MOUNTAIN SERIES 2 BURNER HIGH OUTPUT STOVE

CARE, USE AND SAFETY INSTRUCTIONS

To consumer: Keep this manual for future reference. This
instruction manual contains important information necessary
for the proper assembly and safe use of this product.

Read and follow all warnings and instructions before
assembling and using the appliance.

Follow all warnings and instructions when using the appliance.

DO NOT DISCARD THIS INSTRUCTION MANUAL.

For outdoor use only.

Model #: MS2HP

CAUTION: This is a High Output stove. Use low heat with
griddles. Do Not put empty cookware over burners, damage
may occur.

If using both burners on high for an extended period, the
output may decrease. This is caused by a build-up of frost in the
tank connection. This is normal. This can be avoided by using a
20 lb bulk tank and optional bulk tank hose adaptor. (HRDSP)

PO Box 4057 • Logan, UT 84323

1.800.650.2433 or 1.435.752.3922

FOR YOUR SAFETY

If you smell gas:

1. Do not attempt to light the appliance.

2. Extinguish any open ame.

3. Disconnect from fuel supply.

FOR YOUR SAFETY

Do not store or use gasoline or other liquids with
ammable vapors in the vicinity of this or any other
appliance.

CARBON MONOXIDE HAZARD

This appliance can produce carbon monoxide which has
no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a
camper, tent, car or home.

PARTS LIST

Valve Train

MS-116

Pot Grate

MS-114

Burner Assembly

MS-115

Ignitor

MS-102

Regulator

MS-104

Knob

MS-103

1. DO NOT leave this appliance unattended
while in use. The user must remain in the
immediate area of the product and have a
clear view of the product at all times during
operation.

2. Keep children and pets away from burner
at all times.

3. The use of alcohol, prescription or non­prescription drugs may impair your ability
to properly assemble or safely operate this
appliance.

4. For OUTDOOR use only. Do NOT use in a

building, garage or any other enclosed
area. Do NOT use in or on recreational
vehicles or boats. NEVER use this appliance
as a heater.

5. Do not operate appliance under ANY
overhead construction. Keep a minimum
clearance of 1 foot (0.3 m) from the
sides, front and back of appliance to
ANY construction. Keep the area clear of
all combustible material and flammable
liquids, including wood, dry plants and
grass, brush, paper, and canvas. Never use
this appliance within 25 ft. (7.5 m) of
any flammable liquid.

6. Use ONLY on a level, stable surface.

7. DO NOT place an empty cooking vessel
on burner while in operation. Use caution
when placing anything in the cooking
vessel while burner is in operation.

8. Do NOT move the appliance when in use.
Allow unit to cool to 115°F (45°C) before
moving or storing.

9. This appliance will be hot during and after
use. Use insulated oven mitts or gloves for
protection from hot surfaces or splatter
from cooking liquids.

10. In case there is a fire, call the local fire

department or dial 911. Stay clear from
flames. Do not attempt to extinguish an
oil or grease fire with water.

11. Do not obstruct the flow of combustion

and ventilation air.

NOTE: This appliance is set to use 16.4 oz.
disposable propane cylinders. Use only cylinders
marked propane. Disposable propane cylinders
must be disconnected from the stove when it is in
storage.
Refillable Bulk LP-Gas Tanks with a maximum
capacity of 20 pounds may also be used with an
optional bulk tank adapter hose. (Use Camp
Chef Model HRDSP to connect to the bulk tank.)
Refillable propane gas cylinders must be turned off
at the LP-Gas supply cylinder when the stove is not
in use.
The LP-gas cylinder(s) used with this stove must
be constructed and marked in accordance with
the specifications for LP-gas cylinders of the U.S.
Department of Transportation or Transport Canada,

CAN/CSA B339.

Setup Using Disposable Bottle

1. Make sure burner valves are off.

2. Remove plastic cap from top of propane
cylinder. Save cap for use in storing. Screw
propane cylinder into regulator. Be careful
not to cross thread. Hand Tighten only.

3. Check the connection between the cylinder
and the regulator with soapy water.
Bubbles indicate a leak. Check that the
connection is not cross-threaded and that
it is tight. Perform another leak check. If
there is still a leak, remove the cylinder and
contact the manufacturer for service or
repair.

Leak Test

4. The regulator uses a threaded fitting to
attach to the stove. It is necessary to hold
the stove to make sure the fitting is seated.
Align the regulator to the fuel tube on the
rear of the stove and push on. Screw on
the outer threaded sleeve in a clockwise
direction until tight.

5. Never operate stove with propane cylinder
in an inverted position.

Setup Using Optional Hose And Refillable
Cylinder

1. Make sure burner valves are off.

2. Attach Camp Chef Model HRDSP hose to
regulator & regulator to stove (as shown).

3. Attach hose to cylinder.

4. Open cylinder valve.

5. Perform leak check on hose to regulator,
and hose to cylinder connections with soapy
water. Bubbles indicate a leak. Check that
the connection is not cross-threaded and
that it is tight. Perform another leak check.
If there is still a leak, remove the cylinder
and contact the manufacturer for service
and repair.

Leak Check

Regulator
& Hose

6. Turn off fuel at the cylinder and disconnect
both ends of the hose when not in use.

Dismantling Hose And Refillable Cylinder

1. Before dismantling high pressure hose, be
sure gas pressure in hose is eliminated.

2. Ignite stove and turn off gas valve on
cylinder.

3. Allow flame to self-extinguish.

4. When flame is out, close valves on the
appliance.

5. Remove hose.

Installation Safety Precautions

• Use appliance only with LP (propane) gas

and the regulator/valve assembly supplied.

• Appliance is not for use in or on

recreational vehicle and/or boats.

• Do not modify this appliance. Modifications

will result in a safety hazard. Questions
regarding certification in other areas may be
addressed to 1-435-752-3922.

• Apartment Dwellers: Check with

management to learn the requirements and
fire codes for using an LP Gas appliance at
an apartment. If allowed, use outside on the
ground floor with a 10 foot clearance from
walls or rails.

• Before opening LP tank valve, check the

coupling nut for tightness. When appliance
is not in use, turn off control knob and LP

tank valve on supply cylinder.

• Never use LP tank if visibly rusted, damaged,
or out of date.

• If you notice grease or other hot material
dripping from appliance onto valve, hose
or regulator, turn off gas supply at once.
Determine the cause, correct, clean and
inspect valve, hose and regulator before
continuing. Perform a leak test.

• The regulator may make a humming or
whistling noise during operation. This will
not affect the safety or use of appliance.

• Clean and inspect the hose before each
use of the appliance. If there is evidence of
abrasion, wear, cuts or leaks, the hose must
be replaced prior to the appliance being put
into operation. See product tag for hose &
regulator information.

• Do not block holes in bottom or sides of
appliance.

• Never operate appliance with LP tanks out
of correct position specified in Assembly
Instructions.

WARNING

Combustion by-products produced
when using this product contain
chemicals known to the State of
California to cause cancer, birth
defects, or other reproductive harm.

• Always close LP tank valve and remove
coupling nut before moving LP tank form
specified operating position.

• NEVER store a spare LP tank under or near
appliance or in enclosed areas. NEVER fill
the cylinder beyond 80% full. An overfilled
spare LP tank is hazardous due to possible
gas released from the safety relief valve.
Failure to follow these instructions exactly
could cause a fire resulting in death or
serious injury.

• If you see, smell, or hear escaping gas,
immediately get away from the LP tank/
appliance and call your fire department.

• All spare LP tanks must have safety caps
installed on the LP tank outlet.

WARNING

Hose is a trip hazard

24 “

LP Tank Removal, Transport and Storage

• Turn OFF all control knobs and LP tank valve.
Turn coupling nut counterclockwise by hand
only – do not use tools to disconnect. Install
safety cap onto LP tank valve. Always use
cap and strap supplied with valve. Failure
to use safety cap as directed may result
in serious personal injury and/or property
damage.

safety cap

• A disconnected LP tank in storage or
being transported must have a safety
cap installed (as shown). Refillable LP­Gas cylinders must be stored outdoors in
a well ventilated space, out of the reach
of children, and must not be stored in a
building, garage or any other enclosed area.
Never leave an LP tank inside a vehicle,
which may become overheated by the sun.

• Do not store LP tanks in an area where
children play.

• Storage of an appliance indoors is
permissible only if the cylinder is
disconnected and removed from the
appliance.

• When the refillable LP-gas supply cylinder is
not disconnected from the stove, the stove
and cylinder must be stored outdoors, in
a well ventilated space, out of the reach
of children, and must not be stored in a
building, garage or any other enclosed
areas.

LP Tank

The LP tank used with your appliance must
meet the following requirements:

• Purchase LP tanks only with these required
measurements: 12” (30.5cm) (diameter) x
18” (45.7cm) (tall) with 20 lb. (9 kg.) capacity
maximum.

• Be constructed and marked in accordance
with specifications for LP tank of the U.S.
Department of Transportation (DOT) or
the National Standard of Canada, CAN/
CSA-B339, Cylinders, Spheres and Tubes
for the Transportation of
Dangerous Goods.

• The refillable propane
cylinder used with this
appliance must include
a collar to protect the
cylinder valve.

LP tank valve must have:

• Type 1 outlet compatible with regulator or
appliance.

• Safety relief valve.

• UL listed Overfill Protection Device (OPD).
This OPD safety feature is identified
by a unique triangular hand wheel. Use
only tanks equipped with this type of
valve. LP tank must be arranged for vapor
withdrawal.

LP (Liquefied Petroleum Gas)

• LP gas is non-toxic, odorless and colorless
when produced. For Your Safety, LP gas
has been given an odor (similar to rotten
cabbage) so that it can be smelled.

• LP gas is highly flammable and may ignite
unexpectedly when mixed with air.

LP Tank Filling

• Use only licensed and experienced dealers.

• LP dealer must purge tanks before filling.

• Dealer should NEVER fill LP tank more than
80% of LP tank volume. Volume of propane
in tanks will vary by temperature.

• A frosty regulator indicates gas overfill.
Immediately close LP tank valve and call
local LP gas dealer for assistance.

• Do not release liquid propane (LP) gas
into the atmosphere. This is a hazardous
practice.

• To remove gas from LP tank, contact an LP
dealer or call a local fire department for
assistance. Check the telephone directory
under “Gas companies” for nearest certified
LP dealers.

LP Tank Exchange

• Many retailers that sell appliances offer you
the option of replacing your empty LP tanks
through an exchange service. Use only those
reputable exchange companies that inspect,
precision fill, test and certify their cylinders.
Exchange your tank only for an OPD safety
feature-equipped tank as described in the
“LP Tank” section of this manual.

• Always keep new and exchanged
LP tanks in upright position during use,
transit or storage.

• Leak test new and exchanged
LP tanks BEFORE connecting to appliance.

LP Tank Leak Test For your Safety

• Leak test must be repeated each time LP
tank is exchanged or refilled.

• Do not smoke during leak test.

• Do not use an open flame to check for gas
leaks.

OPD Hand Wheel

• Appliance must be leak checked outdoors
in well-ventilated area, away from ignition

sources such as gas fired or electrical
appliances. During leak test, keep appliance
away from open flames or sparks.

Use a clean paintbrush and 50/50 soap and
water solution. Use mild soap and water. Do
not use household cleaning agents. Damage
to gas train components
can result. Brush soapy solution onto all weld
seams and entire valve area.

WARNING

If “growing” bubbles appear, do not
use or move the LP tank. Contact
an LP gas supplier or your fire
department.

Connecting Regulator To The LP Tank

Only use the pressure regulator & hose
supplied with this appliance. See assembly
instructions or appliance name tag for
regulator model number.

1. Place LP tank on a secure,
level, and stable surface.

2. Turn control knob to the
OFF position.

3. Turn LP tank OFF by turning
hand wheel clockwise to a
full stop.

4. Remove the protective cap
from LP tank valve. Always use cap and
strap supplied with valve.

Do not use a POL transport
plug (plastic part with
external threads)! It will
defeat the safety feature of
the valve.

5. Hold regulator, insert nipple (B) into LP
tank valve. Hand tighten coupling nut,
holding regulator in a straight line (C) with
LP tank valve so as not to cross thread the
connection.

(B) Nipple has to be
centered into the
LP tank valve

6. Turn the coupling nut clockwise to tighten
to a full solid stop. The regulator will seal
on the back-check feature in LP tank valve,
resulting in some resistance. An additional
one-half to three quarters turn is required
to complete connection. Tighten by hand
only – do not use tools.

(C) Hold coupling
nut and regulator
as shown for
proper connection
to LP tank valve

NOTE: If you cannot complete connection,
disconnect regulator and repeat steps 5 and

6. If you are still unable to complete the

connection, do not use this regulator!

• Do not insert any foreign objects into the

valve outlet. You may damage the valve and
cause a leak. Leaking propane may result
in explosion, fire, severe personal injury, or
death.

• Never attempt to attach this appliance to

the self-contained LP gas system of a camper
or trailer or motor home.

Leak Testing Valves, Hoses and Regulator

1. Turn all control knob(s) to OFF.

2. Be sure regulator is tightly connected to LP
tank.

3. Completely open LP tank valve by turning
hand wheel counter clockwise. If you hear
a rushing sound, turn gas off immediately.
There is a major leak at the connection.
Correct before proceeding.

4. Brush soapy solution onto indicated
connections shown at right.

5. If “growing” bubbles appear, there is a
leak. Close LP tank valve immediately and
retighten connections. If leaks cannot
be stopped, do not try to repair. Call for
replacement parts. Order new parts by
giving the serial number, model number
and name of items needed to the Service
Center at 1-435-752-3922.

WARNING

• Do not use appliance until leak

checked.

• If you cannot stop a gas leak,

immediately close LP tank valve
and call LP gas supplier or your
fire department!

6. Always close LP tank valve after performing
tank leak test by turning hand wheel
clockwise.

Setup Instructions:

• Place stove on a flat, level, sturdy surface.

• Open the lid and attach the windscreens to

the tabs on the inside of the lid. Snap into
place as shown.

• Make sure the burners are in the off

position.

• Push regulator assembly firmly into

stove. Tighten nut securely.

• Screw propane cylinder into the regulator.

WARNING

• Do not put hands or any other body

parts over the burner during lighting
or when in use to prevent burns.

Lighting Stove Instructions:

1. Turn burner valve on and press the red
ignitor button until the burner lights.

2. If ignition does not occur in 5 seconds, turn
the burner control(s) off, wait 5 minutes,
and repeat lighting procedure. If built-in
ignitor will not light follow the preceding
steps and hold a lit long igniter or match

next to the burner when opening the
control valve.

3. Adjust the flame to the desired height.
Flame should be compact and blue in color.

4. Avoid getting dirt in the valves, regulator,
and burners.

5. To shut burner off, turn the valve to off.
(Clockwise)

If the flame is accidentally extinguished, turn
the appliance valves OFF and WAIT 5 minutes
before attempting to ignite.

Burner Flame Check

• Light burner; rotate knob(s) from HIGH to

LOW. You should see a smaller flame in
LOW position than seen on HIGH. Always
check flame prior to each use. A good flame
should be blue with minimal yellow tip.
Some yellow tips on flames are acceptable as
long as no carbon or soot deposits appear.

Turning LP Cooker Off

• Turn all knobs to OFF position. Turn LP tank

OFF by turning hand-wheel clockwise to a
full stop.

Hose Check

• Before each use, check to

see if hoses are cut or worn. Replace
damaged hose assembly before using
appliance. Use only valve/ hose / regulator
specified by manufacturer. See product sheet
for hose & regulator information.

Cleaning The Burner

NOTE: Spiders and small insects can spin
webs and build nests inside the burner. This
especially occurs in late summer and fall
before frost when spiders are most active.
These nests can obstruct gas flow and cause

CAUTION

All cleaning and maintenance should
only be done when the appliance is
cool and with the fuel supply turned

off at the LP cylinder. DO NOT clean
any part in a self-cleaning oven. The

extreme heat will damage the finish.

a fire in and around the burner and orifice.
Such a fire can cause operator injury and
serious damage to the appliance. To help
prevent a blockage and ensure full heat
output, clean and inspect burner tube often
(once or twice a month). NOTE: Water or air
pressure will not normally clear a spider web.

Cleaning and Maintenance

Correct care and maintenance will keep
your appliance operating smoothly. Clean
regularly as determined by the amount of
use. NOTE: Clean the entire appliance each
year and tighten all hardware on a regular
basis (1-2 times a year or more depending
on usage). Cleaning should be done where
detergents won’t harm patio, lawn, or the
like. Keep appliance area clear and free
from combustible materials, gasoline and
other flammable vapors and liquids. Keep
the ventilation opening(s) of the cylinder
enclosure free and clear from debris.

Suggested Cleaning Materials

• Mild dish washing liquid detergent

• Wire brush

• Nylon cleaning pad

• Hot water

• Paper clip

• Soft brass bristled brush

Component Cleaning:

• Burner should be wiped clean. Hot soapy
water and a soft bristle brush can be used
to clean the burner surfaces. Clean clogged
gas port holes with an opened paper clip.
Replace corroded or damaged burners that
would emit excess gas.

• COOKING SURFACES, POTS AND PANS: Clean
the cooking surface with soapy water and a
nylon cleaning pad.

• After appliance has cooled, wipe areas
where paint and finish have burned off to
minimize rusting.

LIMITED WARRANTY

To activate warranty, register on-line at:

www.CampChef.com

The manufacturer warrants stove compo-

nents (except paint and finish) to be free

from defect in materials and workmanship

for 1 year from the date of purchase. All ac-

cessories (included with stove or purchased

separately) are warranted from defect in

materials and workmanship for 90 days

from the original purchasing date. Within

these periods, the manufacturer will replace

or repair defective parts deemed unusable

from its original intent by making available

the parts thereof FOB Logan, UT 84321

Product paint and finish is not warranted.

The exterior finish of the product will wear

down over time.

Clean the unit after each use to maintain

the finish and prolong the life of your prod-

uct. Wipe away all grease and ashes. Keep

metal products free of moisture, salts, acids

and harsh fluctuations in temperatures.

Warranty does not cover normal wear of

parts or damage caused by misuse, abuse,

overheating and alteration. Repairs or
alterations made by anyone other than
Camp Chef are not covered in this War-

ranty. Manufacturer will not be held liable

for any losses due to neglectful operation.

Furthermore, this Warranty does not cover

damaged caused by natural disasters such

as earthquakes, hurricanes, tornadoes,

floods, lightning, fires, etc.

Upon the expiration of this warranty all

such liability will terminate. No other

warranties are expressed or implied.

Keep all original sales receipts. Proof of

purchase is required to obtain Warranty

services. Prior written approval and a

Return Authorization Number must be

obtained and accepted for repair or

replacement only. Returns must be shipped

prepaid. Collect shipment or shipments

without a Return Authorization Number

will not be accepted.

To obtain Warranty services call

1.800.650.2433.

*Warranty applies to the contiguous US

states only.

MOUNTAIN SERIES 2 BRÛLEURS, / COMBO CUISINIÈRE

SOINS, L’UTILISATION ET CONSIGNES DE SECURITE

• À l’intention de l’installateur ou de la personne qui assemble
l’appareil: Conserver cette notice avec l’appareil pour
référence ultérieure.

• À l’attention du consommateur: Conserver cette notice
pour référence ultérieure.

Cette notice contient des reseignements importants permettant
un assemblage adéquat et à une utilisation sécuritaire de
l’appareil.

Lire et suivre toutes les mises en garde et toutes les instructions
avant l’assemblage et l’utilisation de l’appareil.
Suivre toutes les mises en garde et toutes les instructions lors de
l’utilisation de l’appareil.

NE PAS JETER CETTE NOTICE D’UTILISATION.

Numéro de modèle: MS2HP

FOR YOUR SAFETY

Si vous sentez une odeur de gaz:

1. Coupez l’admission de gaz de l’appareil.

2. Ouvrir le couvercle.

3. Si l’odeur persiste, appelez immédiatement votre
fournisseur de gaz ou votre service des incendies.

FOR YOUR SAFETY

Ne pasentreposer ni utiliser d’essence ni d’autres vapeurs
ou liquides inflammables à proximité de cet appareil ou
de tout autre appareil

CARBON MONOXIDE HAZARD

Cet appareil peut produire du monoxyde de carbone, un
gaz inodore.
L’utilisation de cet appareil dans des espaces clos peut
entraîner la mort
Ne jamais utiliser cet appareil dans un espace clos comme
un véhicule de camping, une tente, une automobile ou
une maison.

Pour usage en plein air uniquement.
ATTENTION: Il s’agit d’un poêle à haut rendement. Cuire à feu
doux avec plaques de cuisson. Ne pas mettre cuisson vides sur
les brûleurs, des dommages peuvent survenir.

Si vous utilisez les deux brûleurs à puissance élevée pendant une
période prolongée, la sortie peut diminuer. Ceci est causé par une
accumulation de givre dans le raccord de réservoir. Ceci est normal.
Ceci peut être évité en utilisant un réservoir de 9 kg en vrac et
adaptateur en option vrac tuyau de réservoir. (HRDSP)

PO Box 4057 • Logan, UT 84323

1.800.650.2433 or 1.435.752.3922
