Fridge-freezer

KGF..

en Instructions for use Fridge-freezer 3

en Table of contents

Safety and warning information ........... 3

Information concerning disposal ......... 6

Scope of delivery ................................... 7

Installation location ................................ 7

Observe ambient temperature

and ventilation ........................................ 8

Connecting the appliance .................... 8

Getting to know your appliance .......... 9

Switching on the appliance ................ 10

Setting the temperature ...................... 11

Special functions .................................. 11

Alarm function ...................................... 13

Home Connect ..................................... 14

Usable capacity .................................... 18

Refrigerator compartment .................. 19

Super cooling ....................................... 20

The VitaFresh compartment ............... 20

Freezer compartment .......................... 21

Freezing capacity ................................. 21

Freezing and storing food .................. 22

Freezing fresh food ............................. 22

Super freezing ...................................... 23

Thawing frozen food ............................ 24

Interior fittings ....................................... 24

Sticker “OK” .......................................... 25

Switching off and disconnecting

the appliance ........................................ 25

Defrosting .............................................. 26

Cleaning the appliance ....................... 26

Light (LED) ............................................ 27

Tips for saving energy ........................ 27

Operating noises ................................. 27

Eliminating minor faults yourself ....... 28

Appliance self-test ............................... 30

Customer service, product / production

number and technical data ................ 30

enTable of contents

enInstructions for useFridge-freezer

Safety and warning information

Before you switch ON the appliance

Please read the operating and installation instructions carefully! They contain important information on how to install, use and maintain the appliance.

The manufacturer is not liable if you fail to comply with the instructions and warnings. Retain all documents for subsequent use or for the next owner.

Technical safety

Fire hazard

The tubes of the refrigeration circuit convey a small quantity of an environmentally friendly but flammable refrigerant (R600a). It does not damage the ozone layer and does not increase the greenhouse effect. If refrigerant escapes, it may injure your eyes or ignite.

If damage has occurred

■ Keep naked flames and/or

ignition sources away from the appliance,

■ thoroughly ventilate the room

for several minutes,

■ switch off the appliance and

pull out the mains plug,

■ inform customer service.

The more refrigerant an appliance contains, the larger the room must be in which the appliance is situated. Leaking refrigerant can form a flammable gas-air mixture in rooms which are too small. The room must be at least 1 m³ per 8 g of refrigerant. The amount of refrigerant in your appliance is indicated on the rating plate inside the appliance.

When installing the appliance, ensure that the mains cable is not trapped or damaged.

If the power cord of this appliance is damaged, it must be replaced by the manufacturer, Customer Service or a similarly qualified person. Improper installations and repairs may put the user at considerable risk.

Repairs may be performed by the manufacturer, customer service or a similarly qualified person only.

Only original parts supplied by the manufacturer may be used. The manufacturer guarantees that only these parts satisfy the safety requirements.

Do not use multiple sockets, extension leads or adapters.

Fire hazard

Portable multiple outlets or power supplies may overheat, causing a fire. Never leave portable multiple outlets or portable power supplies behind the appliance.

Important information when using the appliance

■ Never use electrical

appliances inside the appliance (e.g. heaters, electric ice makers, etc.). Risk of explosion!

■ Never defrost or clean the

appliance with a steam cleaner! The steam may penetrate electrical parts and cause a short-circuit. Risk of electric shock!

■ Do not use additional means

to accelerate the defrosting process other than those recommended by the manufacturer. Risk of explosion!

■ Do not use pointed or sharp-

edged implements to remove frost or layers of ice. You might damage the refrigerant tubes.Leaking refrigerant may cause eye injuries or ignite.

■ Do not store products which

contain flammable propellant (e.g. spray cans) or explosive substances in the appliance. Risk of explosion!

■ Do not stand on or lean

heavily against the base of the appliance, drawers, doors, etc.

■ For defrosting and cleaning,

pull out the mains plug or switch off the fuse. Do not pull out the mains plug by tugging on the power cord.

■ Store high-percentage alcohol

tightly sealed and in an upright position.

■ Keep plastic parts and the

door seal free of oil and grease. Otherwise, plastic parts and the door seal will become porous.

■ Never cover or block the

ventilation openings of the appliance.

■ Do not store bottled or

canned liquids (especially carbonated drinks) in the freezer compartment.Bottles and cans may burst!

■ Never put frozen food straight

from the freezer compartment in your mouth. Risk of low-temperature burns!

■ Avoiding placing children

and vulnerable people at risk:

At risk here are children, people who have limited physical, mental or sensory abilities, as well as people who have inadequate knowledge concerning safe operation of the appliance.

Check that children and vulnerable people have understood the hazards.

A person responsible for safety must supervise or instruct children and vulnerable people who are using the appliance.

Only children aged 8 years and above may use the appliance.

Supervise children while the appliance is being cleaned or maintained.

Never allow children to play with the appliance.

■ Avoid prolonged touching of

frozen food, ice or the evaporator pipes, etc. Risk of low-temperature burns!

Children in the household

■ Keep children away from

packaging and its parts. Danger of suffocation from folding cartons and plastic film!

■ Do not allow children to play

with the appliance!

■ If the appliance features a

lock: keep the key out of the reach of children!

General regulations

The appliance is suitable

■ for refrigerating and freezing

food,

■ for making ice.

This appliance is intended for use in the home and the home environment.

The refrigeration circuit has been checked for leaks.

This appliance complies with the relevant safety regulations for electrical appliances and is fitted with noise suppression.

This appliance is intended for use up to a maximum height of 2000 metres above sea level.



Information concerning disposal

* Disposal of packaging

The packaging protects your appliance from damage during transit. All utilised materials are environmentally safe and recyclable. Please help us by disposing of the packaging in an environmentally friendly manner.

Please ask your dealer or inquire at your local authority about current means of disposal.

* Disposal of your old appliance

Old appliances are not worthless rubbish! Valuable raw materials can be reclaimed by recycling old appliances.

This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as applicable throughout the EU.

m Warning

Redundant appliances

1. Pull out the mains plug.

2. Cut off the power cord and discard with the mains plug.

3. Do not take out the trays and receptacles: children are therefore prevented from climbing in!

4. Do not allow children to play with the appliance once it has spent its useful life. Danger of suffocation!

Refrigerators contain refrigerant and gases in the insulation. Refrigerant and gases must be disposed of professionally. Ensure that tubing of the refrigerant circuit is not damaged prior to proper disposal.

Scope of delivery

After unpacking all parts, check for any damage in transit.

If you have any complaints, please contact the dealer from whom you purchased the appliance or our customer service.

The delivery consists of the following parts:

■ Free-standing appliance

■ Interior fittings (depending on model)

■ Bag containing installation materials

■ Operating instructions

■ Installation manual

■ Customer service booklet

■ Warranty enclosure

■ Information on the energy

consumption and noises

Installation location

A dry, well ventilated room is suitable as an installation location. The installation location should not be exposed to direct sunlight and not placed near a heat source, e.g. a cooker, radiator, etc. If installation next to a heat source is unavoidable, use a suitable insulating plate or observe the following minimum distances from the heat source:

■ 3 cm to electric or gas cookers.

■ 30 cm to an oil or coal-fired cooker.

The floor of the installation location must not give way; if required, reinforce floor. If the floor is uneven, compensate with supports.

Distance from wall

When installing the appliance, ensure that the door can be opened by 90°.

Observe ambient temperature and ventilation

Ambient temperature

The appliance is designed for a specific climate class. Depending on the climate class, the appliance can be operated at the following temperatures.

The climate class can be found on the rating plate. Fig. ,

Climate class Permitted ambient

temperature SN +10 °C to 32 °C N +16 °C to 32 °C ST +16 °C to 38 °C T +16 °C to 43 °C

Note

The appliance is fully functional within the room temperature limits of the indicated climatic class. If an appliance of climatic class SN is operated at colder room temperatures, the appliance will not be damaged up to a temperature of +5 °C.

Ventilation

Fig. " The air on the rear panel and on the side

panels of the appliance heats up. Conduction of the heated air must not be obstructed. Otherwise, the refrigerating unit must work harder. This increases power consumption. Therefore: Never cover or block the ventilation openings!

Connecting the appliance

After installing the appliance, wait at least 1 hour until the appliance is switched on. During transportation the oil in the compressor may have flowed into the refrigeration system.

Before switching on the appliance for the first time, clean the interior of the appliance (see chapter “Cleaning the appliance”).

Electrical connection

The socket must be near the appliance and also freely accessible following installation of the appliance.

m Warning

Risk of electric shock! If the length of the mains cable is

inadequate, never use multiple sockets or extension leads. Instead, please contact Customer Service for alternatives.

The appliance complies with protection class I. Connect the appliance to 220– 240 V/50 Hz alternating current via a correctly installed socket with protective conductor. The socket must be protected by a 10 A to 16 A fuse.

For appliances operated in nonEuropean countries, check whether the indicated voltage and current type match the values of your electricity supply. This information can be found on the rating plate, Fig. ,.

m Warning

Never connect the appliance to electronic energy saver plugs.

Our appliances can be used with mains and sine-controlled inverters. Mainscontrolled inverters are used for photovoltaic systems which are connected directly to the national grid. Sine-controlled inverters must be used for isolated applications (e.g. on ships or in mountain lodges) which are not connected directly to the national grid.

Getting to know your appliance

Please fold out the illustrated last page. These operating instructions refer to several models.

The features of the models may vary. The diagrams may differ. Fig. ! * Not all models.

A Refrigerator compartment B VitaFresh compartment C Freezer compartment

1–18 Controls 19* Butter and cheese compartment 20 Shelf for small bottles

21 Shelf for large bottles 22 Light (LED) 23* Bottle shelf 24* Breakfast set 25 Partition with humidity controller 26 Vegetable container 27 “Cool-fresh” container 28 Frozen food container

Controls

Fig. $

1 Temperature display freezer

compartment The numbers correspond to the set freezer compartment temperatures in °C.

2 Display ALARM

This lights up if the freezer compartment is too warm or if the freezer compartment door is open too long.

3 Display superfreeze

This lights up if super freezing is in operation.

4 Temperature display VitaFresh

Indicates the set temperature of the VitaFresh compartment.

5 Display sabbath

This lights up when the Sabbath mode is switched on.

6 Alarm display

This lights up if the refrigerator compartment door is open too long.

7 Temperature display refrigerator

compartment The numbers correspond to the set refrigerator compartment temperatures in °C.

8 Display supercool

This lights up if super cooling is in operation.

9 Display vacation mode

This lights up when the vacation mode is switched on.

10 Button “lock” function

If this function is switched on, no settings are possible via the controls.

11 Button lock/alarm off

This button is used to

■ switch off the audible warning

signal (see section "Alarm function")

■ Switch the button lock on and

off.

12 Eco mode indicator

This lights up when the eco mode is switched on.

13 Selection button for appliance

zone To make settings for one appliance zone, repeatedly press the selection button.

14 Display ALARM

This lights up if the appliance becomes too warm.

15 Setting buttons +/-

The buttons are used to set the temperatures of the refrigerator and freezer compartment.

16 “super” button

Is used to switch on the super cooling (refrigerator compartment) as well as super freezing (freezer compartment) functions (see chapter Super cooling or chapter Super freezing).

17 Mode button

For selecting the special functions. See chapter entitled “Special functions”.

18 Display freshness mode

This lights up when the freshness mode is switched on.

Switching on the appliance

1. First insert the plug into the connection on the back of the appliance. Check that the plug has been inserted all the way.

2. Then insert the other end of the cable into the socket.

The appliance is now switched on and a warning signal sounds.

Press the lock/alarm off button to switch off the audible warning signal.

The ALARM display goes out when the appliance has reached the set temperature.

The preset temperatures are reached after several hours. Do not put any food in the appliance beforehand.

The factory has recommended the following temperatures:

■ freezer compartment: -18°C

■ VitaFresh compartment: 0 °C to 2 °C

■ cooling compartment: +4°C

Operating tips

■ After the appliance has been switched

on, it may take several hours until the set temperatures have been reached.

■ The fully automatic NoFrost system

ensures that the freezer section remains free of ice. Defrosting is no longer required.

■ If the door cannot be immediately re-

opened after it has been closed, wait until the resulting low pressure has equalised.

■ The front and side panels

of the housing are partly heated slightly.This prevents condensation from forming.

Setting the temperature

Fig. $

Refrigerator compartment

The temperature can be set from +2 °C to +8 °C.

1. Press selection button 13 until refrigerator compartment display 7 is activated.

2. Keep pressing +/– buttons 14 until the required temperature is indicated.

Perishable food should not be stored above +4 °C.

VitaFresh compartment

The temperature can be set from -1°C to 3°C.

1. Press selection button 13 until VitaFresh 4 display is activated.

2. Keep pressing +/- buttons until the required temperature is indicated.

Freezer compartment

The temperature can be set from -16°C to -24°C.

1. Select the freezer compartment using the °C button.

2. Keep pressing the +/- buttons until the required temperature is indicated.

Special functions

Fig. $

Fresh mode

Fresh mode gives food an even longer shelf life.

Switching on: Press the mode button until the freshness mode display appears.

The appliance automatically sets the following temperatures:

■ Refrigerator section: + 2°C

■ VitaFresh compartment: 0°C

■ Freezer section: remains unchanged

Switching off: Press the mode button repeatedly until the freshness mode display goes off.

Eco mode

Eco mode switches the appliance to energy-saving operation.

Switching on: Press the mode button until the "eco mode" indicator appears.

The appliance automatically sets the following temperatures:

■ Refrigerator section: +8°C

■ VitaFresh compartment: +3°C

■ Freezer section: -16°C

Switching off: Press the mode button until the "eco mode" indicator goes off.

Holiday mode

If leaving the appliance for a long period of time, you can switch the appliance over to the energy-saving holiday mode.

When holiday mode is switched on, automatic super freezing is switched off.

The refrigerator compartment temperature is automatically switched to +14 °C.

Do not store any food in the refrigerator compartment during this time.

Switching on:

Press the mode button repeatedly until the vacation mode display appears.

Sabbath mode

When Sabbath mode is switched on, the following settings are switched off:

■ Audible signals

■ Interior lighting

■ Messages on the display panel

■ The background illumination of the

display panel is reduced

■ Buttons are locked

■ Automatic super freezing

Switching Sabbath mode on and off: Press the super button for 15 seconds.

Button lock function

To switch the button lock on and off, press the lock/alarm off button for 5 seconds.

When the function is switched on, the D display lights up.

The control panel is now protected against unintentional operation.

Exception to the button lock: The lock/alarm off button can be pressed to switch off the button lock or if an audible warning signal sounds.

The appliance automatically sets the following temperatures:

■ Refrigerator section: +14°C

■ VitaFresh compartment: +14°C

■ Freezer section: remains unchanged

Note

"–" appears in the VitaFresh display.

Switching off: Press the mode button repeatedly until the vacation mode indicator goes off.

Alarm function

In the following cases an alarm may be actuated.

Door alarm

The door alarm switches on and ALARM appears in the refrigerator compartment temperature display 7 or in the freezer compartment temperature display 1 if the door of the compartment is left open too long. Close the door of the compartment to switch off the door alarm.

Temperature alarm

The temperature alarm switches on if the appliance gets too hot inside and the food is at risk of thawing. An interval tone sounds and ALARM appears on the temperature display of the freezer compartment 1.

A temperature alarm may occur in these situations:

■ Starting up the appliance for the first

time Do not store any food until the

appliance has reached the set temperature.

■ Storing large quantities of fresh food

in the appliance Switch on super freezing before

storing large quantities of fresh food. Avoid contact between fresh food and food that is already frozen.

■ Appliance door is open for a very long

time Check whether food has defrosted at

all. Do not refreeze food after it has defrosted, even if just partially.

■ the appliance is being heated by a

second refrigerator (side-by-side installation) or another heat source

Call customer service and ask them about ways of insulating your appliance.

Note

Do not refreeze thawing or thawed food. Only ready meals (boiled or fried) may be refrozen.

No longer store the frozen produce for the max. storage period.

The temperature display indicates for 5 seconds the warmest temperature which was reached in the freezer compartment. Then the set temperature is displayed again.

Switching off the alarm

Press the lock/alarm off button to switch off the audible warning signal.

Home Connect

This appliance is Wi-Fi-capable and can be remotely controlled using a mobile device.

Note

Wi-Fi is a registered trade mark of the WiFi Alliance.

If the appliance is not connected to the home network, the appliance functions like a refrigerator without a network connection and can still be manually operated via the controls.

In order to use the Home Connect functions, connect the appliance with a Home Connect Wi-Fi dongle.

If there is no Home Connect Wi-Fi dongle included with your appliance, you can order this from customer service.

Note

Inserting and removing the plug on the rear side of the appliance is more difficult than expected. Ensure that the plug is completely plugged in.

Attach the Home Connect Wi-Fi dongle at a height of 1 metre.

Notes

■ Please observe the safety instructions

and warnings in these instructions for use. Ensure that these are also adhered to when you are operating the appliance using the Home Connect app and are not at home.

Follow the instructions in the Home Connect app as well.

■ Operation on the appliance always

has priority over operation via the Home Connect app. During this time it is not possible to operate the appliance using the app.

Home Connect setup

Notes

■ Observe the Home Connect

supplementary sheet, which is available for download under http:// www.bosch-home.com with the instructions. To do so, enter the E-number of your appliance in the search field.

■ After switching on the appliance, wait

at least two minutes until internal device initialisation is complete. Only then start setting up Home Connect.

■ To make settings with Home Connect,

the Home Connect app must be installed on your mobile device. Please observe the Home Connect documents supplied for doing this.Follow the steps specified by the app to make the settings.

■ If the appliance is not operated for a

long time, the Home Connect menu closes automatically. You can find information on how to open the Home Connect menu at the start of the appropriate sections.

Automatic connection with the home network (WLAN)

If a WLAN router with WPS function is available, you can automatically connect the refrigerator to the home network.

1. Press the super button and the lock/ alarm off button simultaneously to open the Home Connect menu.

The display shows Cn.

Note

Press both buttons at exactly the same time.Button operation is locked if only the lock/alarm off button is pressed for a longer period. Press the lock/alarm off button again until the lock is deactivated.

2. Press the °C button repeatedly until the displays AC and oF are shown.

3. Press the + button. The appliance is ready for automatic

connection. The display shows an animation for

2 minutes. Follow the steps below during this

period.

4. Activate the WPS function on the home network router (e.g. using the WPS/WLAN button; information on this topic can be found in the router documentation).

■ If the connection is successful, on

flashes in the refrigerator display. You can now connect the

refrigerator with the app.

■ If the display shows oF, it was not

possible to establish a connection. Check whether the refrigerator is

located within the range of the home network (WLAN).

Repeat the process or establish the connection manually.

Manual connection with the home network (WLAN)

If the WLAN router present does not have a WPS function, or if this is unknown, you can manually connect the refrigerator with the home network.

1. Press the super button and the lock/ alarm off button simultaneously to open the Home Connect menu.

The display shows Cn.

Note

2. Press the °C button repeatedly until the displays SA and oF are shown.

3. Press the + button. The appliance is ready for manual

connection. The display shows an animation for

5 minutes. Follow the steps below during this

period.

4. The refrigerator has now set up its own WLAN network with the network name HomeConnect.

You can now access this network with your mobile device.

5. Open the settings menu of the mobile device and call up the WLAN settings.

6. Connect the mobile device with the WLAN network HomeConnect.

Password: HomeConnect It can take up to 60 seconds to

establish the connection.

7. After successful connection, open the Home Connect app on the mobile device.

The app will search for the refrigerator.

8. As soon as the refrigerator has been found, enter the network name (SSID) and the password (Key) of your own home network (WLAN) into the corresponding fields.

9. Confirm with the button Transmit to domestic appliances.

■ If the connection is successful, on

flashes in the refrigerator display. You can now connect the

refrigerator with the app.

■ If the display shows oF, it was not

possible to establish a connection. Enter the password again, ensuring

that it is spelt correctly. Check whether the refrigerator is

located within the range of the home network (WLAN).

Repeat the process.

Connecting the refrigerator to the Home Connect app

Once the connection between the refrigerator and the home network has been established, you can connect the refrigerator to the app.

1. Press super button and lock/alarm off button simultaneously to open the Home Connect menu.

The display shows Cn.

Note

Press both buttons at exactly the same time.Button operation is locked if only the lock/alarm off button is pressed for a longer period. Press lock/alarm off button again until the lock is deactivated.

2. Press °C button repeatedly until the displays PA (pairing = connect with app) and oF are shown.

3. Press + button to connect the appliance with the app.

The display shows an animation. As soon as the refrigerator and the

app are connected, the display shows on.

4. Open the app and wait until the refrigerator is displayed. Use Add to confirm the connection between the app and the refrigerator.

If the refrigerator is not automatically displayed, click on Add appliance in the app and follow the instructions. As soon as your refrigerator is displayed, add it with +.

5. Follow the instructions in the app until the process is complete.

■ The displays show PA and on.

The refrigerator has been successfully connected to the app.

■ If the connection has failed, please

check whether the mobile device is connected to the home network (WLAN).

Then connect the refrigerator to the app again.

■ When the display shows Er, reset

the Home Connect settings and perform set-up again from the beginning.

Verify signal strength

You should verify the signal strength if no connection can be established.

1. Press the super button and the lock/ alarm off button simultaneously to open the Home Connect menu.

The display shows Cn.

Note

2. Press the °C button repeatedly until the display shows SI. In the second display, a value appears between 0 (no reception) and 3 (full reception).

Note

The signal strength should be at least

2. If the signal strength is too low, the connection could be interrupted. Place the router and the refrigerator closer together, ensure that the connection is not disturbed by shielding walls or install a repeater to strengthen the signal.

Resetting Home Connect settings

If the connection process does not work or you would like to log the refrigerator on to a different home network (WLAN), you can reset the Home Connect settings:

1. Press the super button and the lock/ alarm off button simultaneously to open the Home Connect menu.

The display shows Cn.

Note

2. Press the °C button repeatedly until the displays rE and oF are shown.

3. Press the + button.

■ The display shows a short

animation and then again oF. The Home Connect settings have

been reset.

■ If the display shows Er, start the

reset again or call customer service.

Customer Service access

If you contact Customer Service, they can access your appliance and view its status after you have given your consent. You need to have your appliance connected to your home network for this.

Further information about Customer Service access and its availability in your country is available under www.homeconnect.com in the Help & Support area.

1. Contact Customer Service.

2. Confirm the start of Customer Service access in the app.

During Customer Service access the symbol CS appears on the control panel.

3. As soon as Customer Service has obtained the necessary data, they end access.

Note

You can interrupt remote diagnosis early by switching off Customer Service access in the Home Connect app.

Information on data protection

When your Home Connect refrigerator is connected for the first time to a WLAN network that is connected to the Internet, your refrigerator transmits the following categories of data to the Home Connect server (initial registration):

■ Unique appliance identification

(consisting of appliance codes as well as the MAC address of the installed Wi-Fi communication module).

■ Security certificate of the Wi-Fi

communication module (to ensure a secure IT connection).

■ The current software and hardware

version of your refrigerator.

■ Status of any possible previous

resetting to factory settings.

This initial registration prepares the Home Connect functions for use and is required only when you want to use Home Connect for the first time.

Note

Please note that the Home Connect functions can only be utilized with the Home Connect app. You can call up information on data protection in the Home Connect app.

Declaration of Conformity

Robert Bosch Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality meets the essential requirements and the other relevant provisions of the Directive 2014/ 53/EU.

A detailed RED Declaration of Conformity can be found online at http:// www.bosch-home.com among the additional documents on the product page for your appliance.

Usable capacity

Information on the usable capacity can be found inside your appliance on the rating plate. Fig. ,

Fully utilising the freezer volume

To place the maximum amount of frozen food in the freezer compartment, you can remove the containers. You can then stack the food directly on the shelf and on the floor of the freezer compartment.

Note

Avoid contact between food and rear panel. Otherwise the air circulation will be impaired.

Food or packaging could freeze to the rear panel.

Removing the fittings

Pull out the frozen food container all the way, lift at the front and remove. Fig. )

2.4 GHz band: 100 mW max.

Refrigerator compartment

The refrigerator compartment is the ideal storage location for meat, sausage, fish, dairy products, eggs, ready meals and pastries.

Note the chill zones in the refrigerator compartment

The air circulation in the refrigerator compartment creates different chill zones:

■ The coldest zones are in front of the

air outlet openings and in the chill compartment, Fig. !/26.

Storing food

■ Store fresh, undamaged food. The

quality and freshness will then be retained for longer.

■ In the case of ready-made products

and bottled goods, observe the bestbefore date or use-by date specified by the manufacturer.

■ To retain aroma, colour

and freshness, pack or cover food well before placing in the appliance. This will prevent the transfer of flavours and the discolouration of plastic parts in the refrigerator compartment.

■ Allow warm food and drinks to cool

down before placing in the appliance.

Note

Do not block air outlet openings with food, otherwise the air circulation will be impaired. Food which is stored directly in front of the air outlet openings may be frozen by the cold air flowing out.

Note

Store perishable food (e.g. fish, sausage, meat) in the coldest zones.

■ Warmest zone is at the very top of the

door.

Note

Store e.g. hard cheese and butter in the warmest zone. The aroma of hard cheese can then continue to develop and butter remains spreadable.

Super cooling

Super cooling sets the refrigerator temperature to the coldest temperature setting for approx. 6 hours. Then the appliance automatically switches to the temperature set prior to super cooling mode.

Switch on super cooling mode, e.g.

■ before placing large quantities of food

in the refrigerator compartment.

■ for the fast cooling of drinks.

Switching on and off

Fig. $

1. Select the refrigerator section using the °C button.

2. Press super button. The supercool indicator lights up.

You do not need to switch off super cooling.After 6 hours the previously set temperature will be automatically restored.

Note

When super cooling is switched on, increased operating noises may occur.

The VitaFresh compartment

The temperature in the cool-fresh compartment is about 0 °C. The low temperature and the optimum moisture provide ideal storage conditions for fresh food.

Food can be kept fresh up to three times longer in the cool-fresh compartment than in the normal cooling zone – for even longer freshness, nutrient retention and flavour.

Vegetable container

Fig. ' The vegetable container is the optimum

storage location for fresh fruit and vegetables. The humidity controller of the partition and a special seal can be used to adjust the air humidity in the vegetable container.

The air humidity in the vegetable container can be set according to the type and amount of products to be stored:

■ Mainly fruit as well as for a large load

– lower air humidity

■ Mainly vegetables as well as for a

mixed load or small load – higher air humidity

Notes

■ Fruit sensitive to cold (e.g. pineapple,

banana, papaya and citrus fruit) and vegetables sensitive to cold (e.g. aubergines, cucumbers, zucchini, peppers, tomatoes and potatoes) should be stored outside the refrigerator at temperatures of approx. +8 °C to +12 °C for optimum preservation of quality and flavour.

■ Condensation may form in the

vegetable container depending on the food and quantity stored. Remove condensation with a dry cloth and adjust air humidity in the vegetable container with the humidity controller.

“Cool-fresh” container

Fig. !/26 The storage climate in the “cool-fresh”

container offers ideal conditions for the storage of fish, meat, sausage, cheese and milk.

Storage times (at 0 °C)

Depending on the initial quality

Fresh fish, seafood up to 3 days Poultry, meat (boiled/fried) up to 5 days Beef, pork, lamb, sausage

(cold meat) Smoked fish, broccoli up to 14 days Salad greens, fennel, apricots,

plums Soft cheese, yoghurt, quark,

buttermilk, cauliflower

up to 7 days

up to 21 days

up to 30 days

Freezer compartment

Use the freezer compartment

■ To store deep-frozen food.

■ To make ice cubes.

■ To freeze food.

Note

Ensure that the freezer compartment door has been closed properly. If the door is open, the frozen food will thaw. The freezer compartment will become covered in thick ice. Also: waste of energy due to high power consumption!

Freezing capacity

Information on the freezing capacity can be found on the rating plate. Fig. ,

Prerequisites for freezing capacity

■ Switch on fast freezing 24 hours

before placing fresh products in the compartment (see chapter “Fast freezing”).

■ Preferably freeze large quantities of

food in the bottom compartment. This is where food freezes particularly quickly and therefore also gently.

Freezing and storing food

Purchasing frozen food

■ Packaging must not be damaged.

■ Use by the “use by” date.

■ Temperature in the supermarket

freezer must be -18 °C or lower.

■ If possible, transport deep-frozen food

in an insulated bag and place quickly in the freezer compartment.

When loading products, please note:

■ Freeze larger quantities of food

preferably in the bottom frozen food container. This is where food freezes particularly quickly and therefore also gently.

■ Distribute the food over the whole

area of the compartments or the frozen food containers.

Note

Food which is already frozen must not come into contact with the food which is to be frozen. If necessary, re-stack frozen food in the frozen food containers.

■ To ensure air circulation in the

appliance, push the frozen food container all the way in.

Freezing fresh food

Freeze fresh and undamaged food only. To retain the best possible nutritional

value, flavour and colour, vegetables should be blanched before freezing. Aubergines, peppers, zucchini and asparagus do not require blanching.

Literature on freezing and blanching can be found in bookshops.

Note

Keep food which is to be frozen away from food which is already frozen.

■ The following foods are suitable for

freezing: Cakes and pastries, fish and seafood, meat, game, poultry, vegetables, fruit, herbs, eggs without shells, dairy products such as cheese, butter and quark, ready meals and leftovers such as soups, stews, cooked meat and fish, potato dishes, soufflés and desserts.

■ The following foods are not suitable

for freezing: Types of vegetables, which are usually consumed raw, such as lettuce or radishes, eggs in shells, grapes, whole apples, pears and peaches, hard-boiled eggs, yoghurt, soured milk, sour cream, crème fraîche and mayonnaise.

Freezing smaller amounts of food

How you freeze smaller amounts of food, so that they are frozen solid extremely quickly, can be found in the section Automatic super freezing.

Packing frozen food

To prevent food from losing its flavour or drying out, place in airtight containers.

1. Place food in packaging.

2. Remove air.

3. Seal the wrapping.

4. Label packaging with contents and date of freezing.

Suitable packaging:

Cling wrap, tubular film made of polyethylene, aluminium foil, freezer containers. These products are available from specialist outlets.

Unsuitable packaging:

Wrapping paper, greaseproof paper, cellophane, bin liners and used shopping bags.

Items suitable for sealing packaged food:

Rubber bands, plastic clips, string, coldresistant adhesive tape, etc.

Bags and tubular film made of polyethylene (PE) can be sealed with a film heat sealer.

Shelf life of frozen food

Storage duration depends on the type of food.

At a temperature of -18 °C:

■ Fish, sausage, ready meals and cakes

and pastries: up to 6 months

■ Cheese, poultry and meat:

up to 8 months

■ Vegetables and fruit:

up to 12 months

Super freezing

Food should be frozen solid as quickly as possible in order to retain vitamins, nutritional value, appearance and flavour.

The appliance runs constantly when super freezing has been switched on. The freezer compartment temperatures are much lower than in normal operation.

Switching on super freezing

Depending on the amounts of food to be frozen, you can use super freezing in different ways.

Note

When super freezing is switched on, increased operating noises may occur.

Automatic super freezing

Smaller amounts of food are frozen solid extremely quickly if you freeze them as follows:

■ In the bottom frozen food container

■ On left

Automatic super freezing automatically switches on when warm food items are placed inside the freezer.

Manual super freezing

Fig. $ Preferably freeze larger quantities of food

in the bottom compartment. Here, it freezes particularly quickly and therefore also gently.

Several hours before placing fresh food in the freezer compartment, switch on super freezing to prevent an unwanted temperature rise.

If the freezing capacity according to the rating plate is to be used, switch on super freezing 24 hours before the fresh products are placed in the freezer compartment.

1. Select the freezer compartment area with °C button.

2. Press super button. The superfreeze indicator will be lit.

Switching off super freezing

Fig. $

1. Select the freezer compartment area with °C button.

2. Press super button. The superfreeze display goes out.

Super freezing is now switched off.

When super freezing has finished, the appliance automatically switches to normal mode.

■ With automatic super freezing: As

soon as the smaller amounts of food to be frozen have frozen solid.

■ With manual super freezing: After

approx. 2½ days.

Thawing frozen food

Depending on the type and application, select one of the following options:

■ at room temperature

■ in the refrigerator

■ in an electric oven, with/without fan

assisted hot-air

■ in the microwave

m Caution

Do not refreeze thawing or thawed food. Only ready meals (boiled or fried) may be refrozen.

No longer store the frozen produce for the max. storage period.

Interior fittings

Shelves and containers

You can reposition the inner shelves and the containers in the door as required: pull shelf forwards, lower and swivel out to the side. Lift the container and remove.

Special features

(not all models)

Butter and cheese compartment

To open the butter compartment, gently press in the middle of the butter compartment flap.

To clean the compartment, lift it at the bottom and take out.

Breakfast set

Fig. % The containers for the breakfast set can

be taken out and filled individually. You can take out the breakfast set for

loading and unloading. To do this, lift the breakfast set and pull out. The container holder can be moved.

Bottle shelf

Fig. & Bottles can be stored securely on the bottle shelf.

Ice cube tray

Fig. +

1. Fill the ice cube tray ¾ full of drinking water and place in the freezer compartment.

2. If the ice tray is stuck to the freezer compartment, loosen with a blunt implement only (spoon-handle).

3. To loosen the ice cubes, twist the ice tray slightly or hold briefly under flowing water.

Freezer calendar

Fig. * To prevent the quality of the frozen food

from deteriorating, do not exceed the storage duration. The figures next to the symbols indicate the permitted storage period of the produce in months. In the case of commercially available frozen food observe the date of manufacture or use-by date.

Ice pack

The ice pack can be removed to cool food temporarily, e.g. in a cold bag.

If a power failure or malfunction occurs, the ice pack can be used to slow down the thawing process.

Sticker “OK”

(not all models) The sticker “OK” lets you check whether

the refrigerator compartment achieves the safe temperature ranges of +4 °C or colder recommended for food. If the sticker does not indicate “OK”, gradually reduce the temperature.

Note

When the appliance is switched on, it may take up to 12 hours until the set temperature is reached.

Switching off and disconnecting the appliance

Switching off the appliance

Press "+" button for 10 seconds. The refrigeration unit switches off.

Press "+" button for 10 seconds to switch on the refrigeration unit again.

Disconnecting the appliance

If you do not use the appliance for a prolonged period:

1. Pull out the mains plug or switch off the fuse.

2. Clean the appliance.

3. Leave appliance doors open.

Note

To avoid damage to the appliance, appliance doors must be opened far enough that they remain in that position on their own. Do not jam any objects into the door to prop it open.

Correct setting

Defrosting

Refrigerator compartment

While the appliance is in operation, condensation droplets or frost form on the back panel of the cooling compartment. As the rear panel defrosts automatically, it is not necessary to remove the frost or the condensation droplets.

Freezer compartment

The fully automatic NoFrost system ensures that the freezer compartment remains free of ice. Defrosting is no longer required.

Cleaning the appliance

m Caution

■ Do not use abrasive, chloride or acidic

cleaning agents or solvents.

■ Do not use scouring or abrasive

sponges. The metallic surfaces could corrode.

■ Never clean shelves and containers

in the dishwasher. The parts may become deformed!

The cleaning water must not get into the following areas:

■ Controls

■ Illumination

■ Ventilation openings

■ Openings in the separating plate

Proceed as follows:

1. Pull out the mains plug or switch off the fuse.

2. Take out the frozen food and store in a cool location. Place ice pack (if available) on the food.

3. The rinsing water must not drip into the controls, lighting, ventilation openings or the openings in the partition!

Clean the appliance with a soft cloth, lukewarm water and a little pH-neutral washing-up liquid.

4. Wipe the door seal with clear water only and then wipe dry thoroughly.

5. After cleaning reconnect the appliance.

6. Put the frozen food back into the appliance.

Features

All variable parts of the appliance can be taken out for cleaning.

Note

The separating plate between the refrigerator compartment and the VitaFresh compartment is permanently fixed. To prevent any damage to the appliance, this may only be removed by customer service or authorized specialists.

Take out shelves in the door

Fig. # Lift shelves upwards and take out.

Take out glass shelves

Pull the glass shelves forwards and take out.

Removing the container

Fig. ( Pull out the container all the way and lift

to detach it. To insert the container, place on

the telescopic rails and push into the appliance. Attach the container by pressing it down.

Taking out the frozen food container

Fig. ) Pull out the frozen food container all

the way, lift at the front and remove.

Light (LED)

Your appliance features a maintenancefree LED light.

These lights may be repaired by customer service or authorised technicians only.

Tips for saving energy

■ Install the appliance in a dry, well

ventilated room! The appliance should not be installed in direct sunlight or near a heat source (e.g. radiator, cooker).

If required, use an insulating plate.

■ Allow warm food and drinks to cool

down before placing in the appliance.

■ Thaw frozen food in the refrigerator

compartment and use the low temperature of the frozen food to cool refrigerated food.

■ Open the appliance as briefly as

possible.

■ To achieve the lowest energy

consumption, leave a small wall gap at the side.

■ The arrangement of the fittings does

not affect the energy rating of the appliance.

Operating noises

Note

When super freezing is switched on, increased operating noises may occur.

Quite normal noises

Droning

Motors are running (e.g. refrigeration units, fan). There may be an increase in operating noise when ambient temperatures are high.

Bubbling, humming or gurgling noises

Refrigerant is flowing through the tubing.

Clicking

Motor, switches or solenoid valves are switching on/off.

Cracking

Automatic defrosting is running.

Preventing noises

The appliance is not level

Please align the appliance with a spirit level. Use the height-adjustable feet or place packing underneath them.

The appliance is not free-standing

Please move the appliance away from adjacent units or appliances.

Containers or storage areas wobble or stick

Please check the removable parts and re-insert them correctly if required.

Bottles or receptacles are touching each other

Move the bottles or receptacles slightly away from each other.

Eliminating minor faults yourself

Before you call customer service: Please check whether you can eliminate the fault yourself based on the following

information. Customer service will charge you for advice – even if the appliance is still under

guarantee!

Fault Possible cause Remedial action

Temperature differs greatly from the set value.

The light does not function. The LED light is defective. See chapter “Light (LED)” section.

Appliance was open too long.

Light is switched off after approx. 10 min.

Displays do not illuminate. Power failure; the fuse has

been switched off; the mains plug has not been inserted properly.

It is too cold in the cooling compartment or the VitaFresh compartment.

The temperature in the freezer section is too warm.

Appliance opened frequently.

The ventilation openings have been covered.

Large quantities of fresh food are being frozen.

In some cases it is adequate to switch off the appliance for 5 minutes.

If the temperature is too high wait a few hours and check whether the temperature has approached the set value.

If the temperature is too low check the temperature again the next day.

When the appliance is closed and opened, the light is on again.

Connect mains plug. Check whether the power is on, check the fuses.

Increase the temperature in the cooling compartment.

Increase the temperature in the VitaFresh compartment.

Do not open the appliance unnecessarily.

Remove obstructions.

Do not exceed the freezing capacity.

Fault Possible cause Remedial action

Appliance is not cooling, temperature display and light are lit.

Showroom mode is switched on.

Press and hold °C button and @ setting button for 5 seconds until an acknowledgement signal sounds. Another acknowledgement signal sounds when the buttons are released.

After a short time check whether your appliance is cooling.

The side panels of the appliance are warm.

Pipes run into the side panels which heat during the cooling process.

That is normal behaviour for the appliance and not a fault.

Furniture touching the appliance will not be damaged by the heat.

Freezer compartment door was open for a long time; temperature is no longer reached.

The evaporator (refrigeration generator) in the NoFrost system is covered in thick ice and can no longer be defrosted fully automatically.

To defrost the evaporator, remove the frozen food with the compartments, insulate well and store in a cool location.

Switch off the appliance and move it away from the wall. Leave the appliance door open.

After approx. 20 min. the condensation begins to run into the evaporation pan, at the rear of the appliance.

To prevent the evaporation pan from overflowing in this case, mop up the condensation with a sponge.

The evaporator is defrosted when the water stops running into the evaporation pan. Clean the interior. Switch the appliance back on again.

Automatic super freezing does not switch on.

The appliance decides independently whether automatic Super freezing is required and automatically switches it on or off.

The following settings are switched off:

■ Audible signals

■ Interior lighting

■ Messages on the display

Sabbath mode is switched on.

Press super button for 15 seconds.

panel

■ Automatic super freezing

The background illumination of the display panel is reduced.

Buttons are locked.

Appliance self-test

Your appliance features an automatic self-test program which shows you sources of faults which may be repaired by customer service only.

Starting the appliance self-test

1. Switch off the appliance and wait 5 minutes.

2. Switch on the appliance and within the first 10 seconds, press and hold the °C button and the "–" setting button for 3–5 seconds until an audible signal sounds.

The self-test programme starts.

When the self-test ends and an audible signal sounds twice, your appliance is in working order.

If 5 audible signals sound, there is an error. Inform customer service.

Ending the appliance self-test

When the programme has ended, the appliance switches over to normal operation.

Customer service, product / production number and technical data

Customer service

If you have any queries, are unable to rectify faults on the appliance yourself or if your appliance needs to be repaired, contact Customer Service.

You can solve many problems yourself by consulting the information on troubleshooting in these instructions or on our website. If this is not the case, contact our Customer Service.

We will always find an appropriate solution and try to avoid unnecessary visits being made by a Customer Service technician.

With any warranty claims, we will make sure that your appliance is repaired by trained Customer Service technicians using genuine spare parts, including after the manufacturer's warranty has expired.

For safety reasons, repairs to the appliance should only be carried out by trained specialist staff. The warranty claim becomes void if repairs or interventions have been carried out by persons not authorised by us for that purpose or if our appliances have been fitted with spare, supplementary or accessory parts that were not genuine parts and then resulted in a defect.

Function-relevant genuine spare parts according to the corresponding Ecodesign Directive can be obtained from Customer Service for a period of at least 10 years from the date on which your appliance was placed on the market within the European Economic Area.

Note

Under the terms of the manufacturer's warranty applicable to the location, the use of Customer Service is free of charge.The minimum duration of the warranty (manufacturer's warranty for private consumers) in the European Economic Area is 2 years (except for Denmark and Sweden, where it is 1 year) according to the terms of warranty applicable to the location. The terms of warranty do not affect other rights or claims held by yourself under local legislation.

Detailed information about the warranty period and terms of warranty in your country are available from Customer Service, your dealer or our website.

When contacting after-sales service, you will need the product number (E no.) and the production number (FD no.) of your appliance.

The contact details for Customer Service can be found in the enclosed Customer Service directory or on our website.

Product number (E no.) and production number (FD no.)

The product number (E no.) and the production number (FD no.) can be found on the rating plate of the appliance. Fig. ,

Make a note of your appliance's details and the Customer Service telephone number to find them again quickly.

Technical data Refrigerant, net volume and further technical specifications can be found on the rating plate. Fig. ,

More information about your model can be found online at https://www.bshgroup.com/energylabel (only applies to countries in the European Economic Area). This web address is linked to the official EU EPREL product database. At the time of printing its web address had not yet been published. Please then follow the instructions on how to search for models. The model identifier is made up of the characters before the slash in the product number (E no.) on the rating plate. Alternatively you can also find the model identifier in the first line of the EU energy label.

Repair order and advice on faults

Contact information for all countries can be found on the enclosed customer service list.

GB 0344 892 8979 Calls charged at

local or mobile rate.

IE 01450 2655 0.03 € per minute

at peak. Off peak

0.0088 € per minute.

US 800 944 2904 toll-free

1-18

VitaFresh 0°

superfreeze

supercool

25 26

9LWD)UHVK



VXSHUIUHH]H

VXSHUFRRO

 



*8001206897*

8001206897 (0009)

Bosch KGF39PIDP, KGF56PIDP Instructions for Use

Specifications and Main Features

Frequently Asked Questions

User Manual
