Z9 USER GUIDE
Introduction
The BlueAnt Z9 Dual Microphone portable mono headset utilizes Bluetooth Wireless
Technology. Its dual microphones combined with the BlueAnt Voice Isolation Technology™
software, provide the BlueAnt Z9 with revolutionary clear and clean voice input enabling high
quality voice communications. Winner of the prestigious CES 2007 Design and Engineering
award, the BlueAnt Z9 is the next generation in Noise Suppression, Echo Cancellation and
Wind Noise Reduction for Bluetooth headsets.
There are two settings of Voice Isolation - STANDARD and MAX.
Voice Isolation Standard is for use in normal environments and gives you a natural
sounding voice removing mild noise.
Voice Isolation Max gives you superior voice clarity in a wide variety of high noise areas.
ENGLISH
Features of the BlueAnt Z9
• Winner of CES 2007 Innovations Design & Engineering Award
• Two microphones for pure speech
• Voice Isolation Technology ™ BlueAnt’s revolutionary Digital Signal
Processor (DSP) software
• During a call, users can switch between two Voice Isolation modes –
Standard and Max
• This world class DSP provides echo suppression, noise reduction and wind
noise reduction which separates the desired voice signal from background
noise enabling crystal clear conversation in even the noisiest of environments
• Incorporates ‘On-the-Fly’ phone switching with up to 3 paired devices
• Automatic connection & reconnection notification
• Different ringtones for known and unknown contacts
• Innovative tie clip for attaching to shirt or cuff, when not in use
• Small & lightweight (1.5” in length & weighs only 0.35 oz) (41mm &10grams)
• Stylish, translucent ear hook
• Up to 5.5 hrs talk-time or 200 hrs standby
• 2 Year Replacement Warranty
• Bluetooth v2.0
What is Bluetooth wireless technology?
Bluetooth is the most advanced cable-replacement technology available today. It enables
effortless wireless connections between your Bluetooth devices within a range of up to 10m
(30 ft).
What devices work with the Z9 Dual Microphone?
Your headset is a Bluetooth V2.0 qualified product and supports both the Headset and
Handsfree Bluetooth profiles. The Z9 can store information and wirelessly interact with up to
three different Bluetooth V1.1, V1.2 or V2.0 com pli ant devices (backward and forward
compatible), including mobile phones, PDA’s, PC’s / Mac’s or any Bluetooth enabled device
that supports Headset profile or Handsfree profile. This manual focuses on how to use
your headset with your Bluetooth enabled phone.
What’s in the Package?
A BlueAnt Z9 Dual Microphone Bluetooth Headset
>
> 3 x Translucent Ear hooks
> USB Cable
> AC Adaptor
> Quick Start Guide
> User Manual
> Warranty Card
ENGLISH
Overview
Getting Started
Before you can use your headset, you mu st do th e foll ow ing two th ing s:
1. Fully charge your headset usin g one of the ch arger s prov ided .
2. Pair your headset with a Bluetooth enabled device, e.g. Cell phone, PDA, Computer
Charging
Your Z9 comes with a built-in rechargeable battery. For first time use, you must fully charge
your Z9. During charging, the indicator shows a steady Red light. When the battery is fully
charged, the Red light will turn off. It takes 120-150 minutes to fully charge the battery. The
more you talk using your headset, the less standb y time your battery has. Your headset will
require longer charging times when not used over extended periods of time.
ENGLISH
Charging the Z9 with the USB connecter
1. Plug the USB charging cable into the PC/Mac's USB port
2. Plug the other end of the USB charging cable into the charging port of your headset.
Make sure the USB plug mat c he s up t o the USB socket on the headset. Do not force the
plug into the socket, it should slide in easily. The Red LED will turn ON.
3. When charging is complete the Red LED will turn OFF. Remove the charging
adapter.
Charging the Z9 with the Wall Char ge r
1. Plug the AC Charger into a power socket and the cable into the charging port on the Z9.
Make sure the USB plug mat c he s up t o the USB socket on the headset. Do not force the
plug into the socket it should slide in easily. The Red LED will turn ON.
2.
When charging is complete the Red LED will turn OFF. Remove the charging
adapter.
Wearing the BlueAnt Z9
Push the ear hook through the ear hook hole which sits on
the headset clip and adjust its length to fit comfortably on
your ear. Ensure that the h ead se t i s po i nt in g towa rd s y ou r
mouth. You can wear the Z9 on left or right ears.
For optimal performance of the Z9
headset, angle the headset so that
it points towards your m out h.
ENGLISH
Pairing
Before use, you must pai r the h ead set with your cell phone. Pairing will create a s tor ed
connection in both the Z9 and your Bluetooth cell phone. Pairing need only be done once,
when first connecting to a new phone. Th e Z9 can s tore pa ir ing i nform atio n for up to three (3)
different Bluetooth dev ic e s. If you wish to pair anot he r d i fferent device once 3 devi ces are
paired, you will need to RESET the Z9 as p er t he instru ction s in B asic He ad se t Fun ction s
below.
Pairing Procedure
This is an example only a nd ma y differ from your phone, b ut t he process will be the same.
1. First turn the phone OFF and then back ON again to refres h its memo ry.
2. Bring the mobile phon e to about 30cm from the Z 9 D ua l M i cro phone.
3. Find the Bluetooth menu in your mobile phone. Turn Bluetooth ON. (Check your mobile
phone user guide if necessary)
4.
With the Z9 OFF, Press and Hold the MFB for about 6 seconds. The LED will appear
a solid Blue, and then will start flashing. The Z9 is now in Pairing mode and ready to be
found in searches by other Bluetooth devices. Pairing mode will be active for 2 minutes.
Pairing Procedure (continued)
5. Perform a Bluetooth device discovery on your mobile phone to add a new device. (It
takes a few seconds to search for and f ind oth er B lueto oth de vices aroun d you) .
6. When Bluetooth device s are found, the phone wil l di sp l ay "BlueAnt Z9". Scroll to it and
press OK to confirm that you want to Pair with it.
7. Enter Passkey "0000" when you r phone prompts you. The phone and Z9 will now Pair.
8. An additional security setting in your phone may be needed to allow the headset and
phone to connect automatically without confirmation each time you connect your Z9.
Generally in the options for t he Bl ueAn t Z9 , i t will be referred to as "se t a s au th or i zed " ,
"add to trusted devices", ‘’allow connection’’ or similar.
9. If required for first time connection, select the BlueAnt Z9 to connect with your phone.
OR, Click the MFB o n the Z9, to connect with th e phone.
ENGLISH
Basic Headset Functions
For easy reference, also see the Button/Function Matrix and the Quick Start Guide.
1. Power ON: Press and Hold the MFB for 3 seconds. The solid Blue LED will light up, and
if the battery has ample charge the Blue LED will stay on for up to 5 Seconds. If the battery is
low a solid Red LED will be displayed. After powering ON, your headset will automatically
connect to your last used phone if it is in operating range. If this phone is not range, the Z9
will enter idle mode after 60 seconds. If no phone has yet been Paired, the Z9 will enter into
Pairing mode.
2. Power OFF: Press and Hold the MFB for 3 seconds. The Red LED flashes three times.
3. Enter Pairing Mode: With the Z9 OFF, Press and Hold the MFB for about 6 seconds
until the LED flashes Blue. The Z9 will stay in pairing mode for 2 minutes then will go into idle
mode. To re-enter pairing mode, repeat this step. If you had already paired 3 devices and
want to pair again, you will need to RESET the Z9 to enter pairing mode.
4. Make a Call: Dial the number using your phone as normal. Audio will automatically transfer
to the headset.
Basic Headset Functions (continued)
5. To Answer or End a call: Click the MFB once when there is an incoming call. Press
and Hold the MFB for 3 seconds to end the call.
6. Reject*: a call: Press and Hold the MFB for 3 seconds when there is an incoming call.
7. Redial*: the last call, Press and Hold the Volume Button for about 3 seconds. To cancel
Redial, click the MFB
8. Activate Voice Dialing*: While connected to a phone, Press the MFB once. Voice
commands must have been previously recorded into your phone (see your phones user guide
for specific instructions).
9. Volume level: Click Volume or Volume during a call to adjust the desired level.
Volume changes will be remembered for the next call. Be sure to use the headset at a
comfortable and safe volume level.
ENGLISH
Basic Headset Functions (continued)
10. Disconnect / Transfer: To disconnect the Z9 with the currently connect phone Click
Volume and Volume together once. This will also transfer an ongoing call to the phone.
11. Reconnect: To reconnect your phone to the Z9, simply turn the Z9 ON. Or with the Z9
ON simply press the MFB . Alternatively, you can use the menu of your Bluetooth phone.
12. Mute/Unmute the microphone. Press and Ho ld Volume for 3 seconds during a call.
13. Call Waiting*: While on a call and another incoming call appears, (beep tones dependent
on your network) Press and Hold Volume and Volume together for 3 seconds. The
current call will be placed on Hold and the incoming call will be answered. To return to the
held call, Click Volume and Volume together again for 3 seconds.
Basic Headset Functions (continued)
14. Call Conference*: To add a held call to the cur re nt conversation, Press and Hold
Volume for 3 se conds
15. Disable/Enable the LED indicators: (for night time driving): When yo ur headset is in idle
or standby mode Press and Hold Volume and Volume together for 3 seconds. After
turning the headset OFF and back ON, the LED Indicators will be active again by default.
Note the LED’s are turned OFF while a call is active.
16. Z9 Reset: If you have already Paired 3 devices to the Z9 it is not possible to pair another
as the memory is full. If you want to pair with another phone you must reset the headset.
To reset the Z9 to factory settings; while in idle mode (not connected to any device), Click
Volume, Volume and MFB together (3 buttons). The Z9 will refresh its memory,
delete all current pairing information and automatically go into Pairing mode (LED will flash
Blue) ready to pair with a new device.
* To use these functions, your phone/device must support the Bluetooth Handsfree Profile.
The Bluetooth Headset profile will not activate these features of the BlueAnt Z9.
ENGLISH
T
BlueAnt Voice Isolation Technology™
You can switch between two settings of Voice Isolation - STANDARD and MAX.
Voice Isolation Standard - For use in normal everyday environments and gives you a
Voice Isolation Max - Gives you more intelligible voice in a wide variety of high
HOW DO I SWITCH?
o switch between Standard and Max: Click the MFB while on a call
• When switching between Standard and Max you will hear a confirmation voice tag
played from the Z9 speaker.
• When you first turn the headset ON, it will be in the Standard setting.
• After switching the headset OFF and back ON, the headset will return to the
Standard setting by default.
• Standard and Max both use the same amount of battery power.
natural sounding voice while removing mild noise.
noise environments.
Button Function
Matrix
Note:
Standby Mode
means connected
to a device but
not on a call.
Idle Mode
means the Z9
is ON but not
connected to any
device
Multiple
button presses
mean click
together
Z9 Function Button Time Status
Power ON
Power OFF
Enter Pairing Mode
Connect to Device 1
Connect to Device 2
Connect to Device 3
Answer Call
End Call
Reject Call
Redial Last Number
Voice Dial Activate
Disconnect/ Transfer
Call Conference
Call Waiting
Volume Up
Volume Down
Mute
Turn LED’s OFF/ON
Switch Voice Isolation
between Standard and Max
Reset Device
MFB
MFB
MFB
MFB
MFB
MFB
MFB
MFB
MFB
Vol
MFB
&
Vol
&
Vol
Vol
Vol
&
MFB
MFB & &
3 Seconds From OFF
3 Seconds Idle/Standby
6 Seconds From OFF
One Click Idle
Two Clicks Idle
Three Clicks Idle
Click Ringing
3 Seconds Active Call
3 Seconds Ringing
3 Seconds Standby
Click Standby
Click Connected
3 Seconds Active Call
3 Seconds Active Call
Click Active Call
Click Active Call
3 Seconds Active Call
3 Seconds Idle/Standby
Click Active Call
Click Idle
ENGLISH
LED Indicator Chart
Power ON Solid Blue for 5 Seconds
Power OFF Red flash 3 times
Pairing Mode Blue flashing
Reset Blue flashing
Charging Solid Red
Charging with Power ON Solid Red with a Purple Flash
Charging Complete Red indicator OFF
Low Battery All LED’s change to Red
Idle Blue flash every 8 seconds
Standby 2 Blue flashes every 5 seconds
Ongoing call NO LED’s
Advanced Headset Functions
Pairing your headset with multiple Bluetooth devices
The Z9 will connect to only one device at a time but 3 devices can be paired to it.
1. Make sure the last phone used has Bluetooth switched off or is out of range.
2. Follow the procedure in ‘Pairing Procedure’ above for each device you want to pair.
On-the-Fly Phone Switching
After pairing a 2nd or 3rd mobile, Smartphone, PDA or comput er as pe r the pai ring procedure,
you can switch between the devices using the following procedure.
Selecting the required mobile phone
1. Disconnect from the currently connected phone: Click Vol
2. Connect to any of the three paired devices on request by clicking the MFB
Once for the first paired phone
Twice for the second paired phone
Three times for the third paired phone
Note: Be sure to remember in what order the 3 devices have been paired.
and Vol
together.
ENGLISH
Firmware upgrade
The BlueAnt Z9 is firmware upgradeable via the USB port and provided USB cable.
Please see the support section at www.blueantwireless.com for information and downlo ads
for available upgrades.
Further Information
Setting up a Phone Profile (different to Bluetooth Profiles)
In your phone, set up a Profile with appropriate ringing volumes and keypad tones and select
and activate when using with the Z9. Some phones can automatically activate a desired
profile when connecting to a Car Kit or Headset Accessory. E.g. Go to Enhancement Settings
and select a Default Profile to activate when the headset connects. With some phones you
can also personalize levels to make suitable for yourself (see your phone’s user manual for
instructions on using and activating Phone Profiles). Typical phone Profiles are General,
Outdoor, Meeting, Silent, Handsfree, Headset, Portable handsfree and Carkit.
Phone/PDA/Computer Software
Please make sure you have the latest firmware upgrade for your phone especially if you are
using a PDA Phone. Go to the support section of the manufacturers’ website to check that
you have the latest version. Many new mobile phones, PDA’s and computer phones require a
Bluetooth patch to improve Bluetooth functionality from the original released version.
Resetting Your Phone/PDA
Phones and PDA’s can become prone to software and memory issues which may cause
Bluetooth reconnection problems. This can be fixed simply by turning the phone OFF and
back ON again. The phone will be reset and the working memory cleared.
Resetting your phone weekly can help maintain it’s functionality including Bluetooth.
Troubleshooting and Support Documents
See the support section of www.blueantwireless.com
Asked Questions (FAQ) as well as info on using with computers for VOIP application\s.
for troubleshooting and Frequently
ENGLISH
Specifications
General
Specification
RF Spec. z Carrier Frequency 2.402 ~ 2.480GHz
User Interface z Blue color LED for operation indication.
Audio 3GPP with DSP solution
Battery type 3.7V Lithium Polymer battery
Talk Time Up to 5.5 Hours
Stand-By time 200hrs.
Weight 0.35 oz / 10 grams without ear hook or 11 grams with ear-hook
Dimensions 1.5 x 0.69 x 0.44 (inches) / 41 x 17.5 x 11.2 (mm)
z Bluetooth v2.0
z Up to 10 meters RF coverage
z CE,FCC,BQB, Ctick, RoHS / WEEE Compliant
z Headset Profile, Hands-Free profile
z < 0.1% BER at -80 dBm
z 0 ± 4 dBm (Class 2)
z Red color LED for low battery indication.
z Mini USB for Charging battery or F/W upgrade
p
Hel
BlueAnt Warranty Process
1. Should you be having difficulties in operation please refer to the online FAQ and support
documents, or call us. Our number is on the back page of th is manual
2. Check our website for more information, updated manuals and troubleshooting.
www.blueantwireless.com
3. Call us and speak to one of the BlueAnt Wireless Customer Service Team
We will clarify whether you have a hardware or connection issue.
4. If your unit is confirmed to be faulty, a Return Merchandise Authorization (RMA) will be
issued.
5. Return the unit directly to BlueAnt for testing and replacement of faulty items.
Warranty Terms and Conditions
1. BlueAnt Warrant the original purchaser of this product only.
2. BlueAnt will replace or repair any faulty product provided it has not
been misused or abused in any way.
3. There are no user serviceable parts inside this product. Using a nonauthorized repairer will void the warranty.
4. The Warranty is valid for 2 years (24 months) from the date of purchase.
• Proof of purchase must be provided to obtain warranty service.
• Headset must be in original packaging with serial number for warranty to be valid.
ENGLISH
5. Warranties are effective from the proof of purchase date and not from the date of any
subsequent repair or rep lacement.
Disclaimers:
This manual is published by BlueAnt. The information contained in this document is subject to
change without notice. All rights reserved. The Bluetooth word, mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks by BlueAnt is under license. Other
trademarks and trade names are those of their respective owners.
Please protect your ears.
Warning: This headset can reach a maximum volume of 101 decibels. Prolonged use of a
headset at high volumes may affect your hearing capacity. Using for extensive time periods
may result in noise induced hearing loss (NIHL). Hearing loss may occur if the headset is
used at maximum volumes for more than 5 minutes per day. Hearing loss may occur if the
headset is used at medium volumes if used for more than 1 hour per day. Exposure to sound
at such a close range may result in hearing loss, even at low lev els. Do not listen at high
volume levels. Remember that your ears will adapt to the volume level set and if you change
to higher levels your ear may feel no discomfort but may be doing damage to your ear.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
This equipment is in compliance with the essential requirements and other relevant provisions of Direc tive 1999/5/EC
(Applicable in the European Union and other European countries with separate collection)
This marking shown on the product or its literature, indicates that it should not be disposed with
other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material
resources. Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they can take this item for
environmentally safe recycling. Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product should not be mixed with other
commercial wastes for disposal.
FCC Notices
This device contains FCC ID: VHFBLUEANTZ9 which complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) Thi s device must acc ept any inter ference recei ved, includin g interferen ce that
may cause undesired operation.
FCC RF Exposure requirements:
“This device and its antenna(s) must not be co-located or operating in conjunction with any other
”
ENGLISH
GUIDE DE L’UTILISATEUR
de BlueAnt Z9
Aperçu du produit
BlueAnt Z9 est une oreillette à deux microphones dotée de la technologie sans fil Bluetooth. Profitant de
BlueAnt Voice Isolation Technology™, logiciel de synthèse réputé pour sa clarté cristalline, le double
microphone révolutionne la saisie vocale et accroît les performances acoustiques de BlueAnt Z9 lors des
communications orales en temps réel. BlueAnt Z9 est lauréat du prix « CES Design and Engineering »; ce
prix prestigieux contribue à en faire la prochaine génération des micros-casques Bluetooth à grandes
capacités antibruit.
L’isolation vocale se fait en deux modes : STANDARD et MAX.
Isolation vocale Standard : Ce mode s’utilise en milieu ordinaire de tous les jours, maintient le
Isolation vocale MAX : Ce mode rend votre voix plus audible dans divers milieux très
bruyants.
naturel de votre voix tout en supprimant les faibles bruits
ambiants.
FRENCH
Caractéristiques de BlueAnt Z9
• Prix CES Innovations Design & Engineering 2007
• Deux microphones pour une saisie vocale intelligible et naturelle
• Voice Isolation Technology ™ issue de Digital Signal Processor (DSP), logiciel de
synthèse révolutionnaire de BlueAnt
• Alternance possible entre deux modes d’isolation vocale – Standard et Max – au cours
d’un appel
• DSP de première qualité et ultraperformant : suppression d’échos, réduction de bruits, y
compris le bruit caractéristique du vent et conversation d’une clarté cristalline, même
dans un milieu très bruyant, grâce à une meilleure isolation des signaux vocaux et des
bruits de fond
• Communication téléphonique à la volée avec possibilité de connecter jusqu’à trois des
appareils jumelés
• Témoin de connexion et de reconnexion automatique
• Sonnerie différente selon les correspondants, connus et inconnus
• Prise casque innovante pour une fixation (hors usage) à la chemise ou à la boutonnière
• Poids et taille réduits (3,8 cm de longueur pour un poids de 11 g seulement)
• Crochet auriculaire translucide et élégant
• Autonomie de conversation/veille : 5,5 h/200 h
• Garantie de pièce de rechange de 2 ans
• Bluetooth 2.0
Technologie sans fil Bluetooth
Bluetooth est la technologie sans fil la plus évoluée aujourd’hui sur le marché. Elle assure
facilement la liaiso n en tre vo s appareils Bluetooth dans un rayon de 10 mètres (30 p ie ds ).
Appareils compatibles avec le microphone mixte Z9
Votre micro-casque est validé Bluetooth 2.0 et gère les profils casque et mains libres.
L’oreillette Z9 peut stocker de l’information et se connecter sans fil à trois appareils
homologués Bluetooth 1.1, 1.2 ou 2.0 (compatibilité descendante et ascendante), y compris
les téléphones mobiles et les ANP (assistant numérique personnel), sous PC ou Mac, ou tout
autre appareil adapté à Bluetooth et prenant en charge les profils casque et mains libres. Le
présent guide vous montre comment utiliser votre oreillette de concert avec votre
téléphone validé Bluetooth.
Contenu de l’emballage
> 1 oreillette Bluetooth à microphone mixte BlueAnt Z9
> 3 crochets auriculaires translucides
> Câble de connexion USB
> Adaptateur CA
> Guide de démarrage rapide
> Guide de l’utilisateur
> Carte de garantie
FRENCH
A
Présentation
MFB (Bouton
Multifonction)
Baisse de
Volume
ugmentation
de volume
Crochet auriculaire
USB
Haut-parleur
Loading...
