Intended use
Your Black & Decker planer has been designed for planing
wood, wood products and plastics. The tool is intended for
hand-held use. This tool is intended for consumer use only.
General safety rules
Warning! Read all instructions. Failure to follow all
instructions listed below may result in electric shock, fire and/
or serious injury. The term “power tool” in all of the warnings
listed below refers to your mains operated (corded) power tool
or battery operated (cordless) power tool.
SAVE THESE INSTRUCTIONS.
1. Work area
a. Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the
risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
b. Use safety equipment. Always wear eye protection.
Safety equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in
the off position before plugging in. Carrying power
tools with your finger on the switch or plugging in power
tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of these
devices can reduce dust related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tools
operation. If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly maintained power
tools.
f. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
5
g. Use the power tool, accessories and tool bits etc.,
in accordance with these instructions and in the
manner intended for the particular type of power
tool, taking into account the working conditions
and the work to be performed. Use of the power tool
for operations different from those intended could result
in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Fitting
◆ Slide the blade into the holder until it is centred in the holder.
◆ Make sure that the holder remains centred in the barrel (9).
◆ Tighten the bolts using the spanner supplied.
◆ Always replace both cutters.
Adjusting the depth of cut (fig. B)
The depth of cut is indicated by the marking (10). The setting
range can be read from the graduation (5).
◆ Turn the planing depth adjustment knob (4) to the required
depth of cut.
◆ Turn the knob to the ‘P’ postion whenever the tool is not in use.
Additional safety instructions for planers
◆ Wait for the cutters to stop before setting the tool
down. An exposed cutter may engage the surface and
lead to possible loss of control and serious injury.
Electrical safety
This tool is double insulated; therefore no earth wire
is required. Always check that the power supply
corresponds to the voltage on the rating plate.
◆ This appliance is not intended for use by young or infirm
persons without supervision. Children must be supervised
to ensure they do not play with the appliance.
◆ If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
This tool includes some or all of the following features.
1. On/off switch
2. Lock-off button
3. Shavings discharge outlet
4. Planing depth adjustment knob
5. Planing depth graduation
Assembly
Warning! Before assembly, make sure that the tool is
switched off and unplugged.
Fitting and removing the parallel fence (fig. C)
The parallel fence (11) is used for optimum control on narrow
workpieces.
◆ Hold the parallel fence (11) in front of the tool as shown.
◆ Fit the parallel fence by inserting the locking knob (12)
into the hole (13).
◆ Tighten the locking knob.
◆ To remove the parallel fence proceed in reverse order.
Fitting and removing the rebating depth stop (fig. D)
The rebating depth stop (15) is used for limiting the planing
depth during rebating.
◆ Hold the stud (16) in front of the tool as shown.
◆ Fit the rebating depth stop by inserting the locking knob (17)
into the hole (18).
◆ Fasten the locking knob.
◆ To remove the rebating depth stop proceed in reverse order.
Adjusting the shavings discharge outlet (fig. E)
The tool facilitates both left-hand and right-hand side
shavings discharge.
◆ Insert the adaptor (19) into the desired outlet opening,
aligning the notch with the recess. Twist the adaptor
clockwise as soon as it is fully inserted.
◆ Insert the plug (20) into the opposite opening, following
the above procedure.
◆ Provide for a suitable dust extraction.
Replacing the cutting blades (fig. A)
The cutting blades provided with this tool are reversible.
Replacement cutting blades can be obtained from your local
retailer.
Removing
◆ Loosen the bolts (6) using the spanner supplied.
◆ Slide the blade (7) out of the holder (8).
◆ Reverse the blade so that the unused side comes in position.
If both sides are worn, the blade must be replaced.
6
Fitting and removing the shavings bag (fig. F)
◆ Slide the shavings bag (21) into the shavings discharge
outlet (3).
◆ Push the shavings bag into place. Make sure that the lug
(22) is correctly located into the hole (23) on the inside of
the shavings bag.
◆ To remove the shavings bag, press the tab (24) and pull
the shavings bag out of the outlet.
Connecting a vacuum cleaner to the tool (fig. G)
◆ Slide the vacuum cleaner hose (25) into the shavings
discharge outlet (3).
Use
Warning! Let the tool work at its own pace. Do not overload.
◆ Adjust the depth of cut.
◆ If necessary, fit and adjust the parallel fence.
◆ Use sharp cutters only.
Adjusting the parallel fence (fig. C)
◆ Slacken the wing nut (14).
◆ Slide the parallel fence (10) into the desired position.
◆ Fasten the wing nut.
Adjusting the rebating depth stop (fig. D)
◆ Slacken the locking knob (17).
◆ Set the depth stop (15) to the desired position.
◆ Fasten the locking knob.
Switching on and off
Switching on
◆ Keep the lock-off button (2) depressed and press the
on/off switch (1).
◆ Release the lock-off button.
Hints for optimum use
◆ Move the tool along the grain of the wood.
◆ If the grain is cross or curly, or if the workpiece material is
a hard type of wood, adjust the depth of cut to take only a
very thin shaving at each pass and take several passes to
achieve the desired result.
◆ To keep the tool in a straight line, press down the front of
the tool at the start, and press down the back of the tool
at the end of the cutting stroke.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
◆ Regularly clean the ventilation slots with a clean, dry
paint brush.
◆ To clean the tool, use only mild soap and a damp cloth.
Never let any liquid get inside the tool and never immerse
any part of the tool into liquid.
Replacing the drive belt (fig. I)
◆ Loosen the screws (26) and remove the cover (27).
◆ Remove the old drive belt.
◆ Place the new belt (28) over the pulleys. Place the belt
over the large pulley (29) first, then over the small pulley
(30), whilst manually rotating the belt steadily.
◆ Put the cover back in place and tighten the screws.
Switching off
◆ Release the on/off switch.
Planing
◆ Hold the tool with the nose piece of the shoe resting on
top of the workpiece surface.
◆ Switch the tool on.
◆ Move the tool steadily forward to perform the cutting stroke.
◆ Switch the tool off after the stroke has been completed.
Rebating (fig. H)
◆ Fit and adjust the parallel fence.
◆ Fit and adjust the rebating depth stop.
◆ Proceed as for planing.
◆ When performing a rebate cut, make sure that the guard
is not trapped, twisted or blocked. Always make sure that
the shoe is placed flat against the rebate edge.
Chamfering edges
The V-groove in the nose piece of the shoe enables you to
chamfer edges at 45˚ angles.
◆ Hold the tool at an angle with the groove around the edge
of the workpiece and perform the cutting stroke.
Protecting the environment
Separate collection. This product must not be
disposed of with normal household waste.
Should you find one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product
available for separate collection.
Separate collection of used products and packaging
allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand for
raw materials.
Local regulations may provide for separate collection of
9electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.
7
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker office at the
address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
KW82
Voltage VAC230
Power input W 900
No-load speed min-117,000
Planing width mm 82
Planing depth mm 3
Rebating depth mm 15
Weight kg 4.2
EC declaration of conformity
Black & Decker declares that these products conform to:
98/37/EC, 89/336/EEC, 2002/96/EC, EN 60745, EN 55014,
LpA (sound pressure) 92 dB(A), LWA (acoustic power) 103 dB(A),
hand/arm weighted vibration 3.49 m/s
KpA (sound pressure uncertainty) 3 dB(A),
KWA (acoustic power uncertainty) 3 dB(A)
KW82
EN 61000
2
◆ The product has been used for trade, professional or hire
purposes;
◆ The product has been subjected to misuse or neglect;
◆ The product has sustained damage through foreign
objects, substances or accidents;
◆ Repairs have been attempted by persons other than
authorised repair agents or Black & Decker service staff.
To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent by
contacting your local Black & Decker office at the address
indicated in this manual. Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-sales
service and contacts are available on the Internet at:
www.2helpU.com
Please visit our website www.blackanddecker.co.uk to
register your new Black & Decker product and to be kept up to
date on new products and special offers. Further information
on the Black & Decker brand and our range of products is
available at www.blackanddecker.co.uk
Kevin Hewitt
Director of Consumer Engineering
Spennymoor, County Durham DL16 6JG,
United Kingdom
1-9-2005
Guarantee
Black & Decker is confident of the quality of its products and
offers an outstanding guarantee. This guarantee statement is in
addition to and in no way prejudices your statutory rights. The
guarantee is valid within the territories of the Member States of
the European Union and the European Free Trade Area.
If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within
24 months from the date of purchase, Black & Decker
guarantees to replace defective parts, repair products
subjected to fair wear and tear or replace such products to
ensure minimum inconvenience to the customer unless:
8
91011
KW82
TYP
1
10 9
43
19
44
45
4
11
12
67
19
14
20
52
16
15
30
31
4
13
17
18
21
22
23
71
46
47
48
49
5
6
27
4
32
33
28
35
1
29
4
36
34
37
38
40
39
4
2
4
7
3
8
50
51
4
4
24
70
26
25
36
53
13
69
54
55
56
58
68
57
E
59
14548
63
66
60
64
61
62
www
65
.
2
hel
pU.com
41
4
21-09-05
42
Australia
Black & Decker (Australia) Pty. Ltd. Tel. 03-8720 5100
20 Fletcher Road, Mooroolbark, Fax 03-9727 5940
Victoria, 3138
New Zealand
Black & Decker Tel. 09 579 7600
81 Hugo Johnston Drive Fax 09 579 8200
Penrose, Auckland, New Zealand
United Kingdom
Black & Decker Tel. 01753 511234
210 Bath Road Fax 01753 551155
Slough, Berkshire SL1 3YD Helpline 01753 574277
491053-00
12
09/05
Loading...
