Brother ADS-2700W User Manual

Online User's Guide

ADS-2200 ADS-2700W

Home > Table of Contents

Before You Use Your Brother Machine ............................................................................................... 1

Definitions of Notes

Trademarks .................................................................................................................................................... 3

Important Note ............................................................................................................................................... 4

Introduction to Your Brother Machine................................................................................................. 5

About This Machine ....................................................................................................................................... 6

Set Up Your Scanner...................................................................................................................................... 7

Control Panel Overview ................................................................................................................................. 8

Touchscreen LCD Overview......................................................................................................................... 10

Paper Handling.................................................................................................................................... 13

Document Specifications.............................................................................................................................. 14

Acceptable Documents ...................................................................................................................... 15

Unacceptable Documents .................................................................................................................. 16

Carrier Sheet Recommendations ....................................................................................................... 20

Notes for Using Carrier Sheets .......................................................................................................... 21

Load Documents .......................................................................................................................................... 22

Load Standard Size Documents......................................................................................................... 23

Load Business Cards ......................................................................................................................... 25

Load a Plastic Card ............................................................................................................................ 26

Load Documents Longer than Standard Size .................................................................................... 27

Load Non-standard Size Documents ................................................................................................. 28

Load Receipts, Clippings, Photos, and Other Documents ................................................................. 30

........................................................................................................................................ 2

Scan...................................................................................................................................................... 32

Before Scanning........................................................................................................................................... 33

Scan Using the Scan Button on Your Brother Machine ............................................................................... 34

Save Scanned Documents on Your Computer...................................................................................35

Save Scanned Documents to a USB Flash Drive .............................................................................. 38

Send Scanned Data to an Email Server............................................................................................. 42

Set Up the Address Book ................................................................................................................... 44

Scan to FTP ....................................................................................................................................... 47

Scan to SFTP ..................................................................................................................................... 51

Scan to Network ................................................................................................................................. 55

Web Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10) .......... 59

Scan Options Using the Touchscreen ................................................................................................ 63

Restrict Scan Functions from External Devices ................................................................................. 64

Scan from Your Computer (Windows®) ....................................................................................................... 65

Scan Using Nuance™ PaperPort™ 14 or Other Windows® Applications ........................................... 66

Scan Using Windows® Photo Gallery or Windows® Fax and Scan ................................................... 73

Scan Using Nuance™ Power PDF ..................................................................................................... 77

Scan from Your Computer (Mac).................................................................................................................. 78

Scan Using Brother iPrint&Scan ....................................................................................................... 79

Scan Using TWAIN-Compliant Applications (Mac)............................................................................. 80

Scan Using Apple Image Capture (ICA Driver) .................................................................................. 83

Network ................................................................................................................................................ 87

Home > Table of Contents

Supported Basic Network Features ............................................................................................................. 88

Network Management Software and Utilities

Learn about Network Management Software and Utilities ................................................................. 90

Additional Methods of Configuring Your Brother Machine for a Wireless Network ...................................... 91

Before Configuring Your Brother Machine for a Wireless Network..................................................... 92

Configure Your Machine for a Wireless Network Using the One-Push Method of Wi-Fi Protected

Setup™ (WPS).................................................................................................................................... 93

Configure Your Machine for a Wireless Network Using the PIN Method of Wi-Fi Protected

Setup™ (WPS).................................................................................................................................... 94

Configure Your Machine for a Wireless Network Using the Machine's Control Panel Setup Wizard . 96

Use Wi-Fi Direct®............................................................................................................................... 98

Advanced Network Features......................................................................................................................108

Synchronize Time with the SNTP Server Using Web Based Management ..................................... 109

Technical Information for Advanced Users................................................................................................. 114

Wireless LAN Error Codes ............................................................................................................... 115

............................................................................................... 89

Security ...............................................................................................................................................116

Lock the Machine Settings ......................................................................................................................... 117

Setting Lock Overview...................................................................................................................... 118

Network Security Features.........................................................................................................................121

Secure Function Lock 3.0................................................................................................................. 122

Manage Your Network Machine Securely Using SSL/TLS............................................................... 126

Send an Email Securely ................................................................................................................... 130

Troubleshooting................................................................................................................................ 132

Error and Maintenance Messages ............................................................................................................. 133

Error and Maintenance Indications ............................................................................................................ 137

Service Call Indications .................................................................................................................... 139

Document Jam ........................................................................................................................................... 140

If You Are Having Difficulty with Your Machine .......................................................................................... 142

Scanning and Other Problems ......................................................................................................... 143

Network Problems ............................................................................................................................ 147

Check the Serial Number ........................................................................................................................... 155

Reset Your Brother Machine ...................................................................................................................... 157

Reset the Usage Counters.........................................................................................................................158

Routine Maintenance ........................................................................................................................ 159

Clean Your Brother Machine ...................................................................................................................... 160

Clean the Outside of the Machine .................................................................................................... 161

Clean the Scanner and Rollers ........................................................................................................ 163

Replace Supplies ....................................................................................................................................... 166

Supplies............................................................................................................................................ 167

Check Supplies Replacement Cycle ................................................................................................ 168

Replace the Pick Up Roller .............................................................................................................. 170

Replace the Brake Roller ................................................................................................................. 172

Pack and Ship Your Brother Machine ........................................................................................................174

Machine Settings............................................................................................................................... 176

Change Machine Settings from the Control Panel ..................................................................................... 177

In the Event of Power Failure (Memory Storage) ............................................................................. 178

Change the General Settings from the Control Panel ...................................................................... 179

Home > Table of Contents

Save Your Favorite Settings as a Shortcut.......................................................................................181

Change Machine Settings from Y

Change Machine Settings Using Web Based Management ............................................................ 185

Change the Machine Settings Using Remote Setup ........................................................................ 189

our Computer......................................................................................... 184

Appendix............................................................................................................................................ 198

Specifications ............................................................................................................................................. 199

Enter Text on Your Brother Machine ..........................................................................................................204

iii

Home > Before You Use Your Brother Machine

Before You Use Your Brother Machine

• Definitions of Notes

rademarks

• T

• Important Note

Home > Before Y

ou Use Your Brother Machine > Definitions of Notes

Definitions of Notes

We use the following symbols and conventions throughout this User's Guide:

CAUTION

IMPORTANT

NOTE

Bold Bold style identifies buttons on the machine's control panel or computer screen.

Italics Italicized style emphasizes an important point or refers you to a related topic.

Courier New

Related Information

• Before Y

ou Use Your Brother Machine

CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injuries.

IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in damage to property or loss of product functionality

NOTE specifies the operating environment, conditions for installation, or special conditions of use.

Tips icons indicate helpful hints and supplementary information.

Courier New font identifies messages shown on the machine's LCD.

Home > Before Y

ou Use Your Brother Machine > Trademarks

Trademarks

Brother is either a trademark or a registered trademark of Brother Industries, Ltd.

Microsoft, Windows, Windows Server trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Apple, Mac, Safari, iPad, iPhone, iPod touch and OS X and Safari are trademarks of Apple Inc., registered in the United States and other countries.

Nuance and PaperPort are trademarks or registered trademarks of Nuance Communications, Inc. or its affiliates in the United States and/or other countries.

Wi-Fi®, Wi-Fi Alliance® and Wi-Fi Direct® are registered trademarks of Wi-Fi Alliance®.

WPA™, WPA2™, Wi-Fi Protected Setup™ and Wi-Fi Protected Setup™ logo are trademarks of Wi-Fi Alliance®.

Android and Google Play are trademarks of Google, Inc. Use of these trademarks are subject to Google Permissions.

Adobe is a registered trademark or trademark of Adobe Systems Incorporated in the United States and/or other countries.

Each company whose software title is mentioned in this manual has a Software License Agreement specific to its proprietary programs.

Any trade names and product names of companies appearing on Brother products, related documents and any other materials are all trademarks or registered trademarks of those respective companies.

, Internet Explorer, Word, Excel and PowerPoint are either registered

Related Information

• Before Y

ou Use Your Brother Machine

Home > Before Y

ou Use Your Brother Machine > Important Note

Important Note

• Go to your model's Manuals page on the Brother Solutions Center at support.brother.com, select your model

number

• Check

To keep your machine performance up to date, check

• Otherwise, some of your machine's functions may not be available.

•

Do not use this product outside the country of purchase as it may violate the wireless telecommunication and power regulations of that country.

• Not all models are available in all countries.

• In this User's Guide, the illustrations of the ADS-2700W are used unless otherwise specified.

• The screens in this User's Guide are for illustration purposes only and may differ from the actual screens.

• Unless otherwise specified, the screens in this manual are from Windows® 7 and macOS v10.10.x. Screens on your computer may vary depending on your operating system.

• If the LCD messages, control panel button names, and other indications are different depending on the country, the indications for each country will be shown.

• The contents of this guide and the specifications of this product are subject to change without notice.

, and download your model's other manuals, including the Quick Setup Guide.

support.brother.com for Brother driver and software updates.

support.brother.com for the latest firmware upgrade.

Related Information

• Before You Use Your Brother Machine

Home > Introduction to Your Brother Machine

Introduction to Your Brother Machine

• About This Machine

• Set Up Y

our Scanner

• Control Panel Overview

• Touchscreen LCD Overview

Home > Introduction to Y

our Brother Machine > About This Machine

About This Machine

1. Extendable Automatic Document Feeder (ADF)

Paper Guides

3. Touchscreen LCD (ADS-2700W)

4. Front Cover

5. Extendable Output Tray

6. Control Panel

7. Ethernet Cable Port (ADS-2700W)

8. USB 2.0 Port (for connecting a USB flash drive)

9. Hi-Speed USB 2.0 Port (for connecting to a computer)

10. AC Adapter Connector

Related Information

• Introduction to Y

our Brother Machine

Home > Introduction to Y

our Brother Machine > Set Up Your Scanner

Set Up Your Scanner

1. Pull the Extendable Tray from the ADF.

2. Open the Output Tray and extend it to match the length of the document pages.

If the Output Tray is even slightly longer than the document size, pages may not be in their original order when you retrieve them from the Output T

ray.

CAUTION

Do not use the ADF as a handle to carry the scanner.

Related Information

• Introduction to Your Brother Machine

Home > Introduction to Y

7 6

our Brother Machine > Control Panel Overview

Control Panel Overview

ADS-2200

1. Error Indicator (with LED)

Blinks when the machine detects an error

4. (Scan to USB)

(Power On/Off) (with LED)

Press

Press and hold to turn off the machine.

Press to stop or cancel your current action and return to Ready Mode.

Press to scan to a USB flash drive.

Press to scan to the computer

to turn on the machine.

(Stop)

(Scan to PC)

ADS-2700W

1. Error Indicator (with LED)

Blinks when the machine detects an error

(Power On/Off) (with LED)

Press to turn on the machine.

Press and hold

few seconds before turning of

(Stop)

Press to stop or cancel your current action and return to Ready Mode.

(Scan to USB)

Press to scan to a USB flash drive.

Press to execute the scan function assigned to the first shortcut.

(Back)

Press to go back to the previous screen or menu.

(Home Button)

Press to return to the Home Screen and Ready Mode.

Touchscreen LCD

Access the menus and options by pressing the touchscreen.

to turn off the machine. The touchscreen displays [Shutting Down] and stays on for a

Related Information

• Introduction to Y

• Add Shortcuts

our Brother Machine

Home > Introduction to Y

to PC to Network

FTP/SFTP

1 / 2

SettingsShortcuts

10:07 AM 10.04.2017

1 2 3 4

to E-mail

Server

to USB

2 / 2

SettingsShort

cuts

WS Scan

10:07 AM 10.04.2017

7 8 9

our Brother Machine > Touchscreen LCD Overview

Touchscreen LCD Overview

Related Models:

ADS-2700W

Home screen

There are two Home screens that you can access by pressing d or c.

The following screens display the machine’

s status when the machine is idle:

Home Screen 1

Home Screen 1 provides access to Scan to PC, Scan to Network, and Scan to FTP/SFTP operations.

Home Screen 2

1. [to PC]

Press to access the Scan to PC function.

2. [to Network]

Press to access the Scan to Network function.

3. [to FTP/SFTP]

Press to access the Scan to FTP/SFTP function.

(Wireless Status)

A four-level indicator on the Ready Mode screen displays the current wireless signal strength when using a wireless connection.

Home Screen 2 provides access to Scan to E-mail Server

, Scan to USB, and WS Scan operations.

0 1 2 Max

-1/5-

SettingsScan

Shortcuts

You can configure wireless settings by pressing the Wireless Status button.

5. ([Shortcuts])

Press [Shortcuts] and then , to create Shortcuts for frequently-used operations such as Scan to PC,

Scan to E-mail, Scan to USB, or other functions.

ou can quickly scan using the options set as Shortcuts.

To display the other Shortcuts screens, press d or c.

Five Shortcut screens are available with up to four Shortcuts on each tab. A total of 20 Shortcuts can be created.

6. ([Settings])

Press to access the Settings menu.

7. [to Email Server]

Press to access the Scan to E-mail Server function.

8. [to USB]

Press to access the Scan to USB function.

9. [WS Scan]

Press to access the WS Scan function.

• The warning icon appears when there is an error or maintenance message; press to return to

Ready Mode.

•

This product adopts the font of ARPHIC TECHNOLOGY CO., LTD.

Settings Menu

Press

([Settings]) to check and access all the machine’

s settings.

• [General Setup]

Press to access the Settings menu.

• [Shortcut Settings]

Press to set Shortcuts. This option is unavailable and cannot be selected if you have not added Shortcuts.

• [Network]

Press to access Network settings.

• [Machine Info.]

Press to check the machine’s information.

• [Initial Setup]

Press to access the [Date & Time], [Reset], and [Local Language] menus.

Related Information

• Introduction to Y

our Brother Machine

Home > Paper Handling

Paper Handling

• Document Specifications

• Load Documents

Home > Paper Handling > Document Specifications

Document Specifications

• Acceptable Documents

• Unacceptable Documents

• Carrier Sheet Recommendations

• Notes for Using Carrier Sheets

Home > Paper Handling > Document Specifications > Acceptable Documents

Acceptable Documents

Do not load documents of varying page thickness or paper quality at the same time.

Standard Paper

Width 2 in. to 8.5 in. (51 mm to 215.9 mm)

Length 2 in. to 14.0 in. (51 mm to 355.6 mm)

Weight 0.11 lb to 0.46 lb (50 g/㎡ to 209 g/㎡)

Thickness 3.15 mil to 10.63 mil (0.06 mm to 0.26 mm)

o scan thinner documents, use the Carrier Sheet (not included).

Maximum Number of Pages Up to 50 pages

Standard Paper Size A4 8.3 in. x 11.7 in. (210 mm x 297 mm)

A5 5.8 in. x 8.3 in. (148 mm x 210 mm)

A6 4.1 in. x 5.8 in. (105 mm x 148 mm)

B5 7.2 in. x 10.1 in. (182 mm x 257 mm)

B6 5 in. x 7.2 in. (128 mm x 182 mm)

Legal 8.5 in. x 14 in. (215.9 mm x 355.6 mm)

Mexican Legal 8.5 in. x 13.38 in. (215.9 mm x 339.9 mm)

India Legal 8.46 in. x 13.58 in. (215 mm x 345 mm)

Letter 8.5 in. x 11 in. (215.9 mm x 279.4 mm)

Executive 7 1/4 in. x 10 1/2 in. (184.1 mm x 266.7 mm)

Folio 8 1/2 in. x 13 in. (215.9 mm x 330.2 mm)

Plastic Card

Size (ISO) 3.37 in. x 2.13 in. (85.6 mm x 54 mm)

Material Plastic (PET)

Type Plastic card such as driver’s license or store card

Thickness Up to 52 mil (1.32 mm) (with embossing)

Up to 43 mil (1.10 mm) (without embossing)

Maximum Number of Cards One card

A plastic card can be scanned and saved to your computer as an image file. Configure the scanning application settings and then enable Plastic Card Mode.

Related Information

• Document Specifications

Home > Paper Handling > Document Specifications > Unacceptable Documents

Unacceptable Documents

The following types of documents may not be scanned successfully:

•

Documents with a carbon sheet attached

• Documents written in pencil

• Documents of uneven thickness, such as envelopes

• Documents with large wrinkles or curls

• Documents that use tracing paper

• Documents that use coated paper

• Photographs (photographic paper)

• Documents printed on perforated paper

• Documents printed on unusually-shaped paper (not square or rectangle)

• Documents with photos, notes, or stickers affixed to them

• Documents that use carbonless paper

• Documents that use loose-leaf paper or any paper with holes in it

• Documents with paper clips or staples

• Documents with wet ink

• Fabrics, metallic sheets, or overhead projector sheets

• Glossy or mirrored media

• Documents that exceed recommended thicknesses

IMPORTANT

• Carbonless papers contain chemical substances that may damage the rollers (for example, the Pick Up Roller). If paper jams occur frequently Roller and Pick Up Roller may be reduced compared to scanning paper with high wood content.

• When scanning paper with high wood content, the life of the Brake Roller and Pick Up Roller may be reduced compared to scanning wood-free paper.

• The Brake Roller and Pick Up Roller may become damaged when a photo or sticky note on the document touches these parts during scanning.

• The surface of the document may be damaged when scanning glossy papers such as photographs.

• The damage caused by using any unacceptable documents with your Brother machine may not be covered under warranty.

, clean the Brake Roller and Pick Up Roller. The life of the Brake

Related Information

• Document Specifications

• Area Not to be Perforated

• Scan a Mixed Batch

• Clean the Scanner and Rollers

Home > Paper Handling > Document Specifications > Unacceptable Documents > Area Not to be

Perforated

Area Not to be Perforated

An error may occur if your document has punched holes in the area shaded in light blue in the following figure:

1. 1.77 in. (45 mm)

Top

3. Bottom

4. Center

5. Feed direction

6. Front side

7. Reference point

This condition applies when the document is set in the center of the Pick Up Roller.

Related Information

• Unacceptable Documents

Home > Paper Handling > Document Specifications > Unacceptable Documents > Scan a Mixed Batch

Scan a Mixed Batch

The following conditions apply when scanning a mixed batch of documents with different paper weights, friction coef

ficients, or sizes. Make sure to test a few sheets first to check if the documents can be scanned.

Paper direction

Align the direction of the paper fiber with the feed direction.

Paper weight

Use the following paper weights: 0.11 lb to 0.46 lb (50 g/㎡ to 209 g/㎡)

Friction coefficient

We recommend using the same type of paper from the same manufacturer. When papers of different manufacturers/brands are mixed, it affects the feeding performance as the difference in the friction coefficient increases.

We recommend using friction coefficients between 0.35 and 0.6 (reference value for paper friction coefficient).

Document position

Use paper sizes that fit the 1.77 in. (45 mm) width of the Pick Up Roller in the center.

Paper size

When you scan a mixed batch with different sizes, not feeding the documents straight may cause problems, such as paper jams or part of the image to appear missing.

We recommend checking the documents thoroughly before scanning and also checking the image if the document was skewed.

When scanning a mixed batch with different sizes, documents are more likely to skew while feeding because the Paper Guides do not touch every sheet.

Documents that cannot be scanned in a mixed batch

The following types of documents cannot be mixed in the same batch:

Carbonless paper

•

• Bond paper

• Perforated documents

• Thermal paper

• Carbon-backed paper

• OHP film

• Tracing paper

• Synthetic paper

• Bent or damaged documents

• Thin paper (less than 40 g/㎡)

How to scan a mixed batch

Load your document in the ADF in descending order of paper size with the largest at the back and the smallest at the front.

If you are loading a paper business card, load it horizontally.

Related Information

• Unacceptable Documents

Home > Paper Handling > Document Specifications > Carrier Sheet Recommendations

Carrier Sheet Recommendations

Brother recommends using a Carrier Sheet (not included) to scan the following documents:

•

Documents with a carbon sheet attached

• Documents written in pencil

• Documents narrower than 2 in. (51 mm)

• Documents shorter than 2.76 in. (70 mm)

• Pages thinner than 3 mil (0.08 mm)

• Documents of uneven thickness, such as envelopes

• Documents with large wrinkles or curls

• Bent or damaged documents

• Documents that use tracing paper

• Documents that use coated paper

• Photographs (photographic paper)

• Documents printed on perforated paper

• Documents printed on unusually-shaped paper (not square or rectangle)

• Documents with photos, notes, or stickers attached to them

• Documents that use carbonless paper

• Documents that use loose-leaf paper or any paper with holes in it

CAUTION

To avoid cutting yourself, do not slide or scrape your hand or fingers along the edge of the Carrier Sheet.

IMPORTANT

• To avoid warping the Carrier Sheet, do not place the Carrier Sheet in direct sunlight or in an area subject to high temperatures and high humidity

• To avoid damaging the Carrier Sheet, do not bend or pull it. Do not use a damaged Carrier Sheet, as it may produce incorrect scan results.

Related Information

• Document Specifications

• Supplies

Home > Paper Handling > Document Specifications > Notes for Using Carrier Sheets

Notes for Using Carrier Sheets

• To avoid document jams, do not load the Carrier Sheet (not included) upside down. See the instructions printed on the Carrier Sheet itself for more information.

•

To avoid document jams, do not put several small documents into the Carrier Sheet at the same time. Insert only one document into the Carrier Sheet at a time.

• Do not write on the Carrier Sheet, as the writing may be seen in scanned documents. If the Carrier Sheet becomes dirty, wipe it with a dry cloth.

• Do not leave documents in the Carrier Sheet for extended periods of time; the printing on the documents may bleed through onto the Carrier Sheet.

• If you use any of the Unacceptable Documents and damage your Brother machine, it may not be

covered under warranty.

Related Information

• Document Specifications

• Supplies

Home > Paper Handling > Load Documents

Load Documents

The ADF can hold up to 50 pages and feeds each sheet individually. Use 20 lb (80 g/㎡) the pages before placing them in the ADF.

paper and always fan

IMPORTANT

• Make sure documents with ink or correction fluid are completely dry.

•

DO NOT pull on the document while it is feeding.

• DO NOT use paper that is curled, wrinkled, folded, ripped, stapled, paper-clipped, pasted, or taped.

• DO NOT use cardboard or fabric.

• Load Standard Size Documents

• Load Business Cards

• Load a Plastic Card

• Load Documents Longer than Standard Size

• Load Non-standard Size Documents

• Load Receipts, Clippings, Photos, and Other Documents

Home > Paper Handling > Load Documents >

Load Standard Size Documents

1. Adjust the Paper Guides (1) to fit the width of your document.

2. Fan the pages several times along both the long edge and the short edge.

3. Align the edges of the pages.

4. Place your document, face down, top edge first in the ADF between the Paper Guides until you feel it touch the inside of the machine.

Feed thin pages slowly and carefully to keep the edge from being folded.

Related Information

• Load Documents

Home > Paper Handling > Load Documents >

Load Business Cards

1. Adjust the Paper Guides (1) to fit the width of your document.

2. Place the card, face down, top edge first inside of the machine.

You can load up to 25 business cards (total thickness less than 0.2 in. (5 mm) at a time).

in the ADF between the Paper Guides until you feel it touch the

Related Information

• Load Documents

Home > Paper Handling > Load Documents >

Load a Plastic Card

1. Adjust the Paper Guides (1) to fit the width of your document.

2. Place the card, face down, top edge first inside of the machine.

• Load only one plastic card at a time.

• Certain types of plastic cards may be scratched when scanned.

• Rigid cards may not be fed correctly.

• If the surface of the card is dirty with grease marks (for example, fingerprints) or similar, wipe the dirt off before scanning.

in the ADF between the Paper Guides until you feel it touch the

Related Information

• Load Documents

Home > Paper Handling > Load Documents >

Load Documents Longer than Standard Size

Make sure documents with ink or correction fluid are completely dry.

1. Adjust the Paper Guides (1) to fit the width of your document.

2. Place your document, face down, top edge first in the ADF between the Paper Guides until you feel it touch the inside of the machine.

• Load only one document at a time.

• Support the document with your hand if the document is longer than the extended ADF.

Related Information

• Load Documents

Home > Paper Handling > Load Documents >

Load Non-standard Size Documents

Make sure documents with ink or correction fluid are completely dry.

1. Fold your document in half and insert it into the Carrier Sheet (not included).

a. Document is Face Down

Carrier Sheet Header is Face Up

Set the Paper document in the center of the Carrier Sheet and align the top of the document with the top of the Carrier Sheet.

2. Adjust the Paper Guides (1) to fit the width of the Carrier Sheet.

3. Place the Carrier Sheet, face down in the ADF between the Paper Guides until you feel it touch the inside of the machine.

To reduce the white space in the center of a scanned page, position the folded edge of the original document close to the edge of the Carrier Sheet.

Related Information

• Load Documents

Home > Paper Handling > Load Documents >

Load Receipts, Clippings, Photos, and Other Documents

Make sure documents with ink or correction fluid are completely dry.

1. Insert the document into the Carrier Sheet (not included).

• Set the Paper document in the center of the Carrier Sheet and align the top of the document with the top of the Carrier Sheet.

If the receipt is longer than the Carrier Sheet, you can fold the receipt in two places so that it overlaps

• when you insert it into the Carrier Sheet.

2. Adjust the Paper Guides (1) to fit the width of the Carrier Sheet.

3. Place the Carrier Sheet, face down in the ADF between the Paper Guides until you feel it touch the inside of the machine.

Related Information

• Load Documents

Home > Scan

Scan

• Before Scanning

• Scan Using the Scan Button on Y

•

Scan from Your Computer (Windows®)

• Scan from Your Computer (Mac)

our Brother Machine

Home > Scan >

Before Scanning

Before scanning, confirm the following:

•

Make sure you have installed the scanner driver by following the steps in the Quick Setup Guide.

• If your Brother machine is connected via a network cable or USB cable, make sure the interface cable is physically secure.

Home > Scan >

Scan Using the Scan Button on Your Brother Machine

• Save Scanned Documents on Y

our Computer

• Save Scanned Documents to a USB Flash Drive

• Send Scanned Data to an Email Server

• Set Up the Address Book

• Scan to FTP

• Scan to SFTP

• Scan to Network

•

Web Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows

10)

• Scan Options Using the Touchscreen

• Restrict Scan Functions from External Devices

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Save Scanned Documents on

Your Computer

Save Scanned Documents on Your Computer

>> ADS-2200 >> ADS-2700W

ADS-2200

To change scan settings, such as resolution, file size or scan type, follow the steps below.

1. Do one of the following:

•

Windows

Click

Mac

•

In the Finder menu bar, click Go > Applications > Brother, and then double-click the Remote Setup icon.

2. Select your model name in the Discover Devices dialog box, and then click Connect.

The Remote Setup Program window appears.

3. Select Scan to PC in the navigation tree, and then configure scan settings as needed.

Windows

(Start) > All Programs > Brother > ADS-XXXXX > Remote Setup.

Mac

4. Click OK to close the Remote Setup window

5. Load your document.

6. Press

The machine starts scanning.

When a USB flash drive is inserted in your machine, scanning from a computer is disabled. To scan from your computer

(Scan to PC) on the control panel.

, remove the USB flash drive.

ADS-2700W

• To change scan settings, such as resolution, file size or scan type, follow the steps below.

This procedure explains how to change the settings each time you scan documents. To use the same

• settings every time, change the settings using Remote Setup.

1. Load your document.

Press d or c to display [to PC], and press it.

3. If multiple computers are connected to the machine, press a or b to display the destination computer you want to save on, and press it.

4. To change the scan settings, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [Skip Blank Page]

• [Advanced Settings]

• To configure other settings, press [Advanced Settings].

To save the settings as a shortcut, press [Save as Shortcut].

•

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

5. Press [Start].

The machine starts scanning.

When a USB flash drive is inserted in your machine, scanning from a computer is disabled. To scan from your computer

, remove the USB flash drive.

Related Information

• Scan Using the Scan Button on Y

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Save Scanned Documents to a

USB Flash Drive

Save Scanned Documents to a USB Flash Drive

To avoid damaging the drive or the data stored on the USB flash drive, DO NOT remove it while the machine is scanning to it.

When a USB flash drive is inserted in your machine, scanning from a computer is disabled. To scan from your computer

>> ADS-2200 >> ADS-2700W

ADS-2200

To change scan settings, such as resolution, file size or scan type, follow the steps below.

1. Do one of the following:

Windows

•

, remove the USB flash drive.

Click

•

Mac

In the Finder menu bar, click Go > Applications > Brother, and then double-click the Remote Setup icon.

2. Select your model name in the Discover Devices dialog box, and then click Connect.

The Remote Setup Program window appears.

3. Select Scan to USB in the navigation tree, and then configure scan settings as needed.

(Start) > All Programs > Brother > ADS-XXXXX > Remote Setup.

Windows

Mac

4. Click OK to close the Remote Setup window

5. Insert a USB flash drive into the machine.

6. Load your document.

7. Press

The machine starts scanning, and then the scanned data is saved on the USB flash drive.

(Scan to USB) on the control panel.

ADS-2700W

• To change scan settings, such as resolution, file size or scan type, follow the steps below.

This procedure explains how to change the settings each time you scan documents. To use the same

• settings every time, change the settings using Remote Setup.

1. Load your document.

Insert a USB flash drive into the machine.

The Scan to USB screen appears automatically. If the Scan to USB screen does not appear, press [to USB] in the Home screen.

3. To change the scan settings, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [Skip Blank Page]

• [Advanced Settings]

• [Set New Default]

• [Factory Reset]

• To configure other settings, press [Advanced Settings].

To save the settings as a shortcut, press [Save as Shortcut].

•

• To select [Long Paper (Narrow)] or [Long Paper (Normal)] for [Document Size], use the following settings: [Scan Type]: [Color] or [Black and White].

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

4. Press [Start].

The machine starts scanning, and then the scanned data is saved on the USB flash drive.

Related Information

• Scan Using the Scan Button on Y

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Send Scanned Data to an Email

Server

Send Scanned Data to an Email Server

Related Models:

Before using this feature, you must first configure your E-mail Server settings using Web Based Management. See Related Information:

1. Load your document.

Press d or c to display [to Email Server], and press it.

3. Do one of the following to enter the destination email address:

• To select an email address from the Address Book, do the following:

a. Press [Address Book].

b. Press a or b until you find the name you are looking for.

c. Press the name from the result.

d. Press [OK].

4. Press [OK].

5. To change the scan settings, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [Skip Blank Page]

• [Advanced Settings]

ADS-2700W

Send an Email Securely

• To configure other settings, press [Advanced Settings].

•

To save the settings as a shortcut, press [Save as Shortcut].

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

6. Press [Start].

The machine starts scanning, and then sends the scanned document to the email address directly

Related Information

• Scan Using the Scan Button on Your Brother Machine

• Use TX Verification Mail

• Send an Email Securely

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Send Scanned Data to an Email

Server > Use TX Verification Mail

Use TX Verification Mail

Related Models: ADS-2700W

Use TX Verification Mail to request notification from the destination computer that your email was received and processed. Use W Notification is On, your email contains an additional field that is automatically populated with the email’s arrival date and time.

1. Start your web browser.

2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's IP address).

For example:

http://192.168.1.2

eb Based Management to turn on the verification feature. When Request Delivery

3. By default, no password is required. If you have previously set a password, type it, and then click

Click the E-mail tab.

5. Click E-mail Send.

6. In the Request Delivery Notification field, click On.

7. Click Submit.

• Message Disposition Notification (MDN)

This field requests the status of the email message after delivery through the Simple Mail T Protocol (SMTP) transport system. After the recipient has received the message, this data is used when the machine or user reads the received email. For example, if the message is opened and read, the receiver sends back a notification to the original sending machine or user.

The recipient must activate the MDN field to be able to send a notification report; otherwise the request will be ignored.

• This Brother machine cannot receive email messages. To use the TX Verification feature, you must redirect the return notification to a different email address. Configure the email address using Web Based Management. Access Web Based Management, click the E-mail tab, click SMTP and confirm

Device E-mail Address. Enter the email address that you want to receive the notification.

Related Information

• Send Scanned Data to an Email Server

ransfer

Home > Scan > Scan Using the Scan Button on Y

Set Up the Address Book

our Brother Machine > Set Up the Address Book

Related Models:

The Address Book feature lets you select an email address to send the scanned data directly.

Configure the Address Book using Remote Setup or Web Based Management.

ADS-2700W

Related Information

• Scan Using the Scan Button on Y

• Register an Email Address Using Remote Setup

• Register an Email Address Using Web Based Management

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Set Up the Address

Book > Register an Email Address Using Remote Setup

Register an Email Address Using Remote Setup

Related Models: ADS-2700W

You can register up to 300 email addresses and enter a name for each address.

Do one of the following:

• Windows

Click

Mac

•

In the Finder menu bar, click Go > Applications > Brother, and then double-click the Remote Setup icon.

2. Select your model name in the Discover Devices dialog box, and then click Connect.

The Remote Setup Program window appears.

3. Select Address Book in the navigation tree.

4. Click + in the Contact area .

5. Enter a name and an email address.

6. Click Create.

7. Click OK.

To create a group, click +

(Start) > All Programs > Brother > ADS-XXXXX > Remote Setup.

in the Group area and then configure settings as needed.

Related Information

• Set Up the Address Book

• Access W

eb Based Management

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Set Up the Address

Book > Register an Email Address Using Web Based Management

Register an Email Address Using Web Based Management

Related Models: ADS-2700W

You can register up to 300 email addresses and enter a name for each address.

Start your web browser.

Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the machine's IP address). For example: http://192.168.1.2

By default, no password is required. If you have previously set a password, type it, and then click

Click the Address Book tab.

3. In the E-mail Address field, type an email address.

4. In the Name field, type a name.

5. Click Submit.

Related Information

• Set Up the Address Book

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to FTP

Scan to FTP

Related Models: ADS-2700W

Scan documents directly to an FTP server when you need to share the scanned information. For added convenience, configure dif

Related Information

ferent profiles to save your favorite Scan to FTP destinations.

• Scan Using the Scan Button on Y

• Set up a Scan to FTP Profile

• Upload Scanned Data to an FTP Server

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

FTP Profile

Set up a Scan to FTP Profile

our Brother Machine > Scan to FTP > Set up a Scan to

Related Models:

Set up a Scan to FTP Profile to scan and upload the scanned data directly to an FTP location.

e recommend Microsoft® Internet Explorer® 8/10/11 for Windows®, and Safari 8.0 for Mac. Make sure that

W JavaScript and Cookies are always enabled in whichever browser you use. If a different web browser is used, make sure it is compatible with HTTP 1.0 and HTTP 1.1.

1. Start your web browser.

ype "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the

T machine's IP address). For example: http://192.168.1.2

By default, no password is required. If you have previously set a password, type it, and then click

Click the Scan tab.

3. Click the Scan to FTP/SFTP/Network menu in the left navigation bar.

4. Select the FTP option, and then click Submit.

5. Click the Scan to FTP/SFTP/Network Profile menu in the left navigation bar.

6. Select the profile you want to set up or change.

ADS-2700W

The Profile setting screen appears.

In the Profile Name field, type a name for this server profile (up to 14 alphanumeric characters).

The machine will display this name on the LCD.

8. In the Host Address field, type the Host Address (for example: ftp.example.com; up to 64 characters) or the

IP address (for example: 192.23.56.189), and type the path (up to 255 characters) to the folder on the FTP server where you want to send your scanned data. Do not type a slash symbol at the beginning of the path.

9. In the Username field, type a user name (up to 32 characters) that has permission to write data to the FTP

server.

10. In the Password field, type the password (up to 33 characters) associated with the user name you entered in the Username field. Type the password again in the Retype password field.

11. In the Store Directory field, type the path (up to 255 characters) to the folder on the FTP server where you want to send your scanned data. Do not type a slash symbol at the beginning of the path.

12. Click the Quality drop-down list, and then select a quality setting. When Auto is selected, you can adjust the detection level of color from the Auto Color detect adjust drop-down list.

13. Click the File T

14. Click the Document Size drop-down list, and then select your document size from the list. This is necessary to make sure the scanned file is the correct size.

15. In the Margin Settings, enter a value between -3 and 3 to add or remove a specific margin at the edge of the image.

16. Click the File Size drop-down list, and then select your file size from the list.

17. Select On from the Skip Blank Page option, to remove blank pages of the document from the scanning results.

18. Click the Skip blank page sensitivity drop-down list, and then select a value between -5 and 5.

19. Click the 2-sided Scan drop-down list.

20. Click the Brightness drop-down list, and then select the brightness level.

21. Click the Contrast drop-down list, and then select the contrast level.

22. Select On from the Continuous Scan option to continue scanning.

23. Set the Passive Mode option to off or on depending on your FTP server and network firewall configuration. The default setting is on. In most cases, this setting does not need to be changed.

24. Change the Port Number setting used to access the FTP server. The default for this setting is port 21. In most cases, this setting does not need to be changed.

25. Click Submit.

• You can set the scanned file name and file name style in the Scan File Name menu in the left

navigation bar

• Using the following characters: ?, /, \, ", :, <, >, |, or * may cause a sending error.

ype drop-down list, and then select the file type you want to use for the scanned document.

Related Information

• Scan to FTP

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to FTP > Upload Scanned

Data to an FTP Server

Upload Scanned Data to an FTP Server

Related Models: ADS-2700W

1. Load your document.

Press d or c to display [to FTP/SFTP], and press it.

3. Press a or b to select one of the FTP server profiles listed.

4. If the Scan to FTP profile is not complete, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [File Size]

• [Skip Blank Page]

• [Advanced Settings]

• To configure other settings, press [Advanced Settings].

•

To save the settings as a shortcut, press [Save as Shortcut].

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

5. Press [Start].

The LCD displays the message [Connecting]. When the connection to the FTP server is successful, the machine starts scanning.

Related Information

• Scan to FTP

Home > Scan > Scan Using the Scan Button on Y

Scan to SFTP

our Brother Machine > Scan to SFTP

Related Models:

Scan documents directly to an SFTP server when you need to share the scanned information. For added convenience, configure dif

ADS-2700W

ferent profiles to save your favorite Scan to SFTP destinations.

Related Information

• Scan Using the Scan Button on Y

• Set up a Scan to SFTP Profile

• Upload Scanned Data to an SFTP Server

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

SFTP Profile

Set up a Scan to SFTP Profile

our Brother Machine > Scan to SFTP > Set up a Scan to

Related Models:

Set up a Scan to SFTP Profile to scan and upload the scanned data directly to an SFTP location.

e recommend Microsoft® Internet Explorer® 8/10/11 for Windows®, and Safari 8.0 for Mac. Make sure that

W JavaScript and Cookies are always enabled in whichever browser you use. If a different web browser is used, make sure it is compatible with HTTP 1.0 and HTTP 1.1.

1. Start your web browser.

ype "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the

T machine's IP address). For example: http://192.168.1.2

By default, no password is required. If you have previously set a password, type it, and then click

Click the Scan tab.

3. Click the Scan to FTP/SFTP/Network menu in the left navigation bar.

4. Select the SFTP option, and then click Submit.

5. Click the Scan to FTP/SFTP/Network Profile menu in the left navigation bar.

6. Select the profile you want to set up or change.

ADS-2700W

The Profile setting screen appears.

In the Profile Name field, type a name for this server profile (up to 14 alphanumeric characters).

The machine will display this name on the LCD.

8. In the Host Address field, type the Host Address (for example: sftp.example.com; up to 64 characters) or the

IP address (for example: 192.23.56.189), and type the path (up to 60 characters) to the folder on the SFTP server where you want to send your scanned data. Do not type a slash symbol at the beginning of the path.

In the Username field, type a user name (up to 32 characters) that has permission to write data to the SFTP

9. server.

10. In the Auth. Method field, select Password or Public Key.

11. Do one of the following:

• If you have selected Password, type the password (up to 32 characters) associated with the user name

you typed in the Username field. Type the password again in the Retype password field.

• If you have selected Public Key, select the authentication type from the Client Key Pair drop-down list.

12. Select the authentication type from the Server Public Key drop-down list.

13. In the Store Directory field, type the path (up to 60 characters) to the folder on the SFTP server where you want to send your scanned data. Do not type a slash symbol at the beginning of the path.

14. Click the Quality drop-down list, and then select a quality setting. When Auto is selected, you can adjust the detection level of color from the Auto Color detect adjust drop-down list.

15. Click the File Type drop-down list, and then select the file type you want to use for the scanned document.

16. Click the Document Size drop-down list, and then select your document size from the list. This is necessary to make sure the scanned file is the correct size.

17. In the Margin Settings, enter a value between -3 and 3 to add or remove a specific margin at the edge of the image.

18. Click the File Size drop-down list, and then select your file size from the list.

19. Select On from the Skip Blank Page option, to remove blank pages of the document from the scanning results.

20. Click the Skip blank page sensitivity drop-down list, and then select a value between -5 and 5.

21. Click the 2-sided Scan drop-down list.

22. Click the Brightness drop-down list, and then select the brightness level.

23. Click the Contrast drop-down list, and then select the contrast level.

24. Select On from the Continuous Scan option to continue scanning.

25. Change the Port Number setting used to access the SFTP server. The default for this setting is port 21. In most cases, this setting does not need to be changed.

26. Click Submit.

• You can set the scanned file name and file name style in the Scan File Name menu in the left

navigation bar

• Using the following characters: ?, /, \, ", :, <, >, |, or * may cause a sending error.

• You can use Web Based Management to create, import, and export a client key pair.

Related Information

• Scan to SFTP

• Access W

eb Based Management

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to SFTP > Upload Scanned

Data to an SFTP Server

Upload Scanned Data to an SFTP Server

Related Models: ADS-2700W

1. Load your document.

Press d or c to display [to FTP/SFTP], and press it.

3. Press a or b to select one of the SFTP server profiles listed.

4. If the Scan to SFTP profile is not complete, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [File Size]

• [Skip Blank Page]

• [Advanced Settings]

• To configure other settings, press [Advanced Settings].

•

To save the settings as a shortcut, press [Save as Shortcut].

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

5. Press [Start].

The LCD displays the message [Connecting]. When the connection to the SFTP server is successful, the machine starts scanning.

Related Information

• Scan to SFTP

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to Network

Scan to Network

• Set up a Scan to Network Profile

• Upload Scanned Data to a Mapped Network Drive (CIFS) Server

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to Network > Set up a Scan

to Network Profile

Set up a Scan to Network Profile

Related Models: ADS-2700W

Set up a Scan to Network Profile to scan and upload scanned data directly to a folder on a Mapped Network Drive (CIFS) server

We recommend Microsoft® Internet Explorer® 8/10/11 for Windows®, and Safari 8.0 for Mac. Make sure that JavaScript and Cookies are always enabled in whichever browser you use. If a different web browser is used, make sure it is compatible with HTTP 1.0 and HTTP 1.1.

1. Start your web browser.

ype "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the

T machine's IP address). For example: http://192.168.1.2

By default, no password is required. If you have previously set a password, type it, and then click

Click the Scan tab.

3. Click the Scan to FTP/SFTP/Network menu in the left navigation bar.

4. Select the Network option, and then click Submit.

5. Click the Scan to FTP/SFTP/Network Profile menu in the left navigation bar.

6. Select the profile you want to set up or change.

The Profile setting screen appears.

In the Profile Name field, type a name for this server profile (up to 14 alphanumeric characters).

The machine will display this name on the LCD.

8. In the Network Folder Path field, type the path to the folder on the Mapped Network Drive (CIFS) server

where you want to send your scanned data.

9. Click the Quality drop-down list, and then select a quality setting. When Auto is selected, you can adjust the detection level of color from the Auto Color detect adjust drop-down list.

10. Click the File Type drop-down list, and then select the file type you want to use for the scanned document.

11. Click the Document Size drop-down list, and then select your document size from the list. This is necessary to make sure the scanned file is the correct size.

12. In the Margin Settings, enter a value between -3 and 3 to add or remove a specific margin at the edge of the image.

13. Click the File Size

14. Select On from the Skip Blank Page option, to remove blank pages of the document from the scanning results.

15. Click the Skip blank page sensitivity drop-down list, and then select a value between -5 and 5.

16. Click the 2-sided Scan drop-down list.

17. Click the Brightness drop-down list, and then select the brightness level.

18. Click the Contrast drop-down list, and then select the contrast level.

19. Select On from the Continuous Scan option to continue scanning.

20. In the Username field, type a user name (up to 96 characters) that has permission to write data to the folder specified in the Network Folder Path field. If the user name is part of a domain, type the user name in one of the following styles:

user@domain

domain\user

21. In the Password field, type the password (up to 33 characters) associated with the user name you entered in the Username field. Type the password again in the Retype password field.

22. Click Submit.

23. You must configure the SNTP (network time server) or you must set the date, time and time zone correctly on the control panel.

• You can set the scanned file name and file name style in the Scan File Name menu in the left

navigation bar

• Using the following characters: ?, /, \, ", :, <, >, |, or * may cause a sending error.

drop-down list, and then select your file size from the list.

Related Information

• Scan to Network

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Scan to Network > Upload

Scanned Data to a Mapped Network Drive (CIFS) Server

Upload Scanned Data to a Mapped Network Drive (CIFS) Server

Related Models:

1. Load your document.

Press d or c to display [to Network], and press it.

3. Press a or b to select one of the Network server profiles listed.

4. If the Scan to Network profile is not complete, press [Options]. Configure the following settings, and then press [OK]:

• [2-sided Scan]

• [Scan Type]

• [Resolution]

• [File Type]

• [Document Size]

• [File Size]

• [Skip Blank Page]

• [Advanced Settings]

• To configure other settings, press [Advanced Settings].

•

To save the settings as a shortcut, press [Save as Shortcut].

• If signed PDF was selected from the [File Type] drop-down list, you must configure the certificate settings using Web Based Management.

ADS-2700W

5. Press [Start].

The LCD displays the message [Connecting]. When the connection to the Network server is successful, the machine starts scanning.

Related Information

• Scan to Network

Home > Scan > Scan Using the Scan Button on Y

Your Network (Windows® 7, Windows® 8 and Windows® 10)

our Brother Machine > Web Services for Scanning on

Web Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10)

The Web Services protocol enables Windows® 7, Windows® 8 and Windows® 10 users to scan using a Brother machine on the network. Y

•

Use Web Services to Install Drivers Used for Scanning (Windows® 7, Windows® 8 and Windows® 10)

•

Scan Using Web Services from the Brother Machine (Windows® 7, Windows® 8 and Windows® 10)

• Configure Scan Settings for Web Services

ou must install the driver via Web Services.

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Web Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10) > Use Web Services to Install Drivers Used for

Scanning (Windows® 7, Windows® 8 and Windows® 10)

Use Web Services to Install Drivers Used for Scanning (Windows® 7, Windows® 8 and Windows® 10)

Related Models: ADS-2700W

Use Web Services to monitor scanners on the network.

Make sure you have installed the Brother software and drivers.

•

• Verify that the host computer and the Brother machine are on the same subnet, or that the router is correctly configured to pass data between the two devices.

• You must configure the IP address on your Brother machine before you configure this setting.

1. Do one of the following:

• Windows® 10

> W

Click

indows System > Control Panel. In the Hardware and Sound group, click Add a device.

• Windows® 8.1

Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings > Change PC settings > PC and devices > Devices > Add a device.

The machine's Web Services Name appears.

• Windows® 8

Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings > Change PC settings > Devices > Add a device.

The machine's Web Services Name appears.

• Windows® 7

Click

The machine's Web Services Name appears with the scanner icon.

Right-click the machine you want to install.

• The Web Services Name for the Brother machine is your model name and the MAC Address (Ethernet Address) of your machine (for example, Brother ADS-XXXXX (model name) [XXXXXXXXXXXX] (MAC Address / Ethernet Address)).

Windows® 8/Windows® 10

•

Move your mouse over the machine name to display the machine's information.

2. Do one of the following:

(Start) > Control Panel > Network and Internet > V

iew network computers and devices.

•

Windows® 8/Windows® 10

Select the machine you want to install, and then follow the on-screen instructions.

• Windows® 7

Click Install in the displayed menu.

To uninstall drivers, click Uninstall or (Remove device).

Related Information

eb Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10)

• W

Home > Scan > Scan Using the Scan Button on Y

Your Network (Windows® 7, Windows® 8 and Windows® 10) > Scan Using Web Services from the Brother

Machine (Windows® 7, Windows® 8 and Windows® 10)

our Brother Machine > Web Services for Scanning on

Scan Using Web Services from the Brother Machine (Windows® 7, Windows® 8 and Windows® 10)

Related Models:

If you have installed the driver for scanning via Web Services, you can access the Web Services scanning menu on your Brother machine's LCD.

Certain characters in the messages displayed on the LCD may be replaced with spaces if the language settings of your OS and your Brother machine are dif

1. Load your document.

Press d or c to display [WS Scan], and press it.

3. Press the type of scan you want to perform.

4. Press a or b to display the computer name where you want to send the data, and then press the computer name.

5. Press [Start].

The machine starts scanning.

ADS-2700W

ferent.

Related Information

• W

eb Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10)

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Web Services for Scanning on

Your Network (Windows® 7, Windows® 8 and Windows® 10) > Configure Scan Settings for Web Services

Configure Scan Settings for Web Services

Related Models: ADS-2700W

1. Do one of the following:

Windows® 10

•

> W

Click

and printers.

• Windows® 8

Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings, and then click Control Panel. In the Hardware and Sound group, click View devices and printers.

• Windows® 7

indows System > Control Panel. In the Hardware and Sound group, click View devices

Click

Right-click the machine icon, and then select Scan profiles....

The Scan profiles... dialog box appears.

3. Select the scan profile you want to use.

4. Make sure the scanner selected in the Scanner list is a Brother machine that supports Web Services for scanning, and then click the Set as Default button.

5. Click Edit....

The Edit Default Profile dialog box appears.

6. Select the Source, Paper size, Color format, File type, Resolution (DPI), Brightness and Contrast settings.

7. Click the Save Profile button.

These settings will be applied when you scan using the Web Services protocol.

If you are requested to select a scanning application, select Windows® Fax and Scan or Windows® Photo Gallery from the list.

(Start) > Devices and Printers.

Related Information

• W

eb Services for Scanning on Your Network (Windows® 7, Windows® 8 and Windows® 10)

Home > Scan > Scan Using the Scan Button on Y

Touchscreen

Scan Options Using the Touchscreen

Related Models: ADS-2700W

To change scan settings, press [Options].

Option Description

2-sided Scan

Scan Type

When using 2-sided scanning, select 2-sided Scan: Long Edge so the layout of the data file’

Select the scan type for your document.

When Auto color and generates a scanned image of the document. For documents that mix color and black and white pages, color pages are scanned in the Color mode, and black and white pages are scanned in the Black and White mode.

s pages matches your original.

is selected, the machine automatically detects whether the document uses

our Brother Machine > Scan Options Using the

Resolution

File Type

Document Size

File Size

Skip Blank Page

Advanced Settings Continuous Scan

Set New Default

Factory Reset

Select a scanning resolution. Higher resolutions produce a finer scanned image but consume more memory and increase transfer time.

Select the file type you want to use for the scanned data.

Select the exact size of your document.

Select Small, Medium, or Large for the file size.

When On is selected, blank pages are skipped.

Use the slider to adjust the sensitivity level for detecting blank pages in the scanned data. The higher the sensitivity

Scan more pages than the maximum capacity of the ADF and save them as one data file.

After scanning the first batch of documents, press Continue to scan additional pages. When you are finished scanning, press Complete.

Color Tone Adjustment

Adjust the brightness and contrast.

Adjust Auto Color Detect

When the Scan Type is set to Auto, you can adjust the detection level of

Skip Blank Page sensitivity

Select the sensitivity level for detecting blank pages in the scanned data. The higher the sensitivity

Margin Settings

Adjust the scanning position of documents if the output position of the images has shifted or if the images are squeezed together or stretched vertically

Returns the settings to the default settings.

Returns the settings to the factory settings.

, the easier it is for the machine to detect blank pages.

color.

Related Information

• Scan Using the Scan Button on Y

our Brother Machine

Home > Scan > Scan Using the Scan Button on Y

our Brother Machine > Restrict Scan Functions from

External Devices

Restrict Scan Functions from External Devices

Related Models: ADS-2700W

This feature allows you to restrict scan functions from external devices. When you restrict scan functions from external devices, an error message appears on the device and users cannot use those scan functions.

e recommend Microsoft® Internet Explorer® 8/10/11 for Windows®, and Safari 8.0 for Mac. Make sure that

W JavaScript and Cookies are always enabled in whichever browser you use. If a different web browser is used, make sure it is compatible with HTTP 1.0 and HTTP 1.1.

1. Start your web browser.

ype "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the

T machine's IP address). For example: http://192.168.1.2

By default, no password is required. If you have previously set a password, type it, and then click

Click the Scan tab.

3. Click the Scan from PC menu in the left navigation bar.

4. Disable the Pull Scan option.

5. Click Submit.

Related Information

• Scan Using the Scan Button on Y

our Brother Machine

Home > Scan >

Scan from Your Computer (Windows®)

There are several ways you can use your computer to scan documents on your Brother machine. Use the software applications provided by Brother

•

Scan Using Nuance™ PaperPort™ 14 or Other Windows® Applications

•

Scan Using Windows® Photo Gallery or Windows® Fax and Scan

•

Scan Using Nuance™ Power PDF

, or use your favorite scanning application.

Home > Scan > Scan from Y

our Computer (Windows®) > Scan Using Nuance™ PaperPort™ 14 or Other

Windows® Applications

Scan Using Nuance™ PaperPort™ 14 or Other Windows® Applications

You can use the Nuance™ PaperPort™ 14 application, which is included in the scanner driver

For detailed instructions on using each application, click the application's Help menu, and then click Getting Started Guide in the Help ribbon.

The instructions for scanning in these steps are for Nuance™ PaperPort™ 14. For other Windows applications, the steps will be similar

TWAIN driver (recommended) is used in these steps.

1. Load your document.

Start Nuance™ PaperPort™ 14. Do one of the following:

• Windows® XP and Windows® 7

Click

Windows® 8

•

Click

•

Windows® 10

Click

Click the Desktop menu, and then click Scan Settings in the Desktop ribbon.

The Scan or Get Photo panel appears on the left side of the screen.

4. Click Select.

5. From the available Scanners list, select TWAIN: Brother ADS-XXXXX or TWAIN: Brother ADS-XXXXX LAN (where ADS-XXXXX is the model name of your machine). To use the WIA driver, select the Brother driver that has "WIA" as the prefix.

6. Select the Display scanner dialog box check box in the Scan or Get Photo panel.

7. Click Scan.

The Scanner Setup dialog box appears.

(Start) > All Programs > Nuance PaperPort 14 > PaperPort.

(PaperPort).

> All apps > Nuance PaperPort 14 > PaperPort.

. Nuance™ PaperPort™ 14 supports both TWAIN and WIA drivers; the

, for scanning.

8. Adjust the settings in the Scanner Setup dialog box, if needed.

Click the Document Size drop-down list, and then select your document size.

10. Click PreScan to preview your image and crop unwanted portions before scanning.

11. Click Scan.

The machine starts scanning.

Related Information

• Scan from Y

• TWAIN Driver Settings (Windows®)

our Computer (Windows®)

Home > Scan > Scan from Y

our Computer (Windows®) > Scan Using Nuance™ PaperPort™ 14 or Other

Windows® Applications > TWAIN Driver Settings (Windows®)

TWAIN Driver Settings (Windows®)

• Note that the item names and assignable values will vary depending on the machine.

•

Load only one document per scanning sequence when Long paper, Carrier Sheet Mode, or Plastic

Card Mode is selected.

1. Scan

Select the Photo, W

Scan (Image Type) Resolution Scan Type

Photo Use for scanning photo images. 300 x 300 dpi 24bit Color

Web Use for attaching the scanned

Text Use for scanning text

2. Resolution

Select a scanning resolution from the Resolution drop-down list. Higher resolutions produce a finer scanned image but consume more memory and increase transfer time.

eb, or Text option depending on the type of document you want to scan.

100 x 100 dpi 24bit Color

image to web pages.

200 x 200 dpi Black & White

documents.

Only 300 × 300dpi can be selected when using long paper.

3. Scan Type

Select from a range of scan color

• Auto

Automatically detects whether the document uses color and generates a scanned image of it. For documents that mix color and black and white pages, color pages will be scanned in Color mode, while black and white pages will be scanned in Black & White mode.

• Black & White

Use for text or line art images.

• True Gray

Use for photographic images or graphics. This mode is more accurate because it uses up to 256 shades of gray.

• 24bit Color

Use to create an image with the most accurate color reproduction. This mode uses up to 16.8 million colors to scan the image, but it requires the most memory and has the longest transfer time.

4. Document Size

Select the exact size of your document from a selection of preset scan sizes. If you select Custom, the Custom Document Size dialog box appears and you can specify the document size.

5. Binding Method

Select Long-edge binding or Short-edge binding if you selected the 2 in 1 option in the Document Size settings.

6. 2-sided Scanning

Scan both sides of the document.

depths.

Load only one document per scanning sequence when Carrier Sheet Mode or Plastic Card Mode is selected.

7. Auto rotate rear image 180 degrees

Rotates the scanned image on the reverse side of the page 180 degrees.

Advanced Settings

Configure advanced settings by clicking the Advanced Settings button in the Scanner Setup dialog box.

• Paper Detection

- Auto Deskew

Set the machine to correct document skewing automatically.

Because the Auto Deskew feature is automatically set to On if you select Auto for the Document Size and set to Of

f if you select fixed for the Document Size, you cannot change the Auto Deskew setting.

- Auto Image Rotation

Changes the direction of the document based on the text orientation.

- Detect End of Page

Detects the end of page and automatically adjusts the size of a page when the length of the document is shorter than the Document Size

- Document Event Capture (Multifeed Detection)

When your machine detects a multifeed or a document size difference, you must confirm that the data scanned so far has been saved, and then start scanning again from the next page or the beginning of the document.

• Load documents of the same paper weight and size in the Paper Guides.

• Suitable paper weight: 0.11 lb to 0.46 lb (50 g/㎡ to 209 g/㎡).

• Make sure the top of each page is not aligned. (Separation between documents of more than

0.33mm to 20.33mm needed.)

selected.

• Make sure the first page is loaded first.

Make sure the document is not crooked. (Less than a 3° horizontal skew, 0.7° skew between

• documents.)

• Will not work when the Long Paper option is selected.

• After loading the first page, the machine will pause for up to four seconds for document analysis.

We recommend disabling this setting when you are scanning thick paper to avoid feeding error.

•

• Image Quality

- B&W Threshold Adjustment

This setting allows you to adjust the image quality when scanning in Black & White values increase the amount of black in the scanned image, while smaller values increase the amount of white.

- Grayscale Adjustment

This function adjusts the brightness and contrast to create gray images.

Brightness

Set the Brightness level by moving the slider to the right or left to lighten or darken the image. If the scanned image is too light, set a lower brightness level and scan the document again. If the image is too dark, set a higher brightness level and scan the document again. You can also type a value in the field to set the brightness.

Contrast

Increase or decrease the Contrast level by moving the slider to the right or left. An increase emphasizes dark and light areas of the image, while a decrease reveals more details in gray areas. You can also type a value in the field to set the contrast.

- Color Tone Adjustment

Allows you to adjust the brightness, contrast and gamma during gray and color scanning.

- Auto Color Detect Adjust

When scan type Auto is selected, you can adjust the detection level of color. Increasing the slider value makes the machine more likely to determine that a given document is a color document.

- Background Processing

• Remove Bleed-through / Pattern

Prevent bleed-through.

• Remove Background Color

Remove the base color of documents to make the scanned data more legible.

- Color Drop

Select a color to remove from the scanned image.

- Boldface Formatting

Emphasize the characters of the original by making them bold.

- Blurred Character Correction

Correct any broken or incomplete characters in the original to make them easier to read.

- Edge Emphasis

Make the characters of the original sharper.

- Noise Reduction

This feature allows you to remove small dots or specks called “noise”, from the background of scanned images. Removing unwanted specks helps to reduce compressed file sizes.

- Remove Ruled Line

This feature allows you to remove lines in the document. You can select the type of line direction to remove (Vertical, Horizontal, Vertical and Horizontal).

• Minimum Line Length

Lines longer than or equal to the specified length are removed.

mode. Larger

• Maximum Clearance

If lines are broken, for example due to fading of the image, the lines that are broken for an interval less than or equal to the specified broken line distance will be detected and removed.

Original Document Scan

Result

There are horizontal and vertical lines. If you select V

Description

ertical, the vertical line is removed.

If you select Horizontal, the horizontal line is removed.

If you select V removed.

ertical and Horizontal, all lines are

- Punch Hole Removal

This feature removes the punch hole markings by filling hole marks with white or the surrounding

color

- Invert Image

Reverse the brightness and the colors in the image.

- Compression

Select the size of the compressed file. If you select Large, the file size of the image will be large, but the quality will be good.

• The following items can be selected when scanning black and white images:

- Binding Method

- Blurred Character Correction

- Noise Reduction

The following items can be selected when scanning color or gray images:

•

- Color Tone Adjustment

- Color Drop

- Remove Background Color

- Boldface Formatting

- Punch Hole Removal

- Remove Bleed-through / Pattern

- Edge Emphasis

- Remove Ruled Line

• Page Control

- Carrier Sheet Mode

Use the Carrier Sheet (not included) to scan the following document types:

Important documents (photos, contracts)

•

• Thin paper (receipts)

• Irregularly-shaped paper (clippings)

- Plastic Card Mode

This feature automatically selects the suitable settings for scanning cards, such as driving licenses and insurance cards.

- Margin Settings

This feature allows you to add or remove a specific margin (from -0.12 in. to 0.12 in. (-3 mm to 3 mm)) at the edge of the image. A positive value decreases the size of the scanned image when it is output and a negative value increases the size of the scanned image when it is output.

- Edge Fill

Fill in the edges on four sides of the scanned image using the selected

Binding Method and B&W Threshold Adjustment cannot be selected when using Edge Fill.

- Skip Blank Page

Remove the document's blank pages from the scanning results.

- Single Page Scan

Scans one page at a time from the ADF

- Continuous Scan

Select this option to scan additional documents using the same settings when a scan has been completed. It is useful when you are scanning more documents than the ADF can hold or when you are scanning several documents at once.

, regardless of the number of pages in the ADF.

color and range.

Related Information

• Scan Using Nuance™ PaperPort™

14 or Other Windows® Applications

Home > Scan > Scan from Y

our Computer (Windows®) > Scan Using Windows® Photo Gallery or

Windows® Fax and Scan

Scan Using Windows® Photo Gallery or Windows® Fax and Scan

Windows® Photo Gallery or Windows® Fax and Scan applications are other options that you can use for scanning.

These applications use the WIA scanner driver

1. Load your document.

2. Launch your scanning application. Do one of the following:

• Windows® Photo Gallery

Click File > Import from Camera or Scanner.

• Windows® Fax and Scan

Click File > New > Scan.

3. Select the scanner you want to use.

4. Click Import or OK.

The New Scan dialog box appears.

5. Adjust the settings in the Scanner Setup dialog box, if needed.

Click Scan.

The machine starts scanning.

Related Information

• Scan from Y

our Computer (Windows®)

• WIA Driver Settings (Windows®)

Home > Scan > Scan from Y

Windows® Fax and Scan > WIA Driver Settings (Windows®)

our Computer (Windows®) > Scan Using Windows® Photo Gallery or

WIA Driver Settings (Windows®)

1. Paper source

ou can select Document Feeder only.

2. Picture Type (Image Type)

Select Color picture, Grayscale picture, Black and white picture or text, or Custom Settings for the type of document you want to scan.

To change advanced settings, click the Adjust the quality of the scanned picture link.

1. Brightness

Contrast

3. Resolution (DPI)

Select a scanning resolution from the Resolution (DPI) list. Higher resolutions produce a finer scanned image but consume more memory and increase transfer time.

4. Picture type

Select or change the type of document you want to scan.

Related Information

• Scan Using Windows® Photo Gallery or Windows®

Fax and Scan

Home > Scan > Scan from Y

our Computer (Windows®) > Scan Using Nuance™ Power PDF

Scan Using Nuance™ Power PDF

You can use the Nuance™ Power PDF application for scanning. It converts the scanned PDF data into other formats including Microsoft® W

to enter the serial number when installing the software, check the label attached to the scanner. See the Nuance™ Power PDF Help menu for more information.

Related Information

ord, Microsoft® Excel, Microsoft® PowerPoint, images and more. If you are asked

• Scan from Y

our Computer (Windows®)

Home > Scan >

Scan from Your Computer (Mac)

There are several ways you can use your Mac to scan documents on your Brother machine. Use the software applications provided by Brother or your

• Scan Using Brother iPrint&Scan

• Scan Using TWAIN-Compliant Applications (Mac)

• Scan Using Apple Image Capture (ICA Driver)

favorite scanning application.

Home > Scan > Scan from Y

our Computer (Mac) > Scan Using Brother iPrint&Scan

Scan Using Brother iPrint&Scan

Use Brother iPrint&Scan for Mac to scan from your computer. Download and install Brother iPrint&Scan from the App Store.

In the Finder menu bar, click Go > Applications, and then double-click the iPrint&Scan icon.

The Brother iPrint&Scan screen appears.

2. If your Brother machine is not selected, click the Select your Machine button, and then follow the on-screen

instructions to select your Brother machine.

3. Click the Scan icon, and then follow the on-screen instructions to scan your documents.

Related Information

• Scan from Your Computer (Mac)

Home > Scan > Scan from Y

our Computer (Mac) > Scan Using TWAIN-Compliant Applications (Mac)

Scan Using TWAIN-Compliant Applications (Mac)

You can scan using TWAIN-compliant applications. For more information about the scanning procedure, see the manual for your application.

Start your graphics application, and then select the scan operation.

The scanner setup dialog box appears.

2. (ADS-2700W) Click the device selection menu, and then select your model name (if not already selected).

Adjust the settings in the Scanner Setup dialog box, if needed.

4. Click the Document Size pop-up menu, and then select your document size.

5. Click the PreScan option to preview your image and crop unwanted portions before scanning.

6. Press Scan.

The machine starts scanning.

Related Information

• Scan from Y

• TWAIN Driver Settings (Mac)

our Computer (Mac)

Home > Scan > Scan from Y

our Computer (Mac) > Scan Using TWAIN-Compliant Applications

(Mac) > TWAIN Driver Settings (Mac)

TWAIN Driver Settings (Mac)

The options and settings available vary depending on the machine.

1. Resolution

Select a scanning resolution from the Resolution pop-up menu. Higher resolutions produce a finer scanned image but consume more memory and increase transfer time.

Scan Type

Select from a range of scan color depths.

• Auto

• Black & White

Use for text or line art images.

• Gray (Error Diffusion)

rue Gray

• T

Use for photographic images or graphics. This mode is more accurate because it uses up to 256 shades of gray.

• 24bit Color

Use to create an image with the most accurate color reproduction. This mode uses up to 16.8 million colors to scan the image, but it requires the most memory and has the longest transfer time.

3. Document Size

Select the exact size of your document from a selection of preset scan sizes. If you select Custom, you can specify the document size.

4. 2-sided Scanning

Scan both sides of the document.

5. Auto rotate rear image 180 degrees

Rotates the scanned image on the back page 180 degrees.

6. Advanced Settings

Configure advanced settings by clicking the Advanced Settings button in the Scanner Setup dialog box.

• Image Quality

- Grayscale Adjustment

This function adjusts the brightness and contrast to create gray images.

Brightness

Set the Brightness level by moving the slider to the right or left to lighten or darken the image.If the scanned image is too light, set a lower brightness level and scan the document again. If the image is too dark, set a higher brightness level and scan the document again. You can also type a value in the field to set the brightness.

Contrast

- Color Tone Adjustment

Allows you to adjust the brightness, contrast and gamma during gray and color scanning.

- Auto Color Detect Adjust

When scan type Auto is selected, you can adjust the detection level of color. Increasing the slider value makes the machine more likely to determine that a given document is a color document.

- Noise Reduction

This feature allows you to remove small dots or specks called “noise”, from the background of scanned images. Removing unwanted specks helps to reduce compressed file sizes.

• Page Control

- Continuous Scan

Related Information

• Scan Using TW

AIN-Compliant Applications (Mac)

Home > Scan > Scan from Y

our Computer (Mac) > Scan Using Apple Image Capture (ICA Driver)

Scan Using Apple Image Capture (ICA Driver)

You can scan a document using the ICA driver. If you installed the Full Driver and Software Package from the Brother Solutions Center at support.brother.com, the ICA driver is already installed on your computer also scan directly using the Image Capture application.

Related Information

. You can

• Scan from Y

• Scan Using Apple Image Capture

• ICA Driver Settings

our Computer (Mac)

Home > Scan > Scan from Y

our Computer (Mac) > Scan Using Apple Image Capture (ICA Driver) > Scan

Using Apple Image Capture

Scan Using Apple Image Capture

1. Launch the Image Capture

2. Select the machine from the list on the left side of the screen.

If you connected the Brother machine to your Mac with a USB cable, you will see the machine in the DEVICES area. If connected via LAN, you will see it in the SHARED

application.

area.

3. Load your document.

Select the size of your document.

5. Select the destination folder or destination application from the Scan To pop-up menu.

6. Click Scan.

The machine starts scanning.

Related Information

• Scan Using Apple Image Capture (ICA Driver)

Home > Scan > Scan from Y

Driver Settings

ICA Driver Settings

our Computer (Mac) > Scan Using Apple Image Capture (ICA Driver) > ICA

To adjust image capture settings, click Show Details.

Item names and assignable values may vary depending on the machine.

1. Kind

Allows you to select from Color, Black&White, or T

2. Resolution

Specifies the document resolution you want.

3. Scan Size/Size

Specifies the paper size of the document.

4. Orientation

Specifies the orientation of the document.

5. Duplex

Allows you to select the Duplex check box to perform 2-sided (duplex) scanning.

6. Scan To

Specifies the destination folder or destination application.

7. Name

Allows you to enter the prefix text used for the name of the scanned image.

8. Format

Specifies the file format of the scanned data.

9. Combine into single document

Allows you to scan a document as one item and save it as one file when selecting PDF or TIFF for the file format.

10. Image Correction

Depending on the Kind option selected, it allows you to configure the following settings:

ext.

Kind Configurable Settings

Color Brightness, T

Black&White Brightness, Contrast

Text Threshold

Related Information

• Scan Using Apple Image Capture (ICA Driver)

int, Temperature, Saturation

Home > Network

Network

• Supported Basic Network Features

• Network Management Software and Utilities

• Additional Methods of Configuring Y

our Brother Machine for a Wireless Network

• Advanced Network Features

• Technical Information for Advanced Users

Home > Network > Supported Basic Network Features

Supported Basic Network Features

Related Models: ADS-2700W

The machine supports various features depending on the operating system. Use this table to see which network features and connections are supported by each operating system.

Operating Systems

Scanning Yes Yes Yes

BRAdmin Light

Web Based Management Yes Yes Yes

Remote Setup Yes Yes

Windows ® XP (SP3)

indows® 7 (SP1)

Windows® 8

Windows® 8.1

Windows® 10

Yes

Windows Server® 2008 R2 (SP1)/2012/2012 R2/2016

macOS v10.10.5

macOS v10.1

macOS v10.12.x

Related Information

• Network

1.x

BRAdmin Light is available as a download from your model's Downloads page at support.brother.com.

Home > Network > Network Management Software and Utilities

Network Management Software and Utilities

Configure and change your Brother machine's network settings using a management utility.

• Learn about Network Management Software and Utilities

Home > Network > Network Management Software and Utilities >

Learn about Network Management

Software and Utilities

Learn about Network Management Software and Utilities

Related Models:

ADS-2700W

Web Based Management

eb Based Management is a utility that uses a standard web browser to manage your machine using the Hyper Text Transfer Protocol (HTTP) or Hyper Text Transfer Protocol over Secure Socket Layer (HTTPS). Type your machine's IP address into your web browser to access and change your scanner settings.

BRAdmin Light (Windows®)

BRAdmin Light is a utility for the initial setup of Brother network-connected devices. This utility can search for Brother products on your network, view the status and configure the basic network settings, such as IP address.

Go to your model's Downloads page on the Brother Solutions Center at latest version of Brother's BRAdmin Light.

• If using Windows® Firewall, or the firewall function of an anti-spyware or antivirus application, temporarily disable them. When you are sure you can scan, configure the software settings by following the manufacturer's instructions.

support.brother.com to download the

Remote Setup (Windows® and Mac)

Remote Setup is a program for configuring many machine and network settings from either a Windows® or a Mac application. When you start this application, the settings on your machine are automatically downloaded to your computer and displayed on your computer screen. If you change the settings, you can upload them directly to the machine.

This utility can be used with either a USB or a network connection.

Related Information

• Network Management Software and Utilities

Home > Network > Additional Methods of Configuring Y

our Brother Machine for a Wireless Network

Additional Methods of Configuring Your Brother Machine for a Wireless Network

• Before Configuring Y

our Brother Machine for a Wireless Network

• Configure Your Machine for a Wireless Network Using the One-Push Method of Wi-Fi

Protected Setup™ (WPS)

• Configure Your Machine for a Wireless Network Using the PIN Method of Wi-Fi Protected

Setup™ (WPS)

• Configure Your Machine for a Wireless Network Using the Machine's Control Panel

Setup Wizard

•

Use Wi-Fi Direct

Home > Network > Additional Methods of Configuring Y

our Brother Machine for a Wireless

Network > Before Configuring Your Brother Machine for a Wireless Network

Before Configuring Your Brother Machine for a Wireless Network

Related Models:

Before attempting to configure a wireless network, confirm the following:

Before configuring wireless settings, you must know your Network name (SSID) and Network Key

• (Password). If using an enterprise wireless network, you must know the User ID and Password.

If you do not know this security information, contact the router manufacturer, your system administrator, or your Internet provider

• To achieve optimum results with normal everyday document scanning, place the Brother machine as close to the wireless access point/router as possible with minimal obstructions. Large objects and walls between the two devices and interference from other electronic devices can affect the data transfer speed of your documents.

Due to these factors, wireless may not be the best method of connection for all types of documents and applications. If you are scanning large files, such as multi-page documents with mixed text and large graphics, you may want to consider selecting wired Ethernet for faster data transfer, or USB for the fastest throughput speed.

• Although the Brother machine can be used in both a wired and wireless network, only one connection method can be used at a time.

ADS-2700W

Related Information

• Additional Methods of Configuring Y

our Brother Machine for a Wireless Network

Home > Network > Additional Methods of Configuring Y

Network > Configure Your Machine for a Wireless Network Using the One-Push Method of Wi-Fi Protected

Setup™ (WPS)

our Brother Machine for a Wireless

Configure Your Machine for a Wireless Network Using the One-Push Method of W

Related Models: ADS-2700W

If your wireless access point/router supports Wi-Fi Protected Setup™ (WPS), you can use WPS from your machine's control panel menu to configure your wireless network settings.

Routers or access points that support WPS are marked with this symbol:

1. Press [Settings]

2. When [Enable WLAN? The Wired Network I/F will be disabled. Do you want to continue?] appears, press [Yes].

The wireless setup wizard starts. To cancel, press [No].

3. When the touchscreen instructs you to start WPS, press the WPS button on your wireless access point/ router. Press [OK], and then your machine automatically tries to connect to your wireless network.

i-Fi Protected Setup™ (WPS)

> [Network] > [WLAN] > [WPS].

If your wireless device is connected successfully, the LCD displays [Connected].

You have completed the wireless network setup. To install drivers and software necessary for operating your device, go to your model's Downloads page on the Brother Solutions Center at

o configure additional Network Settings, use the Web Based Management. See Related Information: Access

T Web Based Management

support.brother.com.

Related Information

• Additional Methods of Configuring Y

• Access Web Based Management

our Brother Machine for a Wireless Network

Home > Network > Additional Methods of Configuring Y

Network > Configure Your Machine for a Wireless Network Using the PIN Method of Wi-Fi Protected Setup

(WPS)

our Brother Machine for a Wireless

Configure Your Machine for a Wireless Network Using the PIN Method

™

of W

Related Models: ADS-2700W

If your wireless access point/router supports WPS, you can use the Personal Identification Number (PIN) Method to configure your wireless network settings.

The PIN Method is one of the connection methods developed by the Wi-Fi Alliance®. By submitting a PIN created by an Enrollee (your machine) to the Registrar (a device that manages the wireless LAN), you can set up the wireless network and security settings. For more information on how to access WPS mode, see the instructions provided with your wireless access point/router

Type A

i-Fi Protected Setup™ (WPS)

Connection when the wireless access point/router (1) doubles as the Registrar.

Type B

Connection when another device (2), such as a computer

Routers or access points that support WPS are marked with this symbol:

1. Press [Settings]

> [Network] > [WLAN] > [WPS w/ PIN Code].

, is used as the Registrar.

2. When [Enable WLAN? The Wired Network I/F will be disabled. Do you want to continue?] appears, press [Yes].

The wireless setup wizard starts. To cancel, press [No].

3. The LCD displays an eight-digit PIN and the machine starts searching for a wireless access point/router.

4. Using a computer connected to the network, in your browser's address bar, type the IP address of the device you are using as the Registrar

5. Go to the WPS settings page and type the PIN, and then follow the on-screen instructions.

• The Registrar is usually the wireless access point/router.

•

The settings page will differ depending on the brand of wireless access point/router. For more detailed information, see the instructions supplied with your wireless access point/router.

. (For example: http://192.168.1.2)

If using a Windows® 7, W the following steps:

6. Do one of the following:

• Windows® 10

Click

• Windows® 8 and Windows® 8.1

Move your mouse to the lower right corner of your desktop. When the menu bar appears, click Settings > Control Panel > Hardware and Sound > Devices and Printers > Add a device.

• Windows® 7

Click

• To use Windows® register it to your network in advance. For more detailed information, see the instructions supplied with your wireless access point/router.

• If you use Windows® 7, Windows® 8, Windows® 8.1, or Windows® 10 as a Registrar, you can install the scanner driver after the wireless configuration by following the on-screen instructions. To install the full driver and software package, see the Quick Setup Guide.

7. Select your machine and click Next.

Type the PIN displayed on the machine's LCD, and then click Next.

> W

(Start) > Devices and Printers > Add a device.

indows® 8, Windows® 8.1, or Windows® 10 computer as a Registrar, complete

indows System > Control Panel. In the Hardware and Sound group, click Add a device.

7, Windows® 8, Windows® 8.1, or Windows® 10 computer as a Registrar, you must

9. (Windows® 7 only) Select your network, and then click Next.

10. Click Close.

If your wireless device is connected successfully, the LCD displays [Connected].

You have completed the wireless network setup. To install drivers and software necessary for operating your device, go to your model's Downloads page on the Brother Solutions Center at

To configure additional Network Settings, use the Web Based Management. See Related Information: Access Web Based Management

support.brother.com.

Related Information

• Additional Methods of Configuring Y

• Access Web Based Management

our Brother Machine for a Wireless Network

Home > Network > Additional Methods of Configuring Y

our Brother Machine for a Wireless

Network > Configure Your Machine for a Wireless Network Using the Machine's Control Panel Setup Wizard

Configure Your Machine for a Wireless Network Using the Machine's Control Panel Setup W

Related Models: ADS-2700W

Before configuring your machine, we recommend writing down your wireless network settings. You will need this information before you continue with the configuration.

1. Check and write down the current wireless network settings.

Network Name (SSID)

Network Key (Password)

For example:

Network Name (SSID)

HELLO

Network Key (Password)

12345

izard

If your router uses WEP encryption, enter the Network Key (Password) used as the first WEP key. Your Brother machine supports the use of the first WEP key only

2. Press [Settings]

3. When [Enable WLAN? The Wired Network I/F will be disabled. Do you want to continue?] appears, press [Yes].

The wireless setup wizard starts. To cancel, press [No].

4. The machine searches for your network and displays a list of available SSIDs. Press a or b to display the SSID you want to connect to, and then press it.

5. Press [OK].

6. Do one of the following:

• If using an authentication and encryption method that requires a Network Key (Password), enter the

Network Key (Password) you wrote down in the first step.

When you have entered all the characters, press [OK].

• If your authentication method is Open System and your encryption mode is None, go to the next step.

7. The machine attempts to connect to the wireless device you have selected.

If your wireless device is connected successfully, the LCD displays [Connected].

You have completed the wireless network setup. To install drivers and software necessary for operating your device, go to your model's Downloads page on the Brother Solutions Center at

o configure additional Network Settings, use the Web Based Management. See Related Information: Access

Web Based Management

> [Network] > [WLAN] > [Setup Wizard].

support.brother.com.

Related Information

• Additional Methods of Configuring Y

our Brother Machine for a Wireless Network

Brother ADS-2700W User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Before You Use Your Brother Machine

Definitions of Notes

Trademarks

Important Note
