Beko RCNA355E21W User manual [EN,PT,FR,ES,D]
Frost Free Refrigerator-Freezer type II
Frost Free Frigorífico Congelador-tipo II
Frost Refrigerateur-Congelateur type II
Frost Free Refrigerador-Congelador de tipo II
Frost-Free Kühl-Gefrier-Typ II
RCNA355E21W
WARNING!
In order to ensure a normal operation of your refrigerating appliance, which uses a completely environmentally
friendly refrigerant the R600a (flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, others than the ones recommended by the
manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been
recommended by the manufacturer.
AVISO!
Afim de assegurar um funcionamento normal do seu aparelho de refrigeração que utiliza um refrigerador, o R600a,
completamente amigo do ambiente (inflamável apenas sob certas condições), deve observar as seguintes normas:
Não obstrua a livre circulação do ar ao redor do aparelho.
Não utilize dispositivos mecânicos que não os recomendados pelo fabricante para acelerar o descongelamento.
Não destrua o circuito de refrigeração.
Não utilize aparelhos eléctricos que não aqueles que devem ter sido recomendados pelo fabricante dentro do
compartimento para guardar comida.
ATTENTION!
Pour assûrer un fonctionnement normal de votre appareil qui utilise un agent frigorifique complètement écologique,
R600a (infammable seulement dans certaines conditions) vous devez respecter les règles suivantes:
N’empêchez pas la libre circulation de l’air autour de l’appareil.
N’ utilisez pas des dispositifs mécaniques pour accélérer le dégivrage, autres que ceux récommendés par le
fabriquant.
Ne détruissez pas le circuit frigorifique.
N’utilisez pas des appareils électiques à l’intérieur du compartiment pourconserver les denrées, apart celles qui
sont éventuellement récommendés par le fabriquant.
ADVERTENCIA !
Para asegurarse del funcionamiento normal de vuestro refrigerador, conteniendo le refrigerante R600a que
contribuye a la protección del ámbito (inflamable sólo en ciertas condiciones), le conviene a respectar las reglas
siguientes :
No impide la circulación del aire alrededor del aparato.
No utilize utensilios mecánicos o otros dispositivos para acelerar el proceso de descongelación otros de los
recomendados por el fabricante.
No cause daño al circuito refrigerante.
No utilize aparatos eléctricos en el interior de los compartimentos de la conservación de los alimentos, si estos
no están conformes con el tipo de aparato recomendado por el fabricante.
WARNUNG!
Ihr Gerät verwendet ein umweltverträgliches Kältemittel, R600a (nur unter bestimmten Umständen brennbar). Um
einen einwandfreien Betrieb Ihres Gerätes sicherzustellen, beachten Sie bitte folgende Vorschriften:
Die Luftzirkulation um das Gerät darf nicht behindert sein.
Verwenden Sie außer der vom Hersteller empfohlenen, keine mechanischen Hilfsmittel, um den Abtauprozess zu
beschleunigen.
Der Kältemittelkreislauf darf nicht beschädigt werden.
Verwenden Sie im Lebensmittelaufbewahrungsbereich Ihres Gerätes keine elektrischen Geräte, es sei denn, sie
sind vom Hersteller empfohlen.
This appliance is not intended for use by person with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Este aparelho não deve ser utilizado por pessoas com capacidades reduzidas quer a nivel
físico, psíquico ou mental ou com falta de experiência e conhecimento, excepto quando
supervisionados ou se lhes foram dadas instruções relacionadas com a utilização do
aparelho, por alguem responsável pela sua segurança.
As crianças devem ser supervisionadas para se assegurar que não brincam com o aparelho.
Cet appareil ne sera pas utilisé par des personnes ayant capacites physiques, sensorielles
ou mentales réduites, ou sans experience concernant l'utilisation de l'appareil, si une
personne responsable de leur sécurité ne les a pas instruites pour ce but.
Les enfants doivent être surveillés pour avoir la certitude qu'ils ne jouent pas avec l'appareil.
Este aparato no ha sido diseñado para ser usado por personas con discapacidades físicas,
sensoriales o mentales; tampoco para personas sin experiencia o conocimiento del aparato, a
no ser que estén supervisadas o instruidas por alguien responsable de su seguridad.
Los niños deben de estar controlados para que no jueguen con el aparato.
Dieses Gerät ist nicht dafür bestimmt durch Personen (einschließlich Kinder) mit
eingeschränkten physischen, sensorischen oder geistigen Fähigkeiten oder mangels
Erfahrung und/oder mangels Wissen benutzt zu werden, es sei denn, sie werden durch eine
für ihre Sicherheit zuständige Person beaufsichtigt oder erhielten von ihr Anweisungen, wie
das Gerät zu benutzen ist.
Safety comes first ! /1
Transport instructions /2
Disposal /2
Device Setup /2
Electrical connections /2
Get to know your device /3
Prior to startup /3
Indicator Panel /4
Cooling /6
Freezing /6
Defrosting of the device /7
Changing the illumination lamp /8
Cleaning and care /8
Practical tips and notes /9
Examples of use /10
Placing the food /10
Setting recomandation /10
Normal operating noises /111
Practical advice concerning the reduction of the electricity
consumption /11
What, if.... /12
Reversing the doors /13
A segurança está sempre em primeiro lugar! /14
Instruções de transporte /15
Configuração do dispozitivo /15
Ligações eléctricas /15
Detalhes do equipamento /16
Antes de colocar em funcionamento /16
Ajustar a temperatura de funcionamento /16
Arrefecimento /18
Congelar /19
Descongelação do equipamento /19
Substituição da lâmpada interior /20
Limpeza e cuidados /20
Notas e dicas práticas /21
Exemplos de utilização /22
Colocação dos alimentos /22
Recomendação de definição /22
Ruídos normais de funcionamento /23
Conselho prático sobre a redução do consumo de energia /23
O que fazer se /24
Inverter as portas /25
La sécurité d'abord ! /26
Instructions de transport /27
Mise au rebut /27
Installation de l'appareil /27
Branchements électriques /27
Apprendre à connaître votre appareil /28
Avant la mise en service /28
Réglage de la température de fonctionnement /28
Réfrigération /29
Congélation /29
Dégivrage de l'appareil /30
Remplacement de la lampe /31
Nettoyage et entretien /31
Conseils pratiques et remarques /32
Exemples d'utilisation /33
Disposition des denrées /33
Réglage recommandé /33
Bruits normaux de fonctionnement /34
Conseil pratique concernant la réduction de la consommation
électrique/34
Et si … /35
Réversibilité des portes /36
EN Index
PT Índice
FR Sommaire
ES Índice
La seguridad es lo primero /38
Instrucciones de transporte /39
Eliminación /39
Instalación del electrodoméstico /39
Conexiones eléctricas /39
Detalles del electrodoméstico /40
Antes de empezar /40
Ajuste de la temperatura de funcionamiento /40
Refrigeración /42
Congelación /43
Deshielo del aparato /43
Cambio de la lámpara de iluminación /44
Conservación y limpieza /44
Notas y consejos útiles /45
Ejemplos de utilización /46
Colocación de los alimentos /46
Ajustes recomendados /46
Ruidos normales de funcionamiento /47
Consejos prácticos para la reducción del consumo
de electricidad /47
Resolución de problemas /48
Inversión de las puertas /49
Wichtige Hinweise zu Ihrer Sicherheit! /50
Transporthinweise /51
Entsorgung /51
Geräteinstallation/Aufstellung /51
Elektrischer Anschluss /51
Lernen Sie Ihr neues Gerät kennen /52
Vor der ersten Inbetriebnahme /52
Einstellen der Betriebstemperatur /52
Kühlen /54
Gefrieren /54
Abtauen des Gerätes /55
Beleuchtung auswechseln /56
Reinigung und Pflege /56
Praktische Tipps und Hinweise /57
Anwendungsbeispiele /58
Lebensmittel platzieren /58
Einstellungsempfehlungen /58
Normale Betriebsgeräusche /59
Praktische Tipps zum Energiesparen /59
Was mache ich, wenn... /60
Türanschlag umkehren /61
D Inhalt
Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If
the subject parts are not included in the product you have purchased, then it is valid for other models.
As figuras que aparecem neste manual de instruções são esquemáticas e podem não corresponder exactamente ao seu
produto. Se as partes referidas não estiverem incluídas no produto que adquiriu, é porque são válidas para outros modelos.
Les illustrations présentées dans cette notice d’utilisation sont schématiques et peuvent ne pas correspondre exactement à votre
produit. Si certains éléments illustrés ne sont pas inclus dans le produit que vous avez acheté, ils concerneront d’autres modèles.
Las ilustraciones incluidas en el presente manual de instrucciones son esquemáticas y puede que no se adecúen a su aparato
con exactitud. Si alguno de los elementos reflejados no se corresponde con el aparato que usted ha adquirido, entonces será válido
para otros modelos.
Abbildungen und Angaben in dieser Anleitung sind schematisch und können etwas von Ihrem Gerät abweichen. Falls Teile nicht
zum Lieferumfang des erworbenen Gerätes zählen, gelten sie für andere Modelle.
1
2
3
4
5 8 6
7 9 10
Congratulations on your choice of our product which will certainly provide you with many years of
good service.
Safety comes first!
Please read the operating manual carefully. It contains important information on how to use your
device. If instructions are not adhered to, you may lose your right to service at no charge during the
warranty period. Please keep this manual in a safe place and pass it on to later users if applicable.
• Do not connect your appliance to the power supply until all packing and transit protectors have
been removed.
• Leave to stand upright for at least 4 hours before switching on to allow the system to settle if
transported horizontally.
• This appliance must only be used for its intended purpose, i.e. the storing and freezing of
edible foodstuff.
• We do not recommend use of this appliance in an unheated, cold room e.g. garage,
conservatory, annex, shed, outdoors, etc. See ‘Location’.
• On delivery, check to make sure that the product is not damaged and that all the parts and
accessories are in perfect condition.
• Do not operate a damaged appliance; if in doubt, check with your dealer.
• Do not allow children to play with the appliance.
• Do not sit or stand on or let the children sit or stand on the appliance or on the pull-out parts.
• Do not hang on the appliance door.
• Your device contains no fluoridated coolants (CFC/HFC), but contains the coolant isobutane
(R600a), a natural gas which is highly compatible with the environment.
(R600a) is easily flammable. Therefore, be sure that the cooling circuit is not damaged either
during transport or during operations.
In the event of damage;
• Avoid any open flame, sources of sparks and flammable substances.
• Immediately air the room in which the appliance is located.
• In case the coolant spraying out contacts your eyes it may cause eye injuries.
• The space in the room where the appliance is installed must not be smaller than 10 cubic metres.
• Do not dispose of the appliance in a fire. Your appliance contains non CFC substances in the
insulation which are flammable.
• Please contact the local authority in your region for information on disposal methods and
facilities available.
Warning - Keep ventilation openings on the appliance enclosure or in the built-in structure,
clear of obstruction.
Warning - Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Warning - Do not damage the refrigerant circuit.
Warning - Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
• Avoid touching the metal condenser wiring on the backside of the appliance; there is risk of injury.
• In the event of a possible malfunction, disconnect the appliance from the power supply first.
• Prior to cleaning the device always unplug the power supply or shut off the fuse.
Do not pull from the cable - pull from the plug.
• Repairs to the electrical equipment may only be made by qualified experts. If the connection
cable is damaged, the manufacturer or customer service must replace it in order to avoid
danger.
Original Spare parts will be provided for 10 years, following the product purchasing date.
1
EN Instruction for use
2
Transport instructions
The appliance should be transported only in
upright position.
Before the performance of the working test in the
shop, the packing of the appliance must be intact.
After a transport in the horizontal position, the
device may only be taken into operation 4 hours
after being stood up vertically again.
The appliance must be protected against rain,
moisture and other atmospheric influences.
The manufacturer assumes no liability if safety
instructions are disregarded.
Disposal
Make the device unusable immediately.
Pull out the mains plug and cut the power cable.
Remove or destroy snap or latch locks
before disposing of the device. In this
manner you prevent children from locking
themselves in and endangering their lives.
Device setup
• Do not operate your appliance in a room where
the temperature is likely to fall below
10°C at night and/or especially in winter. At lower
temperatures the appliance may not operate,
resulting in a reduction in the storage life of the
food.
• The climate class rate of your appliance is given
in Technical Features leaflet and written on the
rating label inside the appliance. It specifies the
appropriate operating ambient temperatures as
explained below.
Climatic class Ambient temperatures
SN........................... +10 °C to 32 °C
N ............................ +16 °C to 32 °C
ST .......................... +16 °C to 38 °C
T.............................. +16 °C to 43 °C
SN-ST..................... +10 °C to 38 °C
SN-T ...................... +10 °C to 43 °C
Location
Only place the appliance, as shown in the
illustration in dry rooms which can be aired.
Avoid direct sunlight or direct heat sources such
as a stove or a heater.
If this cannot be avoided, the following minimum
distances should be maintained:
Electric stoves: 3,00 cm
Heater: 3,00 cm
Cooling devices: 2,50 cm
• Ensure sufficient air circulation for your device.
• Make sure that sufficient room is provided
around the appliance to ensure free air circulation
(Item 3).
Fit the two plastic wall spacers supplied with
the appliance rotating 1/4 turn to the condenser at
the back of the appliance (Item 4).
• The appliance should be located on a smooth
surface. The two front feet can be adjusted as
required (Item 5). To ensure that your appliance is
standing upright adjust the two front feet by turning
clockwise or counter-clockwise, until the product is in
firm contact with the floor.
Correct adjustment of feet avoids excessive
vibration and noise.
Electrical connections
Warning
This appliance must be grounded.
• Check whether the power type and voltage in
your region corresponds to the one stated on the
rating label inside the appliance.
• The electrical safety of the appliance is only
assured when the grounding system in the house is
installed in accordance with regulations.
• When placing the appliance, do not let the power
cable get stuck under it; otherwise the cable will
be damaged.
• Ensure that the plug remains readily accessible.
Do not use a multiple adapter bar or an extension
cable.
EN Instruction for use
3
Get to know your device
Waring
Below information about accessories are supplied
just for reference. Below accessories may not be
exactly same as the accessories of your
appliance.
Item 1
1. Control panel
2. Interior light
3. Fresh Food fan
4. Wine rack
5. Adjustable Cabinet shelves
6. Crisper cover
7. Salad crispers
8. Fresh zone compartment
9. Ice tray support & ice tray
10. Compartment for quickly freezing
11. Compartments for frozen froods keeping
12. Adjustable front feet
13. Dairy Compartment*
14. Shelf for jars
15. Shelf for bottles
16. Freezer fan
* Optional
The fans has the purpose to provide the
circulation of the air in compartment.
Prior to startup
Before you begin operating your device,
the following points should be re-checked for
safety:
• Is the device standing properly on the floor?
• Is there sufficient space for good air
circulation?
• Is the interior clean? (Also see the section
“Cleaning and care”)
• Now connect the appliance to the mains.
The compressor is turned on; the interior light
comes on when the Fridge door is opened.
Do not place foodstuff into the refrigerator until the
temperature has reached the desired level.
Setting the operating temperature
Fresh Food and Freezer Compartment Temperature
can be adjused by the electronic display (Item 2)
“ION” symbol is continuously lightning on display
and indicates that your appliance is provided with
ionizer.
The ionizer is an electronic device who cleans air
from bacteria in fresh food compartment. It operates
during certain intervals of time, start/stop of device
being controlled by a special algorithm.
Ionizer is switched off when fresh food compartment
door is opened.
Dual cooling system:
Your refrigerator is equipped with two separate
cooling systems to cool the fresh food compartment
and freezer compartment. Thus, air in the fresh food
compartment and freezer compartment do not get
mixed.
Thanks to these two separate cooling systems,
cooling speed is much higher than other type
refrigerators.
Odors in the compartments do not get mixed. Also
additional power saving is provided since the
defrosting is performed individually.
EN Instruction for use
4
Indicator Panel
Fig. 2
Indicator panel allows you to set the temperature
and control the other functions related to the
product without opening the door of the product.
Just press the inscriptions on relevant buttons for
function settings.
1. Power failure/High temperature / error
warning indicator
This indicator (!) illuminates during power failure,
high temperature failures and error warnings.
During sustained power failures, the highest
temperature that the freezer compartment reaches
will flash on the digital display. After checking the
food located in the freezer compartment ( )
press the alarm off button to clear the warning.
Please refer to "remedies advised for
troubleshooting" section on your manual if you
observe that this indicator is illuminated.
2. Energy saving function (display off):
If the product doors are kept closed for a long time
energy saving function is automatically activated
after 1 minute and energy saving symbol is
illuminated. ( )
When energy saving function is activated, all
symbols on the display other than energy saving
symbol will turn off. When the Energy Saving
function is activated, if any button is pressed or
the door is opened, energy saving function will be
canceled and the symbols on display will return to
normal.
Energy saving function is activated during delivery
from factory and cannot be canceled.
3.Quick fridge function
Press this button to activate or deactivate the
quick cool function ( )
Use quick cooling function when you want to
quickly cool the food placed in the fridge
compartment. If you want to cool large amounts of
fresh food, activate this function before putting the
food into the product.
If you do not cancel it, quick cooling will cancel
itself automatically after 1 hour or when the fridge
compartment reaches to the required temperature.
This function is not recalled when power
restores after a power failure.
4. Fridge compartment temperature
setting button
Press this button to set the temperature of the
fridge compartment to 8, 7,6, 5,4,3, 2,1, 8...
respectively. Press this button to set the fridge
compartment temperature to the desired value.
( )
5.Vacation Function
In order to activate vacation function, press the
this button ( ) for 3 seconds, and the vacation
mode indicator ( ) will be activated.
When the vacation function is activated,
“- -” is displayed on the fridge compartment
temperature indicator and no active cooling is
performed on the fridge compartment. It is not
suitable to keep the food in the fridge
compartment when this function is activated.
Other compartments shall be continued to be
cooled as per their set temperature.
To cancel this function press Vacation function
button again.
6. Alarm off warning:
In case of power failure/high temperature alarm,
after checking the food located in the freezer
compartment press the alarm off button ( ) to
clear the warning.
7. Key lock
Press key lock button ( 3’’) simultaneously for 3
seconds. Key lock symbol ( ) will light up and key
lock mode will be activated. Buttons will not
function if the Key lock mode is active. Press key
lock button simultaneously for 3 seconds again.
Key lock symbol will turn off and the key lock
mode will be exited.
Press the key lock button if you want to prevent
changing of the temperature setting of the
refrigerator ( 3’’).
8. Eco fuzzy
Press and hold eco fuzzy button one times to
activate eco fuzzy function. Refrigerator will start
operating in the most economic mode at least 6
hours later and the economic usage indicator will
turn on when the function is active ( ). Press
and hold eco fuzzy function button for 3 seconds
to deactivate eco fuzzy function.
This indicator is illuminated after 6 hours when
eco fuzzy is activated.
EN Instruction for use
5
9. Freezer compartment temperature setting
button
Press this button to set the temperature of the
freezer compartment to -18,-19,-20,-21, -22, -23,24, -18... respectively. Press this button to set the
freezer compartment temperature to the desired
value.( )
10. Icematic off indicator (only on products
with icematic machine)
Indicates whether the icematic is on or off. (0/03’’)
If On, then the icematic is not operating. To
operate the icematic again press and hold the OnOff button for 3 seconds.
Water flow from water tank will stop when this
function is selected. However, ice made previously
can be taken from the icematic.
11. Quick freeze function button/ icematic onoff button
Press this button to activate or deactivate the
quick freezing function. When you activate the
function, the freezer compartment will be cooled to
a temperature lower than the set value. ( )
To turn on and off the icematic press and hold it
for 3 seconds (only on products with icematic
machine).
Use the quick freeze function when you want to
quickly freeze the food placed in fridge
compartment. If you want to freeze large amounts
of fresh food, activate this function before putting
the food into the product.
If you do not cancel it, Quick Freeze will cancel
itself automatically after 25 hours or when the
fridge compartment reaches to the required
temperature.
This function is not recalled when power
restores after a power failure.
12. Economic usage indicator
Indicates that the product is running in energyefficient mode. (eco)This indicator will be active if
the Freezer Compartment temperature is set to 18 or the energy efficient cooling is being
performed due to Eco-Extra function.
Economic usage indicator is turned off when
quick cooling or quick freeze functions are
selected.
EN Instruction for use
In order to maintain the quality of the food, the
freezing must be effected as rapidly as possible.
Thus, the freezing capacity will not be
exceeded, and the temperature inside the freezer
will not rise.
Attention
Keep the already deep-frozen food always
separated with freshly placed food.
When deep-freezing hot food, the cooling
compressor will work until the food is completely
frozen. This can temporarily cause excessive
cooling of the refrigeration compartment.
If you find the freezer or fresh food door difficult to
open just after you have closed it, don’t worry.
This is due to the pressure difference which will
equalize and allow the door to open normally after
a few minutes.
You will hear a vacuum sound just after closing
the door. This is quite normal.
Cooling
Food storage
The fridge compartment is for the short-term
storage of fresh food and drinks.
Store milk products in the intended compartment
in the refrigerator.
Bottles can be stored in the bottle holder or in the
bottle shelf of the door.
Raw meat is best kept in a polyethylene bag at the
second shelf from the top of the refrigerator.
Allow hot foods and beverages to cool to room
temperature prior to placing them in the
refrigerator.
It is suggested not to keep frozen food over
crisper cover for thawing purposes.
The other shelves can be used for thawing
purposes.
Attention
Store concentrated alcohol only standing upright
and tightly closed.
Attention
Do not store explosive substances or containers
with flammable propellant gases (canned cream,
spray cans etc.) in the appliance. There is a
danger of explosion.
Freezing
Freezing food
The freezing area is marked with
symbol.
You can use the appliance for freezing fresh food
as well as for storing pre-frozen food Please refer
to the recommendations given on the packaging of
your food.
Attention
Do not freeze fizzy drinks, as the bottle may burst
when the liquid in it is frozen.
Be careful with frozen products such as coloured
ice-cubes.
Do not exceed the freezing capacity of your
appliance in 24 hours. See Technical Features
leaflet.
EN Instruction for use
6
7
Chill compartment
You can increase the inner volume of your
refrigerator by removing the desired snack
compartment. Pull the compartment towards
yourself until it is stopped by the stopper. Raise
the front part for approximately 1 cm and pull the
compartment towards yourself again to remove it
completely.
You can place the food that you want to freeze in
order to prepare them for
freezing in these compartments. You can also use
these compartments
if you want to store your food at a temperature a
few degrees below the fridge compartment.
Making ice cubes
Fill the ice-cube tray 3/4 full with water and place it
in the freezer.
As soon as the water has turned into ice, you can
take out the ice cubes.
Never use sharp objects such as knives or forks to
remove the ice cubes. There is a risk of injury!
Let the ice cubes slightly thaw instead, or put the
bottom of the tray in water for a short moment.
Defrosting of the device
The appliance is a frost free refrigerator.
So there will not be any frost accumulation
inside the food storage area.
However there will be an automatic defrost at the
evaporation area of the appliance when it needs.
The water drams into reservoir at the back of the
appliance and evaporates automatically through
the compressor heat .
Ensure that the reservoir is fixed properly above
the compressor.
Warnings!
The fans inside the freezer and fresh food
compartments circulates cold air. Never insert any
object through the guard. Do not allow children to
play with the fresh food andfreezer fan.
Never store products that contain inflammable
propellant gas (eg dispensers, spray cans etc.) or
explosive substances.
Don’t cover the shelves with any protective
materials, which may obstruct air circulation.
Do not allow children to play with the appliance or
tamper with the controls.
Do not obstruct the fan guards to ensure that you
obtain the best possible performance from your
appliance. (Item 9 and Item 10)
Warning!
Your appliance is fitted with 2 circulating fans
which are essential for the performance of the
refrigerator. Please ensure the fans are not
blocked (stopped) or impaired by food or
packaging. Blocking (stopping) or impairing the
fan can result in an increase of the internal freezer
temperature (Thawing).
EN Instruction for use
8
Changing the illumination lamp
To change the lamp used for illumination of
your refrigerator, please call your Authorized
Service.
The lamp(s) used in this appliance is not
suitable for household room illumination. The
intended purpose of this lamp is to assist the
user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable
way.
The lamps used in this appliance have to
withstand extreme physical conditions such as
temperatures below -20°C.
Cleaning and care
Interior and Exterior Surfaces
Attention
Always unplug the power cable or switch
off the circuit breaker before cleaning.
Clean the exterior using lukewarm water and a
mild detergent.
Never use detergents, abrasive or acidic agents.
Wipe the inside compartment dry.
Be careful to prevent water from getting into
contact with the electrical connections of the
temperature control or the interior light.
If the device is not going to be used for a
long period of time, unplug the power cable and
remove all food. Clean the appliance and keep the
door open.
To preserve the appearance of your appliance,
you can polish the exterior and the door
accessories with a silicone wax.
Clean the condenser at the back of the appliance
once a year using a brush or a vacuum cleaner.
Dust build-up leads to increased energy
consumption.
Inspect the door gasket at regular intervals.
Clean with water only, and wipe totally dry.
Cleaning of the accessories
Door shelves:
Remove all food from the door shelves.
Lift the cover of the shelf upwards and pull it off
sideward.
Remove the bottom of the door shelf by pushing it
upwards.
Collecting container (Pan):
Make sure that the pan at the back of the
appliance is always clean.
Gently release the snap of the pan from the
compressor by pushing it using a tool (like
screwdriver), so that the pan can be removed.
Lift the pan, clean it and wipe it dry.
Re-assemble in reverse order.
Crisper or Drawers:
To clean a drawer, pull it out as far as possible, tilt
it upwards and then pull it out completely
(Item 7-8).
EN Instruction for use
Practical tips and notes
Cooling
• Clean fresh food and vegetables before storing
in the crisper bin.
• Always pack or wrap food, or put it in a suitable
container, before storing it in the appliance.
• Wrap food which is not suitable for storage at
cold temperatures in polyethylene bags
(pineapple, melons, cucumbers, tomatoes etc.).
• Food with strong odour or apt to acquire odour
should be wrapped in airtight or smellproof
packaging material.
• Keep fresh food separate from cooked food, to
avoid bacteria contamination.
• Never keep fresh meat in the fridge for more
than 2 or 3 days.
• Remove any left-over canned food from the can
and store it in a suitable container.
• Refer to the shelf life indicated on the food
packaging.
• Do not obstruct the air circulation inside the
device by covering the shelves.
• Never keep any dangerous or poisonous
substances inside your device.
• Always check food that has been stored for a
long period of time for its suitability for
consumption.
• Do not store fresh and cooked food together in
the same container.
• Close the door immediately after opening, to
avoid unnecessary energy consumption.
• Do not use hard or sharp objects to remove the
ice build-up.
• Do not load hot food into your appliance.
Freezing
• Always leave food to thaw in a container that
allows the thawing water to run off.
• Do not exceed the maximum allowable freezing
capacity when freezing fresh food (see the section
"Freezing")
• Do not give children ice-cream and water ices
direct from the freezer.
The low temperature may cause freeze burns on
lips.
• Never re-freeze defrosted food; defrosted food
must be consumed within 24 hours. Only food that
has been cooked can be refrozen.
• Do not take out frozen food with wet hands.
• Store only fresh and impeccable food.
• Always use appropriate packaging material to
avoid odour penetration or degradation of the
food.
• Store commercially frozen food in accordance
with the instructions given on the packaging.
• Freeze cooked food in small quantities. This
ensures rapid freezing and maintains the quality of
the food.
• Do not freeze liquid in tightly closed bottles or
containers.
The bottles/containers may burst at low
temperatures.
• Carry pre-frozen food in suitable bags and place
it in your freezer as soon as possible.
Always defrost food in the fridge compartment.
9
EN Instruction for use
10
EN Instruction for use
Examples of Use
White wine, beer and mineral water
chill before use
Bananas
do not store in a fridge
Fish or offal
store in polyethylene bags only
Cheese
use airtight containers or polyethylene bags; for
best results, take out from the fridge an hour
before consumption.
Melons
store only for a short period of time, use airtight
packaging/wrapping
Raw meat and poultry
do not store together with delicate food such as
cooked food or milk
Placing the food
Freezer compartment shelves
Various frozen food such as meat, fish, ice cream,
vegetables and etc.
Egg holder
Egg
Fridge compartment shelves
Food in pans, covered plates and closed
containers
Fridge compartment door shelves
Small and packaged food or drinks (such as milk,
fruit juice and beer)
Crisper
Vegetables and fruits
Fresh zone compartment
Delicatessen products (cheese, butter, salami and
etc.)
Setting recomandation
Freezer Compartment
Adjustment
Fridge Compartment
Adjustment
Explanations
-18 or -20°C
4°C
This is the normal recommended setting.
-22 or -24°C
4°C
These settings are recommended when the
ambient temperature exceeds 30°C.
Quick Freeze
4°C
Use when you wish to freeze your food in a
short time. Your refrigerator will return to its
previous mode when the process is over.
-18°C or colder
2°C
If you think that your fridge compartment is not
cold enough because of the hot conditions or
frequent opening and closing of the door.
-18°C or colder
Quick Fridge
You can use it when your fridge compartment is
overloaded or if you wish to cool down your food
rapidly. It is recommended that you activate
quick fridge function 4-8 hours before placing the
food.
EN Instruction for use
11
Normal operating noises
Various functional noises are completely
normal due to the operation of the cooling
system of your appliance;
• Gurgling, hissing, boiling or bubbling noises are
caused by the refrigerant, circulating inside the
cooling system. These noises can still be heard for
a short period of time after the compressor shuts
off.
• Sudden, sharp cracking or popping noises are
caused by the expansion and contraction of the
inside walls or some components inside the
cabinets.
• Buzzing, whirring, pulsating or high-pitched
humming noises are caused by the compressor.
These noises are slightly louder at the start-up of
the compressor and reduce when the appliance
reaches the operating temperatures.
Also to avoid disturbing vibrations and
noises make sure that;
• Your refrigerator is standing level on all four feet.
• Your refrigerator is not in contact with the walls,
surrounding objects or kitchen cabinets and
furniture.
• Cans, bottles or dishes inside the refrigerator are
not touching and rattling against each other.
• All shelves and bins are mounted correctly inside
the refrigerator cabinets and doors.
Practical advice concerning the
reduction of the electricity
consumption
1. Make sure that the appliance is located in wellventilated areas, far from any source of heat
(cooker, radiator etc.). At the same time, the
location of the appliance must be done in such a
way that it prevents it to be under the direct
incidence of the sunbeams.
2. Make sure that the food purchased in
refrigerated/frozen condition is placed into the
appliance as soon as possible, especially during
summertime. It is recommended to use thermal
insulated bags to transport the food home.
3. We recommend the thawing of the packets
taken out from the freezer compartment be done
in the refrigerator compartment. For this purpose,
the packet which is going to be thawed will be
placed in a vessel so that the water resulting from
the thawing does not leak in the refrigerator
compartment. We recommend you to start the
thawing at least 24 hours before the use of the
frozen food.
4. We recommend reducing the number of door
openings to the minimum.
5. Do not keep the door of the appliance open
more than necessary and make sure that after
each opening the door is well closed. When doors
are open, warm air enters the fridge/freezer
cabinets and the appliance consumes more
energy to cool down the foodstuffs.Thus please do
not open doors frequently in order to save energy
and to keep foods at ideal storage temperature.
6. Maximum frozen food storage volume is
achieved without using the middle and upper
drawer provided in the freezer compartment.
Energy consumption of your appliance is declared
while the freezer compartment is fully loaded
without using the middle and upper drawer.
7. Do not block the freezer fan grill by
placing foods in front.There must always be left
minimum 3 cm open distance in front of the
freezer fan grill to allow necessary air flow to
freeze the compartment efficiently.
8. If you do not plan to store foodstuff in freshfood
compartment, please activate Eco Fuzzy function
for energy saving. Freezer compartment keeps
frezing normalıy.
9. Activate “Energy Saving Function”. When
energy Saving Function is active, all icons on the
display will turn off except energy saving icon. All
icons will be lightened, if freshfood door is opened
or display is touched.
10. Recommended temperature settings are +4°C
and -20°C for freshfood and freezer compartments
respectively.
What, if....
1- The appliance will not work, even
though it is switched on.
• Check if the power cable is properly connected!
• Check if the mains supply is in order, or if a
circuit breaker has been tripped!
• Check the temperature control for correct
setting!
2- There is a power failure.
Keep the doors of your device closed. Frozen food
will not be affected if the power failure lasts less
than the ‘Conservation Time From Failure” (hours)
declaration mentioned in the Technical Features
leaflet. If the power failure lasts longer, check the
food and consume it immediately.
You can also cook the defrosted food and then refreeze it.
3- The interior light does not work.
Check the power supply!
Check the installation of the light bulb! Unplug
the power cable before checking the light bulb.
(Also see the section “Replacing the interior light”)
4- There is high temperature alarm
If the actual temperature of the freezer
compartment is warm then the alarm icon on the
display (Fig. 2/1) lights on. The alarm icon lights
off when the actual temperature of the freezer
compartment cools down.
The high temperature alarm may rise up due
following situations.
a) Warm food storage
b) Warm air in the freezer compartment
c) Freezer door is left open for a long time
If the high temperature alarm remains on for more
than 24 hours then contact with the customer
service.
The high temperature alarm is not active in
24 hours after plugging the appliance into the
electricity.
5- There is error messages and alarm
Incase any failure condition due wiring connection
of the appliance occurs, and then the alarm icon
on the display (Fig. 2/1) starts blinking together
with the relevant error message.
Incase some certain characters (E0, E3, ..etc.)
appear on the display then contact with the
customer service.
The alarm icon lights off just after the removal of
the failure.
6- There is actual fridge temperature failure
The appliance performs cooling considering the
fridge set temperature. The actual fridge
temperature shown on the display will reach the
adjusted fridge set temperature, when the
packages are cold enough.
There may be some oscillations on the actual
fridge temperature shown on the display due;
a) The fridge door is Opened / Closed frequently
b) Loading warm packages inside the fridge.
c) Leaving the fridge door open for a long period
of time
7- Other possible malfunctions
Not every malfunction is a case for our customer
service. Very often, you can easily resolve the
problem without requesting service.
Before requesting service, please check if the
malfunction has been caused by an operating
error. If this is the case, and a service has been
requested, a service charge will be levied even if
the device is still under guarantee.
If the problem persists please contact your dealer
or customer service.
Please have the type and serial number of your
device when calling. The rating label is located
inside.
12
EN Instruction for use
Door Open Alarm
There is a built in buzzer in the appliance that will
inform customer if the fridge door is left open for a
minute. This alarm is a periodic alarm and it
reminds the customer that the fridge door is left
open.
There is no buzzer alarm related to freezer door.
In order to stop the door open alarm, it is enough
to press any button on the display or close the
door. Thus the alarm will stop till next time.
13
The symbol on the product or on packaging indicates that this product may not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information
about recycling of this product, please contact your local city office, you household waste disposal
service or the shop where you purchased the product.
EN Instruction for use
Reversing the doors
The door of your refrigerator is designed to
operate towards both sides at your convenience. If
you want the door to open towards the other side,
please call the nearest authorized maintenance
service for assistance.
Parabéns por ter escolhido o nosso produto que lhe irá, certamente, proporcionar muitos anos de bom
serviço.
A segurança está sempre em primeiro lugar!
Leia cuidadosamente o manual de funcionamento. Ele contém informações importantes sobre a forma como
deve utilizar o seu novo equipamento. Se as instruções não forem seguidas, pode perder o direito à assistência
gratuita durante o período de garantia. Guarde este manual num local seguro e passe-o a outros utilizadores, se
aplicável.
• Não ligue o equipamento à corrente eléctrica enquanto não tiver retirado todas as protecções de
embalagem e de transporte.
• No caso do equipamento ter sido transportado na horizontal, deixe-o na vertical durante pelo menos, 4
horas, antes de o ligar.
• Este frigorífico deve ser utilizado apenas para o fim a que se destina, isto é, para armazenar e
congelar alimentos.
• Não recomendamos a utilização deste equipamento numa sala fria e não aquecida como, por
exemplo, garagem, estufa, anexo, abrigo no exterior, etc. Consulte ‘Localização’.
• Na entrega, verifique se o produto não está danificado e se todos os componentes e acessórios estão
em perfeitas condições.
• Não funcione com um equipamento danificado. Em caso de dúvida, consulte o seu representante.
• Não permita que as crianças brinquem com o equipamento.
• Não se ponha em pé nem se sente no equipamento, não permita que as crianças o façam, nem nos
componentes extraíveis.
• Não se pendure na porta do equipamento.
• O seu equipamento não contém líquidos de refrigeração com (CFC/HFC), mas contém isobutano de
refrigeração (R600a), um gás natural que é altamente compatível com o ambiente.
O (R600a) é facilmente inflamável. Assim, certifique-se de que o circuito de arrefecimento não está
danificado devido ao transporte ou outras operações.
Na eventualidade de danos;
• Evite quaisquer chamas abertas, fontes de faíscas e substâncias inflamáveis.
• Ventile imediatamente a sala onde o equipamento está instalado.
• Caso o spray de arrefecimento entre em contacto com os seus olhos ele pode provocar lesões
nos mesmos.
• O espaço na sala onde o frigorífico está instalado não deve ser menor que 10 metros cúbicos.
• Não elimine o equipamento, queimando-o. O seu equipamento contém, no isolamento, substâncias
isentas de CFC que são inflamáveis.
• Para obter informações sobre métodos de eliminação e instalações disponíveis para o efeito, contacte
as autoridades locais da sua região.
Aviso - Mantenha as ranhuras de ventilação, no equipamento ou na estrutura onde está embutido,
limpas e desobstruídas.
Aviso - Não utilize dispositivos mecânicos ou outros para acelerar o processo de descongelação.
Siga apenas as instruções recomendadas pelo fabricante.
Aviso - Não danifique o circuito de refrigeração.
Aviso - Não utilize aparelhos eléctricos dentro dos compartimentos de armazenamento de alimentos
do equipamento, excepto os que forem recomendados pelo fabricante.
• Evite tocar nos fios do condensador de metal na parte posterior do equipamento; existem riscos de lesões.
• Na eventualidade de um possível problema de funcionamento, desligue primeiro o equipamento da
corrente eléctrica.
• Antes de limpar o frigorífico, desligue sempre a fonte de alimentação ou desligue o fusível.
Não puxe pelo cabo, mas sim pela ficha.
• As reparações no equipamento eléctrico só devem ser efectuadas por profissionais qualificados. Se o
cabo fornecido estiver danificado, deve ser substituído pelo fabricante, pelo seu agente de assistência
ou pessoas igualmente qualificadas para evitar perigo.
As peças sobressalentes originais serão fornecidas durante 10 anos a partir da data da compra.
14
PT Instruções para utilização
15
Instruções de transporte
O frigorífico deve ser transportado apenas na
posição vertical.
Antes da realização do ensaio de funcionamento
na loja, a embalagem do equipamento beverá
estar intacta.
Após o transporte na posição horizontal, o
equipamento deverá ser posto na vertical e só
deverá ser colocado a funcionar após 4 horas.
O equipamento deve estar protegido da chuva,
humidade e de outras acções atmosféricas.
O fabricante não assume qualquer
responsabilidade se as instruções de segurança
forem ignoradas.
Eliminação
Inutilize imediatamente o equipamento for a de
uso.
Retire a ficha eléctrica e corte o cabo de
alimentação. Retire ou destrua as fechaduras ou
ferrolhos antes de eliminar o equipamento. Deste
modo, evita que as crianças se fechem dentro
dele e que ponham as suas vidas em perigo.
Configuração do dispositivo
• Não coloque o seu frigorífico a funcionar numa
sala em que a temperatura atinja valores
inferiores a 10℃ durante a noite e/ou
especialmente no Inverno. Em temperaturas
inferiores, o equipamento pode não funcionar, o
que resulta numa redução do período de
armazenamento dos alimentos.
• A classe climática do frigorífico está mencionada
no panfleto Funcionalidades Técnicas, na placa
de características dentro do frigorífico. Esta placa
especifica as temperaturas ambientes de
funcionamento, como explicado abaixo.
Classe climática Temperaturas do ambiente
SN ......................... +10 °C a 32 °C
N ............................ +16 °C a 32 °C
ST .......................... +16 °C a 38 °C
T ............................ +16 °C a 43 °C
SN-ST .................... +10 °C a 38 °C
SN-T ...................... +10 °C a 43 °C
Localização
Posicione o equipamento, conforme mostrado na
ilustração, apenas em repartições secas e que
possam ser arejadas.
Evite a luz solar directa ou as fontes de calor
directas, como um fogão ou aquecedor.
Se não puder evitar esta situação, devem ser
respeitadas as distâncias mínimas seguintes:
Fogões eléctricos: 3.00 cm
Aquecedor: 3.00 cm
Dispositivos de refrigeração: 2,50 cm
• Assegure-se de que existe uma circulação de ar
suficiente para o frigorífico.
• Certifique-se de que existe espaço suficiente em
redor do frigorífico, de modo a assegurar a livre
circulação de ar (Item 3).
Instale os dois espaçadores plásticos de parede
fornecidos com o equipamento, rodando 1/4 de
volta na direcção do condensador, na parte
posterior do equipamento (Item 4).
• O congelador deve ser colocado numa superfície
plana. Os dois pés frontais podem ajustados na
medida do que for necessário (Item 5). Para garantir
que o equipamento fica na vertical, ajuste os dois
pés frontais rodando-os para a direita ou para a
esquerda, até que o produto fique em contacto firme
com o chão.
O ajuste correcto dos pés evita o excesso de
vibração e ruído.
Ligações eléctricas
Aviso
Este equipamento deve estar ligado à terra.
• Verifique se o tipo de alimentação e a tensão na
sua região corresponde à mencionada na placa
de características que se encontra no interior do
equipamento.
• A segurança eléctrica do equipamento só é
assegurada quando o sistema de ligação à terra na
habitação estiver instalado de acordo com os
regulamentos.
• Quando instalar o equipamento, não deixe o
cabo de alimentação ficar apertado debaixo dele;
de outra forma o cabo ficará danificado.
• Certifique-se que a tomada fica em posição de
rápido acesso. Não utilize uma barra de tomadas
múltiplas ou um cabo de extensão.
PT Instruções para utilização
Loading...
