BT Calypso 120 User Manual

BT Calypso 120 – Edition 04 – 04.10.04 – 6329
User Guide
BT CALYPSO 120
6329 Calypso 120 UG 4/10/04 4:25 pm Page 1
Section
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Transfer phonebook entries between your mobile SIM card and BT Calypso handset.
SMS text messaging. Send and receive texts. Large, easy to read colour screen. 150 Name and number phonebook. Use Caller Display to see who is calling and keep track of
unanswered calls. Register up to 5 handsets to a base without the need for
additional wiring. Easy settings for Call Diversion, Call Waiting and
Reminder Call. Assign ringtones to entries in the phonebook. Range of up to 300 metres outside and up to 50 metres
indoors.
Welcome…
to your BT Calypso 120 digital cordless colour screen telephone
6329 Calypso 120 UG 4/10/04 4:25 pm Page 2
Section
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
This User Guide provides you with all the information you need to get the most from your phone.
You must first set up your phone before you can use it. This doesn’t take long and is easy to do. Just follow the simple instructions on the next few pages.
Need help?
If you have any problems setting up or using your BT Calypso 120, contact the Helpline on 0870 605 8047.
Alternatively, you may find the answer in ‘Help’ at the back of this guide.
Hearing aid?
Please note that the BT Calypso works by sending radio signals between the base and handset. These signals may interfere with some hearing aids, causing a humming noise.
Got everything?
BT Calypso 120 base BT Calypso 120 handset 2 x NiMH AAA
rechargeable batteries Battery compartment
cover Mains power adaptor Telephone line cord
In addition
If you have purchased a BT Calypso 120 multiple pack, you will have the following for each additional handset:
BT Calypso 120 handset BT Calypso 120 charger 2 x NiMH AAA
rechargeable batteries Battery compartment
cover Mains power adaptor
6329 Calypso 120 UG 4/10/04 4:25 pm Page 3
Getting started . . . . . . . . . . . . . . . . .7
Location . . . . . . . . . . . . . . . . . . . . . .7
Setting up . . . . . . . . . . . . . . . . . . . . .7
Battery performance . . . . . . . . . . . . .8
BT Calypso multiple pack . . . . . . . . . .10
Getting to know your phone . . . . . . .11
Handset buttons . . . . . . . . . . . . . . . .11
Base . . . . . . . . . . . . . . . . . . . . . . . . .12
Display icons . . . . . . . . . . . . . . . . . . .13
Navigating the menu . . . . . . . . . . . . .14
Menu map . . . . . . . . . . . . . . . . . . . . .15
Using the phone . . . . . . . . . . . . . . . .16
Switch handset on/off . . . . . . . . . . . . .16
Make a call . . . . . . . . . . . . . . . . . . . .16
Preparatory dialling . . . . . . . . . . . . . .16
Call timer . . . . . . . . . . . . . . . . . . . . .16
End a call . . . . . . . . . . . . . . . . . . . . . .16
Receiving calls . . . . . . . . . . . . . . . . . .17
Handsfree . . . . . . . . . . . . . . . . . . . . .17
Earpiece/handsfree volume . . . . . . . . .17
Redial . . . . . . . . . . . . . . . . . . . . . . . .18
Secrecy . . . . . . . . . . . . . . . . . . . . . . .19
Paging . . . . . . . . . . . . . . . . . . . . . . .19
Keypad lock . . . . . . . . . . . . . . . . . . . .20
Internal calls . . . . . . . . . . . . . . . . . . .20
Call another handset . . . . . . . . . . . . .20
3-Way call . . . . . . . . . . . . . . . . . . . . .20
Transfer a call . . . . . . . . . . . . . . . . . .21
Caller on hold . . . . . . . . . . . . . . . . . .22
Phonebook . . . . . . . . . . . . . . . . . . . .23
Writing tips . . . . . . . . . . . . . . . . . . . .23
Add entry . . . . . . . . . . . . . . . . . . . . .23
Dial . . . . . . . . . . . . . . . . . . . . . . . . . .23
Edit name and number . . . . . . . . . . . .24
View details . . . . . . . . . . . . . . . . . . . .24
Delete an entry . . . . . . . . . . . . . . . . .25
Copy from SIM . . . . . . . . . . . . . . . . . .25
Phonebook full . . . . . . . . . . . . . . . . . .26
SMS text messaging . . . . . . . . . . . . .27
To subscribe . . . . . . . . . . . . . . . . . . .27
Cost of the fixed line service . . . . . . . .28
Using SMS . . . . . . . . . . . . . . . . . . . . .28
Write an SMS text message . . . . . . . .28
Writing tips . . . . . . . . . . . . . . . . . . . .29
Character map . . . . . . . . . . . . . . . . . .29
Using options . . . . . . . . . . . . . . . . . .30
Outbox . . . . . . . . . . . . . . . . . . . . . . .31
Deleting . . . . . . . . . . . . . . . . . . . . . .32
Receiving and reading
text messages . . . . . . . . . . . . . . . . . .32
Open Inbox . . . . . . . . . . . . . . . . . . . .33
Open Inbox from standby screen . . . . .34
4
In this guide
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 4
5In this guide
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
SMS settings . . . . . . . . . . . . . . . . . . .34
SMS Service Centre numbers . . . . . . .34
To change the SMS Service Centre
phone numbers . . . . . . . . . . . . . . . . .35
Set SMS text alert . . . . . . . . . . . . . . .35
User areas . . . . . . . . . . . . . . . . . . . . .36
Set personal user area . . . . . . . . . . . .37
Send text message from a user area . .37
Delete user area . . . . . . . . . . . . . . . .38
Default SMS settings . . . . . . . . . . . . .38
BT Calling Features . . . . . . . . . . . . . .39
Caller Display . . . . . . . . . . . . . . . . . . .39
Calls lists . . . . . . . . . . . . . . . . . . . . . .39
Missed calls . . . . . . . . . . . . . . . . . . . .40
Redial . . . . . . . . . . . . . . . . . . . . . . . .41
Delete Calls Lists . . . . . . . . . . . . . . . .41
Call Diversion . . . . . . . . . . . . . . . . . .42
Call Waiting . . . . . . . . . . . . . . . . . . . .42
Reminder call . . . . . . . . . . . . . . . . . . .43
Edit number . . . . . . . . . . . . . . . . . . . .44
Default settings . . . . . . . . . . . . . . . . .44
Handset settings . . . . . . . . . . . . . . . .45
Handset ringtone . . . . . . . . . . . . . . . .45
Ringer volume . . . . . . . . . . . . . . . . . .45
Handset name . . . . . . . . . . . . . . . . . .46
Language . . . . . . . . . . . . . . . . . . . . .46
Menu colour . . . . . . . . . . . . . . . . . . .47
Auto talk . . . . . . . . . . . . . . . . . . . . . .47
Handset default settings . . . . . . . . . . .47
Base settings . . . . . . . . . . . . . . . . . .48
Ringtone . . . . . . . . . . . . . . . . . . . . . .48
Ringer volume . . . . . . . . . . . . . . . . . .48
Handset priority . . . . . . . . . . . . . . . . .49
System PIN . . . . . . . . . . . . . . . . . . . .49
Default base settings . . . . . . . . . . . . .50
Time settings . . . . . . . . . . . . . . . . . .51
Set alarm . . . . . . . . . . . . . . . . . . . . . .51
Alarm tone . . . . . . . . . . . . . . . . . . . .52
Switch alarm off . . . . . . . . . . . . . . . . .52
Set time and date . . . . . . . . . . . . . . .52
Additional handsets and bases . . . . .53
Register a new BT Calypso handset . . .53 Register handset with an
additional base . . . . . . . . . . . . . . . . .54
Select base . . . . . . . . . . . . . . . . . . . .55
De-register a handset . . . . . . . . . . . . .55
Help . . . . . . . . . . . . . . . . . . . . . . . . .56
Replacing handset batteries . . . . . . . .56
Helpline . . . . . . . . . . . . . . . . . . . . . .56
6329 Calypso 120 UG 4/10/04 4:25 pm Page 5
General information . . . . . . . . . . . . .62
Safety . . . . . . . . . . . . . . . . . . . . . . . .62
Cleaning . . . . . . . . . . . . . . . . . . . . . .63
Environmental . . . . . . . . . . . . . . . . . .63
Guarantee . . . . . . . . . . . . . . . . . . . . .64
Returning your phone . . . . . . . . . . . . .65
How many telephones
can you have? . . . . . . . . . . . . . . . . . .66
Connecting to a switchboard . . . . . . . .66
Access code and entering a pause . . .67
Recall . . . . . . . . . . . . . . . . . . . . . . . .67
Declaration of Conformance . . . . . . . .68
R&TTE . . . . . . . . . . . . . . . . . . . . . . .68
Accessories and spares . . . . . . . . . . . .68
For your records . . . . . . . . . . . . . . . . .68
6 In this guide
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 6
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
WARNING
Do not place your BT Calypso 120 in the bathroom or other humid areas.
Handset range
The BT Calypso 120 has a range of 300 metres outdoors when there is a clear line of sight between the base and handset. When there is no clear line of sight between the base and handset, e.g. base indoors and handset either indoors or outdoors, the range could be reduced to 50 metres. Thick stone walls severely affect the range.
Signal strength
The symbol on your handset screen indicates when you are in range. When you are out of range, it flashes.
IMPORTANT
Do not connect the telephone line until at least one of the handsets is fully charged.
The base must be plugged into the mains power at all times.
Location
You need to place your BT Calypso 120 within 2 metres of a mains power and telephone socket so that the cables will reach.
Make sure it is at least 1 metre away from other electrical appliances to avoid interference.
Your BT Calypso 120 works by sending radio signals between the handset and base. The strength of the signal depends on where you site the base. Putting it as high as possible ensures the best signal.
Setting up
1. Plug the power cable into the base.
Getting started 7
Which socket?
Power socket
Telephone line socket
Power adaptor cable
6329 Calypso 120 UG 4/10/04 4:25 pm Page 7
The red Charging light stays on while the handset is on the base, even when the batteries are fully charged.
Talk/Standby time
Under ideal conditions, fully charged handset batteries should give up to 8 hours talktime or 80 hours standby on a single charge.
Battery low warning
The handset battery symbol is empty and flashing and you will hear a warning beep. Start recharging your handset right away.
When charging the battery, level bars are animated.
Replacing batteries
Use only rechargeable 750mAh or higher AAA NiMH batteries.
Battery performance
When batteries are fully charged the display shows 3 green bars.
To keep your batteries in the best conditions, leave the handset off the base for a few hours at a time (after the initial 16 hour charge).
Please note however, that new NiMH batteries do not reach full capacity until they have been in normal use for several days.
2. Insert 2 x AAA NiMH batteries supplied into the handset. Slide the battery compartment covers into place.
3. Charge the handset for at least 16 hours by placing it on the base. The red Charging light comes on. The handset is pre-registered to the base as Handset 1. The screen shows the standby display.
4. After 16 hours, plug the telephone line cord into the wall socket and your BT Calypso 120 base.
8 Getting started
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 8
Range indicator
The symbol on your handset display indicates when you are in range of the base. If the symbol flashes and you hear a warning beep, you are out of range and will need to move closer to the base. The display shows
Base
and the number of the base last used.
Set date and time.
If you have subscribed to your network’s Caller Display service, the time and date will be set automatically when you receive your first call. You can also set the time manually.
1. On the handset, press Menu. Scroll to
Time Settings
and press OK. Scroll to
Set Date & Time
and press OK.
2. Enter the date, e.g. for 16th April. Press OK.
3. Enter the time, e.g. for 9:30am. Press OK.
The time and date is saved.
4. Press and hold Back to return to standby.
9Getting started
Running the batteries right down at least once a week will help them last as long as possible.
The charge capacity of rechargeable batteries will reduce with time as they wear out, so reducing the talk/standby time of the handset. Eventually they will need to be replaced. New batteries can be obtained from the BT Calypso Helpline 0870 605 8047.
Helpline
If you have any difficulties setting up your BT Calypso 120, please call the BT Calypso Helpline on 0870 605 8047.
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 9
Ensure the charger is connected to the mains at all times.
Your BT Calypso 120 is now ready for use.
Additionally, if you have purchased a BT Calypso 120 multiple pack
On each charger:
1. Connect the mains power adaptor to the charger and switch on.
On each additional handset:
2. Insert the batteries.
3. Charge the handset for at least 16 hours.
Your BT Calypso 120 additional handset(s) comes pre-registered to the base as Handset 2, Handset 3, Handset 4 etc and this is shown on the display.
Your BT Calypso 120 multiple pack is now ready for use.
10 Getting started
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 10
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Getting to know your phone
On-screen options
Open the menu and select the
options you require, page 14.
Talk
Press to make calls, page 16.
Handsfree
Press to enter handsfree mode,
page 17.
Scroll/Dialled Calls list/Volume
Scroll through options.
Press up to open Dialled Calls list,
page 41.
During a call, press to increase
volume.
R
For use with a switchboard, page 67
and BT Calling Features, page 39.
On-screen options
Open the phone book and select the options shown on the screen.
Scroll/Missed Calls list/Volume
Scroll through options. Press down to open Missed Calls
list, page 40. During a call, press to decrease
volume.
End/Power on/off
End a call, page 16. Press and hold to switch handset
on or off, page 16.
SMS
Opens the text messaging menu, page 34.
Int
Lets you make calls between handsets registered to the base, page 20.
Also used to switch between upper and lower case characters.
Handset buttons
11
6329 Calypso 120 UG 4/10/04 4:25 pm Page 11
12 Getting to know your phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Base
Power / In use indicator
ON Power on, line ready for use.
FLASHING Incoming call/line in use.
Page
Press to page handset(s) registered to the base, page 19.
Also used when registering additional handsets.
Missed Calls indicator
Lights up if you have
new missed calls.
New SMS
Lights up if you have new
text messages.
SIM Card reader
Insert your SIM card into the tray to copy entries from your SIM card to the phonebook, page 25.
IMPORTANT
3G SIM cards are not compatible with this product.
Battery charging light
Lights up when the handset
is charging on the base.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 12
13Getting to know your phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
* For this feature to work you must subscribe to your Network Provider’s Caller Display service. A quarterly fee may be payable.
Handset identity
The number of the handset is
displayed at all times. You can
change the name on the
handsets, e.g. Michael,
Kitchen, Office etc., page 46.
New Missed Calls*
You have new (unread) entries in
the Missed Calls list, page 40.
Keypad locked, page 20
Handset ringer off, page 45
Current time,
page 52
Alarm set,
page 51
Battery status
Range indicator
Flashes when out of range
Handset idle
The phone is not in use
Menu option
Press the button
below to open the
main menu, page 14.
Names option
Press the button below to open the phonebook, page 23.
Handset display icons
6329 Calypso 120 UG 4/10/04 4:25 pm Page 13
Navigating the menu
Your BT Calypso 120 has a menu system which is easy to use. Each menu leads to a list of options. The menu map is shown on the following page.
When the handset is switched on and in standby, press the option button under Menu to open the main menu. Press the or button to scroll to the menu option you want. Then press OK to select further options or confirm the setting displayed.
For example to change the handset ringer volume:
1. Press Menu then scroll to
Handset
and press OK.
2. Scroll to
Ring Volume
then press OK.
3. The current setting is displayed. Press to increase or
to decrease the volume, the ringtone is played at
each level you select. Press OK to confirm.
Exit or go back one level in the menu
To go back to the previous level in the menu, press Back.
To cancel and return to standby at any time, press and hold Back.
If no button is pressed for 60 seconds, the handset returns to standby automatically.
14 Getting to know your phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Select the option displayed by pressing the button underneath it.
For example, select Names by pressing the option button below it.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 14
15Getting to know your phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Menu map These are the options under each menu heading.
SMS (page 27) • Write messages Inbox Outbox Delete messages Settings
Calls lists (page 39) • Received calls Missed calls Dialled calls Delete Calls List
Handset (page 45) • Ringtone Ring Volume Handset Name Language
Menu Colour Auto Talk PABX Access Code
Base settings (page 48) • Base Ringtone Base Volume Handset Priority
Recall Mode SIM country codes System PIN
Time settings (page 51) • Alarm Set Date & Time
Calling Features (page 42) • Call Diversion Call Waiting Reminder call Edit number
Registration (page 53) • Register Handset Select Base De-register
Names menu (page 23) • Names Options Add Entry Show Details Delete Entry
Edit Entry Ringtone Copy from SIM Delete all Phonebook
6329 Calypso 120 UG 4/10/04 4:25 pm Page 15
Simple and easy.
Switch handset on/off
1. Press and hold to switch the handset off.
2. Press again or place it in the base to switch the handset back on.
Make a call
1. Press then dial the number you want.
Preparatory dialling
1. Enter the number first. If you make a mistake, press
Clear to delete. Press to dial.
Call timer
1. The display shows the duration of all external calls. After you hang up, the total call time is shown briefly.
End a call
1. Press or place the handset back on the base.
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Using the phone16
6329 Calypso 120 UG 4/10/04 4:25 pm Page 16
Receiving calls
Providing you have subscribed to your network’s Caller Display service, the caller’s number (and name if stored in the phone book) is displayed.
1. Press or if the handset is on the base, simply lift it up and speak.
Handsfree
Handsfree lets you talk to your caller without holding the handset. It also enables other people in the room listen to both sides of your conversation.
Make a handsfree call
1. Press . Dial the number. Your call can be heard over the handset’s loudspeaker.
2. To switch back to the handset at any time, press again. Press to end the call.
Adjust earpiece/handsfree volume
1. During a handsfree call, press or to select volume 1-5.
17Using the phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
You can switch to handsfree at any time during a call. Just press .
When in ‘handsfree’, the display shows the icon.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 17
Answer a call in handsfree
When the phone rings:
1. Press . The call comes through the handset loudspeaker. If you want to switch the call to the earpiece, press .
Redial
You can redial up to 20 of the last numbers called. If you have stored a name in the phonebook to go with the number, the name will be displayed instead, see phonebook, page 23.
Redial a number from the list
1. Press to enter the redial list. Scroll or until the number you want is displayed.
2. Press to dial the number.
18 Using the phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 18
Secrecy
During a call, you can talk to someone nearby without your caller hearing you.
1. During the call, press Secrecy. Display shows
Secrecy
On
. Your caller cannot hear you.
2. Press OFF to return to your caller.
Paging
You can use the button on the base to alert handset users that they are wanted or locate a missing handset.
1. Press on the base. The handset(s) ring. Display shows
Paging
.
2. Press to stop the handsets ringing or press any button on the handset.
19Using the phone
Paging calls cannot be answered by a handset.
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 19
You cannot make any calls, including 999 and 112 emergency calls while the keypad is locked. Answer incoming calls by pressing
as normal.
The icon is displayed while the keypad is locked.
Keypad lock
You can lock the keypad to prevent accidental dialling while carrying the handset around.
1. Press and hold until the screen shows
Keypad
Locked
and the padlock symbol appears.
2. Press
Unlock
then YES to use the keypad again.
Internal calls
If you have two or more handsets registered to your base, you can make internal calls. Two handsets can be holding an internal call while a third is making an external call.
Call another handset
1. Press then the handset number you want (1-5).
2. Press to end the call.
3-Way call
You can put an external caller on hold, talk to another handset user, then hold a call between all three.
20 Using the phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 20
1. During an external call, press your caller is put on hold. Enter the handset number you want (1-5).
2. When the other handset answers, press to start the conference call.
If the other handset does not answer, press again to speak to your external caller.
3. Press to hang up.
Transfer a call
You can transfer an external call to another handset.
During the call:
1. Press . Your caller is put on hold. Enter the handset number you want (1-5).
2. When the other handset answers you can tell them they have a call, then press . The external caller is transferred.
If the other handset does not answer or you decide not to transfer the call, press to talk to your caller again.
21Using the phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 21
Caller on hold
You can put an external caller on hold, talk to another handset user, then resume your external call.
1. During a call, press your caller is put on hold. Enter the handset number you want.
2. Press to end the internal call and return to your external caller. The other handset presses
Talk Off
to
end the call.
22 Using the phone
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
6329 Calypso 120 UG 4/10/04 4:25 pm Page 22
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
If you subscribe to your network’s Caller Display service, and want the names in your Phonebook displayed instead of the phone numbers, you must store the full telephone number including the national code.
Your own directory, stored in a handset.
Each Calypso handset can store up to 150 names and numbers. Names can be up to 16 characters long and numbers up to 20 digits.
Add entry
1. Press Names.
2. If the Phonebook is empty,
Add Entry
is highlighted.
Press OK.
Or
3. If names have been stored, they are listed. Press Options.
Add Entry
is highlighted. Press OK.
4. Use the keypad to enter the name, then press OK.
5. Use the keypad to enter the number, then press OK. The screen shows the Names list.
6. Press and hold
Back
to return to standby.
Dial
1. Press Names.
2. Scroll or to the name you want or use the keypad to enter the first letter of the name, e.g. press four times for names beginning with
S
.
3. Press to dial.
Phonebook
Writing tips
Entering names Use the keypad letters to enter
names, e.g. to store TOM:
1. Press once to enter
T
.
2. Press three times to enter
O
.
3. Press once to enter
M
.
If you make a mistake, press Clear to delete the last character or digit.
Press to switch between upper and lower case letters.
The icon will be displayed when you have selected upper case.
23
6329 Calypso 120 UG 4/10/04 4:25 pm Page 23
24
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Edit name and number
1. Press Names then scroll or to the name you want, then press Options. Scroll to
Edit Entry
and
press OK.
2.
Edit Entry
screen is displayed. Press Clear to delete or use or to position the cursor. Use the keypad to change the name. Press OK.
3. Edit the number and press OK. Display returns to the list of names.
4. Press and hold
Back
to return to standby.
View details
1. Press Names then scroll or to the name you want, the press Options.
2. Scroll to
Show Details
and press OK.
3. Display shows the number.
4. Press and hold
Back
to return to standby.
Phonebook
6329 Calypso 120 UG 4/10/04 4:25 pm Page 24
25
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Delete an entry
1. Press Names then scroll or to the name you want, then press Options.
2. Scroll to
Delete Entry
and press OK.
3. Press Ye s to confirm or No to cancel.
4. Press and hold
Back
to return to standby.
Copy from SIM
You can copy complete phonebook lists from compatible mobile phone SIM cards. The SIM phonebook is copied to the handset you are using and will add to the entries already stored.
1. Turn the base upside down and slide the SIM card reader out of the base. Insert the SIM card into the reader and slide it back into the base.
Phonebook
When you copy the whole phonebook or SIM card, it will add to the entries already stored.
DO NOT ATTEMPT TO DOWNLOAD THE PHONEBOOK FROM 3G SIM CARDS.
The SIM card reader in the BT Calypso base is not compatible with
1.8V SIM cards (only available with 3G phones, at the time of writing).
IMPORTANT
Your BT Calypso 120 will only copy numbers stored on your SIM card. If fewer numbers than you expect copy into your BT Calypso 120, check that all numbers are stored on your SIM and not on your mobile phone. Refer to your mobile phone user guide for instructions on how to do this.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 25
If you forget your PIN or if the SIM card becomes locked because the wrong code has been entered, contact your mobile phone provider.
WARNING
Keep SIM cards away from small children as they are a possible choking hazard.
26
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
2. Press Names then Options.
3. Scroll to
Copy From SIM
and press OK. The
Copy
From SIM
screen is displayed.
4. Enter the SIM card PIN code if requested and press OK. During copying, the screen shows the name of each entry as it is copied. When finished you will see
Done
displayed briefly.
If you enter the wrong PIN twice,
Copy SIM Failed
is
displayed and the screen returns to standby.
If the handset memory becomes full during copying the screen shows
Memory Full
.
5. Press and hold
Back
to return to standby.
Phonebook full
If the phonebook becomes full when adding or copying entries, the screen shows
Memory Full
and then returns
to standby.
Phonebook
Handset memory full
If the handset memory becomes full during copying, not all the entries will be transferred.
The maximum number of entries is 150. If your handset phonebook already contains 90 entries, only the first 60 entries on the SIM card will be copied.
Your BT Calypso 120 checks all available directory memory spaces on your mobile SIM card.
During copying, the charging light on the base will flash.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 26
27
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Welcome to the BT Text Service on your BT Calypso 120. The SMS Service is provided by BT.
Your BT Calypso 120 can send and receive messages to any mobile phone from participating mobile networks and compatible landline telephones in the UK.
The fixed line SMS service is provided under BT’s terms and conditions for telephone service. These can be found by visiting the BT.com website at:
http://www.bt.com/terms/tor.htm
To subscribe to the SMS text messaging service
When you send your first SMS text message from your BT Calypso 120 you will automatically be registered for the service.
On receipt of your first SMS through the service, the system will send you a welcome SMS message back.
Please note that if you set up different user areas you will need to send a message from each user area to register them.
You may also register by sending the word Register to 00000 upon which you will receive a confirmation message.
SMS text messaging
IMPORTANT
You must subscribe to your Network Provider’s Caller Display Service in order to use SMS text messaging.
A quarterly fee may be payable. You must not have your telephone number withheld for this service to work.
You may also send messages to landline phones that are NOT SMS compatible. Messages to non­compatible lines will be connected to voice text and delivered in spoken words to the telephone as a call. Please note that the conversion can translate common abbreviations and smileys etc, but to ensure maximum clarity of message delivery, abbreviations etc should be used sparingly.
Some other network operators or line providers may not be compatible with this SMS service.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 27
28
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Cost of the fixed line service
There is no subscription charge (other than the subscription to Caller Display). Visit the BT.com website (www.bt.com) to find out how much it costs to send a text message (depends upon your call package).
Using SMS
With SMS (Short Message Services) you can send and receive text messages up to 160 characters long.
Write an SMS text message
1. Press Menu. The SMS screen is displayed. Press OK.
2. Press OK again to select
Write Message
.
You can enter a word by pressing each letter button a number of times to display the character you want on the screen.
To write the word “Hello”, press , ,
,,.
SMS text messaging
Helpline
If you have any difficulties sending or receiving SMS text messages, please see page 60 for the relevant Helpline number.
When using SMS for the first time, it is recommended that you send a message to yourself on the telephone number your BT Calypso 120 is connected to. If you do this you can see how messages are both sent and received.
CHARACTERS
Counts down the number of characters available from 160 to 0 so you always know how much more text you can write.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 28
29
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Writing tips
SMS text messaging
Character map
Pressing the buttons for normal message writing will give you the following characters with each successive press of the button.
Button Character
0@&
space .,:;!?¡¿’”1
ABC2ÄÅÆÇ? DE F 3É % G
HI
4_
JKL
5-
MNO
6ÑÖ(
PQRS
7/
TUV
8Ü:
WX Y Z
9) €£$¥ #
Deleting text
When writing, press Clear. When reading, press Options, select Delete then OK.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 29
30
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
In addition, the following characters appear in lower case only:
Use
,,
or to move the cursor. If you make
a mistake or want to delete text press Clear.
To read through your message if it is too long to fit on one screen, scroll or .
Using options
While writing press Options to access the following options:
Send To
– press OK. Enter the number when prompted or press Search to open the phonebook. You can send a message to an individual entry.
Save
– scroll to
Save
then press OK to save the
message for sending later.
SMS text messaging
Button Character
à
è
ì
òø
ß
ù
Sending
When you are sending a text, the screen shows Sending Message then Message Sent.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 30
31
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Insert Symbol
– scroll to
Insert Symbol
then press
OK to display the symbol chart. Scroll
,,
or
to select, then OK to insert.
User Name
– You can send from the default user name or select your own user area so that the receiver knows who has sent the text. To set a user area scroll to
User
Name
then press OK. Scroll or to select the
name, then OK to confirm, see page 36.
Outbox
Sent messages are stored in the Outbox.
You can read, forward and delete messages in your Outbox.
If forwarding a message to another person, you can edit the message before finally sending it.
1. From the standby screen, press Menu then OK. Press OK again to open the SMS menu. Scroll down to
Outbox
and press OK.
2. Scroll or to select the message you want then press Read. You can now open the Options menu to
Edit, Send To,Delete
or assign a user name to the
message.
SMS text messaging
Symbols
When writing a message, you can select a symbol from the options list.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 31
32
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Deleting
You can delete all messages from the Inbox or Outbox folder, or delete All Messages from all folders.
1. From the standby screen, press SMS to open the SMS menu. Scroll down to
Delete Messages
and press OK.
2. Scroll or to select the folder you want or
All
Messages
. Press OK. The appropriate screen is displayed.
3. Press OK to confirm or Back to cancel.
4. Press and hold Back to return to standby.
Receiving and reading text messages
When you receive a message it is stored automatically in the Inbox.
The screen alerts you to a new message then displays the new message icon along with the number of new messages in your Inbox. On the base, the New SMS light comes on. You can also set an audible alert, see page 35.
Delivery of SMS messages
The system will always try and deliver the message to a text enabled phone in written format, only if there is a problem with delivery will the message be delivered
SMS text messaging
6329 Calypso 120 UG 4/10/04 4:25 pm Page 32
33
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
as voice text, with the exception of forced voice text messages. See the Help section on page 59.
Once registered, SMS message delivery is 24 hours.
Open Inbox
1. Press Read then scroll or to select the message you want to read then press OK.
2. When reading your messages press Options to access the following options:
Reply
– press OK to send a reply.
Forward
– scroll to
Forward
then press OK to forward the message to another number. Enter the number when prompted or press Search to open the phonebook. You can send a message to an individual entry.
Delete
- scroll to
Delete
then press OK to delete the
message.
3. Press Back to return to the Inbox screen and to standby.
SMS text messaging
When replying to or forwarding a message you have access to the same Options menu used for writing a text message.
When you open the SMS menu, new messages in the Inbox are marked with an ✱.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 33
34
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Open Inbox from standby screen
1. From the standby screen, press to open the SMS menu. Scroll to
Inbox
and press OK.
2. You can now scroll or to the message you want and press Read to open it. You can now open the options menu to reply, forward or delete.
SMS settings
The SMS settings menu lets you:
Select alternative service centres.
Set the Terminal number.
Switch SMS Alert on or off.
Set different users so that each handset can have its own text mailbox.
SMS Service Centre numbers
To send and receive SMS text messages you need the telephone number of your Network’s SMS Centre.
These numbers have been pre-loaded into the BT Calypso 120.
SMS text messaging
6329 Calypso 120 UG 4/10/04 4:25 pm Page 34
35
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
If you accidentally delete the Send or Receive SMS Service Centre numbers you will need to re-enter them in order for your SMS Service to work.
The Send SMS Service number is:
11447700PP11770099440000
The Receive SMS Service number is:
00880000 558877 5522
To change the SMS Service Centre phone numbers
1. From the standby screen, press SMS to open the SMS menu. Scroll to
Settings
and press OK.
2. Press OK to open Service Centres menu. Scroll to the setting you want and select OK.
Receive Centre
– lets you set the number of the
message receiving centre.
Send Centre
– lets you set the number of the message
sending service.
See above for the pre-set Service Centre numbers.
Set SMS text alert
Your handset can play a different melody, a morse beep or a discreet tone to announce a new text message. The default setting is Off.
1. From the standby screen, press SMS to open the SMS menu. Scroll to
Settings
and press OK.
SMS text messaging
6329 Calypso 120 UG 4/10/04 4:25 pm Page 35
36
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
2. Scroll to
SMS Alert
.
3. Press OK.
4. Scroll to
Set Alert
and press OK.
Scroll or to select the type of alert you want –
Morse, Discreet
or
Polyphonic
.
5. Press OK to confirm or Back to return to the previous menu.
6. Scroll or to set the alert On or Off and press OK to confirm the setting.
7. Press and hold Back to return to standby.
User areas
You can receive text messages into a user area or mailbox. The default user area setting is 0.
All handsets can see the default User Area. You can set your own private user area which is protected by a PIN number. Your private user area can be accessed from any registered handset once the correct PIN number has been given.
Up to 5 user areas are available (default +4). However, you can allocate any number between 0-9 to them. The terminal number is automatically allocated but it can be changed.
SMS text messaging
The default setting is Morse.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 36
37
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Set personal user area
1. From the standby screen, press SMS to open the SMS menu. Scroll to
Settings
and press OK. Scroll
to
Users
and press OK.
2. If necessary, scroll to
Add User
and press OK.
Enter the user name and press OK.
3. Enter a password between 1 and 5 digits and press OK. Enter the password again to confirm and press OK. Your user screen is displayed.
4. You will be assigned a terminal number 0-8. To see your Terminal Number scroll to
Terminal Number
and
press OK.
5. Press Back to return to the previous menu.
Send text message from a user area
1. From the standby screen, press SMS then OK.
2. When you have written your message, press Options and scroll to
User Name
.
3. If required, scroll to the user area you want and press OK. Enter your PIN number and press OK.
4. The options menu is displayed again. You can now scroll to the next option you want, e.g.
Send To
.
SMS text messaging
6329 Calypso 120 UG 4/10/04 4:25 pm Page 37
Receiving Service Centre 1 0800 58752
Sending Service Centre 1 1470P1709400
Predictive Text Off
Set SMS Alert Melody Morse
User Area None set
Password protection Off
Default user PIN 0000
38
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Delete user area
1. From the standby screen, press SMS to open the SMS menu. Scroll to
Settings
and press OK. Scroll to
Users
and press OK.
2. Scroll to
Delete User
and press OK. Scroll or
to select the user you want and press OK.
3. Enter the PIN (that was previously allocated) and press
OK to delete. The display returns to the previous menu.
Default settings for SMS text messaging
SMS text messaging
PIN protected
If you have protected your text messages with a security PIN you will have to enter the PIN each time you open your Inbox to read your messages
Keep track of your PIN
You can keep a record of the current security PIN in the space provided at the back of this guide.
If you enter a PIN incorrectly the screen returns to standby.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 38
39
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Helping you manage your calls.
Caller Display
If you subscribe to a Caller Display service you can see who is calling you on your handset display, as well as the time and date of their call.
If you have stored a name to go with the number in your handset phonebook, the name will be displayed as well.
Please store the full telephone number, including the area code, otherwise the name will not match the number stored in the phonebook and any picture or ringtone you have selected will not be used.
Calls lists
Your BT Calypso 120 lets you view details of your last calls.
Received calls – shows details of all recent callers.
Missed calls – shows details of calls that were not
answered, or ‘missed’.
Dialled calls – list shows details of the last 20 calls made from your handset.
A combined total of 50 calls can be stored in the
Received and Missed calls.
IMPORTANT
To use Caller Display you must first subscribe to the service from your network provider. A quarterly fee may be payable.
For more information, call BT free on 0800 800 150.
Caller information not available.
With some incoming calls, the telephone number of the caller is not available and cannot therefore be displayed.
In this case your BT Calypso 120 provides you with some explanatory information.
Unavailable
–The number is
unavailable.
Withheld
– The caller has withheld
their number.
Ringback
–Ringback call.
Operator
–The call has been
made via the operator.
Payphone
–The caller is ringing
from a payphone.
Int’l
–International call.
BT Calling Features
6329 Calypso 120 UG 4/10/04 4:25 pm Page 39
40
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
An next to a number in the Calls list indicates a new caller.
You can display, scroll through and dial numbers in the Calls lists and copy them into the phonebook.
If a call is received when the Calls list is full, the oldest entry will be replaced with details of the new caller.
You can view, dial, delete and add entries to the phonebook.
To access Calls Lists via the menu
1. Press Menu then scroll to
Calls Lists
and press OK
to open the Calls list screen.
2. The Received calls list is highlighted. Scroll to highlight the
Missed
or
Dialled Calls list
. Press OK.
3. If the name of the caller has been stored in the phonebook it is displayed.
4. Press Options. You can now select:
Delete
– to delete the entry.
Show Details
– to view the number.
Save Number
– to store the number in the phonebook.
Press to select the option you want then press OK. Or press Back to return to the previous screen.
Missed calls
To access missed Calls List using the navigator button:
1. From the standby screen, press . New calls are indicated with an . Press or to scroll through the list.
2. Press to dial a number or Options to delete the entry, see further details or add the number to the phonebook.
BT Calling Features
6329 Calypso 120 UG 4/10/04 4:25 pm Page 40
41
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Redial
1. From the standby screen, press . The redial list is displayed. Press or to scroll through the list.
2. Press to dial a number or Options then select:
Delete
– to delete the number.
Show Details
– if a name is displayed, this shows the
number.
Save Number
– to create an entry in the phonebook. Enter the name, press OK. The number is displayed. Press OK to store the number.
Delete Calls lists
1. Press Menu the scroll to
Calls Lists
and press OK
to open the Calls list screen.
2. Scroll to
Delete Calls Lists
and press OK. Press
or to select the list you want to delete:
Received Calls Missed Calls Dialled Calls All Calls
Press OK.
3. Press Ye s to delete or No to cancel.
BT Calling Features
6329 Calypso 120 UG 4/10/04 4:25 pm Page 41
42
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Call Diversion is a chargeable service. Check with your network provider for details.
For BT, call 0800 800 150.
Call Diversion
Divert an incoming call to another number where you can be reached.
1. Press Menu then scroll to
Calling Features
and
press OK.
2. Press or to select:
Call Diversion On Call Diversion Off Call Diversion Check
Press OK. The Call Diversion service number is dialled. Follow the prompts given.
Call Waiting
If an incoming call arrives while you are already on the phone, you will hear a soft beep every 5 seconds. This beep is not audible to the person you are speaking to. The second caller’s number (and name if stored in the phonebook) will appear on the handset display.
Instead of the engaged tone, the second caller will hear an announcement to hold on as you are aware that there is a second call.
The name of the waiting caller will be displayed if you have stored their details in the phonebook and have subscribed to your network’s Caller Display service.
BT Calling Features
Call Waiting is a subscription service. Please check with your network provider for details.
For BT, call 0800 800 150.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 42
43
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
1. Press Menu then scroll to
Calling Features
and
press OK.
2. Press or to select:
Call Waiting On
Call Waiting Off
Call Waiting Check
Press OK to confirm. The Call Waiting service number is dialled. Follow the prompts given.
Reminder Call
You can request a BT reminder call for any time of day or night.
1. Press Menu then scroll to
Calling Features
and
press OK. Press to highlight
Reminder Call
then
press OK.
2. Press or to select:
Reminder Call Set
Reminder Call Cancel
Reminder Call Check
Press OK. The Reminder Call service number is dialled. Follow the prompts given.
BT Calling Features
Reminder Call is a pay as you use service.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 43
44
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Edit number
This will enable you to edit the number dialled to access Call Diversion, Call Waiting or Reminder Call services.
Default settings
BT Calling Features
Call Diversion on 21
Call Diversion off
#
21
#
Call Diversion check 21
#
Call Waiting on 43
#
Call Waiting off
#
43
#
Call Waiting check #43
#
Reminder call set 55
Reminder call cancel
#
55
#
Reminder call check #55
#
6329 Calypso 120 UG 4/10/04 4:25 pm Page 44
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
It’s your phone, make it work the way you want.
The Handset menu lets you set a number of preferences for each handset.
Handset ringtone
You can choose from 5 melodies. You can set different melodies for internal and external calls.
1. Press Menu, scroll to
Handset
and press OK.
2.
Ringtone
is highlighted. Press OK. Press or to
switch between
Internal
or
External
and press OK.
3. Scroll or to the melody you want. A sample is played. Press OK to confirm.
4. Press and hold Back to return to standby.
Ringer volume
There are five handset ringer volume levels and off. If you select off, calls will still ring at the base and your handset screen will indicate incoming calls.
1. Press Menu then scroll to
Handset
and press OK.
2. Scroll to
Ring Volume
and press OK.
Handset settings
If you select Ringer off, the icon is shown on the display.
45
The default ringtone for external calls is Melody 1.
The default ringtone for internal calls is Melody 5.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 45
46
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
3. The current setting is displayed. Press to increase or to decrease the volume. Press OK to confirm.
4. Press and hold Back to return to standby.
Handset name
You can change the name displayed on your handset’s screen, e.g. to Peter, Kitchen etc. The name can be up to 8 characters long. The handset number is not altered.
1. Press Menu then scroll to
Handset
and press OK.
2. Scroll to
Handset Name
, then press OK.
3. Enter the handset name you want. If you make a mistake
press Clear. Press OK to confirm.
4. Press and hold Back to return to standby.
Language
Choose the display language – English, Français, Deutsch, Italiano, Español, Nederlands or Portuguès.
1. Press Menu then scroll to
Handset
and press OK.
2. Press to highlight
Language
and press OK. Press or to highlight the language you want and press OK to select or Back to return to the previous menu.
3. Press and hold Back to return to standby.
Handset settings
6329 Calypso 120 UG 4/10/04 4:25 pm Page 46
47
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Menu colour
You can select Blue, Green or Pink.
1. Press Menu then scroll to
Handset
and press OK.
2. Scroll to
Menu Colour
, then press OK.
3. Scroll or to highlight the colour you want and press
Save
.
4. Press and hold Back to return to standby.
Auto talk
When the handset is on the base and the phone rings, you can answer a call just by picking the handset up from the base, without having to press the button. You can also end a call by placing the handset back on the base.
By switching Auto Talk off you have to press the button to answer a call and to hang up.
1. Press Menu then scroll to
Handset
and press OK.
2. Scroll to
Auto Talk
, then press OK.
The current setting is highlighted.
3. Scroll or to switch between
On
and
Off
.
Press OK to confirm your selection.
4. Press and hold Back to return to standby.
Handset settings
Handset default settings
Handset ringer volume 5
Handset name Calypso Earpiece volume 3 Ringer melody 5
(external and internal)
Display colours Blue Auto Talk On
6329 Calypso 120 UG 4/10/04 4:25 pm Page 47
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
What’s your fancy?
Ringtone
Choose from 5 standard ringer melodies.
1. Press Menu then scroll to
Base Settings
and
press OK.
2. Press OK select
Base Ringtone
. Scroll or to select the ringtone you want. As you highlight each option, you hear a quick sample.
3. Press OK to set the ringtone.
Ringer volume
There are five ringer volume levels and Off.
1. Press Menu then scroll to
Base Settings
and press
OK. Press to highlight
Base Volume
then press OK.
2. Scroll to increase volume or to decrease volume then OK to confirm.
Base settings
The default base ringtone is Melody 5.
The default base ringer volume is 3.
48
6329 Calypso 120 UG 4/10/04 4:25 pm Page 48
49
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Handset priority
Normally, if you have more than one handset registered to your base, they all ring at the same time. However, you can set one of them to ring before the others, so that calls can always be answered at one handset first.
1. Press Menu then scroll to
Base Settings
and
press OK. Press to highlight
Handset Priority
then press OK. Display highlights
All Handsets
. Press OK to select All
Handsets to make all handsets ring together.
Or
2. Scroll to
Select Handset
and press OK. Scroll or
to the handset you want to ring first. Press OK.
3. Scroll or to select the number of rings at the handset before the other handsets start ringing. Press OK to confirm.
System PIN
The System PIN is used for registering and deregistering handsets and some other optional settings. The default System PIN is 0000.
1. Press Menu then scroll to
Base Settings
and press
OK. Press to highlight
System PIN
then press OK.
Base settings
Protecting your settings
When entering a PIN the digits are shown as asterisks.
Keep track of your PIN
If you change the System PIN, keep a record of new number by writing in the space provided on page 68. You need your System PIN for registering handsets and for some other optional settings.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 49
50
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
2. Enter the current PIN (Original setting 0000) and press OK.
3. Enter the new PIN, press OK.
Confirm New PIN
is displayed.
Enter your new PIN again.
4. Press OK to confirm.
SIM Country Code
These settings control the conversion of numbers from mobile format which may include +44 and may have the 0 removed from the area code. You should not normally need to alter these settings if you are using your BT Calypso 120 in the UK and your mobile to call UK numbers. If this is not the case, then please call the BT Calypso Helpline for assistance on 0870 605 8047.
Default base settings
Base settings
If you enter the PIN incorrectly the screen shows Incorrect Pin.
Base ringtone Standard melody 5
Base ringer volume 5
System PIN 0000
Handset priority All handsets
SIM Country Codes Local 0
Country 44 International 00
6329 Calypso 120 UG 4/10/04 4:25 pm Page 50
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Use your phone as an alarm clock.
Set the date and time and use your BT Calypso 120 to give you a reminder alarm.
You can have a different alarm setting for each handset registered to your base. The alarm rings only at the handset, not at the base or any other handset.
Set alarm
1. Press Menu then scroll to
Time Settings
and press
OK. Press OK to select
Alarm
.
2. Press OK to select
On/Off
. Scroll or to highlight
the option you want:
On Once
– alarm goes off just once.
On Daily
– alarm goes off same time each day.
Off
– alarm off.
Press OK to confirm.
3. If you are setting an alarm, the screen shows
Time
. Enter the time you want the alarm to go off, e.g. for 7.30am, then press OK to confirm.
IMPORTANT
If you have subscribed to your network’s Caller Display service the date and time will be set automatically when you receive your first call and you will not need to set the date and time manually, although this is an option.
Time settings
When the alarm is switched on, the standby icon shows the icon
51
6329 Calypso 120 UG 4/10/04 4:25 pm Page 51
52
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Alarm tone
From a choice of 4, you can set which ringtone is played for your alarm.
1. Press Menu then scroll to
Time Settings
and press
OK. Press OK to select
Alarm
.
2. Press to highlight
Set Alarm Tone
, and press OK.
3. Scroll or to select the Alarm Tone you want then press OK to confirm.
Switch alarm off
1. When the alarm sounds, press any button on the handset to switch if off.
Set date and time
1. Press Menu then scroll to
Time Settings
and press
OK. Press to highlight
Set Date & Time
then press OK.
2. Enter the date, e.g. for 22nd February. Press OK to confirm.
3. Enter the time, e.g. for 2.30pm then press OK to confirm.
Time settings
6329 Calypso 120 UG 4/10/04 4:25 pm Page 52
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
You can create phonebook entries and adjust some handset settings such as ringer melody and volume on an unregistered handset or out of range handset.
IMPORTANT
Before registration, make sure the handset batteries are fully charged and that you are close to the base.
You can purchase additional handsets for your BT Calypso 120 by calling the BT Calypso Helpline on 0870 605 8047.
Expanding your system is easy.
Up to five handsets can be registered and operated from the BT Calypso 120.
You can make internal calls between two handsets while third is making an external call.
Each handset can be registered on up to four bases.
If you buy new handsets to use with your BT Calypso 120 they will have to be registered to the base before you can use them.
Register a new BT Calypso handset
At the base:
1. Press and hold until you hear the base beep. The handset screen will show the base ID number. Press OK to confirm. The handset screen then shows
Handset
Registered
. The handset reverts to standby and is given the first available handset number. You can now use the handset.
On the handset:
2. Press Menu, then scroll down to
Registration
and
press OK.
3.
Register Handset
is highlighted. Press OK.
Additional handsets and bases 53
6329 Calypso 120 UG 4/10/04 4:25 pm Page 53
54
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
4. If you have more than one base, scroll or to select the base. Press OK.
5. Enter the base’s SYSTEM PIN (original setting 0000). Press OK.
Register handset with an additional base
A handset registered with one base can then be registered with up to three more bases, e.g. at work, at home, at a relative’s home.
1. Press Menu then scroll to
Registration
and press OK.
2.
Register Handset
is highlighted. Press OK.
3. Scroll or to select the base. Press OK.
4. Enter the selected base’s SYSTEM PIN (original setting
0000). Press OK.
5. At the base: press and hold until you hear the base beep. The handset screen shows the base ID number, press OK. The handset reverts to standby and is given the first available handset number. It is now registered to the new base and ready for use.
Additional handsets and bases
To register a GAP compatible handset to your BT Calypso base, please refer to the instructions supplied with the handset you are trying to register.
All the bases that a handset can be linked to are indicated by an ✱.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 54
55
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Select base
You can switch your BT Calypso handset between bases. You can also set it to automatically select the base with the strongest signal. The handset must first be registered with each base individually.
1. Press Menu then scroll to
Registration
and press OK.
2. Scroll to
Select Base
then press OK. The current
base being used is highlighted.
3. Scroll or to select the base you want or
Automatic
to connect to the base with the strongest signal. Press OK.
De-register a handset
Use one handset to de-register another handset from the same base.
1. Press Menu then scroll to
Registration
and press OK.
2. Scroll down to
De-Register
. Press OK.
3. Enter the system PIN (original setting 0000) then press
OK. The screen lists all handsets registered to the base.
4. Scroll or to select the handset you want to deregister and press OK.
5. Press Ye s to confirm or Back to return to the previous screen listing the handsets.
Additional handsets and bases
6329 Calypso 120 UG 4/10/04 4:25 pm Page 55
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
Replacing the handset batteries
After a time, you may find that the handset batteries are running out of charge more quickly. This is a standard sign of wear and the batteries will need replacing.
For spare 2 x AAA rechargeable NiMH batteries, please contact the BT Calypso Helpline 0870 605 8047.
Remove the battery compartment cover and remove existing batteries. Insert new batteries and replace the compartment cover.
NOTE: BT accepts no responsibility for damage caused to your BT Calypso handset by using any other type of batteries.
Problems Possible cause
No display The batteries may be dead. Recharge or replace the
batteries.
Is the handset switched off? To switch the handset on, see page 16.
No dial tone Check that the telephone line cord is plugged into the
phone socket.
Check that the base is connected to the mains power and switched on.
56
6329 Calypso 120 UG 4/10/04 4:25 pm Page 56
57
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
Problems Possible cause
You cannot link up Is the display flashing ? Check that the base is with the base connected to the mains power and switched on.
Are you are out of range? Move the handset closer to the base.
Are the batteries low or flat? If so, charge the batteries or replace them if necessary.
If using more than one base, check that you are connected to the correct base, see page 55.
No ring on the handset Check that the ringer volume is switched on, see page 45.
Check that the base is plugged into the phone socket and that it is also connected to the mains power and switched on.
Buzzing noise on my Sometimes, your BT Calypso 120 and other DECT GAP radio, TV, computer compatible handsets can interfere with other electrical or hearing aid equipment if placed too close. Try moving it at least one
metre away from such appliances.
The charging does not Check that the base is plugged into the mains socket appear to be working and switched on.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 57
58
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
Problems Possible cause
Check that you are using the correct power adaptor plug. BT Calypso 120 base – Item Code 005391 BT Calypso 120 Twin charger – Item Code 021299 Check that the handset has slotted correctly into the base.
Check that the handset batteries have been correctly fitted.
Cannot adjust an Someone else might be making changes using another option in the base handset. Try again when the other handset user has
finished.
SMS messages The base station power supply or telephone line cord cannot be sent and might not be properly connected. Check that the base screen displays station power supply is plugged into the mains socket
Unable To Send and switched on and that the telephone is plugged into
the telephone wall socket. There might be a fault on the line.
Check your telephone line is working properly.
You might have deleted the server number in error. Refer to page 35 for instructions on how to enter the number.
Your SMS memory might be full. Delete unwanted text messages, see page 32.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 58
59
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
Problems Possible cause
More than one SMS product plugged into the line. Remove other products.
Cannot send text Check Service Centre number is correct including 1470
prefix.
Check call barring (option 4) is not activated on your line if you have the call barring service rented from BT.
Cannot receive text Check Service Centre number is correct.
Ensure you have subscribed to a Caller Display Service and that it is active. You can check this by noting if your phone displays data regarding your caller’s number when you receive an incoming call.
Handset is registered This may be due to your handset being de-registered. to the SMS service and text has been All you need to do is type Register and send it to 00000. previously sent and You will receive a confirmation message back. This received but you are assumes that your Caller Display service is active and now only receiving working on your line. incoming messages as voice text Note: Messages sent to 00000 are not charged for.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 59
60
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
Further help and advice for SMS related queries on BT lines:
BT Residential customers – call 151, choose option 2, when prompted by the Fault Management Service select option 2, input your phone number on the handset and wait to speak to a customer adviser.
BT Business customers – call 154, choose option 2, when prompted by the Fault Management Service select option 2, input your phone number on the handset and wait to speak to a customer adviser.
For other telephone service providers please contact their customer services.
General sales enquiries:
BT Residential lines – call 150. BT Business lines – call 152.
For other telephone service providers please contact their customer services.
Billing enquiries:
Refer to the telephone number shown on your telephone bill.
Other functions and services available from the SMS service
By sending the following commands to the BT text self administration facility you can control functions and capabilities in your SMS phone and the way messages are handled.
Press Menu. Press Menu again to select SMS. Press OK to select Write message. Type in the following commands (depending upon what you wish to do) and press Options then OK to send to 00000.
This will enable you to opt out from receiving voice text messages.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 60
61
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Help
BT Calypso Helpline
0870 605 8047
Call the dedicated BT Calypso Helpline:
if you are having difficulties using your BT Calypso 120 if you need replacement batteries or mains power lead
Lines open 9am – 5.30pm, Monday to Friday and 9.30am – 2.30pm, Saturday
Turns off the opt out option.
Turns on permanent voice text message delivery to your phone. This means all incoming text is delivered as voice text.
Turns off permanent voice text message delivery.
If you are sending a message from a fixed line phone to another fixed line phone.
Forces a message sent to be delivered as voice text even though the recipient may have an SMS enabled phone and usually receives written text.
This command is inserted at the start of the message and applies only to that message, e.g. Hello I will be home late”.
If you are sending a message from a fixed line phone and require a status report.
Will allow a status report to be send back to you when you have sent a message to confirm delivery. Place at the start of your text message. Write the message and send it. You will receive a reply text back to your phone giving the status report for that message.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 61
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Important
This equipment is not designed for making emergency telephone call when the power fails. Alternative arrangements should be made for access to emergency services.
This product is intended for connection to analogue public switched telephone networks and private switchboards in the United Kingdom.
Safety
General
Only use the power supply included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. The item number for the power supply used with the base is 005391. The item number for the power supply used with the charger is 021299 (only applicable when you have purchased the Calypso 120 Twin).
Use only the approved rechargeable batteries supplied. Spare rechargeable batteries are available from the BT Calypso Helpline 0870 605 8047.
Do not open the handset (except to replace the handset batteries) or the base. This could expose you to high voltages or other risks. Contact the Helpline for all repairs.
Radio signal transmitted between the handset and base may cause interference to hearing aids.
It is recommended that advice from a qualified expert be sought before using this product in the vicinity of emergency/intensive care medical equipment.
General information62
6329 Calypso 120 UG 4/10/04 4:25 pm Page 62
63
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
It is recommended that if you have a pacemaker fitted you check with a medical expert before using this product.
Your product may interfere with other electrical equipment, e.g. TV and radio sets, clock/alarms and computers if placed too close. It is recommended that you place your product at least one metre away from such appliances to minimise any risk of interference.
Never dispose of batteries in a fire. There is a serious risk of explosion and/or the release of highly toxic chemicals.
Cleaning
Simply clean the handset and base with a damp (not wet) cloth, or an anti-static wipe. Never use household polish as this will damage the product. Never use a dry cloth as this may cause a static shock.
Environmental
Do not expose to direct sunlight.
The produce may heat up when the batteries are being recharged or during prolonged periods of use. This is normal. However, we recommend that to avoid damage you do not place the product on antique/veneered wood.
Do not stand your product on carpets or other surfaces which generate fibres, or place it in locations preventing the free flow of air over its surface.
Do not submerge any part of your product in water and do not use it in damp or humid conditions, such as bathrooms.
General information
6329 Calypso 120 UG 4/10/04 4:25 pm Page 63
64
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Do not expose your product to fire, explosive or other hazardous conditions.
There is a slight chance that your phone could be damaged by an electrical storm. We recommend that you unplug the power and telephone line cord from the base for the duration of the storm.
Guarantee
Your BT Calypso 120 is guaranteed for a period of 12 months from the date of purchase.
Subject to the terms listed below, the guarantee will provide for the repair of, or at BT’s or its agent’s discretion the option to replace the BT Calypso 120 or any component thereof, (other than batteries), which is identified as faulty or below standard, or as a result of inferior workmanship or materials. Products over 28 days old from the date of purchase may be replaced with a refurbished or repaired product.
The conditions of this guarantee are:
The guarantee shall only apply to defects that occur within the 12 month guarantee period.
Proof of purchase is required.
The equipment is returned to BT or its agent as instructed.
This guarantee does not cover any faults or defects caused by accidents, misuse, fair wear and tear, neglect, tampering with the equipment, or any attempt at adjustment or repair other than through approved agents.
This guarantee does not affect your statutory rights.
General information
6329 Calypso 120 UG 4/10/04 4:25 pm Page 64
65
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Within the 12 month guarantee period:
If you experience difficulty using the product, prior to returning it, please read the Help section beginning on page 56, or contact the BT Calypso Helpline on 0870 605 8047, 9am to 5.30pm Monday to Friday and 9.30am to 2.30pm Saturday.
In the unlikely event of a defect occurring, please follow the Helpline’s instructions for replacement or repair.
Outside of the 12 month guarantee period:
If your product needs repair after the guarantee period has ended, the repair must meet the approval requirements for connection to the telephone network. We recommend that you contact BT’s approved repair agent, TecLogic on 08702 405029 or a local qualified repairer.
Returning your phone
If the Helpline is unable to remedy your problem they will ask you to return the product. Where possible, pack the product in its original packaging. Please remember to include all parts, including the line cords, power supply units and the original batteries. (Please note that we cannot take responsibility for goods damaged in transit.) Please obtain and keep proof of posting from the Post Office or Carrier.
General information
6329 Calypso 120 UG 4/10/04 4:25 pm Page 65
66
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Technical information
How many telephones can you have?
All items of telephone equipment have a Ringer Equivalence Number (REN), which is used to calculate the number of items which may be connected to any other telephone line. Your BT Calypso 120 has a REN of 1. A total REN of 4 is allowed. If the total REN of 4 is exceeded, the telephone may not ring.
With different telephone types there is no guarantee of ringing, even when the REN is less than 4.
Only use the approved power adaptor and charger.
Only use approved AAA NiMH rechargeable batteries.
Connecting to a switchboard
This product is intended for use within the UK for connection to public telephone network and compatible switchboards, which support tone dialling and timed break recall. If in doubt please consult your service provider.
General information
6329 Calypso 120 UG 4/10/04 4:25 pm Page 66
67
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Access code and entering a pause
If you are connecting your BT Calypso 120 to a switchboard/PBX you may need to prefix stored numbers with an access code (e.g. 9) in order to get an outside line. So that the switchboard has time to pick up an outside line, you may also need to add a Pause after the access code.
PABX access code
1. Press Menu then scroll to
Handeset
and press OK.
2. Scroll to
PABX access code
and press OK.
3. Display shows
Set Code
. Press OK.
4. Enter your PABX access code and press Save.
5. Scroll to
ON
and press OK.
6. Press and hold Back to return to standby.
Entering a pause
A pause is entered when storing a number in the phonebook (see page 23) or PABX access code by pressing and holding the button until the display shows
P
.
Recall
The (Recall) button is used when connected to certain switchboards (PBXs) and with some BT Calling Features, or equivalent services available via your Network Provider.
General information
6329 Calypso 120 UG 4/10/04 4:25 pm Page 67
68
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
General information
BT accessories and replacement items
For a full range of accessories and replacement items for BT products please call 0870 240 5522, or visit:
Enter your BT Calypso 120 base PIN here:
[
///
]
(see page 49 for more information)
Enter your BT Calypso 120 SMS security code here:
[
///
]
(see page 36 for more information)
For your records
Date of purchase:
Place of purchase:
Serial number:
For guarantee purposes proof of purchase is required so please keep your receipt.
Declaration of Conformance
Hereby, Suncorp Technologies declares that this BT Calypso 120 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
The Declaration of Conformance for the BT Calypso 120 is published on the website:
http://www.suncorptech.com/bt
R&TTE
This product is intended for use within the UK for connection to the public telephone network and compatible switchboards.
This equipment complies with the essential requirements for the Radio Equipment and Telecommunications Terminal Equipment Directive 1999/5/EC.
6329 Calypso 120 UG 4/10/04 4:25 pm Page 68
BT Calypso 120 – Edition 04 – 04.10.04 – 6329
Offices worldwide
The telecommunications services described in this publication are subject to availability and may be modified from time to time. Services and equipment are provided subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of any contract.
© British Telecommunications plc 2004. Registered Office: 81 Newgate Street, London EC1A 7AJ. Registered in England No. 1800000. BT Calypso 120 (10/04) 4 Designed and produced by The Art & Design Partnership Ltd. Printed in China
Visit us at www.bt.com
6329 Calypso 120 UG 4/10/04 4:25 pm Page 69
Loading...
