Bosch DSA-N2C6X3-12AT, DSA-N2E6X2-08AT, DSA-N2E6X2-12AT, DSA-N2E6X3-12AT, DSX-N1D6X2-12AT Specsheet

Video | DSA E-Series iSCSI Disk Arrays

DSA E-Series iSCSI Disk Arrays

www.boschsecurity.com

u Scale-out network storage solution: controller unit

with 12 internal HDDs with up to 192 HDDs via
state-of-the-art SAS interface-connected expansion
units

DSA E‑Series represents the next generation of iSCSI
digital video disk arrays by Bosch. They are state-of­the-art platforms designed for the security industries
most demanding digital video storage applications to
manage relentlessly growing digital video data. Since
HD IP cameras and encoders have entered the
surveillance market, the ever growing need for high
bandwidth and low complexity of the storage
infrastructure are the main challenges. The new
DSA E‑Series is the answer to it.

System overview

DSA E‑Series is based on one 2U controller unit with
12 internal 3.5”, 7.2 K, SAS (Serial Attached SCSI),
2 TB or 3 TB HDDs (Nearline SAS). The controller unit
is available as a standard Simplex Controller
configuration and as a Dual Simplex Controller
configuration for high-capacity and extreme
performance requirements.
This storage system is a high-performance solution
designed with robust flexibility that makes it a great fit
for wide-ranging video surveillance requirements. Its
balanced performance is designed for supporting high
bandwidth and I/O intensive workloads. The

u Configurable hardware-based RAID protection

(RAID‑5 or RAID‑6) for highest system performance

u Redundant hot-swappable power supplies and

cooling fans

u Two 10 Gigabit Ethernet ports for highest speed

iSCSI connectivity

u Fully modular design for ease of service

DSA E‑Series’ disk shelf option with a standard 2U
expansion unit with 12 x 3.5”, 7.2 K, SAS, 2 TB or 3 TB
HDD and a high-density 4U expansion unit with 60 x

3.5”, 7.2 K, SAS, 3 TB HDD enable custom
configurations that can be optimized for any
environment. And the DSA E‑Series’ fully redundant
I/O paths, advanced protection features, and extensive
diagnostic capabilities deliver high levels of
availability, integrity, and security.

Functions

DSA E‑Series is the co-branded E2600 series from
NetApp. It is a scale-out network storage solution that
provides security, highest “in-the-box” scalability,
peace-of-mind data protection, and simplified
management of all your video data. NetApp pioneered
the iSCSI protocol years ago and offers with the new
E2600 product line a high-end product for the physical
security market.
DSA E‑Series in Simplex Controller configuration
allows connecting up to seven disk shelf expansion
units (12 x 2 TB or 3 TB HDD per expansion shelf) to
one Single Controller base unit. In Dual Simplex

2 | DSA E-Series iSCSI Disk Arrays

Controller configuration up to three high-density shelf
expansion units (60 x 3 TB HDD per expansion shelf)
to one Dual Controller base unit may be connected.
It is a fully featured RAID protected disk array which
provides RAID‑5 protection for capacity-oriented
environments and RAID‑6 protection for availability­oriented environments. The RAID protection is based
on a hardware RAID implementation for highest
system performance. RAID‑6 is highly recommended if
the system will be used with a larger number of disk
shelf expansion units.

High reliability and availability

DSA E‑Series keeps your data safe and available with
redundant hot-swappable power and fans, and
protection from double-disk failure and single bit
errors during RAID rebuilds with high performance
RAID‑6.
With over 20 years of storage development experience,
DSA E‑Series is based on a field-proven design
architected to provide high reliability and availability.
Its redundant components, automated path failover,
and online administration keep organizations
productive 24 x 7 x 365.
Further high-availability features include:

• Automatic drive failover and detection and rebuild
using global hot spare drives

• Mirrored data cache with battery backup and destage
to flash

• SANtricity Proactive Drive Health monitoring
identifies problem drives before they create issues

Monitoring

Full SNMP support with MIB‑II and NetApp custom
MIBs supported. In case of component failures SNMP,
e-mail alert notifications will be generated.
Additionally, an Event Monitor for sending alert
notifications to a central Major Event Log is available.

Management

NetApp SANtricity storage management software
combines robustness and ease of use. Full-time
storage administrators appreciate the extensive
configuration flexibility which allows optimal
performance tuning and complete control over data
placement. Part-time system administrators love the
intuitive interface and wizards designed to simplify
their tasks. With its dynamic capabilities, SANtricity
software supports on-the-fly expansion,
reconfiguration, and maintenance without interrupting
storage system I/O. SANtricity software is available as
32-bit and 64-bit Microsoft OS installation package.

Certifications and approvals

Region Certification

Europe CE DSA E-Series (2.0)

USA UL DSA E-Series

Installation/configuration notes

Installable on 32-bit and 64-bit Windows Clients,
SANtricity storage management software provides
easy central management of all DSA E‑Series arrays
available within one network. There is no additional
software necessary to be installed on peripheral
devices. In addition, the system provides a powerful
Command Line Interface (CLI) which is fully remote
accessible by SSH (Secure Shell).
DSA E‑Series offers per controller a serial console
connector and two dedicated Ethernet management
ports for management access and 2 x 10 Gigabit
Ethernet iSCSI host ports. Each port must be
configured with a separate IP address; the two iSCSI
host ports are separated access paths to the storage
system and represent an individual iSCSI target each.
The net capacity available is shown in the following
table:

Configuration Information
(RAID-5)

Controller Unit (8 x 2 TB) 13034

Controller Unit (12 x 2 TB) 20482

Controller Unit (12 x 3 TB) 30723

Expansion Unit (12 x 2 TB) 20482

Expansion Unit (12 x 3 TB) 30723

Expansion Unit (60 x 3 TB) 153670

Configuration Information
(RAID-6)

Controller Unit (8 x 2 TB) 11172

Controller Unit (12 x 2 TB) 18620

Controller Unit (12 x 3 TB) 27930

Expansion Unit (12 x 2 TB) 18620

Expansion Unit (12 x 3 TB) 27930

Expansion Unit (60 x 3 TB) 139700

Net Capacity (GB)

Net Capacity (GB)

The limitations for the number of concurrent iSCSI
sessions and bandwidth are outlined in the table
below (specifications per controller only):

Network Uplink 1 GbE (RAID-5)

iSCSI

Single
port

Dual
port

Sessions

400 500 / 32 500 / 60

300 per
port

Bandwidth
Mbps
(Base Unit
12 x HDD)

500 / 32 800 / 160

Bandwidth Mbps
(min. 1 x Base Unit + 1 x
Expansion Unit:
24 x HDD)

3 | DSA E-Series iSCSI Disk Arrays

Network Uplink 10 GbE (RAID-5)

iSCSI

Single
port

Dual
port

Network Uplink 1 GbE (RAID-6)

iSCSI

Single
port

Dual
port

Network Uplink 10 GbE (RAID-6)

iSCSI

Single
port

Dual
port

Sessions

400 500 / 32 800 / 60

300 per
port

Sessions

400 400 / 25 600 / 50

300 per
port

Sessions

400 400 / 25 600 / 50

300 per
port

Notice

iSCSI session specifications refer to the total
number of recording and replay sessions.
Bandwidth data refer to <Recording> / <Replay>.
The maximum overall bandwidth of a Dual
Controller (Duplex) system is: 1920 Mbps read /
write throughput in a 10 GbE uplink network.

Bandwidth
Mbps
(Base Unit
12 x HDD)

500 / 32 800 / 160

Bandwidth
Mbps
(Base Unit
12 x HDD)

400 / 25 600 / 50

Bandwidth
Mbps
(Base Unit
12 x HDD)

400 / 25 600 / 120

Bandwidth Mbps
(min. 1 x Base Unit + 1 x
Expansion Unit:
24 x HDD)

Bandwidth Mbps
(min. 1 x Base Unit + 1 x
Expansion Unit:
24 x HDD)

Bandwidth Mbps
(min. 1 x Base Unit + 1 x
Expansion Unit:
24 x HDD)

Technical specifications

Base Unit DSA‑N2E6X2‑08AT

Electrical requirements—controller unit

Parameter Low range High range

Nominal voltage 100 VAC 240 VAC

Frequency 50 to 60 Hz 50 to 60 Hz

Idle current 3.97 A 1.63 A

Maximum operating
current

Sequential drive
group spin up

Simultaneous drive
spin up

System rating plate
label

Power ratings

KVA 0.400

AC Watts 399

BTU/h 1366

Note: for detailed information please see the NetApp E‑Series Storage
Systems Site Preparation Guide

System hardware specifications

Chassis CE2600 controller-drive tray

Power supplies Dual redundant, hot pluggable

Maximum disk drives 8 x 2 TB, 3.5”, Nearline SAS

Maximum net capacity ~13000 GB (RAID‑5 configured)

DDR2 memory (system RAM) 2 GB

4.25 A 1.68 A

4.27 A 1.76 A

6.13 A 2.71 A

7.0 A 2.9 A

conforms to the 483 mm
(19.0 in) rack standard

Notice

DSA E‑Series in Simplex Controller configuration
are only supported by BVIP Firmware 5.52 and
later and VRM 2.30 and later.
DSA E‑Series in Dual Simplex Controller
configuration are only supported by BVIP
Firmware 5.60 and later and VRM 3.0 and later.
DSA E‑Series controller units and 2U expansion
units with 3 TB drives are only supported by BVIP
Firmware 5.60 and later, VRM 3.0 and later, and
Configuration Manager 4.45 and later.

Integrated I/O 2 x 100 Mbps management port;

2 x 1/10 Gigabit Ethernet, copper

Remote management (via LAN) Yes (plus serial console on

dedicated port)

Mechanical

Dimensions (H x W x D)

• Controller-drive tray 86.4 x 482.6 x 552.5 mm
(3.4 x 19 x 21.75 in)

• Shipping carton 241.3 x 584.2 x 685.8 mm
(9.5 x 23 x 27 in)

Weight

• Maximum weight 23 kg (55.72 lb )

• Maximum shipping weight 27.75 kg (61.2 lb)

4 | DSA E-Series iSCSI Disk Arrays

Space requirements

Front—cooling 760 mm (30 in) clearance in front

Rear—cooling 610 mm (24 in) clearance behind

Front of chassis—maintenance 760 mm (30 in) clearance in front

Rear of chassis—maintenance 610 mm (24 in) clearance behind

Environmental

Temperature

• Operating range (both
cabinet and subsystem)

• Maximum rate of change 10 °C (50 °F) per hour

• Storage range -10 °C to +50 °C (+14 °F to

Relative humidity (non-condensing)

• Operating range (both
cabinet and subsystem)

• Storage range 10 to 90%

Acoustic noise

• Sound power (standby
operation)

• Sound pressure (normal
operation)

of the controller

the controller

of the cabinet

the cabinet

+10 °C to +35 °C (+50 °F to
+104 °F)

+122 °F)

20 to 80%

6.5 bels max

65 dBA max

Base Unit DSA‑N2E6X2‑12AT / DSA‑N2C6X2‑12AT /
DSA‑N2E6X3‑12AT / DSA‑N2C6X3‑12AT

Electrical requirements—per controller unit

Parameter Low range High range

BTU/h 1366

Note: for detailed information please see the NetApp E‑Series Storage
Systems Site Preparation Guide

System hardware specifications—per controller chassis

Chassis CE2600 controller-drive tray

conforms to the 483 mm
(19.0 in) rack standard

Power supplies Dual redundant, hot pluggable

(per controller unit)

Maximum disk drives 12 x 2 TB / 3 TB, 3.5”, Nearline

SAS

Maximum net capacity ~20500 GB / 30700 GB (RAID‑5

configured)

DDR2 memory (system RAM) 2 GB

Integrated I/O 2 x 100 Mbps management port;

2 x 1/10 Gigabit Ethernet, copper
(per controller unit)

Remote management (via LAN) Yes (plus serial console on

dedicated port)

Mechanical—per controller chassis

Dimensions (H x W x D)

• Controller-drive tray 86.4 x 482.6 x 552.5 mm
(3.4 x 19 x 21.75 in)

• Shipping carton 241.3 x 584.2 x 685.8 mm
(9.5 x 23 x 27 in)

Weight

• Maximum weight 24.9 kg (54.9 lb) / 27 kg
(59.52 lb)

• Maximum shipping weight 29.65 kg (65.37 lb) / 31.75 kg
(70.0 lb)

Nominal voltage 100 VAC 240 VAC

Frequency 50 to 60 Hz 50 to 60 Hz

Idle current 3.97 A 1.63 A

Maximum operating
current

Sequential drive
group spin up

Simultaneous drive
spin up

System rating plate
label

Power ratings—per controller unit

KVA 0.400

AC Watts 399

4.25 A 1.68 A

4.27 A 1.76 A

6.13 A 2.71 A

7.0 A 2.9 A

Space requirements—per controller chassis

Front—cooling 760 mm (30 in) clearance in front

Rear—cooling 610 mm (24 in) clearance behind

Front of chassis—maintenance 760 mm (30 in) clearance in front

Rear of chassis—maintenance 610 mm (24 in) clearance behind

Environmental—per controller chassis

Temperature

• Operating range (both

cabinet and subsystem)

• Maximum rate of change 10 °C (50 °F) per hour

of the controller

the controller

of the cabinet

the cabinet

+10 °C to +35 °C (+50 °F to
+104 °F)

5 | DSA E-Series iSCSI Disk Arrays

• Storage range -10 °C to +50 °C (+14 °F to

Relative humidity (non-condensing)

• Operating range (both
cabinet and subsystem)

• Storage range 10 to 90%

Acoustic noise

• Sound power (standby
operation)

• Sound pressure (normal
operation)

+122 °F)

20 to 80%

6.5 bels max

65 dBA max

Expansion Unit DSX‑N1D6X2‑12AT /
DSX‑N1D6X3‑12AT

Electrical requirements—expansion unit

Parameter Low range High range

Nominal voltage 100 VAC 240 VAC

Frequency 50 to 60 Hz 50 to 60 Hz

Idle current 2.96 A 1.23 A

Maximum operating
current

Sequential drive
group spin up

Simultaneous drive
spin up

System rating plate
label

Power ratings

KVA 0.276

AC Watts 276

BTU/h 954

Note: for detailed information please see the NetApp E‑Series Storage
Systems Site Preparation Guide

3.03 A 1.26 A

4.23 A 1.76 A

4.43 A 1.83 A

7.0 A 2.9 A

Mechanical

Dimensions (H x W x D)

• Drive tray 86.4 x 482.6 x 552.5 mm

• Shipping carton 241.3 x 584.2 x 685.8 mm

Weight

• Maximum weight 27 kg (59.52 lb)

• Maximum shipping weight 31.75 kg (70.0 lb)

Space requirements

Front—cooling 760 mm (30 in) clearance in front

Rear—cooling 610 mm (24 in) clearance behind

Front of chassis—maintenance 760 mm (30 in) clearance in front

Rear of chassis—maintenance 610 mm (24 in) clearance behind

Environmental

Temperature

• Operating range (both
cabinet and subsystem)

• Maximum rate of change 10 °C (50 °F) per hour

• Storage range -10 °C to +50 °C (+14 °F to

Relative humidity (non-condensing)

• Operating range (both
cabinet and subsystem)

• Storage range 10 to 90%

Acoustic noise

• Sound power (standby
operation)

(3.4 x 19 x 21.75 in)

(9.5 x 23 x 27 in)

of the cabinet

the cabinet

of the cabinet

the cabinet

+10 °C to +40 °C (+50 °F to
+104 °F)

+122 °F)

20 to 80%

6.5 bels max

System hardware specifications

Chassis DE1600 controller-drive tray

conforms to the 483 mm
(19.0 in) rack standard

Power supplies Dual redundant, hot pluggable

Maximum disk drives 12 x 2 TB / 3 TB, 3.5”, Nearline

SAS

Maximum net capacity ~20500 GB / 30700 GB (RAID‑5

configured)

Integrated I/O 6 Gb SAS

• Sound pressure (normal
operation)

6.8 bels max

Expansion Unit DSX‑N6D6X3‑60AT

Electrical requirements—expansion unit

Parameter Low range High range

Nominal voltage 220 VAC 240 VAC

Frequency 50 to 60 Hz 50 to 60 Hz

Idle current 6.0 A 6.0 A

Maximum operating
current

7.56 A 7.56 A

6 | DSA E-Series iSCSI Disk Arrays

Power ratings

KVA 1.268

AC Watts 1222

BTU/h 4180

Note: for detailed information please see the NetApp E‑Series Storage
Systems Site Preparation Guide

System hardware specifications

Chassis DE6600 controller-drive tray

conforms to the 483 mm
(19.0 in) rack standard

Power supplies Dual redundant, hot pluggable

Maximum disk drives 60 x 3 TB, 3.5”, Nearline SAS

Maximum net capacity ~153670 GB (RAID‑5

configured)

Integrated I/O 6 Gb SAS

Mechanical

Dimensions (H x W x D)

• Drive tray 177.8 x 482.6 x 825.5 mm
(7.0 x 19 x 32.5 in)

• Shipping carton 482.6 x 609.6 x 1009.7 mm
(19 x 24 x 39.75 in)

Weight

• Maximum weight 105.2 kg (232 lb)

• Maximum shipping weight 193.2 kg (426 lb)

Space requirements

Front—cooling 760 mm (30 in) clearance in front

of the cabinet

Rear—cooling 610 mm (24 in) clearance behind

the cabinet

Front of chassis—maintenance 760 mm (30 in) clearance in front

of the cabinet

Rear of chassis—maintenance 610 mm (24 in) clearance behind

the cabinet

Acoustic noise

• Sound power (standby
operation)

• Sound pressure (normal
operation)

6.5 bels max

6.8 bels max

Notes:

General technical information for the RAID systems are
provided in the NetApp E‑Series Storage Systems Site
Preparation Guide (Information Web: http://
www.netapp.com; Part number: 54541-01, December

2012)

NetApp and SANtricity are registered trademarks of NetApp, all rights reserved. All data and

dimensions are referenced from the NetApp Site Preparation Guide and from the NetApp

Website and are subject to change without notice.

Ordering information

DSA E-Series base, 8 x 2 TB

High-performance, high-capacity storage system base
unit, iSCSI disk array, 8 x 2 TB HDD

Order number DSA-N2E6X2-08AT

DSA E-Series base, 12 x 2 TB

High-performance, high-capacity storage system base
unit, iSCSI disk array, 12 x 2 TB HDD

Order number DSA-N2E6X2-12AT

DSA E-Series base, 12 x 3 TB

High-performance, high-capacity storage system base
unit, iSCSI disk array, 12 x 3 TB HDD

Order number DSA-N2E6X3-12AT

DSA E-Series base DC, 12 x 3 TB

High-performance, high-capacity storage system base
unit, iSCSI disk array, 12 x 3 TB HDD, Dual Controller

Order number DSA-N2C6X3-12AT

DSA E-Series shelf, 12 x 2 TB

High-performance, high-capacity storage system
expansion unit, iSCSI disk array, 12 x 2 TB HDD

Order number DSX-N1D6X2-12AT

DSA E-Series shelf, 12 x 3 TB

High-performance, high-capacity storage system
expansion unit, iSCSI disk array, 12 x 3 TB HDD

Order number DSX-N1D6X3-12AT

Environmental

Temperature

• Operating range 0 °C to +35 °C (+32 °F to +95 °F)

• Maximum rate of change 10 °C (50 °F) per hour

• Storage range -10 °C to +50 °C (+14 °F to
+122 °F)

Relative humidity (non-condensing)

• Operating range 20 to 80%

• Storage range 10 to 90%

DSA E-Series shelf, 60 x 3 TB

High-performance, high-capacity storage system
expansion unit, iSCSI disk array, 60 x 3 TB HDD

Order number DSX-N6D6X3-60AT

Accessories

DSA E-Series storage expansion 2 TB

2 TB HDD

Order number DSA-EDTK-200A

DSA E-Series storage expansion 3 TB

3 TB HDD

Order number DSA-EDTK-300A

7 | DSA E-Series iSCSI Disk Arrays

DSA E-Series rack

Empty rack, 40U

Order number DSX-NRCK40-INT

Services

Warranty extension, base 8 x 2 TB

12-month warranty extension for DSA E‑Series base
unit, 8 x 2 TB

Order number DSA-N2E6S8-ESW

Warranty extension, base 12 x 2 TB

12-month warranty extension for DSA E‑Series base
unit, 12 x 2 TB

Order number DSA-N2E6S12-ESW

Warranty extension, base 12 x 3 TB

12-month warranty extension for DSA E‑Series base
unit, 12 x 3 TB

Order number DSA-N2E6XS-ESW

Warranty extension, base DC 12 x 3 TB

12-month warranty extension for DSA E‑Series base
unit Dual Controller, 12 x 3 TB

Order number DSA-N2C6XS-ESW

Warranty extension, shelf 12 x 2 TB

12-month warranty extension for DSA E‑Series
expansion unit, 12 x 2 TB

Order number DSX-N1D6S12-ESW

Parts delivery, shelf 12 x 3 TB

12-month parts delivery within 4 hours for
DSA E‑Series expansion unit, 12 x 3 TB

Order number DSX-N1D6XS-4PD

Parts replacement, base 8 x 2 TB

12-month parts replacement within 4 hours for
DSA E‑Series base unit, 8 x 2 TB

Order number DSA-N2E6S8-4PR

Parts replacement, base 12 x 2 TB

12-month parts replacement within 4 hours for
DSA E‑Series base unit, 12 x 2 TB

Order number DSA-N2E6S12-4PR

Parts replacement, base 12 x 3 TB

12-month parts replacement within 4 hours for
DSA E‑Series base unit, 12 x 3 TB

Order number DSA-N2E6XS-4PR

Parts replacement, base DC 12 x 3 TB

12-month parts replacement within 4 hours for
DSA E‑Series base unit Dual Controller, 12 x 3 TB

Order number DSA-N2C6XS-4PR

Parts replacement, shelf 12 x 2 TB

12-month parts replacement within 4 hours for
DSA E‑Series expansion unit, 12 x 2 TB

Order number DSX-N1D6S12-4PR

Warranty extension, shelf 12 x 3 TB

12-month warranty extension for DSA E‑Series
expansion unit, 12 x 3 TB

Order number DSX-N1D6XS-ESW

Parts delivery, base 8 x 2 TB

12-month parts delivery within 4 hours for
DSA E‑Series base unit, 8 x 2 TB

Order number DSA-N2E6S8-4PD

Parts delivery, base 12 x 2 TB

12-month parts delivery within 4 hours for
DSA E‑Series base unit, 12 x 2 TB

Order number DSA-N2E6S12-4PD

Parts delivery, base 12 x 3 TB

12-month parts delivery within 4 hours for
DSA E‑Series base unit, 12 x 3 TB

Order number DSA-N2E6XS-4PD

Parts delivery, base DC 12 x 3 TB

12-month parts delivery within 4 hours for
DSA E‑Series base unit Dual Controller, 12 x 3 TB

Order number DSA-N2C6XS-4PD

Parts delivery, shelf 12 x 2 TB

12-month parts delivery within 4 hours for
DSA E‑Series expansion unit, 12 x 2 TB

Order number DSX-N1D6S12-4PD

Parts replacement, shelf 12 x 3 TB

12-month parts replacement within 4 hours for
DSA E‑Series expansion unit, 12 x 3 TB

Order number DSX-N1D6XS-4PR

Non-returnable disk, base 8 x 2 TB

12-month non-returnable disk option for DSA E‑Series
base unit, 8 x 2 TB

Order number DSA-N2E6S8-NRD

Non-returnable disk, base 12 x 2 TB

12-month non-returnable disk option for DSA E‑Series
base unit, 12 x 2 TB

Order number DSA-N2E6S12-NRD

Non-returnable disk, base 12 x 3 TB

12-month non-returnable disk option for DSA E‑Series
base unit, 12 x 3 TB

Order number DSA-N2E6XS-NRD

Non-returnable disk, base DC 12 x 3 TB

12-month non-returnable disk option for DSA E‑Series
base unit Dual Controller, 12 x 3 TB

Order number DSA-N2C6XS-NRD

Non-returnable disk, shelf 12 x 2 TB

12-month non-returnable disk option for DSA E‑Series
expansion unit, 12 x 2 TB

Order number DSX-N1D6S12-NRD

8 | DSA E-Series iSCSI Disk Arrays

Represented by:

Americas: Europe, Middle East, Africa: Asia-Pacific: China: America Latina:

Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.us

Bosch Security Systems B.V.
P.O. Box 80002
5617 BA Eindhoven, The Netherlands
Phone: + 31 40 2577 284
Fax: [phone]
[e-mail]
www.boschsecurity.com

Robert Bosch (SEA) Pte Ltd, Security
Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.asia

Bosch (Shanghai) Security Systems Ltd.
201 Building, No. 333 Fuquan Road
North IBP
Changning District, Shanghai
200335 China
Phone [phone]
Fax: [phone]
www.boschsecurity.com.cn

Robert Bosch Ltda Security Systems Division
Via Anhanguera, Km 98
CEP 13065-900
Campinas, Sao Paulo, Brazil
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.com

© Bosch Security Systems 2014 | Data subject to change without notice
13473637259 | en, V4, 13. Feb 2014

Non-returnable disk, shelf 12 x 3 TB

12-month non-returnable disk option for DSA E‑Series
expansion unit, 12 x 3 TB

Order number DSX-N1D6XS-NRD
