Video | AUTODOME 4000
AUTODOME 4000
www.boschsecurity.com
u True day/night camera with 30x optical zoom
u 720 TVL resolution
u Wide Dynamic Range (WDR)
The AUTODOME 4000 Mini PTZ Dome is a rugged,
compact, high-resolution, day/night camera that
delivers uncompromised functionality and
performance at a very affordable price. It features a
30x optical zoom (10x digital zoom), a horizontal
resolution of 720 TVL (NTSC and PAL), privacy
masking, Wide Dynamic Range (WDR), and a built-in
heater.
With a dome diameter of only 4.4 inches (11.2 cm),
the AUTODOME 4000 is about 70% smaller than
traditional PTZ cameras and 20% smaller than most
other compact domes. These compact dimensions
make the AUTODOME 4000 ideal for discrete
surveillance applications in both indoor and outdoor
environments.
Certifications and approvals
u Compact, vandal-resistant (IK10 rated) enclosure
u Suitable for indoor and outdoor use
Installation/configuration notes
Region Certification
Europe CE
USA UL
FCC
Australia CTICK
Dimensions, Camera Side
4-Ø4.8
85.6
85.6
2 | AUTODOME 4000
Dimensions, Camera Bottom
Parts included
Quantity Component
1 AUTODOME 4000 Mini PTZ Dome Camera
1 Drilling Template for flush mount
4 6 x 30 mm plastic anchors
4 #8 x 32 screws and attached O-rings
4 M4 x 12 Torx screws and attached O-rings
1 T20 Security Torx wrench
1 Installation Manual
Technical specifications
Camera
Imager 1/4" Double Scan Super HAD CCD II
Lens size fW=3.49 ±0.17 mm fT=104.02 ±5.20
mm
(30x +/- 10% Optical Zoom)
Effective Pixels PAL: 976 (H) x 582 (V)
NTSC: 976 (H) x 494 (V)
Horizontal Resolution 720 TVL (NTSC, PAL)
Optical Zoom 30x Effective Optical Zoom
Digital Zoom 10x
Field of View
2.46° (TELE) to 69.5° (Wide)
(approximate)
Focus Automatic with manual override
Signal-to-Noise Ratio
>50 dB
(SNR)
White Balance Auto, indoor, outdoor, one push
Minimum Illumination 0.2 Lux/ F1.65
0.001 Lux/DSS
0.1 Lux/ICR
Wide Dynamic Range
On/Off
(WDR)
Dynamic Noise
3DNR
Reduction (DNR)
Privacy 15 zones maximum
Mechanical
Weight 1.5 kg (3.3 lb)
Pan Range 360° continuous
Tilt Range 0° to 180° (90° when 3D Privacy Masking
is enabled)
Flip Rotate 180° at bottom of tilt
Auto Scan 8 Auto Scan modes including vector scan
Pre-position Speed 360°/s
Preset Positions 99 (Bosch OSRD);
210 (Pelco P/D) positions with camera
status
Tours 8 Tours (Preset, Pattern, Scan)
Patterns 8 Patterns
On-Screen Display (OSD) Camera ID, Title, Mode, and Angle (multi-
language)
Multi-language OSD English, Chinese, Dutch, French, German,
Italian, Russian, Spanish
Electrical
Power Supply 24 VAC ± 10%, 50/60 Hz
Built-in power line surge
Power Requirements 24 VAC adapter, 1 A (2.5 A with heater)
Power Consumption 24 VAC, 850 mA / 20 W (without heater)
24 VAC, 2A / 45 W (with heater)
Alarm Input 4 normal dry contacts (selectable NC/NO)
Alarm Output 1 normal relay 5 VDC / 40 mA maximum
(selectable NC/NO)
Control RS-485; baud rate: 2400-38.4 Kbps
(default = 9600 bps)
Access Time 0.75 second maximum preset recall time
Camera Address (ID) Physical - 99
Environmental
Ingress Protection Rating IP66
External Mechanical
IK10
Impact
(IK Code or Impact
rating)
Iris Control Auto
3 | AUTODOME 4000
Operating Temperature -40 °C to +50 °C (-40 °F to +122 °F)
Heater works automatically from -40 °C/°F
to +10 °C (+50 °F)
Heater thermostat On/Off at 0 °C to 10 °C (32 °F to 50 °F)
Installation Humidity 80% relative humidity (RH)
Storage Temperature -20 °C to +60 °C (-4 °F to +140 °F)
Communications
Camera Setup/Control RS-485; Bosch Biphase with converter
(sold separately)
Communications
Protocols
Bosch, Pelco P/D;
(Bosch Biphase to RS-485 converter
(MIC-BP3), sold separately)
Construction
Housing Material Cast aluminum
Color White or Charcoal
Size (Diameter x Height) Ø154 x 138 mm (H)
(Ø 6.06 x 5.43 in.)
Bubble Ø112 mm (Ø 4.41 in.) polycarbonate;
clear or tinted
Ordering information
Accessories
UPA-2450-50 Power Supply, 220 V, 50 Hz
Indoor, 220 VAC, 50 Hz In; 24 VAC, 50 VA Out
Order number UPA-2450-50
UPA-2450-60 Power Supply, 120 V, 60 Hz
Indoor, 120 VAC, 60 Hz In; 24 VAC, 50 VA Out
Order number UPA-2450-60
MIC-BP3 Biphase Converter
Biphase converter for IR power supplies or non-IR
power supplies without a free expansion slot available
Order number MIC-BP3
VIP-X1XF
H.264 dual-stream 1‑channel encoder, VCA ready
Order number VIP-X1XF
VEZ-A4-IC VEZ-400 IN-CEILING MOUNT
Order number VEZ-A4-IC
VGA-IC-SP In-ceiling Support Kit
Suspended ceiling support kit for FLEXIDOME cameras
(requires VDA-PLEN-DOME kit).
Order number VGA-IC-SP
AUTODOME 4000 Pipe Mount, Charcoal
Order number VEZ-A4-PC
AUTODOME 4000 Pipe Mount, White
Order number VEZ-A4-PW
AUTODOME 4000 Mini PTZ Dome 30x PAL camera,
white, clear bubble
Order number VEZ-413-EWCS
AUTODOME 4000 Mini PTZ Dome 30x PAL camera, charcoal, clear bubble
Order number VEZ-413-ECCS
AUTODOME 4000 Mini PTZ Dome 30x PAL camera,
white, tinted bubble
Order number VEZ-413-EWTS
AUTODOME 4000 Mini PTZ Dome 30x PAL camera, charcoal, tinted bubble
Order number VEZ-413-ECTS
AUTODOME 4000 Mini PTZ Dome 30x NTSC camera,
white, clear bubble
Order number VEZ-423-EWCS
AUTODOME 4000 Mini PTZ Dome 30x NTSC camera,
charcoal, clear bubble
Order number VEZ-423-ECCS
AUTODOME 4000 Mini PTZ Dome 30x NTSC camera,
white, tinted bubble
Order number VEZ-423-EWTS
AUTODOME 4000 Mini PTZ Dome 30x NTSC camera,
charcoal, tinted bubble
Order number VEZ-423-ECTS
AUTODOME 4000 Wall Mount, Charcoal
Order number VEZ-A4-WC
AUTODOME 4000 Wall Mount, White
Order number VEZ-A4-WW
VDA-CMT-PTZDOME Corner Mount Adapter
Corner mount adapter for use with the appropriate
wall mount for indoor or outdoor pole (mast)
applications
Order number VDA-CMT-PTZDOME
VDA-POMT-PTZDOME Pole Mount Adapter for AUTODOME 4000 / 5000
Pole mount adapter for use with the appropriate wall
mount for indoor and outdoor applications.
Order number VDA-POMT-PTZDOME
LTC 9213/01 Pole Mount Adapter
Pole mount adapter with stainless steel straps, light
gray finish
Order number LTC 9213/01
4 | AUTODOME 4000
