Brother HL-P2500, MFC-P2500 User Manual

Brother Laser Printer

PARTS REFERENCE LIST

MODEL: MFC-P2500 / HL-P2500

Read this list thoroughly before maintenance work.
Keep this list in a convenient place for quick and easy reference at all times.

Dec., 1999
PL-PRN003

NOTE FOR USING THIS PARTS REFERENCE LIST

1. In the case of ordering parts, it needs mentioning the following items:
(1) Code
(2) Q'ty
(3) Description
(4) Symbol ( PCB No., Revision , and Parts location mounted on the PCB.)

Note : No orders without Parts Code or Tool No. can be accepted.

<Example>

(1)

REF.NO. CODE Q’TY DESCRIPTION SYMBOL REMARK

Revision No.: marked on the main printed circuit board.

(2)

(3)

(4)

B48K056 - 201A

Design change indication
Specification No .
Pattern alteration No.
Circuit board No.

Revision No.: marked on the power supply printed circuit board.

Rev. A

Design change indication

(The first version has no sign.)

2. Design-changed parts :

If the parts are changed, any one of the following symbols is indicated in the REMARKS column.

#A : compatible between old and new
#B : replaceable from old to new
#D : incompatible
# : newly established

3. The original of this list was made based on the information available in December, 1999.

4. Parts are subject to change in design without prior notice.

CONTENTS

1. FRAME / DRIVE UNIT.......................................................................... 1

2. LASER UNIT.........................................................................................1

3. DOCUMENT SCANNER FRAME ......................................................... 3

4. PAPER FEEDER ..................................................................................5

5. FIXING UNIT......................................................................................... 7

6. PAPER CASSETTE......................................................................... 9AB

7. COVER...............................................................................................11

8. CONTROL PANEL.............................................................................. 13

9. MAIN PCB...........................................................................................15

10. ENGINE PCB......................................................................................15

11. LOW-VOLTAGE POWER SUPPLY PCB............................................ 17

12. HIGH VOLTAGE POWER SUPPLY PCB...........................................17

13. AC CORD ...........................................................................................19

14. ACCESSORIES..................................................................................19

15. DOCUMENTS..................................................................................... 21

16. PACKING MATERIALS ...................................................................... 21

17. ADJUSTMENT TOOL ......................................................................... 23

1. FRAME / DRIVE UNIT

REF.NO.

REF.NO.

CODE Q'TY DESCRIPTION SYMBOL REMARK
1 UL9311001 1 MAIN MOTOR ASSY
2 087320616 4 TAPTITE, CUP S M3X6
3 LJ4069001 1 SOLENOID ASSY
4 000300415 1 SCREW, BIND M3X4
5 LJ4432001 1 TAPE 32X12
6 UL8984001 1 LINK
7 LJ4745001 1 FAN MOTOR UNIT
8 UL9099001 1 TONER EMPTY PCB UNIT (LIGHT EMISSION) B512038
10 087320616 3 TAPTITE, CUP S M3X6
11 LJ7403001 4 RUBBER FOOT chg
12 UL9104001 1 TONER EMPTY PCB UNIT (LIGHT RECEPTION) B512037
13 087320616 2 TAPTITE, CUP S M3X6
14 LJ8031001 1 LT RELAY PCB ASSY B512060
15 087320616 1 TAPTITE, CUP S M3X6
16 LE1169001 1 USB GROUND PLATE
17 UL8970001 1 SOLENOID RELEASE SPRING 30/99
18 LJ5591001 1 PLANET GEAR ASSY (SP)
19 UL8985001 1 GEAR 59
20 LJ5705001 1 GEAR 21 PRESSURE PLATE
21 087320616 1 TAPTITE, CUP S M3X6
22 UG3005000 1 FERRITE CORE: 16X8X10
23 UL8972001 1 P/R CLUTCH LEVER
24 UL8971001 1 F/R CLUTCH LEVER
25 UL8982001 1 DEVELOP JOINT
26 UL8983001 1 JOINT SPRING

27 UL8959001 1 FRICTION SPRING delete

28 LJ5838001 1 PLANET GEAR ASSY B (SP) Ref.No.CHG

MODEL MFC-P2500/HL-P2500 84U-Z11-010

T/I NO. PR2000014 / PR2000073 / PR2000132 / PR2000152 / PR2001023 / PR2001049 / PR2001061

2. LASER UNIT

CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LJ4157001 1 LASER UNIT (SP) (B512033)
2 087321615 3 TAPTITE, CUP S M3X16

MODEL MFC-P2500/HL-P2500 84U-Z11-020

- 1 -

25

26

28

18

- 2 -

3. DOCUMENT SCANNER FRAME

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LE1072001 2 DOCUMENT SEPARATION ROLLER
2 UF4369000 1 PRESSURE ROLLER SHAFT
3 UF9009001 2 PRESSERE ROLLER
4 UU7032001 2 LF SPRING
5 UU2027001 1 SCANNER MOTOR
6 0A4300605 1 SCREW, PAN (S/P WASHER) M3X6
7 UU2028001 2 CIS SPRING
8 LE1160001 1 CIS UNIT ZL (SP)
9 UU2029001 1 DOCUMENT FEED ROLLER
10 LE1196001 2 ROLLER GEAR
11 UL6244002 2 EJECT PINCH ROLLER
12 UU2009001 2 EJECT PINCH ROLLER SPRING
13 UU2031001 1 DOCUMENT EJECT ROLLER
14 087311016 4 TAPTITE, CUP B M3X10
15 UU2006001 1 FEED ROLLER SHAFT ASSY
16 UU2008001 1 SEPARATION ROLLER SHAFT ASSY

T/I NO. PR2000063

MODEL MFC-P2500/HL-P2500 84U-Z11-015

-3-

3. DOCUMENT SCANNER FRAME

10

13

14

9

8

7

14

7

14

12

11

11

12

15

14

6

5

2

1

3

4

16

T/I NO. PR2000063

MODEL MFC-P2500/HL-P2500 84U-Z11-015

- 4 -

4. PAPER FEEDER

REF.NO.

CODE Q'TY DESCRIPTION REMARK
1 UL9060001 1 PAPER FEED ROLLER ASSY
2 UL9066001 1 PAPER PICK-UP ROLLER ASSY
3 LJ4499001 1 TR ELECTRODE HELICAL SPRING
4 LJ4843001 1 OUTER CHUTE 1 (SP)
5 UL9070001 1 GEAR 21
6 UL9059001 1 JOINT 5 add
7 UL9062001 2 BEARING 5 add
8 UL9069001 1 CONDUCTOR BEARING 5 add
9 UL9053001 2 TRANSFER ARM add
10 UL9052001 2 TRANSFER SPRING add
11 UL9049001 1 REGIST FRONT ACTUATOR ADD
12 UL9050001 1 REGIST REAR ACTUATOR ADD
13 UU2042001 1 ACTUATOR CASSET ADD
14 UL9051001 1 REGIST REAR ACTUATOR SPRING ADD

MODEL MFC-P2500/HL-P2500 84U-Z11-040

- 5 -

4. PAPER FEEDER

7

1

6

5

7

9

3

2

8

10

13

9

12

10

14

11

MODEL MFC-P2500/HL-P2500 84U-Z11-040

T/I NO. PR2000051 / PR2000108 / PR2000130

4

- 6 -

5. FIXING UNIT

REF.NO.

CODE Q'TY DESCRIPTION REMARK
1 LJ7759001 1 FIXING UNIT, 115V (SP) CHG
1 LJ7760001 1 FIXING UNIT, 230V (SP) CHG
1 LJ4718001 1 FIXING UNIT, 230LE (SP)
1-1 UL8902001 1 THERMISTOR ASSY
1-2 087311215 1 TAPTITE, CUP B M3X12
1-3 LJ4169001 1 HEAT ROLLER 25 (SP)
1-3 LJ4719001 1 HEAT ROLLER 25 LE (SP)
1-4 UL8908001 2 HR BEARING 25
1-5 LJ4160001 1 HALOGEN LAMP, 115V (SP)
1-5 LJ4163001 1 HALOGEN LAMP, 230V (SP)
1-6 UL8929001 8 EJECT PINCH ROLLER
1-7 LJ4431001 8 PINCH SPRING
1-8 LJ4407001 2 CLEANER ROLLER ASSY
1-9 LJ4409001 2 CLEANER SPRING
1-10 087312015 2 TAPTITE, CUP B M3X20
1-11 Z07200001 1 TAPTITE, PAN B M3X10
1-12 LJ4845001 4 PICK OFF FINGER (SP)
1-13 LJ4853001 1 PRESSURE ROLLER 20 (SP)
1-13 LJ4852001 1 PRESSURE ROLLER 20 LE (SP)
1-14 UL8920001 1 PAPER EJECT ACTUATOR
1-15 UL8921001 1 EJECT ACTUATOR SPRING
1-16 UL8914001 2 IDLE GEAR 13
1-17 LJ5871001 1 IDLE GEAR HOLDER
1-18 UL8923001 1 FU DRIVE GEAR 20/38
1-19 LJ7256001 1 EJECT ROLLER SHAFT L add
1-20 LJ7257001 1 EJECT ROLLER ASSY R add
1-21 LJ7259001 1 EJECT ROLLER BUSHING L add
1-22 LJ7260001 1 EJECT ROLLER BUSHING R add
1-23 LJ7261001 1 FU FRAME LOWER 2 add
1-24 LJ7262001 1 EJECT ROLLER JAM REMOVE TOOL add
1-25 UL8910001 1 HR GEAR 34 ADD
2 087320815 1 TAPTITE, CUP S M3X8
3 LJ4740001 2 SHOULDER SCREW

MODEL MFC-P2500/HL-P2500 84U-Z11-050/051

- 7 -

5. FIXING UNIT

3

2

1-9

1-9

1-8

3

1-6

1-8

1-6

1-7

1-12

1-10

1-7

1-12

1-10

1-18

1-12

1-11

1-12

1-15

1-14

1-2

1-13

1

1-3

1-4

1-5

1-1

1-25

1-24

1-4

1-19

1-21

1-22

1-20

1-23

MODEL MFC-P2500/HL-P25000 84U-Z11-050/051

T/I NO. PR2000029 / PR2000057 / PR2001118 / PR2002091

- 8 -

6-A. PAPER CASSETTE, LGL

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LE1162001 1 PAPER TRAY ASSY, LGL (SP)
1-1 LJ4537001 1 PRESSURE PLATE ASSY, LGL
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1 SEPARATION PAD SPRING
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4534001 1 PRESSURE ROLLER HOLDER, LGL
1-16

LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY DEL
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-23 LJ4332001 1 TRAY FEED GUIDE ASSY add
1-24 LJ5260001 1 PRESSURE ROLLER COLLAR ADD
1-25 LJ5261001 1 PRESSURE ROLLER SHAFT ADD

MODEL MFC-P2500/HL-P2500 84U-Z11-045

6-B. PAPER CASSETTE, A4

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LJ4181001 1 PAPER TRAY ASSY, A4 (SP)
1-1 UL9074001 1 PRESSURE PLATE ASSY, A4
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 UL9090001 1 SEPARATION PAD SPRING
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4196001 1 PRESSURE ROLLER HOLDER, A4
1-16

LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY DEL
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ2061001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-23 LJ4332001 1 TRAY FEED GUIDE ASSY add
1-24 LJ5260001 1 PRESSURE ROLLER COLLAR ADD
1-25 LJ5261001 1 PRESSURE ROLLER SHAFT ADD

MODEL MFC-P2500/HL-P2500 84U-Z11-047

- 9A -

6-C. PAPER CASSETTE, LEG

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LJ4684001 1 PAPER TRAY ASSY, LEG (SP)
1-1 UL9074001 1 PRESSURE PLATE ASSY, A4
1-2 UL9077001 2 PRESSURE PLATE SPRING
1-3 UL9078001 1 SIDE GUIDE L
1-4 UL9079001 1 SIDE GUIDE R
1-5 U73515001 2 TAPTITE, CUP B M2.6X5
1-6 UL9080001 2 SIDE GUIDE RACK
1-7 UL9081001 1 SIDE GUIDE GEAR
1-8 UL9082001 1 FRICTION SPRING
1-9 087310815 1 TAPTITE, CUP B M3X8
1-10 UL9083001 1 REAR PAPER GUIDE
1-11 UL9084001 1 SEPARATION PAD HOLDER ASSY
1-12 LJ4622001 1 SEPARATION PAD SPRING 250
1-13 UL9091001 1 PAPER INDICATOR
1-14 UL9092001 1 LOCK LEVER
1-15 LJ4196001 1 PRESSURE ROLLER HOLDER, A4
1-16
1-17 UL9095001 1 RELEASE LEVER EXTENSION SPRING
1-18 LJ4197001 1 PAPER TRAY COVER
1-19 UF8709001 1 TAPTITE, TORX PAN B M3X8
1-20 LJ4272001 1 TRAY COVER FILM
1-21 LJ4221001 1 SCRATCH SPONGE HOLDER ASSY
1-22 LJ4200001 2 SCRATCH SPONGE SPRING
1-23 LJ4332001 1 TRAY FEED GUIDE ASSY add
1-24 LJ5260001 1 PRESSURE ROLLER COLLAR ADD
1-25 LJ5261001 1 PRESSURE ROLLER SHAFT ADD

LJ4892001 1 PRESSURE ROLLER COLLAR 2 ASSY DEL

MODEL LJ6012MFP 84U-Z16-043

- 9B -

6. PAPER CASSETTE

1-3

1-4

1-10

1

1-1

1-2

1-13

1-2

1-12

1-24

1-11

1-25

1-21

1-22

1-15

1-23

1-17

1-14

1-6

1-18

1-19

MODEL MFC-P2500/HL-P2500 84U-Z11-045/047

1-5

1-8

1-7

1-9

1-20

- 10 -

7. COVERS PR2002017

REF.NO.

CODE Q'TY DESCRIPTION REMARK
1 LJ5753001 1 MAIN COVER ASSY
2 UL9122001 4 PINCH ROLLER ASSY
3 UL9125001 4 PINCH ROLLER SPRING

4 LJ5763001 1 REAR COVER

5 UL9127001 1 REAR COVER SPRING L
6 UL9128001 1 REAR COVER SPRING R
7 LJ4278001 1 FRONT COVER ASSY P25
7 LJ4733001 1 FRONT COVER ASSY P25 LEG
8 UL9140001 1 TRAY EXTENSION FLAP
9 LJ4280001 1 TOP COVER P25
10 UL9142001 1 SECOND EJECT ROLLER ASSY
11 UF6114008 1 DOCUMENT GUIDE, L
12 UF6115008 1 DOCUMENT GUIDE, R
13 UF4417000 1 GUIDE GEAR
14 UF4418001 1 PRESSURE SPRING
15 UF5034001 1 TAPTITE, B M3X6
16 UU2047001 1 SCANNING GROUND SPRING
17 087311016 1 TAPTITE, CUP B M3X10
18 087321015 2 TAPTITE, CUP S M3X10
19 UF9823001 2 SHOULDER SCREW
20 085320816 6 TAPTITE, BIND S M3X8
21 UL6740001 1 LASER CAUTION LABEL, EUR
21 UL7931001 1 LASER LABEL LEGEND
22 LJ4296001 1 MYLAR LABEL P2500, US
22 LJ4364001 1 MYLAR LABEL P2500, CAN
22 LJ4307001 1 MYLAR LABEL P2500, EUR
23 UG3005000 1 FERRITE CORE: 16X8X10
24 LJ4905001 1 FAN GUARD
25 UL9145001 1 PROCESS UNIT OP LABEL

26 LJ4855001 1 TRAY REAR COVER ASSY ADD

CHNG

MODEL MFC-P2500/HL-P2500 84U-Z11-060

T/I NO. PR2000003 / PR2000075 / PR2000108 / PR2000129 / PR2002017

- 11 -

7. COVERS

23

11

13

15

12

14

26

16

17

10

18

18

9

19

19

6

2

21

4

2

3

20

8

1

3

5

20

25

20

24

20

22

7

T/I NO. PR2000075 / PR2000108 / PR2000129

MODEL MFC-P2500/HL-P2500 84U-Z11-060

8. CONTROL PANEL

REF.NO.

CODE Q'TY DESCRIPTION SYMBOL REMARK

1 LJ4282001 1 PANEL COVER

1 LJ4928001 1 PANEL COVER, LEG

2 LJ4283001 5 KEY, FUNCTION 6

3 LJ4231001 3 KEY, FUNCTION 9.5

4 LJ4284001 1 KEY, TEN

5 LJ4231002 1 KEY, FUNCTION 9.5 (STOP)

6 LJ4285001 1 KEY, START

7 LJ8071001 1 PANEL PCB ASSY B512063

8 UG3062001 1 LCD

9 LJ8068001 1 FPC KEY 2500

10 UU2005001 1 PANEL REAR COVER

11 UU2051001 1 DOCUMENT NIP PIECE SPRING

12 UU2052001 1 DOCUMENT NIP PIECE

13 UU2053001 1 ADF SPRING

14 UU2054001 1 RUBBER HOLDER

15 UU2055001 1 SEPARATION RUBBER

16 UU2056001 1 FRONT SPRING PLATE

17 UF5034001 1 TAPTITE, B 3X6

18 UU2057001 1 DOCUMENT PRESSURE BAR SPRING

19 UU2058001 1 DOCUMENT PRESSURE BAR

20 UU2061001 1 DOC FRONT SENSOR ACTUATOR

21 UU2062001 1 DOC REAR SENSOR ACTUATOR

22 LE1071001 1 ANTI-STATIC BRUSH ZLM

23

087310815 1 TAPTITE, CUP B M3X8

24

087311016

6 TAPTITE, CUP B M3X10

25 LJ4287001 1 LCD COVER, US

25 LJ4316001 1 LCD COVER, EU

25 LJ4736001 1 LCD COVER, LEG

MODEL MFC-P2500/HL-P2500 84U-Z11-090

T/I NO. PR2000003 / PR2000122

- 13 -

8. CONTORL PANEL

17

21

19

16

15

14

12

18

22

23

13

24

20

11

10

24

7

24

24

24

24

8

9

3

2

4

2

6

5

1

25

MODEL MFC-P2500/HL-P2500 84U-Z11-090

- 14 -

9. MAIN PCB

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1 LJ8241001 1 MAIN PCB ASSY, US (SP) B512062-111
1 LJ8242001 1 MAIN PCB ASSY, EU (SP) B512062-112
1 LJ8263001 1 MAIN PCB ASSY, CHILE (SP) B512062-119
1 LJ8258001 1 MAIN PCB ASSY LEG (SP) B512062-113
1-1 LJ8256001 1 MASK ROM
2 LE1169001 1 USB GROUND PLATE, EU

MODEL MFC-P2500/HL-P2500 84U-Z11-102/103

T/I NO. PR2000003

10. ENGINE PCB

REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK

1 LE1506001 1 ENGINE PCB ASSY (SP) B512059-423

MODEL MFC-P2500/HL-P2500 84U-Z11-151

-15-

9. MAIN PCB

1

1-1

2

10. ENGINE PCB

MODEL MFC-P2500/HL-P2500 84U-Z11-101/103

1

MODEL MFC-P2500/HL-P2500 84U-Z11-151

- 16 -

11. LOW-VOLTAGE POWER SUPPLY PCB

REF.NO.

REF.NO.

CODE Q'TY DESCRIPTION SYMBOL REMARK
1 LG4015001 1 PS PCB ASSY ZLE-B,115V
1 LG4016001 1 PS PCB ASSY ZLE-B,230V
2 UK4426001 1 INLET UNIT, 115V
2 UK4430001 1 INLET UNIT, 230V
3 085320816 1 TAPTITE, BIND S M3X8
4 087320616 1 TAPTITE, CUP S M3X6
5 LJ4756001 1 AC INLET FILM
6 LJ8330001 1 PROTECTION TUBE

CHNG
CHNG

MODEL MFC-P2500/HL-P2500 84U-Z11-200/201

T/I NO. PR2000113 / PR2001064

12. HIGH-VOLTAGE POWER SUPPLY PCB

CODE Q'TY DESCRIPTION REMARK
1 LJ8156001 1 HIGH-VOLTAGE PS ASSY (SP)
2 085411215 4 SCREW BIND B TITE M4X12

MODEL MFC-P2500/HL-P2500 84U-Z11-220

- 17 -

11. LOW-VOLTAGE POWER SUPPLY PCB

2

4

6

1

T/I NO. PR2000113

MODEL MFC-P2500/HL-P2500 84U-Z11-200/201

12. HIGH-VOLTAGE POWER SUPPLY PCB

5

3

1

2

2

MODEL MFC-P2500/HL-P2500 84U-Z11-220

- 18 -

13. AC CORDS

REF.NO. CODE Q'TY DESCRIPTION REMARK

1A UH1051001 1 AC CORD, UL/CSA
1B UK4503001 1 AC CORD ASSY, SAA
1C UK4502001 1 AC CORD ASSY, SEV
1D UK4099001 1 AC CORD, CHLI
1E UH1054001 1 AC CORD, BS
1F U34322001 1 AC CORD #6, ISRAEL
1G U34320001 1 AC CORD #4, BS
1H UK4094001 1 AC CORD, DEMKO
1I UK4501001 1 AC CORD ASSY, VDE
1J UK3610001 1 AC CORD ASSY, CHN96

MODEL MFC-P2500/HL-P2500 84U-Z11-230

T/I NO. PR2000003

14. ACCESSORIES

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 UU2080001 1 DOCUMENT SET TRAY ASSY
2 UU2069001 1 PAPER EJECT TRAY ASSY
3 UG4558001 1 I/F CABLE FE

MODEL MFC-P2500/HL-P2500 84U-Z11-910

-19-

13. AC CORD

1A

1B

1C

1D

1E

T/I NO.PR2000003

1F

1G

1H

1I

1J

MODEL MFC-P2500/HL-P2500 84U-Z11-230

14. ACCESSORIES

2

1

3

MODEL MFC-P2500/HL-P2500 84U-Z11-910

- 20 -

15. DOCUMENTS

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LJ4291001 1 CD ASSY US
1 LJ4308001 1 CD ASSY EU
1 LJ8247001 1 CD ASSY LEG
2 LJ4292001 1 SET GUIDE, US
2 LJ4309001 1 SET GUIDE, GER
2 LJ4366001 1 SET GUIDE, FRA
2 LJ4376001 1 SET GUIDE, NL
2 LJ4373001 1 SET GUIDE, NOR
2 LJ4396001 1 SET GUIDE, SWE
2 LJ4388001 1 SET GUIDE, SPA
2 LJ4392001 1 SET GUIDE, ITA
2 LJ4873001 1 SET GUIDE, DEN
3 LJ4812001 1 WIN2000 QUICK SETUP GUIDE, US
3 LJ4813001 1 WIN2000 QUICK SETUP GUIDE, GER
3 LJ4814001 1 WIN2000 QUICK SETUP GUIDE, FRA
3 LJ4815001 1 WIN2000 QUICK SETUP GUIDE, NOR
3 LJ4816001 1 WIN2000 QUICK SETUP GUIDE, NL
3 LJ4817001 1 WIN2000 QUICK SETUP GUIDE, SPA
3 LJ4818001 1 WIN2000 QUICK SETUP GUIDE, ITA
3 LJ4819001 1 WIN2000 QUICK SETUP GUIDE, SWE
4 LJ4830001 1 USER'S MANUAL 6012MFP

(LEG HLP2500)

5 UE2014001 1 BAG, 215X350H

MODEL MFC-P2500/HL-P2500 84U-Z11-920

T/I NO. PR2000003 / PR2000022 / PR2000024 / PR2000067

16. PACKING MATERIALS

REF.NO. CODE Q'TY DESCRIPTION REMARK

1 LJ4300001 1 CARTON, P2500 US
1 LJ4367001 1 CARTON, P2500 CAN
1 LJ4311001 1 CARTON, P2500 EU
1 LL0173001 1 CARTON, P2500 LEG
2 LJ4301001 1 SF ASSY P2500
3 UE3031001 1 BAG, 800X900H
4 UE3122001 1 CARTON FOR MANUAL

T/I NO. PR2000003

MODEL MFC-P2500/HL-P2500 84U-Z11-930

-21-

15. DOCUMENTS

1

4

2

3

5

T/I NO. PR2000022 / PR2000024

16. PACKING MATERIALS

2

1

MODEL MFC-P2500/HL-P2500 84U-Z11-920

4

3

2

MODEL MFC-P2500/HL-P2500 84U-Z11-930

- 22 -

17. ADJUSTING TOOL

PRT-402

TOOL NO. TOOL NAME REMARK

PRT-402
PRT-001a

PRT-001b
PRT-001f

TORX SCREW DRIVER
MOLYKOTE EM-30L

MOLYKOTE EMD-110
MOLYKOTE PG-662

PRT-001f

MODEL MFC-P2500/HL-P2500 84U-Z11

- 23 -
