PARTS LIST
CAP FRAME
(9804)
P-WH11-E
ßE ÄÂËÂϾÉÓÆÂÔ
ÑÑÞÞßßééââììããÀÀììëëññâëâëññðð
, ¥
, ¥
, ¥
, ¥
, ¥ ¥
, ¥ ¥
, ¥
, ¥
, ¥
, ¥
, ¥¥
, ¥¥
&YQMBOBUJPOPG.BSLTsTBOEsTBU&OEPG1BSU/P
k
Please specify, in the follow ing m anner, your m achine model,m anufacturing num ber and
Û
em broidery space w hen you order us with the parts having **** at the end of the part No.:
EE
&Y
Please specify the num ber of needles on your m achine’s head in your parts order by changing
E Û
the marks #### into one of the 4-digit num bers below :
E
&Y
TMFD-612 (450×275)S N o.01234
[M od el] [E mb. Sp ac e] [M fg. N o .]
The part Num ber, EF012345####
4-digit Num bers M achine Type
E
0300…………………3-needle machine
EEE
0600…………………6-needle machine
EEE
0900…………………9-needle machine
EEE
1200…………………12-needle machine
EEE
l
¿Å
WH-1
BASE SASH (TME-DC)
30
31
32
16
27
8
14
17
26
34
37
35
2
38
39
36
18
15
28
19
9
1
10
11
3
12
13
29
23
25
24
33
20
21
23
22
3
3
4
6
7
5
(BH04)
BASE SASH (TME-DC)
BASE SASH (TNE-DC)
WH-1
Ref.No.
1
Y-axis Base Sash CD0J0100****
2
Rail Plate CD0J07000000
3
Hexagon Socket Head Cap Screw SS6205150TN0
4
Screw Bushing WH0121000000
5
Y-axis Frame Sash Block CD0J10000000
6
Block Fixing Bolt CD0J11000000
7
Return Spring CD0J12000000
8
Y-axis Frame Sash Support CD0J04000000
9
Truss Head Screw SS0104100SD0
10
Guide Block WH0117000000
11
Countersunk Head Screw SS1103100SD0
12
Skid Plate WH0114010000
13
Countersunk Head Screw SS1103080SD0
14
Slide Angle CD0J0200****
15
Slide Block WH0116000000
16
Truss Head Screw SS0105120SD0
17
Right Side Slide Block CD0J08000000
18
Truss Head Screw SS0105150SD0
19
Drive Wire WH0126000000
20
Guide Plate WH0125000000
21
Slide Nut WH0127000000
22
Hexagon Socket Head Cap Screw SS6204100TN0
23
Plain Washer WSP04A008SD0
24
Wire Guide Ring WH0124000000
25
Hexagon Socket Head Cap Screw SS6204120TN0
26
Slide Base CD0J03020000
26
Slide Base CD0J09010000
27
Truss Head Screw SS0105060SD0
28
Insert Bushing WH0113000000
29
Bearing Pin WH0107000000
30
Hexagon Nut SSN206SC0000
31
Spring Washer WSS060000KC0
32
Plain Washer WSP06D010SC0
33
Eccentric Bearing Pin WH0108000000
34
WH Attaching Psitioning Indicator CD0B27000000
35
Joint Base CD0J05000000
36
Joint Spacer CD0J06000000
37
Truss Head Screw SS0105080SD0
38
Hexagon Socket Head Cap Screw SS6205150TP0
39
Plain Washer WSP05C008SD0
40
41
42
43
44
45
46
47
48
49
Description Part No. Remark
M5*15
M4*10
M3*10
M3*8
M5*12
M5*15
M4*10
M4
M4*12
500P M/C
M5*6
M6 Type 3
M6
M6
M5*8
M5*15
M5
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-2
BASE SASH (TMFD-C, TMFXIII-C)
BASE SASH (TMFD-C,TMFXV -C)
27
28
29
24
11
14
23
13
31
33
34
35
15
13
30
12
25
16
1
7
8
4
26
20
22
21
17
18
20
19
5
4
3
3
4
9
10
32
2
6
(BH04)
BASE SASH (TMFD-C, TMFXIII-C)
BASE SASH (TMFD-C,TMFXV-C)
WH-2
Ref.No.
1
Y-axis Base Sash WH110100****
2
Y-axis Frame Sash Plate WH011200****
3
Hexagon Socket Head Cap Screw SS6205200TN0
4
Screw Bushing WH0121000000
5
Hexagon Socket Head Cap Screw SS6205150TN0
6
Y-axis Frame Sash Block WH0115000000
7
Guide Block WH0117000000
8
Countersunk Head Screw SS1103100SD0
9
Skid Plate WH0114010000
10
Countersunk Head Screw SS1103080SD0
11
Slide Angle WH110200****
12
Slide Block WH0116000000
13
Truss Head Screw SS0105120SD0
14
Right Side Slide Block WH1111000000
15
Truss Head Screw SS0105150SD0
16
Drive Wire WH0126000000
16
Drive Wire WH0129000000
17
Guide Plate WH0125000000
18
Slide Nut WH0127000000
19
Hexagon Socket Head Cap Screw SS6204100TN0
20
Plain Washer WSP04A008SD0
21
Wire Guide Ring WH0124000000
22
Hexagon Socket Head Cap Screw SS6204120TN0
23
Bearing Base WH1103010000
24
Truss Head Screw SS0105060SD0
25
Insert Bushing WH0113000000
26
Bearing Pin WH0107000000
27
Hexagon Nut SSN206SC0000
28
Spring Washer WSS060000KC0
29
Plain Washer WSP06D010SC0
30
Eccentric Bearing Pin WH0108000000
31
WH Attaching Psitioning Indicator CD0B27000000
32
Corner WH1112000000
33
Hexagon Socket Head Cap Screw SS6205150TP0
34
Spring Washer WSS050000KD0
35
Plain Washer WSP05C008SD0
36
37
38
39
40
41
42
43
44
45
46
47
48
49
Description Part No. Remark
M5*20
M5*15
M3*10
M3*8
M5*12
M5*15
460P M/C
M4*10
M4
M4*12
M5*6
M6 Type 3
M6
M6
M5*15
M5
M5
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-3
BASE SASH (TMFXII-C)
BASE SASH (TMFXU -C)
7
6
5
26
5
9
14
24
25
13
15
13
12
11
10
1
18
7
6
5
2
3
8
4
23
22
27
17
16
19
20
21
(BH04)
BASE SASH (TMFXII-C)
BASE SASH (TMFXU-C)
WH-3
Ref.No.
1
Slide Angle WH0516010000
1
Slide Angle WH0503010000
1
Slide Angle WH0519010000
1
Slide Angle WH0512010000
1
Slide Angle WH0526010000
1
Slide Angle WH0523010000
2
Truss Head Screw SS0105060SD0
3
Cap Joint Plate WH0517020000
3
Cap Joint Plate WH0504020000
3
Cap Joint Plate WH0520020000
3
Cap Joint Plate WH0513020000
3
Cap Joint Plate WH0527020000
3
Cap Joint Plate WH0524020000
4
Rail Plate WH052900****
5
Hexagon Socket Head Flange Screw WH0515000000
6
Positioning Boss WH0501000000
7
Truss Head Screw SS0105100SD0
8
Insert Bushing WH0505000000
9
Drive Wire WH0126000000
10
Guide Plate WH0125000000
11
Slide Nut WH0127000000
12
Hexagon Socket Head Cap Screw SS6204100TN0
13
Plain Washer WSP04A008SD0
14
Wire Guide Ring WH0124000000
15
Hexagon Socket Head Cap Screw SS6204120TN0
16
Cap Frame Base WH0518030000
16
Cap Frame Base WH0508030000
16
Cap Frame Base WH0521030000
16
Cap Frame Base WH0514030000
16
Cap Frame Base WH0528030000
16
Cap Frame Base WH0525030000
17
Silicone Tape BP5423010300
18
Hexagon Socket Head Flange Screw BPM5X10L0000
19
Roller Pin CX03B8010000
20
Needle Bearing BPHK0509T200
21
Hexagon Socket Head Set Screw SS8203040TN0
22
Skid Plate WH0522000000
23
Countersunk Head Screw SS1103080SD0
24
Shim Plate L EC0203L00000
25
Hexagon Socket Head Cap Screw SS6205100TN0
26
Countersunk Head Screw SS1105120SD0
27
Shim Plate R EC0203R00000
28
29
30
31
32
33
34
35
Description Part No. Remark
1-H M/C
2-H M/C
4-H M/C
4-H M/C (360P)
4-H M/C (500P)
6-H M/C
M5*6
1-H M/C
2-H M/C
4-H M/C
4-H M/C (360P)
4-H M/C (500P)
6-H M/C
M5*10
M4*10
M4
M4*12
1-H M/C
2-H M/C
4-H M/C
4-H M/C (360P)
4-H M/C (500P)
6-H M/C
M3*4
M3*8
M5*10
M5*12
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-4
BASE SASH (TMEX-C)
25
23
14
15
21
22
16
19
20
18
17
2
7
5
12
11
13
11
10
24
9
8
1
3
6
4
(BH04)
BASE SASH (TMEX-C)
WH-4
Ref.No.
1
Slide Angle WH0516010000
2
Truss Head Screw SS0105060SD0
3
Cap Joint Plate EC0205020000
3
Cap Joint Plate EC0N02010000
4
Rail Plate WH052900****
5
Truss Head Screw SS0104080SD0
6
Steel Nut BPNQ41500000
7
Drive Wire WH0126000000
8
Guide Plate WH0125000000
9
Slide Nut WH0127000000
10
Hexagon Socket Head Cap Screw SS6204100TN0
11
Plain Washer WSP04A008SD0
12
Wire Guide Ring WH0124000000
13
Hexagon Socket Head Cap Screw SS6204120TN0
14
Cap Frame Base WH0518030000
15
Silicone Tape BP5423010300
16
Roller Pin CX03B8010000
17
Needle Bearing BPHK0509T200
18
Hexagon Socket Head Set Screw SS8203040TN0
19
Skid Plate WH0522000000
20
Countersunk Head Screw SS1103080SD0
21
Shim Plate L EC0203L00000
22
Hexagon Socket Head Cap Screw SS6205100TN0
23
Countersunk Head Screw SS1105120SD0
24
Shim Plate R EC0203R00000
25
Hexagon Socket Head Flange Screw BPM5X10L0000
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
Description Part No. Remark
M5*6
9,12-Needle
1-Needle
M4*8
M4*10
M4
M4*12
M3*4
M3*8
M5*10
M5*12
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-5-1
BASE FRAME 1
BASE FRAME 1
20 18
19
17
17
16
12
19
22
2018
21
1
8
6
7
9
10
9
8
7
2
2
5
11
3
6
27
28
4
6
6
5
16
15
13
24
14
24
29
23
30
3
21
26
25
33
32
22
31
(BH04)
TMFXII-C
TMFXIII-C
TMFXII-C
TMFXII-C,TMFXIII-C
BASE FRAME 1
WH-5-1
Ref.No.
1
Base Frame Complete Set HFU012010000
1
Base Frame Complete Set HFU013010000
1
Base Frame Complete Set HFU016010000
1
Base Frame Complete Set HFU017010000
2
Base Bracket WH0215000000
2
Base Bracket WH0502000000
3
Truss Head Screw SS0105150SD0
4
Base Holder Shaft WH0204000000
5
Hexagon Socket Head Cap Screw SS6204180TN0
6
Plain Washer WSP04C010SC0
7
8mm Dia. Collar WH0231000000
8
Hexagon Socket Head Set Screw SS8204040TN0
9
Base Holder Roller EC0G19010000
10
Liner Plate EF0709200000
11
Drive Base EC0G18010000
12
Guide Base L WH0234000000
13
Guide Base R WH0235000000
14
Truss Head Screw SS0104080SD0
15
Reinforcing Plate EC0G17000000
16
Truss Head Screw SMF8020540CL
17
Guide Bracket WH0209000000
18
Needle Plate Guide WH0208010000
19
Felt WH0226000000
20
Round Countersunk Head Screw SMC5000535CL
21
Inner Groove Ring Guide WH0222000000
22
Truss Head Screw SS0104200SD0
23
Guide Roller A WH0236000000
24
Truss Head Screw SS0104060SD0
25
Guide Roller Shaft WH0237000000
26
E-ring BPE600000000
27
Hexagon Nut SSN008SC0000
28
Plain Washer WSP08F016SC0
29
Guide Roller B WH0217010000
30
Eccentric Guide Pin WH0219000000
31
Hexagon Nut SSN005SC0000
32
Spring Washer WSS050000KC0
33
Plain Washer WSP05C008SC0
34
35
36
37
38
39
40
41
42
43
44
45
46
Description Part No. Remark
For TMFD-C,TMFXV-C
For TNFXU-C
For TME-DC
For TMEX-C
For TME-DC,TMFD-C,TMFXV -C
For TMFXU-C,TMEX-C
M5*15
M4*18
M4
M4*4
For TMFD-C,TMFXU -C,TMFXV -C
M4*8
9/64*40*4
9/64*40*3.5
M4*20
M4*6
M8
M8
M5
M5
M5
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-5-2
BASE FRAME 2
BASE FRAME 2
27
26
28
26
30
32
29
31
13
12
15
6
20
14
5
4
2
22
21
23
5
4
10
3
7
7
24
1
19
25
22
21
13
18
11
17
15
16
14
8
8
11
9
10
(BH04)
TMFXII-C,TMFXIII-C
BASE FRAME 2
WH-5-2
Ref.No.
1
Drive Ring WH0213000000
2
Center Block WH0203000000
3
Round Countersunk Head Screw SMC5000535CL
4
Presser Bar Spring WH0212000000
5
Truss Head Screw SS0103040SD0
6
Lever Bracket L WH0205000000
7
Countersunk Head Screw SS1104080MZ0
8
Hexagon Nut SSN204SD0000
9
Releasing Lever L WH0201000000
10
Lock Pin WH0207000000
11
Hexagon Socket Head Button Screw SS3204060SC0
12
Lever Spring L WH0224000000
13
Lever Pin WH0229000000
14
Hexagon Nut SSN004SD0000
15
Spring Washer WSS040000KC0
16
Lever Bracket R WH0206000000
17
Releasing Lever R WH0202000000
18
Lever Spring R WH0225000000
19
Wire Fixing Fittings WH0123000000
20
Countersunk Head Screw SS1103120MZ0
21
Hexagon Nut SSN003SD0000
22
Spring Washer WSS030000KD0
23
Base Frame Presser Roller WH0232000000
24
Countersunk Head Screw SS1103150MZ0
25
Plain Washer WSP038005SD0
26
Needle Plate EC0C19010000
27
Cap Frame Guide WH0221020000
28
Countersunk Head Screw SS1103080SD0
29
Cap Frame Guide EC0G02010000
30
Guide Fixture EC0G30000000
31
Countersunk Head Screw SS1103040SD0
32
Hexagon Socket Head Cap Screw SS6203100TN0
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Description Part No. Remark
9/64*40*3.5
M3*4
M4*8
M4 Type 3
M4*6
M4
M4
M3*12
M3
M3
M3*15
M3
For TMFD-C,TMFXU -C,TMFXV -C
M3*8
For TME-DC,TMEX-C
M3*4
M3*10
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-6
WIDE CAP FRAME (STANDARD)
WIDE CAP FRAME (STANDARD)
1
21
18 19 20
23
3
4
5
18
22
17
16
15
11
7
2
9
10
11
6
8
12
12
14
13
(BH04)
WIDE CAP FRAME (STANDARD)
WH-6
Ref.No.
1
Wide Cap Frame Complte Set HFU010020150
2
Base Frame WH0301010000
3
Visor Bracket WH0303000000
4
Hexagon Socket Head Cap Screw SS6203080TN0
5
Plain Washer WSP038005SC0
6
Fixing Pin WH0304000000
7
Base Frame Shaft L WH0320L00000
8
Base Frame Shaft R WH0320R00000
9
Hexagon Nut SSN004SD0000
10
Spring Washer WSS040000KD0
11
Plain Washer WSP04A008SD0
12
Clip Stopper WH0321000000
13
Hexagon Socket Head Set Screw SS8204040TN0
14
Double Clip WH0306000000
15
E-ring BPE500000000
16
Lid Frame Fittings A WH0309010000
17
Countersunk Head Screw SS1103060SD0
18
Hexagon Nut SSN003SD0000
19
Spring Washer WSS030000KD0
20
Plain Washer WSP038005SD0
21
Lid Frame A WH0308020000
22
Pinch Lock BPC112900000
23
Truss Head Screw SS0103050MZ0
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Description Part No. Remark
M3*8
M3
M4
M4
M4
M4*4
M3*6
M3
M3
M3
M3*5
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-7
WIDE CAP FRAME (CHILD-USE)
WIDE CAP FRAME (CHILD-USE)
1
18
19
20
23
21
3
18
4
5
22
2
17
6
16
15
9
10
7
11
11
12
13
12
14
8
(BH04)
WIDE CAP FRAME (CHILD-USE)
WH-7
Ref.No.
1
Wide Cap Frame Complte Set HFU010B10150
2
Base Frame WH0301010000
3
Visor Bracket WH0303000000
4
Hexagon Socket Head Cap Screw SS6203080TN0
5
Plain Washer WSP038005SC0
6
Fixing Pin WH0304000000
7
Base Frame Shaft L WH0320L00000
8
Base Frame Shaft R WH0320R00000
9
Hexagon Nut SSN004SD0000
10
Spring Washer WSS040000KD0
11
Plain Washer WSP04A008SD0
12
Clip Stopper WH0321000000
13
Hexagon Socket Head Set Screw SS8204040TN0
14
Double Clip WH0306000000
15
E-ring BPE500000000
16
Lid Frame Fittings A WH0309010000
17
Countersunk Head Screw SS1103060SD0
18
Hexagon Nut SSN003SD0000
19
Spring Washer WSS030000KD0
20
Plain Washer WSP038005SD0
21
Lid Frame C WH0322000000
22
Pinch Lock BPC112900000
23
Truss Head Screw SS0103050MZ0
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Description Part No. Remark
M3*8
M3
M4
M4
M4
M4*4
M3*6
M3
M3
M3
M3*5
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-8
SEMI-WIDE CAP FRAME
SEMI-WIDE CAP FRAME
1
14
15
16
20
16
18
17
19
13
11
12
151610
14
3
4
5
2
6
7
8
9
(BH04)
SEMI-WIDE CAP FRAME (STANDARD TYPE)
WH-8
Ref.No.
1
Semi-wide Cap Frame Complete Set HFU011000150
2
Base Frame A Set WH0311000000
3
Visor Bracket WH0303000000
4
Hexagon Socket Head Cap Screw SS6203080TN0
5
Plain Washer WSP038005SC0
6
Base Frame B WH0312000000
7
Round Countersunk Head Screw SMC5000535CL
8
Reinforcing Pipe HF0304000000
9
E-ring BPE500000000
10
Lid Frame Fittings WH0313000000
11
Lid Frame A WH0315010000
12
Lid Frame B WH0316000000
13
Bolt Base Set WH0314010000
14
Wing Nut SSN403SD0000
15
Spring Washer WSS030000KD0
16
Plain Washer WSP038005SD0
17
Clamp Base HF0307000000
18
Pinch Lock BPC112900000
19
Countersunk Head Screw SS1103060MZ0
20
Hexagon Nut SSN003SD0000
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Description Part No. Remark
M3*8
M3
9/64*40*3.5
M3
M3
M3
M3*6
M3
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-9
SEMI-WIDE CAP FRAME (R-TYPE)
SEMI-WIDE CAP FRAME (R-TYPE)
1
14
15
16
20
16
18
17
19
13
11
12
151610
14
3
4
5
2
6
7
8
9
(BH04)
SEMI-WIDE CAP FRAME (R-TYPE)
WH-9
Ref.No.
1
Semi-wide Cap Frame(R-Type) Complete Set HFU011R00000
2
Base Frame A Set WH0311000000
3
Visor Bracket WH0303000000
4
Hexagon Socket Head Cap Screw SS6203080TN0
5
Plain Washer WSP038005SC0
6
Base Frame B WH0317000000
7
Round Countersunk Head Screw SMC5000535CL
8
Reinforcing Pipe HF0304000000
9
E-ring BPE500000000
10
Lid Frame Fittings WH0313000000
11
Lid Frame A WH0318010000
12
Lid Frame B WH0316000000
13
Bolt Base Set WH0314010000
14
Wing Nut SSN403SD0000
15
Spring Washer WSS030000KD0
16
Plain Washer WSP038005SD0
17
Clamp Base HF0307000000
18
Pinch Lock BPC112900000
19
Countersunk Head Screw SS1103060MZ0
20
Hexagon Nut SSN003SD0000
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Description Part No. Remark
M3*8
M3
9/64*40*3.5
M3
M3
M3
M3*6
M3
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-10-1
SETTING FRAME 1
SETTING FRAME 1
10
9
11
1
4
2
12
7
13
8
14
3
5
6
(BH04)
SETTING FRAME 1
WH-10-1
Ref.No.
1
Gauge Frame Complete Set HFU014020000
2
Gauge Ring B WH0422000000
3
Hexagon Socket Head Flange Screw BPM4X8L00000
4
Setting Sub Base Set HF0405S20000
5
Gauge Frame Complete Set HFU01402000S
6
Gauge Ring B WH0423000000
7
Wire Tension Gauge Set HFU015000000
7
Wire Tension Gauge Set HFU015000460
8
Tension Block A WH0403000000
9
Tension Block B WH0404000000
10
Wing Bolt BPBOLTM06X10
11
Tension Shaft WH0405000000
11
Tension Shaft WH0407000000
12
Tension Nut WH0406000000
13
8mm Dia. Collar EF0418000000
14
E-ring BPE500000000
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Description Part No. Remark
Wide Cap Frame
Wide Cap Frame
Semi-Wide Cap Frame
Semi-Wide Cap Frame
460P M/C
460P M/C
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
WH-10-2
SETTING FRAME 2
SETTING FRAME 2
18
11
12
13
14
41
40
37
39
36
38
13
34
42
33
32
35
30
31
35
29
28
33
32
38
19
41
45
39
15
44
17
16
13
21
43
42
36
1
3
5
10
2
9
4
8
7
3
24
6
26
25
23
26
24
25
14
27
22
20
(BH04)
SETTING FRAME 2
WH-10-2
Ref.No.
1
Setting Frame Base Set UN34050B0000
2
Setting Frame Base A WH0412000000
3
Hexagon Socket Head Cap Screw SS6205120TN0
4
Setting Frame Base B HF0402040000
5
Setting Frame Base C Set WH0416S00000
6
Setting Frame Base C HF0403030000
7
Wing Bolt WH0415000000
8
Table Patch Plate WH0413000000
9
Countersunk Head Screw SS1103080SD0
10
Patch Plate Rubber WH0414000000
11
Roller Bracket WH0419000000
12
Hexagon Socket Head Cap Screw SS6204100TN0
13
Spring Washer WSS040000KC0
14
Plain Washer WSP04A008SC0
15
Base Frame Presser Roller WH0232000000
16
Pan Head Screw SS4103050SD0
17
Plain Washer WSP038005SD0
18
Hexagon Nut SSN003SD0000
19
Hexagon Socket Head Cap Screw SS6203030TN0
20
Setting Frame Sash Liner WH0418000000
21
Countersunk Head Screw SS1105150SD0
22
Gauge Ring Lid WH0420010000
23
15mm Dia. Shaft WH0417000000
24
Washer BPTW15300000
25
15mm Dia. Collar CE0110000000
26
Hexagon Socket Head Set Screw SS8206080TN0
27
Hexagon Socket Head Cap Screw SS6204150TN0
28
Gauge Ring A WH0421000000
29
Countersunk Head Screw SS1104150SD0
30
Center Block WH0203000000
31
Round Countersunk Head Screw SMC5000535CL
32
Presser Bar Spring WH0212000000
33
Truss Head Screw SS0103040SD0
34
Lever Bracket L WH0205000000
35
Countersunk Head Screw SS1104080MZ0
36
Hexagon Nut SSN204SD0000
37
Releasing Lever L WH0201000000
38
Lock Pin WH0207000000
39
Hexagon Socket Head Button Screw SS3204060SC0
40
Lever Spring L WH0224000000
41
Lever Pin WH0229000000
42
Hexagon Nut SSN004SD0000
43
Lever Bracket R WH0206000000
44
Releasing Lever R WH0202000000
45
Lever Spring R WH0225000000
46
47
48
49
50
Description Part No. Remark
M5*12
M3*8
M4*10
M4
M4
M3*5
M3
M3
M3*3
M5*15
M6*8
M4*15
M4*15
9/64*40*3.5
M3*4
M4*8
M4 Type 3
M4*6
M4
Note: As for parts with marks # or *, please follow our instructions on Table of Contents in your parts order.
i BH04j
Loading...
