GBF-5P, GBF-10, AND GBF-20SC
DESMON BLAST CHILLER/FLASH FREEZERS
REPLACEMENT PARTS LIST
EFFECTIVE FEBRUARY 9, 2016
Superseding All Previous Parts Lists.
The Company reserves the right to make substitution in the event that items speciîżed are not available.
ERRORS: Descriptive and/or typographic errors are subject to correction.
44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone: (802) 658-6600 Fax: (802) 860-3732
BLODGETT OVEN COMPANY
www.blodgett.com
P/N 80100 Rev A
24 19
20
GBF-5P
21
13
30
31
28
27
22
26
23
24
25
5
4
6
3
2
11
10
9
8
2
36
12
12
47
47
7
18
49
3
39
42
1
48
41
37
36
1
38
36
50
36
16
46
44
35
40
45
15
29
34
17
32
33
43
FEBRUARY 9, 2016 2 BLAST CHILLER/SHOCK FREEZERS
Ref.
Part
No.
No.
1 80027 FRONT PANEL GBF-5 (NO KEYBOARD,
2 80029 DOOR ASSY GBF-5 TS RIGHT HAND
2 80030 DOOR ASSY GBF-5 TS LEFT HAND
3 80031 DOOR GASKET GBF-5G MM.383X730
4 80032 PLASTIC STRIP COVER
5 80033 CORD HEATER 4W/M L2380 115V/UL
6 80099 NEEDLE PROBE MULTICORE TS Pt1000
8 80035 REV. UPPER DOOR BRACKET BLAST CH.
9 80036 HINGE WITH SPRING&STOP CT4000F
10 80037 NYLON BUSH FOR HINGE D.32 HOLE
11 80038 UPPER HINGE W/PIV. GBF-5
12 80039 SHELVE RACK (1 PC) GBF-5 ETL
13 80040 STEEL PIN FIX GRID BLASTCHILLER ETL
15 80041 DRAINING PIPE BLAST CHILLER
15 80042 DRAINING PIPE'S PLUG
16 80043 DESMON BLAST CHILLER DECAL
17 80044 LEFT HAND DRIP TRAY RUNNER GBF-5,
18 80045 DRIP TRAY 4LT GBF-5G/P NEW WELD
19 80046 EVAPORATOR COIL GBF-5
20 80047 WELD.LOWER BRACKET EVAP.U.BLAST
21 80048 SUP HINGE BRACKET EVAP. GBF-15G
22 80049 FAN MOTOR HOLDER GBF-5 W/OUT UV
23 80050 FAN FINGUER GUARD 250 mm
24 80010 NTC PROBE 3MT SN691300
25 80011 PROBE GUARD BLAST.GBF-5G/P NEW
26 80053 FAN MOTOR A2E250-AL08-12 115V 50/60
27 80054 REAR GRIDDLE GBF-5
28 80055 REAR CORNER COVER GBF-5
29 80056 COMPRESSOR HU CAJ2464Z-A 115/60HZ
30 80057 THERM.VALV.TES2 C/MOP-16EQ.EST.
32 80058 HIGH PRESSURE SWITCH
33 80059 SOLENOID VALVE EVR10 3/8 ODF10MM
33 80060 DIN COIL ZB09 304011 110-120V/60Hz
34 80061 FILTER DRIER
35 80062 LIQUID RECEIVER RT-312V-TS 1,36LT
Description
TS ON DOOR)
HINGED
HINGED
14.2
NEW
NEW
OR01
NSDHA00B39111
GBF-5P
Ref.
Part
No.
No.
36 80019 KIT TOUCH SCREEN (INCLUDING
37 80020 MAGNETIC SENSOR E5301CUL0294
39 80065 CONTACTOR BF250022050 220V50/60HZ
40 80066 COPPER VALVE 1/4 MM.300 VC-500-09
41 80067 FUSE BOX 10.3x38(UL)
42 80068 FAST FUSE 10x38 600V AC 30A UL
43 80069 CONDENSER COIL SFT16251 10060166
44 80070 EL.MOTOR 16W-30-2 115V 60HZ UL-CSA
45 80071 FAN BLADE 230-26-5 ASP.STVF 139-93
46 80072 AIR DUCT CF24 W/GRILL
47 80073 CASTER KIT GBF-5G/P
48 80074 CONDENSER FILTER
Description
PLASTIC FRAME)
FEBRUARY 9, 2016 3 BLAST CHILLER/SHOCK FREEZERS
GBF-10
24
30
31
28
19
22
20
26
23
21
24
5
4
6
25
11
10
9
8
3
2
13
12
12
47
47
27
2
7
3
1
48
18
1
40
29
15
43
34
43
48
17
33
33
32
43
16
36
37
41
36
42
39
50
38
36
36
16
35
FEBRUARY 9, 2016 4 BLAST CHILLER/SHOCK FREEZERS
Ref.
Part
No.
No.
1 80027 FRONT PANEL GBF-10(NO KEYBOARD,
2 80080 DOOR ASSY GBF-10 TS RIGHT HAND
3 80081 DOOR GASKET GBF-10
4 80032 PLASTIC STRIP COVER
5 80082 FRAME HEATER 44W 220V L4400
6 80004 HEATED NEEDLE PROBE MULTICORE TS
8 80035 REV. UPPER DOOR BRACKET BLAST CH.
9 80036 HINGE WITH SPRING&STOP CT4000F
10 80037 NYLON BUSH FOR HINGE D.32 HOLE
11 80038 REV. UPPER DOOR BRACKET BLAST CH.
12 80039 SHELVE RACK (1 PC) GBF-10 ETL
13 80040 STEEL PIN FIX GRID BLASTCHILLER ETL
15 80042 DRAINING PIPE'S PLUG
15 80041 DRAINING PIPE BLAST CHILLER
17 80083 WATER DRAINING TRAY RUNNER
18 80084 MANUAL CONDENSATE PAN 540X240X70
19 80085 EVAPORATOR BLAS.GBF-10
20 80047 WELD.LOWER BRACKET EVAP.U.BLAST
21 80048 SUP HINGE BRACKET EVAP. GBF-15G
22 80086 FAN MOTOR HOLDER GBF-10 W/OUT UV
23 80008 S/S FINGUER GUARD 300mm
24 80010 NTC PROBE 3MT SN691300
25 80011 PROBE GUARD BLAST.GBF-5G/P NEW
26 80012 EL.MOT. R09E-3030HA-4M-2553 D300
27 80087 REAR GRIDDLE GBF-15G
28 80088 REAR CORNER COVER GBF-10 NEW
29 80089 COMPRESSOR TFH2511Z-K 220V60Hz
30 80090 THERM.VALV.TES2 C/MOP-16EQ.EST.
32 80058 HIGH PRESSURE SWITCH
Description
TS ON DOOR)
HINGED
CAB+ET139
14.2
DIS.10026886
NEW
NEW
OR03
NSDHA00B39111
GBF-10
Ref.
Part
No.
No.
33 80091 VALVE EVR10 ODF12MM
34 80092 FILTER DRIER ODS 163S 10MM
35 80093 LIQUID RECEIVER RT 512V-TR 3,50LT
36 80016 KIT TOUCH SCREEN (INCLUDING
37 80044 MAGNETIC SENSOR E5301CUL0294
39 80065 CONTACTOR BF250022050 220V50/60HZ
40 80066 COPPER VALVE 1/4 MM.300 VC-500-09
41 80067 FUSE BOX 10.3x38(UL)
42 80094 FAST FUSE 10x38 500V AC 20A UL
42 80068 FAST FUSE 10x38 600V AC 30A UL
43 80095 CONDENSER ASSY
47 80096 KIT CASTORS GALV/ST.CABINET 700 GOL
48 80097 CONDENSER FILTER
50 80098 THERMAL RELAY RF38 1400 9-14A
Description
PLASTIC FRAME)
FEBRUARY 9, 2016 5 BLAST CHILLER/SHOCK FREEZERS
19
24
25
22
23
29
26
30
35
GBF-20SC
43
35
33
34
33
32
41
42
39
37
24
19
9
2
3
6
36
7
5
4
51
7
36
FEBRUARY 9, 2016 6 BLAST CHILLER/SHOCK FREEZERS
GBF-20SC
Ref.
Part
No.
No.
2 80000 DOOR ASSY 621X1740X80
3 80001 DOOR GASKET 1927x850
4 80002 PVC PROFILE "MONOESTRUSO" R4192
5 80003 FRAME HEATER 15W/M L.5550mm
6 80004 HEATED NEEDLE PROBE MULTICORE TS
7 80005 S/S LEG 85X100 R.188-288
9 80006 DOOR HINGE WITH FLAG H45/67
19 80007 EVAPORATOR COIL GBF-20GN1/1
22 80008 INOX RACK 530X635 CABINET DEPTH80
23 80009 FAN HOLDER PANEL 300mm GBF-
24 80010 NTC PROBE 3MT SN691300
25 80011 PROBE GUARD BLAST.GBF-5G/P NEW
26 80012 EL.MOT. R09E-3030HA-4M-2553 D300
29 80013 COMPR.FRASCOLD D2-15Y 230/3/60UL
Description
6MT
20GN1/1
Ref.
Part
No.
No.
30 80014 TX VALVE R404a 2230/M12SE
32 80015 HIGH/LOW PRESSURE SWITCH
33 80016 SOLENOID VALVE EVR10 3/8 ODF12MM
34 80017 FILTER DRIER ODS 304S 12MM
35 80018 DIN COIL ZB09 304051 208-240/60UL
36 80019 KIT TOUCH SCREEN (INCLUDING
37 80020 MAGNETIC SENSOR E5301CUL0294
39 80021 CONTACT.LOV.BF3800A230 38A230V50/60
41 80022 FUSE BOX CL.J 600V60A 3/P ULCH60J3
42 80023 RAPID FUSE 45A CL.J600V ULIKS
43 80024 CONDENSER ASSY STVF 273 082046101
51 80025 DOOR HANDLE ACTIVA 80 MM
Description
O17H4758B01
PLASTIC FRAME)
FEBRUARY 9, 2016 7 BLAST CHILLER/SHOCK FREEZERS
