BenQ MOD 9001 User Manual

© 2005 Sky’s Microwave Limited Company All Rights Reserved

MOD 9001 BENQ GSM/GPRS Modem

User Manual

Sky Microwave Co. LTD.
Tel: [phone]
Fax: [phone]
Http://www.skymicrowave.com

Email:[e-mail]

PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

1

© 2005 Sky’s Microwave Limited Company All Rights Reserved

Read First

Before operating the system, please read this manual thoroughly, and retain it for future
reference.

Attention

Please not leave the GSM/GPRS Modem and its power adapter in raining or humidity
place. The GSM Modem can only be used after being connected to antenna and has a
valid SIM card inserted.

Please do not remove the shielding cover.

Warning

The Sky’s microwave Corp. will not fix the GSM/GPRS Modem that is opened by user.
In such case, its warranty will be terminated too.

Confidentiality statement

The Recipient of this document hereby agrees that all information that this
document contains is confidential and property of Sky’s Microwave Limited Company
and will not be disclosed to any individual or entity without prior written consent. The
Information, ideas and strategy disclosed in this document shall remain the property of
Sky’s Microwave Limited Company and should not be reproduced and shall be returned to
Sky’s Microwave Limited Company promptly at its request together with all copies made
thereof. Recipient acknowledges that no remedy of law may be adequate to compensate
Sky’s Microwave Limited Company for a violation of this Agreement and Recipient hereby
agrees that in addition to any legal or other rights that may be available in the event of a
breach hereunder, Sky’s Microwave Limited Company may seek equitable relief to
enforce this Agreement in any Court of competent jurisdiction.

PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

2

© 2005 Sky’s Microwave Limited Company All Rights Reserved

1. Summary

More and more applications emerged with the rapid development of wireless data
services, such as vehicle navigation, remote monitoring, wireless Internet access, wireless
POS, etc. Thus, more and more devices need to be able to do wireless communication.

With this background, Sky microwave Corp. develops its MOD 9001 BENQ GSM/GPRS
Modem. Users of this product can add wireless communication capability easily to their own
products, and then, develop many applications.

The MOD 9001 BENQ GSM/GPRS Modem mostly fits the need of data transfer, with
SMS data communication, GPRS data navigation, Circuit Switch / Data Connectivity, TCP/IP
protocol etc. Because the easy setting up in SCM (Single Chip Micyoco), it is convenient for
network data communication. The MOD 9001 BENQ GSM/GPRS Modem with small size,
which fits both embedded application and external peripheral equipment. The AT command
set and RS232 interface will offer easy data connection without any extra circuit control.

Traditionally, the above applications use digital cellular, CDPD or other wire-line modem to
do communication, and these technologies are of the disadvantages of high communication
expense, limited communication range, dial before communications, etc. When we begin to
use MOD 9001 BENQ GSM/GPRS Modem, all these problems disappeared.

Please read this manual carefully before your installation, and please keep this manual for
further reference.

2. Interfaces

u 1 Serial port, （3.3V TTL Voltage level /RS232 Voltage level optional,115200bps、8、

1、N，No hardware flow control）.

u Power supply（DC 7.5V、500mA）.
u Antenna interface.
u Status lights（Red light indicate power status, Green light indicate network status）.

u SIM card holder.

3. Features

u Supporting both Chinese/English SMS data communication.
u Supporting 900/1800/1900 MHz GSM Tri band, better signal quality
u Status lights indication
u Supporting AT Command Set
u Standard RS-232 serial port, easy to use
u Industrial standard design and quality guarantee

PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn

3

© 2005 Sky’s Microwave Limited Company All Rights Reserved

4. Specifications

u Operation temperature ：-25 - +60℃
u Storage temperature：-35 - +80℃
u Humidity ：0 - 95％ non-condense
u Receive Sensitivity：-102dBm
u Maximum Transmit Power：1W
u Dynamic range：62dB
u Frequency tolerance ：≤±0.1ppm
u Power supply：5V、7.5V、12V optional, and can be changed according to customer’s

requirement.。

u Current：standby 50mA，work 300mA。
u Weight： 250g

5. Installation

a) Open the package box and take the GSM MODEM out，check all components within

the package box according to the packing list

b) Remove the GSM modem’s back-cover with a screwdriver, open the SIM card holder,

insert in a valid SIM Card provided by GSM network operator or service provider.
Choice the serial port output voltage by properly set the jumps. Then, fix the

back-over back.
c) Fix the GSM-MODEM to a proper location and connect the antenna to its interface.
d) Fix the data line to the GSM MODEM side first, and then, connect the other side to

user’s equipment’s data port.

e) Connect the GSM-MODEM power supply interface with the power adapter’s output

jack, and then connect the adapter to its power supply source.

Make sure that all connections are correct and proper, then, turn on
power.

Overview
