Black & Decker PRCBM5 User Manual

Coffee Bean

First Use Safety Recommendation

Please read through this booklet for safe and efficient use of the appliance. We urge you to read the "Hint's" section and also follow all detailed instructions even if you are familiar with using this appliance.

Keep this guide handy for future reference.

English Page 02 Farsi Page 13 Arabic Page 19

PRCBM5

English

IMPORTANT SAFEGUARDS

While using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury to persons, basic safety precautions should be followed, including the following:

• Read all instructions carefully, even if you are familiar with the appliance.

• To protect against the risk of electric shock, DO NOT IMMERSE the appliance,

cord set or plug in water or other liquids.

• To clean, wipe the exterior with a damp cloth.

• Close supervision is necessary when any appliance is used near children. Never leave an appliance unattended when in use.

• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

• Switch off and remove the plug from the power outlet when not in use, before assembling or disassembling parts, cleaning or carrying out any maintenance of the appliance. Never pull the cord while unplugging it from power outlet.

• Do not operate any appliance which is damaged in any manner. Return the complete appliance to your nearest authorized service facility for examination, electrical repair, mechanical repair or adjustments to avoid any hazard.

• The use of attachments or accessories not recommended or sold by this appliance manufacturer may result in fire, electric shock or personal injury.

• Do not let the cord hang over the edge of a table, counter, or touch hot surfaces.

• Avoid touching hot surfaces, use handles and knobs.

• Do not operate or place any part of this appliance on or near any hot surfaces (such as gas or electric burner or in a heated oven).

• Do not abuse the cord. Never carry the appliance by the cord or yank it to disconnect it from the outlet; instead, grasp the plug and pull to disconnect.

• When using an extension cord with your appliance, make sure the extension cord is correctly wired, and rated for its use.

• This product is intended for household use only.

• Do not attempt to repair the appliance yourself; instead, take it to your Black & Decker-owned or Authorized Service Centre for repair.

SAVE THESE INSTRUCTIONS

-2-

English

Parts Identification

1 Lid

2 Bowl

3 Grind size indicator

4 Cup quantity selector

5 Start / Stop button

6 Motor Housing

7 Container Lid

8 Coffee Container

9 Cord Storage

10 Main Switch

11 Safety Interlock

MAX

-3-

English

Intended Use

Your Black and Decker Coffee Bean Mill

has been designed for grinding coffee

beans. Do not use this appliance for any

other purpose. This appliance is intended

for indoor consumer use only.

Safety Instructions

Warning! When using mains-powered

appliances, basic safety precautions,

including the following, should always be

followed to reduce the risk of fire, electric

shock, personal injury and material

damage.

• Read all of this manual carefully before

using the appliance.

• The intended use is described in this

manual. The use of any accessory or

attachment or the performance of any

operation with this appliance other than

those recommended in this instruction

manual may present a risk of personal

injury.

• Retain this manual for future reference.

• Always route the cord carefully to avoid

a tripping hazard.

• Never operate an appliance directly

below the socket-outlet it is connected

to.

Electrical safety

This tool is double insulated;

therefore no earth wire is required.

Always check that the power supply

corresponds to the voltage on the rating

plate.

If the supply cord is damaged, it must be

replaced by the manufacturer or an

authorised Black & Decker Service Centre

in order to avoid a hazard.

Grinding Beans

1. Remove the lid (1) from the bowl (2) and

add the required amount of coffee

beans. Do not exceed the maximum

capacity (marked with a line on the side

of the bowl).

2. Refit the lid (1)

3. Ensure the container lid (7) is fitted

securely onto the coffee container (8).

4. Place the bowl into position on the

motor housing (6) and rotate clockwise

until you hear a ratcheting sound.

5. Select the correct grind setting. As a

guide use a fine setting for espresso, a

medium setting for cafetierres and filter

machines and a coarse setting for

percolators. Turn the bowl (2) clockwise

to select a finer setting and anti

clockwise for a coarser setting. The

setting indicator on the housing (6)

should align with the desired grind

setting marked on the bowl (2).

6. Plug the mains cable into a suitable

power supply and switch on the main

switch (10).

7. Turn the cups quantity selector (4) to

select the grinding time and then press

the start / stop button (5) to begin

grinding.

-4-

English

Important: The appliance is fitted with

safety interlocks which prevent the unit

operating if the bowl (2) is not screwed far

enough down. After grinding is complete

the powder cup can be removed from the

unit and taken to the coffee making

machine.

Hints

• Empty the powder cup before it

becomes full.

• During grinding it may be necessary to

shake the unit slightly from side to side

to free any coffee which is not moving

towards the grinding plates.

Maximum Operating Time: 3 minutes.

Always allow 30 minutes rest before

using the unit again.

Warning

Do not apply pressure to the lid (1) or

to the bowl (2).

Care and Cleaning

• Always switch off and unplug before

cleaning.

• Do not immerse the appliance, cord set

or plug in water or other liquids.

• Always clean the unit after each use.

• Always ensure the area around the

safety interlock (11)is free of coffee.

• No parts of the appliance are suitable

for cleaning in a Dishwasher.

Coffee container and lid (8) and (7)

• Wash by hand and dry thoroughly.

Bowl (2)

• Remove the bowl (2) by turning

anticlockwise.

• Wash by Hand and dry thoroughly.

Motor Housing(6)

Clean with damp cloth and dry thoroughly.

Safety of others

• Do not allow children or any person

unfamiliar with these instructions to use

the appliance.

• Do not allow children or animals to come

near the work area or to touch the

appliance or power supply cord. Close

supervision is necessary when the

appliance is used near children.

• Never leave an appliance unattended

when in use

• Do not allow the cord set to hang over

bench tops. When using an extension

cord with your appliance, make sure the

extension cord is correctly wired & rated

for its use.

• This appliance is not intended for use by

persons(including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have been give supervision

or instruction concerning use of the

appliance by a person responsible for

their safety.

-5-

English

• Children must be supervised to ensure

that they do not play with the appliance.

After use

• Switch off and remove the plug from the

socket before leaving the appliance unattended and before changing, cleaning or inspecting any parts of the appliance.

• When not in use, the appliance should

be stored in a dry place. Children should not have access to stored appliances.

Inspection and repairs

• Before use, check the appliance for

damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.

• Do not use the appliance if any part is

damaged or defective.

• Have any damaged or defective parts

repaired or replaced by an authorised repair agent.

• Before use, check the power supply

cord for signs of damage, ageing and wear.

• Do not use the appliance if the power

supply cord or mains plug is damaged or defective.

• If the power-supply cord or mains plug is

damaged or defective it must be repaired by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. Do not cut the power supply cord and do not attempt to repair it yourself.

• Never attempt to remove or replace any

parts other than those specified in this manual.

• Do not attempt to repair the appliance. Take it to your nearest Black & Decker owned or authorised Service Centre for repair.

Protecting the environment

Separate collection. This product must not be disposed of with normal household waste.

Should you find one day that your Black & Decker product needs replacement, or if it is of no further use to you, do not dispose it off with other household waste. Make this product available for separate collection.

Separate collection of used products

and packaging allows materials to be recycled and used again. Use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.

Local regulations may provide for separate collection of electrical products from the household, at municipal waste sites or by the retailer when you purchase a new product.

Black & Decker provides a facility for the collection and recycling of Black & Decker products once they have reached the end of their working life. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf. You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. A list of authorised Black & Decker repair agents and full details of our after-sales service and contact are available on the Internet at: www.2helpU.com

-6-
