BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
PREMIUM, Electric deep fat fryer, FR15
P075375: Single tank P075376: Twin tank
GENERAL FEATURES
* Upper section one-piece 3mm thick stainless steel (top and flush welded sides) allows edge-to-edge assembly and extraordinary strength.
* Designed to eliminate any infiltration and constructed of stainless steel throughout.
* End panels in 30/10 provide exceptional strength and allows virtually flush assembly.
* Chromed cast brass controls recessed to provide protection against impacts or spillages.
* Integral adjustable wall attachment system.
* Available on (See specific technical documentations):
- Fixed stand height 630 mm, with 4 adjustable feet and an undershelf.
- Mobile frame height 630 mm, with 4 casters, 2 with brakes and an undershelf.
- Refrigerated base on legs.
DEEP FAT FRYER 15
* The FR 15 Electric deep fat fryer comprises a self-contained well with a nominal capacity of 13 litres with cool zone in 500 mm wide and two such
self-contained wells in 750 mm wide.
* Fitted with low power density armoured elements to ensure long service life of the oil.
* The hinged bank of elements has a handle and locks in the vertical position for cleaning. Heating is cut-off when elements are raised.
* It is fitted with an electronic temperature control from 140°C to 185°C with automatic liquefaction of solid oils, complete with high temperature
safety shut off (positive) at 210°C and safety light ensuring operation in absolute safety.
* An indicator shows that oil has reached its requisite temperature.
* Well drainage is by means of a ball valve with its control located on the facia.
* Supplied with one or two removable lid.
* Designed to conform to all hygiene and safety standards.
* Delivered with 1 basket 280 x 240 x 130 per tank.
POSSIBLE OTHER EQUIPMENT
* Drain pan.
* Filter for drain pan.
* Supplementary basket FR215 or 2 half-baskets FR15.
* Independent filtration trolley.
STANDARD
EN 60335-2-37: European standard for the safety of electric appliances.
(French standard: C 73-837).
IP 25 and IK 9: Protection rating.
NF X 60-010: Hygiene.
: Complies with
ELECTRICAL connection
(Leave 1.5 m cable tails)
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
P075375 P075376
MODEL
DIMENSIONS (mm)
B-D9P.FR15SC B-D9P.FR15DC
Height 393 393
Width 500 750
Depth 950 950
Basket 280 x 240 x 130 280 x 240 x 130
CAPACITIES
Tank (litres) 13 2 x 13
Basket (kg) 1.5 2 x 1.5
PACKAGING (mm)
Height 500 500
Width 600 850
Depth 1050 1050
WEIGHT (KG)
35 60
ELECTRICITY (Three phase 230V+E or 400V+N+E)
Power (kW) 230V 3a.c. 12 400V 3Na.c. 12 24
Intensity max (A) 230V 3a.c. 30.1 400V 3Na.c. 17.3 34.8
HOURLY PRODUCTION (kg/h)
Frozen chips to NFD 40002 25 50
Frozen chips 6x6 (Practical production) 36 72
Precooked chips 2°C (Practical production) 45 90
Blanching fresh chips to NFD 32725 30 60
Finishing fresh chips 45 90
OPERATING TEMPETRATURE
OPERATING SAFETY
APPLIANCE OF TYPE
Free standing (against a wall or other appliance)
140 to 185°C
210°C
ELECTRICAL CONNECTION
680 mm from floor
Non contractual document Edition 06/2004 – 3BE0238
