Benq SP870 User Manual
SP870 Digital Projector
User Manual
Welcome
Table of c ontents
Important safety instructions ..... 3
Introduction ................................ 6
Projector features............................6
Shipping contents ...........................7
Projector exterior view ...................8
Controls and functions...................9
Projector ..................................................9
Remote control......................................10
Positioning your projector........ 12
Choosing a location......................12
Obtaining a preferred projected
image size ......................................13
Connection ................................ 16
Connecting a computer
or monitor.....................................16
Connecting Video source devices 18
Operation................................... 22
Starting up the projector ..............22
Using the On-Screen Display
(OSD) menus................................23
Securing the projector ..................23
Using a security cable lock ....................23
Utilizing the password function ...........24
Switching input signal ..................26
Adjusting the projected image .....27
Adjusting the projection angle..............27
Auto-adjusting the image .....................27
Fine-tuning the image size and clarity .27
Correcting keystone ..............................28
Magnifying and searching
for details.......................................28
Selecting the aspect ratio ..............29
Optimizing the image...................30
Using Wall Color...................................30
Selecting a picture mode .......................30
Fine-tuning the image quality in user
modes.....................................................31
Setting the presentation timer......33
Remote paging operations ...........34
Hiding the image ..........................35
Freezing the image........................35
Utilizing FAQ function ................35
Locking control keys.....................36
Operating in a high altitude
environment .................................36
Creating your own startup
screen............................................. 37
Adjusting the sound .....................37
Personalizing the On-Screen
Display (OSD) menus ..................38
Shutting down the projector........38
On-Screen Display (OSD)
Menus............................................39
Menu structure ..................................... 39
Description of each menu ....................41
Maintenance ..............................44
Care of the projector ....................44
Lamp information ........................44
Replacing the lamp ...............................46
Indicators .............................................. 48
Troubleshooting ........................49
Specifications .............................50
Projector specifications ................50
Dimensions ................................... 50
Timing chart .................................51
Other information ..................... 53
Warranty and Copyright
information...................................53
Regulation statements ..................53
2 Table of contents
Thank you for your purchase of this quality BenQ projector! It has been designed to provide you with an
enjoyable viewing experience in various situations. For the best results, please read this manual through carefully
as it is your guide through the control menus and operation.
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information technology
equipment. However, to ensure safe use of this product, it is important that you follow the instructions
mentioned in this manual and marked on the product.
1. Please read this manual before you operate
your projector. Save it for future reference.
2. Do not look straight at the projector lens
during operation. The intense light beam may
damage your eyes.
5. Do not place this projector in any of the
following environments.
- Space that is poorly ventilated or confined.
Allow at least 50 cm clearance from walls
and free flow of air around the projector.
- Locations where temperatures may become
excessively high, such as the inside of a car
with all windows rolled up.
- Locations where excessive humidity, dust, or
cigarette smoke may contaminate optical
components, shortening the projector's life
span and darkening the image.
3. Refer servicing to qualified service
personnel.
4. Always open the lens shutter or remove the
lens cap when the projector lamp is on.
- Locations near fire alarms
- Locations with an ambient temperature
above 40°C / 104°F
- Locations where the altitudes are higher than
3000 m (10000 feet)
3000 m
(10000 feet)
0 m
(0 feet)
Important safety instructions
3
6. In areas where the mains voltage may
fluctuate or cut out, it is recommended that
you connect your projector through a power
stabilizer, surge protector or uninterruptible
power supply (UPS).
7. The lamp becomes extremely hot during
operation. Allow the projector to cool for
approximately 45 minutes prior to removing
the lamp assembly for replacement.
10. Do not attempt to disassemble this projector.
There are dangerous high voltages inside
which may cause death if you should come
into contact with live parts. The only user
serviceable part is the lamp which has its
own removable cover.
Under no circumstances should you ever
undo or remove any other covers. Refer
servicing only to suitably qualified
professional service personnel.
11. Do not step on the projector or place any
objects upon it. Besides probable physical
damage to the projector, doing so may result
in accidents and possible injury.
8. Do not operate lamps beyond the rated lamp
life. Excessive operation of lamps beyond the
rated life could cause them to break on rare
occasions.
9. Never replace the lamp assembly or any
electronic components unless the projector is
unplugged.
12. Do not block the ventilation holes.
- Do not place this projector on a blanket,
bedding or any other soft surface.
- Do not cover this projector with a cloth or any
other item.
- Do not place inflammables near the projector.
4
Important safety instructions
13. Always place the projector on a level,
horizontal surface during operation.
- Do not use if tilted at an angle of more than
10 degrees left to right, nor at angle of more
than 15 degrees front to back. Using the
projector when it is not fully horizontal may
cause a malfunction of, or damage to, the
lamp.
14. Do not stand the projector on end vertically.
Doing so may cause the projector to fall over,
causing injury or resulting in damage to the
projector.
15. This product is capable of displaying inverted
images for ceiling mount installation.
Use only BenQ's ceiling mount kit for
mounting the projector and ensure it is
securely installed.
16. When the projector is under operation, you
may sense some heated air and odor from its
ventilation grill. It is a normal phenomenon
and not a product defect.
17. Do not block the projection lens with any
objects when the projector is under operation
as this could cause the objects to become
heated and deformed or even cause a fire.
To temporarily turn off the lamp, press
BLANK on the projector or remote control.
18. Do not place liquids near or on the projector.
Liquids spilled into the projector may cause it
to fail. If the projector does become wet,
disconnect it from the power supply's wall
socket and call BenQ to have the projector
serviced.
Ceiling mounting the projector
We want you to have a pleasant experience using
your BenQ projector, so we need to bring this
safety matter to your attention to prevent possible
damage to person and property.
If you intend to mount your projector on the
ceiling, we strongly recommend that you use a
proper fitting BenQ projector ceiling mount kit
and that you ensure it is securely and safely
installed.
If you use a non-BenQ brand projector ceiling
mount kit, there is a safety risk that the projector
may fall from the ceiling due to an improper
attachment through the use of the wrong gauge or
length screws.
You can purchase a BenQ projector ceiling mount
kit from the place you purchased your BenQ
projector. BenQ recommends that you also
purchase a separate Kensington lock compatible
security cable and attach it securely to both the
Kensington lock slot on the projector and the base
of the ceiling mount bracket. This will perform
the secondary role of restraining the projector
should its attachment to the mounting bracket
become loose.
Important safety instructions
5
Introduction
Projector features
The projector integrates high-performance optical engine projection and a user-friendly design to deliver high
reliability and ease of use.
The projector offers the following features.
• Wall color correction allowing projection on surfaces of several predefined colors
• Quick auto search speeding up the signal detecting process
• Selectable password protected function
• Up to 11 sets of picture modes providing multiple choices for different projection purposes
• 3D color management allowing color adjustments to your liking
• Splash Screen lock to prevent unauthorized use
• Selectable quick cooling function makes the projector cool in a shorter time
• FAQ to troubleshoot operational problems with one quick key press
• Presentation timer for a better control of time during presentations
• High quality manual zoom lens
• One-key auto-adjustment to display the best picture quality
• Digital keystone correction to correct distorted images
• Adjustable color balance control for data/video display
• High brightness projection lamp
• Ability to display 16.7 million colors
• Multi-language On-Screen Display (OSD) menus
• Switchable normal and Economic modes to reduce the power consumption
• Built-in speakers provide mixed mono audio when an audio input is connected
• Powerful AV function to provide high quality video image
• Component HDTV compatibility (YP
• HDCP compatibility
• The apparent brightness of the projected image will vary depending on the ambient lighting conditions,
selected input signal contrast/brightness settings, and is directly proportional to projection distance.
bPr)
• The lamp brightness will decline over time and may vary within the lamp manufacturers specifications.
This is normal and expected behavior.
6
Introduction
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please
contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those illustrated.
*The warranty card and safety manual are only supplied in some specific regions. Please consult your
dealer for detailed information.
(KOREA)
(AU)
(EU)
(CHINA)
(3-2
power
adaptor)
batteries
(UK) (US)
Projector Power cord VGA cable Remote control with
Quick start guide Multi-language user
User manual Warranty card* Safety manual*
manual CD
Optional accessories
If you need to purchase the accessories listed below, please also contact your local dealer.
1. Spare lamp kit
2. Ceiling mount kit
Installing or replacing the remote control batteries
1. To open the battery cover, turn the remote control over to
view its back, push on the finger grip on the cover and slide
it up in the direction of the arrow as illustrated. The cover
will slide off.
2. Remove any existing batteries (if necessary) and install two
AAA batteries observing the battery polarities as indicated
in the base of the battery compartment. Positive (+) goes to
positive and negative (-) goes to negative.
3. Refit the cover by aligning it with the base and sliding it
back down into position. Stop when it clicks into place.
• Avoid leaving the remote control and batteries in an excessive heat or humid environment like the
kitchen, bathroom, sauna, sunroom or in a closed car.
• Replace only with the same or equivalent type recommended by the battery manufacturer.
• Dispose of the used batteries according to the manufacturer's instructions and local environment
regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are dead or if you will not be using the remote control for an extended period of time,
remove the batteries to avoid damage to the remote control from possible battery leakage.
3. Presentation Plus
4. RS232 cable
Introduction
7
Projector exterior view
Front/upper side
1
2
3
Rear/lower side
See "Connection" on page 16 for connection details.
1614 15 2322 2417 2018
9
10
11
12
13
19
21
1. Quick-release foot
2. Projection lens
4
3. Lens cap
4. External control panel
(See page 9 for details.)
5. Focus ring and Zoom ring
5
6
7
(See page 9 for details.)
6. Vent (cool air intake)
7. Front IR remote sensor
8. Quick-release button
9. AC power cord inlet
10. Main power switch
8
1
11. Speaker grill
12. Ceiling mount holes
13. Lamp cover
14. Rear IR remote sensor
15. Wired remote control port
16. RS232 control port
17. USB socket
18. DVI-D signal input socket
19. RGB (PC)/Component Video
25
(YPbPr/ YCbCr) signal input
socket
20. DC 12V output terminal
Used to trigger external devices
such as an electric screen or light
26
control, etc. Consult your dealer
for how to connect these devices.
21. RGB signal output socket
22. Component Video (YPbPr/
27
YCbCr) signal input sockets
11
23. Composite Video signal input
socket
12
24. S-Video signal input socket
25. Audio signal input socket
26. Vent (heated air exhaust)
27. Kensington anti-theft lock slot
8
Introduction
Controls and functions
Projector
1
2
3
4
5
6
7
8
1. Focus ring
Adjusts the focus of the projected picture. See
"Fine-tuning the image size and clarity" on page 27
for details.
2. Zoom ring
Adjusts the size of the projected picture. See "Fine-
tuning the image size and clarity" on page 27 for
details.
3. POWER indicator light
Lights up or flashes when the projector is under
operation. See "Indicators" on page 48 for details.
4. MENU/EXIT
Turns on the On-Screen Display (OSD) menu.
When the OSD menu is activated, exits and saves
the menu settings. See "Using the On-Screen
Display (OSD) menus" on page 23 for details.
I
I
5. Power
Toggles the projector between standby mode and
on. See "Starting up the projector" on page 22 and
"Shutting down the projector" on page 38 for
details.
6. MODE
Depending upon which input signal is selected,
selects an available picture setup mode. See
"Selecting a picture mode" on page 30 for details.
7. ASPECT
Selects the display aspect ratio. See "Selecting the
aspect ratio" on page 29 for details.
8. BLANK
Used to hide the screen picture. See "Hiding the
image" on page 35 for details.
9
10
11
12
13
14
9. TEMPerature indicator light
Lights up if the projector's temperature becomes
too high. See "Indicators" on page 48 for details.
10. LAMP indicator light
Indicates the status of the lamp. Lights up when the
lamp has developed a problem. See "Indicators" on
page 48 for details.
11. AUTO
Automatically determines the best picture timings
for the displayed picture. See "Auto-adjusting the
image" on page 27 for details.
12. Keystone/Arrow keys ( / Up, / Down)
Manually corrects distorted images resulting from
an angled projection. See "Correcting keystone" on
page 28 for details.
Left/
Starts the FAQ function. See "Utilizing FAQ
function" on page 35 for details.
Right/
Locks the keys on the projector. See "Locking
control keys" on page 36 for details.
When the On-Screen Display (OSD) menu is
activated, the arrow keys are used as directional
arrows to select the desired menu items and to
make adjustments. See "Using the On-Screen
Display (OSD) menus" on page 23 for details.
13. SOURCE
Displays the source selection bar. See "Switching
input signal" on page 26 for details.
14. ENTER
Enacts the selected On-Screen Display (OSD) menu
item. See "Using the On-Screen Display (OSD)
menus" on page 23 for details.
Introduction
9
Remote control
13
1
2
3
4
5
6
7
8
9
10
11
12
I
I
1. Power
14
15
16
17
18
19
4
20
21
22
Toggles the projector between standby mode and
on. See "Starting up the projector" on page 22 and
"Shutting down the projector" on page 38 for
details.
2. ASPECT
Selects the display aspect ratio. See "Selecting the
aspect ratio" on page 29 for details.
3. CAPTURE
Captures the projected picture and save it as your
startup screen. See "Creating your own startup
screen" on page 37 for details.
4. Keystone/Arrow keys ( / Up, / Down)
Manually corrects distorted images resulting from
an angled projection. See "Correcting keystone"
on page 28 for details.
5. MENU/EXIT
Turns on the On-Screen Display (OSD) menu.
When the OSD menu is activated, exits and saves
the menu settings. See "Using the On-Screen
Display (OSD) menus" on page 23 for details.
6. Left/
Starts the FAQ function. See "Utilizing FAQ
function" on page 35 for details.
7. BLANK
Used to hide the screen picture. See "Hiding the
image" on page 35 for details.
8. ENTER
Enacts the selected On-Screen Display (OSD)
menu item. See "Using the On-Screen Display
(OSD) menus" on page 23 for details.
9. TIMER ON/SHOW
Activates or displays an on-screen timer based on
your own timer setting. See "Setting the
presentation timer" on page 33 for details.
10. BRIGHTNESS
Displays the BRIGHTNESS adjustment bar. See
"Adjusting Brightness" on page 31 for details.
11. CONTRAST
Displays the CONTRAST adjustment bar. See
"Adjusting Contrast" on page 31 for details.
12. TIMER SETUP
Enters presentation timer setting directly. See
"Setting the presentation timer" on page 33 for
details.
13. Indicator light
Flashes or lights red when any key on the remote
control is pressed.
14. MODE
Depending upon which input signal is selected,
selects an available picture mode. See "Selecting a
picture mode" on page 30 for details.
15. FREEZE
Freezes the projected picture. See "Freezing the
image" on page 35 for details.
16. MUTE
Toggles projector audio between on and off. See
"Muting the sound" on page 37 for details.
17. AUTO
Automatically determines the best picture timings
for the displayed picture. See "Auto-adjusting the
image" on page 27 for details.
10
Introduction
18. Right/
Locks the keys on the projector. See "Locking
control keys" on page 36 for details.
When the On-Screen Display (OSD) menu is
activated, the #4, #6 and #18 keys are used as
directional arrows to select the desired menu
items and to make adjustments. See "Using the
On-Screen Display (OSD) menus" on page 23 for
details.
19. SOURCE
Displays the source selection bar. See "Switching
input signal" on page 26 for details.
20. LASER
Emits visible laser pointer light for presentation
purposes. See "Operating the LASER pointer" on
page 11 for details.
21. PAGE /
Operate your display software program (on a
connected PC) which responds to page up/down
commands (like Microsoft PowerPoint). See
"Remote paging operations" on page 34 for
details.
22. D. ZOOM (+, -)
Magnifies or reduces the projected image size. See
"Magnifying and searching for details" on page 28
for details.
Operating the LASER pointer
The LASER Pointer is a presentation aid
for professionals. It emits red colored
light when you press it and the indicator
lights up red.
The laser beam is visible. It is necessary to
press and hold LASER for continuous
output.
Do not look into the laser light
window or shine the laser light beam on
yourself or others. See the warning messages
on the back of the remote control prior to
using it.
The laser pointer is not a toy. Parents should be
mindful of the dangers of laser energy and keep this
remote control out of the reach of children.
Remote control effective range
Infra-Red (IR) remote control sensors are located on
the front and the back of the projector. The remote
control must be held at an angle within 30 degrees
perpendicular to the projector's IR remote control
sensors to function correctly. The distance between the
remote control and the sensors should not exceed 8
meters (~ 26 feet).
Make sure that there are no obstacles between the
remote control and the IR sensors on the projector that
might obstruct the infra-red beam.
• Operating the projector from the front
°
5
1
.
x
o
r
p
p
A
• Operating the projector from the rear
°
5
1
.
x
o
r
p
p
A
Making the remote control a wired control
The remote control is equipped with a jack on the top
allowing connection to the projector with a 2.5mm
mini jack cable available in the market. This helps you
easily locate the remote control when needed as it is
connected to the projector and within the distance no
greater than the cable’s length.
Introduction
11
Positioning your projector
Choosing a location
Your room layout or personal preference will dictate which installation location you select. Take into
consideration the size and position of your screen, the location of a suitable power outlet, as well as the location
and distance between the projector and the rest of your equipment.
Your projector is designed to be installed in one of four possible installation locations:
1. Front Table
Select this location with the projector placed near the
floor in front of the screen. This is the most common
way to position the projector for quick setup and
portability.
3. Rear Table
Select this location with the projector placed near the
floor behind the screen.
Note that a special rear projection screen is required.
*Set Rear Table after you turn the projector on.
2. Front Ceiling
Select this location with the projector suspended
upside-down from the ceiling in front of the screen.
Purchase the BenQ projector ceiling mount kit from
your dealer to mount your projector on the ceiling.
*Set Front Ceiling after you turn the projector on.
4. Rear Ceiling
Select this location with the projector suspended
upside-down from the ceiling behind the screen.
Note that a special rear projection screen and the BenQ
projector ceiling mount kit are required for this
installation location.
*Set Rear Ceiling after you turn the projector on.
*To set the projector position:
1. Press MENU/EXIT on the projector or remote control and then press /
until the SYSTEM SETUP: Basic menu is highlighted.
2. Press / to highlight Projector Position and press / until the
correct position is selected.
SYSTEM SETUP: Basic
Presentation Timer
Language
Projector Position
Auto Power Off
Blank Timer
Panel Key Lock
Timer Controller
Splash Screen
My Screen
Analog RGB
English
Front Table
Disable
Disable
Off
Disable
BenQ
MENU Exit
12
Positioning your projector
Obtaining a preferred projected image size
The distance from the projector lens to the screen, the zoom setting, and the video format each factors in the
projected image size.
4:3 is the native aspect ratio of this projector. To be able to project a complete 16:9 (widescreen) aspect ratio
image, the projector can resize and scale a widescreen image to the projector's native aspect width. This will result
in a proportionally smaller height equivalent to 75% of the projector's native aspect height.
4:3 aspect image in a 4:3
aspect display area
Thus, a 16:9 aspect image will not utilize 25% of the height of a 4:3 aspect image displayed by this projector. This
will be seen as darkened (unlit) bars along the top and bottom (vertical 12.5% height respectively) of the 4:3
projection display area whenever displaying a scaled 16:9 aspect image in the vertical center of the 4:3 projection
display area.
The projector should always be placed horizontally level (like flat on a table), and positioned directly
perpendicular (90° right-angle square) to the horizontal center of the screen. This prevents image distortion
caused by angled projections (or projecting onto angled surfaces).
The modern digital projector does not project directly forward (like older style reel-to-reel film projectors did).
Instead, digital projectors are designed to project at a slightly upward angle above the horizontal plane of the
projector. This is so that they can be readily placed on a table and will project forward and upwards onto a screen
positioned so that the bottom edge of the screen is above the level of the table (and everyone in the room can see
the screen).
If the projector is mounted on a ceiling, it must be mounted upside-down so that it projects at a slightly
downward angle.
You can see from the diagram on page 15, that this type of projection causes the bottom edge of the projected
image to be vertically offset from the horizontal plane of the projector. When ceiling mounted, this refers to the
top edge of the projected image.
If the projector is positioned further away from the screen, the projected image size increases, and the vertical
offset also increases proportionately.
When determining the position of the screen and projector, you will need to account for both the projected
image size and the vertical offset dimension, which are directly proportional to the projection distance.
BenQ has provided a table of 4:3-aspect-ratio screen sizes to assist you in determining the ideal location for your
projector. There are two dimensions to consider, the perpendicular horizontal distance from the center of the
screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen
(offset).
16:9 aspect image scaled to
a 4:3 aspect display area
Positioning your projector
13
How to determine the position of the projector for a given screen size
1. Select your screen size.
2. Refer to the table and find the closest match to your screen size in the left columns labelled "4:3 screen
diagonal". Using this value, look across this row to the right to find the corresponding average distance
from screen value in the column labelled "Average". This is the projection distance.
3. On that same row, look across to the right column and make note of the "Vertical offset in mm" value. This
will determine the final vertical offset placement of the projector in relation to the edge of the screen.
4. The recommended position for the projector is aligned perpendicular to the horizontal center of the screen,
at the distance from the screen determined in step 2 above, and offset by the value determined in step 3
above.
For example, if you are using a 120-inch screen, the average projection distance is 4416 mm and with a vertical
offset of 210 mm.
If you place the projector in a different position (to that recommended), you will have to tilt it down or up to
center the image on the screen. In these situations, some image distortion will occur. Use the Keystone function
to correct the distortion. See "Correcting keystone" on page 28 for details.
How to determine the recommended screen size for a given distance
This method can be used for situations where you have purchased this projector and would like to know what
screen size will fit in your room.
The maximum screen size is limited by the physical space available in your room.
1. Measure the distance between the projector and where you want to position the screen. This is the
projection distance.
2. Refer to the table and find the closest match to your measurement in the average distance from screen
column labelled "Average". Check that your measured distance is between the min and max distances listed
on either side of the average distance value.
3. Using this value, look across that row to the left to find the corresponding screen diagonal listed in that row.
That is the projected image size of the projector at that projection distance.
4. On that same row, look across to the right column and make note of the "Vertical offset in mm" value. This
will determine the final placement of the screen in relation to the horizontal plane of the projector.
For example, if your measured projection distance was 4.5 m (4500 mm), the closest match in the "Average"
column is 4416 mm. Looking across this row shows that a 120-inch screen is required. If you can only obtain
metric sized screens, the listed screen sizes on either side of the 120-inch screen are the 3.0 m (3000 mm) and 3.5
m (3500 mm) screens.
Checking the min and max projection distance values for these screen sizes, indicates that the 4.5 m measured
projection distance will also fit the 3.0 m (3000 mm) size screen. Be aware that these different screens have
different vertical offset values.
There is 3% tolerance among these numbers due to optical component variations. BenQ recommends that
if you intend to permanently install the projector, you should physically test the projection size and
distance using the actual projector in situ before you permanently install it, so as to make allowance for
this projector's optical characteristics. This will help you determine the exact mounting position so that it
best suits your installation location.
14
Positioning your projector
Projection dimensions
Refer to "Dimensions" on page 50 for the center of lens dimensions of this projector before calculating the
appropriate position.
Maximum zoom
Minimum zoom
Screen
Center of lens
Vertical offset
Projection distance
4:3 screen diagonal Distance from screen in mm Vertical offset
Feet Inches mm Min length
(with max.
zoom)
4.0 48 1219 1635 1766 1897 84
59 1500 2012 2173 2334 104
5.0 60 1524 2044 2208 2371 105
6.0 72 1829 2453 2649 2846 126
79 2000 2683 2897 3112 138
7.0 84 2134 2862 3091 3320 147
8.0 96 2438 3271 3533 3794 168
98 2500 3353 3622 3890 173
9.0 108 2743 3680 3974 4268 189
118 3000 4024 4346 4668 207
10.0 120 3048 4089 4416 4743 210
138 3500 4695 5070 5446 242
12.0 144 3658 4906 5299 5691 252
157 4000 5366 5795 6224 276
15.0 180 4572 6133 6624 7114 315
197 5000 6707 7244 7780 345
18.0 216 5486 7359 7948 8537 379
236 6000 8048 8692 9336 414
25.0 300 7620 10221 11039 11857 526
Average Max length
(with min.
zoom)
in mm
Positioning your projector
15
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
In the connections shown below, some cables may not be included with the projector (see "Shipping
contents" on page 7). They are commercially available from electronics stores.
Connecting a computer or monitor
Connecting a computer
The projector provides a VGA input socket that allows you to connect it to both IBM® compatibles and
Macintosh® computers. A Mac adapter (an optional accessory) is needed if you are connecting legacy version
Macintosh computers.
Additionally, you can also connect the projector to a computer via the USB cable so you can perform paging
operations of the application on the PC or notebook.
To connect the projector to a notebook or desktop computer:
•With a VGA cable: •With a DVI-D cable:
Your computer must be equipped with a
DVI-D input socket.
1. Take the supplied VGA cable and connect one end
to the D-Sub output socket of the computer.
Connect the other end of the VGA cable to the DSUB/COMP. IN signal input socket on the
projector.
2. If you wish to use the remote paging function, take a USB cable and connect the larger end to the USB port
of the computer, and the smaller end to the (USB) socket on the projector. See "Remote paging
operations" on page 34 for details.
3. If you wish to make use of the projector (mixed mono) speakers in your presentations, take a suitable audio
cable and connect one end of the cable to the audio output socket of the computer, and the other end to the
AUDIO socket of the projector.
Once connected, the audio can be controlled by the projector On-Screen Display (OSD) menus. See
"Audio Settings" on page 42 for details.
The final connection path should be like that shown in the following diagram:
Notebook
or desktop
computer
2
1
31
1. Take a DVI-D cable and connect one end to the
DVI-D output socket of the computer. Connect
the other end of the cable to the DVI-D signal
input socket on the projector.
Many notebooks do not turn
on their external video ports
when connected to a
projector. Usually a key
1. VGA cable
1. DVI-D cable
2. USB cable
3. Audio cable
combo like FN + F3 or CRT/
LCD key turns the external
display on/off. Locate a
function key labeled CRT/
LCD or a function key with a
monitor symbol on the
notebook. Press FN and the
labeled function key
simultaneously. Refer to
your notebook's
documentation to find your
notebook's key combination.
16
Connection
Loading...
