the Quick Roast™
Instruction Booklet
BMO715
CONTENTSCONTENTS
3 Breville recommends safety first
8 Know your Breville product
10 Assembling your Breville product
12 Operating your Breville product
17 Care & cleaning
2
BREVILLE RECOMMENDS SAFETY FIRSTBREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions.
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS
CAREFULLY BEFORE USE AND
SAVE FOR FUTURE REFERENCE
• Remove and safely discard any packaging
material and promotional labels before
using the Breville microwave oven for the
first time.
• To eliminate a choking hazard for young
children, remove and safely discard the
protective cover that is fitted to the power
plug of the Breville microwave oven.
• Do not place the microwave oven near the
edge of a bench or table during operation.
Ensure all surfaces are level, clean and free
of water or any other substances.
• Do not place the microwave oven on or
near a hot gas or electric burner, or where
it could touch a heated oven.
• Microwave oven to be installed as
freestanding unit only. When using
the microwave oven, provide adequate
air space above and on all sides for air
circulation. (see page 10 Installation,
point 2).
• Always operate the microwave oven on
a heat-resistant surface. Do not use on a
cloth-covered surface, near curtains or
other flammable materials.
• Do not use the microwave oven on a metal
surface, for example a sink drain board.
• Always ensure the microwave oven is
properly assembled before connecting to
the power outlet and operating. Do not use
the oven without the turntable roller and
glass turntable in place. Ensure the glass
turntable is positioned correctly into the
indents on the turntable roller.
• The microwave oven is not intended to be
operated by means of an external timer or
separate remote control system.
• Never use the microwave oven without
food or water in the oven cavity. Operating
the microwave oven when empty could
cause damage to the appliance.
• Do not leave the microwave oven
unattended when in use.
• Do not touch hot surfaces. Allow the
microwave oven to cool before moving or
cleaning any parts.
• Always ensure the microwave oven is
turned off at the power outlet and the cord
is unplugged from the power outlet before
attempting to move the appliance, when
not in use, if left unattended and before
disassembling, cleaning or storing.
• Keep the appliance clean. Follow the
cleaning instructions provided in this
book (page 17).
• Always turn the microwave oven off by
pressing the STOP/CLEAR button, switch
off at the power outlet and unplug at the
power outlet when it is not in use.
• Before cleaning, always press STOP/
CLEAR position, switch off at the power
outlet and unplug at the power outlet.
• Fire may occur if the oven is covered or
touches flammable material, including
curtains, draperies, walls and the like when
in operation
• Caution should be taken when toasting
and grilling high oil content foods, such as
pine nuts and walnuts. They may catch fire.
If this occurs, please keep the oven door
closed and switch off and unplug oven
until flame has extinguished.
3
BREVILLE RECOMMENDS SAFETY FIRST
• Do not place cardboard, plastic, paper or
other flammable materials into the oven.
• The temperature of accessible surfaces will
be high when the appliance is in operation
and also for some time after use.
• Always wear protective, insulated oven
mitts when inserting, removing or handling
items from the oven.
• Always use extreme caution when
removing any of the accessories or
disposing of hot grease. Allow the oven to
cool before handling.
• Do not place hands inside the oven
during operation.
• Do not insert oversized foods into the oven
as they create risk of fire or electric shock.
• It is recommended to use only the Breville
provided accessories with this oven.
Do not store any materials other than the
Breville oven accessories in the oven when
not in use.
• Do not clean interior of the oven with
metal scouring pads as pieces can break off
the pad and touch electrical parts creating
a risk of electric shock.
• Do not attempt to operate the oven by
any methods other than those described
in this book.
• The top of the oven is very hot during
and after operation. Do not store any
item on top of the oven when in use
and when stored.
• Do not touch hot surfaces. Appliance
surfaces, including the door and outer
surface of the oven are hot during and after
operation. To prevent burns or personal
injury, always use protective hot pads or
insulated oven mitts, or use handles and
knobs where available, when inserting,
removing or handling items from the oven.
Alternatively allow the oven to cool down
before handling.
• The use of any accessory attachments
not recommended by Breville may
cause injuries.
• Use only the wire rack provided by Breville.
The wire rack must always be placed at the
centre of the glass turntable and make sure
the wire rack does not come in contact
with the oven cavity which can cause
electric shock.
IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do not
use the appliance if power cord, power
plug or appliance becomes damaged in
any way. Return the entire appliance to
the nearest authorised Breville Service
Centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
4
BREVILLE RECOMMENDS SAFETY FIRST
BREVILLE RECOMMENDS SAFETY FIRST
• The installation of a residual current
device (safety switch is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in use.
• Before cleaning, always turn the appliance
to the OFF position, switch off at the
power outlet, unplug at the power outlet
and remove the power cord, if detachable,
from the appliance and allow all parts
to cool.
• Do not place this appliance on or near
a heat source, such as hot plate, oven
or heaters.
• Position the appliance at a minimum
distance of 20cm away from walls,
curtains and other heat or stream
sensitive materials and provide
adequate space above and on all sides
for air circulation.
SPECIAL SAFETY
INSTRUCTIONS FOR YOUR
MICROWAVE OVEN
• Wipe the oven cavity with a soft, damp
cloth after each use. Leaving food residue,
grease or fat in the cavity could cause the
microwave oven cavity to overheat and
may cause the microwave oven to smoke
or catch fire.
• The microwave oven should be cleaned
regularly and any food splattering inside
the cavity should be removed. Failure to
maintain the microwave oven in a clean
condition could lead to deterioration of the
surface, adversely affecting the life of the
microwave oven and possibly resulting in
a hazardous situation.
• If the door seals or any of the microwave
oven is damaged, the microwave oven
must not be operated until it has been
inspected and/or repaired at an authorised
Breville Service Centre.
• The microwave oven is intended for
heating food and beverages. Drying of food
or clothing and heating or warming pads,
slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
• Ensure all food containers and/or plates
are suitable for use in the microwave oven.
This should be done prior to preparing
food for heating or cooking in the
microwave oven. Monitor foods and liquids
heating or cooking in the microwave
oven at all times due to the possibility of
containers igniting.
• Containers or plates suitable for use in the
microwave oven should not exceed the
width of the glass turntable as this may
impede the rotation of the turntable and
result in food being unevenly cooked.
• Liquids or other foods must not be heated
in sealed containers since they are liable
to explode.
• Some containers and/or plates may appear
suitable for use in the microwave oven but
may be coated in a glaze that will absorb
the microwave energy, overheat and cause
the container to crack. The glaze may also
prevent the food from heating/cooking.
• Food and/or liquids should not be heated
or cooked directly on the glass turntable.
Food and/or liquids must be placed into a
suitable microwave-proof container before
placing onto the glass turntable.
• Food and/or liquids should not be heated
or cooked in plastic or paper containers or
bags, unless specified a suitable for use by
the manufacturer, due to the possibility of
containers exploding or igniting.
• When heating food in plastic or paper
containers, keep an eye on the oven due to
the possibility of ignition.
• Metal clips or twist ties should be removed
from the packaging as these could cause
sparking and/or fire.
5
BREVILLE RECOMMENDS SAFETY FIRST
BREVILLE RECOMMENDS SAFETY FIRST
• Do not use recycled paper or kitchen
paper towelling when cooking. Recycled
paper may contain small metal or other
impurities which could cause sparking
and/or fire.
• Do not use metal containers or utensils in
the microwave oven as these could cause
sparking and/or fire.
• Only use utensils that are suitable for use
in microwave ovens.
• Food grade foil should not be used in
the microwave oven as this could cause
sparking and/or fire.
• Ensure that lids and caps covering
containers are removed prior to
placing liquids and/or foods into the
microwave oven.
• Feeding bottles and baby food jars should
have lids and caps removed before
warming or heating in the microwave oven.
To avoid burns or scalding after heating,
the contents should be stirred or shaken
and the temperature checked before
serving.
• Always ensure the temperature of food or
drink which has been heated or cooked
in the microwave oven has been tested
before eating, drinking or serving to others,
especially children, disabled or
elderly people.
• The heating of liquids and beverages in
the microwave oven can result in delayed
eruptive boiling. Care must be taken when
handling any containers containing hot
liquids or beverages.
• Do not heat popcorn in the microwave
oven unless it has been commercially
packaged for microwave use. There may be
a number of un-popped kernels that may
overcook and burn when popping popcorn.
Do not use oil unless recommended by
the manufacturer. Do not pop popcorn
longer than the manufacturer’s instructions
(popping time should not exceed
3 minutes). Longer cooking could cause
scorching or fire.
• Do not cook any food surrounded by a
membrane (such as potatoes, chicken
liver, egg yolks, oysters, etc) without first
piercing the membrane several times with
a fork or similar utensils.
• Eggs in the shell and whole hard boiled
eggs should not be cooked or heated in
the microwave oven as they may explode
during cooking, at the end of cooking or
after removing from the microwave oven.
• Do not heat oil or fat in the microwave
oven. Doing so may cause the microwave
oven and/or the oil to overheat and/or
ignite.
• If any smoke is observed, switch off and
unplug the microwave oven at the power
outlet. Keep the door closed to stifle
any flames.
• Do not attempt to operate the microwave
oven by any method other than those
described in this instruction book.
• Do not disconnect the microwave oven
from the power supply by pulling on the
cord to unplug from the power outlet.
• When storing the microwave oven loosely
wind the cord. Do not wrap the cord around
the microwave oven.
• When heating food in plastic or paper
containers, keep an eye on the oven due to
the possibility of ignition.
• The glass window has been specially
treated to make it stronger, more durable
and safer than ordinary glass, however it
is not unbreakable. If dropped or struck
extremely hard, it may break or weaken,
and could at a later time shatter into many
small pieces without apparent cause.
6
BREVILLE RECOMMENDS SAFETY FIRST
WARNING
• Do not attempt to operate the oven with the
door open since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
• Do not place any object between the oven
front face and the door or allow soil or
cleaner residue to accumulate on sealing
surfaces.
• Liquids and other foods must not be heated
in sealed containers since they are liable to
explode.
• If the door or door seals are damaged, the
oven must not be operated until it has been
repaired by a Breville Service Centre. It is
particularly important that the oven door
closes properly and that there is no damage
to the: (1)Door (bent), (2) Hinges and
latches(broken or loosened), (3) Door seals
and sealing surfaces.
• Do not put any foreign material between
the door and door jam of the microwave
oven as this could cause excessive leakage
of microwave energy.
• It is hazardous for anyone other than a
Breville Service Centre to carry out any
service or repair operation that involves the
removal of a cover which gives protection
against exposure to microwave energy.
• When the appliance is operated in the
combination mode, children should only
use the oven under adult supervision due to
the temperature generated.
• Surfaces may be hot during and after use.
• If the apparatus is not maintained in a
good state of cleanliness, its surface could
be degraded and affect the lifespan of the
product and lead to a dangerous situation.
SPECIFICATIONS
POWER CONSUMPTION
230-240V~, 50Hz,
2300W
CONVECTION
OVEN POWER
GRILL POWER
MICROWAVE
OVEN POWER
MICROWAVE
OVEN OUTPUT
OUTSIDE DIMENSIONS
2300W
1100W
1450W
900W 2450MHz
520mm (H)
510mm (W)
325.7mm (D)
GLASS TURNTABLE
DIAMETER
NET WEIGHT
OVEN CAPACITY
315mm
Approx. 19.9kg
30 Litres
These specifications may change
without notice.
SAVE THESE INSTRUCTIONS
7
KNOW YOUR BREVILLE PRODUCT
KNOW YOUR BREVILLE PRODUCT
D
A
B
C
E
A. LED Display
Shows time, cooking progress and
preset functions.
B. Control panel
C. Door release (pull handle)
D. Viewing window
E. Turntable assembly & installation
a. Grill rack
b. Hub (under glass)
c. Glass turntable
d. Turntable shaft
e. Turntable ring assembly
8
a.
b.
c.
d.
e.
KNOW YOUR BREVILLE PRODUCT
A
B
C
D
E
F
A. LED DISPLAY SCREEN
Shows selected cooking time, power,
symbols and time-of-day.
B. AUTO COOK MENU (1–9)
List of AUTO MENU settings available.
C. AUTO COOK
Press to select menu functions (1–9).
D. CONVECTION
Press CONVECTION to initiate convection
function and select desired cooking
temperature and time.
E. DEFROST & CLOCK
Press to toggle between Time and Weight
Defrost. Weight Defrost automatically sets
the defrosting time and power level once the
weight of the food is entered. Time Defrost
automatically sets the power level once
defrosting time is entered. To set the clock,
press and hold for 3 seconds.
G
F. START/ +30 SEC INSTANT START
Press to start the cooking or defrosting
functions. The cooking symbol will appear on
the display and the interior of oven light will
H
turn on, the interior fan will operate and the
turntable will rotate. Each additional press of
the button will add 30 seconds to the
cooking time.
G. GRILL
I
Press GRILL button once and press
START to initiate grill function.
H. MICROWAVE
Press to set power level (10–100%).
I. STOP/CLEAR & CHILD LOCK
Press to cancel the selected microwave
power level, convection, grill or defrost
J
times that are previously programmed.
The time of the day clock cannot be
cancelled by pressing the STOP/CLEAR
button. Child lock can also be initiated by
holding down the STOP/CLEAR button
for 3 seconds.
J. TIME/WEIGHT DIAL
Turn dial to select time or weight for
individual settings.
9
ASSEMBLING YOUR BREVILLE PRODUCT
BEFORE FIRST USE
Remove and safely discard any packaging
material and labels before using the microwave
oven for the first time. Carefully unpack the
microwave oven and keep all the packing
material until all the parts of the microwave
oven have been found and the appliance has
been assembled.
To remove any dust that may have accumulated
during packing, wash the roller ring and glass
turntable tray in warm soapy water, rinse in
clean water then dry thoroughly. Wipe the
interior and exterior of the microwave oven with
a soft, damp cloth then dry thoroughly.
ASSEMBLING THE GLASS TURNTABLE
AND TURNING ON THE MICROWAVE
OVEN
1. Place the roller ring into position in the
indented space in the oven cavity base.
2. Insert the glass turntable into position,
matching the indents (hub) on the base
of the glass turntable with the indents in
the shaft located in the centre of the oven
cavity base.
INSTALLATION
1. Select a level surface that provides
enough open space for the intake and/or
outlet vents.
2. A minimum clearance of 20cm is required
between the oven and any adjacent walls.
• Leave a minimum clearance of 30cm
above the oven.
• Do not remove the legs from the bottom of
the oven.
3. Blocking the intake and/or outlet openings
can damage the oven.
4. Place the oven as far away from radios and
TV as possible. Operation of microwave
oven may interfere with your radio or
TV reception.
5. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage and
the frequency on the rating label.
30cm
3. Plug the power cord into a 240V~ power
outlet. Switch on at the power outlet. The
microwave oven is now on.
10
20cm
20cm
ASSEMBLING YOUR BREVILLE PRODUCT
WARNING
• When using the grill rack, ensure it
is placed securely in the centre of the
turntable, avoiding any contact with the
surrounding cavity. Contact with the cavity
will result in sparking and could damage
the microwave.
• Ensure plates are grill, oven and microwave
safe. Avoid placing Pyrex on the grill rack
in the upper position as it may overheat
and shatter.
• To avoid an electrical circuit overload, it
is recommended that no other appliances
are plugged into the same circuit as your
microwave oven (or other products) when
it is in use.
• Do not install oven over a range cooktop or
other heat-producing appliances. If installed
near or over a heat source, the oven could be
damaged and the warranty would be void.
• Check the oven for any damage, such as
misaligned or bent door, damaged door
seals and sealing surface, broken or loose
door hinges and latches and dents inside
the cavity or on the door. If there is any
damage, do not operate the oven and
contact a Breville service centre.
• Do not immerse the microwave oven, power
cord or plug in water or any other liquid.
SETTING THE CLOCK
When power is activated, the LED will display
0:00 and the buzzer will beep once.
1. Press and hold DEFROST button for
3 seconds, the hour figure will flash.
2. Turn dial to adjust the hour figures, the
input time should be within 0–23.
3. Press START button, the minute figures
will flash.
4. Turn dial to adjust the minutes figures, the
input time should be within 0–59.
5. Press START button to finish clock setting.
‘:’ will flash, and the time will illuminate.
NOTE
During the process of clock setting, if you
press STOP/CLEAR, the oven will go back
to the previous status automatically.
In the event of a power failure or if the
microwave is unplugged, the clock will
have to be reset.
11
OPERATING YOUR NEW BREVILLE PRODUCT
MICROWAVE COOKING
1. Using the dial, input the cooking time,
maximum cooking time is 95 minutes.
NOTE
Turning the dial clockwise, will increase
time. Turning the dial anticlockwise will
reduce time.
2. Press START/+30 SEC button to
commence operation.
NOTE
This mode will have microwave oven
operating at 100% power level.
MICROWAVE COOKING WITH
POWER LEVELS
To set power levels press the
MICROWAVE|POWER button and continue
to press the MICROWAVE|POWER button
until desired power level is selected.
1. Press MICROWAVE|POWER button
(continue to press) until desired power
level is selected.
2. Using the dial input the desired
cooking time.
3. Press START/+30SEC button to
commence operation.
Example: Microwave oven cooking with 50%
power for 15 minutes:
1. Press the MICROWAVE|POWER button
six times: 50%
2. Dial clockwise until 15:00 shows.
3. Press START/+30 SEC button to
commence operation.
MICROWAVE POWER LEVELS
PRESS MICROWAVE
POWER
1 time 100% P100
2 times 90% P90
3 times 80% P80
4 times 70% P70
5 times 60% P60
6 times 50% P50
7 times 40% P40
8 times 30% P30
9 times 20% P20
10 times 10% P10
DISPLAY
INSTANT START
When the unit is in waiting state, press
START/+30 SEC instantly to start cooking at
30 seconds with 100% microwave power. Each
additional press will increase the cooking time
by 30 seconds only, until maximum cooking
time to 95 minutes. Power level will be default
at 100% for INSTANT START
12
OPERATING YOUR NEW BREVILLE PRODUCT
Example: Set 3 minutes instant start:
Press START/+30 SEC once to start cooking,
LED will display 0:30.
Press START/+30 SEC again for 5 times, and
the cooking time will be 3 minutes.
NOTE
Power level and time can be changed
during microwave oven operation only.
To change Power level during microwave
oven function, press the Microwave
button which will display the current set
power level and then continue pressing
until desired power level is selected.
Time can be adjusted by rotating the
time/weight dial during cooking process.
GRILL
1. Press GRILL button and "Grill" will be
displayed on LED screen.
NOTE
When using the grill rack, ensure it
is placed securely in the centre of the
turntable, avoiding any contact with the
surrounding cavity. Contact with the
cavity will result in sparking and could
damage the microwave.
2. Turn time dial to select desired time and
press start. Time range 5 seconds to 95
minutes.
CONVECTION
1. Press CONVECTION|TEMPERATURE
button and default temperature 140°C
will be shown on LED display.
2. Continue pressing
CONVECTION|TEMPERATURE button
until desired temperature is set.
3. Turn the dial to select desired cooking
time then press start. Temperature range
is from 140–230°C.
COMBINATION COOKING
Microwave, Grill and Convection functions can
be used independently or in combination.
To enable combination function, press the
MICROWAVE, GRILL or CONVECTION
buttons until desired combination function
is selected.
The MICROWAVE, GRILL and
CONVECTION buttons can be pressed
to select and deselect each function. The
corresponding icons will appear in the LED
display to indicate the functions selected.
NOTE
To deselect the first entered function
press the STOP/CLEAR button
Temperature and power level cannot be
adjusted in combination mode.
Example: To select Microwave and Convection,
input the following steps:
1. Press MICROWAVE button once to
display the microwave icon. To deselect,
press the STOP/CLEAR button.
13
OPERATING YOUR NEW BREVILLE PRODUCT
2. Press CONVECTION button
once to display the microwave and
convection icons. To deselect, press the
CONVECTION button once more.
• After defrosting the meat allow meat
to stand at room temperature for
5–10 minutes to completely thaw.
• The energy required for defrosting is much
less than for cooking, the microwave causes
the ice formed in the food to melt rather
than heat.
WEIGHT DEFROST
Example: Defrost beef of 500g:
1. Press DEFROST button once, LED will
display dEF1.
2. Dial clockwise until 500 is shown with
'g' symbol displayed on LED. Range of
defrosting weight is 100g–2000g.
3. Press START/+30 SEC to start defrosting.
3. Turn the dial clockwise until desired time
is selected.
4. Press START/+30 SEC button to
commence cooking.
TIPS ON DEFROSTING
• Before defrosting meat, remove the freezer
bag or wrap to prevent meat sitting in
‘drip’, which will otherwise boil as the
meat defrosts causing meat to go grey
and begin to stew. To remove frozen meat
from freezer wrappings, defrost for a few
minutes so the wrap is easy to remove.
• Remove meat from Styrofoam tray, as they
are not microwave safe.
• Place meat onto a rack with a drip tray
to catch juices. Alternatively, place onto
a microwave safe plate that is lined
with absorbent paper and elevate on an
upturned bowl or cup.
• Check the meat throughout the defrosting
time. As outer portions of meat thaw,
remove them from the microwave. If the
edges of meat feel warm, stop microwaving
and allow meat to stand for a few minutes
or until edges are cold again.
TIME DEFROST
Example: To defrost piece of beef in
10 minutes:
1. Press DEFROST button twice, LED will
display dEF2.
2. Dial clockwise until 10:00 is displayed.
3. Press START/+30 SEC to start defrosting.
AUTO COOK
To enable pre-programmed automatic functions,
press the “AUTO COOK” button until desired
auto cook function is selected.
Example: To select Auto Cook Meat function,
input the following steps:
1. Press “AUTO COOK” button 4 times to
display "4".
2. Turn the dial clockwise until desired weight
of the food item is selected (150g, 300g,
450g and 600g).
3. Press START/+30 SEC button to
commence operation.
14
OPERATING YOUR NEW BREVILLE PRODUCT
TYPE
1
AUTO REHEAT
2
VEGETABLE
3
FISH
4
MEAT
5
CHICKEN
6
POTATO
7
PIZZA
8
SOUP
9
OATS
WEIGHT (G)/
VOLUME (ML)/
QUANTITY
150g 150g 1'30"
250g 250g 2'10"
350g 350g 3'10"
450g 450g 4'10"
600g 600g 5'40"
150g 150g 2'40"
350g 350g 4'40"
500g 500g 6'20"
150g 150g 2'50"
250g 250g 4'00"
350g 350g 5'10"
450g 450g 6'20"
650g 650g 8'40"
150g 150g 2'50"
300g 300g 4'30"
450g 450g 6'10"
600g 600g 7'50"
1kg 1000g 30'00"
1.3kg 1300g 40'00"
1.5kg 1500g 50'00"
1 (230g) 1 5'00"
2 2 7'40"
3 3 9'40"
200g 200g 10'30"
300g 300g 12'30"
400g 400g 14'00"
200ml 200 2'10"
400ml 400 4'10"
600ml 600 6'10"
40g 40g 5'20"
120g 120g 9'20"
240g 240g 14'30"
DISPLAY COOKING TIME
15
OPERATING YOUR NEW BREVILLE PRODUCT
TIPS ON AUTO MENU SETTINGS
Auto Reheat
Will calculate the time required to reheat food
above 60˚C. Place food in/on microwave safe
containers and cover with microwave safe lid,
vented cling film or absorbent paper.
Vegetables
When cooking vegetables, always cook
them covered with a vented lid, cling wrap or
absorbent paper. Wash vegetables and shake
lightly, leaving some water clinging to it. Place
into microwave safe bowl and cover.
Fish
Place fish fillets into a microwave safe dish,
evenly spaced. Place dish onto a rack or
inverted bowl. Cover with a microwave safe lid
or vented cling film.
Meat
Place meat on a rack which sits inside a
shallow dish or on a rack which contains its
own run off rim around the edge. Cook fat-side
up first and turn over halfway through cooking.
If cooking mince or diced meat, place into a
microwave safe round casserole dish and stir
halfway through cooking.
Chicken
This setting is suitable for whole or chicken
pieces. To cook a whole chicken, place chicken
in a shallow microwave and grill safe dish
breast side up. To cook chicken pieces, arrange
chicken so that the thicker ends are facing
towards the outside of the dish. Turn chicken
pieces twice during cooking.
Potatoes
Line turntable with absorbent paper. Prick
each potato 3–4 times with a fork and arrange
around the outer edges of turn table.
Pizza
Line turn table with absorbent paper. Place
pizza slices directly on top. This will prevent
crust from becoming soggy.
Soup
Choose a microwave safe bowl large enough to
hold the corresponding amount of soup. Make
sure that the soup comes up no higher than
¾ of the bowl. This prevents spillage or
scolding from boiling liquid. Always stir soup
halfway through cooking time. Cover with a
microwave safe lid or vented microwave safe
cling film.
Oats
Choose a microwave safe bowl large enough
to hold the correct quantity. Make sure that the
porridge comes up no higher than ¾ of the
bowl. The ratio of oats to water is 1:5. Note that
porridge will swell and double in size. Do not
cover bowl and stir halfway through cooking.
SETTING THE DOOR SAFETY LOCK
The safety lock prevents unsupervised
operation by young children. While in lock
mode, the door can be opened, however the
microwave cannot be turned on.
1. To set, press and hold STOP/CLEAR pad
for 3 seconds. There will be a long ‘beep’
denoting unit is entering the childrenlock state and a ‘
2. To unlock, press and hold STOP/CLEAR
pad for 3 seconds, and there will be a long
‘beep’ denoting that the lock is released.
’ will be displayed.
WHEN COOKING IS FINISHED
At the end of any cooking cycle, the microwave
will beep 5 times.
DISPLAY SPECIFICATION
1. In waiting state, LED will display clock
and ‘:’ will flash.
2. In function setting state, LED will display
the related setting.
3. In the operation and suspending state, LED
will display the residual cooking time.
16
CARE & CLEANING
• Switch off the microwave oven at the power
outlet and remove the plug from the power
outlet before cleaning.
• Keep the inside of the oven clean. When
food splatters or spilled liquids adhere to
oven walls, wipe with a damp cloth. Mild
detergent may be used if the oven gets
very dirty. Avoid the use of spray and other
harsh cleaners as they may stain, streak or
dull the door surface.
• The outside surfaces should be cleaned
with a damp cloth. To prevent damage to
the operating parts inside the oven, water
should not be allowed to seep into the
ventilation openings.
• Wipe the door and window on both
sides of the door seals and adjacent parts
frequently with a damp cloth to remove
any spills or spatters. Do not use
abrasive cleaner.
• Do not allow the control panel to become
wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave oven door
open to prevent oven from accidentally
turning on.
• If steam accumulates inside or around the
outside of the oven door, wipe with a soft
dry cloth. This may occur when cooking
foods high in moisture or if the microwave
oven is operated under high humidity
conditions, this is normal.
• It is occasionally necessary to remove the
glass turntable tray for cleaning. Wash the
tray in warm sudsy water, rinse in clean
water and dry thoroughly.
• The roller ring and oven floor should be
cleaned regularly to ensure the turntable
tray rotates correctly and avoid excessive
noise. Simply wipe the bottom surface of
the oven with a soft damp cloth. The roller
ring may be washed in mild sudsy water,
rinse in clean water and dry thoroughly.
When removing the roller ring from cavity
floor for cleaning, be sure to replace in the
proper position.
• Remove odours from your oven by
combining a cup of water with the juice of
one lemon in a deep microwave-safe bowl,
microwave on High (100%) for 5 minutes.
Wipe the oven cavity thoroughly and dry
with a soft cloth.
• When it becomes necessary to replace the
oven light, please consult your Breville
Service Centre to have it replaced.
• Please do not dispose this appliance with
domestic rubbish; it should be taken to the
appropriate disposal centre provided by
the local council municipalities.
BEFORE YOU CALL FOR SERVICE
• Check to ensure that the oven is plugged
in securely. If it is not, remove the plug
from the power outlet, wait 10 seconds and
plug it in again securely.
• Check for a blown circuit fuse or a tripped
main circuit breaker. If these seem to be
operating properly, test the power outlet
with another appliance.
• Check to ensure that the control panel is
programmed correctly and the timer is set.
• Check to ensure that the door is securely
closed engaging the door safety lock
system. Otherwise, the microwave energy
will not flow into the oven.
NOTE
If none of the above rectify the situation,
then contact your Breville Service
Centre. Do NOT try to adjust or repair
the oven yourself.
17
NOTES
NOTES
18
NOTES
19
Loading...
