Instruction manual
CTT5
You’ll soon be enjoying your new Turntable.
It all begins here, with your instructions. Don’t worry, there’s
nothing too technical coming up. Just simple, step-by-step
guidance to get you up and running quickly. Sound good? Then
let’s get started.
Help and Guidance
We’re here to help you get the most from your Turntable. Should you require any
guidance, a simple solution can often be found online at:
www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 600 3021.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Contents
Safety information
1
Safety information 6
Getting to know your Turntable
2
Ready? Let’s begin 10
Accessories 10
Features 11
Connecting to an external sound system 13
Listening to an external source 14
Handling vinyl 14
Fitting the dust cover 15
Using your Turntable
3
Getting started 18
Connecting the power 18
Turn the power On/Off 18
Play a record 19
Replacing the turntable stylus (needle) 19
Other information
4
Care & maintenance 22
Technical specification 22
Product support
5
Troubleshooting 24
Disposal 25
Help and assistance 26
Guarantee 27
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
3
1Safety information
Safety information
Important - Please read these instructions fully before
installing or operating
Power source
• This symbol means that this unit is double insulated. An earth connection is
not required.
• The appliance must be connected to a 100-240 volt 50/60Hz AC supply by
means of a three pin socket.
• Unplug this apparatus during lightning storms or when unused for long
periods of time - to prevent damage to this product.
• Opening or removing covers may expose you to dangerous voltages or other
hazards.
• To prevent risk of fire or electric shock, avoid overloading wall outlets,
extension cords, or integral convenience receptacles.
• Use suitable power sources - Plug the product into a suitable power source, as
described in the operating instructions or as marked on the product.
• The supply voltage should be the same as that indicated in the technical
specifications and the appliance rating plate.
• If the socket outlets in your home are not suitable for the plug supplied with
this unit check with a qualified electrician for replacement.
• In order to disconnect the apparatus from the mains completely, switch off
the outlet and remove the mains plug completely.
• Do not bend, stretch or pull the supply cable in order to avoid electric shock.
• When installed, the power socket must be within easy reach.
Moisture and water
• Do not use this apparatus near water or moisture.
• Do not use this product near a bathtub, wash-bowl, kitchen sink, and laundry tub, in
a wet basement, near a swimming pool, or anywhere else that water or moisture is
present.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Safety information6
Safety information
Important - Please read these instructions fully before
installing or operating
Heat sources and flames
• To prevent risk of fire or electric shock, avoid overloading wall outlets,
extension cords, or integral convenience receptacles.
Servicing and repairs
• Refer all servicing to qualified service personnel
• Servicing is required when the apparatus has been damaged in any way: such as liquid
has been spilled or objects have fallen into the apparatus; the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Safety information
7
Getting to know your Turntable
2
Getting to know your Turntable
You’ll be up and running in no time
Ready? Let’s begin...
Please read these instructions carefully. They contain important information which will
help you get the best from your product and ensure safe and correct installation and
operation.
If you require any further assistance, our technical experts are happy to help. For full
details, refer to the product support section at the end of these instructions.
Accessories
1. CTT5 turntable
2. Mains adapter
3. 1 x spare stylus/needle
4. USB cable
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
10
Getting to know your Turntable
Getting to know your Turntable
AUX IN R L DC 5V 1A
You’ll be up and running in no time
1
2
3
7
6
5
4
1. TURNTABLE platter
2. TONE-ARM rest/lock
3. CARTRIDGE/STYLUS
5. TONE-ARM
6. SPEED selector (33, 45 & 78rpm)
7. TONE-ARM - lift lever
4
4. INTERNAL speakers
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Getting to know your Turntable 11
Getting to know your Turntable
AUX IN R L DC 5V 1A
You’ll be up and running in no time
AUX IN R L DC 5V 1A
8
9
11
8. AUX-IN 3.5mm socket
9. DC MAINS input socket
10. RCA LINE LEVEL output sockets
POWER
OFF MAX
VOLUME
11. DUST cover
12. ON/OFF/Volume control knob
13. POWER LED
10
1312
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
12
Getting to know your Turntable
Getting to know your Turntable
You’ll be up and running in no time
Connecting to an external sound system
Should you wish to connect the turntable to an external amplifier follow the below steps.
AUX IN R L DC 5V 1A
1. Connect an RCA audio cable (not supplied) to the AUDIO LINE OUT sockets on the
rear of the turntable.
Take care to match the RED/WHITE plugs to the corresponding RED/WHITE sockets.
2. Connect the other end of the cable to an AUDIO INPUT on the amplifier (check your
amplifier user manual if you are not sure).
3. The volume control on the turntable will have no effect on the volume level when
connected this way. All volume controls should be operated from the amplifier.
Turn the volume on the turntable all the way down, so it does not interfere with the
external sound system.
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Getting to know your Turntable 13
Getting to know your Turntable
You’ll be up and running in no time
Listening to an external source
Connect other audio sources such as a smartphone to the turntable to allow playback
through the built-in speakers. Follow the below steps to get connected.
AUX IN R L DC 5V 1A
1. Connect a 3.5mm audio cable (not supplied) to the AUX IN socket on the rear of the
turntable. The platter will stop spinning if playing a record.
2. Connect the other end to the earphone/Line out socket on the smartphone.
3. Begin playback on the smartphone.
4. Adjust the volume.
5. When connecting via the headphone output the volume of the built-in speakers
is affected by the volume control on the smartphone. Ensure that the smartphone
volume is set to about 70-80% to avoid distortion.
Handling vinyl
Vinyl records can get dusty. This will cause a buildup of dust on the stylus during playback.
Keeping your vinyl collection clean and cleaning
before use will reduce noisy crackles during
playback and increase your listening experience.
Should you get a dust build-up on the stylus,
gently dust off with a soft brush from back to front
as shown.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
14
Getting to know your Turntable
Getting to know your Turntable
You’ll be up and running in no time
Fitting the dust cover
Refer to the diagram below to attached the plastic dust cover.
AUX IN R L DC 5V 1A
Take care when fitting, and do not press down too hard. Remove the dust cover in the
same manner, but pull the cover upwards.
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Getting to know your Turntable 15
Using your Turntable
3
Using your Turntable
Let’s get started
Getting started
1. Remove all packaging from the turntable including the security wire around the tonearm rest/lock (2) and the white plastic cartridge protector.
2. Place the turntable on a stable surface.
Connecting the power
AUX IN R L DC 5V 1A
Fig 1.
1. Insert the USB plug end of the supplied cable into mains adapter socket. Then insert
the other end into the DC mains input socket (9) on the rear of the turntable. (Fig 1)
Fig 2.
2. Extend the central earth pin upwards on the adapter, then connect to a wall socket
and switch on. (Fig 2)
Turn the power On/O
1. Rotate the ON/OFF/Volume control knob (12) clockwise until you hear a click and the
POWER LED (13) illuminates.
2. To power off the turntable rotate the ON/OFF/Volume control knob (12) anticlockwise until you hear a click and the POWER LED goes off.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Using your Turntable18
Using your Turntable
Let’s get started
Play a record
1. Before use, ensure the security wire (tone-arm rest/lock) and the cartridge protector
(stylus/cartridge) have been removed. And the tonearm lock is released.
2. Place a record on the turntable platter (1).
3. Select the speed required using the speed selector switch (6).
4. Raise the tone-arm (5) using the tone-arm lift lever (7). As you move the tonearm
towards the record the turntable begins spinning. Lower the needle gently onto the
outer edge of the record using the tone-arm lift lever (7).
5. Rotate the ON/OFF/Volume control knob (12) to increase or decrease the volume
level.
6. When the record has finished playing the tone-arm will raise and return to the rest
position.
Replacing the turntable stylus/needle
NOTE Please replace the stylus.needle with extreme care to avoid damage to the tonearm and cartridge.
1. Carefully separate the red plastic section from the bottom of the cartridge.
2. Connect the new stylus/needle to the cartridge.
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Using your Turntable
19
Other information 4
Other information
Helpful technical information
Care & maintenance
After using the Turntable
• Set to Standby.
• Switch the unit off at the mains and unplug it if you are leaving it unattended for a long
period (holidays etc).
Care & cleaning
• All care and cleaning operations should be carried out with the unit unplugged from
the mains power.
• Occasionally wipe the cabinet with a lint free duster. Never clean the unit with liquids
or solvents.
Technical specification
Specification Rating
Supply voltage DC: 5V
Max. power consumption 5W
Speaker power 4 MAX watts, 2 x 1.5w RMS @ 10% THD
Dimensions (W) 418 x (D) 390 x (H) 125mm
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Other information22
1000mA
Product support 5
Product support
Help is always at hand
Troubleshooting
Problem Reason(s) Solution(s)
No power. Power cable not connected
to wall socket.
Make sure the plug is
connected.
No sound when connected
to a home stereo system.
The record is playing too
fast or too slow.
Power socket is not
switched on.
Volume is too low.
3.5mm audio cable is
connected to the AUX input
socket.
AUX IN source volume is
too low.
Adjust the speed setting. Change the speed selector
Switch the power on.
Increase the volume.
Remove the cable to
resume normal playback.
Increase the output volume
of the AUX IN source.
to the correct position.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Product support24
Product support
Help is always at hand
Disposal
• Disposal of your old product. Your product is designed and manufactured with
high quality materials and components, which can be recycled and reused
• When this crossed out wheeled bin symbol is attached to a product it means
the product is covered by the European Directive 2002/96/EC.
• Please make yourself aware of the local collection system for electrical and
electronic products.
• Please act according to your local rules and do not dispose of your old
products with your normal household waste.
• The correct disposal of your old product will help prevent potential negative
consequences for the environment and human health.
This appliance complies with the following EEC directives: 2014/35/EU Low
voltage directive / 2014/30/EU EMC directive
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
Product support 25
Product support
Help is always at hand
Help and assistance
If you require any technical guidance or find that your Turntable is not operating as
intended, a simple solution can often be found in the Troubleshooting section of these
instructions or online at www.argos-support.co.uk
If you still require further assistance, call one of our experts on 0345 600 3021*. To help
give us give you a fast and efficient service please have the following information ready:
You can find these
on the rating plate - a
small information
panel (usually a sticker
or metal plate) on the
rear of your product.
This will be shown on
your receipt
Model Ref.
Serial number
Date of purchase
Local call rates applies*
CTT5
Lines open 8am-7pm Monday to Saturday and
10am-4pm Sunday.
*Calls to Argos enquiry lines may attract a charge and set up fee from residential lines depending on
your call plan/tari. Mobile and other providers costs may vary, see www.bt.com/pricing for details.
For security and training purposes, telephone calls to and from customer service centres may be
recorded and monitored. Calls from Republic of Ireland will attract international call charges.
If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting
Product support26
Product support
Help is always at hand
Call us now and activate your 12 month guarantee
Thank you for choosing Bush. Your new product is guaranteed against faults and breakdowns for 12 months.
Don’t forget to register it with us today so we can provide you with our best possible after-sales service and
useful updates.
www.bushregistration.co.uk
FREEPHONE*
0800 597 8548
Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.
Your Bush Guarantee
This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to
faulty materials or workmanship will be repaired free of charge (or if applicable the product will be replaced or the
purchase price refunded) where possible during this period by the dealer from who your purchased the unit.
The guarantee is subject to the following provisions:
• The guarantee does not cover accidental damage,
misuse, cabinet parts, knobs or consumable items.
• The product must be correctly installed and
operated in accordance with the instructions
contained in the manual.
• It must be used solely for domestic purposes. The
guarantee will be rendered invalid if the product is
Important Data Protection Information
If you provide us with information about another person,
you confirm that they have appointed you to act for
them, to consent to the processing of their personal
data including sensitive personal data and that you have
informed them of our identity and the purposes (as
set out in the Important Data Privacy notice displayed
overleaf) for which their personal data will be processed.
You are entitled to ask for a copy of the information
we hold about you (for which we may charge a small
fee) and to have any inaccuracies in your information
corrected.
Guarantor: Argos Limited - 489 - 499 Avebury Blvd. - Milton Keynes - MK9 2NW
section of these instructions, or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021.
re-sold or has been damaged by inexpert repair.
• Specifications are subject to change without
notice.
• Bush disclaim any liability for loss or damage arising
from the breakdown of the product.
• This guarantee is in addition to and does not
diminish your statutory or legal rights.
For quality control and training purposes, we may
monitor or record your communications with us.
If your personal details change, if you change your mind
about any of your marketing preferences or if you have
any queries about how we use your information, please
let us know by contacting our Data Protection
Officer, Domestic & General, Leicester House
17 Leicester Street, Bedworth, Warwickshire
CV12 8JP.
Product support 27
Contact:
www.argos-support.co.uk
Helpline: 0345 600 3021
Rev1.7
Loading...
