Banner MINI-SCREEN Lens Shields User Manual

4" MSS4 44308 5.4"

8" MSS8 44309 9.4"

12" MSS12 44310 13.4"

16" MSS16 44311 17.4"

20" MSS20 44312 21.4"

24" MSS24 44313 25.3"

28" MSS28 44314 29.3"

32" MSS32 44315 33.3"

36" MSS36 44316 37.3"

40" MSS40 44317 41.3"

44" MSS44 44318 45.3"

48" MSS48 44319 49.3"

Model MSSxx is a replaceable protective cover for the lens of a MINI-SCREEN or
MINI-ARRAY sensor lens. The shield is made of 1.5 mm ( 0.6”) clear polycarbonate.

Shield models are available for every length of sensor from 4-inches to 48-inches
(see chart, below). The shields attach to the sensor using two adhesive-backed Neoprene
foam strips.

Application Note: When shields are installed on both the emitter and receiver, excess
gain is reduced by 36 percent (and maximum operating range is reduced by 20 percent)

• 1.5 mm (0.6") clear polycarbon­ate

• Neoprene foam

•
Easy to assemble; available in

lengths from 4-inches to
48-inches

MINI-SCREEN

®

Lens Shields

For MINI-SCREEN®Sensors

Printed in USA P/N 44418

MSA Series Description

Protective Shield Model Number Assembly Number Length

MS Shield Features

Remove all dust, dirt, and oil from the metal surfaces on all four sides of the MINI­SCREEN sensor lens using a mild detergent or window cleaner and a soft cloth.
Also clean the MINI-SCREEN lens and the lens shield, if needed. NOTE: Avoid
cleaning agents containing alcohol, as they will damage the acrylic lens. If in doubt
about the composition of a cleaning agent, test a small area of the acrylic sensor
lens below the active lens area (i.e. - at the bottom of the sensor, just above the
cable connector) by applying the cleaning agent and allowing it to evaporate.

The foam gasket is pre-attached to the lens shield. Peel the paper backing from the
foam gasket. Press one end of the lens shield to the bottom end of the sensor, just
above the status indicators, and continue by applying pressure and moving slowly to
the top end. The width of the lens shield is very close to the width of the sensor, so
it is easy to keep centered during mounting.

Shield Installation

Remove dirt and/or oil from the front face of the shield using a mild detergent or
window cleaner and a soft cloth. Avoid industrial cleaning agents or cleaning agents
containing alcohol, as they may damage the polycarbonate shield material.

Shield Maintenance

Peel the lens shield away from the sensor starting at the top or bottom end, and con­tinuing to the opposite end of the sensor. All or most of the gasket will remain
attached to the sensor. Peel the gasket material away from the sensor. Clean the
sensor and install the new lens shield as described in the above instructions.

Shield Replacement

Banner Engineering Corp., 9714 Tenth Ave. No., Minneapolis, MN 55441 Telephone: [phone] FAX (applications) [phone]

WARRANTY: Banner Engineering Corporation warrants it products to be free from defects for one year. Banner
Engineering Corporation will repair or replace, free of charge, any product of its manufacture found to be defective at the time
it is returned to the factory during the warranty period. This warranty does not cover damage or liability for the improper
application of Banner products. This warranty is in lieu of any other warranty either expressed or implied.
