Benchtop Printers

Benchtop Printer Comparison

Benchtop Printer Comparison Guide

Use the following comparison guide to quickly see which benchtop printer best ﬁts your application needs. Then turn to the following pages to ﬁnd out more about the printer, compatible materials and ribbons.

BradyPrinter S3000

Label Printer

See page 28

BradyPrinter S3100

Sign and Label Printer

See page 30

BradyPrinter i3300

Label Printer

See page 32

BBP®35 Multi-color

Label Printer

See page 34

Description Positioning

4 in. PC-connect printer for SFID. Does

not offer user standalone use and

accessibility or networking capability,

but does have smaller footprint than

BradyPrinter S3100.

4 in. standalone and PC-connect

printer for SFID with Wi-Fi connectivity.

Standalone use is ideal for multi-user

situations and lean 5S kaizen labeling

events. The ultimate in easy and

accessible.

4 in. PC-connect-only printer for SFID, die-cut wire ID and product ID labels.

Printer is networkable. Does not offer

user standalone use but does have

extra label types.

4 in. standalone and PC-connect

printer for SFID with multi-color printing

and fast print speed. Standalone use

is ideal for multi-user situations and lean 5S kaizen labeling events. The

ultimate in easy and accessible with

multiple colors.

Printer Overview Printer Overview

0.5 to 4 in. wide output 4 in./sec. print speed

PC-connect only Standalone and

Monocolor printing

(1 print color on a label)

20-second material changeovers

Set-up: no calibration,

no sensor adjust,

no label waste

(prints on ﬁrst label)

300+ parts, 14 materials (for SFID),

14 parts, 14 materials (for product ID)

Software:

Brady Workstation

5-year warranty 5-year warranty 5-year warranty 5-year warranty 5-year warranty 5-year warranty 1-year warranty 1-year warranty

0.5 to 4 in. wide output 3 in./sec. print speed

PC-connect printing

Monocolor printing

(1 print color on a label)

20-second material changeovers

Set-up: no calibration, no sensor adjust,

no label waste

Easy user interface

– just walk up and print

300+ parts, 14 materials (for SFID)

14 parts, 14 materials (for product ID)

Software:

Brady Workstation

0.25 to 4.25 in. wide output up to 4 in./sec. print speed

PC-connect only Standalone and

Monocolor printing

(1 print color on a label)

20-second material changeovers

Set-up: no calibration,

no sensor adjust,

no label waste

(prints on ﬁrst label)

300+ parts, 14 materials (for SFID)

485 parts, 45 materials

(for wire ID and product ID)

Software:

Brady Workstation

20-second material changeovers

Set-up: no calibration, no sensor adjust,

– just walk up and print

300+ parts, 14 materials (for SFID)

14 parts, 14 materials (for product ID)

0.5 – 4 in. wide output 5 in./sec. print speed

PC-connect printing

Monocolor and

multi-color printing

no label waste

Easy user interface

Software:

Brady Workstation

Compatible Supplies Compatible Supplies

B30-series materials (all) B30-series materials (all) B33- and B30-series materials B30-series materials (all) B30-series materials (all) B85-series and PowerMark materials J20-series materials (all) J50-series materials (all)

B30-series ribbons

(excluding multi-color panel ribbons)

B30-series ribbons

(excluding multi-color panel ribbons)

B30-series ribbons

(excluding multi-color panel ribbons)

B30-series ribbons (all) B30-series ribbons (all) B85-series and PowerMark ribbons J20-CMY ink cartridge J50-series ink cartridges (all)

Applications Applications

Arc ﬂash labels

Cold-temperature labels

Equipment marking

Facility ID

GHS and chemical labels

Glow-in-the-dark labels

Lean / 5S

Magnetic labels

Panel labels

Pipe and valve marking

Push button labels

Reﬂective labels

Arc ﬂash labels

Equipment labels

GHS labels

Pipe markers

Safety signs

Warning labels

Lean / 5S labels

Panel and enclosure ID

Tags

Barcode labels

Arc ﬂash labels

Equipment labels

GHS labels

Pipe markers

Safety signs

Warning labels

Lean / 5S labels

Panel and enclosure ID

Inside panel and automation ID

Wire and cable ID

Tags

Barcode labels

Miscellaneous die-cut labels

Circuit board labels

Product labels (OEM)

Laboratory specimen labels

Arc ﬂash labels (w/ red variables)

Equipment labels

GHS labels

Pipe markers

Safety signs (multi-color)

Warning labels (multi-color)

Lean / 5S labels

Panel and enclosure ID

Tags

Multi-color labels

Benchtop Printer Comparison

BBP®37 Multi-color

and Cut Label Printer

See page 34

4 in. standalone and PC-connect printer for

SFID with multi-color printing, shape-cutting capabilities (BBP37 only) and fast print speed. Standalone use is ideal for multi-user situations

and lean 5S kaizen labeling events. The ultimate in easy and accessible with multiple colors, and

letter- and shape-cutting options.

0.5 to 4 in. wide output 5 in./sec. print speed

Standalone and

PC-connect printing

Monocolor and multi-color printing

X-Y plotter cutter to cut out text and shapes

20-second material changeovers

Set-up: no calibration,

no sensor adjust, no label waste

Easy user interface

– just walk up and print

300+ parts, 14 materials (for SFID)

14 parts, 14 materials

(for product ID cut-outs)

Software:

Brady Workstation

BBP®85

Label Printer

See page 76

10 in. standalone and PC-connect

printer for SFID with multi-color printing. Particularly popular for any large labeling needs. Ideal for large

signs, large GHS labels and large

equipment placards. The ultimate in

easy and accessible with multiple

colors for larger output.

4 to 10 in. wide output

1 in./sec. print speed

Standalone and

PC-connect printing

Monocolor and

multi-color printing

40-second material changeovers

Set-up: no calibration, no sensor adjust, no

label waste

Easy user interface

– just walk up and print

125 parts, 5 materials

(for SFID)

Software:

Brady Workstation

BradyJet J2000

Color Label Printer

See page 84

Full-color, high-resolution ink jet

printer for creating photo-quality

labels in a single pass, while

reducing material waste and needed

inventory of labeling supplies.

Signiﬁcantly smaller footprint than

BradyJet J5000.

0.75 to 4 in. wide output

Up to 2.5 in./sec. print speed

PC-connect only PC-connect only

Full-color printing Full-color printing

20-second material changeovers and 10-second ink cartridge changeovers

Set-up: self-fed materials

15 parts, 3 materials (for SFID) 15 parts, 1 material (for lab ID)

Software:

Brady Workstation

high-resolution, high-speed color

label printing. Ideal for creating

full-color labels with images, logos,

illustrations, barcodes and more.

The ultimate in high-resolution

20-second material changeovers and 10-second ink cartridge changeovers

BradyJet J5000

Color Label Printer

See page 86

8 in. PC-connect printer with

printing in all colors.

2 to 8 in. wide output

Up to 6 in./sec. print speed

Set-up: self-fed materials,

no sensor adjustment

18 parts,

2 materials

Software:

Brady Workstation

Benchtop Printers

Arc ﬂash labels (w/ red variables)

Equipment labels

GHS labels

Pipe markers (single or multiple-up)

Safety signs (multi-color)

Warning labels (multi-color)

Lean / 5S labels

Panel and enclosure ID

Tags

Multi-color labels

Cut-out text and shapes

Circular or custom shaped labels

Miscellaneous die-cut labels (cut out)

Multiple-up cut-out labels

Gauge labels

Gradient ruler labels

Product labels (cut out small batch)

Larger output

Equipment labels (larger)

GHS labels (larger)

Safety signs (larger)

Multi-color labels (larger)

GHS labels

Pipe markers

Warehouse marking

Visual workplace labeling

Lean / 5S labels

Lockout Tags

General ID

Industrial ID

Laboratory ID

Arc ﬂash labels (w/ red variables)

Equipment labels

GHS labels

Pipe markers

Safety signs and warning labels (multi-

color)

Lean / 5S labels

Multi-color labels

Lock labels (w/ photos)

Asset management

Department signage

Finished goods

BradyPrinter S3000 Sign and Label Printer

Benchtop Printers S3000

High-Performance, Entry-Level Industrial Printing

Turn busy work into smarter work. Get state-of-the-art printing capabilities in a compact package with the BradyPrinter S3000 Sign and Label Printer.

• Get lightning-fast setup times with print smart technology that auto-calibrates print settings when you load materials so you can print on the ﬁrst label

• Easily make any adjustments you need to on the large color touchscreen

• Changing materials is made easy with drop-in fool-proof loading so changeovers take as few as 20 seconds

• Versatility with more than 330 parts and 26 materials options, including ToughStripe

• Move through your print jobs fast with print queue capabilities that automatically prints the next batch after the ﬁrst one is ﬁnished

• Create labels with ease when you add Brady Workstation Label Creation Software apps and suites

Floor Marking Tape

Printer at-a-glance

• Small footprint

• PC-connect printer

• Single color printing

• Safety and facility ID labels only

• 330 parts, 26 materials

Printing supplies

B30-series label rolls ....................... page 36

B30-series print ribbons

.................. page 74

High-performance safety and facilty labels

Supply status is conveniently

displayed on screen

Catalog # Description

S3000 BradyPrinter S3000 Sign and Label Printer B31-WIPER Extra media wipers (5 per pack) PCK-6 Cleaning swabs that are pre-soaked in IPA (50 per pack)

* Printer includes power cord, Quick Start Guide, USB cable,

cleaning kit and cutter cleaning tool.

Lean / 5S labelingSafety tagsGHS labelingPipe marking

Safety signs Equipment and panel

labeling

BradyPrinter S3000 Sign and Label Printer

Printer speciﬁcations

Overview 4 in. PC-connect printer

Applications Arc ﬂash labels, cold-

Label materials Extremely aggressive

Label formats Continuous tapes,

Print technology Thermal transfer

Print resolution 300 dpi

Print speed 4 in./sec.

Media widths 0.5 to 4 in.

Min. label dimension 0.5 in.

Color printing capabilities

Auto cut-off Yes

X-Y plotter cutting (cut-out shapes / text)

PC-connect or standalone operation

Connectivity options USB

Compatible software Brady Workstation Apps

Compatible materials B30 series (all)

Compatible ribbons B30 series (excluding

Calibration required No (no waste)

Label creation and set-up

Ribbon and label roll installation

Warranty 5 years

US. Patent No. #6364552, #5823689, #6570602, #8539868

for SFID. Does not offer user standalone use and accessibility or networking capability, but does have smaller footprint than BradyPrinter S3100.

temperature labels, equipment marking, facility ID, GHS and chemical labels, glow in the dark labels, lean / 5S, magnetic labels, panel labels, pipe and valve marking, push button labels, reﬂective labels

8-10 year outdoor vinyl with high tack and chemical resistance, plus wash-down material, 10-hr glow in the dark, reﬂective, magnetic, tags, engraved plate substitute and more.

pre-printed and blank die-cut labels

Monocolor printing (some pre-printed multi-color supplies also available)

PC-connect only

multi-color panel ribbons)

Automatic (printer or PC software reads data on chip and automatically sets up label size, color, fonts, etc.)

Labels: Supplied in cartridge, drops into place, 15-second changeover Ribbon: Supplied in cartridge, snaps into place, 5-second changeover

Brady Workstation Safety and Facility ID Suite

Brady Workstation has revolutionized how you design and print labels from your PC. When paired with the high-performance printing capabilities of a Brady printer, you get intuitive label set up for simple, efﬁcient and ﬂexible label creation.

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Brady360® 5-year Warranty

We stand behind our products and have strengthened our commitment to you with a 5-year printer warranty standard and free of charge on our benchtop printer models.* With our team of certiﬁed tech support and repair technicians, you can rest easy knowing you have the support you need, every step of the way.

Benchtop PrintersS3000

*Excludes repairs due to negligence. Excludes Wraptor™, BradyJet and portable models.

BradyPrinter S3100 Sign and Label Printer

Benchtop Printers S3100

Walk-up-and-print for ultimate ease of use

Just walk up and print. Literally. The best choice for facility, safety and Lean / 5S labeling

• Intuitive, simple to learn, very approachable. Ideal for multi-user situations, events and centrally located print stations — simple training

• 20-second supply changeover with no waste, calibration or trial and error setup

• Standalone use or PC-Connect use all in one printer

• Automatic label setup with no calibration — the printer “reads” information from your cartridges and automatically sets up the label correctly in the printer or your Brady software

Printer at-a-glance

• Small footprint

• PC-connect or standalone printing

• Touchscreen label creation

• Single color printing

• Safety and facility ID labels only

• 385 parts, 14 materials

Printing supplies

B30-series label rolls ....................... page 36

B30-series print ribbons

.................. page 74

Easy to load drop-in supplies

Catalog # Description

S3100W-BWSSFID

S3100-W BradyPrinter S3100 Printer* 120994 Padded rolling case with handle and supplies pockets B31-WIPER Extra media wipers (5 per pack) B31-CCT Cutting Tool PCK-6 Cleaning swabs that are pre-soaked in IPA (50 per pack)

Printer and Supplies Starter Kits. Kit contents on page 72.

S3100W-ARC-KIT BradyPrinter S3100 Printer w/ Arc Flash Supply Kit* S3100W-GHS-KIT BradyPrinter S3100 Printer w/ GHS Supply Kit* S3100W-SAFE-KIT BradyPrinter S3100 Printer w/ Safety Supply Kit* S3100W-LEAN-KIT BradyPrinter S3100 Printer w/ 5S Visual Workplace Supply Kit* S3100W-PIPE-KIT BradyPrinter S3100 Printer w/ Pipe ID Supply Kit* S3100W-GEN-KIT BradyPrinter S3100 Printer w/ General Industrial Supply Kit*

* Printer ships with power cord, USB cable, network card, drivers CD, stylus,

cleaning kit, cutter cleaning tool, Quick Start Guide and documentation holder.

BradyPrinter S3100 Printer with Brady Workstation Safety and Facility ID Software Suite*

Just walk up and print. So simple, your whole team can use it

Lean / 5S labelingSafety tagsGHS labelingPipe marking

Safety signs Equipment and

panel labeling

BradyPrinter S3100 Sign and Label Printer

Printer speciﬁcations

Overview 4 in. standalone and

Applications Arc ﬂash labels, equipment

Label materials Extremely aggressive

Label formats Continuous tapes,

Print technology Thermal transfer

Print resolution 300 dpi

Print speed 3 in./sec.

Media widths 0.5 to 4 in.

Min. label dimension 0.5 in.

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting (cutout shapes / text)

PC-connect or standalone operation

Connectivity options Standard: USB, Ethernet

Compatible software Brady Workstation Apps

Compatible materials B30 series (all)

Compatible ribbons B30 series (excluding

Calibration required No (no waste)

Label creation and set-up

Ribbon and label roll installation

Warranty 5 years

U.S. Patent No. 8,542,155; 8,648,891; 5,823,689; 6,570,602. Additional patents pending.

PC-connect printer for SFID with Wi-Fi connectivity. Standalone use is ideal for multi-user situations and lean 5S kaizen labeling events. The ultimate in easy and accessible.

labels GHS labels, pipe markers, safety signs, warning labels, lean / 5S labels, panel and enclosure ID, tags barcode labels

8-10 year outdoor vinyl with high tack and chemical resistance, plus washdown material, 10-hr glow in the dark, reﬂective, magnetic, tags, engraved plate substitute and more.

pre-printed and blank die-cut labels

Monocolor printing (some pre-printed multi-color supplies also available)

Standalone and PC-connect printing

Optional: Wi-Fi, Wi-Fi Direct

multi-color panel ribbons)

Automatic (printer or PC software reads data on chip and automatically sets up label size, color, fonts, etc.)

Labels: Supplied in cartridge, drops into place, 15-second changeover Ribbon: Supplied in cartridge, snaps into place, 5-second changeover

Brady Workstation

Benchtop PrintersS3100

Safety and Facility ID Suite

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Brady360® 5-year Warranty

*Excludes repairs due to negligence. Excludes Wraptor™, BradyJet and portable models.

BradyPrinter i3300 Industrial Label Printer

Benchtop Printers i3300

No waste. More labels. Less effort.

Picture your ideal label printing scenario – the labels and ribbons snap into place, there’s no calibration process, you don’t have to throw away blank labels before you actually print one. Ideal is now real with the BradyPrinter i3300 Industrial Label Printer. This mid-volume industrial label printer makes your identiﬁcation projects easy, fast and affordable. Enjoy a variety of time- and money-saving advantages, including:

• No waste printing: With print smart technology, you get auto setup and calibration without throwing out blank labels

• Fast material changeovers: Foolproof drop-in label rolls and ribbons snap into place for 20-second material changeovers

• Full-facility identication: Complete all of your identiﬁcation tasks, from wires, panels and products to safety and facility labels, with one convenient and efﬁcient tool

Printer at-a-glance

• Small footprint

• PC-connect printing

• Single color printing

• Safety, facility, wire and product ID labels

• 300+ parts, 14 materials (for SFID) 350+ parts, 28 materials (Product and Wire ID)

Printing supplies

B30- and B33-series label rolls ....... page 36

B30-series print ribbons

.................. page 74

Product and wire ID in addition to safety and facility ID

Print on the rst label or sleeve — even on the smallest labels

Catalog # Description

149552 BradyPrinter i3300 w/ Brady Workstation Basic Suite 150643 BradyPrinter i3300 w/ Brady Workstation Safety and Facility ID Suite 150645 BradyPrinter i3300 w/ Brady Workstation GHS App 150640 BradyPrinter i3300 w/ Brady Workstation Product and Wire ID Suite 150642 BradyPrinter i3300 w/ Brady Workstation Laboratory ID Suite 150639 BradyPrinter i3300 w/ Brady Workstation Scan and Print and Scanner 120994 Padded rolling case with handle and supplies pockets B31-WIPER Extra media wipers (5 per pack) B31-CCT Cutting Tool PCK-6 Cleaning swabs that are pre-soaked in IPA (50 per pack)

* Printer ships with cleaning kit, cutter cleaning tool, power cord, product CD,

Quick Start Guide and USB cable.

Product ID labelsCircuit board labelingArc ﬂash labelingIndustrial labeling

Wire and cable labels Raised panel labels

and more

BradyPrinter i3300 Industrial Label Printer

Printer speciﬁcations

Overview 4 in. PC-connect-only printer

Applications Arc ﬂash labels, equipment

Label materials Extremely aggressive

Label formats Continuous material,

Print technology Thermal transfer

Print resolution 300 dpi

Print speed up to 4 in./sec.

Media widths 0.5 to 4.25 in.

Min. label dimension 0.25 in.**

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting (cutout shapes / text)

PC-connect or standalone operation

Connectivity options Standard: USB, Ethernet

Compatible software Brady Workstation Apps

Compatible materials B33 series (all)

Compatible ribbons B30 series (excluding

Calibration required No (no waste)

Label creation and set-up

Ribbon and label roll installation

Warranty 5 years

** Performance at minimum label dimension is dependent on label text and size of print run; Users should test suitability for their application.

U.S. Patent No. 5,823,689; 6,570,602. Additional patents pending.

for SFID, die-cut wire ID and product ID labels. Printer is networkable. Does not offer user standalone use but does have extra label types.

labels, GHS labels, pipe markers, safety signs, warning labels, lean / 5S labels, panel and enclosure ID, inside panel and automation ID, wire and cable ID, tags, barcode labels, miscellaneous die-cut labels, circuit board labels, product labels (OEM, laboratory specimen labels

8-10 year outdoor vinyl with high tack and chemical resistance, plus, wash down material, reﬂective, 10-hour glow-in-the-dark, engraved plate substitute, 33 other materials

pre-printed and blank die-cut labels, wire labels and sleeves

Monocolor printing (some pre-printed multi-color supplies also available)

PC-connect only

Optional: Wi-Fi, Wi-Fi Direct

B30 series (all)

multi-color panel ribbons)

Automatic (printer or PC software reads data on chip and automatically sets up label size, color, fonts, etc.)

Labels: Supplied in cartridge, drops into place, 15-second changeover Ribbon: Supplied in cartridge, snaps into place, 5-second changeover

Brady Workstation Product and Wire ID Suite

This suite features:

• A collection of applications for creating product labels, wire and cable markers, panel labels and more

• The ability to serialize and import your data onto the labels

• Specialty label design apps for asset tags, terminal block and patch panel labels

• Real-time information about the label material installed, enabling easy label set up

• Apps feature built-in regulations, standards, pictograms, common phrases,

data importation guidance, help functions and more

Brady360® 5-year Warranty

*Excludes repairs due to negligence. Excludes Wraptor™, BradyJet and portable models.

Benchtop Printersi3300

BBP®35 and BBP®37 Label Printers

Benchtop Printers BBP35 / BBP37

Color your way to an improved workplace

The BBP35 and BBP37 label printers give you the power to make signs and labels in the colors and shapes you need to make an impact – right when you need them.

• Multiple print colors – Color is more memorable, more effective and is the differentiator you need to effectively improve workplace safety and productivity

• Shape cutting with the built-in XY plotter cutter (BBP37 only) Cut out shapes and text, or cut around your message to create labels that look and ﬁt how you want them to

• Label making made easy – Incredibly easy and intuitive interface makes it ideal for multiple users, centralized locations and lean / 5S events

• Automatic label setup – Printer reads critical information from the supplies and then automatically sets up the label attributes in the printer so you can start printing immediately

• Time saving – 20-second changeovers with drop in ribbon and label supplies

Printer at-a-glance

• Single and multi-color printing

• Cuts out shapes and text (BBP37 only)

• PC-connect or standalone printing

• Touchscreen label creation

• 300+ parts, 14 materials (for SFID) 14 parts, 14 materials (for product ID)

Printing supplies

B30-series label rolls ....................... page 36

B30-series print ribbons

.................. page 74

Multi-color printing

in a single print pass

Catalog # Description

BBP35 BBP35 Multicolor Label Printer* BBP37 BBP37 Multicolor and Cut Label Printer* 120994 Rolling case with handle, 2 pockets for supplies BBP35-37-WIPER BBP35/37 Media Wiper (1 each) B31-CCT Cutting Tool PCK-6 Cleaning swabs that are pre-soaked in IPA (50 per pack) B37-BLADE Replacement XY cutting blade for BBP37 (1 each) 76737 Transfer tape for cut-out objects (300 ft. roll)

* Printer ships with cleaning kit, cutter cleaning tool, power cord,

Quick Start Guide and USB cable.

Cut-out shapes and text

with the BBP37 printer

Cut-out text must be 0.75 in. or larger.)

Unprecedented capabilities set the standard in safety and facility ID

(Requires 4 in. wide material.

Safety and industrial

signage

GHS hazcomm

labels

Safety and compliance

labels

Product ID

labels

Pipe markers Cut-out shapes and text

with BBP37 printer

BBP®35 and BBP®37 Label Printers

Printer speciﬁcations

Overview 4 in. standalone and PC-

Applications Arc ﬂash labels (w/ red

Label materials Extremely aggressive

Label formats Continuous tapes,

Print technology Thermal transfer

Print resolution 300 dpi

Print speed 5 in./sec.

Media widths 0.5 to 4 in.

Min. label dimension 0.5 in.

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting (cutout shapes / text)

PC-connect or standalone operation

Connectivity options Standalone use,

Compatible software Brady Workstation Apps

Compatible materials B30 series (all)

Compatible ribbons B30 series (all)

Calibration required No (no waste)

Label creation and set-up

Ribbon and label roll installation

Warranty 5 years

U.S. Patent No. 6364552 B1; 6788324; 6768502 B2; BBP37 printer: 6664995 B2; Ribbon cartridges: 6860658 B2; D480749

connect printer for SFID with multi-color printing and fast print speed. Standalone use is ideal for multi-user situations and lean 5S kaizen labeling events. The ultimate in easy and accessible with multiple colors.

variables), equipment labels, GHS labels, pipe markers, safety signs (multi-color), warning labels (multi-color), lean / 5S labels, panel and enclosure ID, tags, multi-color labels

8-10 year outdoor vinyl with high tack and chemical resistance, plus Toughstripe wash-down material, 10-hr glow in the dark, reﬂective, magnetic, tags, engraved plate substitute and 20 other materials.

pre-printed and blank die-cut labels

Monocolor and multi-color printing

Yes, BBP37 model only

Standalone and PC-connect printing

Ethernet, USB

Automatic (printer or PC software reads data on chip and automatically sets up label size, color, fonts, etc.)

Labels: Supplied in cartridge, drops into place, 15-second changeover Ribbon: Supplied in cartridge, snaps into place, 5-second changeover

ﬂoor tape,

Benchtop PrintersBBP35 / BBP37

Brady Workstation Safety and Facility ID Suite

Brady Workstation has revolutionized how you design and print labels from your PC. When paired with the high-performance printing capabilities of a Brady printer, get intuitive label set up for simple, efﬁcient and ﬂexible label creation.

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Brady360® 5-year Warranty

*Excludes repairs due to negligence. Excludes Wraptor™, BradyJet and portable models.

B30- and B33-Series Materials

B30- and B33-Series Material Supplies

Speciﬁcally designed for use with the BradyPrinter S3000, S3100, i3300,

BBP

30, BBP®31, BBP®33,

BBP

35 and BBP®37 printers.*

B30 / B33 SeriesBenchtop Printers

No-hassle, 20-second material changeovers

Forget fumbling around with supplies that roll away or require complicated threading. These easy-to-load materials and ribbons snap into place for easy 20-second material changeovers. Switch materials frequently throughout the day? You’ll save time to work on your more important tasks.

Efficient label setup with print smart technology

Your printing team – printer, labels, ribbons and software – all work together from the moment you close the printer cover. It’s all in the smart chip embedded in our materials.

When the material is installed, the chip sends vital information such as size, type, color and remaining quantity right to the printer. You’ll be ready to print in no time.

Smart chip auto populates:

• Label size and color

• Pre-printed headers

• Remaining material quantity

*Supplies listed on the following pages are compatible

No wasting labels with auto calibration

The auto calibration that takes place as soon as material is installed, means that you’ll be printing on the very ﬁrst label, saving you valuable time and labels.

unless otherwise noted in the part number tables.

B30- and B33-Series Materials

The right label from the right company

Nothing leaves Brady's doors without meeting the highest quality standards. Backed by more than 100 years of identiﬁcation experience and rigorous R&D testing, Brady manufactures materials you can trust.

That strong background of material development allows us to create materials for all of your applications throughout your facility. Add the printing versatility of a Brady printer, and you get a convenient tool for facility-wide identiﬁcation that offers more than 825 parts and 70 material options, and additional custom label options for a variety of applications, including:

Safety, maintenance and facility applications

Arc Flash Labels Safety Labels

Inventory ID

GHS Labels

Tags

Raised Panel Labels

Specialty applications with the BradyPrinter i3300

Product ID

Wire and cable markers

Electronics and PC boards

Pipe Markers

Floor Marking

Laboratory labels

Cut-out shapes and text with the BBP

Cut-out text Cut-out shapes

37 Printer

Look for the scissors icon on the following pages for 4 inch wide materials that are compatible with the BBP37 XY-plotter cutter.

(Cut-out text must be 0.75 in. or larger.)

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Rigid sign and tag techniques:

4 inch continuous tape rigid panels

Blank rigid signs

Blank Rigid Signs

• Create rigid signs and labels with any adhesive-backed output

• Ideal for surfaces where applying an adhesive label is difﬁcult

• Panels can be mounted using foam tape, magnetic strips or by their included pre-drilled corner holes

Color

White 2.50 6.25 146083 146076 White 2.50 10.25 146113 146077 White 4.25 6.25 13629 13620 White 4.25 10.25 106461 146074 White 4.25 14.25 146082 146075 Yellow 2.50 6.26 146116 146080 Yellow 2.50 10.25 146117 146081 Yellow 4.25 6.25 13630 13620 Yellow 4.25 10.25 146114 146078 Yellow 4.25 14.25 146115 146079

Orange 4.25 6.25 13631 13622

Panel

Height

Inch

Panel

Length

Inch

Aluminum 10/Pack

Plasic 10/Pack

B30 / B33 SeriesBenchtop Printers

Blank Rigid Valve Tags

Print labels on your Brady printer and apply them to industrial-grade plastic tags

• Die-cut labels are sized to ﬁt the recessed area on the tag

• Outdoor tag withstands temperatures -40° F to 180° F

Printing supplies

Fits Printers

All*

Catalog # Color Label Size

B30-242-595-BLNKWT

B30-219-595-BLNKWT

B30-R10000

White 1.125 in. x 2.75 in. for small tag 300

White 2.25 in. x 3.75 in. for large tag 250

Black Print Ribbon -

BradyPrinter S3000, S3100, i3300, BBP

White die-cut label Blank tag

Blank rigid valve tags

Catalog # Color

87696 White 2.1 x 3.6 1.5 x 3 87697 White 3.1 x 4.6 2.5 x 4 41922 Yellow 2.1 x 3.6 1.5 x 3 41923 Yellow 3.1 x 4.6 2.5 x 4 41924 Red 2.1 x 3.6 1.5 x 3 41925 Red 3.1 x 4.6 2.5 x 4 41926 Blue 2.1 x 3.6 1.5 x 3 41927 Blue 3.1 x 4.6 2.5 x 4 41928 Green 2.1 x 3.6 1.5 x 3 41929 Green 3.1 x 4.6 2.5 x 4

Labels per Roll

*All supplies listed are compatible with the following printers unless otherwise noted:

87694 Orange 2.1 x 3.6 1.5 x 3 87695 Orange 3.1 x 4.6 2.5 x 4 87712 Tan 2.1 x 3.6 1.5 x 3 87713 Tan 3.1 x 4.6 2.5 x 4 87710 Brown 2.1 x 3.6 1.5 x 3 87711 Brown 3.1 x 4.6 2.5 x 4 87698 Gray 2.1 x 3.6 1.5 x 3 87699 Gray 3.1 x 4.6 2.5 x 4 41920 Black 2.1 x 3.6 1.5 x 3 41921 Black 3.1 x 4.6 2.5 x 4 142133 Variety Pack* - -

* Pack of 30 tags includes at least one of each size and color. Perfect for evaluating which sizes and colors you need.

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Tag Size

Inch

Recessed Area

Inch

B30- and B33-Series Materials

BBP®37 printer “cutter” labeling techniques

continuous

Circle Gauge Labels with the BBP

The XY cutter and built-in Circle Gauge App on the BBP37 printer make it easy to create gauge labels. The app allows you to:

• Create in-zone, out-of-zone, caution zone or all three

• Specify center hole size

How to: Use multi-color ribbons, 4 in. white continuous tape and the XY cutter on the BBP37 printer to print and cut out a circular label for your gauge. Transparent transfer tape then makes it easy to cleanly apply the label in the proper position on your gauge.

37 Printer

4 inch

tape

Paneled

ribbon

Gauge App

on BBP37 printer

Transfer tape for

proper alignment

during application

Printing supplies – requires BBP37 printer

Catalog # Color

B30C-4000-595-WT White vinyl 4.0 in. x 100 ft.

B30-R10000-GR-8 Green, red ribbon

B30-R10000-KRYG-8 Black, red, yellow and green ribbon

B30-R10000-KRGB-8 Black, red, blue and green ribbon

76737 transfer tape 4.25 in. x 300 ft

Gradient “Ruler” Labels with BBP35 or BBP37 Printers

Create accurate scale or “ruler” labels using the built-in Gradient Label App on the printer with continuous tapes.

The app allows you to:

• Specify units in inches or millimeters

• Choose from several interval tick mark options

• Designate “zones” through multiple color printing

• Set speciﬁc starting point

How to: Use any continuous tape along with the built-in Gradient Label App on the BBP35 and BBP37 printers.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

2.25 inch

continuous tape

Gradient App

on printer

Printing supplies – requires BBP35 or BBP37

Catalog # Color Size

B30C-4000-595-WT White vinyl 4.0 in. x 100 ft. B30C-2250-595-WT White vinyl 2.25 in. x 100 ft. B30C-1125-595-WT White vinyl 1.125 in. x 100 ft. B30C-500-595-WT White vinyl 0.50 in. x 100 ft. B30C-4000-595-YL Yellow vinyl 4.0 in. x 100 ft. B30C-2250-595-YL Yellow vinyl 2.25 in. x 100 ft. B30C-1125-595-YL Yellow vinyl 1.125 in. x 100 ft. B30C-500-595-YL Yellow vinyl 0.50 in. x 100 ft. B30-R10000 Black ribbon B30-R10000-RD Red ribbon B30-R10000-KR-8 Black, red ribbon B30-R10000-KRGB-8 Black, red, green and blue ribbon B30-R10000-KRYG-8 Black, red, yellow and green ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Indoor and Outdoor Vinyl (B-595)

Continuous vinyl material is ideal for lean / 5S labels, pipe markers, equipment and production area identiﬁcation. These labels offer excellent resistance to oils, detergents, dirt, grime and many solvents. Permanent adhesive, very pliable, good for rough surfaces and outdoor use.

Service temp: -40º F to 180º F Application temp: 0º F to 180º F Average outdoor durability: 8-10 years Agency approvals:

Figure 3

B30 / B33 SeriesBenchtop Printers

Fits Printers

All* Fig. 3 B30C-500-595-WT B-595 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-WT B-595 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-WT B-595 White 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-3000-595-WT B-595 White 3.000 (76.2) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-YL B-595 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-YL B-595 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-YL B-595 Yellow 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-3000-595-YL B-595 Yellow 3.000 (76.2) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-RD B-595 Red 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-RD B-595 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-595-RD B-595 Red 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-595-BL B-595 Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-BL B-595 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-595-BL B-595 Blue 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-595-GN B-595 Green 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-GN B-595 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-595-GN B-595 Green 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-595-OR B-595 Orange 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-OR B-595 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-OR B-595 Orange 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-BK B-595 Black 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-BK B-595 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-595-BK B-595 Black 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-595-BR B-595 Brown 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT

All* Fig. 3 B30C-1125-595-BR B-595 Brown 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

All* Fig. 3 B30C-2250-595-BR B-595 Brown 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-1125-595-OC B-595 Ochre 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-OC B-595 Ochre 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-GD B-595 Gold 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-GD B-595 Gold 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-GD B-595 Gold 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-GY B-595 Gray 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-GY B-595 Gray 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-GY B-595 Gray 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-595-PL B-595 Purple 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-PL B-595 Purple 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-595-PL B-595 Purple 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-595-CL B-595 Clear 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-CL B-595 Clear 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-595-CL B-595 Clear 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All*

U.S. Patent No. 5,823,689; 6,570,602. Additional patents pending.

Figure Catalog # B# Color

Fig. 3 B30C-4000-595-WT B-595 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-YL B-595 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-RD B-595 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-BL B-595 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-GN B-595 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-OR B-595 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-BK B-595 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-BR B-595 Brown 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-OC B-595 Ochre 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-GD B-595 Gold 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-GY B-595 Gray 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-595-PL B-595 Purple 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-595-CL B-595 Clear 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Compatible with BBP37 XY cutter.

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Low-Halide Polyester (B-569)

Low-halide content for labeling stainless steel pipes and surfaces. Applies best to very smooth surfaces and ideal for mounting to rigid panels.

Service temp: -40º F to 212º F Application temp: 0º F to 212º F Average outdoor durability: 3-5 years

Fits Printers

All* Fig. 3 B30C-500-569-WT B-569 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-WT B-569 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-WT B-569 White 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-3000-569-WT B-569 White 3.000 (76.2) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-YL B-569 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-YL B-569 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-YL B-569 Yellow 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-RD B-569 Red 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-RD B-569 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-RD B-569 Red 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-BL B-569 Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-BL B-569 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-BL B-569 Blue 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-LB B-569 Light Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-LB B-569 Light Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-LB B-569 Light Blue 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-SB B-569 Sky Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-SB B-569 Sky Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-SB B-569 Sky Blue 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-GN B-569 Green 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-GN B-569 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-GN B-569 Green 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-OR B-569 Orange 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-OR B-569 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-OR B-569 Orange 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-BK B-569 Black 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-BK B-569 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-BK B-569 Black 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-BR B-569 Brown 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-BR B-569 Brown 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-BR B-569 Brown 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-OC B-569 Ochre 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-OC B-569 Ochre 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-OC B-569 Ochre 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-TN B-569 Tan 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-TN B-569 Tan 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-TN B-569 Tan 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-GY B-569 Gray 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-GY B-569 Gray 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-GY B-569 Gray 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-PL B-569 Purple 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-569-PL B-569 Purple 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-2250-569-PL B-569 Purple 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000-WT All* All* Fig. 3 B30C-500-569-PK B-569 Pink 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-PK B-569 Pink 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-PK B-569 Pink 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-500-569-CL B-569 Clear 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-569-CL B-569 Clear 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-569-CL B-569 Clear 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000 All*

Figure Catalog # B# Color

Fig. 3 B30C-4000-569-WT B-569 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-YL B-569 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-RD B-569 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-BL B-569 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-LB B-569 Light Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-SB B-569 Sky Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-GN B-569 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-OR B-569 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-BK B-569 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-BR B-569 Brown 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-OC B-569 Ochre 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-TN B-569 Ta n 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-GY B-569 Gray 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-PL B-569 Purple 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000-WT

Fig. 3 B30C-4000-569-PK B-569 Pink 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-569-CL B-569 Clear 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Figure 3

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30 / B33 SeriesBenchtop Printers

B30- and B33-Series Materials

Pre-Printed GHS / CLP Chemical Labels (B-569 and B-7569)

• Blank labels with pre-printed red diamonds allow the printer to produce two-color GHS / CLP labels in one print pass

• Three sizes of labels, each with diamond layouts that match templates in the printer app (if applicable) or in the Brady Workstation GHS App

• Indoor / outdoor vinyl material and durable inks withstand exposure to moisture, chemicals and handling

Service temp: -4º F to 180º F Application temp: 50º F to 180º F Average outdoor durability: 3-5 years

Fits Printers

All* B30-260-7569-CLP1 B-7569 Vinyl L1 Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

All* B30-261-7569-CLP1 B-7569 Vinyl L1 Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-7569-CLP1 B-7569 Vinyl L1 Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-260-7569-CLP2 B-7569 Vinyl

All* B30-261-7569-CLP2 B-7569 Vinyl L2 Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-7569-CLP2 B-7569 Vinyl L2 Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-260-7569-CLP3A B-7569 Vinyl

All* B30-261-7569-CLP3A B-7569 Vinyl L3A Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-7569-CLP3A B-7569 Vinyl L3A Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-260-7569-CLP3B B-7569 Vinyl

All* B30-261-7569-CLP3B B-7569 Vinyl L3B Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-7569-CLP3B B-7569 Vinyl L3B Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-260-7569-CLP4A B-7569 Vinyl

All* B30-261-7569-CLP4A B-7569 Vinyl L4A Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-7569-CLP4A B-7569 Vinyl L4A Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-260-569-CLP4B B-569 Polyester

All* B30-260-7569-CLP4B B-7569 Vinyl L4B Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

All* B30-261-569-CLP4B B-569 Polyester L4B Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-261-7569-CLP4B B-7569 Vinyl L4B Diamond + Text 2.950 (75.0) 4.330 (110.0) 270 B30-R10000

All* B30-262-569-CLP4B B-569 Polyester L4B Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

All* B30-262-7569-CLP4B B-7569 Vinyl L4B Diamond + Text 4.130 (105.0) 6.100 (155.0) 200 B30-R10000

Catalog # B# Material Legend

L2 Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

L3A Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

L3B Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

L4A Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

L4B Diamond + Text 2.170 (55.0) 3.350 (85.0) 340 B30-R10000

Label Height Inch (mm)

Label Width Inch (mm)

Labels Per Roll

Rec. Ribbon

All* B30-18-7569-CLP4C B-7569 Vinyl

L4C Diamond + Text 1.000 (25.4) 3.000 (76.2) 1000 B30-R10000

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Pre-Printed Right-To-Know Chemical Labels (B-595)

• Pre-printed labels result in 5-color chemical labels in a single print pass

• Indoor / outdoor grade vinyl withstands exposure to moisture, chemicals and handling

Service temp: -40º F to 180º F Application temp: 0º F to 180º F Average outdoor durability: 8 to 10 years Agency approvals:

Fits Printers

S3100, i3300, BBP31, BBP33, BBP35, BBP37

Labels above are not compatible with BradyPrinter S3000 or BBP30 printers.

Catalog # B# Legend

B30-244-595-NFPA B-595

B30-245-595-NFPA B-595

B30-263-595-NFPA B-595 Diamond + Text 4.000 (101.6) 6.250 (158.8) 1 170 B30-R10000

B30-244-595-DIAM B-595

B30-161-595-DIAM B-595 Diamond Only 4.000 (101.6) 4.000 (101.6) 1 240 B30-R10000

B30-246-595-NFR B-595

B30-244-595-CB B-595

B30-245-595-CB B-595

B30-263-595-CB B-595 Color Bar + Text 4.000 (101.6) 6.250 (158.8) 1 170 B30-R10000

B30-244-595-HMIG B-595

B30-246-595-HMIG B-595

Label Height Inch (mm)

Diamond + Text 2.250 (57.5) 2.250 (57.5) 1 365 B30-R10000

Diamond + Text 2.250 (57.5) 4.000 (101.6) 1 240 B30-R10000

Diamond Only 2.250 (57.5) 2.250 (57.5) 1 365 B30-R10000

Diamond NFR 1.125 (28.6) 3.000 (76.2) 1 300 B30-R10000

Color Bar + Text 2.250 (57.5) 2.250 (57.5) 1 365 B30-R10000

Color Bar + Text 2.250 (57.5) 4.000 (101.6) 1 240 B30-R10000

Color Bar Only 2.250 (57.5) 2.250 (57.5) 1 365 B30-R10000

Color Bar HMIG 1.125 (28.6) 3.000 (76.2) 1 300 B30-R10000

Label Width Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Pre-Printed Pre-Cut Blank Sign Headers (B-595)

• Allows printer to create multicolor signs fast in a single print pass

• Headers meet NFPA 70E, OSHA 1910.145

and ASME/ANSI Z535 standards

• Indoor / outdoor grade vinyl conforms to rough, highly textured and difﬁcult-to-adhere-to surfaces

Service temp: -40º F to 180º F Application temp: 0º F to 180º F Average outdoor durability: 8-10 years Agency approvals:

Fits Printers

All* Fig. 70 B30-241-595-OSHADA B-595 2.250 (57.5) 3.000 (76.2) 300 B30-R10000

All* Fig. 70 B30-25-595-OSHADA B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

All* Fig. 70 B30-241-595-OSHACA B-595

All* Fig. 70 B30-25-595-OSHACA B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000 All* Fig. 70 B30-241-595-ANSICA B-595

All* Fig. 70 B30-25-595-ANSICA B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

All* Fig. 70 B30-241-595-ANSIDA B-595

All* Fig. 70 B30-25-595-ANSIDA B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

All* Fig. 70 B30-241-595-ANSIWA B-595

All* Fig. 70 B30-25-595-ANSIWA B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

All* Fig. 70 B30-241-595-ANSINO B-595

All* Fig. 70 B30-25-595-ANSINO B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

All* Fig. 70 B30-25-595-PREC B-595

Figure Catalog # B# Header

HEADERDER

Figure 70

Label Height A Inch (mm)

2.250 (57.5) 3.000 (76.2) 300 B30-R10000

4.000 (101.6) 6.000 (152.4) 175 B30-R10000

Figure 82

Label Width B Inch (mm)

Blank rigid valve tags on page 38

Labels Per Roll Rec. Ribbon

B30 / B33 SeriesBenchtop Printers

All* Fig. 70 B30-25-595-PEL B-595

All* Fig. 82 B30-242-595-BLNKWT B-595 All* Fig. 82 B30-241-595-BLNKWT B-595 2.250 (57.5) 3.000 (76.2) 300 B30-R10000 All* Fig. 82 B30-219-595-BLNKWT B-595 2.250 (57.5) ** 3.750 (95.3) 250 B30-R10000 All* Fig. 82 B30-25-595-BLNKWT B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000 All* Fig. 82 B30-241-595-BLNKYL B-595

All* Fig. 82 B30-25-595-BLNKYL B-595 4.000 (101.6) 6.000 (152.4) 175 B30-R10000

** Sized to ﬁt blank rigid valve tags, see page 38.

Non-Adhesive Tags (B-551)

• Non-adhesive semi-rigid card stock in pre-cut or

4.000 (101.6) 6.000 (152.4) 175 B30-R10000

1.125 (28.6) ** 2.750 (69.8) 300 B30-R10000

2.250 (57.5) 3.000 (76.2) 300 B30-R10000

continuous styles

• Pre-cut style tags micro-perforated between tags to separate cleanly and feature chamfered corners

• Snap-in plastic grommets available for extra

HEADER

strength around mounting hole (Catalog #20596, 100/bag)

Service temp: -40º F to 193º F Average outdoor durability: Up to 2 years

Fits Printers

All* Fig. 69 B30-255-551-ANSIDA B-551 3.250 (82.6) 5.750 (146.1) 100 B30-R10000

All* Fig. 69 B30-255-551-OSHADA B-551 3.250 (82.6) 5.750 (146.1) 100 B30-R10000

All* Fig. 69 B30-255-551-ANSICA B-551 3.250 (82.6) 5.750 (146.1) 100 B30-R10000

Figure Catalog # B# Header

Figure 3

Tag Width A Inch (mm)

Figure 69

Tag Height B Inch (mm)

Tags Per Roll

Rec. Ribbon

All* Fig. 69 B30-255-551-WHT B-551 3.250 (82.6) 5.750 (146.1) 100 B30-R10000

All* Fig. 3 B30C-2500-551-WT B-551 2.500 (63.5) 50 ft. (15.2 m) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-3250-551-WT B-551 3.250 (82.6) 50 ft. (15.2 m) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-4250-551-WT B-551 4.250 (107.9) 50 ft. (15.2 m) 1 roll (cont.) B30-R10000

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Compatible with BBP37 XY cutter.

B30- and B33-Series Materials

HEADERDER HE

ToughWash® Washdown Resistant Labels (B-854 and B-855)

• Withstands high pressure, heat, harsh chemicals and numerous washdown cycles

• Legible and long-lasting for even the toughest washdown cycles

• Ideal for use in the food and beverage industry

• B-854 offers metal detectable layer to allow detection in food stream

Service temp: -40º F to 230º F Agency approvals:

Figure 3

Fits Printers

ToughWash Metal Detectable Material (B-854):

All* Fig. 3 B30C-4000-854-YL B-854 4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000

All* Fig. 3 B30C-4000-854-WT B-854

All* Fig. 73 B30-25-854-OSHADA B-854

All* Fig. 73 B30-25-854-ANSIWA B-854

All* Fig. 73 B30-25-854-ANSIDA B-854

All* Fig. 73 B30-25-854-ANSICA B-854

All* Fig. 73 B30-25-854-PEL B-854

All* Fig. 73 B30-25-854-PREC B-854

ToughWash Material (B-855):

All* Fig. 3 B30C-1125-855-YL B-855 1.125 (28.6) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000 All* Fig. 3 B30C-2250-855-YL B-855 2.250 (57.5) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000 All* Fig. 3 B30C-4000-855-YL B-855 4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000 All* Fig. 3 B30C-1125-855-WT B-855 All* Fig. 3 B30C-2250-855-WT B-855 2.250 (57.5) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000 All* Fig. 3 B30C-4000-855-WT B-855 4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000

Figure Catalog # B# Color

Label Width A Inch (mm)

4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000

4.000 (101.06) 6.250 (158.8) 100 B30-R6000

1.125 (28.6) 50 ft. (15.2 m) 1 roll (cont.) B30-R6000

Figure 73

Length B Inch (mm)

Labels Per Roll Rec. Ribbon

All* Fig. 73 B30-25-855-OSHADA B-855

All* Fig. 73 B30-25-855-ANSIWA B-855

All* Fig. 73 B30-25-855-ANSIDA B-855

All* Fig. 73 B30-25-855-ANSICA B-855

All* Fig. 73 B30-25-855-PEL B-855

All* Fig. 73 B30-25-855-PREC B-855

4.000 (101.06) 6.250 (158.8) 100 B30-R6000

B30 / B33 Series Benchtop Printers

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Chemical and Solvent Resistant Polypropylene Labels (B-425, B-7425)

• Outstanding chemical and solvent resistance and print performance

• Not recommended for prolonged outdoor use

B-425: Service temp: -94° F to 212° F B-7425: Service temp:-320° F to 248° F Agency approvals:

Figure 1

B30 / B33 SeriesBenchtop Printers

Figure 2

Fits Printers

i3300, BBP33 Fig. 1 B33-5-425 B-425 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300 i3300, BBP33 Fig. 2 B33-17-425 B-425 White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-18-425 B-425 White 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-19-425 B-425 White 3.000 (76.2) 2.000 (50.8) 1 500 B30-R4300 i3300, BBP33 Fig. 25 B33-88-7425 B-7425 White 1.000 (25.4) 0.750 (19.1) 2 2000 B30-R4300 i3300, BBP33 Fig. 2 B33-179-7425 B-7425 White 1.000 (25.4) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 25 B33-37-7425 B-7425 White 1.500 (38.1) 0.500 (12.7) 2 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-136-7425 B-7425 White 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-235-7425 B-7425 White 1.500 (38.1) 1.000 (25.4) 1 1250 B30-R4300 i3300, BBP33 Fig. 2 B33-258-7425 B-7425 White 1.500 (38.1) 1.750 (44.5) 1 900 B30-R4300 i3300, BBP33 Fig. 2 B33-53-7425 B-7425 White 2.000 (50.8) 0.500 (12.7) 1 2000 B30-R4300

Figure Catalog # B# Color

Label Width A Inch (mm)

Figure 25

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Retro Reective Tape (B-584)

• Highly reﬂective material shines back brightly when struck by light

• Ideal for labeling outdoor utility pedestals, hard hats, jobsite equipment and roof-top equipment

• Recommended for low light or inclement weather conditions

Service temp: -40º F to 158º F Application temp: 0º F to 158º F (yellow and orange), 50º F to 158º F (silver) Average outdoor durability: 4 to 6 years

Fits Printers

All* Fig. 3 B30C-1125-584-SL B-584 Silver 1.125 (28.6) 50 (15.2) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-584-SL B-584 Silver 2.250 (57.5) 50 (15.2) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-1125-584-YL B-584 Yellow 1.125 (28.6) 50 (15.2) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-584-YL B-584 Yellow 2.250 (57.5) 50 (15.2) 1 roll (cont.) B30-R10000 All* All* Fig. 3 B30C-1125-584-OR B-584 Orange 1.125 (28.6) 50 (15.2) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-584-OR B-584 Orange 2.250 (57.5) 50 (15.2) 1 roll (cont.) B30-R10000 All*

Figure Catalog # B# Color

Fig. 3 B30C-4000-584-SL B-584 Silver 4.000 (101.6) 50 (15.2) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-584-YL B-584 Yellow 4.000 (101.6) 50 (15.2) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-584-OR B-584 Orange 4.000 (101.6) 50 (15.2) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

Figure 3

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

BradyGlo™ High-Intensity Photoluminescent Tape (B-526)

• Designed for directional, evacuation and equipment marking. Ideal for marking emergency utility shut-offs, ﬁre extinguishers, alarm pulls and vital equipment controls

• For glow-in-the-dark identiﬁcation up to 10 hours

• Complies with indoor use requirements speciﬁed in RS 6-1 and 6-1A of New York Local Law 26

Service temp: -40º F to 140º F Application temp: 40º F to 140º F

Fits Printers

All* Fig. 3 B30C-1125-526 B-526 Luminous Green 1.125 (28.6) 50 (15.2) 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-2250-526 B-526 Luminous Green 2.250 (57.5) 50 (15.2) 1 roll (cont.) B30-R10000 All*

Figure Catalog # B# Color

Fig. 3 B30C-4000-526 B-526 Luminous Green 4.000 (101.6) 50 (15.2) 1 roll (cont.) B30-R10000

BradyPrinter S3000, S3100, i3300, BBP

Label Width A Inch (mm)

*All supplies listed are compatible with the following printers unless otherwise noted:

Figure 3

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Compatible with BBP37 XY cutter.

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Printable Magnetic Supply (B-509)

• Easiest and quickest material for removing and repositioning

• Non-adhesive magnetic material that can be printed on directly

• Ideal for reusable, repositionable and Lean / 5S identiﬁcation applications

Service temp: 0º F to 158º F Average outdoor durability: 3 to 5 years

Figure 3

Fits Printers

All* Fig. 3 B30C-2500-509-WT B-509 White 2.500 (63.5) 25 (7.62) 1 roll (cont.) B30-R10000

All*

All* Fig. 3 B30C-2500-509-YL B-509 Yellow 2.500 (63.5) 25 (7.62) 1 roll (cont.) B30-R10000

All*

Figure Catalog # B# Color

Fig. 3 B30C-4250-509-WT B-509 White 4.250 (107.8) 25 (7.62) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4250-509-YL B-509 Yellow 4.250 (107.8) 25 (7.62) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Repositionable Vinyl (B-581)

• Aggressive adhesive stays in place but removes cleanly without leaving adhesive residue

• Ideal for temporary, removable and repositionable labels, such as Lean / 5S inventory labels

Service temp: -40º F to 180º F Application temp: 50º F to 180º F Average outdoor durability: 5 years

Fits Printers

All* Fig. 3 B30C-500-581-WT B-581 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-1125-581-WT B-581 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-2250-581-WT B-581 White 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000

All*

All* Fig. 3 B30C-500-581-YL B-581 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-1125-581-YL B-581 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-2250-581-YL B-581 Yellow 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000

All*

Figure Catalog # B# Color

Fig. 3 B30C-4000-581-WT B-581 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-581-YL B-581 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

Figure 3

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Dissolvable Paper Labels (B-403)

• Designed for temporary applications where easy removal, re-identiﬁcation or waste reduction are valued

• Ideal for labeling glassware, temporary asset tracking, animal housing identiﬁcation and general use

• Completely dissolves in warm water within 30 seconds, leaving no adhesive residue

Service temp: -40° F to 172° F

Fits Printers

All* Fig. 3 B30C-1125-403-WT B-403 White 1.125 (28.575) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-2250-403-WT B-403 White 2.250 (57.15) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-3000-403-WT B-403 White 3.000 (76.2) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-4000-403-WT B-403 White 4.000 (101.6) 100 (30.5) 1 (cont.) B30-R4300

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

Figure Catalog # B# Color

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Figure 3

Label Width A Inch (mm)

Dissolves within 30 seconds leaving no residue.

Roll Length B Inch (mm)

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

General ID Labels for Lean / 5S, Bins and Production Areas (B-483, B-484A, B-498, B-499 and B-595)

• Also ideal for marking backer board, DIN rail, relays, PLCs, switches, solenoids, drive motors and other components inside panels

• All recommended materials are ﬂexible and have high-tack adhesives for adhesion to wide variety of surfaces and components

B-483: Service temp: -40° F to 248° F Agency approvals: B-484A: Service temp: -40° F to 240° F Agency approvals: B-498: Service temp: -40° F to 175° F Agency approvals: B-499: Service temp: -40° F to 193° F Agency approvals: B-595: Service temp: -40° F to 180° F Agency approvals:

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure 1

Figure 2

Figure Catalog # B# Color

Figure 3

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Vinyl cloth with ggressive but repositionable adhesive (B-498):

i3300, BBP33 Fig. 1 B33-90-498 B-498 White 0.250 (6.4) 1.437 (36.5) 6 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-68-498 B-498 White 0.500 (12.7) 0.750 (19.1) 4 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-87-498 B-498 White 0.500 (12.7) 1.437 (36.5) 6 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-1-498 B-498 White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-95-498 B-498 White 0.800 (20.3) 1.437 (36.5) 3 2300 B30-R6200 i3300, BBP33 Fig. 1 B33-5-498 B-498 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-88-498 B-498 White 1.000 (25.4) 0.750 (19.1) 2 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-89-498 B-498 White 1.000 (25.4) 1.437 (36.5) 3 2300 B30-R6200 S3000, S3100, i3300,

BBP35, BBP37

Fig. 1 B30C-4000-498 B-498 White 4.000 (101.6) 80 ft. (24.4 m) 1 roll (cont.) B30-R6200

Nylon Cloth with permanent adhesive (B-499):

i3300, BBP33 Fig. 1 B33-68-499 B-499 White 0.500 (12.7) 0.750 (19.1) 4 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-165-499 B-499 White 0.800 (20.3) 1.437 (36.5) 4 2500 B30-R6000 i3300, BBP33 Fig. 2 B33-125-499 B-499 White 0.900 (22.9) 0.500 (12.7) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-163-499 B-499 White 1.000 (25.4) 0.375 (9.5) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-152-499 B-499 White 1.000 (25.4) 0.375 (9.5) 2 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-136-499 B-499 White 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-137-499 B-499 White 2.000 (50.8) 1.000 (25.4) 1 1100 B30-R6000

Polyester with ultra-aggressive adhesive for highly textured and low-surface energy surfaces (B-483):

i3300, BBP33 Fig. 1 B33-149-483 B-483 White 0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000 i3300, BBP33 Fig. 1 B33-5-483 B-483 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000 i3300, BBP33 Fig. 2 B33-17-483 B-483 White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-7-483 B-483 White 2.750 (69.9) 1.250 (31.8) 1 1000 B30-R6000 i3300, BBP33 Fig. 2 B33-18-483 B-483 White 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-19-483 B-483 White i3300, BBP33 Fig. 2 B33-55-483 B-483 White 4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

Polyester with ultra-aggressive adhesive and pliable for conforming to angular surfaces (B-484A):

i3300, BBP33 Fig. 2 B33-125-484 B-484A White 0.900 (22.9) 0.500 (12.7) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-5-484 B-484A White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000 i3300, BBP33 Fig. 2 B33-136-484 B-484A White 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-17-484 B-484A White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-18-484 B-484A White 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-19-484 B-484A White 3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

Continuous cut-to-length vinyl with permanent adhesive is conformable and indoor / outdoor grade (B-595):

All* Fig. 3 B30C-500-595-WT B-595** All* Fig. 3 All* Fig. 3 B30C-500-595-YL B-595** All* Fig. 3

B30C-1125-595-WT

B30C-1125-595-YL

B-595**

White White Yellow Yellow

0.500 (12.7) 100 ft. (30.5m) 1 roll (cont.) B30-R10000

1.125 (28.6) 100 ft. (30.5m) 1 roll (cont.) B30-R10000

0.500 (12.7) 100 ft. (30.5m) 1 roll (cont.) B30-R10000

1.125 (28.6) 100 ft. (30.5m) 1 roll (cont.) B30-R10000

** Additional sizes and colors available for B-595 on page 40.

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Rec. Ribbon

B30- and B33-Series Materials

Cold Temperature Application Material (B-549)

• Special adhesive permanently adheres to extremely cold surfaces

• Can be applied in -10º F and lasts in -40º F

• Ideal for cold storage warehouses, coolers, freezers and short-term winter outdoor use

Service temp: -40º F to 212º F Average outdoor durability: Up to 1 year

Fits Printers

All* Fig. 3 B30C-1125-549-WT B-549 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-2250-549-WT B-549 White 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000

All*

All* Fig. 3 B30C-1125-549-YL B-549 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R10000

All* Fig. 3 B30C-2250-549-YL B-549 Yellow 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R10000

All*

Figure Catalog # B# Color

Fig. 3 B30C-4000-549-WT B-549 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Fig. 3 B30C-4000-549-YL B-549 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R10000

Label Width A Inch (mm)

Figure 3

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

ToughStripe® Printable Floor Marking Tape (B-483 with overlaminate)

• Revolutionary B-483 material has ultra-aggressive adhesive

• Each roll ships with a roll of clear overlaminate which must be applied over printed label for best performance

Service temp: -40º F to 248º F Agency approvals:

For use with printer* Figure Catalog # B# Color

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483WT-KT B-483 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483WT-KT B-483 White 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-3000-483WT-KT B-483 White 3.000 (76.2) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483YL-KT B-483 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483YL-KT B-483 Yellow 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-3000-483YL-KT B-483 Yellow 3.000 (76.2) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483RD-KT B-483 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483RD-KT B-483 Red 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483BL-KT B-483 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483BL-KT B-483 Blue 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483GN-KT B-483 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483GN-KT B-483 Green 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483BK-KT B-483 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483BK-KT B-483 Black 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R4400-WT

S3000, S3100, i3300, BBP35, BBP37

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-1125-483OR-KT B-483 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37 Fig. 3 B30C-2250-483OR-KT B-483 Orange 2.250 (57.5) 100 (30.5) 1 roll (cont.) B30-R6000

S3000, S3100, i3300, BBP35, BBP37

ToughStripe material is not compatible with BBP®30, BBP®33 and BBP®31 printers.

Fig. 3 B30C-4000-483WT-KT B-483 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R6000

Fig. 3 B30C-4000-483YL-KT B-483 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R6000

Fig. 3 B30C-4000-483RD-KT B-483 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

Fig. 3 B30C-4000-483BL-KT B-483 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

Fig. 3 B30C-4000-483GN-KT B-483 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

Fig. 3 B30C-4000-483BK-KT B-483 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R4400-WT

Fig. 3 B30C-4000-483OR-KT B-483 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) B30-R6000

Figure 3

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

ToughStripe material also available as:

• Solid, striped and dashed tape

• Die-cut shape, numbers and letters

View page 295 for more additional products.

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Raised Prole - Engraved Plate Substitute Labels (B-593)

Push Button Style

• High gloss, polyester label with thick raised proﬁle and ultra-aggressive adhesive (0.70 mm thick)

• High-performance, low-cost substitute to engraved plates – costs up to 80% less

• 10-year outdoor durability rating

• On-demand labeling: prints out in fewer than 4 seconds

• 5 push button sizes (including keyed and non-keyed

22.5 mm and 30.5 mm hole diameters)

Service temp: -4º F to 212º F Application temp: 50º F to 212º F Agency approvals:

B30 / B33 SeriesBenchtop Printers

Fits Printers

All*

Figure Catalog # B# Color

Fig. 18a B30EP-167-593-WT B-593 White 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R6000

Fig. 18b B30EP-167U-593-WT B-593 White 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R6000

Fig. 18a B30EP-169-593-WT B-593 White 1.800 (45.7) 1.800 (45.7) 1.200 (30.5) 1 190 B30-R6000

Fig. 18a B30EP-168-593-WT B-593 White 1.900 (48.3) 1.200 (30.5) 0.885 (22.5) 1 180 B30-R6000

Fig. 18a B30EP-170-593-WT B-593 White 2.400 (60.9) 2.400 (60.9) 1.200 (30.5) 1 145 B30-R6000

Fig. 18a B30EP-167-593-YL B-593 Yellow 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R6000

Fig. 18b B30EP-167U-593-YL B-593 Yellow 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R6000

Fig. 18a B30EP-169-593-YL B-593 Yellow 1.800 (45.7) 1.800 (45.7) 1.200 (30.5) 1 190 B30-R6000

Fig. 18a B30EP-168-593-YL B-593 Yellow 1.900 (48.3) 1.200 (30.5) 0.885 (22.5) 1 180 B30-R6000

Fig. 18a B30EP-170-593-YL B-593 Yellow 2.400 (60.9) 2.400 (60.9) 1.200 (30.5) 1 145 B30-R6000

Fig. 18a B30EP-167-593-BK B-593 Black 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18b B30EP-167U-593-BK B-593 Black 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18a B30EP-169-593-BK B-593 Black 1.800 (45.7) 1.800 (45.7) 1.200 (30.5) 1 190 B30-R4400-WT

Fig. 18a B30EP-168-593-BK B-593 Black 1.900 (48.3) 1.200 (30.5) 0.885 (22.5) 1 180 B30-R4400-WT

Fig. 18a B30EP-170-593-BK B-593 Black 2.400 (60.9) 2.400 (60.9) 1.200 (30.5) 1 145 B30-R4400-WT

Fig. 18a B30EP-167-593-GN B-593 Green 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18b B30EP-167U-593-GN B-593 Green 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18a B30EP-169-593-GN B-593 Green 1.800 (45.7) 1.800 (45.7) 1.200 (30.5) 1 190 B30-R4400-WT

Fig. 18a B30EP-168-593-GN B-593 Green 1.900 (48.3) 1.200 (30.5) 0.885 (22.5) 1 180 B30-R4400-WT

Fig. 18a B30EP-170-593-GN B-593 Green 2.400 (60.9) 2.400 (60.9) 1.200 (30.5) 1 145 B30-R4400-WT

Fig. 18a B30EP-167-593-RD B-593 Red 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18b B30EP-167U-593-RD B-593 Red 1.500 (38.1) 1.200 (30.5) 0.885 (22.5) 1 200 B30-R4400-WT

Fig. 18a B30EP-169-593-RD B-593 Red 1.800 (45.7) 1.800 (45.7) 1.200 (30.5) 1 190 B30-R4400-WT

Fig. 18a B30EP-168-593-RD B-593 Red 1.900 (48.3) 1.200 (30.5) 0.885 (22.5) 1 180 B30-R4400-WT

Fig. 18a B30EP-170-593-RD B-593 Red 2.400 (60.9) 2.400 (60.9) 1.200 (30.5) 1 145 B30-R4400-WT

U.S. Patent No. US8475914B2; US9005729B2.

Figure 18a

Label Height A Inch (mm)

Figure 18b

(without key hole)

Label Width B Inch (mm)

Hole Diameter C Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Raised Prole - Engraved Plate Substitute Labels (B-593)

Rectangular Style

• High gloss, polyester label with thick raised proﬁle and ultra-aggressive adhesive (0.70 mm thick)

• High-performance, low-cost substitute to engraved plates – costs up to 80% less

• 10-year outdoor durability rating

• On-demand labeling: prints out in fewer than 4 seconds

• Ideal for inside-panel backer board labels and front-of-enclosure labeling

Service temp: -4º F to 212º F Application temp: 50º F to 212º F Agency approvals:

Figure 18c

Fits Printers

All* Fig. 18c B30EP-171-593-WT B-593 White 0.490 (12.5) 1.060 (26.9) 1 500 B30-R6000 All* Fig. 18c B30EP-172-593-WT B-593 White 0.590 (15.0) 1.770 (45.0) 1 450 B30-R6000 All* Fig. 18c B30EP-175-593-WT B-593 White 0.750 (19.1) 3.000 (76.2) 1 375 B30-R6000 All* Fig. 18c B30EP-173-593-WT B-593 White 1.000 (25.4) 2.000 (50.8) 1 300 B30-R6000 All* Fig. 18c B30EP-174-593-WT B-593 White 1.000 (25.4) 4.000 (101.6) 1 300 B30-R6000 All* Fig. 18c B30EP-176-593-WT B-593 White 1.000 (25.4) 3.000 (76.2) 1 300 B30-R6000 All* Fig. 18c B30EP-177-593-WT B-593 White 2.500 (63.5) 3.000 (76.2) 1 125 B30-R6000 All* Fig. 18c B30EP-171-593-YL B-593 Yellow 0.490 (12.5) 1.060 (26.9) 1 500 B30-R6000 All* Fig. 18c B30EP-172-593-YL B-593 Yellow 0.590 (15.0) 1.770 (45.0) 1 450 B30-R6000 All* Fig. 18c B30EP-175-593-YL B-593 Yellow 0.750 (19.1) 3.000 (76.2) 1 375 B30-R6000 All* Fig. 18c B30EP-173-593-YL B-593 Yellow 1.000 (25.4) 2.000 (50.8) 1 300 B30-R6000 All* Fig. 18c B30EP-174-593-YL B-593 Yellow 1.000 (25.4) 4.000 (101.6) 1 300 B30-R6000 All* Fig. 18c B30EP-176-593-YL B-593 Yellow 1.000 (25.4) 3.000 (76.2) 1 300 B30-R6000 All* Fig. 18c B30EP-177-593-YL B-593 Yellow 2.500 (63.5) 3.000 (76.2) 1 125 B30-R6000 All* Fig. 18c B30EP-171-593-BK B-593 Black 0.490 (12.5) 1.060 (26.9) 1 500 B30-R4400-WT All* Fig. 18c B30EP-172-593-BK B-593 Black 0.590 (15.0) 1.770 (45.0) 1 450 B30-R4400-WT All* Fig. 18c B30EP-175-593-BK B-593 Black 0.750 (19.1) 3.000 (76.2) 1 375 B30-R4400-WT All* Fig. 18c B30EP-173-593-BK B-593 Black 1.000 (25.4) 2.000 (50.8) 1 300 B30-R4400-WT All* Fig. 18c B30EP-174-593-BK B-593 Black 1.000 (25.4) 4.000 (101.6) 1 300 B30-R4400-WT All* Fig. 18c B30EP-176-593-BK B-593 Black 1.000 (25.4) 3.000 (76.2) 1 300 B30-R4400-WT All* Fig. 18c B30EP-177-593-BK B-593 Black 2.500 (63.5) 3.000 (76.2) 1 125 B30-R4400-WT All* Fig. 18c B30EP-171-593-GN B-593 Green 0.490 (12.5) 1.060 (26.9) 1 500 B30-R4400-WT All* Fig. 18c B30EP-172-593-GN B-593 Green 0.590 (15.0) 1.770 (45.0) 1 450 B30-R4400-WT All* Fig. 18c B30EP-175-593-GN B-593 Green 0.750 (19.1) 3.000 (76.2) 1 375 B30-R4400-WT All* Fig. 18c B30EP-173-593-GN B-593 All* Fig. 18c B30EP-174-593-GN B-593 Green 1.000 (25.4) 4.000 (101.6) 1 300 B30-R4400-WT All* Fig. 18c B30EP-176-593-GN B-593 Green 1.000 (25.4) 3.000 (76.2) 1 300 B30-R4400-WT All* Fig. 18c B30EP-177-593-GN B-593 Green 2.500 (63.5) 3.000 (76.2) 1 125 B30-R4400-WT All* Fig. 18c B30EP-171-593-RD B-593 Red 0.490 (12.5) 1.060 (26.9) 1 500 B30-R4400-WT All* Fig. 18c B30EP-172-593-RD B-593 Red 0.590 (15.0) 1.770 (45.0) 1 450 B30-R4400-WT All* Fig. 18c B30EP-173-593-RD B-593 Red 1.000 (25.4) 2.000 (50.8) 1 300 B30-R4400-WT All* Fig. 18c B30EP-174-593-RD B-593 Red 1.000 (25.4) 4.000 (101.6) 1 300 B30-R4400-WT All* Fig. 18c B30EP-171-593-SL B-593 Silver 0.490 (12.5) 1.060 (26.9) 1 500 B30-R6000 All* Fig. 18c B30EP-172-593-SL B-593 Silver 0.590 (15.0) 1.770 (45.0) 1 450 B30-R6000 All* Fig. 18c B30EP-173-593-SL B-593 Silver 1.000 (25.4) 2.000 (50.8) 1 300 B30-R6000 All* Fig. 18c B30EP-174-593-SL B-593 Silver 1.000 (25.4) 4.000 (101.6) 1 300 B30-R6000

U.S. Patent No. US8475914B2; US9005729B2.

Figure Catalog # B# Color

Green 1.000 (25.4) 2.000 (50.8) 1 300 B30-R4400-WT

Label Height A Inch (mm)

Label Width B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Polyester Labels (B-422, B-423, B-430, B-432, B-483, B-484A and B-489)

• For product, circuit board and component ID as well as for general purpose industrial identiﬁcation

• Ideal for textured and curved surfaces

B-423: Service temp: -94° F to 248° F Agency approvals: B-430: Service temp: -40° F to 212° F Agency approvals: B-432: Service temp: -40° F to 212° F Agency approvals: B-483: Service temp: -94° F to 248° F Agency approvals: B-484A: Service temp: -40° F to 240° F Agency approvals: B-489: Service temp: -94° F to 248° F Agency approvals:

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure 1

Figure

Figure 2

Catalog # B# Color

Standard adhesive (B-423 gloss white):

i3300, BBP33 Fig. 4 B33-11-423 B-423

i3300, BBP33 Fig. 1 B33-38-423 B-423

i3300, BBP33 Fig. 1 B33-149-423 B-423

i3300, BBP33 Fig. 1 B33-1-423 B-423

i3300, BBP33 Fig. 2 B33-46-423 B-423

i3300, BBP33 Fig. 2 B33-49-423 B-423

i3300, BBP33 Fig. 2 B33-103-423 B-423

i3300, BBP33 Fig. 1 B33-3-423 B-423

i3300, BBP33 Fig. 1 B33-5-423 B-423

i3300, BBP33 Fig. 2 B33-43-423 B-423

i3300, BBP33 Fig. 1 B33-29-423 B-423

i3300, BBP33 Fig. 2 B33-45-423 B-423

i3300, BBP33 Fig. 2 B33-72-423 B-423

i3300, BBP33 Fig. 2 B33-53-423 B-423

i3300, BBP33 Fig. 2 B33-17-423 B-423

i3300, BBP33 Fig. 2 B33-18-423 B-423

i3300, BBP33 Fig. 2 B33-19-423 B-423

i3300, BBP33 Fig. 2 B33-55-423 B-423 S3000, S3100, i3300,

BBP35, BBP37

Fig. 3 B30C-4000-423 B-423

Standard adhesive (B-430 clear):

i3300, BBP33 Fig. 1 B33-5-430 B-430

i3300, BBP33 Fig. 2 B33-17-430 B-430

i3300, BBP33 Fig. 2 B33-18-430 B-430

Strong adhesive for textured surfaces (B-422 gloss white):

i3300, BBP33 Fig. 1 B33-149-422 B-422

i3300, BBP33 Fig. 1 B33-5-422 B-422

i3300, BBP33 Fig. 1 B33-147-422 B-422

i3300, BBP33 Fig. 2 B33-102-422 B-422

i3300, BBP33 Fig. 2 B33-136-422 B-422

i3300, BBP33 Fig. 2 B33-17-422 B-422

i3300, BBP33 Fig. 2 B33-18-422 B-422

i3300, BBP33 Fig. 2 B33-19-422 B-422

i3300, BBP33 Fig. 2 B33-76-422 B-422

Figure 3

Gloss White

Clear

Gloss White

Figure 4

Label Width A Inch (mm)

0.250 (6.4) 0.250 (6.4) 12 15000 B30-R6000

0.375 (9.5) 0.375 (9.5) 9 5000 B30-R6000

0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

0.750 (19.1) 0.250 (6.4) 4 5000 B30-R6000

0.750 (19.1) 0.250 (6.4) 1 5000 B30-R6000

0.900 (22.9) 0.250 (6.4) 1 5000 B30-R6000

1.000 (25.4) 0.250 (6.4) 1 5000 B30-R6000

1.000 (25.4) 0.375 (9.5) 3 5000 B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

1.250 (31.8) 0.250 (6.4) 1 5000 B30-R6000

1.250 (31.8) 0.375 (9.5) 2 5000 B30-R6000

1.500 (38.1) 0.250 (6.4) 1 5000 B30-R6000

1.750 (44.5) 0.250 (6.4) 1 5000 B30-R6000

2.000 (50.8) 0.500 (12.7) 1 2500 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

4.000 (101.6) 150 ft. (45.7 m) 1 roll (cont.) B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

1.500 (38.1) 0.375 (9.5) 2 2500 B30-R6000

1.500 (38.1) 0.375 (9.5) 1 2500 B30-R6000

1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

4.000 (101.6) 3.000 (76.2) 1 500 B30-R6000

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Compatible with BBP37 XY cutter.

B30- and B33-Series Materials

Polyester Labels (continued)

Fits Printers

Figure

Stronger adhesive for textured surfaces (B-432 clear):

i3300, BBP33 Fig. 1 B33-149-432 B-432

i3300, BBP33 Fig. 1 B33-5-432 B-432

i3300, BBP33 Fig. 2 B33-17-432 B-432

i3300, BBP33 Fig. 2 B33-18-432 B-432

i3300, BBP33 Fig. 2 B33-19-432 B-432 S3000, S3100, i3300,

BBP35, BBP37

Fig. 3 B30C-4000-432 B-432 Clear 4.000 (101.6) 120 ft. (36.6 m) 1 roll (cont.) B30-R6000

Ultra-aggressive adhesive for highly textured surfaces (B-483 gloss white):

i3300, BBP33 Fig. 1 B33-149-483 B-483

i3300, BBP33 Fig. 1 B33-5-483 B-483

i3300, BBP33 Fig. 2 B33-17-483 B-483

i3300, BBP33 Fig. 2 B33-7-483 B-483

i3300, BBP33 Fig. 2 B33-18-483 B-483

i3300, BBP33 Fig. 2 B33-19-483 B-483

i3300, BBP33 Fig. 2 B33-55-483 B-483 S3000, S3100, i3300,

BBP35, BBP37

Fig. 3 B30C-4000-483 B-483

Ultra-aggressive adhesive for highly textured surfaces (B-489 matte white):

i3300, BBP33 Fig. 1 B33-5-489 B-489

i3300, BBP33 Fig. 2 B33-17-489 B-489

i3300, BBP33 Fig. 2 B33-18-489 B-489

i3300, BBP33 Fig. 2 B33-19-489 B-489 S3000, S3100, i3300,

BBP35, BBP37

Fig. 3 B30C-4000-489 B-489

Ultra-aggressive adhesive and pliable for conforming to angular surfaces (B-484A gloss white):

i3300, BBP33 Fig. 2 B33-125-484 B-484A

i3300, BBP33 Fig. 1 B33-5-484 B-484A

i3300, BBP33 Fig. 2 B33-136-484 B-484A

i3300, BBP33 Fig. 2 B33-17-484 B-484A

i3300, BBP33 Fig. 2 B33-18-484 B-484A

i3300, BBP33 Fig. 2 B33-19-484 B-484A S3000, S3100, i3300,

BBP35, BBP37

Fig. 3 B30C-4000-484 B-484A

Permanent acrylic adhesive (B-488 matte white)

S3000, S3100, i3300, BBP35, BBP37

Fig. 3 B30C-4000-488 B-488 Matte White 4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.) B30-R4300

Self-extinguishing polyvinylﬂuoride (B-787 gloss white)

S3000, S3100, i3300, BBP35, BBP37

Fig. 3 B30C-4000-787 B-787

Catalog # B# Color

Clear

Gloss White

Matte White

Gloss White

Label Width A Inch (mm)

0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

2.750 (69.9) 1.250 (31.8) 1 1000 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.) B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R4300

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R4300

3.000 (76.2) 2.000 (50.8) 1 500 B30-R4300

4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.) B30-R4300

0.900 (22.9) 0.500 (12.7) 1 1500 B30-R6000

1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000

2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

4.000 (101.6) 150 ft. (45.7 m) 1 roll (cont.) B30-R6000

4.000 (101.6) 60 ft. (18.3 m) 1 roll (cont.) B30-R6000

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Metallized Polyester Labels (B-428, B-434, B-435, B-438, B-486 and B-565)

• For product labeling, asset tracking and general industrial identiﬁcation

• Ideal for serial number plates and rating plates with name-plate quality and metal-looking ﬁnish

B-428: Service temp: -40° F to 293° F Agency approvals: B-434: Service temp: -40° F to 194° F Agency approvals: B-435: Service temp: -40° F to 194° F Agency approvals: B-438: Service temp: -40° F to 104° F Agency approvals: B-480: Service temp: -94° F to 248° F Agency approvals: B-486: Service temp: -40° F to 248° F Agency approvals: B-565: Service temp: -40° F to 240° F Agency approvals:

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure 1

Figure

Catalog # B# Color

Figure 2

Figure 3

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Standard adhesive for smooth surfaces (B-428 matte):

i3300, BBP33

i3300, BBP33 S3000, S3100, i3300,

BBP35, BBP37

Fig. 1 B33-5-428 B-428 Matte Silver 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300

Fig. 2 B33-53-428 B-428 Matte Silver 2.000 (50.8) 0.500 (12.7) 1 2500 B30-R4300

Fig. 2 B33-17-428 B-428 Matte Silver 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R4300

Fig. 2 B33-18-428 B-428 Matte Silver 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R4300

Fig. 2 B33-19-428 B-428 Matte Silver 3.000 (76.2) 2.000 (50.8) 1 500 B30-R4300

Fig. 3 B33C-3000-428 B-428 Matte Silver 3.000 (76.2) 85 ft. (25.9m)

Fig. 3

B30C-4000-428

B-428 Matte Silver

4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.)

1 roll (cont.)

B30-R4300

Standard adhesive for smooth surfaces (B-565 matte):

All* Fig. 3 B30C-1125-565-SL B-565 Matte Silver

All* Fig. 3 B30C-2250-565-SL B-565 Matte Silver All*

Fig. 3 B30C-4000-565-SL B-565 Matte Silver

1.125 (28.6) 100 ft. (30.5m) 1 roll (cont.)

2.250 (57.5) 100 ft. (30.5m) 1 roll (cont.)

4.000 (101.6) 100 ft. (30.5m) 1 roll (cont.)

B30-R4300

B30-R4300 B30-R4300

Standard adhesive for smooth surfaces (B-435 gloss):

i3300, BBP33

Fig. 2 B33-18-435 B-435 Gloss Silver 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

Fig. 2 B33-19-435 B-435 Gloss Silver 3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

Fig. 2 B33-55-435 B-435 Gloss Silver 4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

Stronger adhesive for rougher surfaces (B-434 gloss):

i3300, BBP33

i3300, BBP33 S3000, S3100, i3300,

BBP35, BBP37

Fig. 1 B33-5-434 B-434 Gloss Silver 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000

Fig. 2 B33-136-434 B-434 Gloss Silver 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000

Fig. 2 B33-17-434 B-434 Gloss Silver 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

Fig. 2 B33-18-434 B-434 Gloss Silver 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000

Fig. 2 B33-19-434 B-434 Gloss Silver 3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000

Fig. 2 B33-55-434 B-434 Gloss Silver 4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

Fig. 3 B30C-4000-434 B-434 Gloss Silver

4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.)

B30-R6000

Ultra-aggressive adhesive with metallic looking ﬁnish (B-480 satin):

S3000, S3100, i3300, BBP35, BBP37

Fig. 3 B30C-4000-480 B-480 Light Gray

4.000 (101.6) 115 ft. (35.1 m) 1 roll (cont.)

B30-R6000

Ultra-aggressive adhesive for highly textured, powder coated and low surface energy surfaces (B-486 matte):

i3300, BBP33

i3300, BBP33 S3000, S3100, i3300,

BBP35, BBP37

Fig. 2 B33-59-486 B-486 Matte Silver 1.000 (25.4) 0.500 (12.7) 1 2500 B30-R4300

Fig. 1 B33-5-486 B-486 Matte Silver 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300

Fig. 2 B33-53-486 B-486 Matte Silver 2.000 (50.8) 0.500 (12.7) 1 2500 B30-R4300

Fig. 2 B33-17-486 B-486 Matte Silver 2.000 (50.8) 1.000 (25.4) 1 1300 B30-R4300

Fig. 2 B33-7-486 B-486 Matte Silver 2.750 (69.9) 1.250 (31.8) 1 1000 B30-R4300

Fig. 2 B33-18-486 B-486 Matte Silver 3.000 (76.2) 1.000 (25.4) 1 1300 B30-R4300

Fig. 2 B33-19-486 B-486 Matte Silver 3.000 (76.2) 2.000 (50.8) 1 500 B30-R4300

Fig. 2 B33-76-486 B-486 Matte Silver 4.000 (101.6) 3.000 (76.2) 1 500 B30-R4300

Fig. 2 B33-161-486 B-486 Matte Silver 4.000 (101.6) 4.000 (101.6) 1 250 B30-R4300

Fig. 2 B30C-4000-486 B-486 Matte Silver 4.000 (101.6) 115 ft. (35.1 m)

1 roll (cont.)

B30-R4300

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Tamper-Evident Asset ID Labels (B-438)

Leaves checkerboard footprint on surface

and on label if removed to prevent re-use

Service temp: -40° F to 104° F Agency approvals:

Fits Printers

All* Fig. 2 B30-17-438 B-438 Matte Silver 2.000 (50.8) 1.000 (25.4) 1 1225 B30-R4300

All* Fig. 2 B30-18-438 B-438 Matte Silver 3.000 (76.2) 1.000 (25.4) 1 1225 B30-R4300

All* Fig. 2 B30-222-438 B-438 Matte Silver 3.000 (76.2) 2.000 (50.8) 1 650 B30-R4300

All* Fig. 3 B30C-3000-438-SL B-438 Matte Silver 3.000 (76.2) 100 ft. (30.5 m)

Figure

Catalog # B# Color

Paper Labels (B-424)

• Economical choice for light duty general ID

• White ﬁnish and matte topcoat

Figure 2

Label Width A Inch (mm)

Figure 3

Label Height B Inch (mm)

Labels Per Row

1 roll (cont.)

Labels Per Roll

Rec. Ribbon

B30-R4300

• Excellent contrast and smear resistance for barcode printing

Service temp: -40° F to 124° F Agency approvals:

Figure 2

Fits Printers

i3300, BBP33 Fig. 2 B33-53-424 B-424 White 2.000 (50.8) 0.500 (12.7) 1 2500 B30-R4300 i3300, BBP33 Fig. 2 B33-17-424 B-424 White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-7-424 B-424 White 2.750 (69.9) 1.250 (31.8) 1 1000 B30-R4300 i3300, BBP33 Fig. 2 B33-18-424 B-424 White 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-19-424 B-424 White 3.000 (76.2) 2.000 (50.8) 1 500 B30-R4300 i3300, BBP33 Fig. 2 B33-20-424 B-424 White 3.000 (76.2) 5.000 (127) 1 250 B30-R4300 i3300, BBP33 Fig. 2 B33-55-424 B-424 White 4.000 (101.6) 2.000 (50.8) 1 750 B30-R4300 i3300, BBP33 Fig. 2 B33-25-424 B-424 White 4.000 (101.6) 6.000 (152.4) 1 350 B30-R4300 S3000, S3100, i3300,

BBP35, BBP37

Figure Catalog # B# Color

Fig. 3 B30C-4000-424 B-424 White 4.000 (101.6) 150 ft. (45.7 m) 1 roll (cont.) B30-R4300

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Polypropylene Labels (B-425)

• General labeling material for indoor use

• Outstanding chemical and solvent resistance and print performance

• Not recommended for prolonged outdoor use

Service temp: -94° F to 212° F Agency approvals:

Fits Printers

Figure Catalog # B# Color

Figure 1

Label Width A Inch (mm)

Figure 2

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted:

B30- and B33-Series Materials

Standard Polyimide Labels (B-724 and B-727)

Top- or bottom-side component ID or board ID labels that withstand the various processes, ﬂuxes and cleaning solvents encountered in the manufacture of printed circuit boards

B-727: Service temp: -94° F to 212° F

(short burst max temp: 80 sec at 572° F, 5 min at 500° F, 2 hrs at 338° F) Agency approvals:

B-724: Service temp: -94° F to 518° F

(short burst max temp: 80 sec at 626° F, 5 min at 536° F) Agency approvals:

B30 / B33 SeriesBenchtop Printers

Figure 1

Fits Printers

Standard temperature (B-727 gloss white):

i3300, BBP33 Fig. 1 B33-11-727 B-727 Gloss White 0.250 (6.35) 0.250 (6.4) 12 5000 B30-R6000

i3300, BBP33 Fig. 1 B33-38-727 B-727 Gloss White 0.375 (9.5) 0.375 (9.5) 9 5000 B30-R6000

i3300, BBP33 Fig. 1 B33-149-727 B-727 Gloss White 0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

i3300, BBP33 Fig. 1 B33-1-727 B-727 Gloss White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R6000

i3300, BBP33 Fig. 2 B33-49-727 B-727 Gloss White 0.900 (22.9) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 1 B33-2-727 B-727 Gloss White 0.900 (22.9) 0.250 (6.4) 3 5000 B30-R6000

i3300, BBP33 Fig. 2 B33-103-727 B-727 Gloss White 1.000 (25.4) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 B33-58-727 B-727 Gloss White 1.000 (25.4) 0.375 (9.5) 1 4000 B30-R6000

i3300, BBP33 Fig. 2 B33-59-727 B-727 Gloss White 1.000 (25.4) 0.500 (12.7) 1 2500 B30-R6000

i3300, BBP33 Fig. 2 B33-43-727 B-727 Gloss White 1.250 (31.8) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 B33-44-727 B-727 Gloss White 1.375 (34.9) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 B33-45-727 B-727

i3300, BBP33 Fig. 2 B33-72-727 B-727 Gloss White 1.750 (44.5) 0.250 (6.4) 1 5000 B30-R6000

S3000, S3100, i3300, BBP35, BBP37

Extremely high temperature (B-724 matte amber):

i3300, BBP33 Fig. 1 B33-149-724 B-724 Matte Amber 0.500 (12.7) 0.500 (12.7) 4 5000 B30-R4300

i3300, BBP33 Fig. 2 B33-46-724 B-724 Matte Amber 0.750 (19.1) 0.250 (6.4) 1 5000 B30-R4300

i3300, BBP33 Fig. 1 B33-1-724 B-724 Matte Amber 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R4300

i3300, BBP33 Fig. 1 B33-2-724 B-724 Matte Amber 0.900 (22.9) 0.250 (6.4) 3 5000 B30-R4300

i3300, BBP33 Fig. 2 B33-43-724 B-724 Matte Amber 1.250 (31.8) 0.250 (6.4) 1 5000 B30-R4300

i3300, BBP33 Fig. 1 B33-4-724 B-724 Matte Amber 1.500 (38.1) 0.250 (6.4) 2 5000 B30-R4300

S3000, S3100, i3300, BBP35, BBP37

Figure Catalog # B# Color

Fig. 3 B30C-4000-727 B-727 Gloss White 4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.) B30-R6000

Fig. 3 B30C-4000-724 B-724 Matte Amber 4.000 (101.6) 130 ft. (39.6 m) 1 roll (cont.) B30-R4300

Figure 2

Gloss White 1.500 (38.1) 0.250 (6.4) 1 5000 B30-R6000

Figure 3

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Compatible with BBP37 XY cutter.

B30- and B33-Series Materials

Static Dissipative Polyimide Labels (B-717, B-718 and B-719)

• Circuit board and electronic component identiﬁcation with static dissipative adhesive and release liner with surface resistivity values recommended for dissipative ESD packaging

• Complies with EIA-541 packaging material standards for ESD sensitive items

• For top- or bottom-side component or board identiﬁcation

Service temp: -94° F to 212° F (short burst max temp: 80 sec at 572° F, 5 min at 500° F, 2 hrs at 338° F) Agency approvals:

Figure 1

Fits Printers

Standard thickness (B-717 gloss white):

i3300, BBP33 Fig. 2 * B33-46-717 B-717 Gloss White 0.750 (19.1) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-103-717 B-717 Gloss White 1.000 (25.4) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-43-717 B-717 Gloss White 1.250 (31.8) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-45-717 B-717 Gloss White 1.500 (38.1) 0.250 (6.4) 1 5000 B30-R6000

Low-proﬁle label (B-718 gloss white):

i3300, BBP33 Fig. 4 * B33-11-718 B-718 Gloss White 0.250 (6.4) 0.250 (6.4) 12 1500 B30-R6000

i3300, BBP33 Fig. 1 * B33-38-718 B-718 Gloss White 0.375 (9.5) 0.375 (9.5) 9 5000 B30-R6000

i3300, BBP33 Fig. 1 * B33-149-718 B-718 Gloss White 0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000

i3300, BBP33 Fig. 1 * B33-1-718 B-718 Gloss White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-46-718 B-718 Gloss White 0.750 (19.1) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-49-718 B-718 Gloss White 0.900 (22.9) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2

i3300, BBP33 Fig. 2 * B33-45-718 B-718 Gloss White 1.500 (38.1) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-72-718 B-718 Gloss White 1.750 (44.5) 0.250 (6.4) 1 5000 B30-R6000

Low-proﬁle label to prevent sticking of solder balls (B-719 matte white):

i3300, BBP33 Fig. 1 * B33-38-719 B-719 Matte White 0.375 (9.5) 0.375 (9.5) 9 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-46-719 B-719 Matte White 0.750 (19.1) 0.250 (6.4) 1 5000 B30-R6000

i3300, BBP33 Fig. 1 * B33-2-719 B-719 Matte White 0.900 (22.9) 0.250 (6.4) 3 5000 B30-R6000

i3300, BBP33 Fig. 2 * B33-43-719 B-719 Matte White 1.250 (31.8) 0.250 (6.4) 1 5000 B30-R6000

Figure Catalog # B# Color

* B33-43-718 B-718 Gloss White 1.250 (31.8) 0.250 (6.4) 1 5000 B30-R6000

Figure 2

Label Width A Inch (mm)

Figure 4

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

Compatible with BBP37 XY cutter.

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Panel ID Labels (B-483, B-484A, B-499, B-593 and B-595)

• Various sizes in several durable material types

• Also ideal for marking backer board, DIN rail, relays, PLCs, switches, solenoids, drive motors and other components inside panels

• All recommended materials are ﬂexible and have high-tack adhesives for adhesion to wide variety of surfaces and components

B-483: Service temp: -40° F to 248° F Agency approvals: B-484A: Service temp: -40° F to 240° F Agency approvals: B-499: Service temp: -40° F to 193° F Agency approvals: B-593: Service temp: -4° F to 212° F B-595: Service temp: -40° F to 180° F Agency approvals:

HEADERDER

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure 1

Figure 2

Figure Catalog # B# Color

Figure 3

Label Width A Inch (mm)

Label Height B Inch (mm)

Figure 18c

Labels Per Row

Labels Per Roll

Figure 70

Rec. Ribbon

Nylon cloth with permanent adhesive (B-499):

i3300, BBP33 Fig. 1 B33-68-499 B-499 White 0.500 (12.7) 0.750 (19.1) 4 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-165-499 B-499 White 0.800 (20.3) 1.437 (36.5) 4 2500 B30-R6000 i3300, BBP33 Fig. 2 B33-125-499 B-499 White 0.900 (22.9) 0.500 (12.7) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-126-499 B-499 White 0.900 (22.9) 0.500 (12.7) 2 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-163-499 B-499 White 1.000 (25.4) 0.375 (9.5) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-152-499 B-499 White 1.000 (25.4) 0.375 (9.5) 2 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-136-499 B-499 White 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-137-499 B-499 White 2.000 (50.8) 1.000 (25.4) 1 1100 B30-R6000 i3300, BBP33 Fig. 2 B33-125-499 B-499 White 2.000 (50.8) 0.250 (6.4) 1 1500 B30-R6000

Polyester with ultra-aggressive adhesive for highly textured and low surface energy surfaces (B-483):

i3300, BBP33 Fig. 1 B33-149-483 B-483 White 0.500 (12.7) 0.500 (12.7) 4 5000 B30-R6000 i3300, BBP33 Fig. 1 B33-5-483 B-483 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6000 i3300, BBP33 Fig. 2 B33-17-483 i3300, BBP33 Fig. 2 B33-7-483 B-483 White 2.750 (69.9) 1.250 (31.8) 1 1000 B30-R6000 i3300, BBP33 Fig. 2 B33-18-483 B-483 White 3.000 (76.2) 1.000 (25.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-19-483 B-483 White 3.000 (76.2) 2.000 (50.8) 1 500 B30-R6000 i3300, BBP33 Fig. 2 B33-55-483 B-483 White 4.000 (101.6) 2.000 (50.8) 1 750 B30-R6000

B-483 White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R6000

Polyester with ultra-aggressive adhesive and pliable for conforming to angular surfaces (B-484A):

Raised proﬁle polyester with ultra-agressive adhesive (B-593):

All* Fig. 18c B30EP-171-593-WT B-593 White 0.490 (12.5) 1.060 (26.9) 1 500 B30-R6000 All* Fig. 18c B30EP-171-593-BK B-593 Black 0.490 (12.5) 1.060 (26.9) 1 500 B30-R6000

Pre-printed vinyl with permanent adhesive and is conformable and indoor / outdoor grade (b-595):

All* Fig. 70 B30-241-595-ANSIDA B-595 2.250 (57.5) 3.000 (76.2) 1 300 B30-R10000

All* Fig. 70 B30-25-595-ANSIDA B-595 4.000 (101.6) 6.000 (152.4) 1 175 B30-R10000

All* Fig. 70 B30-241-595-ANSIWA B-595

All* Fig. 70 B30-25-595-ANSIWA B-595 4.000 (101.6) 6.000 (152.4) 1 175 B30-R10000

2.250 (57.5) 3.000 (76.2) 1 300 B30-R10000

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Self-Laminating Wire and Cable Labels (B-427)

• Brady’s most popular wire marker

• Features white printable area with clear tail that wraps around marker to protect text

• Superior resistance to abrasion, handling, solvents, water, oil and dirt

• Vinyl with permanent acrylic adhesive designed speciﬁcally for tightly curved surfaces

Service temp: -40° F to 158° F Agency approvals:

Figure 9a

Fits Printers

i3300, BBP33 Fig. 12 B33-80-427 B-427 White 0.500 (12.7) 0.750 (19.1) 0.375 (9.5) 4 2500 B30-R4300 i3300, BBP33 Fig. 12 B33-113-427 B-427 White 0.500 (12.7) 1.000 (25.4) 0.375 (9.5) 4 2500 B30-R4300 i3300, BBP33 Fig. 12 B33-8-427 B-427 White 0.500 (12.7) 1.437 (36.5) 0.500 (12.7) 5 5000 B30-R4300 i3300, BBP33 Fig. 12 B33-56-427 B-427 White 0.750 (19.1) 0.937 (23.8) 0.375 (9.5) 4 5000 B30-R4300 i3300, BBP33 Fig. 12 B33-73-427 B-427 White 0.750 (19.1) 1.750 (44.6) 0.500 (12.7) 4 3500 B30-R4300 i3300, BBP33 Fig. 12 B33-74-427 B-427 White 0.800 (20.3) 1.437 (36.5) 0.500 (12.7) 4 4000 B30-R4300 i3300, BBP33 Fig. 12 B33-115-427 B-427 White 1.000 (25.4) 0.750 (19.1) 0.375 (9.5) 2 2500 B30-R4300 i3300, BBP33 Fig. 12 B33-116-427 B-427 White 1.000 (25.4) 1.000 (25.4) 0.375 (9.5) 2 2500 B30-R4300 i3300, BBP33 Fig. 12 B33-9-427 B-427 White 1.000 (25.4) 1.437 (36.5) 0.500 (12.7) 3 2500 B30-R4300 i3300, BBP33 Fig. 12 B33-75-427 B-427 White 1.000 (25.4) 2.250 (57.2) 0.750 (19.1) 2 1400 B30-R4300 i3300, BBP33 Fig. 15 B33-131-427 i3300, BBP33 Fig. 12 B33-10-427 B-427 White 1.000 (25.4) 3.750 (95.3) 1.000 (25.4) 3 1200 B30-R4300 i3300, BBP33 Fig. 12 B33-81-427 B-427 White 1.000 (25.4) 6.000 (152.4) 1.500 (38.1) 2 500 B30-R4300 i3300, BBP33 Fig. 9a* B33-135-427AW B-427 All White* 1.500 (38.1) 0.750 (19.1) - 1 1500 B30-R4300 i3300, BBP33 Fig. 14 B33-118-427 B-427 White 1.500 (38.1) 1.000 (25.4) 0.375 (9.5) 1 1250 B30-R4300 i3300, BBP33 Fig. 14 B33-119-427 B-427 White 1.500 (38.1) 1.500 (38.1) 0.500 (12.7) 1 1000 B30-R4300 i3300, BBP33 Fig. 14 B33-272-427 B-427 White 1.500 (38.1) 2.250 (57.2) 0.750 (19.1) 1 700 B30-R4300 i3300, BBP33 Fig. 14 B33-120-427 B-427 White 1.750 (44.5) 1.000 (25.4) 0.375 (9.5) 1 1250 B30-R4300 i3300, BBP33 Fig. 14 B33-121-427 B-427 White 1.750 (44.5) 1.500 (38.1) 0.500 (12.7) 1 1000 B30-R4300 i3300, BBP33 Fig. 14 B33-273-427 B-427 White 1.750 (44.5) 2.250 (57.2) 0.750 (19.1) 1 500 B30-R4300 i3300, BBP33 Fig. 9a* B33-137-427AW B-427 All White* 2.000 (50.8) 1.000 (25.4) - 1 1500 B30-R4300 i3300, BBP33 Fig. 14 B33-27-427 B-427 White 2.000 (50.8) 3.750 (95.3) 1.000 (25.4) 1 400 B30-R4300 i3300, BBP33 Fig. 14 B33-26-427 B-427 White i3300, BBP33 Fig. 14 B33-82-427 B-427 White 2.000 (50.8) 6.000 (152.4) 1.500 (38.1) 1 200 B30-R4300

* Label is all white and does not have a clear over-laminate.

Figure Catalog # B# Color

B-427 White 1.000 (25.4) 2.625 (66.7) 1.000 (25.4) 1 1500 B30-R4300

Figure 12

Label Width A Inch (mm)

2.500 (63.5) 2.250 (57.2) 0.750 (19.1) 1 500 B30-R4300

Figure 14

Label Height B Inch (mm)

Figure 15

Print Area Height F Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Zero-Halogen Cable Markers (B-7643)

Thermoplastic polyether polyurethane is a zero-halogen high-density, thermoplastic cable marker designed for dot matrix or thermal-transfer printing.

• Meets the requirements of a halogen-free material per IEC 61249-2-21 (2003-11)

• Excellent chemical, oil and water resistance

Service temp: -40° F to 193° F (-40° C to 90° C) Agency approvals:

Fits Printers

i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

Figure

Fig. 61 Fig. 61 Fig. 61 Fig. 61 Fig. 61 Fig. 61 Fig. 61 Fig. 61

Catalog # B# Color

B33-6010-7643-WT B-7643 White 2.36 (60) 0.39 (9.91) 500 B30-R6000 B33-7525-7643-WT B-7643 White 2.95 (75) 0.98 (24.9) 250 B30-R6000 B33-7510-7643-WT B-7643 White 2.95 (75) 0.39 (9.91) 500 B30-R6000 B33-7515-7643-WT B-7643 White 2.95 (75) 0.59 (14.9) 500 B30-R6000 B33-6010-7643-YL B-7643 Yellow 2.36 (60) 0.39 (9.91) 500 B30-R6000 B33-7525-7643-YL B-7643 Yellow 2.95 (75) 0.98 (24.9) 250 B30-R6000 B33-7510-7643-YL B-7643 Yellow 2.95 (75) 0.39 (9.91) 500 B30-R6000 B33-7515-7643-YL B-7643 Yellow 2.95 (75) 0.59 (14.9) 500 B30-R6000

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Figure 61

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

High-Temp Adhesive Topcoated Polyvinyuoride Wire and Cable Labels (B-437)

• Topcoated polyvinyﬂuoride label for wire and cable marking where high temperature and self-extinguishing features are required

• Heavy-duty performance with excellent resistance to water, oil and ﬂuids

• Meets MIL-M-87958 Standard

Service temp: -94° F to 275° F Agency spprovals:

Also available in self-laminating format. Contact Brady to order custom B-642 material and B30-R4300 ribbon.

Figure 1

Figure 3

Figure 4

B30 / B33 SeriesBenchtop Printers

Fits Printers

i3300, BBP33 Fig. 4 B33-11-437 B-437 White 0.250 (6.4) 0.250 (6.4) 12 15000 B30-R4300 i3300, BBP33 Fig. 1 B33-1-437 B-437 White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-2-437 B-437 White 0.900 (22.9) 0.250 (6.4) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-5-437 B-437 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-29-437 B-437 White 1.250 (31.8) 0.375 (9.5) 2 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-5-437YL B-437 Yellow 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-29-437YL B-437 Yellow 1.250 (31.8) 0.375 (9.5) 2 5000 B30-R4300

Continuous Rolls:

i3300, BBP33 Fig. 3 B33C-1000-437 B-437 White 1.000 (25.4) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-1500-437 B-437 White 1.500 (38.1) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-2000-437 B-437 White 2.000 (50.8) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-3000-437 B-437 White 3.000 (76.2) 85 ft. (25.9m) 1 roll (cont.) B30-R4300

S3000, S3100, i3300, BBP35, BBP37

i3300, BBP33 Fig. 3 B33C-1000-437YL B-437 Yellow 1.000 (25.4) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-1500-437YL B-437 Yellow 1.500 (38.1) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-2000-437YL B-437 Yellow 2.000 (50.8) 85 ft. (25.9m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-3000-437YL B-437 Yellow 3.000 (76.2) 85 ft. (25.9m) 1 roll (cont.) B30-R4300

Figure Catalog # B# Color

Fig. 3 B30C-4000-437 B-437 White 4.000 (101.6) 150 ft. (45.7 m) 1 roll (cont.) B30-R4300

Label Width A Inch (mm)

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Vinyl Cloth Adhesive Wire and Cable Labels (B-498)

• A vinyl cloth label for marking wires, cables and inside-panel components

• Repositionable — a highly unique adhesive and cloth construction gives excellent holding power and still allows for clean removal and reapplication

• Ideal choice for marking both ends of a wire that you may need to cut shorter before ﬁnal termination

Service temp: -40° F to 175° F Agency approvals:

Figure 1

Fits Printers

i3300, BBP33 Fig. 1 B33-90-498 B-498 White 0.250 (6.4) 1.437 (36.5) 6 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-68-498 B-498 White 0.500 (12.7) 0.750 (19.1) 4 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-87-498 B-498 White 0.500 (12.7) 1.437 (36.5) 6 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-1-498 B-498 White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-91-498 B-498 White 0.750 (19.1) 0.937 (23.8) 4 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-95-498 B-498 White 0.800 (20.3) 1.437 (36.5) 3 2300 B30-R6200 i3300, BBP33 Fig. 1 B33-5-498 B-498 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R6200 i3300, BBP33 Fig. 1 B33-88-498 B-498 White 1.000 (25.4) 0.750 (19.1) 2 2500 B30-R6200 i3300, BBP33 Fig. 1 B33-89-498 B-498 White 1.000 (25.4) 1.437 (36.5) 3 2300 B30-R6200

Figure Catalog # B# Color

BradyPrinter S3000, S3100, i3300, BBP

Label Width A Inch (mm)

*All supplies listed are compatible with the following printers unless otherwise noted:

Label Height B Inch (mm)

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Labels Per Row

Labels Per Roll

Compatible with BBP37 XY cutter.

Rec. Ribbon

B30- and B33-Series Materials

High-Temp Adhesive Polyimide Wire and Cable Labels (B-472)

• Top-coated polyimide label for wire and cable marking applications where high temperature and self-extinguishing features are required

• Heavy-duty performance with excellent resistance to water, oil and other ﬂuids

Service temp: -94° F to 320° F Agency approvals:

Figure 1

Fits Printers

i3300, BBP33 Fig. 4 B33-11-472 B-472 White 0.250 (6.4) 0.250 (6.4) 12 15000 B30-R4300 i3300, BBP33 Fig. 1 B33-1-472 B-472 White 0.750 (19.1) 0.250 (6.4) 4 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-2-472 B-472 White 0.900 (22.9) 0.250 (6.4) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-5-472 B-472 White 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-29-472 B-472 White 1.250 (31.8) 0.375 (9.5) 2 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-5-472YL B-472 Yellow 1.000 (25.4) 0.500 (12.7) 3 5000 B30-R4300 i3300, BBP33 Fig. 1 B33-29-472YL B-472 Yellow 1.250 (31.8) 0.375 (9.5) 2 5000 B30-R4300

Continuous Rolls:

i3300, BBP33 Fig. 3 B33C-1000-472 B-472 White 1.000 (25.4) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-1500-472 B-472 White 1.500 (38.1) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-2000-472 B-472 White 2.000 (50.8) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-3000-472 B-472 White 3.000 (76.2) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-1000-472YL B-472 Yellow 1.000 (25.4) 85 ft. (25.9 m) 1 roll (cont.) i3300, BBP33 Fig. 3 B33C-1500-472YL B-472 Yellow 1.500 (38.1) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-2000-472YL B-472 Yellow 2.000 (50.8) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300 i3300, BBP33 Fig. 3 B33C-3000-472YL B-472 Yellow 3.000 (76.2) 85 ft. (25.9 m) 1 roll (cont.) B30-R4300

Figure Catalog # B# Color

Figure 3

Label Width A Inch (mm)

Figure 4

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30-R4300

Terminal Block Adhesive Strips (B-498)

• Specially designed narrow-width continuous label for alignment on terminal blocks and patch panels

• Highly unique adhesive and vinyl cloth construction gives excellent holding power and still allows for clean removal and reapplication

Service temp: -40° F to 175° F Agency approvals:

Figure 3

Fits Printers

i3300, BBP33 Fig. 3 B33C-312-498 B-498 White 0.312 (7.9) 85 (25.9) 1 roll (cont.) B30-R6200 i3300, BBP33 Fig. 3 B33C-375-498 B-498 White 0.375 (9.5) 85 (25.9) 1 roll (cont.) B30-R6200

Figure Catalog # B# Color

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

Patch Panel Adhesive Strips (B-422)

• Continuous supply makes labeling patch panels and other datacomm components quick and easy

• Aggressive adhesive suitable for rough, highly-textured and powder-coated surfaces as well as smooth surfaces

Service temp: -40° F to 212° F Agency approvals:

Fits Printers

i3300, BBP33 Fig. 3 B33C-312-422 B-422 White 0.312 (7.9) 85 (25.9) 1 roll (cont.) B30-R6000 i3300, BBP33 Fig. 3 B33C-375-422 B-422 White 0.375 (9.5) 85 (25.9) 1 roll (cont.) B30-R6000

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

Figure Catalog # B# Color

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Label Width A Inch (mm)

Figure 3

Roll Length B Feet (m)

B30 / B33 Series Benchtop Printers

Labels Per Roll

Rec. Ribbon

B30- and B33-Series Materials

PermaSleeve® PS Polyolen Wire Markers (B-342)

Military / industrial grade sleeves offer the ultimate in marker durability, permanence and aesthetic appearance. 3:1 heat-shrinkable markers ﬁt snugly around wires, are fade-resistant and ﬂame-retardant.

Meets specications:

• SSAE-AS-23053/5

• SAE-AS-81531

Service temp: -40° F to 275° F (short burst max temp: 5 min at 500° F, 24 hrs at 350° F) Agency approvals:

Tested per:

• ASTM E162

• ASTM E662

• MIL-STD-202

Figure 20

(Ø diameter)

Figure 20-2

(perforated)

(Ø diameter)

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure Catalog # Material

For Wire Gauge (approx.)

Range For Wire Diameters Inch (mm)

Supplied Diameter B Inch (mm)

Recovered Diameter Inch (mm)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

Rec. Ribbon

3:1 Shrink ratio, single-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 * B33-94-2-342 B-342

i3300, BBP33 Fig. 20 * B33-125-2-342 B-342

i3300, BBP33 Fig. 20 * B33-187-2-342 B-342

i3300, BBP33 Fig. 20 * B33-250-2-342 B-342

i3300, BBP33 Fig. 20 * B33-375-2-342 B-342

i3300, BBP33 Fig. 20 * B33-500-2-342 B-342

i3300, BBP33 Fig. 20 * B33-750-2-342 B-342

i3300, BBP33 Fig. 20 * B33-1000-2-342 B-342

i3300, BBP33 Fig. 20 * B33-1500-2-342 B-342

i3300, BBP33 Fig. 20 * B33-94-2-342YL

i3300, BBP33 Fig. 20 * B33-125-2-342YL B-342 Ylw. 22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 1000 B30-R4300

i3300, BBP33 Fig. 20 * B33-187-2-342YL B-342 Ylw. 20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 1 750 B30-R4300

i3300, BBP33 Fig. 20 * B33-250-2-342YL B-342 Ylw. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

i3300, BBP33 Fig. 20 * B33-375-2-342YL B-342 Ylw. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

i3300, BBP33 Fig. 20 * B33-500-2-342YL B-342 Ylw. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.187 (4.7) .025 (0.6) +/- .003 (0.07) 1 350 B30-R4300

i3300, BBP33 Fig. 20 * B33-750-2-342YL B-342 Ylw. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.0) 0.250 (6.4) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300

i3300, BBP33 Fig. 20 * B33-1000-2-342YL B-342 Ylw. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 1 250 B30-R4300

i3300, BBP33 Fig. 20 * B33-1500-2-342YL B-342 Ylw. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1 150 B30-R4300

i3300, BBP33 Fig. 20 * B33-1500-2-342BK B-342 Blk. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1

Wt.

28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 1 1000 B30-R4300

Wt.

22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 1000 B30-R4300

Wt.

20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 1 750 B30-R4300

Wt.

16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

Wt.

12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

Wt.

8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.187 (4.7) .025 (0.6) +/- .003 (0.07) 1 350 B30-R4300

Wt.

6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.0) 0.250 (6.4) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300

Wt.

2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 1 250 B30-R4300

Wt.

n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1 150 B30-R4300

B-342 Ylw. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 1 1000 B30-R4300

150 B30-R4500-SV

3:1 Shrink ratio, single-side printable, perforated material resulting in two 1 inch width sleeves (dimension A):

i3300, BBP33 Fig. 20-2 * B33-94-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-125-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-187-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-250-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-375-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-500-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-750-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-1000-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-1500-2-342-2 B-342

i3300, BBP33 Fig. 20-2 * B33-94-2-342YL-2 B-342

i3300, BBP33 Fig. 20-2 * B33-125-2-342YL-2 B-342 Ylw. 22 to 16 0.046 (1.2) - 0.111 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 2 2000 B30-R4300

i3300, BBP33 Fig. 20-2 * B33-750-2-342YL-2 B-342 Ylw. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.1) 0.250 (6.35) .025 (0.6) +/- .003 (0.07) 2 500 B30-R4300

i3300, BBP33 Fig. 20-2 * B33-500-2-342YL-2 B-342 Ylw. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.119 (3.0) .025 (0.6) +/- .003 (0.07) 2 700 B30-R4300

i3300, BBP33 Fig. 20-2 * B33-1000-2-342YL-2 B-342 Ylw. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 2 500 B30-R4300

i3300, BBP33 Fig. 20-2 * B33-1500-2-342YL-2 B-342 Ylw. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 2 300 B30-R4300

Wt.

28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 2 2000 B30-R4300

Wt.

22 to 16 0.046 (1.2) - 0.111 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 2 2000 B30-R4300

Wt.

20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 2 1500 B30-R4300

Wt.

16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 2 1000 B30-R4300

Wt.

12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 2 1000 B30-R4300

Wt.

8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.119 (3.0) .025 (0.6) +/- .003 (0.07) 2 700 B30-R4300

Wt.

6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.1) 0.250 (6.35) .025 (0.6) +/- .003 (0.07) 2 500 B30-R4300

Wt.

2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 2 500 B30-R4300

Wt.

n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 2 150 B30-R4300

Ylw. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 2 2000 B30-R4300

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

B-342 PermaSleeve® PS Polyolen Wire Markers (continued)

Fits Printers

3:1 Shrink ratio, double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 * B33D-94-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-125-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-125-2-342-2 B-342

i3300, BBP33 Fig. 20 * B33D-187-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-250-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-375-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-500-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-750-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-1000-2-342 B-342

i3300, BBP33 Fig. 20 * B33D-1500-2-342

i3300, BBP33 Fig. 20 * B33D-94-2-342YL B-342 Ylw. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 1 1000 B30-R4300

i3300, BBP33 Fig. 20 * B33D-125-2-342YL B-342 Ylw. 22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 1000 B30-R4300

i3300, BBP33 Fig. 20 * B33D-187-2-342YL B-342 Ylw. 20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 1 750 B30-R4300

i3300, BBP33 Fig. 20 * B33D-250-2-342YL B-342 Ylw. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

i3300, BBP33 Fig. 20 * B33D-375-2-342YL B-342 Ylw. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

i3300, BBP33 Fig. 20 * B33D-500-2-342YL B-342 Ylw. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.187 (4.7) .025 (0.6) +/- .003 (0.07) 1 350 B30-R4300

i3300, BBP33 Fig. 20 * B33D-750-2-342YL B-342 Ylw. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.0) 0.250 (6.4) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300

i3300, BBP33 Fig. 20 * B33D-1000-2-342YL B-342 Ylw. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 1 250 B30-R4300

i3300, BBP33 Fig. 20 * B33D-1500-2-342YL B-342 Ylw. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1

i3300, BBP33 Fig. 20 * B33D-94-2-342BK B-342 Blk. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 1 1000 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-125-2-342BK B-342 Blk. 22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 1000 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-187-2-342BK B-342 Blk. 20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 1 750 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-250-2-342BK B-342 Blk. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-375-2-342BK B-342 Blk. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-500-2-342BK B-342 Blk. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.187 (4.7) .025 (0.6) +/- .003 (0.07) 1 350 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-750-2-342BK B-342 Blk. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.0) 0.250 (6.4) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-1000-2-342BK B-342 Blk. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 1 250 B30-R4500-SV

i3300, BBP33 Fig. 20 * B33D-1500-2-342BK B-342 Blk. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1 150 B30-R4500-SV

Figure Catalog # Material

B-342

For Wire Gauge (approx.)

Wt.

28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) .024 (0.6) +/- .003 (0.07) 1 1000 B30-R4300

Wt.

22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 1000 B30-R4300

Wt.

22 to 16 0.046 (1.2) - 1.110 (2.8) 0.125 (3.2) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 2 2000 B30-R4300

Wt.

20 to 10 0.062 (1.6) - 0.150 (3.8) 0.187 (4.7) 0.062 (1.6) .020 (0.5) +/- .003 (0.07) 1 750 B30-R4300

Wt.

16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.4) 0.093 (2.4) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

Wt.

12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.1) .025 (0.6) +/- .003 (0.07) 1 500 B30-R4300

Wt.

8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.187 (4.7) .025 (0.6) +/- .003 (0.07) 1 350 B30-R4300

Wt.

6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.0) 0.250 (6.4) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300

Wt.

2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) .036 (0.9) +/- .003 (0.07) 1 250 B30-R4300

Wt.

n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) .035 (0.9) +/- .003 (0.07) 1 150 B30-R4300

Range For Wire Diameters Inch (mm)

Supplied Diameter B Inch (mm)

Recovered Diameter Inch (mm)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

150 B30-R4300

Rec. Ribbon

QuickSleeve Handheld Sleeve Applicator

The QuickSleeve Handheld Sleeve Applicator is an intuitive multi-tool designed to help you quickly apply sleeves on to wires in three simple steps – just pick, slip and apply. This tool includes:

• Four specially designed slanted tubes sized for sleeve sizes

0.094, 0.125, 0.187 and 0.250 inches

• Built-in LED ﬂashlight for use in low-lit conditions

• Terminal block sized screwdriver

Catalog # Description Qty.

QS Quicksleeve Multi-Tool 1 Set

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30 / B33 Series Benchtop Printers

Slip ApplyPick

B30- and B33-Series Materials

PermaSleeve® HT High-Temperature PVDF Wire Markers (B-345)

Military / industrial grade 2:1 heat shrinkable sleeves speciﬁcally designed for high-temperature and low-vacuum outgassing applications. Irradiated high-temp polyvinylidene ﬂuoride (PVDF) is fade-resistant and ﬂame-retardant.

Meets specications:

• NASA SP-R-0022A Outgassing Performance

• SAE-AS-81531

Service temp: -67° F to 437° F Agency approvals:

Tested per:

• ASTM E162

• ASTM E662

• MIL-STD-202

Figure 20

(Ø diameter)

B30 / B33 SeriesBenchtop Printers

Fits Printers

3:1 Shrink ratio, double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 B33D-94-2-345 B-345

i3300, BBP33 Fig. 20 B33D-94-2-345BK B-345 Blk. 26 to 20 0.031 (0.8) - 0.080 (2.0) 0.094 (2.4) 0.031 (0.8) .015 (0.4) +/- .003 (0.07) 1 1000 B30-R4400-WT

2:1 Shrink ratio, double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 B33D-125-2-345 B-345

i3300, BBP33 Fig. 20 B33D-187-2-345 B-345

i3300, BBP33 Fig. 20 B33D-250-2-345 B-345

i3300, BBP33 Fig. 20 B33D-375-2-345 B-345

i3300, BBP33 Fig. 20 B33D-500-2-345 B-345

i3300, BBP33 Fig. 20 B33D-750-2-345 B-345

i3300, BBP33 Fig. 20 B33D-1000-2-345 B-345

i3300, BBP33 Fig. 20 B33D-1500-2-345 B-345

i3300, BBP33 Fig. 20 B33D-125-2-345BK B-345 Blk. 20 to 16 0.063 (1.6) - 0.110 (2.8) 0.125 (3.2) 0.062 (1.6) .015 (0.4) +/- .003 (0.07) 1 1000 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-187-2-345BK B-345 Blk. 16 to 10 0.094 (2.4) - 0.150 (3.8) 0.187 (4.7) 0.093 (2.4) .015 (0.4) +/- .003 (0.07) 1 750 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-250-2-345BK B-345 Blk. 12 to 8 0.125 (3.2) - 0.215 (5.5) 0.250 (6.4) 0.125 (3.2) .015 (0.4) +/- .003 (0.07) 1 500 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-375-2-345BK B-345 Blk. 8 to 4 0.187 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.187 (4.7) .015 (0.4) +/- .003 (0.07) 1 500 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-500-2-345BK B-345 Blk. 6 to 1 0.250 (6.4) - 0.450 (11.4) 0.500 (12.7) 0.250 (6.4) .015 (0.4) +/- .003 (0.07) 1 350 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-750-2-345BK B-345 Blk. 3 to 4/0 0.375 (9.5) - 0.700 (17.8) 0.750 (19.0) 0.375 (9.5) .015 (0.4) +/- .003 (0.07) 1 250 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-1000-2-345BK B-345 Blk. 2/0 to 0.950 dia 0.450 (11.4) - 0.950 (24.1) 1.000 (25.4) 0.500 (12.7) .017 (0.4) +/- .004 (0.1) 1 250 B30-R4400-WT

i3300, BBP33 Fig. 20 B33D-1500-2-345BK B-345 Blk. N/A 0.750 (19.1) - 1.400 (35.6) 1.500 (38.1) 0.750 (19.1) .024 (0.6) +/- .004 (0.1) 1 150 B30-R4400-WT

Figure Catalog # Material

For Wire Gauge (approx.)

Wt.

26 to 20 0.031 (0.8) - 0.080 (2.0) 0.094 (2.4) 0.031 (0.8) .015 (0.4) +/- .003 (0.07) 1 1000 B30-R6000

Wt.

20 to 16 0.063 (1.6) - 0.110 (2.8) 0.125 (3.2) 0.062 (1.6) .015 (0.4) +/- .003 (0.07) 1 1000 B30-R6000

16 to 10 0.094 (2.4) - 0.150 (3.8) 0.187 (4.7) 0.093 (2.4) .015 (0.4) +/- .003 (0.07) 1 750 B30-R6000

Wt.

12 to 8 0.125 (3.2) - 0.215 (5.5) 0.250 (6.4) 0.125 (3.2) .015 (0.4) +/- .003 (0.07) 1 500 B30-R6000

Wt.

8 to 4 0.187 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.187 (4.7) .015 (0.4) +/- .003 (0.07) 1 500 B30-R6000

Wt.

6 to 1 0.250 (6.4) - 0.450 (11.4) 0.500 (12.7) 0.250 (6.4) .015 (0.4) +/- .003 (0.07) 1 350 B30-R6000

Wt.

2 to 4/0 0.375 (9.5) - 0.700 (17.8) 0.750 (19.0) 0.375 (9.5) .015 (0.4) +/- .003 (0.07) 1 250 B30-R6000

Wt.

2/0 to 0.950 dia 0.450 (11.4) - 0.950 (24.1) 1.000 (25.4) 0.500 (12.7) .017 (0.4) +/- .004 (0.1) 1 250 B30-R6000

Wt.

N/A 0.750 (19.1) - 1.400 (35.6) 1.500 (38.1) 0.750 (19.1) .024 (0.6) +/- .004 (0.1) 1 150 B30-R6000

Range For Wire Diameters Inch (mm)

Supplied Diameter B Inch (mm)

Recovered Diameter Inch (mm)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

Rec. Ribbon

Print double-sided wire sleeves with the BradyPrinter i3300 Industrial Label Printer

You can quickly create double-sided sleeve by using “B33D-” parts and Brady Workstation’s two-sided print feature.

Once the ﬁrst side of your print job is complete, the software prompts you to cut the media and re-insert it for a second print pass.

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

PermaSleeve® HX Polyolen Wire Markers (B-7642)

Military / industrial 2:1 heat-shrinkable sleeves are ﬂame-retardant and high-temperature rated but not as high-temperature as B-345 HT sleeves.

Meets specications:

• SAE-AS23053/5

• SAE-AS-81531

Service temp: -40° F to 248° F (short burst max temp: 5 min at 464° F, 24 hrs at 320° F) Agency approval:

Fits Printers

2:1 Shrink ratio, single-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33

2:1 Shrink ratio, double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33 i3300, BBP33

Figure Catalog # Material

Fig. 20 B33-94-2-7642 B-7642 Wt. 24 to 20 0.047 (1.2) - 0.080 (2.0) 0.094 (2.4) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 500 B30-R4300 Fig. 20 B33-125-2-7642 B-7642 Wt. 20 to 16 0.062 (1.6) - 0.110 (2.8) 0.125 (3.2) 0.063 (1.6) .020 (0.5) +/- .003 (0.07) 1 500 B30-R4300 Fig. 20 B33-187-2-7642 B-7642 Wt. 16 to 10 0.094 (2.4) - 0.151 (3.8) 0.187 (4.8) 0.094 (2.4) .020 (0.5) +/- .003 (0.07) 1 450 B30-R4300 Fig. 20 B33-250-2-7642 B-7642 Wt. 12 to 8 0.125 (3.2) - 0.215 (5.5) 0.250 (6.4) 0.126 (3.2) .025 (0.6) +/- .003 (0.07) 1 400 B30-R4300 Fig. 20 B33-375-2-7642 B-7642 Wt. 8 to 4 0.188 (4.8) - .0320 (8.1) 0.375 (9.5) 0.189 (4.8) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300 Fig. 20 B33-500-2-7642 B-7642 Wt. 6 to 1 0.250 (6.4) - 0.450 (11.4) 0.500 (12.7) 0.252 (6.4) .025 (0.6) +/- .003 (0.07) 1 225 B30-R4300 Fig. 20 B33-750-2-7642 B-7642 Wt. 2 to 4/0 0.375 (9.5) - 0.700 (17.8) 0.750 (19.0) 0.374 (9.5) .030 (0.8) +/- .003 (0.07) 1 150 B30-R4300 Fig. 20 B33-1000-2-7642 B-7642 Wt. 2/0 to 0.950 dia 0.450 (11.4) - 0.950 (24.1) 1.000 (25.4) 0.500 (12.7) .035 (0.9) +/- .005 (0.1) 1 150 B30-R4300 Fig. 20 B33-1500-2-7642 B-7642 Wt. N/A 0.750 (19.0) - 1.400 (35.6) 1.500 (38.1) 0.752 (19.1) .040 (1.0) +/- .006 (0.2) 1 50 B30-R4300 Fig. 20 B33-2000-2-7642 B-7642 Wt. N/A 1.000 (25.4) - 1.900 (48.3) 2.000 (50.8) 1.000 (25.4) .045 (1.1) +/- .007 (0.2) 1 50 B30-R4300

Fig. 20 B33D-94-2-7642 B-7642 Wt. 24 to 20 0.047 (1.2) - 0.080 (2.0) 0.094 (2.4) 0.047 (1.2) .020 (0.5) +/- .003 (0.07) 1 500 B30-R4300 Fig. 20 B33D-125-2-7642 B-7642 Wt. 20 to 16 0.062 (1.6) - 0.110 (2.8) 0.125 (3.2) 0.063 (1.6) .020 (0.5) +/- .003 (0.07) 1 500 B30-R4300 Fig. 20 B33D-187-2-7642 B-7642 Wt. 16 to 10 0.094 (2.4) - 0.151 (3.8) 0.187 (4.8) 0.094 (2.4) .020 (0.5) +/- .003 (0.07) 1 450 B30-R4300 Fig. 20 B33D-250-2-7642 B-7642 Wt. 12 to 8 0.125 (3.2) - 0.215 (5.5) 0.250 (6.4) 0.126 (3.2) .025 (0.6) +/- .003 (0.07) 1 400 B30-R4300 Fig. 20 B33D-375-2-7642 B-7642 Wt. 8 to 4 0.188 (4.8) - 0.0320 (8.1) 0.375 (9.5) 0.189 (4.8) .025 (0.6) +/- .003 (0.07) 1 250 B30-R4300 Fig. 20 B33D-500-2-7642 B-7642 Wt. 6 to 1 0.250 (6.4) - 0.450 (11.4) 0.500 (12.7) 0.252 (6.4) .025 (0.6) +/- .003 (0.07) 1 225 B30-R4300 Fig. 20 B33D-750-2-7642 B-7642 Wt. 2 to 4/0 0.375 (9.5) - 0.700 (17.8) 0.750 (19.0) 0.374 (9.5) .030 (0.8) +/- .003 (0.07) 1 150 B30-R4300 Fig. 20 B33D-1000-2-7642 B-7642 Wt. 2/0 to 0.950 dia 0.450 (11.4) - 0.950 (24.1) 1.000 (25.4) 0.500 (12.7) .035 (0.9) +/- .005 (0.1) 1 150 B30-R4300 Fig. 20 B33D-1500-2-7642 B-7642 Wt. N/A 0.750 (19.0) - 1.400 (35.6) 1.500 (38.1) 0.752 (19.1) .040 (1.0) +/- .006 (0.2) 1 50 B30-R4300 Fig. 20 B33D-2000-2-7642 B-7642 Wt. N/A 1.000 (25.4) - 1.900 (48.3) 2.000 (50.8) 1.000 (25.4) .045 (1.1) +/- .007 (0.2) 1 50 B30-R4300

Tested per:

• ASTM E162 and ASTM E662

• MIL-STD-202

For Wire Gauge (approx.)

Range For Wire Diameters Inch (mm)

Supplied Diameter B Inch (mm)

Figure 20

Recovered Diameter Inch (mm)

(Ø diameter)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

Rec. Ribbon

PermaSleeve® LSZH Low-Smoke Zero-Halogen

Polyolen Wire Markers (B-7641)

Low-halogen, 2:1 heat-shrinkable sleeves offer outstanding ﬁre safety properties and minimal smoke emission.

Meets specications:

• SAE-AS-81531

• EN45545-2

Service temp: -22° F to 221° F Agency approval:

Fits Printers

2:1 Shrink ratio double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 B33D-94-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-125-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-187-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-250-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-375-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-500-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-750-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-1000-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-1500-2-7641 B-7641 i3300, BBP33 Fig. 20 B33D-94-2-7641Y B-7641 Ylw. 0.047 (1.2) - 0.080 (2.0) i3300, BBP33 Fig. 20 B33D-125-2-7641Y B-7641 Ylw. 0.062 (1.6) - 0.110 (2.8) i3300, BBP33 Fig. 20 B33D-187-2-7641Y B-7641 Ylw. 0.094 (2.4) - 0.151 (3.8) i3300, BBP33 Fig. 20 B33D-250-2-7641Y B-7641 Ylw. 0.125 (3.2) - 0.215 (5.5) i3300, BBP33 Fig. 20 B33D-375-2-7641Y B-7641 Ylw. 0.188 (4.8) - .0320 (8.1) i3300, BBP33 Fig. 20 B33D-500-2-7641Y B-7641 Ylw. 0.250 (6.4) - 0.450 (11.4) i3300, BBP33 Fig. 20 B33D-750-2-7641Y B-7641 Ylw. 0.375 (9.5) - 0.700 (17.8) i3300, BBP33 Fig. 20 B33D-1000-2-7641Y B-7641 Ylw. 0.450 (11.4) - 0.950 (24.1) i3300, BBP33 Fig. 20 B33D-1500-2-7641Y B-7641 Ylw. 0.750 (19.0) - 1.400 (35.6)

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

Figure Catalog # Material

Tested per:

• ASTM E162 and ASTM E662

• MIL-STD-202

Range For Wire Diameters Inch (mm)

Wt.

0.047 (1.2) - 0.080 (2.0)

Wt.

0.062 (1.6) - 0.110 (2.8)

Wt.

0.094 (2.4) - 0.151 (3.8)

Wt.

0.125 (3.2) - 0.215 (5.5)

Wt.

0.188 (4.8) - .0320 (8.1)

Wt.

0.250 (6.4) - 0.450 (11.4)

Wt.

0.375 (9.5) - 0.700 (17.8)

Wt.

0.450 (11.4) - 0.950 (24.1)

Wt.

0.750 (19.0) - 1.400 (35.6)

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

(Ø diameter)

Figure 20

Supplied Diameter B Inch (mm)

0.094 (2.4) 0.047 (1.2) .020 (0.5) +/- .003 (0.07)

0.125 (3.2) 0.063 (1.6) .020 (0.5) +/- .003 (0.07)

0.187 (4.8) 0.094 (2.4) .020 (0.5) +/- .003 (0.07)

0.250 (6.4) 0.126 (3.2) .025 (0.6) +/- .003 (0.07)

0.375 (9.5) 0.189 (4.8) .025 (0.6) +/- .003 (0.07)

0.500 (12.7) 0.252 (6.4) .025 (0.6) +/- .003 (0.07)

0.750 (19.0) 0.374 (9.5) .030 (0.8) +/- .003 (0.07)

1.000 (25.4) 0.500 (12.7) .035 (0.9) +/- .005 (0.1)

1.500 (38.1) 0.752 (19.1) .040 (1.0) +/- .006 (0.2)

0.094 (2.4) 0.047 (1.2) .020 (0.5) +/- .003 (0.07)

0.125 (3.2) 0.063 (1.6) .020 (0.5) +/- .003 (0.07)

0.187 (4.8) 0.094 (2.4) .020 (0.5) +/- .003 (0.07)

0.250 (6.4) 0.126 (3.2) .025 (0.6) +/- .003 (0.07)

0.375 (9.5) 0.189 (4.8) .025 (0.6) +/- .003 (0.07)

0.500 (12.7) 0.252 (6.4) .025 (0.6) +/- .003 (0.07)

0.750 (19.0) 0.374 (9.5) .030 (0.8) +/- .003 (0.07)

1.000 (25.4) 0.500 (12.7) .035 (0.9) +/- .005 (0.1)

1.500 (38.1) 0.752 (19.1) .040 (1.0) +/- .006 (0.2)

Recovered Diameter Inch (mm)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

1 1000 B30-R6000 1 1000 B30-R6000 1 450 B30-R6000 1 500 B30-R6000 1 500 B30-R6000 1 225 B30-R6000 1 150 B30-R6000 1 150 B30-R6000 1 50 B30-R6000 1 1000 B30-R6000 1 1000 B30-R6000 1 450 B30-R6000 1 500 B30-R6000 1 500 B30-R6000 1 225 B30-R6000 1 150 B30-R6000 1 150 B30-R6000 1 50 B30-R6000

Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

PermaSleeve® FR Fluid-Resistant Wire Markers (B-344)

Military / industrial grade 3:1 heat-shrinkable sleeves are speciﬁcally designed for applications with exposure to fuels, lubricants and harsh chemicals such as in the installation of hydrogen fuel cells for aerospace. These sleeves are resistant to harsh chemicals including, JP8 Jet Fuel, Skydrol and DOT 3 brake ﬂuid.

B30 / B33 SeriesBenchtop Printers

Meets specication:

• SAE-AS23053/5

Tested per:

• ASTM E162

• ASTM E662

(Ø diameter)

• MIL-STD-202G

Service temp: -94° F to 275° F Agency approvals:

Fits Printers

3:1 Shrink ratio, double-side printable, 2 inch sleeve width (dimension A):

i3300, BBP33 Fig. 20 * B33D-94-2-344 B-344 Wt. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) 0.024 (0.6) +/- 0.003 (0.1) 1 1000 B30-R6600

i3300, BBP33 Fig. 20 * B33D-125-2-344 B-344 Wt. 22 to 16 0.046 (1.2) - 0.111 (2.8) 0.125 (3.1) 0.047 (1.2) 0.020 (0.5) +/- 0.003 (0.1) 1 1000 B30-R6600

i3300, BBP33 Fig. 20 * B33D-187-2-344 B-344 Wt. 20 to 10 0.062 (1.6) - 0.15 (3.81) 0.187 (4.8) 0.062 (1.6) 0.020 (0.5) +/- 0.003 (0.1) 1 750 B30-R6600

i3300, BBP33 Fig. 20 * B33D-250-2-344 B-344 Wt. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.35) 0.093 (2.4) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6600

i3300, BBP33 Fig. 20 * B33D-375-2-344 B-344 Wt. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.2) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6600

i3300, BBP33 Fig. 20 * B33D-500-2-344 B-344 Wt. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.119 (3.0) 0.025 (0.6) +/- 0.003 (0.1) 1 350 B30-R6600

i3300, BBP33 Fig. 20 * B33D-750-2-344 B-344 Wt. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.05) 0.250 (6.35) 0.025 (0.6) +/- 0.003 (0.1) 1 250 B30-R6600

i3300, BBP33 Fig. 20 * B33D-1000-2-344 B-344 Wt. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) 0.036 (0.9) +/- 0.003 (0.1) 1 250 B30-R6600

i3300, BBP33 Fig. 20 * B33D-1500-2-344 B-344 Wt. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) 0.035 (0.9) +/-0 .003 (0.1) 1 150 B30-R6600

i3300, BBP33 Fig. 20 * B33D-94-2-344YL

i3300, BBP33 Fig. 20 * B33D-125-2-344YL B-344 Ylw. 22 to 16 0.046 (1.2) - 0.111 (2.8) 0.125 (3.1) 0.047 (1.2) 0.020 (0.5) +/- 0.003 (0.1) 1 1000 B30-R6600

i3300, BBP33 Fig. 20 * B33D-187-2-344YL B-344 Ylw. 20 to 10 0.062 (1.6) - 0.15 (3.81) 0.187 (4.8) 0.062 (1.6) 0.020 (0.5) +/- 0.003 (0.1) 1 750 B30-R6600

i3300, BBP33 Fig. 20 * B33D-250-2-344YL B-344 Ylw. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.35) 0.093 (2.4) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6600

i3300, BBP33 Fig. 20 * B33D-375-2-344YL B-344 Ylw. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.2) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6600

i3300, BBP33 Fig. 20 * B33D-500-2-344YL B-344 Ylw. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.119 (3.0) 0.025 (0.6) +/- 0.003 (0.1) 1 350 B30-R6600

i3300, BBP33 Fig. 20 * B33D-750-2-344YL B-344 Ylw. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.05) 0.250 (6.35) 0.025 (0.6) +/- 0.003 (0.1) 1 250 B30-R6600

i3300, BBP33 Fig. 20 * B33D-1000-2-344YL B-344 Ylw. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) 0.036 (0.9) +/- 0.003 (0.1) 1 250 B30-R6600

i3300, BBP33 Fig. 20 * B33D-1500-2-344YL B-344 Ylw. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) 0.035 (0.9) +/-0 .003 (0.1) 1 150 B30-R6600

i3300, BBP33 Fig. 20 * B33D-94-2-344BK B-344 Blk. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) 0.024 (0.6) +/- 0.003 (0.1) 1

i3300, BBP33 Fig. 20 * B33D-125-2-344BK B-344 Blk. 22 to 16 0.046 (1.2) - 0.111 (2.8) 0.125 (3.1) 0.047 (1.2) 0.020 (0.5) +/- 0.003 (0.1) 1 1000 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-187-2-344BK B-344 Blk. 20 to 10 0.062 (1.6) - 0.15 (3.81) 0.187 (4.8) 0.062 (1.6) 0.020 (0.5) +/- 0.003 (0.1) 1 750 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-250-2-344BK B-344 Blk. 16 to 8 0.094 (2.4) - 0.215 (5.5) 0.250 (6.35) 0.093 (2.4) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-375-2-344BK B-344 Blk. 12 to 4 0.125 (3.2) - 0.320 (8.1) 0.375 (9.5) 0.125 (3.2) 0.025 (0.6) +/- 0.003 (0.1) 1 500 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-500-2-344BK B-344 Blk. 8 to 1 0.187 (4.8) - 0.450 (11.4) 0.500 (12.7) 0.119 (3.0) 0.025 (0.6) +/- 0.003 (0.1) 1 350 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-750-2-344BK B-344 Blk. 6 to 4/0 0.250 (6.4) - 0.700 (17.8) 0.750 (19.05) 0.250 (6.35) 0.025 (0.6) +/- 0.003 (0.1) 1 250 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-1000-2-344BK B-344 Blk. 2 to 0.950 dia 0.333 (8.5) - 0.950 (24.1) 1.000 (25.4) 0.375 (9.5) 0.036 (0.9) +/- 0.003 (0.1) 1 250 B30-R6700-WT

i3300, BBP33 Fig. 20 * B33D-1500-2-344BK B-344 Blk. n/a 0.500 (12.7) - 1.400 (35.6) 1.500 (38.1) 0.500 (12.7) 0.035 (0.9) +/-0 .003 (0.1) 1 150 B30-R6700-WT

Figure Catalog # Material

B-344 Ylw. 28 to 20 0.023 (0.6) - 0.080 (2.0) 0.094 (2.4) 0.024 (0.6) 0.024 (0.6) +/- 0.003 (0.1) 1 1000 B30-R6600

For Wire Gauge (approx.)

Range For Wire Diameters Inch (mm)

Figure 20

Supplied Diameter B Inch (mm)

Recovered Diameter Inch (mm)

Recovered Wall Thickness Inch (mm)

Sleeves Per Per Row Roll

1000 B30-R6700-WT

Rec. Ribbon

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Color Polyester Labels (B-494)

• Adding color to labels reduces errors, increase efﬁciency and differentiates your lab samples

• Color printed below the label surface withstands the harshest lab environments, including liquid nitrogen, hot water baths and more

• Labels are resistant to common lab chemicals, like ethanol and xylene, when printed with the R6400 series ribbon

Service temp: -320° F to 70° F Agency approvals:

Figure 2

Note: Label dimensions include the color area.

Fits Printers

i3300, BBP33 Fig. 25 B33-152-494-BL BBP33 Lt. Blue 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33 Fig. 24 B33-250-494-BL BBP33 Lt. Blue 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

i3300, BBP33 Fig. 2 B33-179-494-BL BBP33 Lt. Blue 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

i3300, BBP33 Fig. 25 B33-152-494-GN BBP33 Green 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33 Fig. 24 B33-250-494-GN BBP33 Green 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

i3300, BBP33 Fig. 2 B33-179-494-GN BBP33 Green 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

i3300, BBP33 Fig. 25 B33-152-494-OR BBP33 Orange 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33 Fig. 24 B33-250-494-OR BBP33 Orange 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

i3300, BBP33 Fig. 2 B33-179-494-OR BBP33 Orange 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

i3300, BBP33 Fig. 25 B33-152-494-PK BBP33 Pink 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33

i3300, BBP33 Fig. 2 B33-179-494-PK BBP33 Pink 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

i3300, BBP33 Fig. 25 B33-152-494-RD BBP33 Red 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33 Fig. 24 B33-250-494-RD BBP33 Red 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

i3300, BBP33 Fig. 2 B33-179-494-RD BBP33 Red 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

i3300, BBP33 Fig. 25 B33-152-494-YL BBP33 Yellow 1.000 (25.4) 0.375 (9.5) - 2 1500 B30-R6400

i3300, BBP33 Fig. 24 B33-250-494-YL BBP33 Yellow 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

i3300, BBP33 Fig. 2 B33-179-494-YL BBP33 Yellow 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R6400

Figure Catalog # B# Color

Fig. 24 B33-250-494-PK BBP33 Pink 1.000 (25.4) 0.500 (12.7) 0.375 (9.5) dia. 1 1500 B30-R6400

Figure 24

Label Width A Inch (mm)

Figure 25

Label Height B Inch (mm)

Vial Top Dia. C Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Sterilization Indicating Labels (B-7425-AC)

• Pre-printed STERILIZED header indicates steam sterilization when autoclaved at 250.7° F (121.5° C) for 10 minutes

• Labels withstand temperature ranges from -320° F to 248° F (-196° C to 121° C)

• For use in LN2, freezers, autoclave and hot water baths

• Chemical resistance to ethanol, DMSO, IPS, short-term xylene, 10% formalin, 50% acetic acid and toluene

Service temp: -112° F to 158° F Agency approvals:

Figure 81

Note: Label dimensions include the STERILIZED indicating area.

Fits Printers

i3300, BBP33 Fig. 81 B33-235-7425-AC B-7425-AC White 1.500 (38.1) 1.000 (25.4) 1 1250 B30-R4300 i3300, BBP33 Fig. 81 B33-137-7425-AC B-7425-AC White 2.000 (50.8) 1.000 (25.4) 1 1500 B30-R4300

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

Figure Catalog # B# Color

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Label Width A Inch (mm)

Before After

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

B30- and B33-Series Materials

Cryogenic Tube and Vial Labels (B-461, B-490, B-492 and B-7425)

FreezerBondz™ labels can be applied to room temperature or already frozen samples, with a small overlap. The label remains legible and will stick to the tube during processing, even when immersed in liquid or vapor-phase nitrogen and ultra-low temperature freezer storage.

• B-461 Self-Laminating Polyester: Ultra-thin label with clear overlaminate tail that protects print and allows liquid levels to be visible

• B-490 Polyester: Adhere to already frozen tubes and vials when wrapped around itself by at least 0.125 inch

• B-492 Polyester: Ultra-thin label for frosted, frozen or room temperature vials, tubes and canes. Superior chemical and abrasion resistance

• B-7425 Polypropylene: Ideal for labeling dry, room temperature specimen containers. Material withstands temperature ranges from -320° F to 248° F (-196° C to 121° C). Chemical resistance to ethanol, DMSO, IPS, short-term xylene, 10% formalin, 50% acetic acid and toluene

B-461: Service temp: -321° F to 230° F Agency approvals: B-490: Service temp: -320° F to 366° F Agency approvals: B-492: Service temp: -320° F to 230° F Agency approvals: B-7425: Service temp: -112° F to 158° F Agency approvals:

B30 / B33 SeriesBenchtop Printers

Fits Printers

Figure 2

Figure Catalog # B# Color

Figure 7Figure 5

Label Width A Inch (mm)

Figure 14c Figure 15c

Label Height B Inch (mm)

Print-On Height C Inch (mm)

Figure 25a

Labels Per Row

Labels Per Roll

Self-Laminating Polyester (B-461):

i3300, BBP33 Fig. 15c B33-127-461 B-461 White 0.500 (12.7) 2.200 (55.9) 0.750 (19.1) 1 1500 B30-R4300 i3300, BBP33 Fig. 15c B33-133-461 B-461 White 0.600 (15.2) 1.625 (41.3) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 14c B33-139-461 B-461 White 1.000 (25.4) 5.250 (133.4) 1.500 (38.1) 2 650 B30-R4300 i3300, BBP33 Fig. 15c B33-123-461 B-461 White 1.800 (45.7) 0.375 (9.5) 0.750 (19.1) 1 1500 B30-R4300 i3300, BBP33 Fig. 15c B33-122-461 B-461 White 1.800 (45.7) 0.500 (12.7) 0.750 (19.1) 1 1500 B30-R4300 i3300, BBP33 Fig. 14c B33-276-461 B-461 White 2.625 (66.7) 1.000 (25.4) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 15c B33-134-461 B-461 White 3.500 (88.9) 1.500 (38.1) 1.250 (31.8) 1 1000 B30-R4300 i3300, BBP33 Fig. 15c B33-153-461 B-461 White 0.600 (15.2) 2.625 (66.7) 1.000 (25.4) 1 1500 B30-R4300 i3300, BBP33 Fig. 15c B33-183-461 B-461 White 1.750 (44.4) 1.000 (25.4) 1.000 (25.4) 1 2000 B30-R4300

Polyester (B-490):

i3300, BBP33 Fig. 5 B33-144-490 B-490 White 0.500 (12.7) dia. - - 3 2500 B30-R4300 i3300, BBP33 Fig. 2 B33-68-490 B-490 White 0.500 (12.7) 0.750 (19.1) - 4 2500 B30-R4300 i3300, BBP33 Fig. 2 B33-125-490 B-490 White 0.900 (22.9) 0.500 (12.7) - 1 1650 B30-R4300 i3300, BBP33 Fig. 7 B33-126-490 B-490 White 0.900 (22.9) 0.500 (12.7) 0.500 (12.7) dia. 1 2500 sets B30-R4300 i3300, BBP33 Fig. 2 B33-154-490 B-490 White 1.250 (31.8) 0.375 (9.5) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-155-490 B-490 White 1.625 (41.3) 0.600 (15.2) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-156-490 B-490 White 1.900 (48.2) 1.000 (25.4) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-157-490 B-490 White 2.200 (55.9) 1.500 (38.1) - 1 1000 B30-R4300 i3300, BBP33 Fig. 2 B33-158-490 B-490 White 3.750 (95.3) 1.750 (44.4) - 1 1100 B30-R4300

Polyester (B-492):

i3300, BBP33 Fig. 5 B33-143-492 B-492 White 0.375 (9.5) dia. - - 4 1500 B30-R6400 i3300, BBP33 Fig. 5 B33-144-492 B-492 White 0.500 (12.7) dia. - - 3 1500 B30-R6400 i3300, BBP33 Fig. 7 B33-182-492 B-492 White 0.500 (12.7) 1.000 (25.4) 0.440 (11.17) dia 1 1500 sets B30-R6400 i3300, BBP33 Fig. 2 B33-180-492 B-492 White 0.900 (22.9) 1.000 (25.4) - 1 1500 B30-R6400 i3300, BBP33 i3300, BBP33 Fig. 7 B33-163-492 B-492 White 1.000 (25.4) 0.375 (9.5) 0.375 (9.5) dia. 1 1500 sets B30-R6400 i3300, BBP33 Fig. 7 B33-181-492 B-492 White 1.000 (25.4) 0.500 (12.7) 0.500 (12.7) dia 1 1500 sets B30-R6400 i3300, BBP33 Fig. 2 B33-59-492 B-492 White 1.000 (25.4) 0.500 (12.7) - 1 5000 B30-R6400 i3300, BBP33 Fig. 2 B33-179-492 B-492 White 1.000 (25.4) 1.000 (25.4) - 1 1900 B30-R6400 i3300, BBP33 Fig. 2 B33-155-492 B-492 White 1.625 (41.3) 0.600 (15.2) - 1 1500 B30-R6400 i3300, BBP33 Fig. 7 B33-190-492 B-492 White 1.625 (41.3) 0.600 (15.2) 0.375 (9.5) dia. 1 1500 sets B30-R6400 i3300, BBP33 Fig. 2 B33-156-492 B-492 White 1.900 (48.3) 1.000 (25.4) - 1 1500 B30-R6400

Fig. 25a B33-152-492 B-492 White 1.000 (25.4) 0.375 (9.5) - 2 2500 B30-R6400

Polypropylene (B-7425):

i3300, BBP33 Fig. 2 B33-257-7425 B-7425 White 0.825 (21.0) 0.250 (6.4) - 1 1500 B30-R4300 i3300, BBP33 Fig. 25a B33-152-7425 B-7425 White 1.000 (25.4) 0.375 (9.5) - 2 2000 B30-R4300 i3300, BBP33 Fig. 2 B33-59-7425 B-7425 White 1.000 (25.4) 0.500 (12.7) - 1 2000 B30-R4300 i3300, BBP33 Fig. 25a B33-88-7425 B-7425 White 1.000 (25.4) 0.750 (19.1) - 2 2000 B30-R4300 i3300, BBP33 Fig. 2 i3300, BBP33 Fig. 25a B33-37-7425 B-7425 White 1.500 (38.1) 0.500 (12.7) - 2 1500 B30-R4300

B33-256-7425 B-7425 White 1.300 (33.0) 0.600 (15.2) - 1 1500 B30-R4300

*All supplies listed are compatible with the following printers unless otherwise noted:

BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Rec. Ribbon

B30- and B33-Series Materials

Centrifuge and PCR Tube Labels (B-499 and B-7425)

Designed with ultra-thin material that prevents vials from jamming in centrifuges or racks, these labels withstand harsh temperatures and chemicals without falling off, fading or smearing.

• B-499 Nylon Cloth: White nylon cloth for easy handling and conformability

• B-7425 Polypropylene: Moderate chemical resistance, ideal for labeling dry, room temperature specimen containers that withstand temperature ranges from

-320° F to 248° F (-196° C to 121° C). Chemical resistance to ethanol, DMSO, IPS, short-term xylene, 10% formalin, 50% acetic acid and toluene

B-499: Service temp: -40° F to 194° F Agency approvals: B-7425: Service temp: -112° F to 158° F Agency approvals:

Figure 2

Fits Printers

Nylon Cloth (B-499):

i3300, BBP33 Fig. 5 B33-143-499 B-499 White 0.375 (9.5) dia. - - 4 1500 B30-R6000 i3300, BBP33 Fig. 5 B33-144-499 B-499 White 0.500 (12.7) dia. - - 3 1500 B30-R6000 i3300, BBP33 Fig. 7 B33-126-499 B-499 White 0.900 (22.9) 0.500 (12.7) 0.500 (12.7) dia. 1 1500 sets B30-R6000

Polypropylene (B-7425):

i3300, BBP33 Fig. 2 B33-257-7425 B-7425 White 0.825 (21.0) 0.250 (6.4) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-152-7425 B-7425 White 1.000 (25.4) 0.375 (9.5) - 2 2000 B30-R4300 i3300, BBP33 Fig. 7 B33-249-7425 B-7425 White 1.000 (25.4) 0.375 (9.5) 0.375 (9.5) dia. 1 1500 sets B30-R4300 i3300, BBP33 Fig. 2 B33-59-7425 B-7425 White 1.000 (25.4) 0.500 (12.7) - 1 2000 B30-R4300 i3300, BBP33 Fig. 7 B33-251-7425 B-7425 White 1.000 (25.4) 0.500 (12.7) 0.440 (11.1) dia. 1 1500 sets B30-R4300 i3300, BBP33 Fig. 2 B33-179-7425 B-7425 White 1.000 (25.4) 1.000 (25.4) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-256-7425 B-7425 White 1.300 (33.0) 0.600 (15.2) - 1 1500 i3300, BBP33 Fig. 2 B33-37-7425 B-7425 White 1.500 (38.1) 0.500 (12.7) - 2 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-136-7425 B-7425 White 1.500 (38.1) 0.750 (19.1) - 1 1500 B30-R4300 i3300, BBP33 Fig. 2 B33-258-7425 B-7425 White 1.500 (38.1) 1.750 (44.5) - 1 900 B30-R4300 i3300, BBP33 Fig. 2 B33-137-7425 B-7425 White 2.000 (50.8) 1.000 (25.4) - 1 1500 B30-R4300

Figure Catalog # B# Color

Figure 5

Label Width A Inch (mm)

Figure 7

Label Height B Inch (mm)

Vial Top Dia. C Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30-R4300

Microscope Slide Labels (B-481)

• StainerBondz™ polyester material is designed to identify slides and to resist exposure to harsh chemicals during the slide-staining process

• Performs well in stains such as hematoxylin and eosin

• Extreme chemical resistance withstands the rigors of typical deparafﬁnization, including ethanol, xylene and H&E staining processes

Service temp: -112° F to 266° F Agency approvals:

Fits Printers

i3300, BBP33 Fig. 2 B33-195-481 B-481 White 0.900 (22.9) 0.375 (9.5) 1 3000 B30-R6400 i3300, BBP33 Fig. 2 B33-194-481 B-481 White 0.900 (22.9) 0.750 (19.1) 1 2000 B30-R6400 i3300, BBP33 Fig. 25 B33-141-481 B-481 White 0.900 (22.9) 0.900 (22.9) 2 1500 B30-R6400

Figure Catalog # B# Color

Figure 2

Label Width A Inch (mm)

Figure 25

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 Series Benchtop Printers

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30- and B33-Series Materials

Dissolvable Paper Labels (B-403)

• Designed for temporary applications where easy removal,

re-identiﬁcation or waste reduction are valued

• Ideal for labeling vials, tubes or general glassware,

temporary asset tracking, animal housing identiﬁcation and general use

• Completely dissolves in warm water within

30 seconds, leaving no adhesive residue

Service temp: -40° F to 172° F

Fits Printers

All* Fig. 3 B30C-1125-403-WT B-403 White 1.125 (28.6) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-2250-403-WT B-403 White 2.250 (57.15) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-3000-403-WT B-403 White 3.000 (76.2) 100 (30.5) 1 (cont.) B30-R4300 All* Fig. 3 B30C-4000-403-WT B-403 White 4.000 (101.6) 100 (30.5) 1 (cont.) B30-R4300

Figure Catalog # B# Color

Well and Microplate Labels (B-490, B-499)

• Designed with a short height and long width to ﬁt the necessary information on the plate

• B-490 Polyester: White FreezerBondz label ideal for ﬂat frozen surfaces

• B-499 Nylon Cloth: Thick white nylon cloth with permanent adhesive

provides easy handling and conformability

• B-7425 Polypropylene: Moderate chemical resistance,

ideal for labeling dry, room temperature specimen containers

B-490: Service temp: -320° F to 366° F Agency approvals: B-499: Service temp: -40° F to 194° F Agency approvals: B-7425: Service temp: -112° F to 158° F Agency approvals:

Fits Printers

i3300, BBP33 Fig. 2 B33-151-490 B-490 White 2.000 (50.8) 0.250 (6.4) 1 2500 B30-R4300 i3300, BBP33 Fig. 2 B33-151-499 B-499 White 2.000 (50.8) 0.250 (6.4) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-151-7425 B-499 White 2.000 (50.8) 0.250 (6.4) 1 2000 B30-R4300

Figure Catalog # B# Color

Figure 3

Label Width A Inch (mm)

Dissolves within 30 seconds leaving no residue.

Roll Length B Inch (mm)

Figure 2

Label Height B Inch (mm)

Labels Per Roll

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30 / B33 SeriesBenchtop Printers

Tissue Cassette Labels (B-482)

• White polyester label with superior resistance to tissue processing chemicals and embedding procedures

• Use with the BSP™31 Label Attachment system for tissue cassette identiﬁcation

Figure 2

Fits Printers

i3300, BBP33 Fig. 2 B33-199-482 B-482 White 1.050 (26.7) 0.250 (6.4) 1 3000 B30-R6400 i3300, BBP33 Fig. 2 B33-213-482 B-482 White 1.050 (26.7) 0.313 (8) 1 3000 B30-R6400

Figure Catalog # B# Color

BradyPrinter S3000, S3100, i3300, BBP

Label Width A Inch (mm)

*All supplies listed are compatible with the following printers unless otherwise noted:

Label Height B Inch (mm)

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30- and B33-Series Materials

General Identication for Laboratory Storage, Equipment and Safety Labels (B-499, B-595, B-7569)

• Super-strong adhesives and colors ideal for marking laboratory equipment, containers, hoses and lab storage cabinets, shelves and drawers

• GHS labels available for marking chemicals in the lab and shipment boxes when collaborating with other labs

• Pre-printed sign header labels make your safety and housekeeping reminders stand out and stay put

B-499: Service temp: -40° F to 193° F Agency approvals: B-595: Service temp: -40° F to 180° F Agency approvals: B-7569: Service temp: -4° F to 167° F

Figure 1

Fits Printers

Nylon Cloth - Permanent adhesive (B-499):

i3300, BBP33 Fig. 1 B33-68-499 B-499 White 0.500 (12.7) 0.750 (19.1) 4 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-165-499 B-499 White 0.800 (20.3) 1.437 (36.5) 4 2500 B30-R6000 i3300, BBP33 Fig. 2 B33-125-499 B-499 White 0.900 (22.9) 0.500 (12.7) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-126-499 B-499 White 0.900 (22.9) 0.500 (12.7) 2 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-163-499 B-499 White 1.000 (25.4) 0.375 (9.5) 1 1500 B30-R6000 i3300, BBP33 Fig. 1 B33-152-499 B-499 White 1.000 (25.4) 0.375 (9.5) 2 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-136-499 B-499 White 1.500 (38.1) 0.750 (19.1) 1 1500 B30-R6000 i3300, BBP33 Fig. 2 B33-137-499 B-499 White 2.000 (50.8) 1.000 (25.4) 1 1100 B30-R6000 i3300, BBP33 Fig. 2 B33-125-499 B-499 White 2.000 (50.8) 0.250 (6.4) 1 1500 B30-R6000

Indoor / Outdoor Vinyl (B-595):

All* Fig. 3 B30C-500-595-WT B-595 White 0.500 (12.7) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-WT B-595 White 1.125 (28.6) 100 ft. (30.5 m) - 1 roll (cont.) All* Fig. 3 B30C-500-595-YL B-595 Yellow 0.500 (12.7) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-1125-595-YL B-595 Yellow 1.125 (28.6) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000 All* Fig. 3 B30C-500-595-RD B-595 Red 0.500 (12.7) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-RD B-595 Red 1.125 (28.6) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-500-595-BL B-595 Blue 0.500 (12.7) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-BL B-595 Blue 1.125 (28.6) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-500-595-GN B-595 Green 0.500 (12.7) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT All* Fig. 3 B30C-1125-595-GN B-595 Green 1.125 (28.6) 100 ft. (30.5 m) - 1 roll (cont.) B30-R10000-WT

Pre-Printed Pre-Cut Blank Sign Headers (B-595):

All* Fig. 70 B30-241-595-ANSIDA B-595 2.250 (57.5) 3.000 (76.2) 1 300 B30-R10000

All* Fig. 70 B30-25-595-ANSIDA B-595 4.000 (101.6) 6.000 (152.4) 1 175 B30-R10000

All* Fig. 70 B30-241-595-ANSINO B-595

All* Fig. 70 B30-25-595-ANSINO B-595 4.000 (101.6) 6.000 (152.4) 1 175 B30-R10000

Pre-Printed GHS / CLP Chemical (B-7569):

All*

Additional sizes and colors available for: B-595 on page 40; sign headers on page 44; GHS labels on page 42. U.S. Patent No. 5,823,689; 6,570,602 on B-595 vinyl. Additional patents pending.

Figure Catalog # B# Color /Legend

L4B Diamond + Text

L4C Diamond + Text

B30-260-7569-CLP4B B-7569

B30-261-7569-CLP4B B-7569 2.950 (75.0) 4.330 (110.0) 1 270 B30-R10000

B30-18-7569-CLP4C B-7569

Figure 2

Figure 3

HEADERDER

Figure 70

Label Width A Inch (mm)

2.250 (57.5) 3.000 (76.2) 1 300 B30-R10000

2.170 (55.0) 3.350 (85.0) 1 340 B30-R10000

1.000 (25.4) 3.000 (76.2) 1 1000 B30-R10000

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

B30-R10000

*All supplies listed are compatible with the following printers unless otherwise noted: BradyPrinter S3000, S3100, i3300, BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers.

B30 / B33 Series Benchtop Printers

B30-Series Supply Kits

for BradyPrinter S3000, S3100, i3300,

BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers

Get started right and save a little, too, with a Brady supply starter kit. These kits contain the most commonly used labels and ribbons to ensure you have what you need to get going on your projects.

B30 / B33 SeriesBenchtop Printers

Basic Supply Starter Kit

Kit includes:

(1) B30C-4000-595-YL - 4 in. yellow vinyl (1) B30C-4000-595-WT - 4 in. white vinyl (1) B30C-2250-595-RD - 2.25 in. red vinyl (1) B30-R10000 - Black print ribbon (1) B30-R10000-WT - White print ribbon

Catalog # Description

146069 Basic Supply Starter Kit - Small

Printer sold separately.

Arc Flash Supply Kit

Large kit includes:

(2) B30-25-595-ANSIWA - 4 in. x 6 in. B-595 ANSI warning header (1) B30-241-595-ANSIWA - 2.25 in. x 3 in. B-595 ANSI warning header (1) B30EP-174-593-WT - 1 in. x 4 in. B-593 white raised panel label (1) B30C-2250-595-OR - 2.25 in. B-595 orange vinyl (3) B30-R10000 - Black print ribbon

Small kit includes:

(2) B30-25-595-ANSIWA - 4 in. x 6 in. ANSI warning header (1) B30-R10000 - Black print ribbon

Gauge Label Supply Kit for BBP37 Printer*

Kit includes:

(2) B30C-4000-595-WT - 4 in. white vinyl (2) B30-R10000-GR-8 - Green / red paneled print ribbon; 8 in. panel length

Catalog # Description

146070 Gauge Label Supply Kit - Small

* BBP37 printer required to cut gauge label. Printer sold separately.

GHS Supply Kit

Large kit includes:

(1) B30-262-7569-CLP4B - 4 in. x 6 in. four-diamond GHS label (2) B30-261-7569-CLP4B - 3 in. x 4 in. four-diamond GHS label (1) B30-260-7569-CLP4B - 2 in. x 3 in. four-diamond GHS label (3) B30-R10000 - Black print ribbon

Small kit includes:

(2) B30-262-7569-CLP4B - 4 in. x 6 in. four-diamond GHS label (1) B30-R10000 - Black print ribbon

Catalog # Description

142061 Arc Flash Supply Kit - Large 146071 Arc Flash Supply Kit - Small S3100W-ARC-KIT BradyPrinter S3100 w/ Large Arc Flash Supply Kit

Printer sold separately unless otherwise noted.

Catalog # Description

146072 GHS Supply Kit - Large 146073 GHS Supply Kit - Small S3100W-GHS-KIT BradyPrinter S3100 w/ Large GHS Supply Kit

Printer sold separately unless otherwise noted.

B30-Series Supply Kits

Safety and Compliance Supply Kit

Kit includes:

(1) B30-25-595-ANSIDA - 4 in. x 6 in. B-595 ANSI danger header (1) B30-25-595-ANSIWA - 4 in. x 6 in. B-595 ANSI warning header (1) B30-25-595-ANSICA - 4 in. x 6 in. B-595 ANSI caution header (1) B30-25-595-ANSINO - 4 in. x 6 in. B-595 ANSI notice header (1) B30C-4000-526 - 4 in. B-526 photoluminescent (1) B30-263-595-NFPA - 4 in. x 6 in. B-595 NFPA right to know diamond (2) B30-R10000 - Black print ribbon (1) B30-R10000-RD - Red print ribbon

Catalog # Description

142062 Safety Supply Kit - Large S3100W-SAFE-KIT BradyPrinter S3100 w/ Safety Supply Kit

Printer sold separately unless otherwise noted.

Lean / 5S Visual Workplace Supply Kit

Kit includes:

(1) B30C-4000-595-WT - 4 in. B-595 white vinyl (1) B30C-2250-595-WT - 2.25 in. B-595 white vinyl (1) B30C-4000-595-YL - 4 in. B-595 yellow vinyl (1) B30C-2250-595-YL - 2.25 in. B-595 yellow vinyl (1) B30C-2250-581-WT - 2.25 in. B-581 repositionable vinyl (1) B30C-1125-581-WT - 1.125 in. B-581 repositionable vinyl (1) B30C-2500-509-WT - 2.25 in. magnetic vinyl (1) 142133 - Blank valve tag variety pack (1) B30-219-595-BLNKWT - Die-cut labels for valve tags (1) B30-25-595-ANSIWA - 4 in. x 6 in. B-595 caution header (2) B30-R10000 - Black print ribbon (1) B30-R10000-RD - Red print ribbon (1) B30-R10000-GN - Green print ribbon (1) B30-R10000-BL - Blue print ribbon

Catalog # Description

142063 Lean / 5S Supply Kit - Large S3100W-LEAN-KIT BradyPrinter S3100 w/ Lean / 5S Supply Kit

Printer sold separately unless otherwise noted.

Pipe Identication Supply Kit

Kit includes:

(1) B30C-4000-595-YL 4 in. B-595 yellow vinyl (1) B30C-2250-595-YL - 2.25 in. B-595 yellow vinyl (1) B30C-1125-595-YL - 1.125 in. B-595 yellow vinyl (1) B30C-4000-595-GN - 4 in. B-595 green vinyl (1) B30C-2250-595-GN - 2.25 in. B-595 green vinyl (1) B30C-1125-595-GN - 1.125 in. B-595 green vinyl (1) B30C-1125-595-BL - 1.125 in. B-595 blue vinyl (1) B30C-2250-595-RD - 2.25 in. B-595 red vinyl (1) B30C-1125-595-RD - 1.125 in. B-595 red vinyl (1) B30EP-174-593-BK - 1 in. x 4 in. B-593 black raised panel (1) 142133 - Blank valve tag variety pack (1) B30-242-595-BLNKWT - Small die-cut labels for valve tags (3) B30-R10000 - Black print ribbon (2) B30-R10000-WT - White print ribbon

Catalog # Description

142064 Pipe ID Supply Kit - Large S3100W-PIPE-KIT BradyPrinter S3100 w/ Pipe ID Supply Kit

Printer sold separately unless otherwise noted.

General Industrial Supply Kit

Kit includes:

(1) B30C-4000-595-WT - 4 in. B-595 white (1) B30C-2250-595-WT - 2.25 in. B-595 white (1) B30C-1125-595-WT - 1.125 in. B-595 white vinyl (1) B30C-4000-595-YL - 4 in. B-595 yellow vinyl (1) B30C-2250-595-YL - 2.25 in. B-595 yellow vinyl (1) B30C-1125-595-YL - 1.125 in. B-595 yellow vinyl (1) B30EP-177-593-BK - 2.5 in. x 3 in. B-593 black raised panel (1) B30-25-595-ANSIDA - 4 in. x 6 in. B-595 ANSI danger header

B30-25-595-ANSICA - 4 in. x 6 in. B-595 ANSI caution header

(1) (1) B30C-2250-584-YL - 2.25 in. Reﬂective yellow (1) B30C-4250-551-WT - 4.25 in. White tag stock (2) B30-R10000 - Black print ribbon (1) B30-R10000-WT - White print ribbon (1) B30-R10000-RD - Red print ribbon

Catalog # Description

142065 General Industrial Supply Kit - Large S3100W-GEN-KIT BradyPrinter S3100 w/ General Industrial Supply Kit

Printer sold separately unless otherwise noted.

B30 / B33 Series Benchtop Printers

B30-Series Print Ribbons

for BradyPrinter S3000, S3100, i3300,

BBP

30, BBP®31, BBP®33, BBP®35 and BBP®37 printers

• Tough, smear-proof ribbons that produce long-lasting printed text and can withstand years in industrial areas and outdoor conditions

• Self-contained cartridges drop straight into printer with a click – no calibrating, threading, wasted feeding and the ink will always be facing the right direction

• Printer notiﬁes user if installed ribbon is not recommended for installed labels

Single-Color Print Ribbons

• Solid color ribbons for printing a single color onto a label

• Can be used for printing multi-color labels on BBP35 or BBP37 printers if a paneled multi-color ribbon is not on hand

• All ribbons 4.330 in. x 200 ft. (101.9 mm x 60.9 m)

Fits

Catalog # Color

Printers

All*

B30-R10000 Black

All*

B30-R6000 Black

All*

B30-R6200 Black

All*

B30-R6400 Black

All*

B30-R6600 Black

All*

B30-R4300 Black

All*

B30-R10000-WT White

All*

B30-R4400-WT White

All*

B30-R6700-WT White*

All*

B30-R4500-SV Silver*

Fits

Catalog # Color

Printers

All*

B30-R10000-RD Red

All*

B30-R10000-GN Green

All*

B30-R10000-BL Blue

All*

B30-R10000-YL Yellow* B30-R10000-YL2 Yellow*

All* All*

B30-R10000-OR Orange

All*

B30-R10000-MA Magenta

All*

B30-R10000-PRCCY Process Cyan**

All*

B30-R10000-PRCYEL Process Yellow**

All*

B30-R10000-PRCMAG Process Magenta**

Drop and click print ribbons for 5-second ribbon supply changes

* B30-R4500-SV ribbon for use with B-342 black

Permasleeves only; B30-R6700-WT ribbon for use with B-345 black Permasleeves only.

** B30-R10000-YL for printing yellow onto white.

B30-R10000-YL2 for printing yellow onto other colors of B-595.

*** Process ribbons print a much lighter shade.

They are designed to be used with other process ribbons and black ribbon to lay down a dot pattern for printing blended colors and process color objects with the BBP35/37.

B30 / B33 SeriesBenchtop Printers

Multi-Color Paneled Print Ribbons for BBP35 and BBP37

• Ribbons have 2- or 4-color panels for printing multiple colors onto a label

• Print multiple colors without having to swap in multiple ribbons

Two-color print ribbons

Fits Printers Catalog # Color Panel Size Inch (mm) Length Feet (m) 8 inch panel length. Typical yield: 100 panel sets per roll

BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only

16 inch panel length. Typical yield: 60 panel sets per roll

BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only

Four-color print ribbons

Fits Printers Catalog # Color Panel Size Inch (mm) Length Feet (m) 8 inch panel length. Typical yield: 50 panel sets per roll

BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only

16 inch panel length. Typical yield: 30 panel sets per roll

BBP35, 37 Only BBP35, 37 Only BBP35, 37 Only

** Process ribbons print a much lighter shade. They are designed to be used together with other process ribbons and black ribbon to lay down a dot pattern

for printing blended colors and process color objects with the BBP35 and BBP37 printers.

B30-R10000-KR-8 Black and Red 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KY-8 Black and Yellow 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KB-8 Black and Blue 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KO-8 Black and Orange 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KG-8 Black and Green 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-GR-8 Green and Red 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m)

B30-R10000-KR-16 Black and Red 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-KY-16 Black and Yellow 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-KB-16 Black and Blue 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-KO-16 Black and Orange 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-KG-16 Black and Green 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-RB-16 Red and Blue 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m)

B30-R10000-KRGB-8 Black, Red, Green and Blue 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KRYG-8 Black, Red, Yellow and Green 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KRYB-8 Black, Red, Yellow and Blue 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-KRBO-8 Black, Red, Blue and Orange 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m) B30-R10000-CMYK-8 Process Cyan, Magenta, Yellow, Black** 4.330 x 8.000 (101.9 x 203.2) panels 200 ft. (60.9 m)

B30-R10000-KRGB-16 Black, Red, Green and Blue 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-KRYB-16 Black, Red, Yellow and Blue 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m) B30-R10000-CMYK-16 Process Cyan, Magenta, Yellow, Black** 4.330 x 16.000 (101.9 x 604.4) panels 200 ft. (60.9 m)

B30-Series Print Ribbons

Print ribbon and label material compatibility

B-# Material

(Black)

B30-R4300

(Black)

B30-R6000

(Black)

B30-R6200

B30-R6400

(Black)

B30-R6600

(Black)

B30-R10000

(Black)

(Silver)

B30-R4500-SV*

(White)

B30-R4400-WT

(White)

B30-R6700-WT*

(White)

B30-R10000-WT

(Yellow)

B30-R10000-YL

(Yellow)

B30-R10000-YL2

B30-R10000

(Colors)

B-342 Polyoleﬁn

B-344 Polyoleﬁn – – – –

B-345 Polyoleﬁn –

B-403 Paper

B-422 Polyester –

B-423 Glossy white polyester –

B-424 Matte white paper

B-425 Polypropylene

B-427 Vinyl

B-428 Metallized polyester

B-430 Polyester –

B-432 Glossy clear polyester –

B-434 Glossy metallized polyester –

B-437 Polyvinylﬂuoride

B-438

B-461 Polyester

B-472 Polyimide

B-480 Metallized polyester – – –

B-481 Polyester – – –

B-482 Polyester – – –

B-483 Glossy white polyester –

B-483 Toughstripe

B-484A Glossy white polyester –

B-486 Matte metallized polyester

B-489 Matte white polyester

B-490 Polyester

B-492 Polyester – – –

B-494 Color polyester – – –

B-498 Cloth – –

B-499 Nylon

B-509 Printable magnetic – – – – –

B-526 Photoluminescent polyester – – – – –

B-549 Cold temperature polyester – – – – –

B-551 Non-adhesive tag – – – – –

B-565 Metallized polyester – – – – –

B-569 Low-halide polyester –

B-581 Repositionable vinyl – – – – –

B-584 Retro reﬂective – – – – –

B-593

B-595 Outdoor vinyl – – – – –

B-717 Polyimide –

B-718 Polyimide –

B-719 Polyimide –

B-724 Matte amber polyimide

B-727 Glossy white polyimide –

B-854 Toughwash

B-855 Toughwash –

B-7425 Polypropylene – – –

B-7425-AC Polypropylene – – –

B-7569

B-7641 Polyoleﬁn

B-7642 Polyoleﬁn

B-7643 Polyurethane –

Tamper evident metallized polyester

ﬂoor marking tape –

Raised panel polyester

metal detectable –

Vinyl ﬁlm – – – – –

* B30-R4500-SV ribbon for use with B-342 black PermaSleeves

– – – – –

– – –

– – – – –

– – – – – – – – – – – –

– – – – –

l l

– – – – – – – – – – – –

– –

– – – – – – – – –

– – – – – – – – – – – –

l l

– – – –

–

– – – – – – – –

l l

– –

only; B30-R6700-WT ribbon for use with B-345 black PermaSleeves® only.

– – – – – – – – – –

– – – – – – – – –

– – – – – – – – – – –

– – – – –

– – – – – – – – – – –

– – – – –

– – – – – – – – –

– – – – – – – – – – –

– – – – –

– – – – – – – – – – –

– –

– – – – – – – – –

– – – – – – – – – –

– – – – – – – – – – –

– – – – –

– – – – – – – – – – –

– – – – – – – – –

– –

– – – –

– – – – – – – –

– – – – – – – – –

– – – – – –

– – – – –

– – – – – – –

– – – – – –

– – –

– – – – – –

– – – – – – –

– – –

– – – – – –

– – – – –

– – –

– – – – – – –

–

– – – – –

**Colored ribbons optimized for use on white material. Test use on other material colors for suitability to your application. ***Use B30-R10000-YL for printing yellow onto white. Use B30-R10000-YL2 for printing yellow onto other colors of B-595.

– – – –

– – –

– – – –

l *

– –

l l ** l ** l *

– – – –

l *

B30 / B33 Series Benchtop Printers

BBP®85 Sign and Label Printer

There’s big and bold. Then there’s big and bold from Brady.

The BBP85 Sign and Label Printer allows you to create extra-large 10 inch labels in multiple colors, and it has an easier-than-ever interface that anyone on your team can use. No more complex, tedious design steps. Now you can just walk up and print – anyone can do it.

Big Output. Little Fuss.

Create custom signs and labels right now. This printer has our fastest, easiest operating system, so anyone on your team can design visuals with little to no training. The ideal printer for multi-user lean / 5S and kaizen labeling events.

• Unmistakably large visuals up to 10 in. wide

• Just walk up and print – it really is that easy

• Simple touchscreen interface for standalone use, including label design apps to quickly create safety signs, pipe markers, GHS, arc ﬂash, right-to-know labels and more

• Connect to your PC to print labels created through Brady Workstation apps

• USB port for importing ﬁles, fonts and graphics

Printer at-a-glance

• Large output up to 10 in. wide

• Single- and multi-color printing

• PC-connect or standalone printing

• Touchscreen label creation

• 125 parts, 5 materials

Catalog # Description

BBP85 BBP85 Sign and Label Printer* B85-DC BBP85 Printer Dust Cover STYLUS-3PK Replacement Stylus Pens (3 per pack)

* Printer ships with documentation CD, printer driver CD, power cord, USB cord, Quick Start Guide and cleaning kit.

BBP85Benchtop Printers

Printing supplies

BBP85 label rolls ........................ page 78

BBP85 print ribbons

................... page 83

Big, bold and better than ever

Large signs

up to 10 in. wide

on demand

GHS labels Pipe markingLow light applicationsEquipment IDCustom signs

Printer speciﬁcations

Overview 10 in. standalone and

Applications Larger output of equipment

Label materials Extremely agressive

Label formats Continuous tapes,

Print technology Thermal transfer

Print resolution 300 dpi

Print speed 1 in./sec.

Media widths 4 to 10 in.

Min. label dimension 4 in.

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting (cutout shapes / text)

PC-connect or standalone operation

Connectivity options Standard: USB, Ethernet

Compatible software Brady Workstation Apps

Compatible materials B85-series and

Compatible ribbons B85-series and

Calibration required No (no waste)

Label creation and set-up

Ribbon and label roll installation

Warranty 5 years

* Patent No. 8,542,155; 8,783,983. Additional patents pending.

PC-connect printer for SFID with multi-color printing. Particularly popular for any large labeling needs. The ultimate in easy and accessible with multiple colors for larger output

labels, GHS labels, safety signs and multi-color labels

8-10 year outdoor vinyl with high tack and chemical resistance, plus reﬂective, 10-hour glow-in-the-dark and polyester.

pre-printed and blank die-cut labels

Monocolor and multi-color printing

Standalone and PC-connect printing

Optional: Wi-Fi, Wi-Fi Direct

PowerMark materials

Powermark ribbons

Automatic (printer or PC software reads data on chip and automatically sets up label size, color, fonts, etc.)

Labels: Supplied in cartridge, drops into place, 15-second changeover Ribbon: Supplied in cartridge, snaps into place, 5-second changeover

BBP®85 Sign and Label Printer

Brady Workstation Safety and Facility ID Suite

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Brady360® 5-year Warranty

*Excludes repairs due to negligence. Excludes Wraptor™, BradyJet and portable models.

BBP85 Benchtop Printers

BBP®85 Label Materials

Indoor / Outdoor Grade Vinyl Tape (B-595)

• Durable, low-shrink vinyl with our most aggressive adhesive and 8-10 year outdoor durability

• Conforms to irregular, curved, rough and highly textured surfaces (painted cinder blocks and wood, textured plastics, cast-iron and paper-jacketed pipes, powder-coated surfaces)

Service temp: -40° F to 180° F; Application temp: 0° F to 180° F Average outdoor durability: 8-10 year outdoor vinyl label durability

Figure 33

BBP85Benchtop Printers

Fits Printers Figure Catalog # B# Color

BBP85, PMK Fig. 33 13538 B-595 White 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13549 B-595 White 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13651 B-595 White 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13551 B-595 White 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13562 B-595 White 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13539 B-595 Yellow 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13550 B-595 Yellow 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13652 B-595 Yellow 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13552 B-595 Yellow 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13563 B-595 Yellow 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13540 B-595 Red 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13601 B-595 Red 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13654 B-595 Red 7.000 (177.8) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 BBP85, PMK Fig. 33 13610 B-595 Red 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13541 B-595 Blue 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13602 B-595 Blue 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13656 B-595 Blue 7.000 (177.8) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13554 B-595 Blue 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13611 B-595 Blue 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13542 B-595 Green 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13603 B-595 Green 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13655 B-595 Green 7.000 (177.8) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13555 B-595 Green 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13612 B-595 Green 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13543 B-595 Orange 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13604 B-595 Orange 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13653 B-595 Orange 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK BBP85, PMK Fig. 33 13613 B-595 Orange 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13544 B-595 Black 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13605 B-595 Black 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13557 B-595 Black 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13614 B-595 Black 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13545 B-595 Gold 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13606 B-595 Gold 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13558 B-595 Gold 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13615 B-595 Gold 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13546 B-595 Gray 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13607 B-595 Gray 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13559 B-595 Gray 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13616 B-595 Gray 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13547 B-595 Brown 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13608 B-595 Brown 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13560 B-595 Brown 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13617 B-595 Brown 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13548 B-595 Purple 4.000 (101.6) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13609 B-595 Purple 6.000 (152.4) 50 (15.2) 1 roll (cont) 13513 BBP85, PMK Fig. 33 13561 B-595 Purple 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 13618 B-595 Purple 10.000 (254.0) 50 (15.2) 1 roll (cont) 13512 BBP85, PMK Fig. 33 59529 B-595 Clear 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 59530 B-595 Clear 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511 BBP85, PMK Fig. 33 59531 B-595 Clear 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510 BBP85, PMK Fig. 33 59532 B-595 Clear 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

U.S. Patent No. 5,318,370; 5,823,689; 6,570,602. Additional patents pending.

Fig. 33 13556 B-595 Orange 8.000 (203.2) 50 (15.2) 1 roll (cont) 13510

13553 B-595 Red 8.000 (203.2) 50 (15.2) 1 roll (cont) 13512

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

Low-Halide Polyester (B-569)

• For labeling stainless steel and smooth surfaces

• Low-halide content for labeling stainless steel surfaces

• Applies best to very smooth surfaces and is ideal for mounting to rigid panels

Service temp: -40° F to 212° F; Application temp: 0° F to 212° F Average outdoor durability: 3-5 years

BBP®85 Label Materials

Figure 33

Fits Printers Figure Catalog # B# Color

BBP85, PMK Fig. 33 13565 B-569 White 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13569 B-569 White 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13573 B-569 White 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13577 B-569 White 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13566 B-569 Yellow 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13570 B-569 Yellow 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13574 B-569 Yellow 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13578 B-569 Yellow 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13567 B-569 Orange 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13571 B-569 Orange 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13575 B-569 Orange 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13579 B-569 Orange 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 99167 B-569 Ochre 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33

BBP85, PMK Fig. 33 99169 B-569 Ochre 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 99170 B-569 Ochre 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13564 B-569 Clear 4.000 (101.6) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13568 B-569 Clear 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511

BBP85, PMK Fig. 33 13572 B-569 Clear 7.000 (177.8) 50 (15.2) 1 roll (cont) 13510

BBP85, PMK Fig. 33 13576 B-569 Clear 10.000 (254.0) 50 (15.2) 1 roll (cont) 13510

99168 B-569 Ochre 6.000 (152.4) 50 (15.2) 1 roll (cont) 13511

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

PowerMark™ Label Maker Materials

The BBP85 printer accepts many of the same materials that the PowerMark. Simply look for “BBP85” or “A” on the supply roll’s label to verify compatibility with both models.

Questions? Call Brady Tech Support at 1-800-643-8766.

BBP85 Benchtop Printers

BBP®85 Label Materials

Pre-Printed GHS / CLP Chemical Labels (B-7569)

• For GHS and hazard communication labeling

• Blank labels with pre-printed red diamonds save time during label printing

• 6 diamond layouts that match templates in Brady Workstation App and

standalone printer app

• Indoor / outdoor vinyl withstands exposure to moisture, chemicals and handling

Service temp: -4° F to 180° F; Application temp: 50° F to 180° F Average outdoor durability: 3-5 years

Fits Printers Catalog # B# Legend

BBP85 130766 B-7569 L1 diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

BBP85 130772 B-7569 L1 diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

BBP85 130767 B-7569

BBP85 130773 B-7569 L2 diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

BBP85 130768 B-7569

BBP85 130774 B-7569 L3A diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

BBP85 130769 B-7569

BBP85 130775 B-7569 L3B diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

BBP85 130770 B-7569

BBP85 130776 B-7569 L4A diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

BBP85 130771 B-7569

BBP85 130777 B-7569 L4B diamond + text 6.100 (154.9) 8.300 (210.8) 1 70 13510

L2 diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

L3A diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

L3B diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

L4A diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

L4B diamond + text 4.100 (104.1) 6.100 (154.9) 1 90 13511

Label Height Inch (mm)

Label Width Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Pre-Printed Pre-Cut Blank Sign Headers (B-595, B-7569)

• For creating arc ﬂash and safety warning labels in seconds

• Create custom, colorful safety labels using only a black ribbon

• Meet NFPA 70E, OSHA 1910.145 and ASME / ANSI Z535 standards

• Indoor / outdoor grade material conforms to rough,

highly textured, and difﬁcult to adhere to surfaces

B-595 vinyl: Service temp: -40° F to 180° F; Application temp: 0° F to 180° F Average outdoor durability: 8-10 years outdoor vinyl durability

B-7569 vinyl: Service temp: -4° F to 167° F; Application temp: 50° F to 167° F Average outdoor durability: Up to 3 years vinyl durability

HEADERDER

Figure 70

Figure 82

BBP85Benchtop Printers

Fits Printers Figure Catalog # B# Header

BBP85 Fig. 70 140886 B-7569 10.000 (254.0) 14.000 (355.6) 40 13510

BBP85 Fig. 70 130750 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130749 B-595 4.000 (101.6) 6.000 (152.4) 95 13511 BBP85 Fig. 70 140887 B-7569

BBP85 Fig. 70 130753 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130752 B-595 4.000 (101.6) 6.000 (152.4) 95 13511

BBP85 Fig. 70 140888 B-7569 BBP85 Fig. 70 130756 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130755 B-595 4.000 (101.6) 6.000 (152.4) 95 13511 BBP85 Fig. 70 140889 B-7569 BBP85 Fig. 70 130759 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130758 B-595 4.000 (101.6) 6.000 (152.4) 95 13511 BBP85 Fig. 70 140885 B-7569 BBP85 Fig. 70 130762 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130761 B-595 4.000 (101.6) 6.000 (152.4) 95 13511 BBP85 Fig. 70 140890 B-7569 BBP85 Fig. 70 130765 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 70 130764 B-595 4.000 (101.6) 6.000 (152.4) 95 13511 BBP85 Fig. 82 140883 B-7569

BBP85 Fig. 82 132393 B-595 7.000 (177.8) 10.000 (254.0) 60 13510 BBP85 Fig. 82 140884 B-7569 BBP85 Fig. 82 132395 B-595 7.000 (177.8) 10.000 (254.0) 60 13510

Label Height A Inch (mm)

10.000 (254.0) 14.000 (355.6) 40 13510

Label Width B Inch (mm)

Labels Per Roll

Rec. Ribbon

Creating On-Demand Rigid Signs

Rigid Sign Blanks

Create your own rigid signs using printed output from your Brady printer and rigid sign panels.

Three mounding techniques to choose from:

• Mount label to a rigid sign panel using the label’s pressure sensitive adhesive

• Use the BLS1255 Laminating System to laminate output to a rigid sign panel

• Mount label behind a clear acrylic sign panel using the panel’s included pressure sensitive adhesive

BBP®85 Label Materials

Aluminum panels

Catalog # Material Color

146083 Alum. 146113 Alum.

13629 Alum.

106461 Alum.

146082 Alum. 13632 Alum. 106460 Alum. 106462 Alum. 13635 Alum. 146116 Alum. 146117 Alum. 13630 Alum. 146114 Alum. 146115 Alum. 13633 Alum. 13636 Alum. 13631 Alum. Org 4.250 6.250 10 13634 Alum. Org 7.625 10.375 10 15Y885 Alum. Org 10.250 14.250 10

Height (inch)

Wht

2.500 6.260 10

Wht

2.500 10.250 10

Wht

4.250 6.250 10

Wht

4.250 10.250 10

Wht

4.250 14.250 10

Wht

7.250 10.250 10

Wht

7.630 10.380 10

Wht

10.250 10.250 10

Wht

10.250 14.250 10

Ylw

2.500 6.260 10

Ylw

2.500 10.250 10

Ylw

4.250 6.250 10

Ylw

4.250 10.250 10

Ylw

4.250 14.250 10

Ylw

7.625 10.375 10

Ylw

10.250 14.250 10

Length (inch)

Plastic panels

Catalog # Material Color

Qty

146076 Plastic 146077 Plastic 13620 Plastic 146074 Plastic 146075 Plastic 13623 Plastic 146080 Plastic 146081 Plastic 13621 Plastic 146078 Plastic 146079 Plastic 13622 Plastic Org 4.250 6.250 10 13625 Plastic Org 7.630 10.380 10 13628 Plastic Org 10.250 14.250 10

BLS1255 Laminating System

BLS1255 laminator enables you to quickly and easily make custom rigid signs for your facility

• Mount signs to rigid panels to create signs for your facility

• Fast and easy to use

• No heat or electricity needed

• Laminate documents up to 12 in. wide

Catalog # Description

105038 BLS1255 Laminating System 105041 12 in. x 50 ft. Double-Sided Polyester Overlaminate

Height (inch)

Wht

2.500 6.250 10

Wht

2.500 10.250 10

Wht

4.250 6.250 10

Wht

4.250 10.250 10

Wht

4.250 14.250 10

Wht

7.630 10.380 10

Ylw

2.500 6.250 10

Ylw

2.500 10.250 10

Ylw

4.250 6.250 10

Ylw

4.250 10.250 10

Ylw

4.250 14.250 10

Length (inch)

Clear acrylic panels

Includes pressure sensitive adhesive

Qty

backing to mount output behind the clear panel — protecting the graphics

Catalog # Material Color

13638 Acrylic Clear 4.000 6.000 10 106464 Acrylic Clear 4.250 10.250 10 13639 Acrylic Clear 7.250 10.000 10 106463 Acrylic Clear 7.250 10.250 10 13640 Acrylic Clear 10.000 14.000 10 106465 Acrylic Clear 10.25 in. 10.25 in. 10

Height (inch)

Length (inch)

Qty

BBP85 Benchtop Printers

Laminates documents up to 12 in. wide

BBP®85 Label Materials

Pre-Printed Right-To-Know Chemical Labels (B-595)

• For quickly creating NFPA and color bar labels

• Blank die-cut labels pre-printed with chemical diamonds and color bars

• Indoor / outdoor grade material withstands exposure to moisture, chemicals and handling

• Allows printer to produce 5-color chemical labels in a single print pass

Service temp: -40° F to 180° F; Application temp: 0° F to 180° F Average outdoor durability: 8 to 10 years outdoor vinyl label durability

BBP85Benchtop Printers

Fits Printers Catalog # B# Legend

BBP85 130808 B-595 Diamond + text 4.000 (101.6) 6.000 (152.4) 1 95 13511

BBP85 130809 B-595 Diamond + text 7.000 (177.8) 10.000 (254.0) 1 60 13510

BBP85 130810 B-595

BBP85 130811 B-595

BBP85 130812 B-595 Color bar + text 7.000 (177.8) 10.000 (254.0) 1 60 13510

Diamond only 6.000 (152.4) 6.000 (152.4) 1 95 13511

Color bar + text 4.000 (101.6) 6.000 (152.4) 1 95 13511

Label Height Inch (mm)

Label Width Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Retro Reective Tape (B-584)

• For highly reﬂective identiﬁcation that shines back brightly when struck by light

• Ideal for labeling outdoor metal utility poles, pedestals, jobsite equipment and roof-top equipment especially in low light

Service temp: -40° F to 158° F; Average outdoor durability: 4 to 6 years Application temp: 0° F to 158° F (yellow and orange), 50° F to 158° F (silver)

Fits Printers Figure Catalog # B# Color

BBP85, PMK Fig. 33 13580 B-584 Silver 4.000 (101.6) 33 (10.0) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13585 B-584 Silver 7.000 (177.8) 33 (10.0) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13590 B-584 Silver 10.000 (254.0) 33 (10.0) 1 roll (cont) 13510 BBP85, PMK Fig. 33 51584 B-584 Yellow 4.000 (101.6) 33 (10.0) 1 roll (cont) 13511 BBP85, PMK Fig. 33 51585 B-584 Yellow 7.000 (177.8) 33 (10.0) 1 roll (cont) 13510 BBP85, PMK Fig. 33 51586 B-584 Yellow 10.000 (254.0) 33 (10.0) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13404 B-584 Orange 4.000 (101.6) 33 (10.0) 1 roll (cont) 13511 BBP85, PMK Fig. 33 13403 B-584 Orange 7.000 (177.8) 33 (10.0) 1 roll (cont) 13510 BBP85, PMK Fig. 33 13402 B-584 Orange 10.000 (254.0) 33 (10.0) 1 roll (cont) 13510

Label Width A Inch (mm)

Figure 33

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

BradyGlo™ High-Intensity Photoluminescent Tape (B-526)

• Identiﬁcation that glows in the dark for up to 10 hours

• Ideal for marking emergency utility shut-offs, ﬁre extinguishers, alarm pulls, and vital equipment controls

Service temp: -40° F to 140° F; Application temp: 40° F to 140° F

Fits Printers Figure Catalog # B# Color

BBP85, PMK Fig. 33 105912 B-526 Luminous Green 4.000 (101.6) 33 (10.0) 1 roll (cont) 13511 or 13595 BBP85, PMK Fig. 33 105913 B-526 Luminous Green 7.000 (177.8) 33 (10.0) 1 roll (cont) 13510 or 13514 BBP85, PMK Fig. 33 105914 B-526 Luminous Green 10.000 (254.0) 33 (10.0) 1 roll (cont) 13510 or 13514

Label Width A Inch (mm)

Figure 33

Roll Length B Feet (m)

Labels Per Roll

Rec. Ribbon

BBP®85 Print Ribbons

BBP85 Printer Ribbons

Choose from a variety of heavy-duty, smear-proof ribbons, including single color and multi-color paneled ribbons. These ribbons are uniquely designed with memory cells that communicate information to the BBP85 printer.

Single color print ribbons

Fits Printers Catalog # Color

BBP85, PMK 13511 Black 6.250 (158.0) 200 (60.9) BBP85, PMK 13510 Black 8.800 (224.0) 200 (60.9) BBP85, PMK 13513 White 6.250 (158.0) 200 (60.9) BBP85, PMK 13512 White 8.800 (224.0) 200 (60.9) BBP85, PMK 13595 Red 6.250 (158.0) 200 (60.9) BBP85, PMK 13514 Red 8.800 (224.0) 200 (60.9) BBP85, PMK 13596 Blue 6.250 (158.0) 200 (60.9) BBP85, PMK 13515 Blue 8.800 (224.0) 200 (60.9) BBP85, PMK 13597 Green 6.250 (158.0) 200 (60.9) BBP85, PMK 13516 Green 8.800 (224.0) 200 (60.9) BBP85, PMK 13598 Magenta 6.250 (158.0) 200 (60.9) BBP85, PMK 13517 Magenta 8.800 (224.0) 200 (60.9) BBP85, PMK 13599 Yellow 6.250 (158.0) 200 (60.9) BBP85, PMK 13518 Yellow 8.800 (224.0) 200 (60.9) BBP85, PMK 13600 Orange 6.250 (158.0) 200 (60.9) BBP85, PMK 13519 Orange 8.800 (224.0) 200 (60.9)

Size Inch (mm)

Length Foot (m)

Single color print ribbon

Four-color panel print ribbon

Two-color panel print ribbon

Two-color panel print ribbons

Fits Printers Catalog # Color

8 in. panels used to create two color signs up to 8 in. long

BBP85, PMK 13523 Black and Red 6.250 (158.0) 8.000 (203.2) 200 (60.9) 100 labels (8 in.) BBP85, PMK 13522 Black and Red 8.800 (223.5) 8.000 (203.2) 200 (60.9) 100 labels (8 in.) BBP85, PMK 13527 Black and Yellow 6.250 (158.0) 8.000 (203.2) 200 (60.9) 100 labels (8 in.) BBP85, PMK 13529 Black and Orange 6.250 (158.0) 8.000 (203.2) 200 (60.9) 100 labels (8 in.) BBP85, PMK 13704 Black and Green 6.250 (158.0) 8.000 (203.2) 200 (60.9) 100 labels (8 in.) BBP85, PMK 13706 Black and Green 8.800 (223.5) 8.000 (203.2) 200 (60.9) 100 labels (8 in.)

15 in. panels used to create two color signs up to 14 in. long

BBP85, PMK 13521 Black and Red 6.250 (158.0) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13520 Black and Red 8.800 (223.5) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13525 Black and Blue 6.250 (158.0) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13524 Black and Blue 8.800 (223.5) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13526 Black and Yellow 8.800 (223.5) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13528 Black and Orange 8.800 (223.5) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13705 Black and Green 6.250 (158.0) 15.000 (381.0) 200 (60.9) 60 labels (14 in.) BBP85, PMK 13707 Black and Green 8.800 (223.5) 15.000 (381.0) 200 (60.9) 60 labels (14 in.)

Ribbon Width Inch (mm)

Color Panel Length Inch (mm)

Overall Length Feet (m)

Typical Yield From Ribbon

Four-color panel print ribbons

Fits Printers Catalog # Color

8 in. panels used to create four color signs up to 8 in. long

BBP85, PMK 13533 Black / Red / Blue / Yellow 6.250 (158.0) 8.000 (203.2) 200 (60.9) 50 labels (8 in.) BBP85, PMK 13532 Black / Red / Blue / Yellow 8.800 (223.5) 8.000 (203.2) 200 (60.9) 50 labels (8 in.) BBP85, PMK 13537 Black / Red / Blue / Green 6.250 (158.0) 8.000 (203.2) 200 (60.9) 50 labels (8 in.) BBP85, PMK 13536 Black / Red / Blue / Green 8.800 (223.5) 8.000 (203.2) 200 (60.9) 50 labels (8 in.) BBP85, PMK 51448 Black / Red / Orange / Blue 8.800 (223.5) 8.000 (203.2) 200 (60.9) 50 labels (8 in.)

15 in. panels used to create four color signs up to 14 in. long

BBP85, PMK 13531 Black / Red / Blue / Yellow 6.250 (158.0) 15.000 (381.0) 200 (60.9) 30 labels (14 in.) BBP85, PMK 13530 Black / Red / Blue / Yellow 8.800 (223.5) 15.000 (381.0) 200 (60.9) 30 labels (14 in.) BBP85, PMK 13535 Black / Red / Blue / Green 6.250 (158.0) 15.000 (381.0) 200 (60.9) 30 labels (14 in.) BBP85, PMK 13534 Black / Red / Blue / Green 8.800 (223.5) 15.000 (381.0) 200 (60.9) 30 labels (14 in.)

Ribbon Width Inch (mm)

Color Panel Length Inch (mm)

Overall Length Feet (m)

Typical Yield From Ribbon

BBP85 Benchtop Printers

BradyJet J2000 Color Label Printer

Benchtop Printers J2000

new

Improve productivity and safety with color

Get the impactful color labels you need to create a safer, more efﬁcient workplace. The BradyJet J2000 Color Label Printer is a compact on-demand, mid-volume inkjet solution for creating photo-quality color labels in a single pass, while improving efﬁciency and saving you money. With the BradyJet J2000 you’ll beneﬁt from:

Colorful identication – get more impactful identiﬁcation with more than 16 million color options for your labels

Quick identication when you need it – efﬁcient printing means you keep your workplace running smoothly

Savings on costs and space – get custom identiﬁcation in a small footprint without the high cost of outsourced printing

Printer at-a-glance

• Full-color CMYK inkjet printing

• Fast 2.5 in. per second print speeds

• Output up to 4 inches wide

• Small and lightweight at only 7 lbs

• 15 SFID parts, 2 materials

Printing supplies

J20-series materials .................... page 85

J20-series ink cartridge

............. see table

1 ink cartridge = 16 million colors

Catalog # Description

J2000 BradyJet J2000 Inkjet Label Printer

J2000-BWSSFID

J20-CMY J20 Ink Cartridge J20-PAD J20 Ink Pads

J20-ROLL

* Printer ships with ink cartridge, material roll for printhead alignment only, USB with drivers and manuals, power cord, USB cable and Quick Start Guide.

BradyJet J2000 with Brady Workstation SFID Suite

J20 material roll for print head alignment

Improve productivity and safety

Facility tags And moreLock labelsPipe markingGHS labelingPhoto signage

BradyJet J2000 Color Label Printer

Printer speciﬁcations

Description Full-color, high-resolution ink jet

Applications GHS labels, pipe markers,

Label material types Inkjet receptive topcoated vinyl,

Types of labels Continuous and die-cut labels

Print technology Thermal inkjet

Print resolution Up to 4800 dpi

Max print width 4 in.

Media widths 1.125 to 4.25 in.

Minimum label size 1.125 in.

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting No

PC-connect or standalone operation

Connectivity options USB only

Compatible software Brady Workstation Apps

Compatible materials J20 series (all)

Calibration required Required only on initial setup

Ink and label roll installation

Warranty 1 year*

printer for creating photo-quality labels in a single pass, while reducing inventory of labeling supplies. Signiﬁcantly smaller footprint than BradyJet J5000

warehouse marking, visual workplace labeling, lean / 5S labels, lockout tags, general ID Industrial ID, laboratory ID

polyester and tagstock

Full-color process; up to 16.7 million colors

PC-connect only

Labels: Supplied as rolls, 20-second changeover Ink: Supplied as cartridge, 10-second changeover

Brady Workstation Safety and Facility ID Suite

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Benchtop PrintersJ2000

BradyJet J2000 Label Materials

BradyJet J2000 materials feature a topcoat that enhances the colors and protects your print from smudging and harsh conditions. These labels have been tested to withstand exposure to liquids, alcohol and chemicals, as well as indoor ﬂuorescent and UV lighting.

Die-cut Labels

Figure Catalog # B# Material Color

Fig. 2 J20-260-2569 B-2569 Polyester White 2.170 (55.11) 3.350 (85.09) 340 Fig. 2 J20-261-2569 B-2569 Polyester White 2.950 (74.93) 4.330 (109.98) 270 Fig. 2 J20-262-2569 B-2569 Polyester White 4.130 (104.90) 6.100 (154.94) 200 Fig. 2 J20-260-2595 B-2595 Vinyl White 2.170 (55.11) 3.350 (85.09) 340 Fig. 2 J20-261-2595 B-2595 Vinyl White 2.950 (74.93) 4.330 (109.98) 270 Fig. 2 J20-262-2595 B-2595 Vinyl White 4.130 (104.90) 6.100 (154.94) 200

Label Width A Inch (mm)

Continuous Material

Figure Catalog # B# Material Color

Fig. 3 J20C-1125-2569 B-2569 Polyester White 1.125 (28.57) 100 (30.5) 1 cont. Fig. 3 J20C-2250-2569 B-2569 Polyester White 2.250 (57.15) 100 (30.5) 1 cont. Fig. 3 J20C-4000-2569 B-2569 Polyester White 4.000 (101.6) 100 (30.5) 1 cont. Fig. 3 J20C-1125-2595 B-2595 Vinyl White 1.125 (28.57) 100 (30.5) 1 cont. Fig. 3 J20C-2250-2595 B-2595 Vinyl White 2.250 (57.15) 100 (30.5) 1 cont. Fig. 3 J20C-4000-2595 B-2595 Vinyl White 4.000 (101.6) 100 (30.5) 1 cont.

Label Width A Inch (mm)

Non-adhesive Tagstock

Figure Catalog # B# Material Color

Fig. 13 J20-255-2551 B-2551 Tagstock White 3.250 (82.55) 5.750 (146.05) 100 Fig. 3 J20C-3250-2551 B-2551 Tagstock White 3.250 (82.55) 50 ft (15.24 m) 1 cont. Fig. 3 J20C-2500-2551 B-2551 Tagstock White 2.500 (63.50) 50 ft (15.24 m) 1 cont.

Label Width A Inch (mm)

Label Height B Inch (mm)

Roll Length B Feet (m)

Tag Length B Inch (mm)

Labels Per Roll

Tags Per Roll

Figure 2

Figure 3

Figure 13

BradyJet J5000 Color Label Printer

High-resolution, high-speed full-color label creation

Get the impactful color labels you need to create a safer, more efﬁcient workplace. The BradyJet J5000 Color Label Printer is an on-demand, inkjet solution for creating photo-quality color labels for indoor use in a single pass, while reducing your inventory of labeling supplies and material waste.

• 4,800 dpi print resolution for high-resolution clarity and ﬁne detail

• Full-color photo reproduction and wide tonal range allows for labels with photos, graphics, illustrations, text, linear and 2D bar codes

• More than 16 million color possibilities with only 4 ink cartridges

• Large ink cartridges that reduce the amount of changeovers or replacements

Printer at-a-glance

• Full-color CMYK inkjet printing

• High-resolution print ideal for photos

• Large output up to 8 in. wide

• PC-connect only

• 18 parts, 2 materials

• Fast print speeds up to 6 inches per second

• Print up to 5,000 high resolution labels per day, using only the ink and label materials needed to keep waste and inventory down

• Variety of label options with 2 to 8 inch wide continuous and die-cut materials

J5000Benchtop Printers

Printing supplies

J50-series labels rolls ....................page 88

J50-series Ink cartridges

Easy to load supplies can be changed in seconds.

...............page 88

High-resolution and full-color identication throughout your facility

Catalog # Description

J5000 BradyJet J5000 Color Label Printer*

* Printer ships with printhead with set-up ink cartridges, set-up CD, USB cable, power cord, Quick Start Guide.

GHS hazcommPipe markingAsset managementSafety signage

Standard work /

dance chart

Photo signage

and more

BradyJet J5000 Color Label Printer

Printer speciﬁcations

Description

Applications

Label material types

Types of labels

Print technology

Print resolution

Max print width

Media widths

Minimum label size

Color printing capabilities

Auto cut-off Ye s

X-Y plotter cutting No

PC-connect or standalone operation

Connectivity options USB, Ethernet and wireless

Compatible software Brady Workstation Apps

Compatible materials J50 series (all)

Calibration required Required only on initial setup

Ink and label roll installation

Warranty 1 year*

8 in. PC-connect printer with high-resolution, high-speed color label printing. Ideal for creating full-color labels with images, logos, illustrations, barcodes and more. The ultimate in high-resolution printing in all colors

Arc ﬂash labels (w/ red variables), equipment labels, GHS labels, pipe markers, safety signs and warning labels (multi-color), lean / 5S labels, multi-color labels, lock labels (w/ photos), asset management, department signage, ﬁnished goods

Inkjet receptive topcoated vinyl and polyester

Continuous and die-cut labels

Thermal inkjet

Up to 4800 dpi

4 in.

2 to 8 in.

2 in.

Full color process; up to 16.7 million colors

PC-connect only

Labels: Supplied as rolls, 20-second changeover Ink: Supplied as cartridge, 10-second changeover

Brady Workstation Safety and Facility ID Suite

This suite features:

• A collection of applications for creating the custom signs, labels and pipe markers you need to add visual safety guidance to your facility

• The ability to serialize and import your data onto the labels

• Real-time information about the label material installed, enabling easy label set up

• Built-in regulations, standards, pictograms, common phrases, data importation guidance, help functions and more

Full-color printing means less material to inventory

Three white BradyJet J5000 label rolls can create the same types of labels

as these 14 colored and pre-printed rolls.

J5000 Benchtop Printers

BradyJet J5000 Label Materials

BradyJet J5000 label materials feature a topcoat that enhances the colors and label appearance, and protects your print from smudging and harsh conditions. These labels have been tested to withstand exposure to liquids, alcohol and chemicals, as well as indoor ﬂuorescent and UV lighting Custom sizes of B-2595 and B-2569 available.

Die-cut Labels

Figure Catalog # B# Material Color

Fig. 2 J50-260-2595 B-2595 Vinyl White 3.35 (85.0) 2.17 (55.0) 340 Fig. 2 J50-261-2595 B-2595 Vinyl White 4.33 (110.0) 2.95 (75.0) 270 Fig. 2 J50-262-2595 B-2595 Vinyl White 6.10 (155.0) 4.13 (105.0) 200 Fig. 2 J50-267-2595 B-2595 Vinyl White 8.30 (210.8) 6.10 (154.9) 120 Fig. 2 J50-265-2595 B-2595 Vinyl White 10.00 (254.0) 7.00 (177.8) 100 Fig. 2 J50-260-2569 B-2569 Polyester White 3.35 (85.0) 2.17 (55.0) 340 Fig. 2 J50-261-2569 B-2569 Polyester White 4.33 (110.0) 2.95 (75.0) 270 Fig. 2 J50-262-2569 B-2569 Polyester White 6.10 (155.0) 4.13 (105.0) 200 Fig. 2 J50-267-2569 B-2569 Polyester White 8.30 (210.8) 6.10 (154.9) 120 Fig. 2 J50-265-2569 B-2569 Polyester White 10.00 (254.0) 7.00 (177.8) 100

Label Width A Inch (mm)

Continuous Tapes

Figure Catalog # B# Material Color

Fig. 3 J50C-2250-2595 B-2595 Vinyl White 2.25 (57.5) 100 (30.5) 1 cont. Fig. 3 J50C-4000-2595 B-2595 Vinyl White 4.00 (101.6) 100 (30.5) 1 cont. Fig. 3 J50C-6000-2595 B-2595 Vinyl White 6.00 (152.4) 100 (30.5) 1 cont. Fig. 3 J50C-8000-2595 B-2595 Vinyl White 8.00 (203.2) 100 (30.5) 1 cont. Fig. 3 J50C-2250-2569 B-2569 Polyester White 2.25 (57.5) 100 (30.5) 1 cont. Fig. 3 J50C-4000-2569 B-2569 Polyester White 4.00 (101.6) 100 (30.5) 1 cont. Fig. 3 J50C-6000-2569 B-2569 Polyester White 6.00 (152.4) 100 (30.5) 1 cont. Fig. 3 J50C-8000-2569 B-2569 Polyester White 8.00 (203.2) 100 (30.5) 1 cont.

Label Width A Inch (mm)

Roll Length B Inch (mm)

Roll Length B Feet (m)

Labels Per Roll

Figure 2

Figure 3

J5000Benchtop Printers

Non-adhesive Tag Stock

Figure Catalog # B# Material Color

Fig. 13 J50-255-2551 B-2551 Vinyl Tag White 3.250 (82.6) 5.750 (146.1) 100

Label Width A Inch (mm)

Roll Length B Inch (mm)

Clear Acrylic Overlaminate (B-910)

• Clear acrylic ﬁlm with permanent adhesive provides improved label durability including outdoor UV resistance up to 3 years

• Hand apply after label is applied to surface

• Overlaminate is slightly wider than BradyJet continuous tape

Catalog # B# Color

149259 B-910 Clear 2.75 (69.9) 120 (36.6) 149258 B-910 Clear 4.5 (114.3) 120 (36.6) 149257 B-910 Clear 6.5 (165.1) 120 (36.6) 149260 B-910 Clear 8.5 (215.9) 120 (36.6)

Roll Width Inch (mm)

Roll Length Feet (m)

BradyJet J5000 Ink Cartridges

Catalog # Description

J50-CY Cyan J50-MA Magenta J50-YL Yellow J50-BK Black — cartridge contains double the volume as colors J50-CMYK Multi-pack — 1 each of cyan, magenta, yellow, black cartridges

Tags Per Roll

Figure 13

BradyJet J5000 Color Label Printer

Creating On-Demand Rigid Signs

Rigid Sign Blanks

Create your own rigid signs using printed output from your Brady printer and rigid sign panels.

Three mounding techniques to choose from:

• Mount label to a rigid sign panel using the label’s pressure sensitive adhesive

• Use the BLS1255 Laminating System to laminate output to a rigid sign panel

• Mount label behind a clear acrylic sign panel using the panel’s included pressure sensitive adhesive

Aluminum panels

Catalog # Material Color

146083 Alum. 146113 Alum.

13629 Alum.

106461 Alum.

Height (inch)

Wht

2.500 6.260 10

Wht

2.500 10.250 10

Wht

4.250 6.250 10

Wht

4.250 10.250 10

Wht

4.250 14.250 10

Wht

7.250 10.250 10

Wht

7.630 10.380 10

Wht

10.250 10.250 10

Wht

10.250 14.250 10

Ylw

2.500 6.260 10

Ylw

2.500 10.250 10

Ylw

4.250 6.250 10

Ylw

4.250 10.250 10

Ylw

4.250 14.250 10

Ylw

7.625 10.375 10

Ylw

10.250 14.250 10

Length (inch)

Plastic panels

Catalog # Material Color

Qty

BLS1255 Laminating System

BLS1255 laminator enables you to quickly and easily make custom rigid signs for your facility

• Mount signs to rigid panels to create signs for your facility

• Fast and easy to use

• No heat or electricity needed

• Laminate documents up to 12 in. wide

Height (inch)

Wht

2.500 6.250 10

Wht

2.500 10.250 10

Wht

4.250 6.250 10

Wht

4.250 10.250 10

Wht

4.250 14.250 10

Wht

7.630 10.380 10

Ylw

2.500 6.250 10

Ylw

2.500 10.250 10

Ylw

4.250 6.250 10

Ylw

4.250 10.250 10

Ylw

4.250 14.250 10

Length (inch)

Clear acrylic panels

Includes pressure sensitive adhesive

Qty

backing to mount output behind the clear panel — protecting the graphics

Catalog # Material Color

Height (inch)

Length (inch)

Qty

J5000 Benchtop Printers

Catalog # Description

105038 BLS1255 Laminating System 105041 12 in. x 50 ft. Double-Sided Polyester Overlaminate

Laminates documents up to 12 in. wide

MiniMark™ Label Materials

Benchtop Printers MiniMark

The MiniMark printer has been discontinued, but Brady continues to manufacture and stock labels and ribbons for the printer.

Indoor / Outdoor Grade Vinyl (B-595)

• Conforms well to irregular, curved, rough and highly textured surfaces

• 8-10 year average outdoor durability in temperatures from -40° F to 180° F. Labels can be applied in temperatures from 0° F to 180° F

• Patent Number D481.414

White 113186 113185 113184 113183 113182 103025 Yellow 113195 113194 113193 113192 113191 103025 Red 113199 113198 113197 – 113196 103026

Blue 113211 113210 113209 – 113208 103026

Green 113207 113206 113205 – 113204 103026

Black 113215 113214 113213 – 113212 103026 Brown 115762 115761 115760 – 115759 103026

Gold - 115757 115756 – 115755 103025 Grey 115754 115753 113219 – 113218 103025

Purple 115752 115751 113217 – 113216 103026

Orange 113203 113202 113201 – 113200 103025 Clear 113190 113189 113188 – 113187 103025

0.500 in. x 100 ft. (12.7 mm x 30.48 m)

1.125 in. x 100 ft. (28.6 mm x 30.48 m)

2.250 in. x 100 ft. (57.2 mm x 30.48 m)

Figure 33b

3.000 in. x 100 ft. (76.2 mm x 30.48 m)

4.000 in. x 100 ft. (101.6 mm x 30.48 m)

Rec. Ribbon

General Purpose Indoor / Outdoor Vinyl (B-7569)

• Excellent for facility, safety, chemical and lean 5S labeling

• Five year average outdoor durability in temperatures from -40° F to 180° F. Labels can be applied in temperatures from 0° F to 180° F

• Patent Number D481.414

1.125 in. x 110 ft. (28.6 mm x 30.48 m)

White 120847 120854 120861 52042 Yellow 120848 120855 120862 52042 Red 120849 120856 120863 52042 Orange 120852 120859 120866 52042

Blue 120851 120858 120865 52044 Green 120850 120857 120864 52044

Black 120853 120860 120867 52044

2.250 in. x 110 ft. (57.2 mm x 30.48 m)

Figure 33b

4.000 in. x 110 ft. (101.6 mm x 30.48 m)

Rec. Ribbon

Pre-Printed Header Stripe Supply

for Arc Flash Labels and Signs (B-595)

• Pre-printed continuous stripe on top portion, then supply is cut-to-length according to length of text entered

MiniMark™ Label Materials

Figure 71

Diagram Catalog # Material Stripe Color

Fig. 71 113221 B-595 Red 4.000 (101.6) 100 (30.48) 1.000 (25.4) 1 roll (cont.) 103025 Fig. 71 113230 B-595 Red 2.250 (57.15) 100 (30.48) 0.500 (12.7) 1 roll (cont.) 103025 Fig. 71 113222 B-595 Orange 4.000 (101.6) 100 (30.48) 1.000 (25.4) 1 roll (cont.) 103025 Fig. 71 113227 B-595 Orange 3.000 (76.2) 100 (30.48) 0.750 (19.05) 1 roll (cont.) 103025 Fig. 71 113228 B-595 Orange 2.250 (57.15) 100 (30.48) 0.500 (12.7) 1 roll (cont.) 103025 Fig. 71 113220 B-595 Yellow 4.000 (101.6) 100 (30.48) 1.000 (25.4) 1 roll (cont.) 103025 Fig. 71 113226 B-595 Yellow 3.000 (76.2) 100 (30.48) 0.750 (19.05) 1 roll (cont.) 103025 Fig. 71 113229 B-595 Yellow 2.250 (57.15) 100 (30.48) 0.500 (12.7) 1 roll (cont.) 103025

Label Height A Inch (mm)

Roll Length B Feet (m)

Stripe Width C Inch (mm)

Labels Per Roll

Rec. Ribbon

Tamper-Evident Metallized Polyester (B-438)

• Permanent adhesive

• Tape destructs into tiny fragments when tampered with, making removal very tedious and difﬁcult

Diagram Catalog # Material Color

Fig. 29 52148 B-438 Silver 2.000 (50.8) 1.000 (25.4) 1 1,240 103025 Fig. 29 52149 B-438 Silver 3.000 (76.2) 1.000 (25.4) 1 1,225 103025 Fig. 29 52150 B-438 Silver 3.000 (76.2) 2.000 (50.8) 1 650 103025 Fig. 29 52152 B-438 Silver 3.000 (76.2) 110 ft. (33.5 m) - 1 roll (cont.) 103025

Label Width A Inch (mm)

Figure 29

Label Height B Inch (mm)

Labels Per Row

Labels Per Roll

Rec. Ribbon

Benchtop PrintersMiniMark

MiniMark Print Ribbons

Ribbons for B-595 and B-438 materials Ribbons for B-7569 material

Catalog # Roll Size Color

103026 4 in. x 290 ft. White 2 103025 4 in. x 290 ft. Black 2

Rolls Per Pack

Catalog # Roll Size Color

52044 4.4 in. x 290 ft. White 2 52042 4.4 in. x 290 ft. Black 2 52045 4.4 in. x 290 ft. Red 2 52059 4.4 in. x 290 ft. Green 2 52047 4.4 in. x 290 ft. Blue 2

Rolls Per Pack

GlobalMark® Label Materials

GlobalMark Version 2 Logo Concepts

The GlobalMark printer has been discontinued, but Brady continues to manufacture and stock labels and accessories for the printer.

GlobalMark2 Printer Accessories

Catalog # Description

120994 Rolling case w/ handle and supplies pockets for benchtop printers STYLUS-3PK Stylus Pens (3/pk) 64MB-CF 256MB Memory Card 76811 Replacement Cutting Blade 76737 Transfer Tape (4.25 in. x 300 ft.) 20596 Grommets for Tags (100/pk) 20591 Hole Punch for Tags 81762 7 in. Nylon Cable Ties (100/pk)

GlobalMarkBenchtop Printers

Pre-Printed Blank Sign Headers (B-595)

• Allows printer to create multicolor signs fast - in a single print pass

• Headers meet NFPA 70E, OSHA 1910.145 and ASME / ANSI Z535 standards

• Indoor / outdoor grade material conforms to rough, highly textured, and “difﬁcult to adhere to” surfaces

Service temp: -40ºF to 180ºF; Application temp: 0ºF to 180ºF Average Outdoor Durability: 8-10 years

Diagram Catalog # B# Header

Fig. 73 121550 B-595 2.250 (57.2) 3.250 (82.6) 1 270 76739 Fig. 73 121558 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121552 B-595 Fig. 73 121560 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739

Fig. 73 121551 B-595 Fig. 73 121559 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121549 B-595 Fig. 73 121557 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121553 B-595 Fig. 73 121561 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121554 B-595 Fig. 73 121562 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121563 B-595 Fig. 73 121547 B-595 2.250 (57.2) 3.250 (82.6) 1 270 76739 Fig. 73 121564 B-595 2.250 (57.2) * 3.750 (95.2) 1 250 76739 Fig. 73 121555 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739 Fig. 73 121548 B-595 Fig. 73 121556 B-595 4.000 (101.6) 6.250 (158.8) 1 165 76739

*Pre-sized to ﬁt blank rigid valve tags below, but can also be used as general purpose label.

Label Height A Inch (mm)

2.250 (57.2) 3.250 (82.6) 1 270 76739

1.125 (28.6) * 2.750 (69.8) 1 300 76739

2.250 (57.2) 3.250 (82.6) 1 270 76739

Figure 73

Label Width B Inch (mm)

HEADERDER HE

Labels Per Row

Labels Per Roll

Rec. Ribbon

Blank Rigid Valve Tags

• Die-cut labels are sized to ﬁt the recessed area on the tag

• Outdoor tag withstands temperatures

-40° F to 180° F

Blank rigid valve tags

Catalog # Color

Tag Size Inch

Recessed Area Inch

Catalog # Color

87712 Ta n 2.1 x 3.6 1.5 x 3 87713 Ta n 3.1 x 4.6 2.5 x 4 87710 Brown 2.1 x 3.6 1.5 x 3 87711 Brown 3.1 x 4.6 2.5 x 4 87698 Gray 2.1 x 3.6 1.5 x 3 87699 Gray 3.1 x 4.6 2.5 x 4 41920 Black 2.1 x 3.6 1.5 x 3 41921 Black 3.1 x 4.6 2.5 x 4 142133 Variety Pack*

* Pack of 30 tags includes at least one of each size and color. Perfect for evaluating which sizes and colors you need.

Tag Size Inch

Recessed Area Inch

GlobalMark® Label Materials

Non-Adhesive and Pre-Cut Safety Tags (B-551)

• Non-adhesive semi rigid card stock with perforations between tags

HEADER

• Tags are pre-cut with hole and chamfered corners

• Snap-in plastic grommets available for extra strength around mounting hole

Service temp: -40ºF to 193ºF; Average Outdoor Durability: up to 2 years

Figure 69

Diagram Catalog # B# Header

Fig. 69 121543 B-551 3.250 (82.6) 5.750 (146.1) 1 100 76739

Fig. 69 121544 B-551 3.250 (82.6) 5.750 (146.1) 1 100 76739

Fig. 69 121545 B-551 3.250 (82.6) 5.750 (146.1) 1 100 76739

Fig. 69 121546 B-551 3.250 (82.6) 5.750 (146.1) 1 100 76739

Tag Width A Inch (mm)

Tag Height B Inch (mm)

Tags Per Row Tags Per Roll Rec. Ribbon

Right-to-Know Labels (B-595)

• Outdoor grade vinyl adhesive label in Color Bar or NFPA 704M diamond formats

• 4-color diamond or bars are pre-printed so that labels only require 1-color print pass (black) through the printer

Catalog # B# Legend

115763 B-595 Diamond + Text 4.000 (101.6) 6.250 (158.8) 1 170 96089

115766 B-595 Diamond + Text 2.250 (57.2) 4.000 (101.6) 1 240 96089

115772 B-595 Diamond + Text 2.250 (57.2) 2.250 (57.2) 1 365 96089

115765 B-595

115773 B-595 Diamond Only 2.250 (57.2) 2.250 (57.2) 1 365 96089

115764 B-595

115767 B-595 Color Bar + Text 2.250 (57.2) 4.000 (101.6) 1 240 96089

115771 B-595

115768 B-595

115770 B-595

115769 B-595

Overlaminate for RTK Labels (B-674)

Protect your printed labels with a pressure sensitive polyester overlaminate.

Diamond Only 4.000 (101.6) 4.000 (101.6) 1 240 96089

Color Bar + Text 4.000 (101.6) 6.250 (158.8) 1 170 96089

Color Bar + Text 2.250 (57.2) 2.250 (57.2) 1 365 96089

Color Bar Only 2.250 (57.2) 2.250 (57.2) 1 365 96089

Color Bar HMIG 1.125 (28.6) 3.000 (76.2) 1 300 96089

Diamond NFR 1.125 (28.6) 3.000 (76.2) 1 300 96089

Catalog # B# Color

64984 B-674 Clear 1.500 (38.1) 2.500 (63.5) 50 58476 B-674 Clear 2.500 (63.5) 2.500 (63.5) 50 58706 B-674 Clear 3.500 (88.9) 5.500 (139.7) 50 64985 B-674 Clear 4.500 (114.3) 6.500 (165.1) 50

Label Width Inch (mm)

Label Height Inch (mm)

Label Width Inch (mm)

Labels Per Row

Label Height Inch (mm)

Labels Per Pkg

Rec. Ribbon

Labels Per Pkg

GlobalMark Benchtop Printers

GlobalMark® Label Materials

Indoor / Outdoor Grade Vinyl Tape (B-595)

• Conforms well to irregular, curved, rough and highly textured surfaces

• Low-shrink vinyl minimizes the amount of unsightly dust and grime buildup often found around the edges of other vinyl labeling supplies

• 8-10 year average outdoor durability in temperatures from -40° F to 180° F (-40° C to 82° C). Labels can be applied in temperatures from 0° F to 180° F

Figure 33

GlobalMarkBenchtop Printers

Diagram Catalog # B# Color

Fig. 33 113109 B-595 Fig. 33 113110 B-595

Fig. 33 113111 B-595 White 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113112 B-595 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113113 B-595 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113114 B-595 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113115 B-595 Yellow 3.000 (76.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113116 B-595 Yellow 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113117 B-595 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113118 B-595 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113119 B-595 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113120 B-595 Red 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113121 B-595 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113122 B-595 Red 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113127 B-595 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113128

Fig. 33 113129 B-595 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113130 B-595 Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113123 B-595 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113124 B-595 Green 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113125 B-595 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113126 B-595 Green 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113131 B-595 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113132 B-595 Black 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113133 B-595 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113134 B-595 Black 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113135 B-595 Brown 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113136 B-595 Brown 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113137 B-595 Brown 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113138 B-595 Brown 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113139 B-595 Gold 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113140 B-595 Gold 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113141 B-595 Gold 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113142 B-595 Gold 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113143 B-595 Grey 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113144 B-595 Grey 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113145 B-595 Grey 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113146 B-595 Grey 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113147 B-595 Purple 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113148 B-595 Purple 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113149 B-595 Purple 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113150 B-595 Purple 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741

Fig. 33 113151 B-595 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113152 B-595 Orange 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113153 B-595 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113154 B-595 Orange 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113105 B-595 Clear 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113106 B-595 Clear 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 113107 B-595 Clear 1.125 (28.6) 100 (30.5)

Fig. 33 113108 B-595 Clear 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

B-595 Blue 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741

White White

Label Width A Inch (mm)

4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

3.000 (76.2) 100 (30.5) 1 roll (cont.) 76739

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

1 roll (cont.) 76739

GlobalMark® Label Materials

Polyester Tape (B-569)

• Continuous outdoor grade polyester

• Best choice for marking stainless steel pipes and surfaces (low halide content)

• Ultra-smooth ﬁnish excellent for mounting to rigid panels and very smooth surfaces

• Applies best to very smooth surfaces

Figure 33

Diagram Catalog # B# Color

FIg.33 76614 B-569 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76615 B-569 White 3.000 (76.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76616 B-569 White 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76617 B-569 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76618 B-569 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76619 B-569 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76620 B-569 Yellow 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76621 B-569 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76622 B-569 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76623 B-569 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76624 B-569 Red 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76625 B-569 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76626 B-569 Red 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76627 B-569 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76628 B-569 Blue 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76629 FIg.33 76630 B-569 Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76639 B-569 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76640 B-569 Green 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76641 B-569 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76642 B-569 Green 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76647 B-569 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76648 B-569 Black 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76649 B-569 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76650 B-569 Black 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76643 B-569 Brown 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76644 B-569 Brown 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76645 B-569 Brown 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76646 B-569 Brown 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76602 B-569 Tan 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76603 B-569 Tan 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76604 B-569 Tan 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76651 B-569 Grey 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76652 B-569 Grey 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76653 B-569 Grey 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76654 B-569 Grey 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76631 B-569 Purple 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76632 B-569 Purple 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76633 B-569 Purple 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76634 B-569 Purple 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76635 B-569 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76636 B-569 Orange 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76637 B-569 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76638 B-569 Orange 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76598 B-569 Pink 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76599 B-569 Pink 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76600 B-569 Pink 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76601 B-569 Pink 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76606 B-569 Lt. Blue 4.000 (101.6) 100 (30.5) FIg.33 76607 B-569 Lt. Blue 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76608 B-569 Lt. Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 FIg.33 76609 B-569 Lt. Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76741 FIg.33 97738 B-569 Ochre 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97739 B-569 Ochre 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97740 B-569 Ochre 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97741 B-569 Ochre 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97742 B-569 Sky Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97743 B-569 Sky Blue 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97744 B-569 Sky Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 97745 B-569 Sky Blue 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76610 B-569 Clear 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76611 B-569 Clear 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76612 B-569 Clear 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 FIg.33 76613 B-569 Clear 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

B-569 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

1 roll (cont.) 76741

GlobalMark Benchtop Printers

GlobalMark® Label Materials

ToughStripe® Print-On-Demand Floor Labels (B-483)

• Revolutionary B-483 material has ultra aggressive adhesive

• Withstands forklift and pallet jack trafﬁc without tearing or lifting

• Easy 3-step process: print label, position on ﬂoor, apply overlaminate

• Each roll ships with a roll of clear overlaminate which must be applied over printed label and onto appropriate surface for best performance

• Plotter-cutting shapes and text not allowed with this material

Figure 33

Diagram Catalog # B# Color

Fig. 33 142155 B-483 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142154 B-483 White 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142156 B-483 White 3.000 (76.2) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142157 B-483 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142162 B-483 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142161 B-483 Yellow 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142163 B-483 Yellow 3.000 (76.2) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142164 B-483 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142166 B-483 Red 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142165 B-483 Red 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142167 B-483 Red 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142169 B-483 Blue 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142168 B-483 Blue 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142170 B-483 Blue 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142172 B-483 Green 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142171 Fig. 33 142173 B-483 Green 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142159 B-483 Black 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142158 B-483 Black 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142160 B-483 Black 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76741 Fig. 33 142175 B-483 Orange 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142174 B-483 Orange 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 142176 B-483 Orange 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

B-483 Green 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Label Width A Inch (mm)

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Phosphorescent Tape (B-526)

• Permanent adhesive and glows in darkness for 10 hours

• Glows brighter and longer than B-582

• Complies with indoor use requirments speciﬁed in RS 6-1 and

6-1A of New York Local Law 26

• Plotter-cutting shapes and text not allowed with this material

Figure 33

GlobalMarkBenchtop Printers

Diagram Catalog # B# Color

Fig. 33 105909 B-526 Phosphorescent 4.000 (101.6) 50 (15.2) 1 roll (cont.) 76739, 76743 Fig. 33 105910 B-526 Phosphorescent 2.250 (57.2) 50 (15.2) 1 roll (cont.) 76739, 76743

Fig. 33 105911 B-526 Phosphorescent 1.125 (28.6) 50 (15.2) 1 roll (cont.) 76739, 76743

Phosphorescent Tape (B-582)

• Permanent adhesive and glows in darkness for hours

• Meets ISO, and ASTM standards

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color

Fig. 33 76711 B-582 Phosphorescent 4.000 (101.6) 50 (15.2) 1 roll (cont.) 76739, 76743 Fig. 33 76712 B-582 Phosphorescent 2.250 (57.2) 50 (15.2) 1 roll (cont.) 76739, 76743

Fig. 33 76713 B-582 Phosphorescent 1.125 (28.6) 50 (15.2) 1 roll (cont.) 76739, 76743

Label Width A Inch (mm)

Figure 33

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

GlobalMark® Label Materials

ToughWash® Tape (B-854, B-855)

• Withstands pressures of high heat, harsh chemicals

and numerous washdown cycles

• B-854 offers metal detectable layer to detect

foreign debris in food stream

• Ideal for use in the Food and Beverage industry

• Plotter-cutting shapes and text not allowed with this material

Figure 33

HEADERDER HE

Figure 73

Diagram Catalog # B# Legend

B-854 ToughWash

Fig. 33 133134 B-854 4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) 134352

Fig. 33 133133 B-854

Fig. 73 133141 B-854

Fig. 73 133140 B-854

Fig. 73 139812 B-854

Fig. 73 133139 B-854

B-855 ToughWash Material

Fig. 33 133159 B-855 4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) 134352

Fig. 33 133158 B-855

Fig. 73 133166 B-855

Fig. 73 133165 B-855

Fig. 73 139811 B-855

Fig. 73 133164 B-855

Metal Detectable Material

Label Width A Inch (mm)

4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) 134352

4.000 (101.06) 6.250 (158.8) 100 134352

4.000 (101.06) 50 ft. (15.2 m) 1 roll (cont.) 134352

4.000 (101.06) 6.250 (158.8) 100 134352

Length B Inch (mm)

Labels Per Roll Rec. Ribbon

Reective Tape (B-584)

• Permanent adhesive / outdoor grade

• Shines back at viewer brightly when light shines on label

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color

Fig. 33 76705 B-584 Silver 4.000 (101.6) 50 (15.2) 1 roll (cont.) 76739 Fig. 33 76706 B-584 Silver 2.250 (57.2) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 76707 B-584 Silver 1.125 (28.6) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 96060 B-584 Yellow 4.000 (101.6) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 96061 B-584 Yellow 2.250 (57.2) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 96062 B-584 Yellow 1.125 (28.6) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 99219 B-584 Orange 4.000 (101.6) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 99220 B-584 Orange 2.250 (57.2) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 99221 B-584 Orange 1.125 (28.6) 50 (15.2) 1 roll (cont.) 76739

Label Width A Inch (mm)

Figure 33

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

Tag Stock Material (B-551)

• Non-adhesive tag stock meets OSHA 50 lb. pull requirement

• Grommets and hole punch available

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color

Fig. 33 76714 B-551 White 4.250 (107.9) 50 (15.2) 1 roll (cont.) 76739 Fig. 33 76715 B-551 White 3.250 (82.5) 50 (15.2) 1 roll (cont.) 76739

Fig. 33 76716 B-551 White 2.500 (63.5) 50 (15.2) 1 roll (cont.) 76739

Label Width A Inch (mm)

Figure 33

Roll Length B Feet (m)

Labels Per Roll Rec. Ribbon

GlobalMark Benchtop Printers

GlobalMark® Label Materials

Repositionable Vinyl Tape (B-581)

• Special adhesive allows you to easily remove the label and re-apply

• Ideal for indoor marking where frequent repositioning is required

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color Label Width A Inch (mm) Roll Length B Feet (m) Labels Per Roll Rec. Ribbon

Fig. 33 76697 B-581 White 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 76698 B-581 White 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76699 B-581 White 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76700 B-581 White 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76701 B-581 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76702 B-581 Yellow 2.250 (57.2) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76703 B-581 Yellow 1.125 (28.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76704 B-581 Yellow 0.500 (12.7) 100 (30.5) 1 roll (cont.) 76739

Magnetic Tape (B-509)

• Non-adhesive

• Print directly onto magnetic material

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color Label Width A Inch (mm) Roll Length B Feet (m) Labels Per Roll Rec. Ribbon

Fig. 33 76686 B-509 White 4.000 (101.6) 25 (7.62) 1 roll (cont.) 76739 Fig. 33 76687 B-509 White 2.500 (63.5) 25 (7.62) 1 roll (cont.) 76739

Fig. 33 76688 B-509 Yellow 4.000 (101.6) 25 (7.62) 1 roll (cont.) 76739

Fig. 33 76689 B-509 Yellow 2.500 (63.5) 25 (7.62) 1 roll (cont.) 76739

Figure 33

GlobalMarkBenchtop Printers

Cold Temperature Tape (B-549)

• Permanently adheres to surfaces at temperatures as low as -10˚F

• Great for use in any cold storage warehouse, cooler or freezer

• Plotter-cutting shapes and text not allowed with this material

Diagram Catalog # B# Color Label Width A Inch (mm) Roll Length B Feet (m) Labels Per Roll Rec. Ribbon

Fig. 33 76691 B-549 White 4.250 (107.9) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 76692 B-549 White 2.500 (63.5) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76693 B-549 White 1.375 (34.9) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76694 B-549 Yellow 4.000 (101.6) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76695 B-549 Yellow 2.500 (63.5) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76696 B-549 Yellow 1.375 (34.9) 100 (30.5) 1 roll (cont.) 76739

Figure 33

Metallized Polyester Tape (B-565)

• Permanent adhesive

• Non-cuttable supply suitable for continuous-style labels

• Cuttable supply ideal for multi-up, cut labels in basic rectangular and round shapes only. Not suitable for cut-out text or intricate shapes.

Diagram Catalog # B# Color Label Width A Inch (mm) Roll Length B Feet (m) Labels Per Roll Rec. Ribbon

Fig. 33 76720 B-565 Non-cuttable Metalized 4.250 (107.9) 100 (30.5) 1 roll (cont.) 76739 Fig. 33 76721 B-565 Non-cuttable Metalized 2.500 (63.5) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 76722 B-565 Non-cuttable Metalized 1.375 (34.9) 100 (30.5) 1 roll (cont.) 76739

Fig. 33 114533 B-565 Cuttable Metalized 4.250 (107.9) 100 (30.5) 1 roll (cont.) 76739

Figure 33

Transfer Tape For Cut Text

from liner to the desired surface

• Leaves cut characters pre-spaced for transferring

Diagram Catalog #

Fig. 33 76737 4.250 (107.9) 300 ft. (91.44 m)

Label Width A Inch (mm)

Roll Length B Feet (m)

GlobalMark® Print Ribbons

GlobalMark2 Industrial Print Ribbons

• Super-tough smear-proof ribbons assure your printed text lasts for years outdoors and in an industrial environment

• Ribbons ship self-contained in cartridges that drop straight in the printer with a click

• No calibrating, threading, wasted feeding, hassles and the ink will always be facing the right direction

Example of a

Single Color Ribbon

Examples of

Multi-Color Paneled Ribbons

Single Color Print Ribbons

Catalog # Color Size Inch (mm) Length

76739 Black 4.110 (104.4) 200 (60.9) 134352 Black (for use with B-854 and B-855 ToughWash 96089 Black (for use with RTK labels) 4.110 (104.4) 200 (60.9) 76741 White 4.110 (104.4) 200 (60.9) 76743 Red 4.110 (104.4) 200 (60.9) 76745 Blue 4.110 (104.4) 200 (60.9) 76747 Green 4.110 (104.4) 200 (60.9) 76749 Magenta 4.110 (104.4) 200 (60.9) 76751 Yellow 4.110 (104.4) 200 (60.9) 76752 Orange 4.110 (104.4) 200 (60.9) 76759 Process Cyan 4.110 (104.4) 200 (60.9) 76760 Process Yellow 4.110 (104.4) 200 (60.9) 76761 Process Magenta 4.110 (104.4) 200 (60.9)

• 2- and 4-color paneled ribbons are used to print labels and signs containing more than 1 print color

• Patent D481,755

material only) 4.110 (104.4) 200 (60.9)

Two Color Print Ribbons

Catalog # Color Size Inch (mm) Length Panels: 4.110 x 8.000 (104.4 x 203.2 mm)

Typical yield: 100 labels (8 in.) from 8 in. paneled ribbon

76739 Black 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76763 Black and Red 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 110220 76775 Black and Blue 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76767 Black and Yellow 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76771 Black and Orange 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76779 Black and Green 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9)

Panels: 4.110 x 16.000 (104.4 x 406.4 mm) Typical yield: 60 labels (16 in.) from 16 in. paneled ribbon

76762 Black and Red 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76774 Black and Blue 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76766 Black and Yellow 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76770 Black and Orange 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76778 Black and Green 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76782 Red and Blue 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9)

Red and Green 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9)

Four Color Print Ribbons

Catalog # Color Size Inch (mm) Length Panels: 4.110 x 8.000 (104.4 x 203.2 mm)

Typical yield: 50 labels (8 in.) from 8 in. paneled ribbon

76787 Black, Red, Blue and Green 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 110221 Red, Green, Yellow and Black 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76791 Black, Red, Blue and Yellow 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 76795 Cyan, Magenta, Yellow and Black 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9) 51447 Black, Red, Orange and Blue 4.110 x 8.000 (104.4 x 203.2 mm) panels 200 (60.9)

Panels: 4.110 x 16.000 (104.4 x 406.4 mm) Typical yield: 30 labels (16 in.) from 16 in. paneled ribbon

76786 Black, Red, Blue and Green 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76790 Black, Red, Blue and Yellow 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9) 76794 Cyan, Magenta, Yellow and Black 4.110 x 16.000 (104.4 x 406.4 mm) panels 200 (60.9)

GlobalMark Benchtop Printers

Labelizer® Plus and VersaPrinter™ Supplies

The Labelizer PLUS and VersaPrinter have been discontinued, but for a limited time Brady will continue to stock labels for these printers.

Benchtop Printers

Indoor / Outdoor Vinyl Tape with Ribbon (B-595)

• Conforms well to irregular, curved or rough surfaces

• Ideal for general purpose industrial uses – stands up to grease, oil and most industrial chemicals

8-10 year average outdoor durability in temperatures from 180° F to -40° F (82° C to -40° C). Can be applied as low as 0° F (-18° C)

Catalog # B# RIbbon and Tape Color Label Width A Inch (mm) Roll Length B Feet (m)

142760 B-595 Black on Clear 0.500 (12.7) 90 (27.4) 2 142759 B-595 Black on Clear 1.125 (28.6) 90 (27.4) 2 142758 B-595 Black on Clear 2.250 (57.2) 90 (27.4) 1 142757 B-595 Black on Clear 4.000 (101.6) 90 (27.4) 1 142762 B-595 White on Clear 2.250 (57.2) 90 (27.4) 1 142765 B-595 Black on Green 1.125 (28.6) 90 (27.4) 2 142764 B-595 Black on Green 2.250 (57.2) 90 (27.4) 1 142763 B-595 Black on Green 4.000 (101.6) 90 (27.4) 1 142750 B-595 Black on Yellow 0.500 (12.7) 90 (27.4) 2 142749 B-595 Black on Yellow 1.125 (28.6) 90 (27.4) 2 142748 B-595 Black on Yellow 2.250 (57.2) 90 (27.4) 1 142747 B-595 Black on Yellow 3.000 (76.2) 90 (27.4) 1 142746 B-595 Black on Yellow 4.000 (101.6) 90 (27.4) 1 142769 B-595 White on Green 0.500 (12.7) 90 (27.4) 2 142768 B-595 White on Green 1.125 (28.6) 90 (27.4) 2 142767 B-595 White on Green 2.250 (57.2) 90 (27.4) 1 142766 B-595 White on Green 4.000 (101.6) 90 (27.4) 1 142777 B-595 White on Blue 0.500 (12.7) 90 (27.4) 2 142776 B-595 White on Blue 1.125 (28.6) 90 (27.4) 2 142775 B-595 White on Blue 2.250 (57.2) 90 (27.4) 1 142774 B-595 White on Blue 4.000 (101.6) 90 (27.4) 1 142772 B-595 White on Red 0.500 (12.7) 90 (27.4) 2 142773 B-595 White on Red 1.125 (28.6) 90 (27.4) 2 142771 B-595 White on Red 2.250 (57.2) 90 (27.4) 1 142770 B-595 White on Red 4.000 (101.6) 90 (27.4) 1 142756 B-595 Black on Orange 0.500 (12.7) 90 (27.4) 2 142755 B-595 Black on Orange 1.125 (28.6) 90 (27.4) 2 142754 B-595 Black on Orange 2.250 (57.2) 90 (27.4) 1 142753 B-595 Black on Orange 4.000 (101.6) 90 (27.4) 1 142785 B-595 Black on Gray 0.500 (12.7) 90 (27.4) 2 142784 B-595 Black on Gray 1.125 (28.6) 90 (27.4) 2 142783 B-595 Black on Gray 2.250 (57.2) 90 (27.4) 1

Labelizer Plus

142782 B-595 Black on Gray 4.000 (101.6) 90 (27.4) 1 142793 B-595 White on Brown 1.125 (28.6) 90 (27.4) 2 142792 B-595 White on Brown 2.250 (57.2) 90 (27.4) 1 142791 B-595 White on Brown 4.000 (101.6) 90 (27.4) 1 142787 B-595 White on Tan 1.125 (28.6) 90 (27.4) 2 142786 B-595 White on Tan 2.250 (57.2) 90 (27.4) 1 142790 B-595 White on Magenta 1.125 (28.6) 90 (27.4) 2 142789 B-595 White on Magenta 2.250 (57.2) 90 (27.4) 1 142788 B-595 White on Magenta 4.000 (101.6) 90 (27.4) 1 142781 B-595 White on Black 0.500 (12.7) 90 (27.4) 2 142780 B-595 White on Black 1.125 (28.6) 90 (27.4) 2 142779 B-595 142778 B-595 White on Black 4.000 (101.6) 90 (27.4) 1

Labelizer® Plus

Industrial Labeling System

White on Black 2.250 (57.2) 90 (27.4) 1

VersaPrinter Label and Sign Maker

Tape Cartridges Per Pkg.

(Ribbon included in cartridge)

™

100

Labelizer® Plus and VersaPrinter™ Supplies

Low-Halide Polyester Tape (B-569)

• Specially designed with a low halide content – best choice for use on stainless steel and nickel piping and other smooth surfaces

• 8-10 year average outdoor durability in temperatures from 180° F to -40° F (82° C to -40° C) and can be applied as low as 0° F (-18° C)

Catalog # B# RIbbon and Tape Color Label Width A Inch (mm) Roll Length B Feet (m)

64347 B-569 Black on Clear 1.125 (28.6) 110 (33.5) 2 64348 B-569 Black on Clear 2.250 (57.2) 110 (33.5) 1 64349 B-569 Black on Clear 4.000 (101.6) 110 (33.5) 1 64331 B-569 White on Green 1.125 (28.6) 110 (33.5) 2 64332 B-569 White on Green 2.250 (57.2) 110 (33.5) 1 64333 B-569 White on Green 4.000 (101.6) 110 (33.5) 1 64335 B-569 White on Blue 1.125 (28.6) 110 (33.5) 2 64336 B-569 White on Blue 2.250 (57.2) 110 (33.5) 1 64339 B-569 White on Red 1.125 (28.6) 110 (33.5) 2 64340 B-569 White on Red 2.250 (57.2) 110 (33.5) 1 64355 B-569 Black on White 1.125 (28.6) 110 (33.5) 2 64356 B-569 Black on White 2.250 (57.2) 110 (33.5) 1 64357 B-569 Black on White 4.000 (101.6) 110 (33.5) 1

Tape Cartridges Per Pkg.

(Ribbon included in cartridge)

Reective Tape (B-584)

• Reﬂective capabilities are ideal for reading labels in low light areas both indoors and out

Catalog # B# RIbbon and Tape Color Label Width A Inch (mm) Roll Length B Feet (m)

64739 B-584 Black on White 1.125 (28.6) 75 (22.8) 2

64740 B-584 Black on White 2.250 (57.2) 75 (22.8) 1

64741 B-584 Black on White 4.000 (101.6) 75 (22.8) 1

64401 B-584 Black on Orange 2.250 (57.2) 58 (17.7) 1

64402 B-584 Black on Orange 4.000 (101.6) 75 (22.8) 1

64403 B-584 Black on Yellow 1.125 (28.6) 69 (21.0) 2

64404 B-584 Black on Yellow 2.250 (57.2) 58 (17.7) 1

64405 B-584 Black on Yellow 4.000 (101.6) 75 (22.8) 1

Tape Cartridges Per Pkg.

(Ribbon included in cartridge)

Overlaminates (B-674)

• Hand apply overlaminate after label is applied for improved label durability

Catalog # B# RIbbon and Tape Color Label Width A Inch (mm) Roll Length B Feet (m) Cartridges Per Pkg.

25966 B-674 Clear 0.750 (19.05) 30 (9.1) 1

25967 B-674 Clear 1.375 (34.9) 30 (9.1) 1

25968 B-674 Clear 2.500 (63.5) 30 (9.1) 1

25969 B-674 Clear 4.250 (107.9) 30 (9.1) 1

Repositionable Vinyl Tape (B-581)

• Special adhesive allows easy removal of label with reapplication again and again

• Ideal for indoor use where frequent repositioning is required, such as storage shelves

Catalog # B# RIbbon and Tape Color Label Width A Inch (mm) Roll Length B Feet (m)

64731 B-581 Black on White 1.125 (28.6) 90 (27.4) 2

64732 B-581 Black on White 2.250 (57.2) 90 (27.4) 1

64733 B-581 Black on White 4.000 (101.6) 90 (27.4) 1

64735 B-581 Black on Yellow 1.125 (28.6) 90 (27.4) 2

64736 B-581 Black on Yellow 2.250 (57.2) 90 (27.4) 1

64737 B-581 Black on Yellow 4.000 (101.6) 90 (27.4) 1

Tape Cartridges Per Pkg.

(Ribbon included in cartridge)

Benchtop Printers

Labelizer Plus

101

Brady Benchtop Printer Comparison Catalog Page

Specifications and Main Features

Frequently Asked Questions

User Manual
