Extractor hood
DUL60AF24
[en]
User manual and installation instructions
en Safety
Table of contents
USER MANUAL
1 Safety....................................................................2
2 Avoiding material damage...................................4
3 Environmental protection and saving en-
ergy .......................................................................4
4 Operating modes .................................................5
5 Familiarising yourself with your appliance ........6
6 Basic operation ....................................................6
7 Cleaning and servicing........................................6
8 Troubleshooting...................................................8
9 Disposal................................................................8
10 Customer Service.................................................9
11 INSTALLATION INSTRUCTIONS .........................9
11.4 Secure installation ..........................................
...10
1 Safety
Please read the safety information to ensure
that you use the appliance safely.
1.1 General information
¡ Read this instruction manual carefully. Only
this will ensure you use the appliance
safely and efficiently.
¡ Keep the instruction manual and the
product information safe for future reference or for the next owner.
¡ Check the appliance after unpacking it. Do
not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Read the information on intended use to ensure that you use the appliance correctly and
safely.
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
The appliance can only be used safely if it is
correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works perfectly at its
installation location.
Only use this appliance:
¡ For extracting cooking vapour.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 2000m above
sea level.
Do not use the appliance:
¡ With an external timer.
1.3 Restriction on user group
Avoid risks to children and vulnerable persons.
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inadequate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
WARNING‒Risk of poisoning!
Risk of poisoning from flue gases being
drawn back in. Room-air-dependent heat-producing appliances (e.g. gas, oil, wood or coaloperated heaters, continuous flow heaters or
water heaters) obtain combustion air from the
room in which they are installed and discharge the exhaust gases into the open
through an exhaust gas system (e.g. a chimney). With the extractor hood switched on, air
is extracted from the kitchen and the adjacent
rooms. Without an adequate supply of air, the
air pressure falls below atmospheric pressure.
2
Safety en
Toxic gases from the flue or the extraction
shaft are sucked back into the living space.
▶
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as a
room-air-dependent heat-producing appliance is being operated.
▶
It is only possible to safely operate the appliance if the pressure in the room in which
the heating appliance is installed does not
drop more than 4Pa(0.04mbar) below atmospheric pressure. This can be achieved
whenever the air needed for combustion is
able to enter through openings that cannot
be sealed, for example in doors, windows,
incoming/exhaust air wall boxes or by
other technical means. An incoming/exhaust air wall box alone does not ensure
compliance with the limit.
▶
In any case, consult your responsible chimney sweep. They are able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures
to you.
▶
Unrestricted operation is possible if the appliance is operated exclusively in circulating-air mode.
▶
Never extinguish burning oil or fat with water. Switch off the cooking zone. Extinguish
flames carefully using a lid, fire blanket or
something similar.
When gas burners are in operation without
any cookware placed on them, they can build
up a lot of heat. A ventilation appliance installed above the cooker may become damaged or catch fire.
▶
Only operate the gas burners with cook-
ware on them.
Operating multiple gas hobs at the same time
generates a great deal of heat. A ventilation
appliance installed above the cooker may become damaged or catch fire.
▶
Only operate the gas hobs with cookware
on them.
▶
Activate the ventilation system.
▶
Never operate two gas hobs simultan-
eously on the highest flame for longer than
15 minutes. Two gas hobs correspond to
one large burner.
▶
Never operate large burners of more than
5kW with the highest flame for longer
than 15minutes, e.g. a wok.
WARNING‒Risk of burns!
The accessible parts of the appliance become
hot during operation.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
The appliance will become hot during operation.
▶
Allow the appliance to cool down before
cleaning it.
WARNING‒Risk of fire!
Fatty deposits in the grease filters may catch
fire.
▶
Never operate the appliance without a
grease filter.
▶
Clean the grease filters roughly every2
months.
▶
Never work with naked flames close to the
appliance (e.g. flambéing).
▶
Do not install the appliance near a solid
fuel heating appliance (e.g. wood- or coalburning) unless the heating appliance has
a sealed, non-removable cover. There must
be no flying sparks.
Hot oil or grease ignites very quickly.
▶
Always supervise hot oil and fat.
WARNING‒Risk of injury!
Components inside the appliance may have
sharp edges.
▶
Carefully clean the appliance interior.
Items placed on the appliance may fall off.
▶
Do not place any objects on the appliance.
Changes to the electrical or mechanical assembly are dangerous and may lead to malfunctions.
▶
Do not make any changes to the electrical
or mechanical assembly.
The light emitted by LED lights is very
dazzling, and can damage the eyes (risk
group 1).
▶
Do not look directly into the switched-on
LED lights for longer than 100seconds.
3
en Avoiding material damage
WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶
If the appliance or the power cord is damaged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶
Call Customer Service. →Page9
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Customer Service
or a similarly qualified person in order to
prevent any risk.
An ingress of moisture can cause an electric
shock.
▶
Before cleaning, pull out the mains plug or
switch off the fuse in the fuse box.
▶
Do not use steam- or high-pressure clean-
ers to clean the appliance.
WARNING‒Risk of explosion!
Highly caustic alkaline or highly acidic cleaning agents in conjunction with aluminium parts
in the interior of the appliance may cause explosions.
▶
Never use highly caustic alkaline or highly
acidic cleaning agents. In particular, do not
use commercial or industrial cleaning
agents in conjunction with aluminium parts,
e.g. grease filter on extractor hoods.
2 Avoiding material damage
▶
ATTENTION!
Condensate may cause corrosion damage.
▶
To prevent condensation from building up, switch on
the appliance during cooking.
If moisture gets into the controls, this may result in
damage.
▶
Never clean controls with a wet cloth.
Incorrect cleaning damages the surfaces.
▶
Follow the cleaning instructions.
▶
Do not use harsh or abrasive detergents.
Clean stainless steel surfaces in the direction of the
finish only.
▶
Never clean controls with stainless steel cleaners.
If you put incorrect stress on the design elements, they
may break off.
▶
Do not pull design elements.
▶
Do not place objects on the design elements or
hang objects from them.
There is a risk of surface damage if you do not peel off
the protective film.
▶
Remove the protective film from all parts of the ap-
pliance before using for the first time.
3 Environmental protection and saving energy
Help protect the environment by using your appliance
in a way that conserves resources and by disposing of
reusable materials properly.
3.1 Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
Information about current disposal methods are
available from your specialist dealer or local authority.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
Ensure that there is sufficient ventilation when cooking.
The appliance works more efficiently and with fewer
¡
operating noises.
Switch off the lighting if you no longer require it.
The lighting does not consume any energy.
¡
Clean or replace the filters at regular intervals.
The effectiveness of the appliance is increased.
¡
Put the cooking lid on.
The cooking vapours and condensation are re-
¡
duced.
4
4 Operating modes
4.1 Air extraction mode
The air which is drawn in is cleaned by the grease filters and conveyed to the exterior by a pipe system.
The air must not be discharged into a
flue that is used for exhausting fumes
from appliances burning gas or other
fuels (not applicable to appliances that
only discharge the air back into the
room).
¡ If the exhaust air is to be conveyed
into a non-functioning smoke or exhaust gas flue, you must obtain the
consent of the heating engineer responsible.
¡ If the exhaust air is conveyed
through the external wall, a telescopic duct should be used.
Operating modes en
5
en Familiarising yourself with your appliance
5 Familiarising yourself with your appliance
5.1 Controls
The controls are used to configure all functions of your
appliance and to obtain information about the operating status.
6 Basic operation
Activating or deactivating ventilation
Activating ventilation for 60minutes
Deactivating ventilation
Lighting
6.1 Switching on the appliance
▶
Set the control knob to .
a The damper closes automatically after 60minutes.
6.2 Switching off the appliance
▶
Set the control knob to .
7 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
7.1 Cleaning products
You can obtain suitable cleaning products from aftersales service or the online shop.
ATTENTION!
Unsuitable cleaning products may damage the surfaces of the appliance.
▶
Do not use harsh or abrasive detergents.
▶
Do not use cleaning products with a high alcohol
content.
▶
Do not use hard scouring pads or cleaning
sponges.
▶
Do not use any special cleaners for cleaning the appliance while it is hot.
▶
Only use glass cleaners, glass scrapers or stainless
steel care products if recommended in the cleaning
instructions for the relevant part.
▶
Wash sponge cloths thoroughly before use.
6.3 Switching on the lighting
The lighting can be switched on and off independently
of the ventilation system.
▶
Set the control knob to .
6.4 Switching off the lighting
▶
Set the control knob to .
7.2 Cleaning the appliance
Clean the appliance as specified. This will ensure that
the different parts and surfaces of the appliance are
not damaged by incorrect cleaning or unsuitable cleaning products.
WARNING‒Risk of explosion!
Highly caustic alkaline or highly acidic cleaning agents
in conjunction with aluminium parts in the interior of the
appliance may cause explosions.
▶
Never use highly caustic alkaline or highly acidic
cleaning agents. In particular, do not use commer-
cial or industrial cleaning agents in conjunction with
aluminium parts, e.g. grease filter on extractor
hoods.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Before cleaning, pull out the mains plug or switch
off the fuse in the fuse box.
▶
Do not use steam- or high-pressure cleaners to
clean the appliance.
6
Cleaning and servicing en
WARNING‒Risk of burns!
The appliance will become hot during operation.
▶
Allow the appliance to cool down before cleaning it.
WARNING‒Risk of injury!
Components inside the appliance may have sharp
edges.
▶
Carefully clean the appliance interior.
1.
Observe the information regarding the cleaning
agents.
2.
Clean as follows, depending on the surface:
‒ Clean stainless steel surfaces in the direction of
the finish using a sponge cloth and hot soapy
water.
‒ Clean painted surfaces using a damp sponge
cloth and hot soapy water.
‒ Clean aluminium using a soft cloth and glass
cleaner.
‒ Clean plastic using a soft cloth and glass
cleaner.
‒ Clean glass using a soft cloth and glass cleaner.
3.
Dry with a soft cloth.
4.
Apply a thin layer of the stainless steel cleaning
product to stainless steel surfaces using a soft
cloth.
You can obtain stainless steel cleaning products
from the after-sales service or the online shop.
7.3 Cleaning controls
WARNING‒Risk of electric shock!
Penetrating moisture may cause an electric shock.
▶
Do not use wet sponge cloths.
1.
Observe the information regarding the cleaning
agents.
2.
Clean using a damp sponge cloth and hot soapy
water.
3.
Dry with a soft cloth.
7.4 Removing the grease filter
1.
ATTENTION!
Falling grease filters may damage the hob below.
▶
Grip below the grease filter with one hand.
Open the locks on the grease filters.
7.5 Cleaning grease filters manually
The grease filters filter the grease from the cooking vapour. Regularly cleaned grease filters guarantee a high
level of grease removal.
WARNING‒Risk of fire!
Fatty deposits in the grease filters may catch fire.
▶
Clean the grease filters roughly every2 months.
Requirement:The grease filters have been removed.
→"Removing the grease filter", Page7
1.
Observe the information regarding the cleaning
agents.
2.
Soak the grease filter in hot soapy water.
Use special grease solvent for stubborn dirt. You
can obtain grease solvents from after-sales service
or the online shop.
3.
Use a brush to clean the grease filters.
4.
Rinse the grease filters thoroughly.
5.
Allow the grease filters to drain.
7.6 Cleaning grease filters in the dishwasher
The grease filters filter the grease from the cooking vapour. Regularly cleaned grease filters guarantee a high
level of grease removal.
WARNING‒Risk of fire!
Fatty deposits in the grease filters may catch fire.
▶
Clean the grease filters roughly every2 months.
ATTENTION!
The grease filters may become damaged if they are
squeezed.
▶
Do not squeeze the grease filters.
Note:When cleaning the grease filter in the dishwasher, light discolouration may occur. This discolouration has no effect on the performance of the metal
grease filters.
Requirement:The grease filters have been removed.
→"Removing the grease filter", Page7
1.
Observe the information regarding the cleaning
agents.
2.
Place the grease filters loosely into the dishwasher.
Do not clean heavily soiled grease filters with
utensils.
Use special grease solvent for stubborn dirt. You
can obtain grease solvents from after-sales service
or the online shop.
3.
Start the dishwasher.
Select a temperature of no more than 70°C.
4.
Allow the grease filters to drain.
2.
Remove the grease filters from the holders.
To prevent grease from dripping, hold the grease fil-
ter horizontally.
7.7 Fitting grease filters
ATTENTION!
Falling grease filters may damage the hob below.
▶
Grip below the grease filter with one hand.
1.
Fit the grease filters.
2.
Fold the grease filters upwards and engage the
locks.
3.
Make sure that the locks engage.
7
en Troubleshooting
8 Troubleshooting
▶
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
8.2 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The mains plug of the power cord is not plugged in.
▶
Connect the appliance to the power supply.
The circuit breaker is faulty.
▶
Check the circuit breaker in the fuse box.
There has been a power cut.
▶
Check whether the lighting in your kitchen or other appliances are working.
The lighting does not work. Different causes are possible.
▶
Call the after-sales service.
→"Customer Service", Page9
General malfunctions occur. Malfunction
1.
Switch off the fuse in the fuse box.
2.
Switch the fuse back on after approx. 10 seconds.
3.
If the malfunction occurs again, call after-sales service.
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
Only use genuine spare parts when repairing the
appliance.
▶
If the power cord of this appliance is damaged, it
must be replaced by the manufacturer, the manufac-
turer's Customer Service or a similarly qualified per-
son in order to prevent any risk.
8.1 Replacing defective LED lights
▶
Defective LED lights may be replaced by the manu-
facturer, their customer service or a qualified techni-
cian (electrician) only.
9 Disposal
Find out here how to dispose of old appliances correctly.
9.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local authority.
This appliance is labelled in accordance with European Directive
2012/19/EU concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE).
The guideline determines the framework for the return and recycling of
used appliances as applicable
throughout the EU.
8
10 Customer Service
Customer Service en
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our aftersales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
11 Installation instructions
Observe this information when installing the appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
10.1 Product number (E-Nr.) and production number (FD)
You can find the product number (E-Nr.) and the production number (FD) on the appliance's rating plate.
Depending on the model, the rating plate can be found:
¡ Inside the appliance (remove grease filters for ac-
cess).
¡ On top of the appliance.
Make a note of your appliance's details and the Customer Service telephone number to find them again
quickly.
11.2 Unit dimensions
You will find the dimensions of the appliance here
11.1 Scope of delivery
After unpacking all parts, check for any damage in
transit and completeness of the delivery.
11.3 Safety clearances
Comply with the safety clearances for the appliance.
9
en Installation instructions
11.4 Secure installation
Follow these safety instructions when installing the appliance.
WARNING‒Risk of poisoning!
Risk of poisoning from flue gases being
drawn back in. Room-air-dependent heat-producing appliances (e.g. gas, oil, wood or coaloperated heaters, continuous flow heaters or
water heaters) obtain combustion air from the
room in which they are installed and discharge the exhaust gases into the open
through an exhaust gas system (e.g. a chimney). With the extractor hood switched on, air
is extracted from the kitchen and the adjacent
rooms. Without an adequate supply of air, the
air pressure falls below atmospheric pressure.
Toxic gases from the flue or the extraction
shaft are sucked back into the living space.
▶
Always ensure adequate fresh air in the
room if the appliance is being operated in
exhaust air mode at the same time as a
room-air-dependent heat-producing appliance is being operated.
▶
It is only possible to safely operate the appliance if the pressure in the room in which
the heating appliance is installed does not
drop more than 4Pa(0.04mbar) below atmospheric pressure. This can be achieved
whenever the air needed for combustion is
able to enter through openings that cannot
be sealed, for example in doors, windows,
incoming/exhaust air wall boxes or by
other technical means. An incoming/exhaust air wall box alone does not ensure
compliance with the limit.
▶
In any case, consult your responsible chimney sweep. They are able to assess the
house's entire ventilation setup and will
suggest the suitable ventilation measures
to you.
▶
Unrestricted operation is possible if the appliance is operated exclusively in circulating-air mode.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from chil-
dren.
▶
Do not let children play with packaging ma-
terial.
WARNING‒Risk of fire!
Grease deposits in the grease filter may catch
fire.
▶
The specified safety clearances must be
complied with in order to prevent a build-up
of heat.
▶
Observe the specifications for your cooking
appliances. If the installation instructions for
the cooking appliances specify a different
clearance, the larger of the two must al-
ways be provided for. If gas hobs and elec-
tric hobs are operated together, the largest
specified clearance applies.
▶
The appliance must be installed with no
more than one side directly next to a high-
sided unit or a wall. The distance between
the appliance and wall or high-sided unit
must be at least 50mm.
Grease deposits in the grease filter may catch
fire.
▶
Never work with naked flames close to the
appliance (e.g. flambéing).
▶
Do not install the appliance near a heat-
producing appliance for solid fuel (e.g.
wood or coal) unless a closed, non-remov-
able cover is available. There must be no
flying sparks.
WARNING‒Risk of injury!
Components inside the appliance may have
sharp edges.
▶
Wear protective gloves.
The appliance may fall down if it has not been
properly fastened in place.
▶
All fastening components must be fixed
firmly and securely in place.
Changes to the electrical or mechanical assembly are dangerous and may lead to malfunctions.
▶
Do not make any changes to the electrical
or mechanical assembly.
10
Installation instructions en
WARNING‒Risk of electric shock!
Sharp-edged components inside the appliance may damage the connecting cable.
▶
Do not kink or trap the connecting cable.
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶
If the appliance or the power cord is dam-
aged, immediately unplug the power cord
or switch off the fuse in the fuse box.
▶
Call Customer Service. →Page9
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repair-
ing the appliance.
▶
If the power cord of this appliance is dam-
aged, it must be replaced by the manufac-
turer, the manufacturer's Customer Service
or a similarly qualified person in order to
prevent any risk.
Improper installation is dangerous.
▶
Connect and operate the appliance only in
accordance with the specifications on the
rating plate.
▶
Connect the appliance to a power supply
with alternating current only via a properly
installed socket with earthing.
▶
The protective conductor system of the do-
mestic electrical installation must be prop-
erly installed.
▶
Never equip the appliance with an external
switching device, e.g. a timer or remote
control.
▶
When the appliance is installed, the mains
plug of the power cord must be freely ac-
cessible. If free access is not possible, an
all-pole isolating switch must be installed in
the permanent electrical installation accord-
ing to the conditions of Overvoltage Cat-
egory III and according to the installation
regulations.
▶
When installing the appliance, check that
the power cable is not trapped or dam-
aged.
11.5 General information
Follow these general instructions during the installation.
¡ For the installation, observe the currently valid build-
ing regulations and the regulations of the local electricity and gas suppliers.
¡ When discharging the exhaust air, the official and
legal regulations, such as the regional building
code., must be observed.
¡ The width of the extractor hood must correspond at
least with the width of the hob.
¡ To optimally detect the cooking vapours, install the
appliance in the middle of the hob.
¡ In order to freely access the appliance for servicing,
select an easy-to-reach installation site.
¡ The surfaces of the appliance are sensitive. Avoid
damaging them during installation.
11.6 Information on the installation situation
¡ Install this appliance in a kitchen cupboard.
¡ To install additional special accessory parts, ob-
serve the enclosed installation instructions.
11.7 Instructions for the electrical connection
In order to safely connect the appliance to the electrical system, follow these instructions.
WARNING‒Risk of electric shock!
It must always be possible to disconnect the appliance
from the electricity supply. The appliance must only be
connected to a protective contact socket that has been
correctly installed.
▶
The mains plug for the mains power cable must be
easily accessible after the appliance is installed.
▶
If this is not possible, an all-pole isolating switch
must be integrated into the permanent electrical installation according to the conditions of overvoltage
category III and according to the installation regulations.
▶
The permanent electrical installation must only be
wired by a professional electrician. We recommend
installing a residual-current circuit breaker (RCCB)
in the appliance's power supply circuit.
Sharp-edged components inside the appliance may
damage the connecting cable.
▶
Do not kink or trap the connecting cable.
¡ The connection data can be found on the rating
plate. →Page9
¡ The connecting cable is approx.1.30m long.
¡ This appliance complies with the EC interference
suppression regulations.
¡ The appliance corresponds to protection class 1.
You should therefore only use the appliance with a
protective earth connection.
¡ Do not connect the appliance to the power supply
during installation.
¡ Ensure that the protection against contact is guaran-
teed during installation.
11
en Installation instructions
11.8 Instructions for the exhaust air pipe
The appliance manufacturer does not provide any warranty for faults attributable to the pipeline.
¡ Use a short, straight exhaust air pipe with as large a
pipe diameter as possible.
¡ Long, rough exhaust air pipes, many pipe bends or
small pipe diameters reduce the suction power and
increase the fan noise.
¡ Use an exhaust pipe that is made of non-combust-
ible material.
¡ To prevent condensate from returning, fit the ex-
haust pipe with a 1° gradient from the appliance.
Round pipes
Use round pipes with an inner diameter of 150mm (recommended) or at least 120mm.
11.9 Instructions for the air extraction mode
For air extraction mode, a one-way flap should be installed.
Notes
¡ If a one-way flap is not included with the appliance,
one can be ordered from a specialist retailer.
¡ If the exhaust air is conveyed through the external
wall, a telescopic duct should be used.
Installing the appliance
1.
Insert the screws in the appliance.
2.
Hold the appliance at the bottom of the unit and
screw it firmly in place.
11.10 Installation
Checking the unit
1.
Check whether the fitted unit is level and has sufficient load-bearing capacity.
The max. weight of the appliance is 6kg.
2.
Ensure that the fitted unit is heat-resistant up to
90°C.
3.
Ensure that the fitted unit is still stable after the cutouts have been made.
Preparing the units
Requirement:The unit is suitable for the installation.
→"Checking the unit", Page12
1.
Cover the hob to prevent damage.
2.
Ensure that the fitted unit is still stable after the cutouts have been made.
3.
Make the cut-out for the exhaust pipe.
3.
Secure the exhaust pipe to the air pipe connector.
4.
Connect the exhaust pipe to the exhaust air opening
on the external air extraction system.
5.
Seal the joints.
6.
Insert the mains plug into the protective contact
socket.
7.
Fit the grease filters.
To avoid causing damage, do not bend the grease
filters.
8.
Close the holes with the plug.
4.
Remove any shavings.
Preparing the appliance
▶
Remove the grease filters.
To avoid causing damage, do not bend the grease
filters.
12
Installing the side panels
2mm
1.
Screw in the screws, but do not tighten them.
2.
Hook in the side panels in place and screw them in
tightly.
Installation instructions en
2.
In order to increase the air flow, open the one-way
flap and remove the reducing disc.
3.
Adjust the reducing disc.
Installing the glass screen
▶
Secure the glass screen.
Setting the air flow
Requirement:The grease filters have been removed.
→"Removing the grease filter", Page7
1.
To set the air flow, change the position of the absorber.
4.
Insert the reducing disc and close the one-way flap.
Measuring the airflow
▶
In order to measure the pressure drop, attach the
hose to the measurement opening on the front
edge of the air pipe connector.
Removing the appliance
1.
Disconnect the appliance from the power supply.
2.
Loosen the exhaust pipe.
3.
Remove the grease filters.
To avoid causing damage, do not bend the grease
filters.
4.
Loosen the screw connection with the fitted unit.
5.
Remove the appliance.
13
en Installation instructions
Static pressure drop
pA
L = The A-measured sound pressure level at 10 m² sabin
L = The A-measured sound pressure level relative to 1 pW
WA
Setting
11.11 Air flow diagrams
You can find the air flow diagrams below.
Basic ventilation – adjustment diagram
K1 K2 K3 K4 K5 K6 K7 K8 K9 K10 K11 K12
Kfactor
14
0.46 0.54 0.65 0.77 0.86 0.96 1.1 1.21 1.34 1.46 1.62 1.77
Basic ventilation – size diagram
Real pressure in the ventilation duct
pA
L = The A-measured sound pressure level at 10 m² sabin
L = The A-measured sound pressure level relative to 1 pW
WA
Installation instructions en
15
en Installation instructions
Static pressure drop
pA
L = The A-measured sound pressure level at 10 m² sabin
L = The A-measured sound pressure level relative to 1 pW
WA
Cut-away rings
Existing opening of the reducing disc
Without reducing disc
Forced ventilation – adjustment diagram
K1 K2 K3 K4 K5
K-factor 2.37 2.82 3.35 3.96 4.76
16
Forced ventilation – size diagram
Real pressure in the ventilation duct
pA
L = The A-measured sound pressure level at 10 m² sabin
L = The A-measured sound pressure level relative to 1 pW
WA
Installation instructions en
17
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001578320*
9001578320 (010125)
en
Loading...
