Technical Specications
ULTRAGAIN PRO-8 DIGITAL ADA8000
Audiophile 8-Channel A/D & D/A Converter with Premium Mic
Preampliers and ADAT Interface
2 ULTRAGAIN PRO-8 DIGITAL ADA8000 Technical Specifications
ULTRAGAIN PRO-8 DIGITAL ADA8000
Audiophile 8-Channel A/D & D/A Converter with
Premium Mic Preampliers and ADAT Interface
Ultra-high quality 8-channel A/D and D/A converter for virtually any digital recording/mixing environment
8 state-of-the-art, studio-grade IMP “Invisible” Mic Preamps
Phantom power on all microphone inputs
Audiophile 24-bi t A/D and D/A conver ters for ultimate signal integrity
Processes 44.1 and 48 kHz sample r ates
Exter nal sample rate synchronization via wo rdclock or ADAT input
Optical ADAT in/out interface for ultimate compatibility
All mic/line inputs are r outed to the ADAT output
ADAT input can be routed to all Line outputs
High-quality components and exceptionally rugged construction ensure long life
Conceived and designed by BEHRINGER Germany
Specications
Microphone Inputs
Type Electronically balanced,
discrete input circuitry
Gain range +10 to +60 dB
Max. input level +6 dBu @ +10 dB gain for 0 dBFS
Impedance approx. 2 kΩ b alanced
Phantom power +48 V, switchable
Line Inputs
Type ¼" TRS connector, electronically balance d,
discrete input circuitry
Impedance approx. 20 kΩ b alanced,
approx. 10 kΩ unbalanced
Gain range -10 to +40 dB
Max. input level +26 dBu @ -10 dB gain for 0 dBFS
Line Outputs
Type XLR, electronically balanced
Impedance approx. 500 Ω balanced,
approx. 250 Ω unb alanced
Max. outpu t level +16 dBu @ 0 DBFS
Digital Input
Digital Output
Type TOSLINK, optical connector
Format ADAT, 8 channels, 24-bit @ 44,1/48 kHz
A/D Converter
Type 24-bit, 64-times oversampling, delta-sigma
Dynamic range Analog input to digital output,
approx. 103 dB
D/A Converter
Type 24-bit, 128-times oversampling,
delta-sigma
Dynamic range Digital input to analog output,
approx. 100 dB
Synchronization
Source Internal 44.1 kHz, internal 48 kHz,
ADAT input, wordclock input
Wordclock Input
Type BNC, 1 x sample rate
Input level 2 to 6 V peak-to-peak
Frequency range 44.1 to 48 kHz
Type TOSLINK, optical connector
Format ADAT, 8 channels,
24-bit @ 44,1/48 kHz
3 ULTRAGAIN PRO-8 DIGITAL ADA8000 Technical Specifications
System Specications
Frequency range 10 Hz to 21 kHz @ 48 kHz sample rate
THD <0,01%
Crosstalk <-86 dB
Power Supply
Mains Voltage
USA / Canada 120 V~, 60 Hz
Europe / U.K. / Aust ralia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Power consumption 25 W
Fuse 100 - 120 V ~: T 630 mA H
200 - 240 V ~: T 315 mA H
Mains connection Standard IEC receptacle
Dimensions
(H x B x T) ca. 1 ¾ x 19 x 8 ½"
ca. 44.5 x 482.6 x 217 mm
WEIGHT approx. 2.3 kg
SHIPPING WEIGHT approx. 3.3 kg
