brite-View BV-210C User Manual

0

Table of Content

1. IMPORTANT INFORMATION.....................................................................................................2

1.1 Important Safety Notes........................................................................................2

1.2 Federal Communications Commission Interference Statement...........................3

2. INTRODUCTION....................................................................................................................5

2.1 Package Content.................................................................................................5

2.2 Product Overview................................................................................................5

2.2.1 Buttons and LEDs ............................................................................................5

3. HARDWARE INSTALLATION ....................................................................................................7

3.1 Application 1 – Provide Network Connection for Your Networked Device ...........7

3.2 Application 2 – Extend Wireless Access Point Coverage....................................7

ENCRYPTED PLC NETWORK.................................................................................................8

4.

4.1 Create a Private Encrypted PLC Network Group..............................................8

4.2 Remove Device from an Existing Network Group.............................................9

4.3 Create Additional Private Network.....................................................................9

4.4 Standby Mode...................................................................................................9

5.

ENHANCE PLC PERFORMANCE...........................................................................................10

6. SPECIFICATIONS ................................................................................................................12

1

1. IMPORTANT INFORMATION

1.1 Important Safety Notes

z Please read all instructions before installing and operating this product.
z Please keep all instructions for later reference.
z Please follow all warnings and instructions marked on the product.
z For safety reasons, when the device is powered on, the venting holes should remain

uncovered.

z Unplug the Powerline device from the wall outlet before cleaning. Use a dry cloth for

cleaning. DO NOT use liquid cleaners or aerosol cleaners.

z DO NOT operate this product near any liquid.
z This product should never be placed near or over a radiator and heat register.

This product relies on the building’s electrical installation for short-circuit (over-current)
protection.

z It is recommended that the adapter is plugged directly into an electrical outlet, rather than

into an uninterruptable power supply or extension cord with surge protection. brite-View
Powerline adapters have their own power filter for surge protection.

z Only a qualified technician should service this product. Opening or removing covers may

expose you to dangerous voltage or other hazards.
Unplug the product from the wall outlet and refer the product to qualified service personnel for the
following conditions:

¾ If liquid has been spilled into the product.

¾ If the product has been exposed to rain or water.

¾ If the product does not operate normally when the operating instructions are followed.

¾ If the product exhibits a distinct change in performance.

2

1.2 Federal Communications Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:

Any changes or modifications not expressly approved by the grantee of this device could void the
user's authority to operate the equipment.

Labeling Requirements

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

RF Exposure Warning

This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least
20 cm from all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter. End-users and installers must be provide with antenna installation
instructions and transmitter operating conditions for satisfying RF exposure compliance.

Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.

Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Industry Canada (IC) radio

3
