Behringer Synthisizer User Manual
LC2412
Users Manual
ENGLISH
Version 1.1 May 2004
EUROLIGHT
EUROLIGHT LC2412
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock, do not remove
the top cover (or the rear section). No user
serviceable parts inside; refer servicing to qualified
personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain and moisture. The
apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
This symbol, wherever it appears, alerts you to the
presence of uninsulated dangerous voltage inside
the enclosurevoltage that may be sufficient to
constitute a risk of shock.
DETAILED SAFETY INSTRUCTIONS:
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturers instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
This symbol, wherever it appears, alerts you to
important operating and maintenance instructions
in the accompanying literature. Please read the
manual.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
15) CAUTION - These service instructions are for use by
qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than
that contained in the operation instructions unless you
are qualified to do so.
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH IDENTICAL
OR EQUIVALENT TYPE.
2
EUROLIGHT LC2412
EUROLIGHT
Professional 24-channel DMX lighting console
s
24 preset channels, assignable to 512 DMX channels
s
Up to 3 DMX channels can be controlled per preset channel
s
120 scenes storable in 10 banks
s
Integrated chaser with up to 650 steps featuring sync-to-bass beat
s
Frequency-dependent sound-to-light function
LC2412
s
Crossfade time freely selectable for super-smooth scene fades
s
Two additional, multi-functional channels for special effects (e.g. fog machine, color changer)
s
Ultra-flexible fading functions for manual and automatic operation
s
Intuitive solo & channel flash functions
s
Extremely effective preview function allows hidden memory and chaser checks even during live performances
s
Dimmer control via DMX or analog output (0/+10 V)
s
MIDI interface for cascading of two LC2412s (master/slave setup)
s
PCMCIA card slot for storing of up to 25 complete settings (PCMCIA card not supplied)
s
Illuminated display/controls and BNC lamp socket for easy operation in dark stage environments
s
Extremely rugged steel construction ensures long life even under the most demanding conditions
s
Rack-mounting kit for installation in standard 19" racks included
s
Conceived and designed by BEHRNIGER Germany. Made in China.
3
EUROLIGHT LC2412
FOREWORD
Dear Customer,
welcome to the team of
BEHRINGER users, and
thank you very much for
expressing your confidence in us by purchasing the EUROLIGHT
LC2412.
Writing this foreword
for you gives me great
pleasure, because it
represents the culmination of many months
of hard work delivered
by our engineering team
to achieve a very
ambitious goal: to present an outstanding light
mixing console that
offers plenty of features
and on which you can rely even under the most demanding
conditions. The task of designing our new LC2412 certainly meant
a great deal of responsibility, which we assumed by focusing
on you, the discerning user and musician. Meeting your expectations also meant a lot of work and night shifts. But it was fun,
too. Developing a product usually brings a lot of people together,
and what a great feeling it is when all who participated in such
a project can be proud of what theyve achieved.
It is our philosophy to share our enjoyment with you, because
you are the most important member of the BEHRINGER team.
With your highly competent suggestions for new products youve
made a significant contribution to shaping our company and making
it successful. In return, we guarantee you uncompromising quality
as well as excellent technical and audio properties at an extremely
reasonable price. All of this will enable you to give free rein to
your creativity without being hampered by budget constraints.
We are often asked how we manage to produce such highquality devices at such unbelievably low prices. The answer is
quite simple: its you, our customers! Many satisfied customers
mean large sales volumes enabling us to get better purchasing
terms for components, etc. Isnt it only fair to pass this benefit on
to you? Because we know that your success is our success
too!
I would like to thank all of you who have made the LC2412
possible. You have all made your own personal contributions,
from the developers to the many other employees at this company,
and to you, the BEHRINGER user.
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ........................... 2
EUROLIGHT .................................................................... 3
FOREWORD ................................................................... 4
1. INTRODUCTION ......................................................... 5
1.1 Before you get started ................................................. 5
1.1.1 Shipment ............................................................. 5
1.1.2 Initial operation .................................................... 5
1.1.3 Warranty............................................................. 5
1.2 The users manual ........................................................ 5
1.3 General features and functions ................................... 5
2. CONTROL ELEMENTS ............................................... 6
2.1 Control elements of the A PRESET section ........... 7
2.2 Control elements of the B MEMORY section ........ 7
2.3 Control elements of the Sound-to-light section ... 8
2.4 Section : FLASH keys and SOLO .......................... 8
2.4.1 Disabling the solo function ................................. 8
2.5 Control elements of the programming section ....... 9
2.6 Control elements of the main section ................... 9
2.7 Control elements of the chase section .............. 10
2.8 Rear panel connectors of the LC2412 ....................... 10
3. PRESETS ................................................................. 11
3.1 Basic configuration ..................................................... 11
3.1.1 Preset mode ..................................................... 11
3.2 Expanding to 24 preset channels (upper mode) ....... 11
3.3 Crossfading between presets ................................... 11
4. THE B MEMORY SECTION ....................................... 12
4.1 Programming, recalling and altering
memories (scenes) ..................................................... 12
4.1.1 Programming ..................................................... 12
4.1.2 Fading in scenes .............................................. 12
4.1.3 Previewing and modifying memories ............... 12
4.2 Crossfading between different setups ..................... 12
4.2.1 Crossfading between presets and memories. 12
4.2.2 Crossfading between memories ..................... 13
4.2.3 Crossfading between memories
of different banks ............................................. 13
4.3 Preset flash and memory flash .................................. 13
4.3.1 Preset flash ...................................................... 13
4.3.2 Memory flash .................................................... 13
4.4 Programming memories without direct control (blind) 13
4.5 Previewing memories individually
on the stage (live mode) ............................................. 14
4.6 Additional application of memories ............................. 14
My friends, its been worth the effort!
Thank you very much,
Uli Behringer
4
5. SOUND-TO-LIGHT .................................................... 14
6. CHASE CONTROL ....................................................14
6.1 Programming or erasing chases ................................ 14
6.1.1 Programming level chase ................................. 14
6.1.2 Programming memory chase ........................... 14
6.1.3 Erasing chases ................................................ 15
6.2 Running and pausing chases ..................................... 15
6.2.1 Chase control through music ........................... 15
6.2.2 Chase control by means of
SPEED fader (RUN) .......................................... 15
6.2.3 Crossfading manually using the
X-FADE fader (manual mode) .......................... 15
6.2.4 Manual fades using the STEP key ........... 15
6.2.5 Replacing memory steps .................................. 16
6.2.6 Inserting memory steps .................................... 16
6.3 Saving chases as memories (chase to memory) ...... 16
6.3.1 Replaying chases stored as memories (CTM) 16
6.3.2 Previewing and editing CTM ............................. 16
6.4 Previewing chases in live mode ................................ 17
7. ADDITIONAL FUNCTIONS OF THE LC2412 ............. 17
7.1 Locking program mode ............................................... 17
7.2 Putting the output on hold ........................................... 17
7.3 Special channels ......................................................... 17
7.4 Theater mode .............................................................. 17
7.4.1 Activating theater mode ................................... 17
7.4.2 Programming fading times in theater mode ...... 18
7.5 MIDI functions ............................................................. 18
7.5.1 Cascading two EUROLIGHT LC2412s ............. 18
7.6 Storing data on a memory card .................................. 18
7.7 Adjusting differing illumination levels ......................... 19
7.8 Erasing all settings/displaying software version ....... 19
8. DIMMER CONTROL ..................................................19
8.1 Analog control ............................................................ 19
8.1.1 Controlling analog dimmers via DMX512 .......... 19
8.2 Digital control via DMX512 .......................................... 19
8.2.1 Digital control features ..................................... 19
8.2.2 Assigning DMX channels (softpatch) .............. 20
9. INSTALLATION ......................................................... 20
9.1 Cables recommended for DMX512 ............................ 21
9.2 Terminal resistor (bus termination) ............................. 21
9.3 Pin assignment ............................................................ 21
9.3.1 DMX512 connections ....................................... 21
9.3.2 Sub D connections (analog control) ................ 21
9.3.3 MIDI connection ................................................ 21
9.3.4 Audio connections ........................................... 21
9.3.5 Footswitch ....................................................... 21
9.4 Rack mounting ............................................................ 21
10. SPECIFICATIONS ................................................... 22
11. MIDI IMPLEMENTATION ......................................... 23
12. WARRANTY ............................................................ 24
EUROLIGHT LC2412
1.1 Before you get started
1.1.1 Shipment
The LC2412 was carefully packed at the assembly plant to
assure secure transport. Should the condition of the cardboard
box suggest that damage may have taken place, please inspect
the unit immediately and look for physical indications of damage.
+ Damaged units should NEVER be sent directly to us.
Please inform the dealer from whom you acquired
the unit immediately as well as the transportation
company from which you took delivery of the unit.
Otherwise, all claims for replacement/repair may
be rendered invalid.
1.1.2 Initial operation
Please make sure the unit is provided with sufficient ventilation,
and never place the EUROLIGHT on top of an amplifier or in the
vicinity of a heater to avoid the risk of overheating.
+ Before plugging the unit into a power socket, please
make sure you have selected the correct voltage:
The fuse compartment near the power plug socket contains
three triangular markings. Two of these triangles are opposite
one another. The voltage indicated adjacent to these markings is
the voltage to which your unit has been set up, and can be
altered by rotating the fuse compartment by 180°. ATTENTION:
This does not apply to export models that were for
example manufactured only for use with 120 V!
+ If you alter the units voltage, you must change the
fuses accordingly. The correct value of the fuses
needed can be found in the chapter TECHNICAL
DATA.
+ Faulty fuses must be replaced with fuses of
appropriate rating without exception! The correct
value of the fuses needed can be found in the
chapter TECHNICAL DATA.
1. INTRODUCTION
Thank you very much for the confidence you have placed in
us by purchasing the EUROLIGHT LC2412. You now own an
outstanding, ultra-compact light mixing console, that features
the state-of-the-art digital DMX512 control. In addition, your
LC2412 is equipped with an analog output which allows to use it
virtually in every environment you can think of. The design of the
LC2412 (how it operates and how it is programmed) was
constructed with controlling dimmer packs and standard
spotlights in mind. To optimally use multi-function spotlights such
as scanners and moving heads, you should use control
consoles specifically created for this purpose.
This users manual is designed to give you an overview of all
the controls, so that you get to know all possible applications the
LC2412 offers. General safety instructions are followed by a
structured overview of the control panel. Afterwards, all functions
of your LC2412 are described in detail.
Future-minded BEHRINGER technology
To allow for the highest possible level of operational safety,
we manufacture our equipment under the highest quality
standards in the industry.
Your LC2412 has been manufactured under ISO9000 certified
management system.
+ The following users manual is intended to
familiarize you with the units control elements,
so that you can master all the functions. After having
thoroughly read the users manual, store it at a safe
place for future reference.
Power is delivered via the cable enclosed with the unit. All
requiered safety precautions have been adhered to.
+ Please make sure that the unit is grounded at all
times. For your own protection, you should never
tamper with the grounding of the cable or the unit
itself.
1.1.3 Warranty
Please take a few minutes and send us the completely filled
out warranty card within 14 days of the date of purchase. You
may also register online at www.behringer.com. The serial number
needed for the registration is located at the top of the unit. Failure
to register your product may void future warranty claims.
1.2 The users manual
The users manual is designed to give you both an overview of
the controls, as well as detailed information on how to use them.
In order to help you understand the links between the controls,
we have arranged them in groups according to their function. If
you need to know more about specific issues, please visit our
website at http://www.behringer.com.
1.3 General features and functions
LC2412 means: 24 preset channels and 12 memory channels.
But thats hardly all: You can simultaneously control 78 dimmer
channels via the DMX512 digital interface (26 console channels
x 3 DMX channels). And because several light units can be
operated on a single dimmer channel, this console gives you a
plethora of mixing possibilities.
1. INTRODUCTION
5
EUROLIGHT LC2412
Comparable to a mixing console in a recording studio, a light
mixing console is a switching central for stage lighting. Therefore,
a light mixing console has to be absolutely reliable and under no
circumstances leave you stranded. We created our LC2412 using
the most modern components in order to guarantee you the
maximum reliability possible.
But without functionality, no amount of reliability is of use to
you. Thats why we integrated a tremendeous number of functions in an extremely compact unit. You have always full control
of the light conditions, regardless whether you run the light show
at a live concert, a club or on a stage. To enable you complete
control over the current setup, the EUROLIGHT LC2412 has an
intuitive design structure and features a large number of LEDs
and a large LCD display.
A light mixing console is basically a controlling unit that
comprises a full system once it is integrated with a power source
and light elements.
Two different standards have established themselves in the
field of light control (analog controlling with 0 to +10 V and digital
controlling via the DMX512 control protocol). Your LC2412 is
compatible with both. The extent of controlling your lighting
situation can range from simply fading lights in and out, all the
way to configuring and programming entire light shows. You
can manually control the speed at which a program runs, enter
the desired speed into a preset for each step, or let it be
automatically determined by an internal beat generator. On the
other hand, you can control this beat generator by using a fader,
or let your musical program directly determine the beat for the
lighting setup.
Presets
Complex lighting situations can be set up using single faders
(each controlling up to 24 channels, whereby up to 72 single
dimmers can be controlled). You can light up individual channels
at full blast independently from their fader position using the
FLASH keys.
Memories
Presets can be stored into ten separate preset banks (with
twelve memory slots each), and can also be individually recalled.
All memories can be archived by using separate PCMCIA memory
cards.
Chases
The expression Chases refers to situations in which
individually programmed light steps (up to 99 steps) are executed
in succession (the lights chase each other). These steps can
be both individual presets as well as memories.
You can create extremely complex chases. For example,
parameters such as fade-in speed of a step, chase sequence
speed and their control via the built-in beat generator or music
can all be programmed.
Crossfade
There are several ways to alternate between various stored
or newly developed lighting situations. Conversely, you can also
alternate back and forth between individual steps of a single
chase manually or automatically.
Preview
With this function, you can preview stored memories or chases
without these being visible on the stage. This way, you can
discretely control the next step before letting it be seen on the
stage.
Sound to light
This function is more widely known as party light. It basically
means that your music drives the light show. An incomming
music signal is broken down into three frequency ranges (bass,
mids and highs), each of which is assigned to a (memory) channel.
Depending on the volume of the respective signal segments, the
lights assigned to them will shine accordingly. You can even
program a setup for song pauses.
MIDI
The LC2412 can be controlled via MIDI. Two EUROLIGHT
LC2412s can be operated as master and slave by using the MIDI
interface. Entire shows can be stored and recalled by means of
a MIDI sequencer.
DMX512
The DMX digital protocol lets you flexibly assign 78 of the 512
digital channels to individual light console channels (softpatch).
Memory card
The EUROLIGHT LC2412 offers you access to 120 storable
lighting setups (memories) that can easily be altered. A virtually
unlimited archive of lighting setups can be created by using the
interchangeable memory cards on which these setups are stored.
The sky is the limit when you put your creativity to the test with
the 99 programmable chases, each consisting of 99 single steps.
2. CONTROL ELEMENTS
The control panel of your LC2412 is divided into various areas
with different functions. The way the controls on the LC2412
were designed makes using the unit and capturing current
settings a breeze. The control elements are described on the
following pages according to the functions they play. If parts of
the unit are shown in light grey in an illustration, that means that
these controls belong to another section (described elsewhere
in the manual).
All control elements and function keys are provided with control
lights to enable you full oversight of the setup/functions currently
selected.
The sections: A PRESET section, B MEMORYsection + bank display, sound to light, FLASH keys,
programming section, MAIN section, CHASE
section.
The LC2412 also has additional functions that cannot be
assigned to a particular section (special channels):
SPECIAL 1 key. Used to activate a special channel, for
example for turning a fog machine on/off.
SPECIAL 2 key. The same function as SPECIAL 1 key. Just
like in the case of other channels, three DMX channels can
be assigned to these two channels (i.e. to SPECIAL 1/2).
Both special channels are then labeled as channels 25 and
26 on the console. SPECIAL 1 and SPECIAL 2 keys can be
programmed as switches, keys or kill keys. Additional
information on this subject can be found in chapter 7.3.
POWER switch. Used to power up the EUROLIGHT LC2412.
The POWER switch should always be in the Off position
when you connect the unit to the mains.
+ Please take note: Merely switching the unit off does
not mean that it is fully disconnected from the
mains. When not using the unit for prolonged
periods of time, please unplug the units power
cord from the power outlet.
The BNC connector is used for connecting a gooseneck
lamp (optional).
6
2. CONTROL ELEMENTS
EUROLIGHT LC2412
Fig. 2.1: Section overview
2.1 Control elements of the A PRESET section
Fig. 2.2: A PRESET section (detail)
Faders 1-12. Used to set the intensity of light elements
connected to the dimmer pack.
UPPER switch. When you press this switch, the A PRESET
section is switched to the twelve additional channels. After
that, you can set up the intensity of channels 13 - 24. See
also chapter 3.2.
Setting up presets
Channel faders are used for setting up a preset that can be
directly recalled by moving fader A . As in all other setups,
the MAIN fader (see chapter 2.6) determines the maximum
illumination level of selected light sources.
2.2 Control elements of the
B MEMORY section
The faders of the B MEMORY section are located in the block
underneath the A PRESET section.
These faders control the illumination level of an entire group
of channels in a ratio to one another that you previously
determined by setting up the A PRESET faders and saving
this setting as a memory.
Fig. 2.3: B MEMORY section
Exception: When the LC2412 is in preset mode (P shown in
the bank display), the faders control the same channels as the
faders of the A PRESET section. This way, you can simultaneously create a second preset.
- These faders are also a part of this section, but they
have a double function. When the LC2412 is in sound to
light mode (party light function), they control the illumination
level of individual memories assigned to particular frequency
ranges.
The BANK display shows the storage bank to which the
memories you recall belong. It also shows if the LC2412 is
currently in preset mode (P diplayed). The display starts
flashing when you switch into preset mode, and lights up
constantly after three seconds. The preset mode is active
only after the flashing has stopped. This prevents accidental
activation of the preset mode as well as rough fades.
2. CONTROL ELEMENTS
7
EUROLIGHT LC2412
UP/DOWN keys. Use them to select a preset bank (0 - 9)
or switch into preset mode (P). The control lights flash
when you select a new bank while memories from the
previous bank are still active (the fader(s) is(are) pulled
up). Pull the fader(s) (
memory out. When you pull the fader(s) up again, the
memory of the new preset bank is visible on the stage
(also see chapter 4.1.2).
SOUND TO LIGHT key. See chapter 2.3.
PREVIEW key. It gives you the option to preview (or modify)
stored memories one more time before implementing them
on the stage. This is particularly useful when you saved
chases as memories and wish to double-check and/or
modify their speed before integrating them into a running
show. When preview is activated, the chases are shown
on control LEDs exclusively.
Each fader is assigned to a FLASH key (section ). This key
is used to assign a specific bank position to individual presets
while programming a memory.
2.3 Control elements of the
SOUND-TO-LIGHT section
The SOUND-TO-LIGHT controls are located in the right-hand
section of the B MEMORY section.
If the sound-to-light function is active, memories 9 - 12 are
controlled by a music signal, whereby the volume of the signal
dictates the illumination level of the memories. The music signal
is divided into three frequency ranges (bass, mids, higs). One
memory slot is assigned to each of the three frequency ranges.
For optimal results, please put the faders to the middle position.
This will let you bring individual settings of memories into sync
with one another, should the levels vary from memory to memory.
, - ) down to fade the
The music signal necessary for controlling the show can be
fed into the ANALOG INPUT connector located at the rear of the
LC2412.
2.4 Section : FLASH keys and SOLO
Fig. 2.5: The FLASH keys
FLASH keys. Pressing one of the FLASH keys sets the
respective channel to the maximum illumination level set on
the MAIN fader, independent from its own fader position.
For this purpose, the CH FLASH key has to be pressed.
The channel flash function is automatically activated in
preset mode.
Dual-function FLASH keys. Memories or chases can be
stored to memory positions 9 - 12 (chase to memory).
When a respective storage bank is selected, chases are
indicated with yellow LEDs. Chases can also be recalled
by using the FLASH keys.
Solo
When the solo function is simultaneously active (SOLO key
, LED lit), all other emitters or light elements are deactivated.
Only the channel selected via the FLASH key is still active.
2.4.1 Disabling the solo function
You have the option to exclude specific channels from the
solo function, so that these channels remain active even when
Solo is activated.
Disabling solo is achieved by performing the folloing
programming sequence:
Fig. 2.4: The SOUND-TO-LIGHT section
The PAUSE fader is, just like the fader , used primarily
to control the illumination level of memories. If the sound-tolight function is active, it controls a memory slot assigned
to run during program breaks between two musical pieces.
The BASS fader takes over the basic configuration of the
illumination levels for the memory slot assigned to the bass
portion of the frequency range.
The MID fader is conversely assigned to the mids.
The TREBLE fader is conversely assigned to the highs.
and : Bank display and UP/DOWN keys, see chapter
2.2.
The SOUND-TO-LIGHT key activates the sound-to-light
funtion.
1. Press UTILITY 1 .
2. Select the option DISABLE SOLO by using the SOFT A key
located below the display. The channel for which the
solo function should be disabled or enabled is shown in the
top left section of the display. The respective disabled/
enabled status of the said channel is indicated to the right of
the channel number itself.
3. To select the channel you wish to adjust, turn the DATA
wheel . The desired channel can also be selected by
using the FLASH key (for channels 13 - 24: first press the
UPPER key).
4. SOFT B selects DISABLE and thus disables the solo
function for this channel; SOFT A selects ENABLE.
5. To exit this procedure, press the QUIT key , thus
confirming the procedure.
+ When you disable the solo function for a particular
channel, the channel remains active in case when it
is part of an activated memory that fades after
pressing one of the FLASH keys.
Example:
You have disabled the solo function for channel 8. The light on
channel 8 remains lit if you press one of the FLASH keys, as long
as the solo function is active.
Previously, you have programmed a memory that uses channel
8. The memory has just been activated on the stage. Now, press
one of the FLASH keys (CH FLASH is also activated). There
are two lights on the stage, i.e. channel 8 and the channel
activated with the key!
