USER GUIDE

Big Button 3725

Big Button 3725 Twin Big Button 3725 Triple

Digital Cordless Telephone with

Telephone Answering Machine (TAM)

Binatone Helpline (for UK only)

Monday to Friday

from 9:00am to 5:00pm Tel: 0845 345 9677 **Please note that all calls are charged at local rate

or visit our website:

THIS EQUIPMENT IS NOT DESIGNED FOR MAKING EMERGENCY TELEPHONE CALLS WHEN THE POWER FAILS. ALTERNATIVE ARRANGEMENTS SHOULD BE MADE FOR ACCESS TO DIAL EMERGENCY SERVICES.

please read these instructions carefully.

www.binatoneonline.com

Before operating this set,

Package Contents

•

1 Handset (2 with a Twin system, 3 with a Triple system) 1 Base Station

•

1 Mains Power Adapter

•

1 Telephone Line Cord

•

2 Rechargeable Batteries for each handset 1 Charger Pod with mains power adapter for each additional

•

handset of a multi-handset system

•

1 User Guide.

Connection and Conditions for use:

You can connect your phone to a direct exchange line (DEL) on a local exchange with its own phone number; to an extension socket connected to a DEL; or to an extension on an approved compatible PBX. Do not connect as an extension to a payphone. The ringer equivalence number (REN) of all equipment (phones, fax machines, modems, etc.) connected to an exchange line must not add up to more than 4, otherwise one or more of them may not ring and/or answer calls correctly. This phone has a REN of 1, and most other telephones have a REN of 1 unless marked otherwise.

Handset - Base Connection

1) When purchased, all handsets are already registered to the base unit and should link to it when they are all powered up.

2) To use your cordless handset and base unit together, you must be able to establish a radio link between

handset and the base is in accordance with the normal

a DECT phone: Maximum range up to 300 metres outdoors or 50

metres indoors. Be

aware that:

> Any large metal object, such as a refrigerator, mirror or filing cabinet, between the handset and the base unit may block the radio signal. > Other solid structures, like walls, may reduce the signal strength. > Other electrical equipment may cause interference and/or affect the range.

3) Do not place close to another telephone, a TV or audio equipment - it may cause interference.

4) Out of Range warning. If you hear a warning tone during a call, and/or the sound in the earpiece becomes faint or distorted, you may be going out of range of the base unit, so move nearer to the base unit within 20 seconds, otherwise the call may be cut off.

them. The signal between the

standards for

TECHNICAL DETAILS

Standard

Frequency range Channel bandwidth Operating range

Operating time

Temperature range

Electrical power

Caution

Risk of explosion if battery is replaced by an incorrect type Dispose of used batteries according to the instructions.

Port specification

The port (connec ted to the mains power supply) is a EN41003.

The

port (connected to the telephone line) is aTNV port with respect to EN41003.

Every effort has been made to ensure high standards of reliability for your

BB3725 system. However, if something does go wrong, please

repair it yourself,

Digital Enhanced Cordless

Telecommunication(DECT)

1.88 to 1.9GHz (bandwidth = 20 MHz)

1.728 MHz

Up to 300m outdoors; up to 50m indoors Standby: 100 hours Talking: 10 hours

Battery charge time:15 hours

Operating 0 C to 40 C, Storage -20 C to 60 C

Base unit:

Ten Pao - S005CV0600030 / S005CB0600045 input 100-240VAC 50/60Hz 1 0mA, output 6VDC

Charger unit:

Ten Pao - S002CV0600030 / S002CB0600030 input 100-240VAC 50/60Hz 100mA, output 6VDC 300mA

Handset Battery Information : GP – VTHC043C02, Type NiMH (Rechargeable battery) Voltage Rating 2 x AAA size NiMH 1.2V 400mAh BYD- H-AAA400BX2, Type NiMH (Rechargeable battery) Voltage Rating

2 x AAA size NiMH 1.2V 400mAh

SELV port with respect to

consult your supplier or the Helpline.

0mA

do not try to

TABLE OF CONTENTS

INSTALLING YOUR PHONE

1.1 CONNECTING THE BASE STATION.........................................................................................................

1.2 INSTALLING AND CHARGING THE BATTERIES.........................................................................................

GETTING TO KNOW YOUR PHONE

2.1 OVERVIEW OF THE HANDSET...............................................................................................................

2.2

DISPLAY ICONS AND SYMBOLS

2.3

BASE STATION OVERVIEW

2.4 B

2.5 MENU STRUCTURE............................................................................................................................ 11

2.6 TEXT AND DIGIT ENTRY TABLE .......................................................................................................... 11

USING YOUR PHONE

3.1 MAKE A CALL ...................................................................................................................................13

3.2 MAKE A CALL FROM DIRECT EMORY ................................. ......................................13

3.3 ANSWER A CALL...............................................................................................................................13

3.4 AUDIO BOOST FEATURE.................................................................................................................... 13

3.5 END A CALL......................................................................................................................................14

3.6 ADJUST EARPIECE AND HANDSFREE VOLUME ................................................................................... 14

3.7 MUTE A CALL.................................................................................................................................... 14

T O T H R ....................................................................................................14

3.8

3.9 TURN ON THE KEYPAD LOCK.............................................................................................................14

3.10 ..................................................................................................................... 14

3.11 FIND THE HANDSET ......................................................................................................................... 15

3.12 MAKE AN INTERNAL CALL ............................................................................................................... 15

3.12.1 INTERCOM ANOTHER HANDSET...................................................................................................... 15

3.12.2 CALL ALL HANDSETS ..................................................................................................................... 15

3.12.3 TRANSFER AN EXTERNAL CALL TO ANOTHER HANDSET ................................................................... 1

3.12.4 MAKE A 3-WAY CONFERENCE CALL................................................................................................ 1

PRIVATE PHONEBOOK

4.1 ADD A NEW PHONEBOOK ENTRY....................................................................................................... 16

4.2 SEARCH A PHONEBOOK ENTRY......................................................................................................... 16

4.3 VIEW A PHONEBOOK ENTRY.............................................................................................................. 16

4.4 EDIT A PHONEBOOK ENTRY............................................................................................................... 18

4.5 DELETE A PHONEBOOK ENTRY.......................................................................................................... 18

4.6 DELETE ENTIRES RIVATE PHONEBOOK...................................................................... 18

4.7 CHECK THE PHONEBOOK USAGE.......................................................................................................18

4.8 SET THE FAST DIAL NUMBERS........................................................................................................... 18

CALLER DISPLAY (NETWORK DEPENDENT)

5.1 VIEW THE CALL L .........................................................................................................................19

5.2 STORE A CALL L NUMBER INTO THE PHONEBOOK......................................................................... 19

5.3 DELETE AN ENTRY IN THE CALL LOG .................................................................................................19

5.4 DELETE THE CALL LOG .................................................... ...........19

5.5 VIEW THE DETAILS OF A CALL L ENTRY .....................................................................................

ASE TWO

URN

UMBER

AST

IGIT-

LLA

ENTRIES FROM

...............................................................................................................

..................................................................................................7

.........................

......

LED D

ANDSET EDIALR

............................................................................................................9

ISPLAY

................................................................................1

NFORMATION

.......................................................................................................................13

INGER

/ CONTACTS............................................................................................. 1

ROM

..................................................................................8

EYS

K (M1-M3) ..

...............................................................................19

....

.......................

PHONE SETTINGS........................6

..........................................................................................20

6.1

LOCK

6.2

6 6

REMOTE OPERATION...................................................................................................................... 17

LARM

ANDSET

......................................................................21

6.3 B

ASE

ERGISTRATION

.6 6

ESET

ANSWERING MACHINE (TAM)........................

7.1

TURN ON/OFF THE ANSWERING MACHINE..........................................................................................26

7.2

LISTEN TO THE MESSAGES IN THE ANSWERING MACHINE ................................................................... 26

7.3

DELETE ALL MESSAGES IN THE ANSWERING MACHINE ...................................................................... 27

7.4

RECORD MEMO ................................................................................................................................. 27

7.5

ANSWERING MACHINE SETTINGS....................................................................................................... 28

7.5.1

SET THE ANSWER MODE ................................................................................................................. 2

7.5.2

SET THE OUTGOING MESSAGE LANGUAGE .......................................................................................2

7.5.3

RECORD YOUR OWN OUTGOING MESSAGE (OGM) ..........................................................................2

7.5.4

PLAYBACK AND DELETE THE OUTGOING MESSAGE ...........................................................................29

7.5.5

SET THE ANSWER DELAY ................................................................................................................ 2

7.5.6

SET THE ECORDING TIME OR INCOMING MESSAGE .....................................................29

7.5.

CHANGE THE COMPRESSION RATE .................................................................................................. 31

7.5.

CTIVATE REMOTE ACCESS ............................................................................................................

8 A

7.5.

CALL SCREENING ..........................................................................................................................

TROUBLESHOOTING

8 9

.................................

ETTINGS

.........................................................

ETTINGS

.......................................

ETTINGS

.............................................................................................................................

OUR

HONE

M R

AXIMUM

....................................................................................................20

...................................................................20

............

.................................................................................26

.......................................................................................................................33

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

..23.4

When using your telephone equipment, basic safety precautions should always be

..2.6 ..................................................................................................... ........................5 ..

followed to reduce the risk of fire, electric shock and injury, including the following:

..2........................................................................................................ ...............

1) Read and understand all the instructions.

2) Follow all warnings and instructions marked on the product.

3) Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4) Do not use this product near water (for example, near a bath tub, kitchen sink, swimming pool).

5) Do not overload wall outlets and extension cords as this can result in the risk of

8 8 8

31 32

REMOTE OPERATION...................................................................................................................... 30

DECLARATION OF CONFORMITY.................................................................................................34

GUARANTEE A ND SERVICE............................................................................................... ........... 3

fire or electric shock.

6) Unplug this product from the wall outlet and refer servicing to our Repair

Centre under the following conditions:

•

When the power supply cord or plug is damaged or frayed.

•

If the product does not operate normally by following the operating instructions.

•

If the product has been dropped and the cabinet has been damaged.

•

If the product exhibits a distinct change in performance.

NEVER use your cordless telephone outdoors during a thunderstorm - unplug the base from the telephone line and the mains socket when there are storms in your area. Damage caused by lightning is not covered by the guarantee.

8) Do not use the telephone to report a gas leak in the vicinity of the leak.

9) Use only the supplied NiMH (Nickel Metal Hydride) batteries! The operation periods for the handsets are only applicable with the default battery capacities

10) The use of other battery types or non-rechargeable batteries/primary cells can be dangerous. These may cause interference and/or

surroundings.

The manufacturer will not be held liable for damage arising from such non-compliance.

11) Do not use third party charging bays. The batteries may be damaged.

12)

Please ensure the batteries are inserted in the correct polarity.

13)

Dispose of batteries safely. Do not immerse them in water, burn them, or put

damage to the unit or

them where they could get punctured.

GETTING TO KNOW YOUR PHONE

1 INSTALLING YOUR PHONE

Connecting the base station

1.1

1) Plug the power adapter into the base station.

2) Plug the power

socket, & the other

telephone line

Warning: Always use the line cord provided in the box. Other line cords may not be compatible and may not

Warning: Only use the power adapter supplied. Others will result in non-compliance with the safety specification EN60950, and will invalidate any approval given with this apparatus.

Warning: The Base unit needs mains power for normal operation, not just for charging the handset batteries.

Installing and charging the batteries

1.2

adapter into a 230Vac, 50Hz mains

socket.

1) Slide open the battery compartment cover.

2) Place the 2 batteries

as shown.

3) Slide the battery compartment cover back.

4) Put the handset on the base and charge for

15 hours before first time use.

harging starts.beeps when c

Warning: Only use AAA size NiMH rechargeable batteries.

1.3 If you have a Broadband Line

If you connect your telephone to a line with a broadband connection, you will need to insert a micro-filter between the telephone and the telephone line, otherwise you may get interference between the telephone and the broadband, which could cause problems. In a home with broadband, every telephone must have a micro-filter connected, not just the one at the telephone point that your modem is connected to. If you need more broadband micro-filters, contact your broadband provider.

& line cord

end of the line cord into your

work.

with the correct polarity,

The handset

GETTING TO KNOW YOURPHONE

2 GETTING TO KNOW YOUR PHONE

2.1 Overview of the Handset

1. UP/ DOWN During a call: Press to increase or decrease the earpiece volume.

2. M1/M2/M3 - DIRECT MEMORY KEYS In idle mode: Press and hold to dial the stored number.

3. CLEAR /BACK/MUTE In main menu mode: Press to go back to idle screen. In sub-menu mode: Press to go back to previous level. In sub-menu mode: Press and hold to go back to idle screen. In editing / predialing mode: Press to clear a character / digit. In editing / predialing mode: Press and hold to delete all the characters / digits. During a call: Press to mute / unmute the microphone. In idle mode: Press to intercom another handset.

4. UP/CALL LOG In idle mode: Press to access the call log. In menu mode: Press to scroll up the menu items. In Contacts list / Redial list / Call List: Press to scroll up the list.

5. DOWN/REDIAL LIST In idle mode: Press to access the redial list. In menu mode: Press to scroll down the menu items. In Contacts list / Redial list / Call List: Press to scroll down the list.

6. TALK OFF During a call: Press to end a call and go back to idle mode. In menu / editing mode: Press to go back to previous menu. In menu / editing mode: Press and hold to go back to idle screen. In idle mode: Press and hold to power off the handset. In idle mode (when the handset is powered off): Press and hold to power on the handset.

7. ALPHANUMERIC KEYPAD, * (STAR), # (HASH) Press to insert a digit / character / * / #

1-9 keys in idle mode: Press and hold to dial out pre-stored fast-key

* key in idle mode: Press and hold to enable or disable the keypad lock. * key during a call (in Pulse mode): Press to switch to tone # key during a call: Press and hold to insert a recall (R) signal (also called flash). # key in Idle mode: Press and hold to turn on / off the handset ringer. 0 key in idle / predialing / number editing mode: Press and hold to insert a pause. # key in Call Log mode: Press to review caller’s number if applicable.

GETTING TO KNOW YOUR PHONE

memories.

mode.

GETTING TO KNOW YOUR PHONE

8. MICROPHONE

9. TALK ON/SPEAKERPHONE In idle / predialing mode : Press to make a call. Presa again to turn on the speakerphone.

In Redial list / Call List / Contacts entry: Press to make a call to the selected entry in the list. Press again to turn on the speakerphone. During ringing: Press to answer a call. Press again to answer with speakerphone.

10. MENU/OK In idle mode: Press to access the main menu In sub-menu mode: Press to confirm the selection During a call: Press to access Intercom/ Phonebook/ Redial List/ Call Log

11. AMPLIFY During a call: Press to turn on or off the audio boost. (Only in Handset earpiece mode)

12. LED Steadily on when audio boost is turned on. Flashes when incoming call.

13. EARPIECE

2.2 Display Icons and Symbols

The screen display gives you information on the current status of the telephone.

Steady on when the handset is within range of the base. Flashes when the handset is in marginal range of the base. Off when out of range of the base or cannot communicate with the base.

Steady on when a call is in progress. Flashes when there is an incoming call.

On when the speakerphone is turned on. Steady on when an intercom call is in progress.

Flashes during intercom ringing. Steady on when the telephone answering machine (TAM) is turned on.

Flashes when new TAM messages are received.

On when a new TAM message is playing or a new call is viewed in the Call Log.

On when the handset ringer is switched off. Steady on when an alarm is set. Flashes when the alarm time has been reached.

On when the keypad is locked. On when

you have a new Voice Mail message. (This is a caller display

service and is not usually available fr

Indicates when there are more characters or numbers in front of those being displayed.

Indicates when there are more characters or numbers after those being displayed.

Full battery power level.

2/3 battery power level.

1/3 battery power level.

Flashes when low battery power level is detected, needs charging.

Cycle when, battery is charging.

2.3 B ase St ation Overv iew

DELETE Press once to delete the message during playback. Press and hold to delete all the messages. Note: New voice messages will not be deleted.

GETTING TO KNOW YOUR PHONE

om UK network providers.)

GETTING TO KNOW YOUR PHONE

2. VOLUME UP (+) Increase (+) speaker volume during message playback.

3. TAM ON/OFF Press to turn on the answering machine. Press again to turn off the answering machine.

4. SKIP FORWARD Press to skip the current message and play the next message.

5. PLAY/STOP Press to play the message. Press again to stop the message playback.

6. SKIP BACKWARD Press to repeat playing the current message from the beginning. Press twice to skip backward to the previous message.

7. VOLUME DOWN (-) Decrease (-) speaker volume during message playback.

8. PAGE Press the Page on the base station to page your registered handset(s).

Press and hold to start registration process.

2.4 Base Two Digit-LED Display Information 0F-> --

0n-> XX

Displayed when the answering machine is turned OFF Displayed when the answering machine is turned ON where XX is number of messages in T

AM memory. 00 Steady ON: No voice messages in the TAM. XX Flashing: There are XX new messages recorded where XX is from 01 to 59. ZZ Steady ON: There are ZZ old messages

in the TAM memory no new

and

messages.

XX/FF Flashing XX alternately with FF: There are XX new voice messages recorded and

the TAM memory is full.

FF Flashing FF: The TAM memory is full and there are no new messages.

- - /XX Flashing XX alternately with - -: The Time/Date is not set and there are XX new messages recorded.

- - Flashing - -: The Time/Date is not set and there are no new messages recorded.

XX XX Steady ON: Playing the current XX old recorded message.

XX Flashing: Playing the current XX new recorded incoming message.

A1/A2 Steady ON: Playing the current outgoing message (OGM) where A1 is the Answer

& Record OGM and A2 is the Answer Only OGM.

XX/An Flashing XX alternately with An:

Currently recording the new XX incoming

message.

rA Flashing: Remote access is in progress

from a handset or via the external line.

LX Steady ON: Indicates the current volume level where X is from 1 to 8.

2.5 Menu Structure In idle mode, press <MENU/OK> Refer to the following

for the menu structure.

Press <UP> or <DOWN> to go to other options in the menu list. Press <MENU/OK> to enter a sub-menu or function. Press <C> to go back to the previous level.

to go to CONTACTS, the first option in the menu list.

GETTING TO KNOW YOUR PHONE

<UP/

DOWN>

RINGER TONE EQLIZER SEL BASE LANGUAGE HS NAME DISPLAY AUTO ANS MEM KEY MAILBOX

LOG

Review Call Log Under a selected Call Log entry: STORE DELETE DEL ALL DETAILS CATEGO RY

<UP/

DOWN>

BS SET HS SET CLOCK ALARM REGISTER DEFAULT TAM

RINGER RING VOL DEL HS

DIALMODE FLASH CHG PIN

Key Press

<MENU >

Main

CONTACTS CALL

Sub

Review

contacts list Under a Contacts entry:

ADD VIEW EDIT DELETE DEL ALL CAPACITY FASTDIAL

2.6 Text and Digit Entry Table The following tables show you where each letter and punctuation character can be found, by

using repeatedpresses of the alphanumeric keypad.

his will be helpful when storing a name in the contacts and renaming your handset.

T In editing mode, a cursor is displayed to indicate the current text entry position. It is positioned at the right of the last character entered.

Writing Tips:

1. Once a character is selected, the cursor will move to the next position after a short pause.

2. You can move the cursor within the text with the <UP/DOWN> keys to amend the text entry.

3. Press <C> to delete the last character.

4. Press and hold <C> to delete the entire text string.

<UP/

DOWN>

DATE FMT TIME FMT SET TIME SET DATE

ON OFF

<UP/

DOWN>

<UP/ O

WN>

2.6.1 English Character Set

Alphanumeric Editing

Key

1st 2nd3rd 4th 5th 6th 7th 8th 9th 10th

press

1 space - 1 1 2 A B C 2 2 3 D E F 3 3 4 G H I 4 4 5 J K L 5 5 6 M N O 6 6 7 P Q R S 7 7 8 T U V 8 8 9 W X Y Z 9 9 0 0 0, P (Pause) * * ? / \ ( ) * # # ‘ , - . & #

(For contacts name editing and renaming handset)

Number Editing

(For phone number editing,

date/time editing)

<UP/

DOWN>

PLAYBACK DEL ALL MEMO ON/OFF SETTINGS ANS MODE LANGUAGE OGM SET ANS DLAY REC TIME REMOTE COMPRESS CHG PIN

GETTING TO KNOW YOUR PHONE

2.6.4 Greek Character Set

Key

Key press

1 SP - 1 1

2 Α Β Γ 2 2 3 Δ Ε Ζ 3 3 4 Η Θ Ι 4 4 5 Κ Λ Μ 5 5 6 Ν Ξ Ο 6 6 7 Π Ρ Σ 7 7 8 Τ Υ Φ 8 8 9 Χ Ψ Ω 9 9 0 0 0, P (Pause) * * # #

2.6.5 Russian Character Set

Key press

1 SP - 1 1 2 А Б В Г 2 2

3 Д Е Ж З 3 3 4 И Й К Л 4 4 5 М Н О П 5 5 6 Р С Т У 6 6 7 8 Ш Щ Ъ Ы 8 8 9 Ь Э Ю Я 9 9 0 0 0, P (Pause)

* * # #

1st 2nd3rd 4th 5th 6th 7th 8th 9th 10th

Key

1st 2

(For contacts name editing and renaming handset)

* * ? / \

# ‘ , - . &

(For contacts name editing and renaming handset)

Ф Х Ц Ч 7

* * ? / \

# ‘ , - . &

Alphanumeric Editing

( )

Alphanumeric Editing

•

3rd 4th 5th 6th 7th 8th 9th 10th

( )

2 13

Number Editing

(For phone number editing,

date/time editing)

Number Editing

(For phone number editing,

date/time editing)

GETTING TO KNOW YOUR PHONE

3 USING YOUR PHONE

3.1 Make a Call

3.1.1 Preparatory Dialling Enter the phone number and press <TALK ON/SPEAKERPHONE> to dial the number, press it again to

turn on the speakerphone.

3.1.2 Direct Dialling Press <TALK ON/SPEAKERPHONE> to connect to the line and then enter the phone number.

you ente r

a wrong digit you cannot

again to turn on the

3.1.3 Call from the Contacts List Press <MENU/OK> to access the contacts list and press <UP/DOWN> to select the desired phonebook

entry. Press <TALK

speakerphone.

3.1.4 Call from the Call Log Press <UP> to access the call log and press <UP/DOWN> to select the desired call log entry. Press <TALK ON/SPEAKERPHONE> to dial out to the selected call log entry. Press it again to turn on the speakerphone.

Alternatively, press <MENU/OK> and <UP/DOWN> to acce

3.1.5 Call from the redial list Press <DOWN> to access the redial list and press <UP/DOWN> to select the desired redial number. Press <TALK ON/SPEAKERPHONE> to dial out to the selected redial number. Press it again to turn on the speakerphone.

3.1.6 Call timer Your handset automatically times the duration of every call. The call timer

answer a

a call.

It is shown in hours, minutes and seconds format (HH:MM:SS).

3.2 Make a cal l f ro m d ir ect m emory

A direct memory key, M1, M2 or M3 must be programmed with a number before it can be used. Please see section 6.3.11 for details.

In idle, press and hold <M1>/<M2>/<M3> to dial the number pre-stored into the respective key. OR Press <TALK ON/SPEAKERPHONE>, and then press and hold <M1>/<M2>/<M3> to dial the number pre-stored into the respective key.

- If no number is stored, you will hear a double beeps tone.

3.3 Answer a Call If the handset is not on the base or a charging cradle: When the phone rings, press <TALK ON/SPEAKERPHONE> to answer a call, press it again to turn on the speakerphone.

If the handset is on the base or charging cradle and if AUTO ANS is set to ON: when the phone rings, pick up the handset to answer

3.4 Audio Boost Feature The audio boost feature allows you to amplify the handset earpiece volume to compensate for the ear’s limited sensitivity.

ON/SPEAKERPHONE> to dial out to the selected entry

call or 15 seconds after dialling and remains on the,

When entering the number, if you make a mistake, press

speakerphone.

correct it with the <C> key.) Press <TALK

ss the call log from the main menu.

screen for 5 seconds after the end of

keys (M1-M3)

the call automatically, without having to press an button.

<C> to delete digits.

ON/SPEAKERPHONE>

. Press it again to turn on the

is displayed as soon as you

( Note: if

USING YOUR PHONE

1. To turn on the audio boost feature, press <AMPLIFY> at any time during a call. The handset top indicator turns on.

2. When the audio boost feature is activated, press <Slide UP/DOWN> to increase or decrease the

earpiece volume within the specific frequency range set in Equalizer. See section 7.3.5 for more details.

3. To turn off the audio boost feature and return the earpiece volume back to normal, press <AMPLIFY>

again and the handset top indicator light turns off.

- The audio boost feature will be turned off automatically when the call is ended.

3.5 End a Call

During a call connection, press <TALK OFF> to end the call. OR Put the handset on the base station or charging cradle to end the call.

3.6 Adjust Earpiece and Handsfree Volume

There are 5 levels (VOLUME 1 to VOLUME 5) to choose from for each of the earpiece and handsfree volumes.

During a call: Press <UP/DOWN> to select volume 1-5. The current setting is shown. When you end the call, the setting will remain at the last selected level.

3.7 Mute a Call

You can talk to someone nearby without letting the caller hear you during a call. During a call: Press < > to mute the microphone and “MUTED” will display on the screen. Your caller cannot

hear you. Press < > again to unmute the microphone.

3.8 To Turn the Handset Ringer Off

In idle mode, press and hold the <#> key to turn off the handset ringer. The ringer off icon < > will be displayed. When the ringer is off, press and hold the <#> key to turn on t

< > will turn off.

3.9 Turn on the Keypad Lock

In idle mode, press and hold the <*> key to turn on the keypad lock. The keypad lock icon “ will be displayed

Note: You can still use the <TALK ON> key to answer a call when the handset is ringing.

In ke pad lock mode, press and hold the <*> key to turn off the keypad lock. The keypad lock icon “ ” will turn off.

3.10 Redial the last number

You can redial any of the 5 last numbers called. If you have stored a name in the phonebook to go with the at

the top

number, shows a name will be displayed instead. The most recent last number will display

redial list.

of the

he handset ringer. The ringer off icon

”

3.10.1 Redial a Number from the Redial List

1. In idle mode, press <DOWN> to access the redial list.

Note: If the redial entry shows a name, press the <#> key to view the number.

2. Press <UP/DOWN> to browse the redial list.

3. Press <TALK ON/SPEAKERPHONE> to dial the selected redial number.

Note: If there are no numbers in the redial list, the display shows “EMPTY”.

3.10.2 Store a Redial Number into your ontacts list

1. Follow Steps 1 and 2 in section

2. Press <MENU/OK> and <UP/DOWN> to select STORE.

3.10.1.

14 15

USING YOUR PHONE

3. Press < OK> enter the name you want to use in your Contacts list.

4. Press <MENU/OK> and then modify the number, if necessary.

5. Press <MENU/OK> to show RING 1.

6. Press <UP/DOWN> to browse the ring tone list. The respective

MENU/ and then

when browsing the ring tone list. (Note: the selected ring tone will subscribe to Caller Display and the

incoming number matches the stored number.)

ring tone will be played

only be played if you

7. Press <MENU/OK> to confirm the selected ring tone and to save the entry.

3.10.3 Delete a Redial Number

1. Follow Steps 1 and 2 in section 3.10.1.

2. Press <MENU/OK> and <UP/DOWN> to select DELETE.

3. Press <MENU/OK> to confirm and the entry will be deleted.

3.10.4 Delete all Redial List entries.

1. Follow Steps 1 and 2 in section 3.10.1.

2. Press <MENU/OK> and <UP/DOWN> to select DEL ALL

3. Press <MENU/OK> to display CONFIRM?

4. Press

<MENU/OK> again to confirm.

All entries will be deleted and the display will show EMPTY.

3.11 Find the Handset You can locate the handset by pressing <PAGE> on the base station. All the handsets registered to the base will produce the paging tone and show “PAGING” on the screen. You can stop the paging by pressing <TALK ON/SPEAKERPHONE> / <TALK OFF> / <C> on any handset or <PAGE> on the base again. Note: If there is an incoming call during paging, the phone will ring with the incoming call instead of paging.

3.12 Make an Internal Call This feature is only applicable when there are at least two registered handsets. It allows you to make internal calls, transfer external calls from one handset to another handset and make conference calls. If the called handset is not answered within 60 seconds, the called handset will stop ringing and the calling handset will return to standby mode.

Note: If only one handset is registered to the base station, when <C/MUTE/INT> is pressed, it will display “FAILED”.

3.12.1 Intercom Another Handset

1. In idle mode, press <C/MUTE/INT> and all the other registered handset numbers will display, alone with a “9”.

2. Enter the

3. The called handset rings. Press <TALK ON/SPEAKERPHONE> on the called handset to establish

Note: If only two handsets are registered to the base station, pressing <C/MUTE/INT> will call the other handset immediately.

Note: If there is an external call while you are on an intercom call, you'll hear warning beeps, and will have to end the intercom call before you can answer the external call.

3.12.2 Call All Handsets

1. In idle mode, press <CLEAR/MUTE/INT> and the registered handset numbers will display.

2. Press <9> to ring to all registered handsets.

number of the handset that you want to call, or enter <9> to call all handsets.

the internal call.

3.12.3 Transfer an External Call to another handset

CONTACTS PHONEBOOK

During an external call:

1. Press <MENU/OK> and <UP/DOWN> to select INTERCOM.

2. Press

<MENU/OK> to show all the other registered handset numbers, plus "9".

Enter the number for the handset you want to transfer the call to.

3. The external call is put on hold automatically and the called handset rings.

4. Press <TALK ON/SPEAKERPHONE> on the called handset to establish an internal call.

5. Press <TALK OFF> on the calling handset or put the calling handset on the charging cradle to end the current call with the external party.

6. The external call is transferred to the called handset.

Note: If the other handset has not answered the intercom call, you can stop the intercom and return to the external call by pressing <TALK OFF> at any time. If the other handset does not answer the intercom call within 30 seconds, the intercom will stop and you will return to the external call automatically.

3.12.4 Make a 3-way Conference Call

The conference call feature allows one external call to be shared with two handsets (in intercom). The three parties can share the conversation and no additional network subscription is required. During an external call:

1. Follow Steps 1 to 4 in section

2. Press and hold the <*> key on the calling handset to establish the conference call.

Either handset can exit the conf erence by pressing <TALK OFF>, leaving the other handset still connected to the external call.

4 PRIVATE PHONEBOOK-CONTACTS Each handset can store up to 20 privat

phonebook entry can have a maximum of 20 digits for the phone number and 8 characters for the name. You can also select different ringtones for your phonebook

ringtones only play if you subscribe to Caller Display andthe incoming number matches the stored number.)

Phonebook entries are stored alphabetically by name.

4.1 Add a New Contacts Entry

1. From idle model, press <MENU/OK> to show and then press <MENU/OK> to enter the contacts list.

2. Press <MENU/OK> to show ADD.

3. Press <MENU/OK> and then to enter the name.

4. Press <MENU/OK> and then to enter the number.

5. Press <MENU/OK> and <UP/DOWN> to select the desired ringtone for your phonebook entry.

6. Press <MENU/OK> to store the phonebook entry.

4.2 Sear ch fo r

1. From idle model, press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Enter the first

2 key three times), and then press <UP/DOWN> to scroll to the entry you want.

4.3 View a Contacts Entry

1. From idle model, press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Press <UP/DOWN> to select the desired contact entry.

3. Press <MENU/OK> and <UP/DOWN> to select VIEW.

4. Press <MENU/OK> and <UP/DOWN> to review the name, number and melody of the selected

phonebook entry.

a Co nt act s Entry

letter of the name using the alphanumeric keys (e.g. if it begins with C, press the

3.12.3.

e phonebook entries with names and numbers. Each

entries. (Note: the different

CONTACTS

You can also use the codes on the other side of this card

(Default Remote Access PIN is 0000) to activate the remote access feature.

You can then enter the 4-digit remote access PIN

the remote access mode after 10 rings.

automatically.

PIN should follow without any delays.. If the 4-digit Remote Access

Note: If your answering machine is switched off, the phone will enter into

PIN is entered incorrectly three times

consecutively, the line will be release

The default code is 0000. For details of how to set a new code,

see the User Guide

Note: <*> key must be entered while the OGM is still playing, and the 4-digit

The

7.5.8.1 on page 2 .

Using a tone-dialling phone, dial your home number

While your outgoing message is playing, press

Key in your remote security code

BB3725 system

Remote operation

CONTACTS PHONEBOOK

Note: If number is more than 8 digits, press

4.4 Edit a Contacts Entry

1. From idle model, press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Press <UP/DOWN> to select the desired contact entry.

3. Press <MENU/OK> and <UP/DOWN> to select EDIT.

4. Press

<MENU/OK> to display the current name.

5. Edit the name

the name.

6. Edit the number

confirm the number.

7. Press <UP/DOWN> to select the ringtone and press <MENU/OK> to confirm.

4.5 Delete a Contacts Entry

1. From idle model, press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter

confirm the number.

2. Press <UP/DOWN> to select the contact entry you want to delete.

3. Press <MENU/OK> and <UP/DOWN> to select DELETE.

4. Press

4.6 Delete All Contact Entires

1. Press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Press <MENU/OK> and <UP/DOWN> to select DEL ALL .

3. Press <MENU/OK> to show CONFIRM?

4. Press

4.7 Check the Contacts Usage You can check how many contact entries

available for you to store in the Contacts list.

1. Press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Press <MENU/OK> and <UP/DOWN> to select CAPACITY.

3. Press

<14/20> means

4.8 Set the Fast Dial Numbers

Up to 8 of your Contact entries can be allocated to a fast dial key (from 2 to 9), where you can

dial the number from idle mode by simply pressing and holding the appropriate digit key for

more than 2 seconds. If no fast dial number is stored, you will hear a double-beep tone when the key is held down.

using the <C/MUTE/INT> key to delete letters, and press <MENU/OK> to confirm

using the <C/MUTE/INT> key to delete numbers, and press <MENU/OK> to

<MENU/OK> to confirm, and the entry will be deleted.

<MENU/OK> to confirm. All entries will be deleted and the display will show EMPTY.

<MENU/OK> to display how much of the contacts phonebook is being used, for example

14 entries are stored out of the total of 20 available spaces

the <*> key or <#> key to view the remaining

and stored in your handset and how many spaces are

digits.

4.8.1 Add or Edit the Fast Dial Number

1. Press <MENU/OK> to show CONTACTS and then press <MENU/OK> to enter the contacts list.

2. Press <MENU/OK> and <UP/DOWN> to select FASTDIAL.

3. Press

<MENU/OK> and <UP/DOWN> to show the digit key from 2 to 9 that you want to set.

Then press <MENU/OK> to select it.

If EMPTY is displayed briefly, there is no number stored in the selected key:

4. Press <UP/DOWN> to select an entry from the contacts list.

5. Press <MENU/OK> to

If a name is displayed, there is already a number stored in the selected key:

4. Press <MENU/OK> to select EDIT.

save the new number in the selected fastdial key.

5. Press <MENU/OK> and then <UP/DOWN> to select an entry from the contacts list.

CALLER DISPLAY

6. Press <MENU/OK> to save the new number in the selected fastdial key.

4.8.2 Delete a Fast Dial Number

1. Repeat the steps 1 to 3 in section 4.8.1.

3. Press <MENU/OK> to confirm the delete.

5 CALLER DISPLAY (NETWORK DEPENDENT) This feature is available if you have subscribed the Caller Line Identification service with your network

service provider. Your phone can store up to 10 received calls with date/time information in the Call Log. The number willshown on the screen when the phone is ringing. If the number matches with one of the entries in your Contacts be list, the caller’s name stored in alternately with the number and the handset will ring with the ring tone associated with that contacts entry.

If the call is from someone who withheld their number, e.g. by dialling 141, WITHHELD will display.

If the call is from someone whose number is unavailable, e.g. an international call or from a private exchange, OUT AREA will display. If you've got new Caller Display records, the handsets will display X CALLS in standby mode, where X is the number of new calls. The new calls indication will remain until all the new call

records have been viewed, and each handset has to clear its own new calls.

5.1 View the Call Log All received calls are saved in the call log with the latest call at the top of the list. When the call log is full, the oldest call will be replaced by a new call. Any unanswered calls which have not been viewed are marked with a <

1. Press <UP> to access the call list. Or Press <MENUOK> then <UP/DOWN> to show CALL LOG

2. Press <UP/DOWN> to select the desired entry. 3 Press <#> to view the caller’s number if applicable.

4. Press <MENU/OK> then <UP/DOWN> to show DETAILS, and then <MENU/OK> to display the date of the call. Press <# > to see the t ime of t he call, and press <MENU/OK> to return to the name or number.

5.2 Store a Call Log Number into the Contacts

1. Follow Steps 1 and 2 in Section

2. Press <MENU/OK> and <UP/DOWN> to show STORE.

3. Press <MENU/OK> and then to enter the name.

4. Press <MENU/OK> and the selected call log number is displayed.

5. Edit the number if necessary.

6. Press <MENU/OK> and <UP/DOWN> to select the ringtone.

7. Press

<MENU/OK> to store the entry in the Contacts list, and return to the Call Log.

5.3 Delete an entry from the Call Log

1. Follow Steps 1 and 2 in Section 5.1.

2. Press <MENU/OK> and <UP/DOWN> to show DELETE.

3. Press <MENU/OK> to confirm.

5.4 Delete all Call Log entires

1. Follow Steps 1 and 2 in Section

2. Press <MENU/OK> and <UP/DOWN> to show DEL ALL .

3. Press <MENU/OK> to display CONFIRM?.

4. Press

<MENU/OK> to confirm. All entries will be deleted and the display will show EMPTY.

> at the top of the display.

5.1.

DELETE.2. Press <MENU/OK> and <UP/DOWN> to select

the Contact list will be displayed

and then <MENU/OK> to select it.

PHONE SETTINGS

5.5 Call Log Category

You can set the handset to record all received calls or only missed calls in the Call Log.

1. Follow Steps 1 and 2 in Section 5.1.

2. Press <MENU/OK> and <UP/DOWN> to show

3. Press <MENU/OK> and then <UP/DOWN> to

4. Press <MENU/OK> to confirm the chosen option.

6 PHONE SETTINGS

Your phone comes with a selection of settings that you can change to personalise your phone the way you like it to work.

6.1 Clock Settings

If you subscribe to the Caller Display service, the time and date settings will be updated automatically when you receive an incoming call, although you may need to set the correct year. Otherwise you will need to set the correct time and date so that the you know when you received answering machine messages, or if you want to display the

CATEGORY.

show ALL or MISSED.

time in standby mode.

6.1.1 Change the Date Format

1. Press <MENU/OK> and <UP/DOWN> to show .

2. Press <MENU/OK> and <UP/DOWN> to select DATE FMT.

3. Press

<MENU/OK> and then <UP/DOWN> to choose a date format of either DDMMYY

or MMDDYY.

4. Press <MENU/OK> to confirm your choice.

6.1.2 Change the Time Format

1. Press <MENU/OK> and <UP/DOWN> to show CLOCK.

2. Press <MENU/OK> and <UP/DOWN> to select TIME FMT.

3. Press

<MENU/OK> and then <UP/DOWN> to choose a time format of either 12HR or 24HR.

4. Press <MENU/OK> to confirm your choice.

6.1.3 Set the Time

1. Press <MENU/OK> and <UP/DOWN> to show CLOCK.

2. Press <MENU/OK> and <UP/DOWN> to select SET TIME.

3. Press <MENU/OK> and then to enter the time information

4. Press <MENU/OK> to confirm your setting. Note: If time has been set before, the current time will display, otherwise, “HH:MM” will display.

6.1.4 Set the Date

1. Press <MENU/OK> and <UP/DOWN> to show CLOCK.

2. Press <MENU/OK> and <UP/DOWN> to select SET DATE.

3. Press <MENU/OK> to enter the date information 7.1.1.

4. Press <MENU/OK> to confirm your setting. Note: If date has been set before, the current date will display, otherwise, “DDMMYY” will display.

6.2 Alarm Settings

You can set an alarm time on this phone. When an al handset display. When the alarm time is reached, the < > and “ALARM ON ” flash on the handset display, and thealarm tone rings for 45 seconds. You can press any ke

CLOCK

in 24 hour format.

in the format you set in section

arm is set, the < > is shown on the

y to disable the alarm. If snooze

PHONE SETTINGS PHONE SETTINGS

function is activated, the alarm will sound again at the end of the snooze period of 7 minutes.

can also press and hold <TALK OFF> snooze function.

Note: a.

A key press will still disable the alarm even if the handset keypad is locked when the alarm rings.

b. The alarm volume level is the same as the settings of the handset ringer volume. If the

handset ringer is set to

c. During an external call or internal call, if an alarm is set and when the alarm time is reached,

the < to alert the user the alarm holds <TALK OFF> to disable the alarm, the

d. During paging or ringing, the alarm will not sound when the alarm time is reached. However,

if the snooze

again at the end of the

.2.1 Turn on/off the Alarm

1. Press <MENU/OK> and <UP/DOWN> to select ALARM.

2. Press <MENU/OK> and <UP/DOWN> to show ON or OFF .

3. Press <MENU/OK> to confirm your choice. Note: If ON is selected, you will be prompted to set the alarm time.

6.2.2 Set the Alarm Time (if the Alarm is set to be ON)

1. Follow Steps 1 to 4 in Section .

2. Enter the alarm time in 24 hour format.

3. Press <MENU/OK> to display SNOOZE.

4. Press <MENU/OK> and <UP/DOWN> to show ON or OFF.

5. Press <MENU/OK> to confirm your setting.

6.3 Handset Settings

7.3.1 Set the Ringer Melody for Internal Calls

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select RINGER.

3. Press <MENU/OK> and <UP/DOWN> to select INT RING.

4. Press <MENU/OK> and <UP/DOWN> to select the

calls.

Note:

5. Press < OK> to confirm.

6.3.2 Set the Ringer Melody for External Calls

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press < OK> and <UP/DOWN> to select RINGER.

3. Press <MENU/OK> and <UP/DOWN> to select EXT RING.

4. Press <MENU/OK> and <UP/DOWN> to select the

calls.

Note:

5. Press <MENU/OK> to confirm.

6.3.3 Set the Ringer Volume

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select RINGER.

3. Press <MENU/OK> and <UP/DOWN> to select RING VOL.

and “ALARM ON ” will still flash. An alarm tone will be emitted from the earpiece

funtion is enabled and there is no paging or ringing, the alarm will sound

There are 10 ring tones, and each will play as you step through the list.

MENU/

There are 10 ring tones, and each will play as you step through the list.

while the alarm is sounding, to stop the alarm and turn

OFF, the alarm still sounds at VOLUME 1 level.

time is reached. Once the user presses any key or presses and

display will revert to the call duration .

snooze period.

6.2.1

ringtone you want to hear for internal

ringtone you want to hear for external

2 2

1 2

You

off the

4. Press <MENU/OK> and <UP/DOWN> to select the desired ringer volume (a total of 6 ringer

levels including

volume Note: The respective ringer volume will be played during your selection. If OFF is selected,

ringer off

icon

5. Press <MENU/OK> to confirm.

6.3.4 Set Alert Tones

Three different alert tones are set on by default, but can be turned off, if desired. Key Tone - a single beep is emitted when you press a key. Low Battery Tone - emitted while you are talking on the phone to alert you that you need to charge the handset batteries. Out of Range Tone - emitted while you are talking on the phone to alert you to move closer to the base unit, before the call is lost.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select TONE.

3. Press <MENU/OK> and <UP/DOWN> to select KEY TONE / LOW BATT / OUTRANGE

4. Press <MENU/OK> and <UP/DOWN> to turn these tones ON or OFF.

5. Press <MENU/OK> to confirm.

6.3.5 Set the Equalizer The phone has three different frequency range

the sound i

to adjust

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select EQLIZER.

3. Press <MENU/OK> and <UP/DOWN> to select NORMAL, BASS or TREBLE.

4. Press <MENU/OK> to confirm the setting.

6.3.6 Select Base

If you have registered the handset to more than one base, you can select any one of them to use with your your handset.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select SEL BASE.

3. Press <MENU/OK> and <UP/DOWN> to select the desired base.

(Note: the currently selected base is indicated by a *.)

4. Press <MENU/OK> to confirm.

base.

6.3.7 Set the Handset Language

OFF).

< > will be displayed after confirming .

n the earpiece to suit your

filters (NORMAL, BASS, TREBLE) that you can set,

preference.

Note: you can only use the handset with one base at any one time.

Note: the handset may take a short while to search for the new

the

The language used on the handset display may be changed from English, if required.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select LANGUAGE.

3. Press <MENU/OK> and <UP/DOWN> to select the desired language.

4. Press <MENU/OK> to confirm.

6.3.8 Rename the Handset

The handset name, displayed in the standby mode (default HS), can be changed to any other name of up to 6 letters.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select HS NAME.

3. Press <MENU/OK> and enter the name, of up to 6 letters for your handset.

4. Press <MENU/OK> to confirm.

PHONE SETTINGS

6.3.9 Choose the Information to be displayed in Idle

You can choose to display the time or handset name in your idle screen.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select DISPLAY.

3. Press <MENU/OK> and <UP/DOWN> to select HS NAME or TIME.

4. Press <MENU/OK> to confirm.

6.3.10 Set the Auto Answer

If you turn on the Auto Answer, you can

handset off

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select AUTO ANS.

3. Press <MENU/OK> and <UP/DOWN> to turn ON or OFF the auto answer feature.

4. Press <MENU/OK> to confirm.

the base or charger, without having to press

answer a call automatically by just lifting the

any key.

6.3.11 Set the Direct Memory Keys

There are three direct memory keys M1, M2 and M3. You can store

into each of

digits

the key

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select MEM KEY.

3. Press <NENU/OK> and <UP/DOWN> to select the desired memory key from M1, M2

and M3.

4. Press <MENU/OK> to enter a new number or edit the number stored already.

5. Press <MENU/OK> to confirm

these keys and dial them

for more than 2 seconds.

directly from idle

a number of up to 20

mode, by pressing and holding

6.3.12 Set the Mailbox Number

You can store a number of up to 20 digits, which can be dialled out directly from idle mode by pressing and holding the digit <1> key for more than 2 seconds. This may be used to store your network voice mail number, such as 1571, for easy access to that service.

1. Press <MENU/OK> and <UP/DOWN> to select HS SET.

2. Press <MENU/OK> and <UP/DOWN> to select MAILBOX.

3. Press <MENU/OK> and then enter a new number or edit the mailbox number.

4. Press <MENU/OK> to confirm.

6.4 Base Settings

6.4.1 Set the Base Ringer Melody

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select RINGER.

3. Press <MENU/OK> and <UP/DOWN> to select the desired ringer melody (a total of 5 melodies for your Note: The respective ringer melody will be played while browsing the melody list.

4. Press <MENU/OK> to confirm.

6.4.2 Set the Ringer Volume

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select RING VOL.

3. Press <MENU/OK> and <UP/DOWN> to select the desired ringer volume (a total of 6 ringer volume

selection)

levels

including

OFF).

PHONE SETTINGS

Note: The respective ringer volume will be played during your selection.

4. Press <MENU/OK> to confirm.

6.4.3 De-register a Handset

This operation should only be necessary if one of your handsets becomes faulty or lost and needs to be replaced. You will need to enter the 4-digit system PIN (Default PIN is 0000) in order to de-register a handset from the base station. A de-registered handset will have the antenna flashing and --UNREG-- on the display.

Note: You cannot de-register the handset that you are currently using.

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select DEL HS.

3. Press <MENU/OK> and

4. Enter the 4-digit system PIN.

5. Press <MENU/OK> and the first handset number is displayed.

6. Press <UP/DOWN> to you want to de-register.

of the

handset

7. Press <MENU/OK> to confirm, and the chosen handset will be de-registered.

6.4.4 Change the Dial Mode

You should normally leave the Dial Mode at its default setting of TONE (also called DTMF) unless the phone is connected to an old exchange that only recognises PULSE dialling. Note: If PULSE dialling is set, you can press the * key to switch to TONE dialling for the rest of that call.

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select DIALMODE.

3. Press <MENU/OK> and <UP/DOWN> to select TONE or PULSE.

4. Press <MENU/OK> to confirm.

6.4.5 Change the Recall(Flash) Time

the display shows PIN?---

step through the list of registered handsets, and select the number

You may need to change the recall (flash) time if your phone is connected to a PBX. The recall time options are SHORT (the default value of 100ms), MID (300ms) or

LONG (600ms).

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select FLASH.

3. Press <MENU/OK> and <UP/DOWN> to select your desired recall(flash) time (SHORT, MID,

LONG).

4. Press <MENU/OK> to confirm.

.4.6 Change the System PIN Code

6 A 4-digit system PIN code is used for changing the system settings of the base station. It is used to protect your phone against unauthorised use. The default system PIN code is 0000.

1. Press <MENU/OK> and <UP/DOWN> to select BS SET.

2. Press <MENU/OK> and <UP/DOWN> to select CHG PIN.

3. Press <MENU/OK> and

4. Press <MENU/OK> and the enter the old system PIN.

5. Press

<MENU/OK>, the display shows NEW PIN , press <MENU/OK> and enter your

new 4-digit

6. Press

new 4-digit

system PIN.

<MENU/OK>, the display shows CONFIRM?, press <MENU/OK> and enter your

system PIN again.

the display shows OLD PIN?

Play the message

Turn on the answering machine

Turn off the answering machine

Keys

While message is not playing

Functions

Repeat playing the current message

message.

Skip to play the next message

Stop the current message playback

skip backward to play the previous

Stop the current message playback

Delete the current message playing.

from the beginning. Press twice to

While message is playing

PHONE SETTINGS

Note: If the new PIN entered in Step 6 is not

5, you must

7. Press <MENU/OK> to confirm.

.5 Reg is tr ati on

IMPORTANT: When you purchase a BB3725 system, all handsets are already registered to your base, so you do not need to register them. Handset registration is only necessary when you buy extra handsets or if a handset has

enter your new PIN at step 5 again.

the same as the new system PIN entered in Step

become faulty. You can register additional handsets to have up to 5 handsets per base unit, with each

handset's number (1 to 5) shown on its display. Each handset can be registered to up to 4 different bases, but can only operate with one

base at a time. (See 6.3.6 Select Base, for how to change between bases.)

1. Press and hold <PAGE> on the base station for more then five seconds, to put the base

following handset sequence must be completed within this time.

2. Press <MENU/OK> and <UP/DOWN> to select REGISTER

3. Press <MENU/OK> to display BASE 1.

4. Press <UP/DOWN> to select which base number you want to use. (Note: a * will be shown next the new registration will overwrite it.)

5. Press <MENU/OK> to display PIN?----.

6. Enter the 4-digit system PIN (default is 0000).

7. Press <MENU/OK> to confirm, and the display will show SEARCH'G.

If the handset registration is successful,

the new handsetnumber a

The handset will automatically be allocated the next available handset number.

handset registration is

.6 Reset Yo ur Pho ne

You can reset your phone to the default settings. After reset, all your personal settings

including your PIN

answering machine messages will be

although the direct memory keys deleted.

1. Press <MENU/OK> and <UP/DOWN> to select DEFAULT .

2. Press <MENU/OK> and you are requested to enter the 4-digit

3. Enter the 4-digit system PIN.

4. Press <MENU/OK> to show CONFIRM?

5. Press <MENU/OK> again to confirm the reset.

to any base numbers the handset is already registered with, and if selected

nd the <antenna icon> will stop flashing.

the display will change to standby mode with

unsuccessful, the <antenna icon> will still flash.

numbers,

the redial list and

(M1-3) and the

call log entries will be

but your phonebook remains unchangeed,

erased,

Mailbox (key 1) memory will be

1 minute, so the station intoregistration mode. It will stay in registration mode for about

If the

and all

deleted,

PIN (default = 0000)

ANSWERING MACHINE

7.5.7 Change the Compression Rate Three different compression rates (HIGH, MID and LOW) are provided for you to select different quality levels of recording incoming message. The lower the compression rate, the

higher the recording quality level attained,attained, but the shorter the total recording time

available. (LOW=7 minutes, MID=10 minutes, HIGH=16 minutes, approximately.)

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select COMPRESS.

4. Press <MENU/OK> and <UP/DOWN> to select your desired compression rate.

(The currently selected option is indicated with a "*".)

5. Press <MENU/OK> to confirm.

7.5.8 Activate Remote Access Your phone lets you check your messages, or otherwise operate your answering machine, by calling the answering machine when you are away from home and then entering a 4-digit

prevent other peopl

7.5.8.1 Change the 4-Digit Remote Access PIN

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select CHG PIN.

4. Press (Default Remote Access PIN is 0000) .

5. Press

4-digit PIN.

6. Press <MENU/OK> to show CONFIRM? Press <MENU/OK> again and then enter the New PIN again.

Note: If the new PIN entered in Step 6 is not

must enter your new PIN at step 5 again.

you

7 Press <MENU/OK> to confirm

7.5.8.2 Activate or Deactivate the Remote Access

The Remote Access is activated by default, but you can deactivate it to prevent any external access.

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select REMOTE.

4. Press <MENU/OK> and <UP/DOWN> to select ON or OFF to

respectively.

or off,

5. Press <MENU/OK> to confirm.

7.5.8.3 Access Your Answering Machine Remotely You can ring your phone from another tone-dialling phone to switch the answering machine on or off and/or

1. Place a call from a tone-dialling phone to your phone.

2. When the answering machine answers the call and starts playing the OGM, press

Press

Note: <C> at any time during the recording or playing back to return to the previous screen

e from unauthorised

<MENU/OK> to show NEW PIN?, press <MENU/OK> again and then enter your new

(The currently selected option is indicated with a "*".)

listen to your messages remotely.

without saving the personalised OGM.

tone-diremote access PIN from a alling phone. the 4-digit remote access PIN code is used to

access of your answering machine.

KO/UNEM< sserp ,?NIP D LO wohs ot >KO/UNEM< > again and then

the same as the new system PIN entered

enter the Old PIN

in Step 5,

turn the remote access on

<KEY *>.

ANSWERING MACHINE

7 ANSWERING MACHINE (TAM ) Your phone includes a telephone answering machine that records unanswered calls when it is on. The LED message counter (two digits seven segment display) on the base will show the number of the messages when the answering machine is on. The answering machine can store up to 59 messages within the maximum recording time of

rate set (see section 7.3.8).

As well as recording incoming messages, you can record memos for other

the answering

handset's name or time,

7.1 Turn On/Off the Answering Machine You can turn the answering machine on or off using the base or handset. When the answering

machine is set toON, calls will be answered after the set answer delay and

Record mode is set, the cal l er can

set to OFF, calls will be answered after 10 rings and to your callers. They will not be able to leave you a message.

Using the Base:

1. Press <TAM ON/OFF> on the base station. Using the Handset:

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select ON/OFF.

3. Press <MENU/OK> and <UP/DOWN> to select ON or OFF.

4. Press <MENU/OK> to confirm.

screen and the message counter on the base station will display - -.

7.2 Listen to the Messages in the Answering Machine When new messages are recorded on the answering machine, the TAM icon < > flashes on the handset display and the message counter on the base flashes with the number of new messages in the answering machine until all the new messages are played. Old messages will be played after all new messages are played completely. The message counter LED stays steady to

indicate the number of old messages stored in the answering machine.

Listen new messages through the Base:

1. Press <PLAY> on the base station.

2. The new messages are played from the loudspeaker on the base station in the sequence they

are recorded with

3. Press <+> or <-> to increase or decrease the volume during message playback respectively. Note: If there are no new messages, “00” will display steadily in the message counter on the base. Pressing <PLAY> will have no effect.

Listen new messages through the Handset:

1. Press <MENU> and <UP/DOWN> to select TAM.

2. Press <OK> and <UP/DOWN> to select PLAYBACK .

3. Press <OK> to start message playback through the handset loudspeaker and the screen

machine

memory is full, the Handset will display TAM FULL alternately with

depending on the handset standby display mode

messages before any new ones can

emos eteled ot evah lliw uoy dna

then leave you a message. When the

If the answering machine is set to ON, the TAM icon < > displays on the handset screen and the

message counter on the base station will display the number of incoming messages.

If the answering machine is set to OFF, the TAM icon < > will not appear on the handset

the number of that message flashing as it is played.

displays the date of the message received. Press <#> to see the time the message was

received.

up to 17 minutes, depending on the compression

users of your phone. If

be recorded.

if the Answer and

the answer only message will be played

answering machine is

ANSWERING MACHINE

3. Enter the 4-digit Remote Access, Note:

The * must be entered while the OGM is still playing, the OGM will stop, and the

4-digit PIN should follow without any delays.

Note: If the 4-digit Remote Access PIN is entered incorrectly three times consecutively, the line will be released automatically.

4. Press the following keys to carry out your desired function.

Keys

2 4

5 Play the message Stop the current message playback 6

7 Turn on the answering machine 9 Turn off the answering machine

Note: If your answering machine is switched off, the phone will answer the call after 10 rings. You can press <*> and then enter the 4-digit remote access PIN (Default Remote Access PIN is

0000) to activate the remote access feature.

When your answering machine memory is full and the answer mode is in ANS&REC

mode, the

but will still a nswer

It will change back to ANS&REC mode automatically after some messages have been deleted.

7.5.9 Call Screening When the answering machine

screening automatically

Adjust the base

The handset will display SCREEN?, and if <MENU/OK> is pressed you will be able to hear the incoming caller through the handset loudspeaker and the display will change to SCREEN'G.

At any time if you want to pick up the call, you can press <TALK ON/SPEAKERPHONE> on the handset and the message recording will be stopped automatically. If the answering machine is

in the process of recording, the

If you don't want to pick up the call, you can press <MENU/OK> again to listen through the

While message is not playing While message is playing

ANSONLY automatically,

change to

incoming calls a

and you will be able to hear the OGM and the incoming caller.

volume control, if

or preshandset earpiece, s <C> to stop the screening and return the display to SCREEN?

if the PIN is accepted, a long beep is played.

Functions

Delete the current message playback

Skip to repeat playing the current message

from the beginning. Press twice to skip

backward to the previous message.

Skip to play the next message

a nd will no t allow ca llers to leave mes sag es,

fter the pre-set

answers a call, the base will start call

number of rings.

necessary.

message already stored will be saved.

the

mode, the

ANSWERING MACHINE

Press < TALK/SPEAKERPHONE>

Note: The star icon<*> is displayed on the screen to indicate that it is a new message.

message has to that message again.

Note: If there are no new messages, PLAYBACK.

4. During message playback, press <UP> or <DOWN> to increase or decrease the message playback volume Note: After a new message is played, it will be saved as an old message automatically unless it is

,)9.3. 6 noitces ees( tes

deleted.

5. Press <MENU/OK> then <UP/DOWN> to select STOP, FORWARD, PREVIOUS, DELETE to perform the following functions during message playback.

6. Press <MENU/OK> to confirm the function.

Note: Alternatively, you can use the following shortcut keys to control different operations during

message playback.

Press <Key 5> to stop message playback. Press <Key 4> once to repeat playing the current message from the beginning. Press <Key 4> twice to skip Press <Key 6> to skip to play next message. Press <Key 2> to delete the current message

7.3 Delete All Messages in the Answering Machine

Delete all messages using the Base: In idle:

1. Press and hold <DELETE> on the base station until a long beep is played.

2. All the old messages will be deleted.

Note: not be base station.

Delete all messages using the Handset:

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select DEL ALL .

3. Press <MENU/OK> to show CONFIRM?

4. Press <MENU/OK> to delete all old messages.

Note:

7.4 Record Memo

You can record your memo message for another user. When you record a memo, the message counter will increase by one and the message can be played back in the same way as answering machine messages. Memo recording can still function even when the answering machine is turned off.

been played, the STAR icon < > will disappear and will not be shown if

respectively.

STOP: Stop the current message playback and return to the menu. FORWARD: Skip to play the next message. The date or time information of the next message will display if there is another message.

PREVIOUS: Repeat playing the current message from the beginning. The date or time information of the current message will display. DELETE: Delete the current message and start playing the next message.

If three short beeps are heard, there were no old messages to delete. New

deleted. If there are no more messages in the answering machine, “00’’ will

The display briefly shows EMPTY and then returns to DEL ALL.

to play the messages through the handset earpiece

the handset display will briefly show then return to

back to play the previous message.

“00/00’’

PLAYBACK

playing, and start playing the next message.

TROUBLESHOOTING

8 TROUBLESHOOTING

If you have difficulty with your phone, please try the suggestions listed below.

Problem Cause Solutions

a. The connection cord of the base

No dialling tone when pressing <TALK ON/SPEAKERPHONE> key

When connected to a PBX, no and/or wrong connection after dialling.

"SEARCH'G" is displayed.

The call does not work.

No display. Empty battery Recharge battery Answering Machine The unit does not record new messages.

The caller cannot leave a message.

I cannot operate the answering machine remotely.

While recording an outgoing message or listening to messages, the unit rings and recording stops.

If the fault persists: a. Disconnect all other instruments connected to the same telephone line and try to make a call. If the call now works the fault is with the other instruments. b. Disconnect the base unit from the telephone line and plug a different phone into the master telephone socket. If this works the line is ok. c. If the call does not work, and you are using a two-way socket adapter, remove it and plug a telephone directly into the socket. If the call now works, the adapter may be faulty.

This telephone is not equipped with a grounding function! Therefore, some of the functions may

when used in PBX systems.

be limited

station is not plugged in.

b. The adapter cord is not plugged in

correctly in the base station.

Another handset is using the base to make a call.

d. Wrong telephone line cord.

Dialling prefix is needed. Insert the dialling prefix

a. Base station out of range. b. Base station not connected to mains. Service not activated or wrong operator or wrong dialling mode setting

The answering machine is turned off. Turn on the answering machine.

a. The answering machine is turned off. b. Message memory is full.

c. Answer Only mode is set.

a. You are entering the wrong remote access code. b. You are pressing the dial keys too quickly. c.

You are using a pulse telephone.

A call is being received.

a. Check the connections. Unplug

and plug back in the mains. Check that the telephone line cord has been plugged into the base station and the phone socket.

b. Check

the mains adapter is firmly plugged into the mains socket and into the base station.

c. Wait until the line is unoccupied. d. Use the original

a. Reduce the range. b. Connect base station to mains.

Check your Subscription with network or change the dial mode.

a. Turn on the answering machine. b. Erase unnecessary messages.

b. Change to ANS&REC mode.

a. If you forget the remote access code, reset to the default settings. c.

b. Press each key firmly.

Try again using a touch tone phone.

Answer the incoming call and try again to record your outgoing message later.

When a

you listen

messages will

display on the

line cord supplied.

ANSWERING MACHINE

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select MEMO.

3. Press <MENU/OK> to start memo recording and “RECORD’G” is displayed.

4. Press <MENU/OK> to stop memo

played back. Press <MENU/OK> or

4. Press

<C> at any time during RECORD'G or PLAYING to

back to TAM menu.

and return

7.5 Answering Machine Settings You can use the SETTINGS menu in the handset to change the settings of your answering machine.

7.5.1 Set the Answer Mode By default, the answer machine is set in ANS&REC mode which allows callers to leave a message.

mode can be changed to

This

selected

callers will be prompted to call back later.

case, your

1. Press <MENU/OK> and <UP/DOWN> to select TAM

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select ANS MODE.

4. Press <MENU/OK> and <UP/DOWN> to select ANS&REC or ANSONLY

op tio n i s indicated with a * )

let it finish playing to save the memo.

recording. The display shows PLAYING and the memo is

stop memo recording without saving

ANSONLY which does not allow callers to leave a message. In that

(The currently

5. Press <MENU/OK> to confirm.

7.5.2 Set the Outgoing Message(OGM) Language The answering machine announces the outgoing message(OGM) when it answers a call.

There is a pre-set

English or French (FRANC,) on

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select LANGUAGE.

4. Press <MENU/OK> and <UP/DOWN> to select ENGLISH or FRANC,

5. Press <MENU/OK> to confirm.

.5.3 Record Your Own Outgoing Message (OGM)

You can record your own OGM for ANS&REC mode or ANSONLY mode. When you record your own OGM, it

personalised OGM is deleted, the pre-set

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select OGM SET.

4. Press <MENU/OK> and <UP/DOWN> to select ANS&REC or ANSONLY .

5. Press <MENU/OK> and <UP/DOWN> to select RECORD.

6. Press <MENU/OK> to start recording your personalised OGM and “RECORD’G”

is displayed on the screen.

OGM foreach of

will be used when the answering machine answers the call. If your

ANS&REC mode or ANSONLY

this model.

OGM will be restored automatically.

mode, which can be in

7. Press <MENU/OK> to stop recording your personalised OGM. Your new OGM will playback automatically.

DECLARATION OF CONFORMITY

9 DECLARATION OF CONFORMITY

We the manufacturer / Importer : Binatone Telecom Plc,

Declare under our sole responsibility that the following product Type of equipment: Model Name:

Country of Origin: Brand:

complies with the essential protection requirements of R&TTE Directive

1999/5/EC on

Radio Spectrum Matters,

approximation of the laws of the Member

compatibility (EMC)

relating to

Assessment of compliance of the product with the requirements relating to the essential requirements according to Article 3 R&TTE was based on Annex III

of the Directive 1999/5/EC and the following standard:

Radio Spectrum: EN 301406: V1.5.1 : 2003; EMC: EN 301489-01: V1.8.1 : 2008;

the approximation of the laws of the Member States relating to

and the European Community Directive 2006/95/EC

Electrical Safety.

Electrical Safety: EN 60950-1: 2006.

Manufacturer / Importer (signature of authorized person)

The conformity to the requirements is validated by the

NOTE: In compliance with Directive 2002/96/EC, when you purchase a product that comes

dispose of electrical and electronic equipment by separate waste collection

and you cannot dispose of the product as normal waste.

with the symbol shown on the right, you are required to

This equipment and all its components, subsystems and consumable materials formed an integral part of this product and when you decide to dispose of them you have to take them to a local recycling centre for

appropriate waste disposal, in compliance with the current regulations. Details about the location of these centres can be obtained from

your local authority.

Notes for battery disposal

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed of with normal household waste.

Please be aware of the local rules on separate collection of batteries. The correct disposal of batteries helps protect the environment and prevent health hazards.

1 Apsley Way London, NW2 7HF

Digital cordless telephone

BB3725 Series

China Binatone

the Council Directive 2004/108/EC on the

Statesrelating to electromagnetic

EN 301489- 6: V1.3.1 : 2008;

30 Nov 2009

Date

Signature

symbol.

7.5.4 Playback and Delete the Outgoing Message

ANSWERING MACHINE

You can listen to your own personali ANS&REC mode or ANSONLY mode

that the pre-set OGM cannot

note

or delete your personalised OGM

sed OGM or the pre-set OGM for

be deleted.

or record a new one at any time. Please

7.5.4.1 Playback the OGM

1. Press <MENU/OK> and <UP/DOWN> to select

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select OGM SET.

4. Press <MENU/OK> and <UP/DOWN> to select ANS&REC or ANSONLY .

5. Press <MENU/OK> and <UP/DOWN> to select PLAYBACK .

6. Press <MENU/OK> to play your current OGM and

7. Press <MENU/OK> to stop the OGM playback or let it finish playing and return to the previous menu.

Note: If a personalised OGM has not been recorded, the pre-set OGM will be played.

TAM.

“PLAYING” is displayed on the screen.

7.5.4.2 Delete the Personalised OGM

1. Repeat Steps 1 to 6 in Section

2. Press <C> while the OGM is playing to delete your personalised OGM and return to previous menu with the Note: If a pre-set OGM is playing, you are not allowed to delete

stop the playback

.5.5 Set the Answer Delay

You can set the number of rings before the answering machine answers and starts playing your OGM. You can

saver (TS). If time saver (TS) is set, the if there are no so if you call in for remote up and save on call charges. Note: If your network voice messaging service (e.g. BT 1571) is enabled, you will need to set the ring delay

set the answering machine to answer after two to eight rings or

new messages already recorded, or after 2 rings

on your BB3725 to less than 6 rings, otherwise the network service will

answer and record incoming calls,

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS

3. Press <MENU/OK> and <UP/DOWN> to select ANS DLAY

4. Press <MENU/OK> and <UP/DOWN> to select

RINGS or TS. (The currently selected option is indicated with a

7.5.4.1

pre-set OGM restored

eturn to the previous menu.and r

access and it doesn't answer after 2 or 3 rings,

automatically.

answering

it, so pressing <C> will just

machine will answer after 6 rings

if there is a new message,

and prevent the BB3725 from recording them.

from 2 RINGS, 4 RINGS, 6 RINGS, 8

"*".)

you

time

can hang

5. Press <MENU/OK> to confirm.

7.5.6 Set the Maximum Recording Time for Incoming Messages. You can set the maximum length of the recording time of the incoming

60 seconds,

1. Press <MENU/OK> and <UP/DOWN> to select TAM.

2. Press <MENU/OK> and <UP/DOWN> to select SETTINGS.

3. Press <MENU/OK> and <UP/DOWN> to select REC TIME

4. Press <MENU/OK> and <UP/DOWN> to select

currently selected option is indicated with a "*".)

5. Press <MENU/OK> to confirm.

120 seconds, 180 seconds or unlimited (up to the total

from 60S, 120S, 180S, or UNLIMIT. (The

messages to be either

recording time available).

GUARANTEE AND SERVICE

1 GUARANTEE AND SERVICE

The

BB3725 system is guaranteed for 12 months from the date of

purchase shown on your sales receipt. This guarantee

does not cover any

faults or defects caused by accidents,misuse, fair wear and tear, neglect, faults on

the telephone line, lightning, tampering with the equipment, or any

attempt at

adjustment or repair other than through approved agents.

Please keep your sales (till) receipt this is your guarantee.

You should also keep the original packaging material. In the unlikely event that you need to return your

BB3725 system

to our Repair Centre while it is under guarantee, there may be handling charge.

While the unit is under Guarantee

1. Disconnect the base unit from the telephone line and the mains electricity supply.

2. Pack up all parts of your BB37255 system , using the original

packaging.

3. Return the unit to the shop where you bought it, making sure you take your sales receipt.

Remember to include the mains adapter.

After the Guarantee has expired

If the unit is no longer under Guarantee, first follow steps 1 and 2 as for repair under Guarantee. Then...

3. Call Helpline on 0845 345 9677 (for UK only) and ask for a quotation of the repair charge and details of where to send your

BB3725

system

for repair.

4. Make sure you include with your

Your name and address

BB3725 system.

¾ A cheque or postal order for the value of the repair

¾ A brief description of the fault

5. Return your BB3725 system Department.

to the address given by the Service

* This does not affect your statutory rights.

Binatone TRIPLE 3725, TRIPLE TWIN User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
