Model: 8600/B, 8601/B, 8602/B, 8610/B, 8612/B, 8614/B, 8616, 8620, 8622, 8624, and 8625
Programmable DC Electronic Loads
USER MANUAL
www.GlobalTestSupply.com
i
Safety Summary
The following safety precautions apply to both operating and maintenance personnel and must be followed during all phases of operation, service, and repair of this instrument.
Before applying power to this instrument:
• Read and understand the safety and operational information in this manual.
• Apply all the listed safety precautions.
• Verify that the voltage selector at the line power cord input is set to the correct line
voltage. Operating the instrument at an incorrect line voltage will void the warranty.
• Make all connections to the instrument before applying power.
• Do not operate the instrument in ways not specified by this manual or by B&K Precision.
Failure to comply with these precautions or with warnings elsewhere in this manual violates the safety standards of design, manufacture, and intended use of the instrument. B&K Precision assumes no liability for a customer’s failure to comply with these requirements.
Category rating
The IEC 61010 standard defines safety category ratings that specify the amount of electrical energy available and the voltage impulses that may occur on electrical conductors associated with these category ratings. The category rating is a Roman numeral of I, II, III, or IV. This rating is also accompanied by a maximum voltage of the circuit to be tested, which defines the voltage impulses expected and required insulation clearances. These categories are:
Category I (CAT I): Measurement instruments whose measurement inputs are not intended to be connected to the mains supply. The voltages in the environment are typically derived from a limited-energy transformer or a battery.
Category II (CAT II): Measurement instruments whose measurement inputs are meant to be connected to the mains supply at a standard wall outlet or similar sources. Example measurement environments are portable tools and household appliances.
Category III (CAT III): Measurement instruments whose measurement inputs are meant to be connected to the mains installation of a building. Examples are measurements inside a building's circuit breaker panel or the wiring of permanently-installed motors.
www.GlobalTestSupply.com
ii
Category IV (CAT IV): Measurement instruments whose measurement inputs are meant to be connected to the primary power entering a building or other outdoor wiring.
Do not use this instrument in an electrical environment with a higher category rating than what is specified in this manual for this instrument.
You must ensure that each accessory you use with this instrument has a category rating equal to or higher than the instrument's category rating to maintain the instrument's category rating. Failure to do so will lower the category rating of the measuring system.
Electrical Power
This instrument is intended to be powered from a CATEGORY II mains power environment. The mains power should be 120 V RMS or 240 V RMS. Use only the power cord supplied with the instrument and ensure it is appropriate for your country of use.
Ground the Instrument
To minimize shock hazard, the instrument chassis and cabinet must be connected to an electrical safety ground. This instrument is grounded through the ground conductor of the supplied, three-conductor AC line power cable. The power cable must be plugged into an approved three-conductor electrical outlet. The power jack and mating plug of the power cable meet IEC safety standards.
Do not alter or defeat the ground connection. Without the safety ground connection, all accessible conductive parts (including control knobs) may provide an electric shock. Failure to use a properly-grounded approved outlet and the recommended three-conductor AC line power cable may result in injury or death.
Unless otherwise stated, a ground connection on the instrument's front or rear panel is for a reference of potential only and is not to be used as a safety ground.
www.GlobalTestSupply.com
iii
Do not operate in an explosive or flammable atmosphere
Do not operate the instrument in the presence of flammable gases or vapors, fumes, or finely­divided particulates.
The instrument is designed to be used in office-type indoor environments. Do not operate the instrument
• In the presence of noxious, corrosive, or flammable fumes, gases, vapors, chemicals, or
finely-divided particulates.
• In relative humidity conditions outside the instrument's specifications.
• In environments where there is a danger of any liquid being spilled on the instrument or
where any liquid can condense on the instrument.
• In air temperatures exceeding the specified operating temperatures.
• In atmospheric pressures outside the specified altitude limits or where the surrounding
gas is not air.
• In environments with restricted cooling air flow, even if the air temperatures are within
specifications.
• In direct sunlight.
This instrument is intended to be used in an indoor pollution degree 2 environment. The operating temperature range is 0 °C to 40 °C and the operating humidity range is ≤ 95% relative humidity with no condensation allowed.
Measurements made by this instrument may be outside specifications if the instrument is used in non-office-type environments. Such environments may include rapid temperature or humidity changes, sunlight, vibration and/or mechanical shocks, acoustic noise, electrical noise, strong electric fields, or strong magnetic fields.
Do not operate instrument if damaged
If the instrument is damaged, appears to be damaged, or if any liquid,
chemical, or other material gets on or inside the instrument, remove the instrument's power
www.GlobalTestSupply.com
iv
cord, remove the instrument from service, label it as not to be operated, and return the instrument to B&K Precision for repair. Notify B&K Precision of the nature of any contamination of the instrument.
Clean the instrument only as instructed
Do not clean the instrument, its switches, or its terminals with contact cleaners, abrasives, lubricants, solvents, acids/bases, or other such chemicals. Clean the instrument only with a clean dry lint-free cloth or as instructed in this manual.
Not for critical applications
This instrument is not authorized for use in contact with the human body or for use as a component in a life-support device or system.
Do not touch live circuits
Instrument covers must not be removed by operating personnel. Component replacement and internal adjustments must be made by qualified service-trained maintenance personnel who are aware of the hazards involved when the instrument's covers and shields are removed. Under certain conditions, even with the power cord removed, dangerous voltages may exist when the covers are removed. To avoid injuries, always disconnect the power cord from the instrument, disconnect all other connections (for example, test leads, computer interface cables, etc.), discharge all circuits, and verify there are no hazardous voltages present on any conductors by measurements with a properly-operating voltage-sensing device before touching any internal parts. Verify the voltage-sensing device is working properly before and after making the measurements by testing with known-operating voltage sources and test for both
DC and AC voltages. Do not attempt any service or adjustment unless another person capable of
rendering first aid and resuscitation is present.
Do not insert any object into an instrument's ventilation openings or other openings.
www.GlobalTestSupply.com
v
Hazardous voltages may be present in unexpected locations in circuitry being tested when a fault condition in the circuit exists.
Fuse replacement
Fuse replacement must be done by qualified service-trained maintenance personnel who are aware of the instrument's fuse requirements and safe replacement procedures. Disconnect the instrument from the power line before replacing fuses. Replace fuses only with new fuses of the fuse types, voltage ratings, and current ratings specified in this manual or on the back of the instrument. Failure to do so may damage the instrument, lead to a safety hazard, or cause a fire. Failure to use the specified fuses will void the warranty.
Servicing
Do not substitute parts that are not approved by B&K Precision or modify this instrument. Return the instrument to B&K Precision for service and repair to ensure that safety and performance features are maintained.
Cooling fans
This instrument contains one or more cooling fans. For continued safe operation of the instrument, the air inlet and exhaust openings for these fans must not be blocked nor must accumulated dust or other debris be allowed to reduce air flow. Maintain at least 25 mm clearance around the sides of the instrument that contain air inlet and exhaust ports. If mounted in a rack, position power devices in the rack above the instrument to minimize instrument heating while rack mounted. Do not continue to operate the instrument if you cannot verify the fan is operating (note some fans may have intermittent duty cycles). Do not insert any object into the fan's inlet or outlet.
www.GlobalTestSupply.com
vi
Do not short-circuit batteries
When using a DC load to discharge a battery, do not exceed the battery manufacturer's specified maximum rate of discharge.
Use correctly sized wires
To connect the load to the power supply, use a wire diameter large enough to handle the maximum continuous output short-circuit current of the power supply without the wire overheating.
For continued safe use of the instrument
• Do not place heavy objects on the instrument.
• Do not obstruct cooling air flow to the instrument.
• Do not place a hot soldering iron on the instrument.
• Do not pull the instrument with the power cord, connected probe, or connected test
lead.
• Do not move the instrument when a probe is connected to a circuit being tested.
www.GlobalTestSupply.com
vii
Compliance Statements
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)
This product is subject to Directive 2002/96/EC of the European Parliament and the Council of the European Union on waste electrical and electronic equipment (WEEE) , and in jurisdictions adopting that Directive, is marked as being put on the market after August 13, 2005, and should not be disposed of as unsorted municipal waste. Please utilize your local WEEE collection facilities in the disposition of this product and otherwise observe all applicable requirements.
www.GlobalTestSupply.com
viii
CE Declaration of Conformity
The instrument meets the requirements of 2006/95/EC Low Voltage Directive and 2004/108/EC Electromagnetic Compatibility Directive with the following standards.
Low Voltage Directive
- EN61010-1: 2001
EMC Directive
- EN 61000-3-2: 2006
- EN 61000-3-3: 1995+A1: 2001+A2: 2005
- EN 61000-4-2 / -3 / -4 / -5 / -6 / -11
- EN 61326-1: 2006
www.GlobalTestSupply.com
ix
Safety Symbols
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Chassis (earth ground) symbol.
On (Power)
Off (Power)
On (Power). This is the In position of the power switch when instrument is ON.
Off (Power). This is the Out position of the power switch when instrument is OFF.
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Safety instructions (or equivalent) signs indicate specific safety­related instructions or procedures.
www.GlobalTestSupply.com
x
Table of Contents
Safety Summary ................................................................................................... i
Compliance Statements ............................................................................................................. vii
CE Declaration of Conformity.................................................................................................... viii
1 General Information ..................................................................................... 1
1.1 Product Overview ........................................................................................................... 1
1.2 Package Contents ............................................................................................................ 2
1.3 Product Dimensions ........................................................................................................ 2
1.4 Rackmount Installation ................................................................................................... 6
1.5 Front Panel Overview ...................................................................................................... 7
Front Panel Description ........................................................................................................... 8
1.6 Rear Panel Overview ....................................................................................................... 9
Rear Panel Description .......................................................................................................... 10
1.7 Display Overview ........................................................................................................... 10
Display Description ................................................................................................................ 11
2 Getting Started ........................................................................................... 12
2.1 Input Power and Fuse Requirements ............................................................................ 12
Input Power ........................................................................................................................... 12
Fuse Requirements ................................................................................................................ 13
Fuse Replacement ................................................................................................................. 13
2.2 Input Connections ......................................................................................................... 14
2.3 Preliminary Check ......................................................................................................... 15
Self-test Errors ....................................................................................................................... 15
Input Check ............................................................................................................................ 16
Check Model and Firmware Version ..................................................................................... 17
3 Front Panel Operation ................................................................................ 18
3.1 Menu Options ............................................................................................................... 18
System Menu ......................................................................................................................... 18
Config Menu .......................................................................................................................... 18
How to Navigate the Menu ................................................................................................... 19
3.2 Configure Operation Modes (CC/CV/CR/CW) ............................................................... 20
www.GlobalTestSupply.com
xi
Constant Current (CC) Mode ................................................................................................. 20
Constant Voltage (CV) Mode ................................................................................................. 23
Constant Resistance (CR) Mode ............................................................................................ 24
Constant Power (CW) Mode .................................................................................................. 25
Setting CC, CV, CR, CW Mode ................................................................................................ 27
3.3 SYSTEM Menu ............................................................................................................... 27
Restore Factory Default Settings ........................................................................................... 28
Configure Power-On State ..................................................................................................... 29
Load On Knob ........................................................................................................................ 29
Configure Trigger Source ....................................................................................................... 30
Save/Recall Instrument Settings ........................................................................................... 31
Display Input On Timer .......................................................................................................... 34
Remote Interface Setup ......................................................................................................... 34
3.4 CONFIG Menu ............................................................................................................... 37
Von Operation ....................................................................................................................... 37
Configure Protection Settings ............................................................................................... 40
Configure Timed Input .......................................................................................................... 44
Measurement Configurations ............................................................................................... 44
CR LED Function .................................................................................................................... 46
Remote Sense ........................................................................................................................ 47
External Analog Control and Monitor ................................................................................... 48
3.5 Short Operation ............................................................................................................ 50
3.6 Transient Operation ...................................................................................................... 51
Continuous ............................................................................................................................ 51
Pulse ...................................................................................................................................... 52
Toggle .................................................................................................................................... 52
3.7 List Operation ................................................................................................................ 56
Configure List ........................................................................................................................ 57
Run List .................................................................................................................................. 59
3.8 Battery Test Function .................................................................................................... 60
3.9 Test Operations ............................................................................................................. 61
Automatic Test Function ........................................................................................................ 61
OCP Test Function .................................................................................................................. 71
www.GlobalTestSupply.com
xii
OPP Test Function .................................................................................................................. 74
3.10 Key Lock......................................................................................................................... 77
4 Remote Operation ...................................................................................... 78
4.1 Interface Connection..................................................................................................... 78
RS-232 ................................................................................................................................... 78
GPIB (non-B series only) ........................................................................................................ 79
USBTMC ................................................................................................................................. 79
4.2 Remote Commands ....................................................................................................... 79
5 Troubleshooting Guide ............................................................................... 80
General .................................................................................................................................. 80
Remote Control ..................................................................................................................... 80
6 Specifications ............................................................................................. 81
Supplementary Characteristics ................................................................................................. 87
7 Calibration .................................................................................................. 89
Index ................................................................................................................. 90
www.GlobalTestSupply.com
1
1 General Information
1.1 Product Overview
The 8600/B Series DC Electronic Loads are versatile instruments used for static and dynamic testing of DC power supplies, batteries, DC-to-DC converters, and battery chargers. Other applications include fuel-cell and photovoltaic cell test.
The DC load can be used in one of the following operation modes: constant voltage (CV), constant current (CC), constant resistance (CR), or constant power (CW). A wide range of dynamic loading applications can be simulated through user-programmable slew rates, load levels, duration, and conducting voltage. The DC load can be remotely programmed via the USB, GPIB (non-B series only), or RS-232 serial interface. Versatile triggering options allow the dynamic load behavior to be synchronized with other events.
A battery test mode is provided that will measure the ampere-hour (Ah) characteristic of a battery. Shorts can be simulated by either the front panel or custom programming. The DC source or other components can be protected from excessive voltage, current, or power, which will cause the DC load to shut down if excessive levels or reverse polarity are detected.
Features:
• CC/CV/CR/CW operating modes
• High Resolution Display
• Transient mode up to 25 kHz
• List mode function
• Measurement speed up to 50 kHz
• Remote sense function
• Built-in battery test function
• OCP and OPP auto test function
• CR-LED function
• Store/recall up to 100 setups
• RS232/USBTMC/GPIB (non-B series only) interfaces
• Analog current control and monitoring
• Adjustable slew rate in CC mode
• OVP/OCP/OPP/OTP and reverse voltage protection
www.GlobalTestSupply.com
2
1.2 Package Contents
Please inspect the instrument mechanically and electrically upon receiving it. Unpack all items from the shipping carton, and check for any obvious signs of physical damage that may have occurred during transportation. Report any damage to the shipping agent immediately. Save the original packing carton for possible future reshipment. Every instrument is shipped with the following contents:
• 1x 8600/B series DC Electronic load
• 1x AC Power Cord
• Certificate of Calibration
Verify that all items above are included in the shipping container. If anything is missing, please contact B&K Precision.
1.3 Product Dimensions
All models are designed to fit in a standard 19-inch rackmount. The dimensions are shown in Figure 1 below.
www.GlobalTestSupply.com
3
Figure 1 – Front and Side View (Half-rack models)
Figure 2 - Front and Side View (Full-rack 3U models)
www.GlobalTestSupply.com
4
Figure 3 Front and Side View (Full-rack 6U models)
www.GlobalTestSupply.com
5
Figure 4 - Rear View (Half-rack models)
Figure 5 - Rear View (Full-rack 3U models)
www.GlobalTestSupply.com
6
1.4 Rackmount Installation
The instrument can be installed in a standard 19 inch rack. For half-rack models, the optional rackmount kit IT-E151 is required (No rackmount kit required for full-rack models). Below is an image of a half-rack model installed with the IT-E151 rackmount kit.
Figure 6Rear View (Full-rack 6U models)
www.GlobalTestSupply.com
7
This rackmount kit will allow up to two half-rack models installed side by side, as shown below.
1.5 Front Panel Overview
1
2
3
4
5 6 7
9
10
12
14 8 13
11
15
Figure 7 – Front Panel (Half-rack models)
www.GlobalTestSupply.com
8
Front Panel Description
Power On/Off switch
Local button
Shift button
Numeric keypad
CC/OCP button
CW/OPP button
Enter/Recall settings button
Input On/Off and key lock button
CR button
CV/Setup button
Navigation arrow keys
Input terminal
Rotary knob
VFD display
ESC button
Recall button (Full-rack models)
Trig button (Full-rack models)
Pause button (Full-rack models)
1
11
4 5 6
7
9
10 8 15
3
13
14
2
16
17
18
19
20
1 2 3 4 5 6 7
8
14
12
13
9
10
11
15
16
Figure 8 - Front Panel (Full-rack models)
17
18
www.GlobalTestSupply.com
9
Trans button (Full-rack models)
List button (Full-rack models)
1.6 Rear Panel Overview
1
2
3 4 5 6 9 8 7
10
11
12
13
14
15
1
2
3 9 4
5
6
7
8
10
11
12
13
14
Figure 9 - Rear Panel (Half-rack models)
Figure 10 - Rear Panel (Full-rack models)
19
20
www.GlobalTestSupply.com
10
Rear Panel Description
Cooling fan vent
Remote control port (not used)
RS232 Interface
Current Monitor BNC output
USB Interface
GPIB Interface
AC input receptacle
Fuse box
Line voltage selector
Voltage fault (VF) output terminal
Input On/Off (ON) control terminal
External trigger input terminals
External programming input terminals
Remote sense terminals
Input Terminal (Full-rack models)
1.7 Display Overview
Figure 11 – Display Screen
80.000V
12.000A
0.0W
OFF CC CV CR CW Rmt Addr SRQ Error Trig Sense Prot Rear Auto
CC = 85.000 V
1
2
3
4
1
2
3
4 5 6
7
8
9
10
11
12
13
14
15
www.GlobalTestSupply.com
11
Display Description
Measured input voltage
Measured input power
Settings Display
Displays parameter settings such as CC, CV, CR, CW
Measured input current
OFF
Indicates input is disabled
CC
Indicates constant current (CC) operation
CV
Indicates constant voltage (CV) operation
CR
Indicates constant resistance (CR) operation
CW
Indicates constant power (CW) operation
Rmt
Indicates remote mode
Addr
Indicates remote communication activity
SRQ
SRQ service request indicator
Error
Indicates an error has occurred
Trig
Indicates waiting for trigger
Sense
Indicates remote sense enabled
Prot
Indicates protection trip for over voltage, over power, or over current
Rear
Indicates external analog control is enabled.
Auto
Indicates voltage auto range is enabled.
*
Indicates key lock is enabled
Shift
Indicates shift mode (for access to secondary button functions)
1
2
3
4
www.GlobalTestSupply.com
12
2 Getting Started
Before connecting and powering up the instrument, please review and go through the instructions in this chapter.
2.1 Input Power and Fuse Requirements
Input Power
The load has a selectable AC input that accepts line voltage input within:
Voltage: 115 V (+/-10%) or 230 V (+/- 10 %)
Frequency: 47 Hz – 63 Hz
Use the line voltage selector switch in the back to switch between 110 V and 220 V operation.
Figure 12 - Line Voltage Switch Location
110 or 220 Switch
110
www.GlobalTestSupply.com
13
Disconnect all cables including the power cord from the instrument when changing the instrument's line voltage. After changing the line voltage setting, ensure the instrument has fuses of the proper ratings and types for the selected line voltage before applying line power.
Fuse Requirements
An AC input fuse is necessary when powering the instrument. Below is a table of the fuse required for all models operating with either 110 VAC or 220 VAC input.
Table 1 - Fuse Requirements
Model
Fuse Specification (110 VAC)
Fuse Specification (220 VAC)
8600/B
T 1.25 A, 250 V
T 500 mA, 250 V
8601/B
T 1.25 A, 250 V
T 500 mA, 250 V
8602/B
T 1.25 A, 250 V
T 500 mA, 250 V
8610/B
T 3.15 A, 250 V
T 1.6 A, 250 V
8612/B
T 3.15 A, 250 V
T 1.6 A, 250 V
8614/B
T 3.15 A, 250 V
T 1.6 A, 250 V
8616
T 3.15 A, 250 V
T 1.6 A, 250 V
8620
T 3.15 A, 250 V
T 1.6 A, 250 V
8622
T 3.15 A, 250 V
T 1.6 A, 250 V
8624
T 5 A, 250 V
T 2.5 A, 250 V
8625
T 5 A, 250 V
T 2.5 A, 250 V
Fuse Replacement
Follow the steps below to replace or check the fuse.
1. Locate the fuse box next to the AC input connector in the rear panel.
2. With a small flat blade screwdriver, insert into the fuse box slit to pull and slide out the
fuse box as indicated below.
3. Check and replace fuse (if necessary) for the desired line voltage operation.
www.GlobalTestSupply.com
14
Figure 13 - Fuse Box
2.2 Input Connections
The main DC input terminal is a screw type binding post terminal located in the front panel. To loosen, turn the terminal cap counter-clock wise.
Note: The screws on the terminals can be completely removed to allow for ring type adapters (must be greater than 6mm in diameter).
Due to the high current rating of the DC load, proper wire sizes are necessary for safe connectivity and to prevent wires from overheating.
Before connecting wires to the input terminals, turn OFF the load to avoid damage to the instrument and the device under test (DUT). For safety, wires must have a wire gauge size large enough to prevent overheating when the load operates at maximum rated current. It will also minimize large voltage drops from resistances in the wires.
Fuse box slit
Fuse box
Check/Remove Fuse
www.GlobalTestSupply.com
15
2.3 Preliminary Check
Complete the following steps to verify that the load is ready for use.
1. Verify AC Input Voltage
Verify and check to make sure proper AC voltages are available to power the instrument. The AC voltage range must meet the acceptable specification as explained in “2.1 Input Power and Fuse Requirements”.
Check to verify that the unit is configured to operate at the AC input voltage level of the power source. If not, it will damage the unit and void its warranty.
2. Connect Power and Self Test
Connect AC power cord to the AC receptacle in the rear panel and press the power
switch to the |( ) ON position to turn ON the instrument. It will run through a self test procedure with the screen shown below:
Self-test Errors
The following errors will be displayed if self-test did not complete successfully:
System Selftest . . . .
. .
www.GlobalTestSupply.com
16
Table 2 - Self-test Messages
Error Message on Display
Description
EEPROM FAILURE
The internal EEPROM is corrupted or damaged.
Config Data Lost
The last operation data within the EEPROM is lost.
Calibration Data Lost
Calibration data within the EEPROM is lost.
FactoryCal.Data Lost
Factory calibration data is lost.
MainframeInitialize Lost
The system settings within the EEPROM is lost.
If any of these errors occur, please contact B&K Precision.
Input Check
Follow the steps below to check that the load is operating correctly. A DC power supply rated for at least 5V and 1 A will be required to proceed with this check.
1. Power on the load. The display will show the OFF annunciator above the voltage
display.
2. Connect the input terminal to a DC power supply and configure the supply to output 5 V
and current limit to 1 A.
3. Turn on the DC power supply’s output. Observe the load’s measured voltage display,
which should read close to or exactly 5.000V.
4. Press so that its back light turns on, and enter 0.500 A using the numeric
keypad. Press .
5. The display should show CC = 0.500A on the bottom right.
6. Press and its backlight will be lit. The OFF indicator will change to CC and the
measured current should now display a value close to 0.500 A.
7. This setup verifies that the load is drawing power correctly from the power supply.
Note: If the load is not drawing power from the DC power supply, check all load
protection limits and settings within the menu to verify that the load is configured to allow drawing power at 5V, 0.500 A. Also, verify that the CC mode parameters are setup to operate within the configured valid ranges by pressing
( ) and .
www.GlobalTestSupply.com
17
Check Model and Firmware Version
The model and firmware version can be verified by using the *IDN? query remote command. It can also be found from the front panel:
1. Press ( ) and press .
2. The display will show the following:
3. The model is shown above as 8600/B, and the firmware version is shown as 1.29-1.36.
4. Press once to return to the normal display.
8600 Ver : 1.29 – 1.36
0.000A
0.000V
www.GlobalTestSupply.com
18
3 Front Panel Operation
3.1 Menu Options
Most settings and parameters can be configured from the built-in menu systems of the instrument. There are two main menus: System and Config.
System Menu
To access the system menu, press ( ) then ( ).
The system menu will have the following options:
Initialize
Reset load settings to factory default values.
Power-On
Configure power-on state.
Buzzer
Enable/Disable key sound.
Knob
Controls update method when using knob to control load.
Trigger
Configure Trigger.
Memory
Select memory location for save/recall instrument settings.
Displ (Display)
Enable/Disable load ON timer.
Communication
Select communication interface.
Protocol
Select standard SCPI or extended set of protocols for remote communication.
Config Menu
To access the system menu, press ( ) then ( ).
The system menu will have the following options:
Von
Configures Von function
Protect
Configures protection parameters and limits
Measure
Configures measurement parameters
CR_LED
Enables/Disables CR LED function
Remote-Sense
Enables/Disables remote sense
Ext-Program
Enables/Disables external analog control
www.GlobalTestSupply.com
19
How to Navigate the Menu
Before using the instrument, it is important to be familiarized with its menu structure and learn how to view or change settings and parameters. Follow the steps below to guide you in selecting menu options.
1. Follow the instructions above to access the System or Config menu.
2. The selected item will be blinking. Use and ( or ) keys to move
through the menu selections.
3. When the desired menu section is blinking, press to access its menu settings.
4. Below is the display when SYSTEM is selected.
5. The selected item will be blinking. Use and ( or ) keys to move
through the menu items. When there is a on the right side of the display, that means there are more menu items available to select from. Similarly, a will
appear on the left side of the display when there are menu items to the left
6. There may be parameters or options to select within each menu item. Follow the same
instructions as described in the previous steps to select them. Some settings can be
changed by using ( or ) arrow keys. To save changes to a setting, press .
7. To exit the menu at any time, press .
SYSTEM MENU
Initialize Power-On
www.GlobalTestSupply.com
20
3.2 Configure Operation Modes (CC/CV/CR/CW)
The electronic load can work in the following modes:
1) Constant current (CC) operation mode
2) Constant voltage (CV) operation mode
3) Constant resistance (CR) operation mode
4) Constant power (CW) operation mode
Constant Current (CC) Mode
In this mode, the electronic load will sink a current in accordance with the programmed value regardless of the input voltage.
Configure CC Parameters
There are several parameters that should be setup prior to operating in CC mode. Press
so that it lights up, then press ( ) and to access Setup for CC
mode. The setup menu will be shown:
Constant Current
Range=60.000A
www.GlobalTestSupply.com
21
The setup parameters are: Range, High (Voltage limit), Low (Voltage limit), and Rise/Fall time.
Use the ( or ) key to select each parameter, and use the numeric keypad to
change the value. Press to confirm the change.
Range
Use the numeric keypad to change the range. This value will also act as a limit to how much current the load can be configured to. The adjustable ranges vary depending on the model. See specifications for details.
High
This parameter refers to the voltage high limit for the automatic test mode. During automatic test mode, the device under test (DUT) must be operating below the configured value for the test to PASS upon completion. If the DUT operates above the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Low
This parameter refers to the voltage low limit for the automatic test mode. During automatic test mode, the DUT must be operating above the configured value for the test to PASS upon completion. If the DUT operates below the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
High-Rate / Low-Rate
Use the and keys to select either High-Rate or Low-Rate, then press . Depending on the selection, the configurable range for the rise and fall times will be different.
Rise Up / Fall Down
These parameters define the slew rate of the load, which determines the rate at which the input current to a module changes to a new programmed value. You can set the current level’s rise/fall slew rate on the front panel or by remote operation. The programmed slew rate is immediately in effect to the triggered and transient current level changes.
www.GlobalTestSupply.com
22
Slew Rate Measurement and Actual Transition time
Current slew rate is defined as the change in current over time. A programmable slew rate allows a controlled transition from one load setting to another. The actual transition time is defined as the time for the input to change from 10% to 90%, or 90% to 10% of the programmed current values. The graph below illustrates slew rate measurements.
Figure 14 - Slew Rate Measurement
Between the 10% and 90% region, the slew rate can be measured by observing the steepest slope portion. In case of very large load changes, e.g. from no load to full load, the actual transition time will be larger than the expected (measured) time. For this reason, the firmware allows the user to program slew rate values outside of the specified slew rate ranges. The minimum transition time for all programmable slew rates is also limited in cases where the transition from one setting to another is very small, due to bandwidth limitations of the load.
www.GlobalTestSupply.com
23
Constant Voltage (CV) Mode
In this mode, the electronic load will attempt to sink enough current to control the source voltage to the programmed value.
Configure CV Parameters
There are several parameters that should be set up prior to operating in CV mode. Press
so that it lights up, then press ( ) and to access Setup for CV mode.
The setup menu will be shown:
The setup parameters are: Range, High (Current limit), and Low (Current limit). Use the
( or ) key to select each parameter, and use the numeric keypad to change the
value. Press to confirm the change.
Range
Use the numeric keypad to change the range. This value will also act as a limit to how much voltage the load can be configured to. The adjustable ranges vary depending on the model. See specifications for details.
Constant Voltage
Range=60.000V
www.GlobalTestSupply.com
24
High
This parameter refers to the current high limit for the automatic test mode. During automatic test mode, the device under test (DUT) must be operating below the configured value for the test to PASS upon completion. If the DUT operates above the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Low
This parameter refers to the current low limit for the automatic test mode. During automatic test mode, the DUT must be operating above the configured value for the test to PASS upon completion. If the DUT operates below the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Constant Resistance (CR) Mode
In this mode, the electronic load is equivalent to a constant resistance, as shown below. The electronic load will linearly change the current, according to the input voltage.
Configure CR Parameters
There are several parameters that should be set up prior to operating in CR mode. Press
so that it lights up, then press ( )and to access Setup for CR mode.
The setup menu will be shown:
www.GlobalTestSupply.com
25
The setup parameters are: Range, High (Voltage limit), and Low (Voltage limit). Use the
( or ) key to select each parameter, and use the numeric keypad to change the
value. Press to confirm the change.
Range
Use the numeric keypad to change the range. This value will also act as a limit to how much resistance the load can be configured to. The adjustable ranges vary depending on the model. See specifications for details.
High
This parameter refers to the voltage high limit for the automatic test mode. During automatic test mode, the device under test (DUT) must be operating below the configured value for the test to PASS upon completion. If the DUT operates above the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Low
This parameter refers to the voltage low limit for the automatic test mode. During automatic test mode, the DUT must be operating above the configured value for the test to PASS upon completion. If the DUT operates below the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Constant Power (CW) Mode
In this mode, the electronic load will consume a constant power. When input voltage increases, the input current will decrease, while power (P = V*I) will remain the same.
Constant Resistance
Range=7500.0Ω
www.GlobalTestSupply.com
26
Configure CW Parameters
There are several parameters that should be set up prior to operating in CW mode. Press
so that it lights up, then press ( )and to access Setup for CW
mode. The setup menu will be shown:
The setup parameters are: Range, High (Voltage limit), and Low (Voltage limit). Use the
( or ) keys to select each parameter, and use the numeric keypad to change the
value. Press to confirm the change.
Range
Use the numeric keypad to change the range. This value will also act as a limit to how much power the load can be configured to. The adjustable ranges vary depending on the model. See specifications for details.
High
This parameter refers to the voltage high limit for the automatic test mode. During automatic test mode, the device under test (DUT) must be operating below the configured value for the
Constant Power
Range=250.00W
www.GlobalTestSupply.com
27
test to PASS upon completion. If the DUT operates above the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Low
This parameter refers to the voltage low limit for the automatic test mode. During automatic test mode, the DUT must be operating above the configured value for the test to PASS upon completion. If the DUT operates below the configured value, the test will FAIL upon completion.
Note: This parameter is used for Automatic Test Function ONLY.
Setting CC, CV, CR, CW Mode
Follow the steps below to configure the mode and enable the load.
1. Press / / / (for CC/CV/CR/CW mode) so that it lights up.
2. Use the numeric keypad or the rotary dial to enter the desired setting value.
3. Use the and ( or ) keys to change the cursor position to adjust
different digits.
4. Press to enable the input.
3.3 SYSTEM Menu
All setup procedures and settings explained in this section can be accessed from the SYSTEM
menu. To access this menu, press ( ) and ( ).
www.GlobalTestSupply.com
28
Restore Factory Default Settings
All instrument settings can be reset back to their factory default values by doing the following:
Note:
Restoring the instrument to factory default will change all current instrument settings and parameters back to their default values.
1. From the SYSTEM menu, select Initialize and press .
2. The following screen will display. Select Yes to restore default settings, or No to cancel.
The following table lists some of the factory default settings.
Table 3 - Factory Default Settings
Communication
RS232 (4800, 8, N, 1, NONE)
Display On Timer
Off
Trigger Source
Manual
Protocol
SCPI
Von
Latch
A-Limit
Off
SYSTEM MENU
Initialize Power-ON Buzzer
INITIALIZE SYSTEM?
NO YES
www.GlobalTestSupply.com
29
Memory
Group 0
Power-On
RST
Buzzer
On
Load On Knob
Update
On Timer
Off
Voltage Auto Range
On
Averaging Filter
2^14
Remote Sense
Off
External Program
Off
Configure Power-On State
The initial Power-On state of the load can be configured by following the steps below:
1. From the SYSTEM menu, select Power-On and press .
2. There are two options:
Rst(Def) – Factory Default. Sav0 – Settings before last power up. Recalls the settings saved to “0” memory location.
3. Select the settings you want during power up, and press to save changes.
4. To exit the menu at any time, press twice.
Load On Knob
This setting controls the behavior of the knob.
1. From the SYSTEM menu, select Knob and press .
2. There are two options:
Update(default) – Real time update. Old – No update (when turning load ON/OFF, original value before use of rotary knob
will be set)
3. Select the settings you want during power up and press to save changes.
4. To exit the menu at any time, press twice.
www.GlobalTestSupply.com
30
Configure Trigger Source
The trigger function is used to initiate the start of a program in list mode and also as a toggle for transient mode. The trigger source can be set so that users can send a trigger from the front panel, through a remote command via remote interface or through the external trigger input in the rear panel. Follow the steps below to configure the trigger mode:
1. From the SYSTEM menu, browse and select Trigger and press .
2. Here are the options:
Manual(Def) – Manual trigger. Front panel trigger button is used to send a trigger
(press and (or press ) to send trigger). External – External trigger. Trigger can be sent by connecting the Trig input and the ground input together in the rear panel. A TTL signal may also be used as a trigger signal when sent across these terminals. If using a TTL signal, the unit triggers off of a falling edge.
NOTE:
Signal pulse width must be > 10 µs.
Hold – Hold trigger. This behaves similarly to Bus trigger, however the TRIG:IMM
command is used instead. Bus – Bus trigger. Remote commands *TRG and TRIG:IMM can both be used to send a trigger. With Bus trigger, multiple devices can be triggered at the same time when communicating via GPIB (non-B series only) interface. Timer – Timer trigger. A trigger will be sent periodically based on the set time. Time can be set from 0.01 s to 9999.99 s.
3. Select one of the options. For timer trigger, use the numeric keypad or rotary knob to
set the time.
Rear Panel Terminals
www.GlobalTestSupply.com
31
4. To exit the menu at any time, press twice.
Save/Recall Instrument Settings
The instrument can save up to 100 instrument settings in non-volatile memory. Memory is allocated in 10 different storage groups (group 0 to 9), and each group has 10 memory locations to store settings (0 to 9). These memory locations are referenced by numbers 1 – 100. When saving an instrument setting, numbers 1 to 100 can be selected. However, when recalling an instrument setting, the group must be selected first and then the numeric keypad buttons 1 through 9 and 0, which refers to the 10 locations of the selected storage group. Below is the table illustrating the storage group and allocated memory locations.
Table 4 - Save/Recall Storage Group
Storage
Group
Corresponding memory
locations for save operation
0
1 – 10
1
11 – 20
2
21 – 30
3
31 – 40
4
41 – 50
5
51 – 60
6
61 – 70
7
71 – 80
8
81 – 90
9
91 - 100
When recalling settings, each of the numeric keypad numbers corresponds to the memory locations based on the storage group selected according to the table above. For storage group
0, recalling memory location 1 is done by pressing ; location 2 is done by pressing ,
and so on. Memory location 10 is recalled by pressing . For storage group 1, recalling
memory location 11 by pressing , location 12 by pressing , and so on.
www.GlobalTestSupply.com
32
Example:
Settings are saved to memory location 60. To recall those settings, set storage group to 5 from
the menu, then press recall and the number .
Select Storage Group
1. From the SYSTEM menu, browse and select Memory and press . The following
screen will appear.
2. Use the current adjust knob or the numeric keypad to enter the storage group. Select
between 0 – 9. Press to save selection.
3. To exit the menu at any time, press twice.
NOTE:
The storage group setting also affects the automatic test function of the load. Refer to “Automatic Test Function” for more details.
Save Settings
1. Set up all the instrument settings that you want to save.
2. Then, press ( ) and . The display will show the following:
MEMORY
Group = 0
www.GlobalTestSupply.com
33
3. Use the current adjust knob or the numeric keypad to enter the memory location in
which to store current instrument settings. Select between 0 – 100. Press to save to the selection location.
NOTE:
The “0” memory location is reserved for storing instrument settings last configured before power-off and is used only for power-on state configuration only.
Recall Settings
1. First, consider the memory locations you want to recall from. As they are grouped
together, select the appropriate storage group from the SYSTEM menu first by following the instructions in previous section.
2. Once selected, press and (or press ) and it will light up to indicate
the instrument is in Recall mode.
3. Use the keypad numbers to recall the settings from the corresponding memory location
referenced by the storage group selected in Step 1.
4. Once entered, the saved settings at the location will be immediately recalled.
Note: When in Recall mode, users can recall settings from different locations
without having to press additional keys each time. For example, you can press 1 to recall settings in location one, and then press 5 to recall settings in location 5 on the fly.
5. To exit Recall mode, press .
80.000V
12.000A
0.00 W Save 1
www.GlobalTestSupply.com
34
Display Input On Timer
The instrument has an internal timer that counts how long the input has been enabled (ON). Follow the steps below to enable the timer display.
1. From the SYSTEM menu, browse and select Displ and press . The following
screen will appear.
2. Select On to enable the timer, and Off (default) to disable. Press to confirm.
3. Press twice to exit the menu. The timer will now be displayed like the following:
4. When input is enabled (ON), the timer will start counting the time. When input is
disabled (OFF), the timer will reset itself to a value close to 0 seconds.
Remote Interface Setup
The instrument has RS232, USBTMC, and GPIB (non-B series only) remote interfaces available for remote communication. Follow the steps below to select and configure each interface.
DISPLAY ON TIMER
On Off(default)
80.000V
12.000A
0.00 W 0.0000 S CC = 1.000A
www.GlobalTestSupply.com
35
Note: The RMT indicator will appear on display when the instrument is successfully connected to a PC remotely through any remote interface. Keys on the front panel will be locked until the
instrument is in LOCAL mode. To return to LOCAL mode from the front panel, press
( and then ) . The RMT indicator will disappear when the instrument is in LOCAL mode.
From the SYSTEM menu, browse and select Communication and press . The following screen will appear.
RS-232
Follow the steps below to configure the instrument for RS-232 operation:
1. Select RS-232 and press to set to RS-232 for remote communication. The
following display will be shown:
2. 4800 is the baud rate; 8 is the data bits; N is the parity; 1 is the stop bit; Addr… is for
address.
3. Use the and ( or ) keys to select between each serial settings, and use
( or ) keys to change the settings.
4. The following setting options that can be used:
Baudrate: 4800, 9600, 19200, 38400, 57600, 115200* Data bits: 8
COMMUNICATION
RS232 USBTMC GPIB
RS232
4800 , 8 , N , 1 , NONE
www.GlobalTestSupply.com
36
Parity: N (None), E (Even), O (Odd) Stop bit: 1 Flow control: NONE, CTS/RTS, XON/XOFF
Note: The default is 4800, 8, N, 1, NONE.
*Setting the baud rate to 115200 may provide unstable results during remote communication. Select a lower baud rate if communication errors occur.
5. All serial settings must match with the settings configured on the PC in order for
communication to link successfully.
USBTMC
A USB Type A to Type B cable (i.e. USB printer cable) is required to connect the USB port in the rear panel to a PC. Follow the steps below to setup the load for remote communication.
1. From the SYSTEM menu, browse and select Communication and press .
2. Select USBTMC and press to set USBTMC for remote communication.
3. Install the USB driver. For Windows® 7 and 8 users, this may install automatically. For
other users, visit www.bkprecision.com to download the driver.
Note: Users who have LabVIEW™ or NI-VISA installed will automatically have
this driver in their system. In this case, driver download is not required.
GPIB (non-B series only)
Follow these instructions to select GPIB interface for remote operation.
1. From the SYSTEM menu, browse and select Communication and press .
2. Select GPIB and press to set to GPIB for remote communication.
3. The load will give a prompt to select an Address. This is the GPIB address to which the
instrument will be assigned to.
4. Use the current adjust knob or the numeric keypad to enter an address from 0 – 31.
5. Press to save the selected address and the display will return to the
Communication menu.
www.GlobalTestSupply.com
37
3.4 CONFIG Menu
All setup procedures and settings explained in this section can be accessed from the CONFIG
menu. To access this menu, press ( ) and ( ). The following screen will show:
Von Operation
The Von voltage value can be set to control the voltage turn on state for the electronic load. When the input voltage exceeds the Von voltage value, the electronic load’s input state turns on.
This function can protect a DUT when its voltage goes below a specified level. For example, when testing a power supply’s discharge characteristics, you can set the Von voltage level start and stop discharging of the power supply.
Note: Von Operation will have a short delay (< 1 s) from when a condition exceeds or goes below a specified level to when the load’s input state changes.
When Von Latch is ON, the electronic load will begin sinking current if input voltage exceeds Von voltage. When the input voltage drops below the Von voltage value, the electronic load will stop sinking current and the input will turn off.
CONFIG MENU
Von Protect Measure CR_LED
www.GlobalTestSupply.com
38
Figure 15 - The Load's Operating Range with Von Latch set to ON
When Von Latch is OFF, the electronic load will begin sinking current if the input voltage exceeds the Von voltage. When the input voltage drops below the Von voltage value, the electronic load will still continue sinking current and the input remains on.
www.GlobalTestSupply.com
39
Figure 16 - Von Latch OFF The Load's Operating Range with Von Latch set to OFF
To set the Von modes, from the CONFIG menu, select Von and press . The following will be displayed:
Use the and ( or ) keys to select between On or Off and press confirm selection. Afterwards, you will be prompted to enter the voltage point of Von. Use the numeric keypad or rotary knob to change this value.
VON LATCH
On Off
www.GlobalTestSupply.com
40
Configure Protection Settings
The electronic load has the following protection functions: Overvoltage protection (OVP), overcurrent protection (OCP), overpower protection (OPP), overtemperature protection (OTP), and local and remote reverse voltage protection (LRV/RRV).
The instrument will act appropriately once any of the above protections are active. You can press any button on the front panel to restore the protection function. For example, if the electronic load triggers the overtemperature protection, the buzzer will alarm, the input will automatically turn off, and the mainframe VFD will display OTP.
Some OCP and OPP features can be configured from within the Protect menu. To access this menu, go into CONFIG menu and select Protect. The following display will show:
Overcurrent Protection (OCP)
The electronic load includes both hardware and software overcurrent protection features.
Hardware OCP - The electronic load’s maximum input current will be limited to approximately 110% of the current range. Once the hardware OCP is triggered, the status register’s OC bit will be set. When the hardware OCP is removed, the status register’s OC bit will be reset. Hardware overcurrent protection will not affect the electronic load’s input on/off state.
Software OCP - Users can set the electronic load’s software OCP value with the following steps.
1. Go to CONFIG menu and select Protect. Then press .
2. Select A-limit and press .
3. To enable software OCP, select On and press . The default is Off.
4. If enabled (ON), the load will prompt to enter a value for Point. Use the numeric keypad
or rotary knob to enter the OCP current limit value, then press . The valid range depends on the model of the load.
PROTECT MENU
Max-P A-Limit P-Limit Time
www.GlobalTestSupply.com
41
5. It will then prompt to enter a value for Delay. This is the protection trip delay, which is
the amount of time to delay from when the input has reached the limit before triggering OCP. Use the numeric keypad or rotary knob to enter a value, then press to
confirm change. The valid range is 0 – 60 seconds.
NOTE:
Software OCP will disable the input if the input current has reached or exceeded the protection limits.
Operations to Clear the OCP State
Check whether the input current is within the electronic load’s rated current or the
programmed protection current ranges. If it is outside the range, disconnect the device under test. Then press any key on the front panel or remotely send SCPI command PROTection:CLEar. The OCP displayed on the front panel will turn off and the load exits OCP protection state.
Overpower Protection (OPP)
The electronic load includes both hardware and software OPP features.
Hardware OPP – In the event that the electronic load’s input power exceeds the set power protection limit, the hardware OPP will limit the power. Once the hardware OPP is triggered, the status register’s OP bit will be set. When the hardware OPP is removed, the status register’s OP bit will be reset. Hardware overpower protection will not turn the electronic load’s input off.
Follow the steps below to set the hardware OPP limit.
1. Go to CONFIG menu and select Protect. Then press .
2. Select Max-P and press .
3. The load will prompt to enter a value for Point. This is the hardware OPP limit value.
Use the numeric keypad or rotary knob to enter a value. Press to confirm the change.
www.GlobalTestSupply.com
42
Software OPP - Users can set the electronic load’s software OPP value with the following steps.
1. Go to CONFIG menu and select Protect. Then press .
2. Select P-limit and press .
3. To enable software OPP, select On and press . The default is Off.
4. If enabled (ON), the load will prompt to enter a value for Point. Use the numeric keypad
or rotary knob to enter the OPP power limit value, then press . The valid range depends on the model of the load.
5. It will then prompt to enter a value for Delay. This is the protection trip delay, which is
the amount of time to delay from when the input has reached the limit before triggering OPP. Use the numeric keypad or rotary knob to enter a value, then press to
confirm change. The valid range is 0 – 60 seconds.
Operations to Clear the OPP State
Check whether the input power is within the rated power range or the programmed protection ranges. If it is outside the range, disconnect the device under test. Then press any key on the front panel or remotely send command PROTection:CLEar. The OPP displayed on the front panel will turn off and the electronic load exits OPP protection state.
Overvoltage Protection (OVP)
The instrument’s maximum OVP limit is 110% of the maximum rated voltage.
If the OVP circuit has triggered, input will turn off, buzzer alarm will go off, and the status register’s OV and VF bit will be set. The mainframe will display OVP and the condition will remain until they are reset. Once overvoltage protection occurs, the VF pin on the rear panel will output TTL Low voltage level. Under normal conditions, it outputs a 5 V TTL high signal.
Operations to Clear the OVP State
Check whether the input voltage is within the electronic load’s rated voltage or the
programmed protection voltage ranges. If it is outside the range, please disconnect the device under test. Then press any key on the front panel or remotely send SCPI command PROTection:CLEar. The OVP displayed on the front panel will turn off and the electronic load exits OVP protection state.
www.GlobalTestSupply.com
43
Overtemperature Protection (OTP)
There is an overtemperature protection circuit, which will turn off the input if the internal temperature exceeds safe limits. When the electronic load’s internal circuit temperature is over
85C, the load will enable OTP. Input will automatically be turned off and the VFD will display OTP. At the same time the OT and PS bits in the status register will be set and remain until they are reset.
Operations to Clear the OTP State
When the electronic load temperature has dropped below the protection point, press any key on the front panel or remotely send command PROTection:CLEar. The OTP displayed on the front panel will turn off and the electronic load exits OTP protection state.
Reverse Voltage Protection (LRV/RRV)
This function protects the electronic load in case the input DC voltage lines are connected with the wrong polarity. When a reverse voltage (LRV – local reverse voltage, RRV – remote reverse voltage) connection condition is detected, the input will immediately turn off, the buzzer will alarm the user, and the status register’s reverse voltage (LRV/RRV) and VF bits will be set. The load will display LRV/RRV until they are reset.
In this condition, the VF pin will output a low level.
Operations to Clear the Reverse Voltage State
Check whether the connection is reversed. If so, disconnect the device to be measured and the reverse voltage state will be cleared.
www.GlobalTestSupply.com
44
Configure Timed Input
The load has a built-in timer function that can be configured to allow enabling (ON) the main input for a specified amount of time. To configure this time, follow the steps below:
1. Go to CONFIG menu and select Protect. Then press .
2. Select Time and press .
3. To enable timed input, select On and press . The default is Off.
4. It will then prompt to enter a value for Delay. This is the amount of time to enable the
input from when the is pressed (or when input is turned ON remotely). Once this time is past, input will be disabled (OFF). Use the numeric keypad or rotary knob to
enter the value. Press to confirm the change. The valid range is 0 – 60000 seconds.
5. Now, press twice to exit the menu. The instrument will show the delay timer as
follows:
Measurement Configurations
Voltage Auto Range
By default, the load has auto range enabled for voltage measurements and operations. To enable or disable, follow the steps below:
1. Go to CONFIG menu and select Measure and press .
2. Select V-Range and press .
80.000V
12.000A
0.00 W 60000.0S CC = 1.000A
www.GlobalTestSupply.com
45
3. To enable voltage auto range, select On and press . To disable, select Off and
press to confirm the change.
Measuring Rise and Fall Time
The instrument can measure the rise or fall time from a specified start and stop voltage level of the measured input. This feature requires the display timer to be enabled first. To enable timer, please follow the instructions in the “Display Input On Timer” section of “3.3 SYSTEM Menu”.
To setup this measurement, follow the steps below:
1. Go to CONFIG menu and select Measure. Then press .
2. Select TimeV1 and press . The load will prompt to enter a value. Use the
numeric keypad or rotary knob to set a value and press to confirm. This is for the start voltage level. When the measured input voltage reaches this level, the timer will start.
3. Now, select TimeV2 from the Measure menu and press . The load will prompt to
enter a value. Use the numeric keypad or rotary knob to set a value and press to confirm. This is for the stop voltage level. When the measured input voltage reaches this level, the timer will stop. The time on display will show the time difference between the measured start and stop voltage level.
Measurement Averaging Filter
The measurement averaging filter can be adjusted. Increasing the averaging will provide more accurate readings, but slower measurement update rate. Decreasing the averaging will provide faster measurement update rate, but less accurate readings.
To configure, follow the steps below:
4. Go to CONFIG menu and select Measure. Then press .
5. Select Filter and press . The load will prompt to enter a value for Average Count.
6. Use the numeric keypad or rotary knob to adjust this value, then press to save
the change. The valid range is from 2 – 16 (2^2 – 2^16). The default is 14 (2^14).
www.GlobalTestSupply.com
46
CR LED Function
CR LED is a function that allows the instrument to simulate the loading behavior of typical LEDs, which can be used for testing LED drivers. When the function is enabled, the load allows the user to configure the LED’s operating resistance and forward voltage along with the voltage range (same as CR operation). Below illustrates the V-I characteristics curve of a typical LED.
Figure 17 - CR LED IV Characteristics Curve
Vd = Forward voltage of the LED Rd = LED’s operating resistance Vo = Operating voltage across the LED Io = Operating current across the LED
To configure CR LED function, follow the steps below:
1. Press ( ) and ( ) to access the CONFIG menu.
2. Select CR_LED and press .
3. Select On and press . Press to exit the CONFIG menu.
4. Press to enter CR operation, then press ( ) and to access CR
mode settings.
I
V
Io
Vo
Rd
Vd
www.GlobalTestSupply.com
47
5. Use the numeric keypad or rotary knob to enter the values for Range, Voltage High,
Voltage Low, and Vd. Vd will be the forward voltage of the LED you want to simulate. This option will only appear after CR_LED has been enabled from the CONFIG menu.
6. While in CR mode, use the numeric keypad or rotary knob to enter a value for Rd, the
resistance.
7. Now that both Vd and Rd are configured, turn ON the input by pressing .
Remote Sense
Remote sense can be used to compensate for voltage drops (up to 1 V) due to resistance from test leads connected to your device under test (DUT), thus providing more accurate voltage measurement. The instrument is setup with remote sense disabled by default.
To enable and use remote sense, follow the steps below:
1. Power OFF the load and disconnect all leads/cables connected to it.
2. Connect the sense terminals in the rear panel to the DUT source terminals.
3. Then, connect the DUT source terminals to the load’s main input terminals. The setup
should look like the figure below:
Figure 18 - Remote Sense Connection Setup
Half-rack models
Rear Panel Terminals
DUT
+
-
www.GlobalTestSupply.com
48
7. To enable remote sense, go to CONFIG menu and select Remote-Sense and press
.
8. Select On to enable or Off to disable remote sense. The default is Off.
9. Once it is turned on, the Sense annunciator will appear at the top of the display.
The electric potential on the positive terminal of Sense+ connector must be higher than the negative terminal.
External Analog Control and Monitor
External Current Control
You can control the current setting of the electronic load in CC mode using the external analog programming terminals labeled EXT PRG. A 0-10 V input signal will simulate 0 – full scale of the electronic load to regulate the input current of the electronic load (10V indicates the full range of electronic load’s current rating).
To configure this function, follow the steps below:
1. Go to CONFIG menu and select Ext-Program and press .
2. Select On to enable external analog control. Then press to confirm. To disable,
select Off and press .
3. The Rear annunciator will appear on the front panel once external analog control is
enabled.
80.000V
12.000A
0.00 W 60000.0S CC = 1.000A
S e ns e
www.GlobalTestSupply.com
49
4. Connect the external analog control pins from the rear panel of the instrument to your
voltage control source as shown below:
Figure 19 - Analog Control Setup
5. Set the instrument to CC mode and enable the input to begin controlling with the
external voltage source.
Do not connect more than 30 V into the external program terminal pins or damages may occur.
External Input On/Off Control
The electronic load’s input can be enabled (ON) or disabled (OFF) via the external control pins
labeled ON and ground pin ( ).
Enable (ON) input: Short the two pins together, as shown below:
Rear Panel Terminals
0 – 10 V
External Voltage Source
Rear Panel Terminals
www.GlobalTestSupply.com
50
Disable (OFF) input: Disconnect the short between the two pins.
Note: The external analog control does not have to be turned ON from the menu for
these pins to function as intended. To avoid accidentally turning ON the load’s
input, keep these pins opened with nothing connected when external On/Off control is not used or needed.
Voltage Fault Indicator
The terminal pin labeled VF in the rear panel outputs a 5 VDC signal under normal operations. When OVP, LRV, or RRV conditions occur, the pin will output 0 VDC to indicate the protection trip.
Current Monitor
The rear panel has a BNC output labeled I Monitor for current monitoring. It will output a 0-10 V analog signal which reflects 0 - full range of the input current accordingly. You can connect an external voltmeter or an oscilloscope to display the input current’s change.
3.5 Short Operation
The electronic load can simulate a short circuit at its input. During front panel operation, press
( ) and then to switch the short on/off state. Short operation will not affect the
present setting. When turning off the short state, the load returns to the original set state.
The actual value of the electronic load in short operation depends on the mode and range that is active when the short is turned on. In CC or CR mode, the maximum short current is typically 110% of the current range. In CV mode, short means setting the load’s constant voltage to be 0 V. In short operation mode, you can measure the maximum short current (Amax) or DC current (ADC) of the power source to be measured. You can set this function via the Configuration menu.
www.GlobalTestSupply.com
51
3.6 Transient Operation
Transient operation enables the module to periodically switch between two load levels, as might be required for testing power supplies or other DC sources. There are three different transient testing modes: continuous, pulse, and toggle.
Continuous
Generates a respective pulse stream that toggles between two load levels.
Pulse
Generates a load change that returns to its original state after some time period.
Toggle
Generates a repetitive pulse stream that toggles between two load levels. It is similar to continuous mode except that the transient points are controlled by explicit triggers instead of an internal transient generator.
Continuous
In this mode, the electronic load generates a repetitive pulse stream that toggles between two load levels. Load could switch the state between two value settings, value A and value B.
In CC mode, transient testing can be used to check the stability of the source voltage. Transient functions have two current levels (A level, B level), which should be in the same range (high range or low range). You can set the frequency as well as the duty cycle, which will affect the timing and width of each level.
The slew rate determines the rate at which the level changes. Upon receiving a trigger, and the load will continuously switch between the A/B levels preset. Transient loads are usually used to test the power supply’s performance under continuous changing load conditions. Figure 20 shows the current waveform of continuous transient operation mode.
www.GlobalTestSupply.com
52
Figure 20 - Continuous Transient Operation Current Waveform
Pulse
In this mode, the electronic load generates a transient pulse of programmable width when pulse transient operation is in effect.
In pulse mode, you can set A/B level, the pulse width, and A/B slew rate. The electronic load will automatically switch to A level after maintaining A width time. Then it will switch to B level. The electronic load will not switch to A level again until the instrument receives a trigger signal. The following figure shows the current waveform in pulse transient operation.
Figure 21 - Pulse Transient Operation
Toggle
In toggle mode, the electronic load will switch between A level and B level when receiving a trigger signal. The following picture shows the current waveform in toggle transient operation.
www.GlobalTestSupply.com
53
Figure 22 - Toggle Transient Operation
To enable and setup transient mode, follow the steps below:
1. First, select the load’s mode of operation, which will determine which type of transient
operation will be configured. Press or to select between CC, CV, CW, or CR mode. Verify the selection by the backlight behind its corresponding button, which will be lit when selected.
2. From the front panel, press and then (or press ). The following display
will show:
3. To enable transient operation, select On and press . The following display will
show:
TRANSITION
On Off
www.GlobalTestSupply.com
54
4. Select the transient mode Continuous, Pulse, or Toggle. Press .
5. For CC mode, the following display will show. For all other modes, skip to step 9.
6. Select either High-Rate or Low-Rate. These options configure the settable slew rate
range. If High-Rate is selected, users can adjust the slew rate of the transient in the A/us range. If Low-Rate is selected, users can adjust the same in A/ms range. The settable range will vary depending on the model.
7. The load will then prompt to enter a value for Rise Up, which is the slew rate for a rising
transition between the two levels of the transient. Use the numeric keypad or rotary knob to set the value, then press to confirm.
8. The load will then prompt to enter a value for Fall Down, which is the slew rate for the
falling transition between the two levels of the transient. Use the numeric keypad or rotary knob to set the value, then press to confirm.
9. The load will then prompt to enter a value for Level A. This is one of the two load levels
for transient operation, and as such will be labeled as level A. Enter a value within the
load’s full range, then press . The next prompt will ask to enter a value for Level B, which is the other load level for transient operation. Enter a value and press .
10. For Continuous mode: The load will prompt to enter the transient’s Frequency. Enter a
value and press . It will then prompt to enter the Duty cycle. Enter a value between 0.01% and 99.99%.
For Pulse mode: The load will prompt to enter the Pulse Width. Enter a value, then press .
TRANSITION
Continuous Pulse Toggle
TRANSITION
High-Rate Low-Rate
www.GlobalTestSupply.com
55
11. The load will return to the Transient menu. Press to return to the normal display.
The Trig annunciator will appear and the display will look like below.
12. Depending on the selected Trigger Source from within the SYSTEM menu, the operation
may start immediately.
13. To run the transient operation, first press to enable the input. Then, send a trigger
to start the operation. If Trigger Source is set to Manual, press and then (or press ) to send a trigger. Refer to “Configure Trigger Source” in section “3.3
SYSTEM Menu” to configure the Trigger Source.
Note: The number next to TRAN on display will count each transition. It can only count
up to 65535 transitions, after which it will reset to 0 and start over.
14. To disable transient operation, first press to disable the input. Then, press
and (or press ). Select Off and press to confirm.
80.000V
12.000A
0.00 W 00000.0S 1 TRAN
T r ig
www.GlobalTestSupply.com
56
3.7 List Operation
List mode lets you generate complex sequences of input changes with rapid, precise timing. This is useful when running test sequences with a minimum amount of overhead.
The parameters of List operation include the name, number of steps (2-84), step width time (20us-3600s), and every steps’ set value and slew rate. The list file can be saved in non-volatile memory where it can be quickly recalled. Users can edit up to 7 groups of List files in CC mode only.
In List operation mode, the electronic load begins to enable the List operation when it receives the trigger signal and will continue until the List operation is completed or the instrument receives another trigger signal.
List Sequence
Figure 23 - List Mode Current Waveform
www.GlobalTestSupply.com
57
Configure List
Follow the steps below to configure list operation:
1. From the front panel, press and then (or press ). The following
display will show:
2. Select Edit and press . The following display will show:
3. Select either High-Rate or Low-Rate. These options configure the settable slew rate
range. If High-Rate is selected, users can adjust the slew rate of the transient in the A/us range. If Low-Rate is selected, users can adjust the same in A/ms range. The settable range will vary depending on the model.
4. The load will then prompt to enter a value for Current Range. Use the numeric keypad
or rotary knob to set the value for current range, then press to confirm.
5. The load will then prompt to enter a value for File Step, which is the total number of
steps for the list. Use the numeric keypad or rotary knob to set the value, then press
to confirm. Valid range is 2 – 84.
6. The load will prompt to enter values for each steps parameters, starting with the step
level. Use the numeric keypad or rotary knob to enter a value.
LIST
On Recall Edit
EDIT LIST
High-Rate Low-Rate
www.GlobalTestSupply.com
58
7. Press and it will prompt to enter the slew rate of the step. If High-Rate was
selected earlier, units will be in A/us. Otherwise, it will be in A/ms.
8. Press and it will prompt to enter the step with. Valid range is 20 us – 3600 s.
Enter a value and then press to continue.
9. The load will prompt to enter parameters for the next step. Follow steps 6-8 to enter
the values for the step’s parameters. Once all steps’ parameters are entered, the load will prompt for the Repeat Count, which sets how many times to repeat the list
program. Valid range is 1 – 65535. Press to continue.
10. The load will prompt to select the memory location to store the list parameter
information. There are seven total save locations. Enter a value between 1 and 7, then press to confirm. The display will return to the List menu.
Note: If List mode is enabled, the Edit menu will be locked and list parameters cannot be
changed until List mode is disabled.
EDIT LIST
Step 001 Level = 0.0000A
EDIT LIST
Step 001 Rate = 0.0001A/us
EDIT LIST
Step 001 Width = 0.00002S
www.GlobalTestSupply.com
59
Run List
To run a list, follow the steps below:
1. From the List menu, select Recall and press . The load will prompt for the
memory location of the list to recall. Enter between 1 – 7 and press to recall.
2. Then, select On and press . The Trig annunciator will appear, and the On
selection will become Off.
3. Press to go back to the normal display, which will then look like the following:
4. Press to enable (ON) the load’s input, and send a trigger to initiate the start of
the list program.
5. If Trigger Source is set to Manual, press and then (or press ) to send a
trigger. Refer to “Configure Trigger Source” in section “3.3 SYSTEM Menu” to configure the Trigger Source.
Note: The number next to LIST on the display shows the current running step number.
When the list ends, it will change back to “0”.
Note: If List mode is enabled, the Recall menu will be locked and list parameters cannot
be changed until List mode is disabled.
Note: At the end of a list operation, the load’s input does not disable automatically and
will continue to draw power at the list’s last step value until is pressed to
disable the input or if controlled remotely, the input OFF command is sent at the end.
80.000V
12.000A
0.00 W 00000.0S 0 LIST 1
T r ig
www.GlobalTestSupply.com
60
6. To disable list operation, first press to disable the input and then press and
(or press ). Select Off and press to confirm. The Trig annunciator will
disappear when list operation is disabled.
3.8 Battery Test Function
The load has a built-in battery test function that uses CC mode and calculates the battery capacity using a fixed current load. The test’s stop conditions can be specified by the following:
Stop Voltage: Set a cut-off voltage level. When this level is reached, the test will end. Valid range: 0 V – max. rated voltage.
Stop Capacity: Sets a capacity level. When the calculated capacity reaches this level, the test will end. Valid range: 0 Ah – 999.99 Ah
Stop Timer: Sets a timer. When the specified time is reached, the test will end. Valid range: 0 s – 99999 s.
During operation, the load will sink current at the specified level while measuring and updating the capacity value in amp-hours (Ah) and tracking the time period of the test. When any one of the three stop conditions above is met, the test will end, and the display will show the measured capacity and time results.
To setup and run the battery test function, follow the steps below:
1. Disable the input of the load and connect it to the battery to be tested.
2. Press and use the numeric keypad or rotary knob to enter a current sink value
for the test. Press .
3. Press ( ) and ( ) to configure and enable the battery test function.
4. The load will prompt to enter all three test stop conditions, starting with Stop Voltage
value. Use the numeric keypad or rotary knob to enter a voltage level. Then press
to continue.
5. The load will prompt to enter the Stop Capacity. Use the numeric keypad or rotary
knob to enter a capacity value in Ah. Then press to continue.
www.GlobalTestSupply.com
61
6. Lastly, it will prompt to enter the Stop Timer. Use the numeric keypad or rotary knob to
enter a time value in seconds. Then press to finish the setup.
7. The display will then show the following:
8. To start the battery test, press ( ) once. The input will automatically be
enabled (ON) with the button’s backlight lit. The timer on the display will run continuously and Ah measurement will update through time. The test will continue to run until one of the three stop conditions is met.
3.9 Test Operations
Automatic Test Function
The automatic test function of the load is useful for simulating various tests and allows the user to edit up to 10 program files. Each file has 10 steps and up to 100 steps can be edited and saved into the EEPROM. Convenient for production environments, automatic test can cascade sequences across multiple channels and allows setting of Pass/Fail (P/F) criteria.
Setting Up Program Files
Configuring Pass/Fail Parameters
The Pass/Fail criteria can be found in the SETUP menu of the front panel, under the high/low parameters. Users must set pass/fail criteria for each mode (Configure CC Parameters, Configure CV Parameters, Configure CR Parameters, and/or Configure CW Parameters) used in
10.000V
0.000A
0.00 W 0.0S 0.000Ah
OFF CC
www.GlobalTestSupply.com
62
the Automatic Test sequence, prior to running the automated test. Please see the Configure CC Parameters, Configure CV Parameters, Configure CR Parameters, and/or Configure CW Parameters configuration sections to set these parameters.
Configuring Instrument Settings
The automatic test runs a program that uses the settings stored into the internal EEPROM memory.
Each program can run 10 sequences, and each of these sequences is correlated to instrument settings that are stored within a designated group of internal EEPROM memory. They are designated according to the table below:
Table 5 - Program Save Group/Sequence Association
PROGRAM 1 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
1 2 3 4 5 6 7 8 9
10
PROGRAM 2 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
11
12
13
14
15
16
17
18
19
20
PROGRAM 3
1 2 3 4 5 6 7 8 9
10
Save Group
21
22
23
24
25
26
27
28
29
30
PROGRAM 4 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
31
32
33
34
35
36
37
38
39
40
PROGRAM 5 Sequence
1 2 3 4 5 6 7 8 9
10
Save Group
41
42
43
44
45
46
47
48
49
50
PROGRAM 6 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
51
52
53
54
55
56
57
58
59
60
PROGRAM 7 Sequence
1 2 3 4 5 6 7 8 9
10
Save Group
61
62
63
64
65
66
67
68
69
70
PROGRAM 8 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
71
72
73
74
75
76
77
78
79
80
www.GlobalTestSupply.com
63
PROGRAM 9 Sequence
1 2 3 4 5 6 7 8 9
10 Save Group
81
82
83
84
85
86
87
88
89
90
PROGRAM 10 Sequence
1 2 3 4 5 6 7 8 9
10
Save Group
91
92
93
94
95
96
97
98
99
100
Example:
In Program 1, sequence 1 correlates to instrument settings stored in memory location 1.
In Program 5, sequence 5 correlates to instrument settings stored in memory location 45.
In Program 8, sequence 10 correlates to instrument settings stored in memory location 80.
Within each program, sequences can be activated or deactivated (skipped), but they run in order from 1 through 10. Therefore, when setting and storing instrument settings into the memory, keep in mind the order of which you want them to be recalled and run in the automatic test program.
For example, suppose you want to run a test program that simulates the load profile below:
Configure and save settings into memory according to the table below:
Settings
Store to Memory location
Mode of Operation
Setting Value
www.GlobalTestSupply.com
64
CC
1 A
1
CV
3 V
2
CW
0.5 W
3
CR
2 Ω
4
CC
3.8 A
5
CC
0.5 A
6
CV
2.8 V
7
Refer to section “Save/Recall Instrument Settings” in section “3.3 SYSTEM Menu” for details on saving settings into internal memory.
Note: If the program requires more than 10 sequences, each program can be linked
(chained) to another program after it has completed.
1. Setup the program parameters. From the front panel press ( ) and then (
) to access the PROGRAM menu. It will look like the display below:
2. Select Edit and press . The first parameter to configure is the Active Sequence.
This allows activating or deactivating a sequence in the program. Sequences that are activated will be part of the test program. Deactivated sequences will be skipped. To activate a sequence, press the number corresponding to the sequence using the
numeric keypad. For example, if sequence 1 through 5 are to be activated, press
PROGRAM
Run Recall Edit
EDIT PROGRAM
Active Sequence = 0987654321
www.GlobalTestSupply.com
65
. The activated sequence numbers on the display will change to Y,
indicating that they are active and will be run as part of the test program. In this example, the display will look like below:
To deactivate, press the corresponding number with the numeric keypad again. The sequence number on the display will change back from Y to the actual sequence number.
3. Press to continue. The next parameter to configure will be the Pause Sequence.
This allows the test program to pause after running any selected sequence. For example, if the test program should pause before running sequence 2 and 4, use the
numeric keypad and press and ( ) so that number 1 and 3 in the Pause Sequence on the display will indicate Y. When the program finishes running sequence 1, it will pause until user presses a button to continue the test. Then when the program finishes running sequence 3, it will pause again until user presses a button to continue the test. The display will look like below for this configuration:
Note: A □ symbol will replace the sequence numbers that are deactivated from the previous steps.
4. Press to continue. The next parameter to configure will be the Short Sequence.
This allows the test program to run a short circuit test of the selected sequence. Use the numeric keypad to select which sequence number to activate short circuit test, and its number will change to Y.
EDIT PROGRAM
Active Sequence = 09876YYYYY
EDIT PROGRAM
Pause Sequence = □□□□□□4Y2Y
www.GlobalTestSupply.com
66
5. Press to continue. The display will show the following:
SEQ01 will be shown if sequence 1 is activated. Otherwise, it will display SEQXX where XX is the first sequence number in the program that is activated (starts from 1-9 and then 0). The load is prompting to enter the On Time for the sequence number in seconds. This is the length of time in which to run the sequence with input enabled (ON). Valid range is
0.0 s – 60.0 s. Use the numeric keypad or rotary knob to enter a value. Then press .
6. Now, the load will prompt to enter Off Time. This is the length of time in which to run
the sequence with input disabled (OFF). Valid range is 0.0 s – 60.0 s. Use the numeric keypad or rotary knob to enter a value. Then press .
7. The load will then prompt to enter P/F Delay Time. This is delay time is illustrated by
the graph below:
EDIT PROGRAM
Short Sequence = □□□□□□4Y2Y
EDIT PROGRAM
SEQ01 On Time = 0.0 S
www.GlobalTestSupply.com
67
0 ≤ T
pf
≤ (Ton+ T
off
)
Tpf = P/F Delay Time Ton = On Time T
off
= Off Time
Use the numeric keypad or rotary knob to enter a value. Then press .
8. If there are more than one active sequence, the load will repeat the prompts to
configure the On Time, Off Time, and P/F Delay Time. Follow steps 7 – 9 for each sequence.
9. Once all sequences’ parameters are configured, the display will show:
Select Complete-Stop or Failure-Stop, then press . Complete-Stop: Stop test when program is complete. Failure-Stop: Stop test when testing fails.
10. The load will prompt to enter a value for Chain Program File. This specifies the next
program to run immediately after the end of the test. Select between 0 – 10. Select 0 if no other programs will be run at the end of the test. Otherwise, select the program number to run after the test is completed. Use the numeric keypad or rotary knob to
enter a value and then press to confirm.
11. Lastly, the load will prompt to select a number to Save Program File. This is the
program number that will be referred to when recalling all the configured settings from previous steps or chaining with another program. Select between 1 – 10 with the
PROGRAM
Complete–Stop Failure–Stop
www.GlobalTestSupply.com
68
numeric keypad or rotary knob. Then press to confirm and save all settings to the selected program number. The display will not return to the PROGRAM menu.
Recall and Run Program
The following is a procedure to recall and run a saved test program.
Recall a Program
1. Press ( ) and then ( ) to enter the Program menu.
2. Select Recall and press . The display will be shown as below:
3. Use the numeric keypad or rotary to select the program number to recall from memory.
Enter a number between 1 and 10. Then press .
4. The display go back to the Program menu. To view the recalled settings, select Edit and
press .
Note: If you recall a program from an empty location, it will give you an error message,
and all settings viewed under the Edit option will be reset to default values.
Run a Program
1. Press ( ) and then ( ) to enter the Program menu.
2. Make sure the program you want to run has already been recalled from the previous
instructions. Select Run and press .
3. The display will show the following:
RECALL PROGRAM
Recall Program File = 1
www.GlobalTestSupply.com
69
PRG01 from this display indicates which program has been loaded to run. Depending on which program is recalled, it will show PRG01-PRG10.
STOP indicates the program is not running.
4. Now, press ( ) once to start running the program. The display will change to:
-01 next to PRG01 indicates the current running sequence number within the selected
program number.
on indicates the input state is enabled for the selected sequence. If On Time is not set to 0.0S for the sequence, it will show on. This indicator can also show off to indicate the input state is disabled. If short is selected for the sequence, it will display short.
pass indicates at the current sequence has passed the test. If a failure occurs, it will indicate fail.
5. If pause is activated for a selected sequence while running the program, the display will
show:
10.000V
0.000A
PRG01 STOP
OFF CC
10.000V
0.000A
PRG01-01 on pass
OFF CC
www.GlobalTestSupply.com
70
At this point, the program is in a pause state. To continue the test, press ( ) once.
Note: At any time while the program is in the running state, if you wish to re-test a
sequence or test a previous sequence, press the ( ) key. Each press will go back up one sequence and run the test again starting from that sequence. You
can also skip to the next sequence in the test by pressing ( ).
To pause the program at any time while it is in the running state, press and
then (or press ). A Pause indicator will appear on the bottom right of the display. To resume, repeat the same step.
When the program is in a pause state, the input state can be overridden by pressing
.
6. At the end of the test, the display will show:
10.000V
0.000A
PRG01-01 off key pass
OFF CC
10.000V
0.000A
PRG pass
OFF CC
www.GlobalTestSupply.com
71
If there is a failure, fail will be indicated in place of pass. At this point, you can press
( ) to view which sequences were tested and passed/failed. It will be
indicated like the following:
Y indicates the tested sequence(s) that passed/failed. If a sequence has been skipped in the test, its sequence number will be indicated instead of a Y.
7. To stop a running program at any time, press ( )once. To completely exit
the automatic test function, press a few times until the load returns back to the normal display.
OCP Test Function
The load has a built-in OCP test function that can be used to automate testing for OCP conditions. The load can save up to 5 OCP test programs into internal memory, which can be recalled and run.
The OCP Test program requires the following parameters be configured before it can be run.
Voltage On Level
This is the minimum voltage level the load measures before the start of the test.
Voltage On Delay
This is the delay time from when the Voltage On Level is reached to the actual start of the test.
Current Range
This specifies the current range of the test. All models have two current ranges, with the lower range allowing for higher resolution. This value will also limit the maximum current settings for other parameters configured for the test program.
10.000V
0.000A
PRG01: □□□□□□4Y2Y pass
OFF CC
www.GlobalTestSupply.com
72
Start Current
This is the starting current value when OCP test begins. The settable range of this value is limited by Current Range.
Step Current
This is the size of the step current as the test runs from the Start Current to End Current. The test will only run through in steps if the
measured input voltage is greater than the OCP Voltage. Otherwise, the test will end after running the Start Current for the amount of time specified in Step Delay.
Step Delay
This is the delay time to hold each current step in the test. This determines how fast or slow to run through the test.
End Current
This is the ending current value before OCP test ends. The test will only run through in steps from Start Current to the End Current if input voltage is greater than the OCP Voltage. The settable range of this value is limited by Current Range.
OCP Voltage
This value is a limit that is used to test for OCP conditions. In the event of an over current condition, when the input voltage is greater than this value, the test will run through from Start Current to End Current in steps. The input current (the over current) value will be checked during this process. If current is within the Max Trip Current and Min Trip Current boundaries, the load will indicate Pass at the end of the test. If outside of these boundaries, the load will indicate Fault.
Max Trip Current
The maximum acceptable current limit of the over current value.
Min Trip Current
The minimum acceptable current limit of the over current value.
The following is a step by step procedure to configure an OCP test program.
1. Press ( ) and to enter the OCP Test menu. The following will be
displayed:
2. Select Edit and press . Enter a value using the numeric keypad or rotary knob
for Voltage On Level. The value must be within the maximum input limits of the load. Press to continue.
OCP TEST
Run Recall Edit
www.GlobalTestSupply.com
73
3. Enter a value for Voltage On Delay. This can be set between 0.00s and 99.99s. Then
press to continue.
4. Follow the same steps for Current Range. The value must be within the maximum
input limits of the load. Press to continue.
5. Set the Start Current. The value must be less than Current Range. Press to
continue.
6. Do the same for Step Current and End Current. Press after each setting to
continue.
7. Enter a value for OCP Voltage and press to continue.
8. Finally, enter a value for Max Trip Current, and then Min Trip Current. Press
after each settings to continue.
9. The load will prompt to Save OCP File. Select a number between 1 and 5. Then press
to save all settings to the selected location.
Note: At any time when configuring any parameters for the test, you can press the
key to select the previous parameter to edit.
To recall the settings:
1. Press ( ) and to enter the OCP Test menu. Select Recall and
press .
2. Use the keypad or knob to select the saved location number and press .
All settings will be recalled when selecting Edit from the OCP Test menu.
To run the OCP test:
1. Recall the settings from memory by following the steps above.
2. Then, from the OCP Test menu, select Run and press . The display
will show the following:
www.GlobalTestSupply.com
74
3. Press to start the test. When the test is running, Run will be indicated
in place of Stop. When the test ends, either Pass or Fault will appear next to Stop.
4. To stop the test at any time, press .
OPP Test Function
The load has a built-in OPP test function that can be used to automate testing for OPP conditions. The load can save up to 5 OPP test programs into internal memory, which can be recalled and run.
The OPP Test program requires the following parameters be configured before it can be run.
Voltage On Level
This is the minimum voltage level the load measures before the start of the test.
Voltage On Delay
This is the delay time from when the Voltage On Level is reached to the actual start of the test.
Current Range
This specifies the current range of the test. All models have two current ranges, with the lower range allowing for higher resolution. This value will also limit the maximum settings for other parameters configured for the test program.
Start Power
This is the starting power value when OPP test begins.
Step Power
This is the size of the step power as the test runs from the Start Power to End Power. The test will only run through in steps if the measured input voltage is greater than the OPP Voltage. Otherwise, the test will end after running the Start Power for the amount of time specified in
10.000V
0.000A
0.00W 0.0000A Stop
OFF CC
www.GlobalTestSupply.com
75
Step Delay.
Step Delay
This is the delay time to hold each power step in the test. This determines how fast or slow to run through the test.
End Power
This is the ending power value before OPP test ends. The test will only run through in steps from Start Power to the End Power if input voltage is greater than the OPP Voltage.
OPP Voltage
This value is a limit that is used to test for OPP conditions. In the event of an over power condition, when the input voltage is greater than this value, the test will run through from Start Power to End Power in steps. The input power (the over power) value will be checked during this process. If power is within the Max Trip Power and Min Trip Power boundaries, the load will indicate Pass at the end of the test. If outside of these boundaries, the load will indicate Fault.
Max Trip Power
The maximum acceptable power limit of the over power value.
Min Trip Power
The minimum acceptable power limit of the over power value.
The following is a step by step procedure to configure an OPP test program.
1. Press ( ) and to enter the OPP Test menu. The
following will be displayed:
2. Select Edit and press . Enter a value using the numeric keypad
or rotary knob for Voltage On Level. The value must be within the maximum input limits of the load. Press to continue.
3. Enter a value for Voltage On Delay. This can be set between 0.00s and
99.99s. Then press to continue.
4. Follow the same steps for Current Range. The value must be within
the maximum input limits of the load. Press to continue.
5. Set the Start Power. The value must be within the maximum input
limits of the load. Press to continue.
OPP TEST
Run Recall Edit
www.GlobalTestSupply.com
76
6. Follow the same steps for Step Power and End Power. Press
after each settings to continue.
7. Enter a value for OPP Voltage and press to continue.
8. Enter a value for Max Trip Power, and then Min Trip Power. Press
after each settings to continue.
9. The load will prompt to Save OPP File. Select a number between 1 and
5. Then press to save all settings to the selected location.
Note: At any time when configuring any parameters for the test, you can press the
( ) key to select the previous parameter to edit.
To recall the settings:
1. Press ( ) and to enter the OPP Test menu.
Select Recall and press .
2. Use the keypad or knob to select the saved location number and
press . All settings will be recalled when selecting Edit from the OPP Test menu.
To run the OPP test:
1. Recall the settings from memory by following the steps above.
2. From the OPP Test menu, select Run and press . The display will show the
following:
10.000V
0.000A
0.00W 0.00W Stop
OFF CC
www.GlobalTestSupply.com
77
3. Press ( ) to start the test. When the test is running, Run will be indicated
in place of Stop. When the test ends, either Pass or Fault will appear next to Stop.
4. To stop the test at any time, press ( ).
3.10 Key Lock
The front panel keys can be locked to prevent unwanted changes to output settings and instrument configurations. Follow the steps below to enable/disable key lock.
1. Press ( ) and then ( ). A * indicator will light up on the display,
indicating that the front panel keys are lock. At this point, all keys are disabled except for the Lock function.
2. To unlock the keys again, press ( ) and then ( )again. The *
indicator will disappear and all keys will be enabled.
www.GlobalTestSupply.com
78
4 Remote Operation
4.1 Interface Connection
RS-232
For RS-232 connectivity, refer to the diagram below for pinout information. The RS-232 is labeled in the rear panel and it is a female DB-9 interface.
Table 6 - RS232 Pin Outs
PIN
Description
1 - 2
Transmit Data
3
Receive Data
4 - 5
GND 6 - 7 CTS
8
RTS 9 -
A straight pin-to-pin DB9 female to DB9 male serial cable is required for using the RS-232 interface. Do not use a null modem or crossover DB9 serial cable.
1 2 3 4 5
6
7 8 9
www.GlobalTestSupply.com
79
GPIB (non-B series only)
The load can be configured with a GPIB address from 0 – 31. To communicate via GPIB, connect a GPIB cable to the GPIB interface on the rear panel, as illustrated below.
USBTMC
The device is SR1, RL1, and DT1 enabled. It can receive the following request:
REN_CONTROL, GO_TO_LOCAL, LOCAL_LOCKOUT. When it receives MsgID = TRIGGER USBTMC command, it will transmit TRIGGER command to the function layer.
4.2 Remote Commands
The instrument supports some SCPI commands and some instrument specific commands. These commands enable a computer to remotely communicate and control the instrument over any of the supported remote interfaces: USBTMC, RS-232, and GPIB(non-B series only) .
Refer to the programming manual for details, which can be downloaded from
www.bkprecision.com.
www.GlobalTestSupply.com
80
5 Troubleshooting Guide
Below are some frequently asked questions and answers. Please check if any apply to your instrument before contacting B&K Precision.
General
Q: I cannot power up the instrument.
Check that the power cord is securely connected to the AC input and there is live power from your electrical AC outlet.
Verify that the AC power coming from the mains have the correct voltage. The load can accept a specific range of AC input voltages. Refer to section “2.1”.
Q: I cannot set power (in CW) or current (in CC) at the maximum rating.
4. Check the power and current Limits from the Protect menu within the CONFIG menu.
Refer to section 3.4 for details.
Remote Control
Q: I am trying to send the commands over USB/RS232, but it does not seem to respond.
Check that you are sending ASCII strings that are terminated with a CR (carriage return) and LF (line feed) character.
For RS-232, check that the baud rate, parity, data bits, stop bit, and flow control settings match with the settings configured on the software interface. To check these settings, go to the SYSTEM menu and enter the Communication menu, and select RS-232.
www.GlobalTestSupply.com
81
6 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes over an ambient temperature range of 23 °C ± 5 °C. Specifications are subject to change without notice.
Model
8600/B
8601/B
8602/B
Input Ratings
Input Voltage
0 – 120 V
0 – 120 V
0 – 500 V
Input Current
Low
0 – 3 A
0 – 6 A
0 – 3 A
High
0 – 30 A
0 – 60 A
0 – 15 A
Input Power
150 W
250 W
200 W
Minimum Operating Voltage
Low
0.11 V at 3 A
0.18 V at 6 A
1 V at 3 A
High
1.1 V at 30 A
1.1 V at 60 A
4.5 V at 15 A
CV Mode
Range
Low
0 – 18 V
0 – 50 V
High
0 – 120 V
0 – 500 V
Resolution
Low
1 mV
High
10 mV
Accuracy
Low
±(0.05%+0.02%FS)
±(0.025%+0.05%FS)
±(0.05%+0.025%FS)
High
±(0.05%+0.025%FS)
±(0.025%+0.05%FS)
±(0.05%+0.025%FS)
CC Mode
Range
Low
0 – 3 A
0 – 6 A
0 – 3 A
High
0 – 30 A
0 – 60 A
0 – 15 A
Resolution
Low
0.1 mA
0.1 mA
0.1 mA
High
1 mA
1 mA
1 mA
Accuracy
Low
±(0.05%+0.05%FS)
High
±(0.05%+0.05%FS)
CR Mode
Range
Low
0.05 Ω – 10 Ω
0.3 Ω – 10 Ω
High
10 Ω - 7.5 kΩ
Resolution
16 bit
Accuracy
Low
0.01%+0.08 S
High
0.01%+0.0008 S
CW Mode
Range
150 W
250 W
200 W
Resolution
10 mW
Accuracy
0.1% + 0.1%FS
0.2% + 0.2%FS
0.1% + 0.1%FS
www.GlobalTestSupply.com
82
Models
8600/B
8601/B
8602/B
Transient Mode (CC mode)
T1 & T2 1
20 µs – 3600 s / Resolution: 10 µs
Accuracy
5 µs + 100 ppm
Slew Rate
2
Low Rate
0.001-2.5 A/ms
0.001-1 A/ms
High Rate
0.001-2.5 A/µs
0.001-1 A/µs
Accuracy
within 40 % of programmed value
Measurement
Readback Voltage
Range Low
0 – 18 V
0 – 18 V
0 – 50 V
High
0 – 120 V
0 – 120 V
0 – 500 V
Resolution Low
1 mV
High
10 mV
Accuracy
±(0.05 %+0.05 % FS)
Readback Current
Range Low
0 – 3 A
0 – 6 A
0 – 3 A
High
0 – 30 A
0 – 60 A
0 – 15 A
Resolution Low
0.01 mA
0.1 mA
0.01 mA
High
0.1 mA
1 mA
0.1 mA
Accuracy
±(0.05 %+0.05 %
FS)
±(0.05 %+0.1 % FS)
±(0.05%+0.05 % FS)
Readback Power
Range
150 W
250 W
200 W
Resolution
10 mW
Accuracy
±(1 %+0.1 % FS)
±(0.2 %+0.2 % FS)
±(0.1 %+0.1 % FS)
Protection Range (typical)
OPP
150 W
250 W
200 W
OCP
Low
3.3 A
6.6 A
3.3 A
High
33 A
66 A
16.5 A
OVP
120 V
120 V
500 V
OTP
85℃
General (typical)
Short Circuit
Current (CC)
Low
3.3 A
6.6 A
3.3 A
High
33 A
66 A
16.5 A
Voltage
0 V
Resistance
35 mΩ
30 mΩ
300 mΩ
Input Terminal Impedance
150 kΩ
300 kΩ
1 MΩ
www.GlobalTestSupply.com
83
Model
8610/B
8612/B
8614/B
8616
Input Ratings
Input Voltage
0 – 120 V
0 – 500 V
0 – 120 V
0 – 500 V
Input Current
Low
0 – 12 A
0 – 3 A
0 – 24 A
0 – 6 A
High
0 – 120 A
0 – 30 A
0 – 240 A
0 – 60 A
Input Power
750 W
1500 W
1200 W
Minimum Operating Voltage
Low
0.12 V at 12 A
0.36 V at 3 A
0.15 V at 24 A
0.36 V at 6 A
High
1.2 V at 120 A
3.6 V at 30 A
1.5 V at 240 A
3.6 V at 60 A
CV Mode
Range Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 50 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 500 V
Resolution Low
0.1 mV
1 mV
0.1 mV
1 mV
High
1 mV
10 mV
1 mV
10 mV
Accuracy
Low
±(0.025%+0.05%FS)
±(0.025%+0.025
%FS)
±(0.025%+0.05%FS) High
±(0.025%+0.05%FS)
CC Mode
Range Low
0 – 12 A
0 – 3 A
0 – 24 A
0 – 6 A
High
0 – 120 A
0 – 30 A
0 – 240 A
0 – 60 A
Resolution Low
1 mA
0.1 mA
1 mA
0.1 mA
High
10 mA
1 mA
10 mA
1 mA
Accuracy Low
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%
FS)
±(0.05%+0.05%FS)
High
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%
FS)
±(0.05%+0.05%FS)
CR Mode
Range Low
0.02 Ω – 10 Ω
0.15 Ω – 10 Ω
0.01 Ω – 10 Ω
0.1 Ω – 10 Ω
High
10 Ω - 7.5 kΩ
Resolution
16 bit
Accuracy Low
0.01%+0.08 S
High
0.01%+0.0008 S
CW Mode
Range
750 W
1500 W
1200 W
Resolution
10 mW
100 mW
Accuracy
0.2% + 0.2%FS
www.GlobalTestSupply.com
84
Models
8610/B
8612/B
8614/B
8616
Transient Mode (CC mode)
T1 & T21
20 µs – 3600 s/Resolution: 10 µs
Accuracy
5 µs + 100 ppm
Slew Rate
2
Low Rate
0.001-0.25 A/µs
0.0001-0.1 A/µs
0.001-0.25 A/µs
0.0001-0.1 A/µs
High Rate
0.01-2.5 A/µs
0.001-1 A/µs
0.01-2.5 A/µs
0.001-1 A/µs
Accuracy
within 40% of programmed value
Measurement
Readback Voltage
Range Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 50 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 500 V
Resolution Low
0.1 mV
1 mV
0.1 mV
1 mV
High
1 mV
10 mV
1 mV
10 mV
Accuracy
±(0.05%+0.05%FS)
Readback Current
Range Low
0 – 12 A
0 – 3 A
0 – 24 A
0 – 6 A
High
0 – 120 A
0 – 30 A
0 – 240 A
0 – 60 A
Resolution Low
1 mA
0.1 mA
1 mA
0.1 mA
High
10 mA
1 mA
10 mA
1 mA
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
Readback Power
Range
750 W
1500 W
1200 W
Resolution
10 mW
100 mW
Accuracy
±(0.2%+0.2%FS)
Protection Range (typical)
OPP
760 W
1550 W
1250 W
OCP
Low
13.2 A
3.3 A
26.4 A
6.6 A
High
132 A
33 A
264 A
66 A
OVP
130 V
530 V
130 V
530 V
OTP
85℃
General (typical)
Short Circuit
Current (CC)
Low
13.2 A
3.3 A
26.4 A
6.6 A
High
132 A
33 A
264 A
66 A
Voltage
0 V
Resistance
10 mΩ
120 mΩ
6 mΩ
60 mΩ
Input Terminal Impedance
300 kΩ
1 MΩ
300 kΩ
1 MΩ
Notes:
www.GlobalTestSupply.com
85
1) Fast pulse trains with large transitions may not be achievable.
2) The slew rate specifications are not warranted but are descriptions of typical performance. The actual transition
time is defined as the time for the input to change from 10% to 90%, or vice versa, of the programmed current values. In case of very large load changes, e.g. from no load to full load, the actual transition time will be larger than the expected time. The load will automatically adjust the slew rate to fit within the range (high or low) that is closest to the programmed value.
Model
8620
8622
8624
8625
Input Ratings
Input Voltage
0 – 120 V
0 – 500 V
0 – 120 V
0 – 120 V
Input Current
Low
0 – 48 A
0 – 10 A
0 – 60 A
0 – 72 A
High
0 – 480 A
0 – 100 A
0 – 600 A
0 – 720 A
Input Power
3000 W
2500 W
4500 W
6000 W
Minimum Operating Voltage
Low
0.2 V at 48 A
0.3 V at 10 A
0.18 V at 60 A
0.18 V at 72 A
High
2 V at 480 A
3 V at 100 A
18 V at 600 A
1.8 V at 720 A
CV Mode
Range Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 18 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 120 V
Resolution Low
1 mV
High
10 mV
Accuracy
Low
±(0.025%+0.05%FS)
±(0.025%+
0.025%FS)
±(0.025%+0.05%FS) High
±(0.025%+0.05%FS)
CC Mode
Range Low
0 – 48 A
0 – 10 A
0 – 60 A
0 – 72 A
High
0 – 480 A
0 – 100 A
0 – 600 A
0 – 720 A
Resolution Low
1 mA
High
10 mA
Accuracy Low
±(0.25%+0.05%FS)
High
±(0.25%+0.05%FS)
CR Mode
Range Low
0.01 Ω – 10 Ω
0.03 Ω – 10 Ω
0.01 Ω – 10 Ω
0.005 Ω – 10 Ω
High
10 Ω - 7.5 kΩ
Resolution
16 bit
Accuracy Low
0.01%+0.08 S
High
0.01%+0.0008 S
CW Mode
Range
3000 W
2500 W
4500 W
6000 W
Resolution
100 mW
Accuracy
0.2% + 0.2%FS
www.GlobalTestSupply.com
86
Models
8620
8622
8624
8625
Transient Mode (CC mode)
T1 & T21
20 µs – 3600 s/Resolution: 10 µs
Accuracy
5 µs + 100 ppm
Slew Rate
2
Low Rate
0.001-0.25 A/µs
0.0001-0.1 A/µs
0.001-0.25 A/µs
0.001-0.25 A/µs
High Rate
0.01-2.5 A/µs
0.01-1 A/µs
0.01-2.5 A/µs
0.01-2.5 A/µs
Accuracy
within 40% of programmed value
Measurement
Readback Voltage
Range Low
0 – 18 V
0 – 50 V
0 – 18 V
0 – 18 V
High
0 – 120 V
0 – 500 V
0 – 120 V
0 – 120 V
Resolution Low
1 mV
High
10 mV
Accuracy
±(0.025%+0.025%FS)
Readback Current
Range Low
0 – 48 A
0 – 10 A
0 – 60 A
0 – 72 A
High
0 – 480 A
0 – 100 A
0 – 600 A
0 – 720 A
Resolution Low
1 mA
High
10 mA
Accuracy
±(0.05%+0.1%FS)
±(0.05%+0.05%FS)
±(0.05%+0.1%FS)
±(0.05%+0.1%FS)
Readback Power
Range
3000 W
2500 W
4500 W
6000 W
Resolution
100 mW
Accuracy
±(0.2%+0.2%FS)
Protection Range (typical)
OPP
3050 W
2550 W
4550 W
6050 W
OCP
Low
26.4 A
11 A
66 A
79.2 A
High
264 A
110 A
660 A
792 A
OVP
130 V
530 V
130 V
130 V
OTP
85℃
General (typical)
Short Circuit
Current (CC)
Low
52.8 A
11 A
66 A
79.2 A
High
528 A
110 A
660 A
792 A
Voltage
0 V
Resistance
5 mΩ
30 mΩ
3 mΩ
2.5 mΩ
Input Terminal Impedance
300 kΩ
1 MΩ
300 kΩ
300 kΩ
Notes:
1) Fast pulse trains with large transitions may not be achievable.
www.GlobalTestSupply.com
87
2) The slew rate specifications are not warranted but are descriptions of typical performance. The actual transition
time is defined as the time for the input to change from 10% to 90%, or vice versa, of the programmed current values. In case of very large load changes, e.g. from no load to full load, the actual transition time will be larger than the expected time. The load will automatically adjust the slew rate to fit within the range (high or low) that is closest to the programmed value.
Supplementary Characteristics
Memory capacity
100 Groups
Recommended calibration period
Once per year
AC Input (selectable by switch on the rear panel)
Option 1: 220 V ±10%, 50/60 Hz
Option 2: 110 V ±10%, 50/60 Hz
Cooling method
Fan cool
Environmental conditions
This instrument is intended for indoor use in a pollution degree 2 environment. Environmental limits are as follows:
Operating temperature
0 to 40 °C
Storage temperature
-10 to 60 °C
Humidity
Indoor use, ≤ 95%
www.GlobalTestSupply.com
