Beurer FWM 50 User Manual

FWM 50

READ THIS MANUAL COMPLETELY AND CAREFULLY BEFORE

USING THIS PRODUCT

Keep this manual in a safe location for future reference

LEA TODO ESTE MANUAL CON ATENCIÓN

ANTES DE USAR ESTE PRODUCTO

Conserve este manual en un lugar seguro para consultarlo en el futuro

LISEZ CE MODE D’EMPLOI COMPLÈTEMENT ET

ATTENTIVEMENT AVANT D’UTILISER CE PRODUIT

Conservez ce manuel en lieu sûr pour y faire référence ultérieurement

ENGLISH

Shiatsu Foot Warmer

Instructions for use .................................................2

ESPANOL

C

alientapiés con masaje Shiatsu

Manual de instrucciones ........................................8

FRANÇAIS

Chaue-pieds Shiatsu

Mode d’emploi ......................................................14

Distributed by/Distribuido por/Distribué par:
Beurer North America LP
900 N Federal Highway, Suite 300
Hallandale Beach, FL 33009
www.beurer.com

Questions or comments?
Call toll free 1-800-536-0366 or contact [e-mail]

¿Preguntas o comentarios? Llame gratis al
1-800-536-0366 o póngase en contacto [e-mail]

Questions ou commentaires? Appeler gratuitement
1-800-536-0366 ou communiquez avec [e-mail]

ENGLISH

Content

1. IMPORTANT SAFEGUARDS ...........................2

2. Important information .................................... 4

3. Introduction .....................................................4

4. Package Contents .......................................... 5

5. Parts an Controls ............................................ 5

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

If the instruction manual is damaged or if you no longer have the instruction manual
in your possession, please contact Beurer customer service. Please see warranty for
service contact.

Dear Customer,

Thank you for choosing this Beurer product. Our name stands for high-quality, thoroughly tested products
for applications in the areas of heat, weight, blood pressure, body temperature, pulse, gentle therapy,
massage and air.
Please read these instructions completely and carefully before using this product and keep them for later
reference. Be sure to make them accessible to other users and observe the information they contain.

With best regards,
Your Beurer Team

1. IMPORTANT SAFEGUARDS

Signs and symbols

The following signs appear in the Safety Section (page 2) and in this manual on pages 4 and 5.

READ AND UNDERSTAND THIS ENTIRE MANUAL INCLUDING THE SAFETY SECTION AND
ALL INSTRUCTIONS AND WARNINGS COMPLETELY AND CAREFULLY BEFORE USING THIS
PRODUCT. FOLLOW ALL SAFETY INSTRUCTIONS AND WARNINGS TO AVOID HAZARDOUS
SITUATIONS AND TO MAKE CORRECT USE OF THIS PRODUCT.

6. To Use .............................................................. 5

7. Cleaning and Maintenance ............................ 5

8. Troubleshooting Guide ................................... 6

9. FCC Compliance Statement .......................... 6

10. Warranty ........................................................6

WARNING WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

WARNING

•

Read these instructions carefully before use.

•

Non-observance of the following notes may result in personal injury or material damage (electric
shock, skin burns, fire). The following safety and hazard information is not only intended to protect
your health and the health of others, it should also protect the product. For this reason, pay atten­tion to these safety notes and include these instructions when handing over the product to others.

•

Do not use on small children or people with no heat sensitivity (e.g. diabetics, persons with illness­related skin changes or scarred skin areas in the application area, or after consuming medications
or alcohol).

•

This foot warmer must not be used by people who are not sensitive to heat or by vulnerable people
who may not be able to react to overheating.

•

This foot warmer must not be used by children under three.

•

This foot warmer is intended for adult use and should not be used by children unless the controller has
been set by a parent or responsible adult and the child is closely supervised at all times during use.

2

•

This foot warmer may not be used by persons (including children) with reduced physical, sensory or
mental skills or a lack of experience or knowledge, unless they are closely supervised and have been
instructed on how to use the foot warmer safely and are fully aware of the risks of use.

•

Cleaning and user maintenance must not be performed by children.

•

Ensure the device is undamaged before use. If any malfunction should occur during use, remove
your feet from the device, shut the device off immediately and remove the plug from the electri­cal outlet. This device contains no user serviceable parts; never attempt to repair the unit yourself.

•

The device is intended only for the purpose described in these instructions. The manufacturer will
not be responsible for damage caused by improper or careless use.

•

Do not use the device on parts of the body which are inflamed, injured, or swollen. If in doubt, seek
medical advice prior to use.

•

Excessively long use can cause the skin to be burned.

•

Never fall asleep while the device is in use.

•

The electric and magnetic fields emitted by this device can interfere with the operation of pacemak­ers even though electric and magnetic field strengths are far below permissible limits. Consult your
doctor and the manufacturer of your pacemaker before using this device.

•

The unit is not intended for commercial or industrial use. It is intended solely for household use only.

•

Never immerse the device in water.

•

Do not switch the device on when it is folded or compressed. Do not pinch the device between
objects or bend it sharply.

•

Only use in dry surroundings.

•

Do not pull on, twist or sharply bend the cables.

•

Do not stick pins, needles, or sharp objects into this device.

•

Keep this device away from children; it is not a toy.

•

Use only the included power supply.

•

This foot warmer must not be used to keep animals warm.

•

Do not use this foot warmer with shoes.

•

Please check this foot warmer frequently for signs of wear and tear or damage. If there are signs
indicating the above or if this foot warmer was used improperly, it must be returned to the manu
facturer or retailer before further use.

•

If the power cord is damaged, it must be replaced by the manufacturer; contact customer service
for repair or replacement.

•

Always observe the notes on operation (chapter 6) and cleaning and maintenance (chapter 7).

•

If you should have any questions about using our devices, please contact Customer Service.

-

3

Intended use

This product is intended for warming and massaging human feet.

2. Important information

Signs and symbols

The following symbols are used in these instructions for use, on the packaging and on the type plate
for the device and accessories:

Do not wash

Read instructions!

Do not bleach

Do not tumble dry

Do not insert needles!

Do not iron

Only use in dry rooms Do not clean

Must not be used by very

IPX1

Drip proof

young children
(0-3 years old)

WARNING; Warning instruction indicating a risk of injury or
damage health

WARNING; Safety note indicating possible damage to the unit/
accessory

3. Introduction

Shiatsu is a form of body massage originally developed in Japan around 100 years ago. It is based on ideas
anchored in traditional Chinese medicine, in particular the meridian system, i.e. the paths in the human body
along which energy is conveyed. The aim of Shiatsu massage is to promote the physical, emotional, and
mental well-being of the person being treated by dissolving energy blocks and bottlenecks in the meridians
and stimulating the self-regulating ability of the body. Shiatsu therapists achieve this by exerting pressure in
flowing movements along the meridians.

Although Shiatsu can be literally translated as “finger pressure,” practitioners also use the base of their hands,
elbows, and knees as well as their fingers. In the process, the therapist will use his or her full body weight
in order to generate the required pressure.
Massage of a specific point on the sole of the foot may influence the corresponding organ of the body.
However, we recommend studying relevant literature and asking your doctor before using point reflex zone
massage.

4

This Shiatsu foot warmer can provide a soothing, effective Shiatsu foot massage with no help required.
Besides the intense Shiatsu massage, the foot warmer also provides a warming function. Both functions
can be used either at the same time or separately.

4. Package Contents

1

x Shiatsu foot warmer with lining

1

x Power supply

1

x Instruction manual

7

6

5. Parts an Controls

1. Power Supply

2. Cable

3. Power Supply Socket

4. Massage Button

5. ‘Warm’ Button

6. Shiatsu Foot Warmer

7. Lining

4

3

5

1

2

6. To Use

1. Connect the power cord to the Power Supply Socket and to a standard 110 VAC electrical outlet.

2. To switch on the Shiatsu massage function, press the Massage Button. The massage heads will begin
to rotate. Press the Massage Button again to switch off the Shiatsu massage function.

3. To activate the warming function, press the
deactivate. When the function is active, a red LED will illuminate above the

4. The device will shut itself off after 30 minutes of use. To reactivate, press the Massage Button or

Button again. After each use, unplug the power cord from the electrical outlet.

5. After each use, unplug the power cord from the electrical outlet.

NOTES:

- If you press on the massage heads too firmly, the massage function will shut off to protect the device.
To reactivate, you must unplug the power cord and then plug it in again.

- If the foot warmer is being used over several hours, we recommend selecting the lowest heat setting on
the controller to avoid overheating the feet, which may lead to burns to the skin.

- During the first use, the device may emit a plastic smell that will soon stop.

Button. Press the Button again to

Button.

7. Cleaning and Maintenance

WARNING

Before cleaning, always remove the power supply from the socket.

Do not wash the device or immerse it in water or other liquids. To spot clean, use a damp cloth
or sponge and, if necessary, a small amount of liquid detergent. Do not place the device in a clothes
dryer. The foot warmer may not be spun, dry-cleaned, wrung out, pressed or ironed. The remov
able lining is machine washable at 86°F (30°C). Do not use the foot warmer until it is completely dry.

For long-term storage, place the device in its original packaging and store it in a dry location, uncovered. Let
the device cool completely before storing.

5

-

8. Troubleshooting Guide

Problem Cause Solution

The foot warmer does not warm
up or the massage function can
not be activated while:
– the power supply is connected
to a working socket
– the power supply cable is
connected to the Power Supply
Socket on the foot warmer
– both functions (heat +
massage) are switched on

The foot warmer is

-

faulty.

Contact Customer Service.

9. FCC Compliance Statement

Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television recep­tion, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

10. Warranty

Limited Lifetime Warranty For Original Purchaser

Your Beurer Shiatsu foot warmer, Model FWM50 is warranted to be free from defects in materials and work­manship for the life of the product under normal conditions of intended use and service.

We will, at our option, repair or replace the Beurer Shiatsu foot warmer, Model FWM50, without additional
charge, for any part or parts covered by these written warranties. No refunds will be given. Repair or repla
cement is our only responsibility and your only remedy under this written warranty. If replacement parts for
defective materials are not available, the warrantor reserves the right to make product substitutions in lieu
of repair or replacement.

For warranty service contact our customer service department at 1-800-536-0366 to provide a description
of the problem. If the problem is deemed to be within the scope of the limited lifetime warranty, you will be
asked to mail the product at your costs in its original package with proof of purchase, your name, address
and phone number. If the problem is not deemed to be within the scope of the limited lifetime warranty, we
will provide a quotation for repair, respectively, replacement and return shipping fees.

This warranty does not cover damage caused by misuse or abuse; accident; the attachment of unauthorized
accessories; alteration to the product; improper installation; misapplication; lack of reasonable care with res­pect to the product; unauthorized repairs or modifications; improper use of electrical/power supply; old worn
batteries; normal wear; loss of power; dropped product; malfunction or damage of an operating part as a result
of failure to comply with instructions for use or to provide manufacturer’s recommended maintenance; transit

6

-
