Behringer NU6000DSP Brochure

Product Information Document

Class-D

Class-AB

Output Power

Eciency

100

80

60

40

20

0 20406080100

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

Delivers 2 x 1500 Watts into

#

2Ohms; 2 x 900 Watts into 4 Ohms;
3000Watts into 4 Ohms (bridge
mode) and weighs less than
7 lbs / 3.3 kg

Ultimate reliability through

#

revolutionary cool-running
High-Density Class-D technology
with “near-zero” thermal buildup

Ultra-e cient switch-mode

#

power supply for noise-free audio,
superior transient response and low
powerconsumption

“Zero-Attack” limiters o er

#

maximum output level with reliable
overload protection

Built-in stereo crossover with low-

#

cut, high-cut and full range mode

Detented and illuminated gain

#

controls for precise level setting

Precise 4-segment Signal and Limit

#

LEDs to monitor performance

XLR and ¼ " TRS combination input

#

connectors for compatibility with
any source

Professional twist-lock speaker

#

connectors for ultimate reliability

Independent DC, LF and thermal

#

overload protection on each channel
automatically protects ampli er and
speakers without shutting down
theshow

“Back-to-front” ventilation system

#

prevents thermal buildup for
reliableoperation

3-Year Warranty Program**

#

Conceived and designed by

#

BEHRINGER Germany

The iNUKE NU3000 power ampli er

packs 3,000 Watts (2 x 1500 Watts

@ 2 Ohms; 2 x 900 Watts @ 4 Ohms;

3000 Watts @ 4 Ohms in Bridge mode)

into an exceptionally lightweight

(7 lbs/3.3 kg) and rack-mountable

package. And because the NU3000

is so much more e cient than

conventional designs, it runs cooler

and don’t require the massive heat

sinks and heavy toroid transformers

typically associated with its conventional counterparts. You can run it

full-out for hours on-end thanks to our “Zero-Attack” limiters, which o er

maximum output level with exceptionally-reliable overload protection.

Our revolutionary high-density Class-D technology, combined with

ultra-e cient, switch-mode power supplies, ensures this feather-light

powerhouse will drive your rig e ortlessly for many years to come.

Class-D - Massive Power, Perfect Sound

Thanks to our revolutionary Class-D ampli er technology, we are able to provide you with
enormous power and incredible sonic performance in an easy-to-use, ultra-portable and
lightweight package. Class-D ampli cation makes all the di erence, o ering the ultimate
in energy e ciency – and eliminating the need for a heavy power supply and massive
heat sinks. This amazing technology makes it possible to design and build extremely­powerful products that are signi cantly lighter in weight than their traditional counterparts,
while using less energy and protecting the environment.

**Warran ty details can b e found at music-gro up.com.

Product Information Document

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

Sublimely Simple Operation

The front panel controls and indicators provide your system’s vital signs at a glance. After pressing
the Power button, the Power LED lights to show the amp is ready for action. All channels feature
positive-detent Gain controls with Signal LEDs that light when a signal is present, as well as Clip LEDs
to indicate when the signal is distorted and you need to reduce the input signal.

Just as elegant as the front, the rear panel is home to the combo XLR and ¼ " TRS Input connectors,
making the iNUKE NU3000 compatible with virtually any source, balanced or unbalanced.
Professional twist-lock speaker sockets are provided to ensure every drop of output power gets to
your loudspeakers. The rear panel is also where you’ll  nd the switches that enable the NU3000 amp
to run in your choice of dual mono, stereo or mono bridge mode.

Three Ways to Shape Your Sound

The NU3000 features a built-in 3-way Crossover, which is selectable as: Full-Range mode, where the
output is sent un ltered to your loudspeakers; LF mode, which sends the low-frequency content
(<100 Hz) to passive subwoofers, or HF mode, where the high-frequency content (>100 Hz) is
channeled to your full-range loudspeakers.

Sound Value

Sporting massive output ratings, lightweight Class-D technology, an equally lightweight price
tag – and all the amenities a professional audio engineer could ask for – the iNUKE NU3000 power
ampli er is a serious amp for your most demanding applications.

Experience the iNUKE NU3000 ampli er at your local dealer today, and  nd out why more and
more professionals are turning to BEHRINGER ampli ers for their superb performance and
extraordinary value.

2 of 6

Product Information Document

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

You Are Covered

We always strive to provide the best possible Customer Experience. Our products are made in our
own MUSIC Group factory using state-of-the-art automation, enhanced production work ows and
quality assurance labs with the most sophisticated test equipment available in the world. As a result,
we have one of the lowest product failure rates in the industry, and we con dently back it up with a
generous 3-Year Warranty program.

3 of 6

Product Information Document

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

4 of 6

Product Information Document

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

5 of 6

Product Information Document

PA Ampli ers

iNUKE
NU3000

Ultra-Lightweight, High-Density
3000-Watt Power Ampli er

For service, support or more information contact the BEHRINGER location nearest you:

Europe
MUSIC Group Services UK

Tel: [phone]
Email: [e-mail]

MUSIC Group accepts no liability for any loss which may be su ered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.
Technical speci cations, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. MIDAS, KLARK TEKNIK,
TURBOSOUND, BEHRINGER, BUGERA and DDA are trademarks or registered trademarks of MUSIC Group IP Ltd. © MUSIC Group IP Ltd. 2014 All rights reserved.
