Bosch BEL634GS1B Instructions for Use
Microwave
BEL634GS1B, BER634GS1B
[en] Instruction manual
en
Table of contents
[en]Instruction manual
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 19
( Important safety information . . . . . . . . . . . . . . . 4
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 7
7 Environmental protection . . . . . . . . . . . . . . . . . . 7
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 7
* Getting to know your appliance . . . . . . . . . . . . . 8
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Cooking compartment functions . . . . . . . . . . . . . . . . . 9
_ Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
K Before using for the first time. . . . . . . . . . . . . . 10
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning the cooking compartment and accessories 10
1 Operating the appliance . . . . . . . . . . . . . . . . . . 11
Switching the appliance on and off . . . . . . . . . . . . . . 11
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Selecting an operating mode . . . . . . . . . . . . . . . . . . . 11
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 20
E number and FD number . . . . . . . . . . . . . . . . . . . . .20
Technical specifications . . . . . . . . . . . . . . . . . . . . . . .20
J Tested for you in our cooking studio . . . . . . . . 21
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Defrosting, heating up or cooking frozen food . . . . . .22
Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Microwave tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Combined grill and microwave . . . . . . . . . . . . . . . . . .24
E Test dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cooking only using the microwave. . . . . . . . . . . . . . .25
Defrosting only using the microwave . . . . . . . . . . . . .25
Cooking with the microwave and grill. . . . . . . . . . . . .25
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com
^ Microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cookware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Microwave power settings . . . . . . . . . . . . . . . . . . . . . 12
Setting the microwave . . . . . . . . . . . . . . . . . . . . . . . . 12
d Grilling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting the grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting the microwave to combi-mode . . . . . . . . . . . . 14
O Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
P Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting a programme . . . . . . . . . . . . . . . . . . . . . . . . . 15
Information on the programmes. . . . . . . . . . . . . . . . . 16
Resting time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programme table . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the basic settings. . . . . . . . . . . . . . . . . . . . 17
List of basic settings . . . . . . . . . . . . . . . . . . . . . . . . . 17
Power cut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3
en Intended use
8Intended use
Intended use
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 8 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~ "Accessories" on page 10
(Important safety
information
Important safety information
General information
:Warning
Risk of fire!
Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance door
if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
:Warning
Risk of burns!
■ The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning
Risk of scalding!
■ The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot
steam may escape. Open the appliance
door with care. Keep children at a safe
distance.
Risk of scalding!
■ Water in a hot cooking compartment may
create hot steam. Never pour water into the
hot cooking compartment.
:Warning
Risk of injury!
■ Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■ The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
4
Important safety information en
:Warning
Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the aftersales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning
Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
Microwave
:Warning
Risk of fire!
■ Using the appliance for anything other than
its intended purpose is dangerous and may
cause damage.
The following is not permitted: drying out
food or clothing, heating slippers, grain or
cereal pillows, sponges, damp cleaning
cloths or similar.
For example, heated slippers and grain or
cereal pillows may catch fire, even several
hours after they have been heated.The
appliance must only be used for the
preparation of food and drinks.
Risk of fire!
■ Food may catch fire. Never heat food in
heat-retaining packages.
Do not leave food heating unattended in
containers made of plastic, paper or other
combustible materials.
Do not select a microwave power or time
setting that is higher than necessary. Follow
the information provided in this instruction
manual.
Never use the microwave to dry food.
Never defrost or heat food with a low water
content, e.g. bread, at too high a microwave
power or for too long.
Risk of fire!
■ Cooking oil may catch fire. Never use the
microwave to heat cooking oil on its own.
:Warning
Risk of explosion!
Liquids and other food may explode when in
containers that have been tightly sealed.
Never heat liquids or other food in containers
that have been tightly sealed.
:Warning
Risk of burns!
■ Foods with peel or skin may burst or
explode during, or even after, heating.
Never cook eggs in their shells or reheat
hard-boiled eggs. Never cook shellfish or
crustaceans. Always prick the yolk when
baking or poaching eggs. The skin of foods
that have a peel or skin, such as apples,
tomatoes, potatoes and sausages, may
burst. Before heating, prick the peel or skin.
Risk of burns!
■ Heat is not distributed evenly through baby
food. Never heat baby food in closed
containers. Always remove the lid or teat.
Stir or shake well after the food has been
heated. Check the temperature of the food
before it is given to the child.
Risk of burns!
■ Heated food gives off heat. The ovenware
may become hot. Always use oven gloves
to remove ovenware or accessories from
the cooking compartment.
Risk of burns!
■ Airtight packaging may burst when food is
heated. Always observe the instructions on
the packaging. Always use oven gloves to
remove dishes from the cooking
compartment.
5
en Important safety information
:Warning
Risk of scalding!
■ There is a possibility of delayed boiling
when a liquid is heated. This means that the
liquid reaches boiling temperature without
the usual steam bubbles rising to the
surface. Even if the container only vibrates a
little, the hot liquid may suddenly boil over
and spatter. When heating, always place a
spoon in the container. This will prevent
delayed boiling.
Risk of serious damage to health!
■ Microwave energy may escape if the
cooking compartment door or the door seal
is damaged. Never use the appliance if the
cooking compartment door or the door seal
is damaged. Contact the after-sales service.
Risk of serious damage to health!
■ Microwave energy will escape from
appliances that do not have any casing.
Never remove the casing. For any
maintenance or repair work, contact the
after-sales service.
:Warning
Risk of injury!
■ Unsuitable ovenware may crack. Porcelain
or ceramic ovenware can have small
perforations in the handles or lids. These
perforations conceal a cavity below. Any
moisture that penetrates this cavity could
cause the ovenware to crack. Only use
microwave-safe ovenware.
Risk of injury!
■ If using the appliance in microwave mode
only, placing cookware and containers
made of metal inside the appliance may
cause sparks when the appliance is
operating. This will damage the appliance.
Never use metal containers when using the
appliance in microwave mode only.Use only
microwave-safe cookware or, alternatively,
the microwave in combination with a type of
heating.
:Warning
Risk of electric shock!
The appliance is a high-voltage appliance.
Never remove the casing.
:Warning
Risk of serious damage to health!
■ The surface of the appliance may become
damaged if it is not cleaned properly.
Microwave energy may escape. Clean the
appliance on a regular basis, and remove
any food residue immediately. Always keep
the cooking compartment, door seal, door
and door stop clean. ~ "Cleaning"
on page 18
6
Causes of damage en
]Causes of damage
Causes of damage
Caution!
■ Creation of sparks: Metal – e.g. a spoon in a glass –
must be kept at least 2 cm from the cooking
compartment walls and the inside of the door.
Sparks can irreparably damage the glass on the
inside of the door.
■ Foil containers: Do not use foil containers in the
appliance. They damage the appliance by producing
sparks.
■ Operating the microwave without food: Operating the
appliance without food in the cooking compartment
may lead to overloading. Never switch on the
microwave unless there is food inside. The short
crockery test is the exception to this rule.
~ "Microwave" on page 12
■ Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■ Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■ Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean.
~ "Cleaning" on page 18
■ Microwave popcorn: Never set the microwave output
too high. Use a maximum microwave output of 600
watts. Always place the popcorn bag on a glass
plate. The door panels may jump if overloaded.
7Environmental protection
Environmental protection
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
7
en Getting to know your appliance
*Getting to know your
appliance
Getting to know your appliance
In this chapter, we will explain the displays and controls.
You will also find out about the various functions of your
appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
RQ
RII
( Buttons
The buttons on the left- and right-hand side of the
control panel have a pressure point. Press these
buttons to activate them.
For appliances that do not have a stainless steel
front, these two button touch fields do not have a
pressure point.
0 Touch fields
There are sensors under the touch fields. Simply
touch the respective symbol to select the function.
8 Rotary selector
The rotary selector is fitted so that you can turn it
indefinitely to the left or right. Press it lightly and
move it in the direction required using your finger.
@ Display
You can see the current adjustment values,
options or notes in the display.
Controls
The individual controls are adapted for the various
functions of your appliance. You can set your appliance
simply and directly.
Buttons and touch fields
Here you can find a short explanation of the various
buttons and touch fields.
Symbol Meaning
Buttons
ÿ on/off Switching the appliance on and
l start/stop Starting or stopping an operation
off
Control panel
In the control panel, you can use the various buttons,
touch fields and the rotary selector to set the required
function of the appliance. The current settings are
shown in the display.
The overview shows the control panel when the
appliance is switched on with a selected operating
mode.
+HL]DUWHQ
:
[
PV
#
Touch fields
90 Microwave output Selects 90 watts
180 Microwave output Selects 180 watts
360 Microwave output Selects 360 watts
600 Microwave output Selects 600 watts
900 Microwave output Selects 900 watts
( Grilling/combi-mode Selects the grill setting or grill set-
s Time-setting options Select time-setting options
% Programmes Selects a programme
a Weight Selects the weight in the pro-
° Information Display notes
v Automatic door opening Opens the appliance door
--------
The touch field, which has a value on the display that
can be changed or displayed in the foreground, lights
up red.
Rotary selector
You use the rotary selector to change the adjustment
values shown in the display.
In most selection lists, e.g. programmes, the first
selection follows the last.
In some selection lists, e.g. duration, you have to turn
the rotary selector back the other way when you reach
the minimum or maximum value.
VWDUW
VWRS
ting with microwave output
gramme
Hold down (approx. 3 secs) to call
up the basic settings
8
Getting to know your appliance en
Display
The display is structured so that the information can be
read at a glance in any situation.
The value that you can currently set is in focus. It is
displayed in white lettering and underlined. The value in
the background is displayed in grey.
Focus The value in focus can be changed directly with-
out first being selected.
After starting an operation, the cooking time is
always in focus.
Emphasis As you change the value in focus using the rotary
selector, only this value is displayed larger.
+HL]DUWHQ
J
:HLJKW
+HL]DUWHQ
P
Î:
V
Display ring
The display ring can be found around the outside of the
display.
If you change a value, the display ring shows you where
you are in the selection list. Depending on the settings
area and length of the selection list, the display ring
may be continuous or divided into segments.
As the cooking time counts down, one red segment
disappears each second. After each full minute, all
segments light up red again.
Further information
Notes
■ If you open the appliance door during operation, the
operation is paused.
■ When you close the appliance door, the operation
does not continue automatically. You must restart
the operation manually.
■ If the appliance has been switched off for a long
time, the appliance door will open after a time delay.
Interior lighting
When you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
around five minutes, the cooking compartment lighting
switches off again. When the automatic door opening is
activated, the cooking compartment lighting switches
on again.
For all operating modes, the cooking compartment
lighting switches on as soon as the operation is started.
When the operation has finished, the lighting switches
off.
Cooling fan
The cooling fan switches on as required. The hot air
escapes above the door.
The cooling fan may continue to run for a certain time
after the operation.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
Notes
■ The appliance remains cool during microwave
operation. Despite this, the cooling fan will still
switch on. The fan may run on even when the
microwave operation has ended.
■ Condensation may form on the door window, interior
walls and floor. This is normal and does not
adversely affect microwave operation. Wipe away the
condensation after cooking.
In most cases, the appliance provides notes and further
information on the action just carried out.
Touch the ° field. The note is shown in the display for a
few seconds. Use the rotary selector to scroll to the end
of longer notes.
Some notes are displayed automatically, for example as
confirmation, or to provide an instruction or warning.
Cooking compartment functions
The functions in the cooking compartment make your
appliance easier to use. This, for example, enables the
cooking compartment to be well lit and a cooling fan to
prevent the appliance from overheating.
Automatic door opening
The appliance door springs open if you activate the
automatic door opening. You can fully open the
appliance door manually.
The automatic door opening does not work in the event
of a power cut. You can open the door manually.
9
