CCTV | WZ16 Integrated Day/Night High-res Bullet Camera
145 (5.71)
1/4”-20 mount
WZ16 Integrated Day/Night High-res Bullet
Camera
SuperHAD 1/3 in CCD, 520 TVL
▶
18 m (59 ft) night vision in zero lux
▶
Mechanical lens filter for 24/7 performance
▶
4 to 9 mm varifocal lens
▶
Compact, all-weather housing
▶
The WZ16 provides reliable day and night surveillance in a
compact, water resistant design that integrates 18 infrared
LEDs for 18 m (59 ft) of IR-cut filtered night vision.
Incorporating a SuperHAD 1/3 in CCD, the WZ16 delivers
520 TVL color imaging during day and 18 m (59 ft) of activeinfrared night vision under zero lux.
The WZ16 also features a mechanical IR-cut lens filter for
accurate daytime color and exceptional performance under
infrared. Mechanical filter technology minimizes IR bleed
and prevents focus shift from daytime to night-time modes.
The WZ16 uses 18 photocell-controlled infrared LEDs to
deliver up to 18 m (59 ft) of night vision for effective 24/7
performance. Photocell-controlled LEDs ensure accurate
on/off switching and help increase energy efficiency.
The WZ16 includes a versatile mounting bracket suitable for
walls, surfaces and ceilings, as well as a sun hood.
Constructed of extruded aluminum, the WZ16 is compact
and discreet, featuring an anodized silver finish.
The WZ16 is a quick and easy Plug-and-Play solution for
24/7 day and night surveillance.
Functions
Applications
Industrial sites
•
Casinos
•
Warehouses
•
Service stations
•
Commercial
•
Parking lots
•
Retail
•
Perimeters
•
Transportation hubs
•
Ports
•
Residential
•
Hotels and nightclubs
•
Schools and colleges
•
Installation/Configuration Notes
www.boschsecurity.com
2 | WZ16 Integrated Day/Night High-res Bullet Camera
Ø60
(2.36)
65.4 (2.58)
115 (4.53)
1/4”-20 mount
60 (2.36)
97
(3.82)
max.
2.5mm wrench
1/4”-20 UNC
36 (1.42)
41.6
(1.64)
3-Ø4.5
mm (in)
Technical Specifications
Video
Signal Processing Digital signal processing (DSP)
CCD Camera 1/3 in SuperHAD CCD
Filter IR-Cut, lens mounted
Resolution High resolution 520 TVL
Effective Pixels (H x V) PAL: 752 x 582, NTSC: 768 x 494
Night-Time Sensitivity 0 lux (infrared on)
Electronics Iris 1/50 to 1/100,000 s (PAL),
1/60 to 1/100,000 s (NTSC)
Output Signal 1 VPP composite video, 75 ohm
S/N Ratio Greater than 48 dB
Gamma 0.45
Lens Varifocal 4 to 8 mm, DC auto-iris
LEDs Infrared array, photocell-controlled
Wavelength 850 nm
Number of LEDs 18
Electrical
Voltage 12 to 24 VDC or VAC
Power Draw 700 mA maximum
Power Supply Not included
Mechanical
Construction Robust aluminum extrusion
Finish Anodized silver
Sunshield Included as standard
Bracket Pan-tilt bracket included as standard
Weight 0.56 kg (1.2 lb)
Dimensions Ø 60 x 145 (L) mm (2.4 x 5.7 in)
Environmental
Operation Temperature
Range
Environment IP67 compliant
-30 ºC to +55 ºC (-22 ºF to +131 ºF)
Ordering Information
WZ16NV408‑0 IDN High-res Bullet Camera
IDN bullet cam, 520TVL, SuperHAD, color
switching to bw, lens filter, 18LEDs, silver,
NTSC, 4 to 8 mm lens, PSU separate
WZ16PV408‑0 IDN High-res Bullet Camera
IDN bullet cam, 520TVL, SuperHAD, color
switching to bw, lens filter, 18LEDs, silver,
PAL, 4 to 8 mm lens, PSU separate
Accessories
EXPS.008 VAC Power Supply
Power supply 120 VAC/ 24 VAC 1500 mA
PSU-230‑24 Power Supply
Power Supply, 230 VAC / 24 VAC, 50 W
WZ16 Integrated Day/Night High-res Bullet Camera | 3
WZ16NV408‑0
WZ16PV408‑0
EXPS.008
PSU230-24
