Microwave Oven
BFL520MS0 BFL520MW0 BFL520MB0 BFL520M.0
[en]
User manual and installation instructions
en Safety
Table of contents
USER MANUAL
1 Safety....................................................................2
2 Preventing material damage ...............................5
3 Environmental protection and saving en-
ergy .......................................................................5
4 Familiarising yourself with your appliance ........6
5 Before using for the first time .............................7
6 Basic operation ....................................................7
7 Cleaning and servicing........................................8
8 Troubleshooting.................................................10
9 Disposal..............................................................11
10 Customer Service...............................................11
11 How it works.......................................................11
12 INSTALLATION INSTRUCTIONS .......................15
12.1 Safe installation ..............................................
...15
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 4000m above
sea level.
This appliance complies with the standards
EN 55011 and CISPR 11. It is a group 2,
class B product. Group 2 means that microwaves are produced for the purpose of
heating food. Class B means that the appliance is suitable for private households.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inadequate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the
product information safe for future reference or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under the
warranty.
The appliance can only be used safely if it is
correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works perfectly at its
installation location.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
1.4 Safe use
WARNING‒Risk of fire!
Combustible objects that are left in the cooking compartment may catch fire.
▶
Never store combustible objects in the
cooking compartment.
▶
If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Overheating can cause a fire.
▶
Never install the appliance behind a decorative door or the door of a kitchen unit.
WARNING‒Risk of burns!
Accessories and cookware get very hot.
▶
Always use oven gloves to remove accessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any alcoholic vapours inside may catch fire.
▶
Only use small quantities of drinks with a
high alcohol content in food.
▶
Open the appliance door carefully.
2
Safety en
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, depending on the temperature.
▶
Open the appliance door carefully.
▶
Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶
Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶
Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the appliance door, as they may scratch
the surface.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶
Keep your hands away from the hinges.
Cracks, splinters or breaks in the glass
turntable are dangerous.
▶
Never allow hard objects to strike the
turntable.
▶
Handle the turntable with care.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repair-
ing the appliance.
▶
If the power cord of this appliance is dam-
aged, it must be replaced by the manufac-
turer, the manufacturer's Customer Service
or a similarly qualified person in order to
prevent any risk.
If the insulation of the power cord is damaged, this is dangerous.
▶
Never let the power cord come into contact
with hot appliance parts or heat sources.
▶
Never let the power cord come into contact
with sharp points or edges.
▶
Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶
Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked
or fractured surface.
▶
Call customer services. →Page11
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from chil-
dren.
▶
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
1.5 Microwave
Follow these safety instructions when using
the microwave.
WARNING‒Risk of fire!
Using the appliance for anything other than its
intended purpose is dangerous and may
cause damage. For example, heated slippers
and pillows filled with grain or cereal may
catch fire, even several hours later.
▶
Never dry food or clothing with the appli-
ance.
▶
Never heat up slippers, pillows filled with
grain or cereal, sponges, damp cleaning
cloths or similar with the appliance.
▶
The appliance must only be used to pre-
pare food and drink.
Food may catch fire.
▶
Never heat food contained in heat-retaining
packaging.
▶
Do not leave food heating unattended in
containers made of plastic, paper or other
combustible materials.
▶
Never set the microwave power too high or
the cooking time too long. Follow the in-
structions provided in this instruction
manual.
▶
Never use the microwave to dry food.
3
en Safety
▶
Never defrost or heat food with a low water
content, such as bread, at too high a microwave power or for too long.
Cooking oil may catch fire.
▶
Never use the microwave to heat cooking
oil on its own.
WARNING‒Risk of explosion!
Liquids and other food may explode when in
containers that have been tightly sealed.
▶
Never heat liquids or other food in containers that have been tightly sealed.
WARNING‒Risk of burns!
Foods with peel or skin may burst or explode
during heating, or even afterwards.
▶
Never cook eggs in their shells or reheat
hard-boiled eggs.
▶
Never cook shellfish or crustaceans.
▶
Always prick the yoke when baking or
poaching eggs.
▶
The skin of foods that have a peel or skin,
such as apples, tomatoes, potatoes and
sausages, may burst. Always prick the peel
or skin before heating.
Heat is not distributed evenly through baby
food.
▶
Never heat baby food in closed containers.
▶
Always remove the lid or teat.
▶
Stir or shake well after heating.
▶
Check the temperature before giving the
food or drink to a child.
Heated food gives off heat. The cookware
may become hot.
▶
Always use oven gloves to remove cook-
ware or accessories from the cooking com-
partment.
Airtight packaging may burst when food is
heated.
▶
Always follow the instructions on the pack-
aging.
▶
Always use oven gloves to remove dishes
from the cooking compartment.
The accessible parts of the appliance become
hot during operation.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
Using the appliance for anything other than its
intended purpose is dangerous. This is because, for instance, overheated slippers, pillows filled with grain or cereal, sponges and
damp cleaning cloths, etc., may cause burns
to the skin.
▶
Never dry food or clothing with the appliance.
▶
Never heat up slippers, pillows filled with
grain or cereal, sponges, damp cleaning
cloths or similar with the appliance.
▶
The appliance must only be used to prepare food and drink.
WARNING‒Risk of scalding!
There is a possibility of delayed boiling when
a liquid is heated. This means that the liquid
reaches boiling temperature without the usual
steam bubbles rising to the surface. Even if
the container only vibrates a little, the hot liquid may suddenly boil over and spatter.
▶
Always place a spoon in the container
when heating liquids. This will prevent
delayed boiling.
WARNING‒Risk of injury!
Unsuitable cookware may crack. Porcelain or
ceramic cookware can have small perforations in the handles and lid. These perforations conceal a cavity below. If moisture penetrates this cavity, it could cause the cookware to crack.
▶
Only use microwave-safe cookware.
Cookware and containers made from metal or
cookware with metal edging may lead to
sparks being formed during simple microwave operation. The appliance is damaged.
▶
Never use metal containers during mi-
crowave-only operation.
▶
Only use microwave-safe cookware.
WARNING‒Risk of electric shock!
The appliance uses a high voltage.
▶
Never remove the casing.
WARNING‒Risk of serious harm to
health!
The surface of the appliance may become
damaged if it is not cleaned properly. Microwave energy may escape.
4
Preventing material damage en
▶
Clean the appliance on a regular basis,
and remove any food residue immediately.
▶
Always keep the cooking compartment,
door and door stop clean.
Microwave energy may escape if the cooking
compartment door is damaged.
▶
Never use the appliance if the cooking
compartment door or the plastic door
frame is damaged.
2 Preventing material damage
2.1 General
ATTENTION!
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶
Always wipe away the condensation after cooking.
▶
Do not keep moist food in the cooking compartment
for a long time with the door closed.
▶
Do not store food in the cooking compartment.
Sitting or placing objects on the appliance door may
damage it.
▶
Do not place or hang objects on the appliance door.
2.2 Microwave
Follow these instructions when using the microwave.
ATTENTION!
Metal touching the wall of the cooking compartment
will cause sparks, which may damage the appliance or
the inner door pane.
▶
Metal (e.g. a spoon in a glass) must be kept at least
2cm from the cooking compartment walls and the
inside of the door.
Placing aluminium containers in the appliance may
cause sparks, which will damage the appliance.
▶
Do not use aluminium containers in the appliance.
Operating the appliance without food in the cooking
compartment may lead to overloading.
▶
Call the customer service.
Microwave energy will escape from appliances that do not have any casing.
▶
Never remove the casing.
▶
Contact our after-sales service if mainten-
ance or repair work is needed.
▶
Do not switch on the microwave unless there is food
inside. The only exception to this rule is when per-
forming a short cookware test.
If you prepare several bags of microwave popcorn in
immediate succession at a microwave power level that
is too high, the cooking compartment may be damaged.
▶
Leave the appliance to cool down for several
minutes between each use.
▶
Never set a microwave power level that is too high.
▶
Use a maximum microwave output of 600 watts.
▶
Always place the popcorn bag on a glass plate.
The microwave feed is damaged by the removal of the
cover.
▶
Never remove the cover of the microwave feed in
the cooking compartment.
Removing the transparent film from the inside of the
door damages the appliance door.
▶
Never remove the transparent film on the inside of
the door.
Liquid that penetrates the interior of the appliance may
damage the turntable drive.
▶
Monitor the cooking process.
▶
Set a shorter cooking time first and, if necessary, in-
crease the cooking time.
▶
Never use the appliance without the turntable.
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
5
en Familiarising yourself with your appliance
1
2
3
1
2
3
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
Note:On certain models, specific details such as colour and shape may differ from those pictured.
Door opener Open the door.
Time switch Set the cooking time in minutes.
Power selector Set the microwave power setting in watts.
4.2 Types of heating
Here you can find an overview of the types of heating. You can find recommendations on using the types of heating.
Symbol Name Use
90–800 Microwave Defrosting, cooking or heating food and liquids.
6
Before using for the first time en
4.3 Cooling fan
The cooling fan switches on and off as required.
The cooking compartment remains cold during microwave operation. Despite this, the cooling fan will still
switch on.
Note:The cooling fan may run on even if the oven has
been switched off.
5 Before using for the first time
Configure the settings for initial start-up. Clean the appliance and accessories.
5.1 Cleaning the appliance before using it for the first time
Clean the cooking compartment and accessories before using the appliance to prepare food for the first
time.
1.
Make sure that there is no leftover packaging, accessories or other objects in the cooking compartment.
2.
Clean the smooth surfaces in the cooking compartment with a soft, damp cloth.
3.
To eliminate the new-appliance smell, wipe the
empty cooking compartment with hot soapy water.
→"Cleaning the cooking compartment", Page9
4.4 Condensation
Condensation can occur in the cooking compartment
and on the appliance door when cooking. Condensation is normal and does not adversely affect appliance
operation. Wipe away the condensation after cooking.
5.2 Fitting the turntable
Never use the appliance without the turntable.
1.
Place the roller ring into the recess in the cooking
compartment.
6 Basic operation
6.1 Microwave power settings
This is where you can find an overview of the different
microwave power settings and when to use them.
Microwave power
setting in watts
90 Defrost delicate foods.
180 Defrost food and continue
360 Cooking meat and fish or heat-
600 Heat and cook food.
800 Heat liquids.
6.2 Microwave-safe cookware and accessories
To heat food evenly and avoid damaging your appliance, it is important to use the right cookware and accessories.
Note:Read the manufacturer's instructions before using any cookware in the microwave. If in doubt, carry
out a cookware test.
Use
cooking.
ing delicate foods.
2.
Engage the turntable in the drive in the centre
of the cooking compartment floor.
3.
Check whether the turntable is correctly engaged.
Note:The turntable can turn anti-clockwise or clock-
wise.
Microwave-safe
Cookware and accessories
Cookware made from
heat-resistant, microwavesafe material:
¡ Glass
¡ Glass ceramic
¡ Porcelain
¡ Temperature-resistant
plastic
¡ Fully glazed ceramic
without cracks
Metal cutlery Note:You can use metal
ATTENTION!
Metal touching the wall of the cooking compartment
will cause sparks, which may damage the appliance or
the inner door pane.
Reason
These materials allow microwaves to pass
through. Microwaves do
not damage heat-resistant
cookware.
cutlery, e.g. place a
spoon in a glass, to prevent delayed boiling.
7
en Cleaning and servicing
▶
Metal (e.g. a spoon in a glass) must be kept at least
2cm from the cooking compartment walls and the
inside of the door.
Not microwave-safe
Cookware and accessories
Metal cookware Metal does not allow mi-
Cookware with gold or silver decoration
Reason
crowaves to pass
through. The food hardly
heats up.
Microwaves can damage
gold and silver decoration.
Tip:You can only use this
kind of cookware if the
manufacturer guarantees
that it is microwave-safe.
6.3 Testing cookware for microwave suitability
Test cookware to see whether it is suitable for microwave use. Testing cookware is the only time the appliance should be operated in microwave mode without
any food inside.
WARNING‒Risk of scalding!
The accessible parts of the appliance become hot during operation.
▶
Never touch these hot parts.
▶
Keep children at a safe distance.
1.
Place the empty cookware in the cooking compartment.
2.
Set the appliance to the maximum microwave power
setting for 30 seconds to 1 minute.
3.
Start the operation.
4.
Check the cookware several times:
– If the cookware is cold or warm to the touch, it is
suitable for microwave use.
– If the cookware becomes hot or sparks are cre-
ated, stop the cookware test. The cookware is
not microwave-safe.
6.4 Configuring the microwave settings
ATTENTION!
Operating the appliance without food in the cooking
compartment may lead to overloading.
▶
Do not switch on the microwave unless there is food
inside. The only exception to this rule is when performing a short cookware test.
Tip:To ensure optimum use of your appliance, you can
refer to the information in the recommended settings.
→"How it works", Page11
1.
Follow the safety instructions. →Page3
2.
Read the safety instructions and the section on how
to prevent material damage. →Page5
3.
Read the information on microwave-safe cookware
and accessories. →Page7
4.
Use the power selector to set the required microwave power setting.
5.
Use the time selector to set the required cooking
time.
If the required cooking time is less than
twominutes, first set it to a longer duration and then
back to the required duration.
Note:If you open the cooking compartment door during operation, the microwave interrupts the operation
and pauses the set time that is counting down. When
you close the cooking compartment door, the operation continues.
6.5 Changing the cooking time
You can change the cooking time at any time.
▶
Use the time selector to set the required cooking
time.
If the required cooking time is less than
twominutes, first set it to a longer duration and then
back to the required duration.
6.6 Pausing operation
1.
Open the appliance door.
2.
To continue the operation, close the appliance door.
a The set cooking time continues to count down.
6.7 Cancelling the operation
▶
Set the time selector to 0.
7 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
7.1 Cleaning products
Only use suitable cleaning products.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Do not use steam- or high-pressure cleaners to
clean the appliance.
8
ATTENTION!
Unsuitable cleaning products may damage the surfaces of the appliance.
▶
Do not use harsh or abrasive detergents.
▶
Do not use cleaning products with a high alcohol
content.
▶
Do not use hard scouring pads or cleaning
sponges.
▶
Do not use any special cleaners for cleaning the appliance while it is hot.
▶
Only use glass cleaners, glass scrapers or stainless
steel care products if recommended in the cleaning
instructions for the relevant part.
▶
Wash sponge cloths thoroughly before use.
You can find out which cleaning products are suitable
for each surface or part of the appliance in the individual cleaning instructions.
7.2 Cleaning the appliance
Clean the appliance as specified. This will ensure that
the different parts and surfaces of the appliance are
not damaged by incorrect cleaning or unsuitable cleaning products.
WARNING‒Risk of injury!
Scratched glass in the appliance door may develop
into a crack.
▶
Do not use any harsh or abrasive cleaners or sharp
metal scrapers to clean the glass on the appliance
door, as they may scratch the surface.
1.
Read the information on cleaning products.
→Page8
2.
Observe the information on cleaning the appliance
components or surfaces.
3.
Unless otherwise specified:
‒ Clean the components of the appliance with hot
soapy water and a dish cloth.
‒ Dry with a soft cloth.
7.3 Cleaning the cooking compartment
ATTENTION!
Incorrect cleaning may damage the cooking compartment.
▶
Do not use oven spray, abrasive materials or other
aggressive oven cleaners.
1.
Read the information on cleaning products.
→Page8
2.
Clean with hot soapy water or a vinegar solution.
3.
Use oven cleaner to remove very heavy soiling.
Only use oven cleaner when the cooking compart-
ment is cold.
Tip:To eliminate unpleasant odours, heat up a cup
of water with a few drops of lemon juice for 1 to
2minutes at maximum microwave power setting. Always place a spoon in the container to prevent
delayed boiling.
4.
Wipe out the cooking compartment with a soft cloth.
5.
Leave the cooking compartment to dry with the door
open.
Cleaning the turntable
1.
Read the information on cleaning products.
→Page8
2.
Remove the turntable.
3.
Clean the turntable with hot soapy water and a soft
dish cloth.
4.
Dry with a soft cloth.
5.
Reinsert the turntable.
Ensure that the turntable engages correctly.
Cleaning and servicing en
7.4 Cleaning the front of the appliance
ATTENTION!
Incorrect cleaning may damage the front of the appliance.
▶
Do not use glass cleaner, metal scrapers or glass
scrapers for cleaning.
▶
To prevent corrosion on stainless steel fronts, re-
move any limescale, grease, starch and albumin
(e.g. egg white) stains immediately.
▶
On stainless steel surfaces, use special stainless
steel cleaning products suitable for hot surfaces.
1.
Read the information on cleaning products.
→Page8
2.
Clean the front of the appliance using hot soapy wa-
ter and a dish cloth.
Note:Slight differences in colour on the front of the
appliance are caused by the use of different materi-
als, such as glass, plastic and metal.
3.
For stainless steel appliance fronts, apply a thin
layer of the stainless steel cleaning product with a
soft cloth.
You can obtain the stainless steel cleaning products
from the after-sales service or the online shop.
4.
Dry with a soft cloth.
7.5 Cleaning the control panel
ATTENTION!
Incorrect cleaning may damage the control panel.
▶
Never wipe the control panel with a wet cloth.
1.
Read the information on cleaning products.
→Page8
2.
Clean the control panel using a microfibre cloth or a
soft, damp cloth.
3.
Dry with a soft cloth.
7.6 Cleaning the accessories
1.
Read the information on cleaning products.
→Page8
2.
Soften baked-on food remnants with a damp dish
cloth and hot soapy water.
3.
Clean the accessory with hot soapy water and a soft
dish cloth or a scrubbing brush.
4.
Dry with a soft cloth.
7.7 Cleaning the door panels
ATTENTION!
Incorrect cleaning may damage the door panes.
▶
Do not use a glass scraper.
1.
Read the information on cleaning products.
→Page8
2.
Clean the door panels with a soft dish cloth and
glass cleaner.
Note:Shadows on the door panels, which look like
streaks, are caused by reflections made by the in-
terior lighting.
3.
Dry with a soft cloth.
9
en Troubleshooting
7.8 Cleaning aid
The cleaning aid is a quick alternative for occasionally
cleaning the cooking compartment. The cleaning aid
softens dirt by vaporising the soapy water. The dirt can
then be removed more easily.
Setting the cleaning aid
1.
Add a few drops of washing-up liquid to a cup of
water.
2.
Place a spoon in the cup to prevent delayed boiling.
8 Troubleshooting
3.
Place the cup in the centre of the cooking compartment.
4.
Set the microwave power setting to 600W.
5.
Set the duration to threeminutes.
6.
Start the microwave.
7.
Once the duration has elapsed, keep the door
closed for a further threeminutes.
8.
Wipe out the cooking compartment with a soft cloth.
9.
Leave the cooking compartment to dry with the door
open.
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
Only use genuine spare parts when repairing the
appliance.
▶
If the power cord of this appliance is damaged, it
must be replaced by the manufacturer, the manufacturer's Customer Service or a similarly qualified person in order to prevent any risk.
8.1 Malfunctions
Fault Cause and troubleshooting
The appliance is not working. The mains plug of the power cord is not plugged in.
▶
Connect the appliance to the power supply.
The circuit breaker is faulty.
▶
Check the circuit breaker in the fuse box.
There has been a power cut.
▶
Check whether the lighting in your kitchen or other appliances are working.
Malfunction
1.
Switch off the fuse in the fuse box.
2.
Switch the fuse back on after approx. 10seconds.
a If the fault was a one-off, the message disappears.
3.
If the message appears again, call the after-sales service. Please specify the
exact error message when calling.
→"Customer Service", Page11
Door is not fully closed.
▶
Check whether food remains or foreign material are trapped in the door.
The time selector is not set.
▶
Set the time selector. →Page8
Food takes longer than usual to
heat up.
Turntable grates or grinds. There is dirt or foreign objects in the area of the turntable drive.
Microwave mode is cancelled. Appliance has a fault.
The microwave power setting is set too low.
▶
Set a higher microwave power setting. →Page8
You have placed a larger amount of food than normal in the appliance.
▶
Set a longer cooking time.
You need double the time when you have double the amount.
The food is colder than usual.
▶
Turn or stir the food from time to time during cooking.
▶
Clean the roller ring and recess in the cooking compartment.
▶
If this fault recurs, call the after-sales service.
10
Fault Cause and troubleshooting
The appliance is not in operation.
A cooking time is shown in the
display.
The turntable has been activated accidentally.
▶
Press .
9 Disposal
Disposal en
Find out here how to dispose of old appliances correctly.
9.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
▶
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local authority.
10 Customer Service
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Detailed information on the warranty period and terms
of warranty in your country is available from our aftersales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
This appliance is labelled in accordance with European Directive
2012/19/EU concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE).
The guideline determines the framework for the return and recycling of
used appliances as applicable
throughout the EU.
10.1 Product number (E-Nr.) and production number (FD)
You can find the product number (E-Nr.) and the production number (FD) on the appliance's rating plate.
You will see the rating plate with these numbers if you
open the appliance door.
Make a note of your appliance's details and the Customer Service telephone number to find them again
quickly.
11 How it works
Here, you can find the ideal settings for various dishes
as well as the best accessories and cookware. We
have tailored these recommendations to your appliance.
11.1 What is the best way to proceed?
In this section, you will find out the best way to proceed
step-by-step in order to be able to make optimum use
of the recommended settings. You will get information
on many meals, with details and tips on how to best
use and set your appliance.
WARNING‒Risk of burns!
Heated food gives off heat. The cookware may become
hot.
▶
Always use oven gloves to remove cookware or accessories from the cooking compartment.
Note:The times given in the tables are guidelines and
depend on the quality, temperature and consistency of
the food.
1.
Before using the appliance, remove all unnecessary
cookware from the cooking compartment.
2.
Select a type of food from the recommended set-
tings.
3.
Add the food to a suitable tableware.
→"Microwave-safe cookware and accessories",
Page7
4.
Always place the cookware on the turntable.
5.
Set the appliance according to the recommended
settings.
Time ranges are often specified in the recommen-
ded settings. Set the shorter cooking time first. If ne-
cessary, increase the cooking time. If two mi-
crowave power settings and times are specified in
the tables, set the first microwave power setting and
cooking time first and, after the signal, set the
second.
Tip:If you want to cook quantities that deviate from
those specified in the tables, set approximately double
the time for double the amount.
11
en How it works
11.2 Tips for defrosting and heating
Follow these tips for good results when defrosting and
heating.
Issue Tip
The food should be defrosted, hot or cooked
once the time has
elapsed.
Once the time has
elapsed, the food should
not be overheated at the
edge and cooked in the
middle.
After defrosting, poultry or
meat should not be defrosted on the outside
only but still frozen in the
middle.
The food should not be
too dry.
Set a longer cooking
time. Larger quantities
and food which is piled
high require longer times.
¡ Stir the food occasion-
ally.
¡ Set a lower microwave
power setting and a
longer cooking time.
¡ Set a lower microwave
power setting.
¡ If you are defrosting a
large quantity, turn it
several times.
¡ Set a lower microwave
power setting.
¡ Set a shorter cooking
time.
¡ Cover the food.
¡ Add more liquid.
11.3 Defrosting
With your appliance you can defrost frozen food.
Defrosting food
1.
Place the frozen food in an open container on the
turntable.
Delicate parts, such as the legs and wings of
chicken or fatty outer layers of roasts, can be
covered with small pieces of aluminium foil. The foil
must not touch the sides of the cooking compartment.
2.
Start the operation.
You can remove the foil halfway through the defrost-
ing time.
3.
Note:Liquid is produced when you defrost meat
and poultry.
Drain off any liquid when turning and under no cir-
cumstances use it for other purposes or allow it to
come into contact with other foods.
4.
Redistribute the food or turn it once or twice as it
defrosts.
Turn large pieces of food several times.
5.
To even out the temperature, leave the defrosted
food to stand at room temperature for approx. 10–
20 minutes.
You can remove the giblets from poultry at this
point. You can continue to cook the meat even if a
small section of it is still frozen in the centre.
Defrosting with the microwave
Observe the recommended settings for using the microwave to defrost frozen food.
Food Weight ing Microwave power
setting inW
Whole pieces of beef, veal or pork (on the
bone or boned)
Whole pieces of beef, veal or pork (on the
bone or boned)
Whole pieces of beef, veal or pork (on the
bone or boned)
Meat in pieces or slices of beef, veal or pork 200 1. 180
Meat in pieces or slices of beef, veal or pork 500 1. 180
Meat in pieces or slices of beef, veal or pork 800 1. 180
Minced meat, mixed
Minced meat, mixed
Minced meat, mixed
1
Separate any defrosted parts when turning.
2
Freeze the food flat.
3
Remove any meat that has already defrosted.
4
Turn the food several times.
5
Separate any defrosted parts.
6
Carefully stir the food occasionally.
7
Remove all packaging.
8
Only defrost cakes without icing, whipped cream, gelatine or custard.
9
Separate the pieces of cake.
2, 3
2, 3
2, 3
800 1. 180
2. 90
1000 1. 180
2. 90
1500 1. 180
2. 90
2. 90
2. 90
2. 90
200 90 10
500 1. 180
2. 90
800 1. 180
2. 90
Cooking time inmins
1. 15
2. 10–20
1. 20
2. 15–25
1. 30
2. 20–30
1
1. 2
2. 4–6
1
1. 5
2. 5–10
1
1. 8
2. 10–15
4
4
1. 5
2. 10–15
4
1. 8
2. 10–20
12
How it works en
Food Weight ing Microwave power
Cooking time inmins
setting inW
Poultry or poultry portions
Poultry or poultry portions
Fish fillet, fish steak or fish slices
5
5
5
600 1. 180
2. 90
1200 1. 180
2. 90
400 1. 180
2. 90
1. 8
2. 10–20
1. 15
2. 10–20
1. 5
2. 10–15
Vegetables, e.g. peas 300 180 10–15
Fruit, e.g. raspberries
Fruit, e.g. raspberries
Butter, defrosting
Butter, defrosting
Loaf of bread 500 1. 180
Loaf of bread 1000 1. 180
Cakes, plain, e.g. sponge cake
Cakes, plain, e.g. sponge cake
Cakes, moist, e.g. fruit flan, cheesecake
Cakes, moist, e.g. fruit flan, cheesecake
1
Separate any defrosted parts when turning.
2
Freeze the food flat.
3
Remove any meat that has already defrosted.
4
Turn the food several times.
5
Separate any defrosted parts.
6
Carefully stir the food occasionally.
7
Remove all packaging.
8
Only defrost cakes without icing, whipped cream, gelatine or custard.
9
Separate the pieces of cake.
5
5
7
7
300 180 7–10
500 1. 180
2. 90
125 1. 180
2. 90
250 1. 180
2. 90
1. 8
2. 5–10
1. 1
2. 2–3
1. 1
2. 3–4
6
1. 6
2. 90
2. 5–10
1. 12
8, 9
8, 9
2. 90
500 90 10–15
750 1. 180
2. 90
8
500 1. 180
2. 90
8
750 1. 180
2. 90
2. 10–20
1. 5
2. 10–15
1. 5
2. 15–20
1. 7
2. 15–20
6
11.4 Heating
With your appliance you can heat food.
Heating food
WARNING‒Risk of burns!
Heated food gives off heat. The cookware may become
hot.
▶
Always use oven gloves to remove cookware or accessories from the cooking compartment.
WARNING‒Risk of scalding!
There is a possibility of delayed boiling when a liquid is
heated. This means that the liquid reaches boiling temperature without the usual steam bubbles rising to the
surface. Even if the container only vibrates a little, the
hot liquid may suddenly boil over and spatter.
▶
Always place a spoon in the container when heating
liquids. This will prevent delayed boiling.
ATTENTION!
Metal touching the wall of the cooking compartment
will cause sparks, which may damage the appliance or
the inner door pane.
▶
Metal (e.g. a spoon in a glass) must be kept at least
2cm from the cooking compartment walls and the
inside of the door.
1.
Take ready meals out of the packaging and place in
microwave-safe cookware.
2.
Distribute the food flat in the cookware.
3.
Cover the food with a suitable lid, a plate or special
microwave foil.
13
en How it works
4.
Start the operation.
5.
Turn or stir the food several times during cooking.
The speed at which different components of the
meal heat up may vary.
6.
Check the temperature.
7.
To even out the temperature, leave the heated food
to stand at room temperature for approx. 2–5
minutes.
Heating frozen food in the microwave
Observe the recommended settings for using the microwave to heat frozen food.
Food Weight ing Microwave power
setting inW
Set menu, plated meal, ready meal with 2–3
300–400 600 8–11
components
Soup 400 600 8–10
Stew 500 600 10–13
Slices or pieces of meat in sauce, e.g.
500 600 12–17
goulash
Bakes, e.g. lasagne, cannelloni 450 600 10–15
Side dishes, e.g. rice, pasta
Side dishes, e.g. rice, pasta
Vegetables, e.g. peas, broccoli, carrots
Vegetables, e.g. peas, broccoli, carrots
Creamed spinach
1
Separate the pieces of meat when stirring.
2
Add a little liquid to the food.
3
Pour water into the dish so that it covers the base.
4
Cook the food without any additional water.
4
2
2
3
3
250 600 2–5
500 600 8–10
300 600 8–10
600 600 14–17
450 600 11–16
Cooking time inmins
1
Heating in the microwave
Observe the recommended settings for using the microwave to heat food.
Food Amount Microwave power
setting inW
Beverages
Beverages
Baby food, e.g. baby bottles
Baby food, e.g. baby bottles
Baby food, e.g. baby bottles
1
1
4
4
4
200ml 800 2–3
500ml 800 3–4
50ml 360 Approx. 0.5
100ml 360 Approx. 1
200ml 360 1.5
Soup, 1 cup 200g 600 2–3
Soup, 2 cups 400g 600 4–5
Set menu, plated meal, ready meal with 2–3
350–500g 600 4–8
components
Meat in sauce
7
500g 600 8–11
Stew 400g 600 6–8
Stew 800g 600 8–11
Vegetables, 1 portion
Vegetables, 2 portions
1
Place a spoon in the glass.
2
Do not overheat alcoholic drinks.
3
Check the food occasionally.
4
Heat up baby food without the teat or lid.
5
Always shake the food well after heating.
6
Always check the temperature.
7
Separate the slices of meat.
8
Add a little liquid to the food.
8
8
150g 600 2–3
300 g 600 3–5
Cooking time inmins
2, 3
2, 3
5, 6
5, 6
5, 6
14
Installation instructions en
11.5 Test dishes
These overviews have been produced for test institutes to facilitate appliance testing in accordance with EN
60350-1:2013 or IEC 60350-1:2011 and EN 60705:2012, IEC 60705:2010.
Cooking with the microwave
Recommended settings for cooking with the microwave.
Food Microwave power
setting inW
Custard, 750g 1. 360
2. 90
Biscuit 600 8–10 Place a 22cm diameter Pyrex
Meat loaf 600 20–25 Place a Pyrex dish on the
Defrosting with the microwave
Recommended settings for using the microwave to defrost food.
Food Microwave power
setting inW
Meat 1. 180
2. 90
Cooking time inmins Note:
1. 12–17
2. 20–25
Cooking time inmins Note:
1. 5–7
2. 10–15
Place the Pyrex dish 20x25cm
on the turntable.
dish on the turntable.
turntable.
Place the Pyrex dish (22cm diameter) on the turntable.
12 Installation instructions
Observe this information when installing the appliance.
12.1 Safe installation
Follow these safety instructions when installing the appliance.
¡ The appliance can only be used safely if it
is correctly installed according to the safety
instructions. The installer is responsible for
ensuring that the appliance works perfectly
at its installation location.
¡ Check the appliance for damage after un-
packing it. Do not connect the appliance if
it has been damaged in transit.
¡ Before starting up the appliance, remove
any packaging material and adhesive film
from the cooking compartment and the
door.
¡ Never remove the transparent film on the
inside of the door.
¡ Proceed in accordance with the installation
sheets for installing accessories.
¡ Fitted units must be temperature-resistant
up to 90°C, and adjacent unit fronts up to
65°C.
¡ Do not install the appliance behind a decor-
ative door or the door of a kitchen unit.
There is a risk of overheating.
¡ Cut-out work on the units should be carried
out before installing the appliance. Remove
any shavings. Otherwise, the correct operation of electrical components may be adversely affected.
¡ Only a licensed professional may connect
appliances without plugs. Damage caused
by incorrect connection is not covered under the warranty.
WARNING‒Risk of injury!
Sharp-edged parts may be accessible during
installation.
▶
Wear protective gloves.
WARNING‒Risk of fire!
It is dangerous to use an extended power
cord and non-approved adapters.
▶
Do not use extension cables or multiple
socket strips.
15
en Installation instructions
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
12.2 Electrical connection
In order to safely connect the appliance electrically, follow these instructions.
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
▶
Only a qualified electrician may route the socket or
replace a power cable while taking into consideration the applicable regulations.
▶
Connect the appliance only to a correctly installed,
earthed socket.
▶
If the plug is no longer accessible following installation, an all-pole isolating unit with a contact clearance of at least 3mm must be available on the installation side. Contact protection must be ensured
by the installation.
12.3 Scope of delivery
After unpacking all parts, check for any damage in
transit and completeness of the delivery.
12.5 Installation dimensions in the upper cabinet
Observe the installation dimensions and the safety
clearances in an upper cabinet.
12.6 Preparing the upper cabinet
1.
Determine the wall thickness of the unit.
An x-value is assigned to the wall thickness.
2.
Note:The x-value corresponds to the distance
between the lower edge of the connection plate and
the bottom of the fitted unit.
Screw the connection plate tightly into the upper
unit.
When doing so, observe the x-value that was determined.
12.4 Fitted units
Here, you can find notes on safe installation.
ATTENTION!
Any shavings may impair the function of electrical components.
▶
Carry out cut-out work on the units before installing
the appliance.
▶
Remove the shavings.
¡ The minimum installation height is 850mm.
¡ The installation cabinet must not have a back panel
behind the appliance.
¡ The ventilation slots and intake openings must not
be covered.
¡ Fitted units must be heat-resistant up to 90°C, and
adjacent unit fronts up to 65°C.
16
12.7 Installation dimensions in the tall unit
Observe the installation dimensions and the safety
clearances in a tall unit.
12.8 Preparing the tall unit
1.
Determine the wall thickness of the unit.
An x-value is assigned to the wall thickness.
2.
Note:The x-value corresponds to the distance
between the lower edge of the connection plate and
the bottom of the fitted unit.
Screw the connection plate tightly to the tall unit.
When doing so, observe the x-value that was de-
termined.
Installation instructions en
3.
Screw the middle screw tightly on the base of the
microwave.
4.
Loosen the two outer screws on the microwave
base.
12.9 Preparing the appliance
If you install your appliance in a tall unit, you must prepare the appliance.
1.
Remove the middle screw on the base of the microwave.
2.
Remove the cover at the base of the microwave.
5.
Secure the built-in frame on the microwave base
with the two outer screws.
6.
Secure the four supporting feet to the base of the
microwave.
17
en Installation instructions
=
=
12.10 Installing the appliance
1.
Secure the spacers to the appliance in accordance
with the wall thickness.
2.
Note:
Do not trap or kink the power cable.
4.
Check the clearance to the adjacent appliances.
The clearance to the adjacent appliances must be
at least 3mm.
5.
Remove any packaging material and adhesive film
from the cooking compartment and the door.
Insert the appliance into the unit and move it to the
right.
3.
Screw the appliance in until the appliance is centrally aligned.
18
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001610731*
9001610731 (010203)
en
Loading...
