Blaupunkt PA4100 User Manual

Below is a basic trouble-shooting guide to assist in seeking out and correcting a problem that may occur in the installation
process. Although lengthy, this chart cannot address every single problem possible but mainly the ones most common.

PARAMETER/FEATURE PA4100

Channels 4/3/2

Size ( W x H x D) 10.4 x9.8x2.6 inches (265x250x67mm)

Weight (with housing) 6.0 lbs (2.7 kg)

Crimping style speaker terminals? YES

Maximum terminal wire size 10 ga.

Subsonic filter YES (10 Hz)

Separate front/rear or left/right gains? F/R YES, L/R NO

Fuse Type ATC spade -2@40A

Speaker short, short to +12V, and short to ground protection? YES

High, low, and reverse voltage protection? YES

Power output transistors MOSFET

Switching power supply transistors MOSFET

Minimum speaker impedance (non-bridged) 2 ohms

(bridged) 4 ohms

PERFORMANCE DATA

Rated power output @ 0.1% THD, 13.8V

4 channels into 4 ohms / 2 ohms 4 x 100 W / 4 x 125 W

2 channels into 4 ohms 2 x 250 W

Total Harmonic Distortion @ rated full output 0.03% THD

Rated Signal/Noise ratio (averaged value)

Measured @ 1 watt / 1 kHz dBA 82

Measured @ full rated power (0.1% THD) dBA >100

Damping factor >100

Frequency response (full-range mode) 20 - 50,000 Hz

High-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct

Low-pass crossover frequency limits 50 H z - 250 Hz (variable), 12dB/oct

Input impedance 10 kohms

Input signal voltage control range 0.3 - 6.0 vrms

Current Draw @ 13.8 VDC (typical values @ X watts / Efficiency %)

@ full rated power, bridged mode (@ 4 ohms) 70 A (65%)

@ full rated power, unbridged (@ 4 ohms) 42 A (78%)

@ 33% rated power, unbridged (@ 4 ohms) 16 A (60%)

@ 10% rated power, unbridged (@ 4 ohms) 8 A (40%)

@ idle (@ 4 ohms) 2.5 A

Minimum battery voltage to maintain rated power 12.6 VDC

Usable battery voltage 10 - 16 VDC

Trigger line voltage range 10 - 16 VDC

Trigger line current draw @ 20 mA

Turn on delay time @ 2.0 seconds

Thermal shutoff temperature (average heat-sink temp) @ 85˚ C (185˚ F)

NOTE: DUE TO ONGOING PRODUCT IMPROVEMENTS, DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE
