Bushnell Neo Ion Quick Start Guide
Quick Start Guide
www.bushnellgolf.com
®
12-15
Golf Menu
1
BUTTONS / FUNCTIONS
Up
3
Select
4
2
Menu
1. Golf Menu Button: View Golf Menu
2. MENU Button: View Main Menu Options.
3. UP Button: Scrolls up through Menu items.
4. SELECT Button: Selects from menu items.
5. DOWN Button: Scrolls down through menu items. Press & hold (7 seconds) to power on/o.
1
5
Down/
Power
*Note: Backlight is activated with any button push. The backlight will remain lit for 10 seconds after last button push.
Backlight is disabled in Play Golf Mode.
A full user manual detailing the additional features of the Neo iON can be downloaded at:
www.bushnellgolf.com or www.bushnellgolf.eu.
Care and Maintenance
The Neo iON watch is durable and waterproof. To help ensure reliable operation, the following care and maintenance
guidelines are recommended :
• Avoid exposing the watch to extreme environmental conditions for a prolonged period of time.
• Avoid severe impacts on the watch.
• You may clean the watch occasionally with a soft, damp cloth.
• Brush the clip contacts at the bottom of the watch regularly. Dirt build-up on the surface of the contact points may
aect normal charging and data transfer. *Note: Use a soft-bristled brush (included). Hard bristles or wire brushes
may leave scratches on the watch.
• DO NOT expose the watch to strong chemicals such as gasoline and alcohol, as they will damage the watch.
• Store the watch in a dry place when it is not in use.
Charging the Battery
The rechargeable battery of the Neo iON Watch is long lasting and provides up to 3 rounds of golf (based upon average
of 4 hours per round), or one year of use as an everyday (time only) watch. However, battery life may be reduced due to
a variety of factors (external temperature, etc). All rechargeable batteries lose their eective charge length over time.
Charging your battery with one bar remaining (Fig. 1, next page) will guarantee that you will be able to make through
the entire next round.
To check your remaining battery life, press the MENU button (2) and select BATTERY. To recharge the battery, insert the
watch into the charging cradle, with the charge contacts on the back of the watch (Fig 2) lined up with the charge pins on
the left side of the cradle (Fig 3). Then, connect the charging cradle to an open USB port on your computer, a powered USB
hub, or smartphone AC charger. Look for the scrolling battery icon to indicate that your Neo iON watch is charging (make
sure to connect from either the Home (Time) screen (as seen on pg. 1) or from the BATTERY screen (Fig 1).
2
Charge Contacts
Charge Pins
Fig. 1
Package Contents
1 - Bushnell Neo iON GPS Rangender Watch
1 - Charging Cradle w/USB Cable
1 - Contact Cleaning Brush
1 - Quick Start Guide
Computer Requirements
USB Port
OS: Windows (XP or later), Mac (OS 10.6 or later)
Firmware/Software Updates
Please check www.bushnellgolf.com or www.bushnellgolf.
eu periodically for the latest rmware and software releases.
SETTING THE TIME
Set Time by GPS
*To ensure reception, make sure you are outdoors away from tall buildings and trees, with a clear view of the sky.
This is the easiest way to set the time. From the TIME Options Menu (Fig. 4), select SET TIME, then select BY GPS from the
Fig. 2
Fig. 3
Charging Cradle
Watch on Charging Cradle
3
