Braun Beard & Head Trimmer User Manual

Stapled booklet, 105 x 148 mm, 36 p (incl. 8 p cover), 2/2c = PMS7621U + black

beard& head

Beard & Head Trimmer

Type/Modèle / Modelo 5418

English 6

Français 16

Español 25

Thank you for purchasing a Braun product. We hope you are completely satisfied with your new Braun shaver. If you have any questions, please call: US residents 1-800-BRAUN-11 1-800-272-8611 Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun. Nous espérons que vous serez pleinement satisfait de votre nouveau rasoir Braun. Si vous avez des questions, veuillez appeler Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto Braun. Esperamos que quede completamente satisfecho con su nueva afeitadora Braun. Si tiene alguna duda, por favor llame al: En México 01(800) 508-5800

96503908/VIII-13 USA/CDN/MEX

English

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

Read all instructions before using this appliance.

When disconnected, this appliance may be cleaned under running tap water.

DANGER

To reduce the risk of electric shock:

1. Use only in dry condition.

2. Do not submerge in water.

3. Do not reach for an appliance that has fallen into water. Unplug immediately.

4. Do not use while bathing or in a shower.

5. Do not place, store or charge the appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.

6. Except when charging, always unplug this appliance from the electrical outlet immediately after using.

7. Unplug this appliance before cleaning.

8. This appliance is provided with a special cord set with integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it.

9. Do not use an extension cord with this appliance.

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by,

on, or near children or persons with disabilities.

2. Use this appliance only for its intended use as described in this

manual. Do not use attachments not recommended by the manufacturer.

3. Never operate this appliance if it has a damaged cord or plug,

if it is not working properly, if it has been dropped or damaged, or if the power supply has been dropped into water. Return the appliance to a service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening of the

appliance.

6. Do not use outdoors or operate where aerosol (spray) products

are being used or where oxygen is being administered.

7. Do not use this appliance with a damaged or broken cutter or

comb, as serious skin injuries may occur.

8. Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls off, then remove plug from outlet.

9. When plugging to an electrical outlet outside North America, use

a plug adapter to match the outlet’s pin configuration.

10. Caution: The battery used in this device may present a fire or

chemical burn hazard if mistreated. Do not disassemble, heat above 100 °C (212 °F), or incinerate.

11. Only use the special electric cord set provided with the

appliance.

12. Oil bottle

Keep out of reach of children. Do not swallow. Do not apply to

eyes. Dispose of properly when empty.

SAVE THESE INSTRUCTIONS

Our products are designed to meet the highest standards of quality, functionality and design. We hope you entirely enjoy your new Braun product.

This appliance is designed for household use only

Caution

For usage in other body areas, please make sure that the skin is stretched.

Description

1a Beard comb for trimming beard and short hair 1b Hair comb for cutting hair 1c Release buttons for comb 2 Wide trimmer (32 mm) 3 Pilot light 4 Length selector 5 On/off switch 6 Special cord set

Charging

Recommended ambient temperature for charging is 41 °F to 95 °F / 5 °C to 35 °C. The battery may not charge properly or at all under extreme low or high temperatures. Recommended ambient temperature for shaving is 60 °F to 95 °F / 15 °C to 35 °C. Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended periods of time.

• Using the special cord set (6), connect the appliance to an electrical outlet

with the motor switched off.

• When charging for the first time or when the appliance is not used for a

few months, leave the appliance to charge continuously for 4 hours.

• Once the appliance is completely charged, discharge it through normal

use. Then recharge to full capacity. Subsequent charges will take about 8 hours.

• A full charge provides up to 40 minutes of cordless operating time.

This may vary according to your beard growth.

• Maximum battery capacity will only be reached after several charging/

discharging cycles.

Pilot light (3) The pilot light shows the status of the batteries. It shines permanently green provided the appliance is connected to an electrical outlet. When the battery is fully charged, the pilot light turns off.

Comb attachments (1a, 1b)

The combs can be taken off by pressing the release buttons (1c) with your thumb and forefinger.

Beard trimming

• Place the beard comb (1a) on the appliance with the appliance turned off (a).

• Press length selector (4) and slide the beard comb up to your desired

beard length (possible length settings: 1, 3, 5, 7, 9, 11mm).

• It is advisable to begin with the highest setting and then reduce the setting

until you reach the desired beard length.

• Press the on/off switch. Hold the beard comb with the angled edge

against your beard and guide the trimmer against the direction of the hair growth (a).

• To avoid clogging the beard comb with hair, clean it from time to time with

the brush.

Contour Trimming / Styling

The wide trimmer (2) evenly cuts and trims large areas. It is ideal for shaping sideburns, moustaches and partial short beards. Take off the comb. While stretching the skin, guide the wide trimmer against the direction of hair growth (b).

Hair cutting

The hair should be clean, well combed, tangle-free and dry.

• Place the hair comb (1b) on the appliance with the appliance turned off (c).

• Press the length selector (4) and slide the distance comb up to your

desired hair length (possible length settings: 10, 12, 14, 16, 18, 20 mm). If you are not used to clipping hair, begin with a higher setting and then reduce the setting to avoid cutting more hair than desired. If you want to cut your hair shorter than 10mm, we advise to first cut it with the hair comb (1b) down to 10mm and then use the beard comb for the desired length.

• Use a slow and controlled movement. Do not force the appliance through

the hair faster than it can be cut (d).

• In between, shake or blow off the hair. If too much hair is caught in the

comb, remove and clean it.

Cleaning

The appliance is suitable for cleaning under running tap water. Warning: Detach the appliance from the power supply before cleaning it with water.

Regular cleaning ensures better trimming performance.

Cleaning with the brush

• Switch off the appliance. Open the wide trimmer by pressing with the

thumb against the trimmer from the front side. It opens by ca. 45° and can also be taken off (e).

• Using the brush clean the trimmers and the space behind the wide

trimmer (inside the housing).

Cleaning with water

• Switch off the appliance and rinse the head and trimmers under warm

running water (f). You can also rinse the opened wide trimmer (g). You may use liquid soap without abrasive substances. Rinse off all foam.

• Leave the appliance with opened wide trimmer to dry.

• If you regularly clean the trimmers under water, apply a few drops of light

machine oil onto the trimmers as indicated in the drawing (h).

Keeping your appliance in top shape

Preserving the batteries

In order to maintain the optimum capacity of the rechargeable batteries, the appliance has to be fully discharged (by trimming/cutting) every 6 months approximately. Then recharge the appliance to full capacity.

Environmental notice

This product contains rechargeable batteries. In the interest of protecting the environment, please do not dispose of the product in the household waste at the end of its useful life. Disposal can take place at a Braun Service Center or at appropriate collection points provided in your country.

Subject to change without notice.

For electric specifications, see printing on the special cord set.

How to obtain service in the USA 60 day money back satisfaction guarantee

Should your Braun product require service, please call 1-800-BRAUN 11 (272-8611) to be referred to the Authorized Braun Service Center closest to you.

To obtain service:

A. Carry the product in to the Authorized Braun Service Center of your choice or,

B. Ship the product to the Authorized Braun Service Center of your choice.

Pack the product well. Ship the product prepaid and insured (recommended). Include a copy of your proof of purchase to verify warranty coverage, if applicable.

To obtain original Braun replacement parts and accessories:

Contact a Braun Authorized Service Center. Please call 1-800-BRAUN 11 (272-8611) to be referred to the Authorized Braun Service Center closest to you.

To speak to a Braun Consumer Service Representative:

Please call 1-800-BRAUN 11 (272-8611).

How to obtain service in Canada 60 day money back satisfaction guarantee

Should your Braun product require service, please call 1-800-387-6657 to be referred to the Authorized Braun Service Center closest to you.

To obtain service:

A. Carry the product in to the Authorized Braun Service Center of your choice or,

B. Ship the product to the Authorized Braun Service Center of your choice.

Pack the product well. Ship the product prepaid and insured (recommended). Include a copy of your proof of purchase to verify warranty coverage, if applicable.

To obtain original Braun replacement parts & accessories:

Contact a Braun Authorized Service Center. Please call 1-800-387-6657 to be referred to the Authorized Braun Service Center closest to you.

To speak to a Braun Service Representative:

Please call 1-800-387-6657.
