
22
• Do not use extension
cords or adapters.
• Do not excessively pull
or fold the power cord
or touch the plug with
wet hands.
• Do not damage the
plug and/or the power
cord; this could cause
electrical shocks or
fires.
• If the supply cord is
damaged, it must be
replaced by the
manufacturer, its
service agent or
similarly qualified
person in order to
avoid a hazard.
• Do not place or store
inflammable and
highly volatile
materials such as
ether, petrol, LPG,
propane gas, aerosol
spray cans, adhesives,
pure alcohol, etc.
These materials may
cause an explosion.
• Do not use or store
inflammable sprays,
such as spray paint,
near the Wine
Coolers. It could cause
an explosion or fire.
• Do not place objects
and/or containers
filled with water on
the top of the
appliance.
• We do not
recommend the use of
extension leads and
multi-way adapters.
• Do not dispose of the
appliance on a fire.
Take care not to
damage, the cooling
circuit/pipes of the
appliance in
transportation and in
use. In case of damage
do not expose the
appliance to fire,
potential ignition
source and
immediately ventilate
the room where the
appliance is situated.
23
• The refrigeration
system positioned
behind and inside the
Wine Coolers contains
refrigerant. Therefore,
avoid damaging the
tubes.
• Do not use electrical
appliances inside the
food storage
compartments of the
appliance, unless they
are of the type
recommended by the
manufacturer.
• Do not damage the
refrigerant circuit.
• Do not use mechanical
devices or other
means to accelerate
the defrosting
process, other than
those recommended
by the manufacturer.
• Do not use electrical
appliances inside the
food storage
compartments, unless
they are of the type
recommended by the
manufacturer.
• Do not touch internal
cooling elements,
especially with wet
hands, to avoid cracks
or injuries.
• Maintain the
ventilation openings in
the appliance
enclosure or in the
built-in structure, free
of obstruction.
• Do not use pointed or
sharp-edged objects
such as knives or forks
to remove the frost.
• Never use hairdryers,
electrical heaters or
other such electrical
appliances for
defrosting.
• Do not scrape with a
knife or sharp object
to remove frost or ice
that occurs. With
these, the refrigerant
circuit can be
damaged, the spill
from which can cause
a fire or damage your
eyes.
24
• Do not use mechanical
devices or other
equipment to hasten
the defrosting
process.
• Absolutely avoid the
use of open flame or
electrical equipment,
such as heaters, steam
cleaners, candles, oil
lamps and the like in
order to speed up the
defrosting phase.
• Never use water wash
the compressor
position, wipe it with a
dry cloth thoroughly
after cleaning to
prevent rust.
• It is recommended to
keep the plug clean,
any excessive dust
residues on the plug
can be the cause fire.
• The product is
designed and built for
domestic household
use only.
• The guarantee will be
void if the product is
installed or used in
commercial or non-
residential domestic
household premises.
• The product must be
correctly installed,
located and operated
in accordance with the
instructions contained
in the User
Instructions Booklet
provided.
• The guarantee is
applicable only to new
products and is not
transferable if the
product is resold.
• Our company
disclaims any liability
for incidental or
consequential
damages.
• The guarantee does
not in any way
diminish your
statutory or legal
rights.
• Do not perform
repairs on this Wine
Coolers. All
interventions must be
25
performed solely by
qualified personnel.
SAFETY CHILDREN!
• If you are discarding
an old product with a
lock or latch fitted to
the door, ensure that
it is left in a safe
condition to prevent
the entrapment of
children.
• This appliance can be
used by children aged
from 8 years and
above and by persons
with reduced physical,
sensory or mental
capabilities or with a
lack of experience and
knowledge; provided
that they have been
given adequate
supervision or
instruction concerning
how to use the
appliance in a safe
way and understand
the hazards involved.
• Children should not
play with the
appliance. Cleaning
and user maintenance
should not be made
by children without
supervision.
26
PARTS AND FEATURES
REVERSIBLE DOOR
1.GLASS DOOR
2.LAMP SWITCH
3.USER INTERFACE
4.CABINET
5.CHROME WINE SHELVES
6.CHROME WINE SHELVES
7.FOOT
8.LED
INSTALLATION INSTRUCTIONS
Before Using Your Wine Cooler
• Remove the exterior and interior packing,
including protective foam on door panels.
• Check to be sure the following parts are
included:
o 6 slide out shelves
o 2 wine rack
o 1 user manual
• Before connecting the appliance to the
power source, let it stand upright for
approximately 2 hours. This will reduce the
possibility of a malfunction in the cooling
system from handling during transportation.
• Clean the interior surface with lukewarm
water using a soft cloth.
Installation of Your Wine Cooler
• Place your appliance on a floor that is
strong enough to support the appliance
when it is fully loaded. To level your
appliance, adjust the legs at the front of
the appliance.
• Allow 5 inches of space between the back
and sides of the appliance, which allows
the proper air circulation to cool the
compressor.
• Locate the appliance away from direct
sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight may
affect the acrylic coating and heat sources
may increase electrical consumption.
• Extreme cold ambient temperatures may
also cause the appliance not to perform
properly.
• Avoid locating the appliance in moist
areas. Too much moisture in the air will
cause frost to form quickly on the
evaporator.
• Plug the appliance into an exclusive
properly installed-grounded wall outlet.
Do not under any circumstances cut or
remove the third (ground) prong from the
power cord.
• Any questions concerning power and or
grounding should be directed toward a
certified electrician or an authorized
products service center.
Warning: Improper use of the grounded plug
can result in the risk of electrical shock. If the
power cord is damaged, have it replaced by
an authorized products service center.
EXTERNAL HANDLE
If the external handle is presented in the
product, follow the below steps for assembly.
27
Reversing the Door Swing of Your
Wine Cooler
This wine cooler has the capability of either
opening the door from the left or right side.
The unit is delivered to you with the door
opening from the left side. Should you desire
to reverse the opening direction, please follow
the instruction.
NOTE:
Before reversing the door, the power must be
shut off.
All parts removed must be saved to do the
reinstallation of the door.
① Get ready of
the product
on a flat
floor.
② Take out the
external
handle and 4
screws.
③ Use a
magnetic
cross screw
driver to fix
the external
handle on
the 4 prescrew holes.
④ Check and
make sure all
screws are
fixed well
① Prepare the
product and
tools
② Remove the
upper hinge cover
first
③ Remove the
screws that hold the
upper hinge (right
side) and take away
the upper hinge
④ Remove the
hole covers to the
left side.
⑤ Lift the door and
place it on a
protective place
⑥ Remove the
screws that hold
the lower hinge
⑦ Install the lower
hinge onto the left
opposite side
⑧ Refit the door
to the left hinge
and then screw
the left upper
hinge. After fixing
the hinge cover,
then complete the
reversing process.
28
WARNING: If the external handle is presented
in the product, the wine cooler has NO
capability of either opening the door from the
left or right side.
IMPORTANT SAFEGUARDS
Do not store food in wine cooler, as interior
temperature may not get cool enough to
prevent spoilage. As a natural result of
condensation, in summer months or area of
high humidity, the glass door may build up
moisture on the outside. Just wipe it away.
OPERATING YOUR WINE COOLER
It is recommended you install the wine cooler
in a place where the ambient temperature is
between 22 -25 degree Celsius. If the ambient
temperature in above of below the
recommended temperature, conditions may
cause interior temperature to fluctuate.
If the interior light is left on, the temperature
inside the wine cooler will be higher.
Recommended Temperatures for chilling
Wine
Temperature
Position
Red wines:
15.5-18.5 C
1-2
Dry/White
Wines
10-15 C
2-3
Sparkling
Wines
7.2-9.5 C
5-6
Rose Wines
9.5-10.5 C
4-5
The above temperatures may fluctuate
depending on whether or not the interior bulb
is on or off of whether the bottles are located
on the lower/middle or lower section.
CANDY MECHANICAL
This specification concerns the function of the
mechanical control for wine cellars. The image
below shows the Candy version of the user
interface.
The user interface is formed by:
- 1 knob for temperature setting
- 1 side button for the light
Function
Rotating the thermostat knob you can adjust
the temperature of the wine cellar to the
preset level.
SHELVES
Shelf is chrome plated. To accommodate
different size bottles, they can be moved up or
down by sliding them out the tracks first.
Shelves are designed to accommodate
maximum amount of bottles.
WINE RACK
There is an additional wine rack at bottom
section of the unit where you can store up to 6
wine bottles. This rack is removable for
cleaning purpose.
There is a 4 to 6 C variance between the top
and bottom shelves of the wine chiller.
Therefore, if you have set the wine chiller for
red wine only and you want to place a mix of
white and red wines, you should place the
white wine bottles on the bottom shelves and
the red wines on the top shelves.
CARE AND MAINTENANCE
Cleaning Your Wine Cooler
• Unplug the wine cooler and remove the
bottles.
• Wash the inside with a warm water and
baking soda solution. The solution should be
about 2 tablespoons of baking soda to a liter
of water.
• Wash the shelves and trays with a mild
detergent solution.
• The outside of the wine cooler should be
cleaned with mild detergent and warm
water.
• It may also be necessary to periodically wipe
the bottom part of the storage area, as the
29
wine cooler is designed to retain humidity,
and condensation may collect there.
Maintenance of Your Wine Cooler
Power Failure
Most power failures are corrected within a few
hours and should not affect the temperature
of your wine cooler if you minimize the
number of times the door is opened. If the
power is going to be off for a longer period of
time, you need to take the proper steps to
protect your contents.
Vacation Time
During long absences, remove all the bottles;
unplug your wine cooler, clean your wine
cooler, and leave the door open slightly to
avoid possible formation of condensation,
mold, or odors.
Moving Your Wine Cooler
• Remove all the bottles.
• Securely tape down all loose items inside
your wine cooler.
• Turn the levelling screws up to the base to
avoid damage.
• Tape the doors shut.
• Be sure the wine cooler stays in the upright
position during transportation.
TROUBLESHOOTING
You can solve many common wine cooler
problems easily, saving you the cost of a
possible service call. Try the suggestions below
to see if you can solve the problem before
calling the servicer.
PROBLEM
POSSIBLE CAUSE
Wine cooler does
not operate.
Not plugged in.
The circuit breaker
tripped or blown
fuse.
Wine cooler is
not cold enough.
Check to be sure
the temperature
control setting.
External
environment may
require a higher
setting.
The door is opened
too often.
The door is not
closed completely.
The door gasket
does not seal
properly.
The wine cooler
does not have the
correct clearances.
Compressor turns
on and off
frequently.
The room
temperature is
hotter than
normal.
A large amount of
contents has been
added to the wine
cooler.
The door is opened
too often.
The door is not
closed completely.
The temperature
control is not set
correctly.
The door gasket
does not seal
properly.
The wine cooler
does not have the
correct clearances.
The light does not
work.
The home circuit
breaker or fuse has
tripped.
The wine cooler is
unplugged.
The bulb has
burned out.
The switch is in the
"OFF" position.
Vibrations.
Check to assure
that the wine
cooler is level.
The wine cooler
seems to make
too much noise.
The rattling noise
may come from the
flow of the
refrigerant, which
is normal.
As each cycle ends,
you may hear
gurgling sounds
caused by the flow
of refrigerant in
your wine cooler.
Contraction and
expansion of the
inside walls may
30
cause popping and
crackling noises.
The wine cooler is
not level.
The door will not
close properly.
The wine cooler is
not level.
The doors were
reversed and not
properly installed.
The gasket is dirty.
The shelves are out
of position.
Technical specifications:
For detailed specifications, please refer to the
nameplate at the back of the wine cellar. The
specifications are subject to change without
prior notice due to products improvement.
31
SCRAPPING OLD APPLIANCES
This appliance is marked according to the
European directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE).
WEEE contains both polluting substances
(which can cause negative consequences for
the environment) and basic components
(which can be re-used). It is important to have
WEEE subjected to specific treatments, in
order to remove and dispose properly all
pollutants, and recover and recycle all
materials.
Individuals can play an important role in
ensuring that WEEE does not become an
environmental issue; it is essential to follow
some basic rules:
WEEE should not be treated as household
waste.
WEEE should be handed over to the relevant
collection points managed by the municipality
or by registered companies. In many countries,
for large WEEE, home collection could be
present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is
of equivalent type and has the same functions
as the supplied equipment.
Conformity
By placing the mark on this product, we
are confirming compliance to all relevant
European safety, health and environmental
requirements which are applicable in
legislation for this product.
ENERGY SAVING
For better energy saving we suggest:
• Installing the appliance away from heat
sources and not exposed to direct sunlight
and in a well-ventilated room.
• Avoid putting hot food into the refrigerator
to avoid increasing the internal temperature
and therefore causing continuous
functionalizing of the compressor.
• Do not excessively stuff foods so as to
ensure proper air circulation.
• Defrost the appliance in case there is ice to
facilitate the transfer of cold.
• In case of absence of electrical energy, it is
advisable to keep the refrigerator door
closed.
• Open or keep the doors of the appliance
open as little as possible.
• Avoid adjusting the setting to temperatures
too cold.
• Remove dust present on the rear of the
appliance.
Loading...
