Breaker Lockout Toolbox
• Everything you need to lockout most circuit breakers
• Includes Mini Cable Lockout (see page 43 for details)
• Components:
• 1 Mini Cable Lockout (50940)
• 2 120V Snap-On Breaker Lockout (65387)
• 2 120/277V Clamp-On Breaker Lockouts w/cleats (65396)
• 2 480/600V Clamp-On Breaker Lockouts w/cleats (65397)
• 1 Universal Multi-Pole Breaker Lockout (66321)
• 1 Oversized Breaker Lockout (65329)
• 1 Lockout Toolbox (65290)
• Padlock Options:
• Choose between two keyed-different safety padlocks (99552) or steel
padlocks (99500).
• Padlocks come with two heavy duty, re-usable lockout tags (65520)
and nylon cable ties
Lockout Kits
Catalog No. Description
99305 Breaker Lockout Toolbox (Kit)
99307 Kit w/2 Safety P adlocks & 2 Tags
99308 Kit w/2 Steel P adlocks & 2 Tags
Electrical Lockout Toolbox
• All the basics for locking out breakers, electrical plugs, wall switches and fuses
• Includes Mini Cable Lockout (see page 43 for details)
• Components:
• 1 Mini Cable Lockout (50940)
• 2 120V Snap-On Breaker Lockouts (65387)
• 2 120/277V Clamp-On Breaker Lockouts w/cleats (65396)
• 2 480/600V Clamp-On Breaker Lockouts w/cleats (65397)
• 2 Universal Multi-Pole Breaker Lockouts (66321)
• 1 Oversized Breaker Lockout (65329)
• 1 3-in-1 Plug Lockout (PLO23)
• 1 Wall Switch Lockout (65392)
• 1 Small Fuse Blockout (65390)
• 1 Large Fuse Blockout (65691)
• 1 Extra-Large Lockout Toolbox (LKP-TKLBOX)
• Padlock Options:
• Choose between two keyed-different safety padlocks (99552) or steel padlock (99500).
• Padlocks come with two heavy duty, re-usable lockout tags (65520) and
nylon cable ties
Breaker Lockout Toolbox
Electrical
Lockout Toolbox
Catalog No. Description
99310 Electrical Lock out Toolbox (Kit)
99312 Kit w/2 Safety P adlocks & 2 Tags
99313 Kit w/2 Steel P adlocks & 2 Tags
Lockout / Tagout
9
Lockout Stations
Small Lockout Station
●
Provides everything you need for locking out
all types of electrical control points
●
Includes Mini Cable Lockout (see page 407)
●
Station constructed of sturdy white
polystyrene with predrilled holes for easywall
mounting
●
Built-in lock rail holds 10-15 locks
depending on lock size
●
Pegboard-style holes for hooks drilled into
back (4 hooks supplied standard)
●
Dimensions: 18"H x 12"W x 4"D
Small Lockout Station with Brady
Safety Padlocks
Catalog No. Description
99706 Station w/ Components & 6 Brady Safety P adlocks, 12 Tags
99707 Station w/ Components & 6 Brady Steel P adlocks, 12 Tags
50997 Small Lock out Station (unfilled)
●
Components:
●
1 - Mini Cable Lockout (50940)
●
2 - 120V Snap-On Breaker Lockouts (65387)
●
2 - 120/277V Clamp-On Breaker Lockouts w/cleats (65396)
●
2 - 480/600V Clamp-On Breaker Lockouts w/cleats (65397)
●
2 - Universal Multi-Pole Breaker Lockouts (66321)
●
1 - Oversized Breaker Lockout (65329)
●
1 - Wall Switch Lockout (65392)
●
1 - 110V Plug Lockout (65674)
●
1 - 3-in-1 Plug Lockout (PLO23)
●
1 - Small fuse blockout (65690)
●
1 - Large fuse blockout (65691)
●
2 - Labeled Lockout Hasps (65960)
●
Padlock Options:
• Choose between 6 keyed-different safety padlocks (99552) or
6 steel padlocks (99500).
• Padlocks come with 12 heavy duty, re-usable lockout
tags (65520) and nylon cable ties
Lockout / Tagout
Combined Lockout / Lock Box Station
Catalog No. Description
99709 Station w/ Components & 6 Brady Safety P adlocks, 12 Tags
99710 Station w/ Components & 6 Brady Steel P adlocks, 12 Tags
LC252M Metal Lock out Cabinet (unfilled)
LG252M Metal W all Lock Box (Lock Box Only)
LC254M Extra Shelf
●
All metal, yellow powder-coated cabinet comes with one
adjustable shelf (extra shelves available)
●
Capable of being locked closed
●
Lockout safety tips printed on inside door
●
Lock box attaches to bottom of cabinet, accommodates 8-10
locks depending on lock size
●
Cabinet dimensions: 16"H x 14"W x 6"D
●
Lock box dimensions: 6"H x 15"W x 3"D
●
Components:
●
1 - 120V Snap-On Breaker Lockouts (65387)
●
1 - 120/277V Clamp-On Breaker Lockout w/cleats (65396)
●
1 - 480/600V Clamp-On Breaker Lockout w/cleats (65397)
●
1 - Universal Multi-Pole Breaker Lockout (66321)
●
1 - Oversized Breaker Lockout (65329)
●
1 - Wall Switch Lockout (65392)
●
1 - 110V Plug Lockout (65674)
●
1 - 3-in-1 Plug Lockout (PLO23)
●
1 - 1" – 21/2" Gate Valve Lockout (65560)
●
1 - 1" – 61/2" Adjustable Gate Valve Lockout (64057)
●
Padlock Options:
• Choose between 6 keyed-different safety padlocks
(99552) or 6 steel padlocks (99500).
• Padlocks come with 12 heavy duty, re-usable lockout
tags (65520) and nylon cable ties
18
Other Electrical Lockouts
!
Push Button Lockouts
NEW
Emergency Stop Cover
NEMA 30.5mm
• Guard against unauthorized operation or accidental activation.
• Two sizes to accommodate standard NEMA 30.5 mm and IEC 20.5mm buttons.
• Emergency Stop Safety Covers:
- Permanently install over push/pull or twist-release emergency stops.
- Durable metal bar locks button in the depressed (off) position.
• Push Button Safety Covers:
-Clear Lexan cover with hinged door completely covers button, preventing access.
Push Button Cover
IEC 20.5mm
Emergency Stop Cover
IEC 20.5mm
Wall Switch Lockouts
• Device may be used with most wall-mounted switches
• Easy to install using existing screws
• High visibility red color
• Locks switch in “on” or “off” position
• Lock not included
• Patent No. 5,260,528
Catalog Number Quantity
65392 1/Pkg.
65696 6/Pkg.
Fuse Lockout Devices
Push Button Cover
NEMA 30.5mm
Catalog Number Description
104600 Emergency Stop Safety Co vers - NEMA 30.5 mm
104601 Emergency Stop Safety Co vers - IEC 20.5 mm
104602 Push Button Safety Co ver - NEMA 30.5 mm
104603 Push Button Safety Co ver - IEC 20.5 mm
●
Clear plastic lockout uses existing wall
plate screws to mount
●
Patented non-hinge design
●
Made of strong, clear polycarbonate
●
Lock not included
●
Patent #5,543,593, 5,260,528
Catalog Number Description
WSLO Wall Switch Lock out
Lockout / Tagout
52
Fuse Blockout Devices
●
Block out 1⁄4" to 11⁄16" and blade type fuses
●
Use these highly visible devices in conjunction with Brady Lockout Tags (sold
separately on page 24) to comply with OSHA's Lockout/Tagout Standard
●
Patent No. 4,669,794
Catalog Number Description Quantity
65690
65691
1
⁄4",9⁄32",13⁄32" & 9⁄16" fuses 6/Pkg.
13
⁄16", 11⁄16" & blade type fuses 6/Pkg.
●
Unique locking mechanism prevents device from being accidentally
removed from fuse block
●
Available in two sizes for most commonly used fuses
●
Patent No. 5,207,590
Catalog Number Size Quantity
65750
65751
13
⁄32" 6/Pkg.
9
⁄16" 6/Pkg.
