Brady BEPM10 Users Guide

Brady RFID

External Programming

Module

Users Guide

Preliminary

Brady RFID EPM Users Guide Copyright 2000, Brady Worldwide Inc.

Table of Contents

Important Information......................... 3

Specifications...................................... 4

Product Description............................ 5

Basic Assembly.................................. 8

Installation.......................................... 9

EPM Positioning Instructions........... 10

Operation.......................................... 13

Maintenance..................................... 13

Brady RFID EPM Users Guide 2 Copyright 2000, Brady Worldwide Inc.

Important Information

Limited Hardware Warranty

Brady Worldwide, Inc. warrants solely to the purchaser that the hardware
components of the External Programming Module will be free from
defects in materials and workmanship under normal use for a period of 90
days from the date of shipment by Brady Worldwide. This limited
warranty does not extend to any components which have been subject to
misuse, neglect, accident, or improper installation or application. Brady
Worldwide's liability to the purchaser's remedy for the breach of this
warranty shall be at Brady Worldwide's option to either (i) repair or
replace defective components or (ii) upon return of the defective
components, refund the purchase price paid for the components. EXCEPT

FOR THE LIMITED HARDWARE WARRANTY SET FORTH ABOVE,
BRADY WORLDWIDE AND ITS LICENSORS PROVIDE THE
HARDWARE ON AN "AS IS" BASIS, AND WITHOUT WARRANTY OF
ANY KIND EITHER EXPRESS, IMPLIED, OR STATUTORY.

Limitation of Liability

In no event shall Brady Worldwide or its suppliers be liable for any
damages in excess of the price paid by the end user to Brady Worldwide
for the components, regardless of under what legal theory such damages
may be alleged arising out of the use or inability to use the component,
even if Brady Worldwide has been advised of the possibility of such
damages.

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject
to the following condition: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may

Brady RFID EPM Users Guide 3 Copyright 2000, Brady Worldwide Inc.

cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at their own
expense.

FCC ID

NUC-BEPM10

Specifications

Input Voltage . . . . . . . . . . . . . . . . . . +12V DC Nominal

Input Current

While Activated . . . . . . . . . . 150 mA

Standby . . . . . . . . . . . . . . . . . . 20 mA

Frequency of Operation . . . . . . . . . . ASK (Amplitude Shift Keying)

Temperature

Operating . . . . . . . . . . . . . . . +5o to 40o C (41o to 104o F)

20% to 85% non-condensing R.H.

Storage . . . . . . . . . . . . . . . . . -40o to 60o C (-40o to 140o F)

20% to 85% non-condensing R.H.

RS-232 Communications . . . . . . . . . 19.2kb, 8 data, 1 stop, No parity

Host Software OS . . . . . . . . . . . . . . Win95/98 , WinNT 

Brady RFID EPM Users Guide 4 Copyright 2000, Brady Worldwide Inc.
