Breville BEM410, BEM410R Operating Instructions
the Scraper Mixer
Instruction Booklet
Suits all BEM410 models
CONGRATULATIONS
on the purchase of your new
Breville Scraper Mixer
CONTENTS
4 Breville recommends safety first
7 Know your Mixer
10 Assembly and operation
of your Mixer
14 Care, cleaning and storage
16 Measuring and weighing
18 Cooking information
20 Hints and tips
24 The vital ingredients
32 Recipes
3
BREVILLE RECOMMENDS SAFETY FIRST
At Breville we are very safety conscious. We design and manufacture consumer products with
the safety of you, our valued customer, foremost in mind. In addition we ask that you exercise
a degree of care when using any electrical appliance and adhere to the following precautions.
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS
BEFORE USE AND SAVE FOR
FUTURE REFERENCE
• Carefully read all instructions before
operating and save for future reference.
• Remove any packaging material and
promotional stickers before using the
mixer for the first time.
• Do not place the mixer near the edge
of a bench or table during operation.
Ensure the surface is level, clean and
free of water, flour, etc. Vibration during
operation may cause the appliance
to move.
• Do not place this appliance on or near
a hot gas or electric burner, or where it
could touch a heated oven.
• Use only the beater, dough hook or
whisk supplied with this mixer.
• Never operate the mixer whilst the mixer
head is in the raised position.
• Ensure the speed Control Dial is in the
‘0 – Stand By’ position and the mixer is
switched off and unplugged from the
power outlet before attaching the beater,
dough hook or whisk.
• Do not operate the appliance
continuously on heavy loads for more
than 3 minutes.
• Handle the mixer and attachments with
care. Never place your fingers inside the
mixing bowl or near the beater, dough
hook or whisk during operation.
• Keep hands, hair, clothing, as well as,
spatulas and other utensils away from
moving beater, dough hook or whisk
during operation.
• Should an object such as a spoon or
spatula fall into the bowl while mixing,
immediately ensure the speed Control
Dial is in the ‘0 – Stand By’ position, turn
the Mixer off, unplug at the power outlet
and remove the object.
• Do not place hands in the mixing
bowl unless the appliance is
disconnected from the power outlet.
Ensure the speed Control Dial is in
the ‘0 – Stand By’ position, the mixer
is switched off and unplugged from
the power outlet before removing the
beater, dough hook or whisk.
• Ensure the motor and beater, dough
hook or whisk has completely stopped
before disassembling.
• Always remove the beater, dough hook
or whisk from the mixer before cleaning.
• Ensure the Mixer motor head is locked
into the horizontal (closed) position
when not in use and before storing.
• Always ensure the speed control dial is
in the ‘0 – Stand By’ position, the power
is switched off at the power outlet and
the cord is unplugged from the power
outlet before attempting to move the
appliance, when the mixer is not in use
and before cleaning or storing.
• Do not use the mixer on metal surfaces,
for example a sink drain board.
• To protect against electric shock do not
immerse cord, plug or mixer in water or
any other liquid.
4
BREVILLE RECOMMENDS SAFETY FIRST
• Do not move the mixer whilst
in operation.
• Do not leave the mixer unattended when
in use.
• Keep the appliance clean. Follow
the cleaning instructions provided in
this book.
5
5
BREVILLE RECOMMENDS SAFETY FIRST
IMPORTANT SAFEGUARDS FOR
ALL ELECTRICAL APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do not
use the appliance if power cord, power
plug or appliance becomes damaged in
any way. Return the entire appliance to
the nearest authorised Breville Service
Centre for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.
IMPORTANT
Ensure the speed control dial is in
the ‘0 – stand by’ position, the mixer
is switched off at the power outlet
and unplugged from the power outlet
before attaching the beater, whisk or
dough hook.
Never operate the mixer whilst
the mixer head is in the raised
open position.
SAVE THESE
INSTRUCTIONS
6
KNOW
Breville Scraper Mixer
KNOW YOUR BREVILLE SCRAPER MIXER
D
A
E
B
C
F
A. Mixer motor head
Powerful 700 watt motor for powerful
and thorough mixing results
B. Large 4.7L stainless steel mixing bowl
For mixing your ingredients
C. Die cast metal mixer stand
The heavy duty die cast metal stand
keeps the mixer secure and stable
during operation
D. Speed control dial with 6
speed settings
E. Tilt back hinge button
The mixer motor head tilts back and
locks into position to allow easy removal
of the mixing bowl and attachments
8
F. Bowl locking recess
The bowl locking recess allows the bowl
to be securely locked into place for
safety and stability when the mixer is
in operation
G. Scraper beater
Scrapes the sides and bottom of the bowl
for exceptionally thorough mixing, of cake
and biscuit batter, pastry, frosting and
more
H. Wire whisk
Consistently mixes and aerates for egg
whites, cream and thin batters
I. Dough hook Effectively kneads heavy
dough for bread and pizza
KNOW YOUR BREVILLE SCRAPER MIXER
G
H
I
ABOUT YOUR SCRAPER BEATER
The Breville Scraper Beater folds ingredients
and continuously scrapes down the sides
and bottom of the bowl for exceptionally
thorough mixing. It virtually eliminates
the need to scrape the bowl by hand with a
spatula and cuts mixing time up to 60%.
Under-mixed batters produce poorly baked
results, resulting in collapsing, unevenness
of crumb, holes, low rising, streaking and
course textures. the Scraper Beater will help
to ensure a thoroughly mixed batter for your
favourite cakes, biscuits, frosting and more.
Many of the recipes provided in your
instruction booklet specify the use of the
Flat Beater, however, for exceptionally
thorough mixing and to save time, you can
use your Scraper Beater instead.
9
ASSEMBLY AND
OPERATION
of your Breville Scraper Mixer
ASSEMBLY AND OPERATION
ASSEMBLING THE MIXER
Before using your Breville mixer for the first
time, remove any packaging material and
promotional labels.
Ensure the speed control dial is in the ‘0 –
Stand By’ position, the mixer is switched
off at the power outlet and the power cord
is unplugged.
Remove the mixing bowl, scraper beater,
whisk and dough hook and wash in warm
soapy water with a soft cloth. Rinse and dry
thoroughly. The bowl and the attachments
may be washed in the dishwasher.
NOTE
When first using your Breville mixer,
you may notice an odour coming from
the motor. This is normal and will
dissipate with use.
ATTACHING THE BOWL
1. Place the mixer stand on a level, dry
surface such as a bench top. The mixer
motor head should be in the horizontal
(closed) position.
2. Raise the mixer motor head by
depressing the tilt back hinge button,
then lift the mixer motor head up
until it tilts back and locks into the
open position.
3. Insert the mixing bowl into the bowl
locking recess of the mixer stand and
turn clockwise until the bowl locks
securely into place.
NOTE
To remove or insert the mixing bowl,
the mixer motor head must be raised
and locked into the open position.
11
ASSEMBLY AND OPERATION
ATTACHING THE SCRAPER BEATER,
DOUGH HOOK OR WHISK
1. Ensure the mixer motor head is in the
raised open position. Align the groove
in the top of the scraper beater, dough
hook or whisk with the locking pin on
the spindle extending down from the
mixer motor head.
2. Press the scraper beater, dough hook or
whisk upwards and turn clockwise until
it locks securely onto the locking pin on
the spindle.
NOTE
When ingredients are in the mixing
bowl, the scraper beater may make a
slight noise as it scrapes the sides and
bottom of the bowl. This is normal and
should not cause concern.
Do not turn the mixer on with the
scraper beater in place if the mixing
bowl is empty. This will cause the
scraper beater to make a loud noise as
it scrapes the bowl.
OPERATING THE MIXER
Planetary Mixing Action
By replicating a similar mixing action used
by commercial mixers in bakeries and
patisseries, the Breville mixer head rotates
around the bowl whilst rotating the beater
in the opposite direction. This ensures
a superior and thorough mixing result
without the need for a rotating bowl.
1. Ensure the speed control dial is set to
the ‘0 – Stand By’ position, plug the cord
into a 230/240v power outlet and switch
the power ‘ON’ at the power outlet.
3. Lower the mixer motor head by
depressing the tilt back hinge button
and pushing the mixer motor head
down until it locks into the horizontal
(closed) position.
12
2. Add ingredients to the mixing bowl as
indicated in the recipe.
3. Always begin mixing by selecting a low
ASSEMBLY AND OPERATION
speed setting on the speed control dial.
This will prevent ingredients splattering.
Increase the speed as suited to the
mixing task. The speed setting can be
adjusted during operation by moving
the dial forward and back. Use the
mixing guide as a reference.
4. If necessary, stop the mixer during
operation and scrape any food mixture
down the sides of the mixing bowl with
a spatula.
5. When mixing is complete, turn the
speed control dial to the ‘0 – Stand By’
position, switch the appliance off at the
power outlet and unplug the cord.
6. Raise the mixer motor head by
depressing the tilt back button and lift
the mixer motor head up until it tilts
back and locks into the open position.
7. Remove the scraper beater/dough hook/
whisk by holding the mixer motor head
and pressing the attachment upwards
on the spindle. Turn the attachment
anticlockwise to release it from the pin
on the spindle.
Use a soft plastic spatula to remove
mixture from the scraper beater, dough
hook or whisk.
9. Lower the mixer motor head by
depressing the tilt back hinge button
and pushing the mixer motor head
down until it locks into the horizontal
(closed) position.
WARNING
Avoid contact with scraper beater/
dough hook/whisk during operation.
Keep hands, hair, clothing, spatulas
and other utensils away from scraper
beater/dough hook/whisk to prevent
personal injury or damage to the mixer.
NOTE
When lowering or lifting the mixer,
always support the motor head with
your other hand to prevent from
free-falling.
8. Remove the mixing bowl from the
indented bowl locking recess of the
mixer stand and turn anti-clockwise
until the bowl releases. Use a soft plastic
spatula to remove mixture from the
mixing bowl.
13
CARE, CLEANING
AND STORAGE
of your new Breville Scraper Mixer
CARE AND CLEANING
CLEANING AFTER USE
1. Always ensure the speed control dial is
in the ‘0 – Stand By’ position, the mixer
is switched off at the power outlet and
the power cord is unplugged.
2. Remove the scraper beater, dough hook
or whisk and mixing bowl from the
mixer. Follow instructions in ‘Assembly
and Operation' of your mixer. Wipe the
mixer motor head and mixer stand with
a soft, damp cloth then dry thoroughly.
3. Wipe any excess food particles from the
power cord.
4. Wash the bowl, scraper beater, dough
hook, and whisk in warm soapy water
with a soft cloth or they can be washed in
the dishwasher. Rinse and dry thoroughly.
A small bottle brush can be used to clean
inside the neck of the attachments if needed.
NOTE
Do not use abrasive scouring pads
or cleaners when cleaning the
mixing bowl, scraper beater, dough
hook or whisk as these may scratch
the surface. Also ensure that the
attachments are not soaked in water
for extended periods of time, for
example several hours or overnight,
as this may damage the finish.
STORAGE
Your mixer should be kept in a convenient
position on your kitchen bench top or in an
accessible cupboard.
Always ensure the speed control dial is
in the ‘0 – Stand By’ position, the mixer
is switched off at the power point and the
power cord is unplugged.
Store the mixing bowl in the bowl locking
recess in the mixer stand.
Place the attachments inside the mixing
bowl and lower the mixer motor head into
the horizontal (closed) position.
NOTE
The motor head cannot be taken off
the base for any purpose.
WARNING
Never immerse the mixer, power cord
or plug in water or any other liquid.
NOTE
Do not wash or immerse the mixer
motor head and mixer stand in water
or any other liquid. Clean with a soft,
damp cloth and dry thoroughly. Do
not allow water or any liquid to enter
the gear system as damage may result.
15
MEASURING AND
WEIGHING
with your new Breville Scraper Mixer
MEASURING AND WEIGHING
Care should be taken when weighing and
measuring ingredients to achieve accuracy
and consistency. Recipes in this instruction
book have been developed using Australian
metric weights and measurements.
AUSTRALIAN METRIC
MEASUREMENTS
1 teaspoon
1 tablespoon
1 cup
FOR NEW ZEALAND
CUSTOMERS — NEW ZEALAND
METRIC MEASUREMENTS
1 teaspoon
1 tablespoon
1 cup
ml
5
20
250
ml
5
15
250
The New Zealand tablespoon is 5ml less than
the Australian tablespoon, so care should
be taken when measuring ingredients to
compensate for the variance. For example,
1 Australian tablespoon = 1 New Zealand
tablespoon + 1 New Zealand teaspoon.
It is important to note that New Zealand
ingredients, especially flour and yeast, can
differ from Australian equivalents. Suitable
New Zealand Products have been listed in the
'Vital Ingredients' section of this booklet.
We suggest these New Zealand products be
substituted for the Australian products in
the Recipe Section.
For further New Zealand bread making
assistanceTelephone: 0800 273 845.
METRIC WEIGHING SCALES
For consistent results it is recommended
that a set of metric weighing scales be used
to weigh larger quantities as they provide
greater accuracy than measuring cups.
Tare (zero) the scales with the container in
position then spoon or pour ingredients in
until the desired weight is achieved.
NOTE
In general, water weighs the same in
grams as it measures in millilitres.
METRIC MEASURING CUPS
AND SPOONS
If using graduated metric measuring cups,
it is important to spoon the dry ingredients
loosely into the required cup. Do not tap the
cup on the bench or pack the ingredients
into the cup unless otherwise directed. Level
the top of the cup with a knife. When using
graduated metric measuring spoons, level
the top of the spoon with a straight edged
knife or spatula.
METRIC LIQUID MEASURING JUGS
If using a graduated, metric measuring jug,
place jug on a flat surface and check for
accuracy at eye level.
IMPORTANT
Do not use tableware cups or
spoons. Do not use tableware jugs or
measuring cups.
17
COOKING
INFORMATION
for your new Breville Scraper Mixer
COOKING INFORMATION
The following oven temperature settings
are included as a guide. These settings
may need to be adjusted to suit the
individual oven.
NOTE
If using fan forced ovens be sure to
turn the temperature down by 1520°C. Also check recipes at the back
of this book.
THERMOSTAT SETTINGS
DESCRIPTION OF OVEN
TEMPERATURES
Very slow 120 250 120 250 1
Slow 150 300 150 300 2
Moderately slow 170 325 160 325 3
Moderate 180 350 180 350 4
Moderately hot 200 400 190 375 5
Hot 220 425 200 400 6
Very hot 230 450 230 450 7
ELECTRIC
°C °F
GAS
°C °F
GAS
MARK
19
HINTS AND TIPS
for your new Breville Scraper Mixer
Loading...
