DATASHEET
The top-of-the-line AXIS Q60-C PTZ Dome Network Cameras provide exceptional and reliable
surveillance in environments such as deserts, where high ambient temperatures and solar
radiation require cameras to operate in extreme heat. The robust AXIS Q60-C cameras are ideal
for use at construction and open-pit mining sites, along pipelines, and for city surveillance.
AXIS Q60-C PTZ Dome Network Cameras
High-speed PTZ domes with active cooling.
> Operate in
temperatures up to
75 °C (167 °F)
> Easy and reliable
installation: dustand waterproof, meet
military standard
> Powerful zoom;
resolutions up to
HDTV 1080p
> SFP slots for ber,
RJ-45 connections
> I/O for alarm in/out
With a built-in active cooling system, AXIS Q60 cameras
can operate in temperatures up to 75 °C (167 °F). The
robust cameras meet the tough military standard,
MIL-STD-810G, ensuring reliable operation in harsh
weather conditions such as sandstorms. Installing the
outdoor-ready cameras is fast and easy. No additional
housing is required.
AXIS Q60-C camera models support resolutions ranging
from D1, up to HDTV 1080p. They enable wide area
coverage with high-speed 360° pan and powerful zoom
for capturing details.
The supplied media converter switch allows AXIS Q60-C
cameras to be connected in a daisy chain to the network
using standard network or fiber optic cables that help
lower the cost of installing the cameras over long
distances. The media converter switch also enables the
cameras to connect to external alarm devices via two
configurable input/output ports, and to 12 V power.
AXIS Q60-C cameras, which support day/night
functionality and H.264 compression, ensure the delivery
of high-quality video even under extreme conditions.
Mounting brackets are sold
separ ately.
Page 2
AXIS Q60-C PTZ domes ensure reliable surveillance in demanding environments. The cameras are tested
to meet the tough MIL-STD-810G standard for high temperature, temperature shock, radiation, rain,
humidity, salt fog, sand and dust.
With precision pan/tilt performance, the high-speed AXIS Q60-C cameras can follow a walking person
or pan at a speed of 450° per second. The cameras also have powerful zoom. AXIS Q6035-C, for
example, can capture the license plate of cars up to 275 m (900 ft.) away. The cameras support full
frame rate video in resolutions up to HDTV 1080p (1920x1080), wide dynamic range, automatic guard
tour, alarm management and intelligent video capabilities such as autotracking and Active Gatekeeper.
Exceptional video surveillance in searing heat
330 mm (13")
304 mm (12")
252 mm (10")
302 mm (12")
Side view
Top view
Dimensions: AXIS Q60-C PTZ Dome Network Cameras
Engineered for handling extreme heat
AXIS Q60-C cameras use Peltier technology to increase the operating temperature to 75 °C (167 °F). The advanced
climate control also handles rapid temperature changes to eliminate condensation on the clear dome cover. The
system ensures that the cameras always operate at an optimal temperature to reduce wear and tear to maintain
the cameras’ lifetime.
Front view
Back underside view
Fan
Heat sinks
Fan
Peltier element draws heat out of
or into the camera as needed; forms part
of the barrier separating the camera unit
from the outer environment
Cooler
air in
Warmer air out
Heat inside camera is
transferred out
Air-tight camera compartment;
no air ow between camera unit and outer part
Page 3
AXIS Q6035-C AXIS Q6034-C AXIS Q6032-C
Easy installation and reliable performance
An AXIS Q60-C connects to the supplied A XIS T8605 Media Converter
Switch using a multi-connector cable, which attaches to the camera with
a simple click. Through the media converter switch, the multi-connector
cable enables the camera to receive power, and send and receive data to
and from external alarm devices and the network. Two SFP slots and two
RJ-45 connectors in the media converter switch give installers the flexibility
to network the cameras cost-effectively over long distances in a daisy
chain or in a ring topology for increased reliability in the event of a single
point of failure.* The RJ-45 connectors can also be used for connection
to complementary cameras such as a thermal camera or temporarily to a
laptop to service the system locally. With bayonet mounting, AXIS Q60-C
cameras attach easily to Axis’ standard mounting accessories.
Cable
with IP66
connector
Control
room
Multi-connector cable
(5 m/16 ft.)
supplied for
Ethernet, power, I/O
Media converter
switch
Fiber/Cat-5
Media converter
switch
Power supply
(not included)
Power supply
(not included)
Power in
Power in
Power in
Power
Bayonet
connection
AXIS T91A Mounting Accessories
Wall/Pole
Corner
Ceiling
Pendant
kit
Parapet
IP
NETWORK
Data rate RJ-45: 10/100 Mbps; SFP: 100/1000 Mbps
Network cables Shielded category 5 or higher, all fiber
Connectors 2x RJ-45 connectors
2x SFP slots (e.g. for SFP optical fiber modules)
2 configurable alarm input/output ports
1x power
Power 12.0 - 13.2 V DC, min. 75 W (power in from
power supply)
Display &
indicators
Power
5x Network
Compliance RoHS, RE ACH, WEEE, CE, EN 50022, IEC 60715,
AS2756
Approvals EMC:
EN 55022 Class A, EN 55024, VCCI,
FCC Part 15 Class A with STP cabling, KCC
Safety:
IEC/EN/UL 60950-1, IEC/EN/UL 60950-22
Operating
conditions
-40 °C to 75 °C (-40 °F to 167 °F)
Storage
conditions
-40 °C to 75 °C (-40 °F to 167 °F)
Installation Bracket Mount DIN Clip (included) for a
35 mm DIN rail
Dimensions 150 x 100 x 30 mm (5.9” x 3.9” x 1.2”)
AXIS T8605 Media Converter Switch
AXIS T8008 PS12 (Optional accessory)
Power in 90 - 264 V AC (operating)
115 - 230 V AC (nominal)
47 - 63 Hz
Power out 12.5 V DC +/-0.2 V DC, 85 W
Approvals EMI Class B, EN61000 Immunity
IEC 68-2-27, IEC 68-2-6/IE C 721-3-2,
UL+CSA 6 0950-1 2nd Edition,
UL+CSA 6 0601-1 2nd Edition,
CB Scheme 60950-1,
EN 61347-1/-2-13 , IP6 4
Operating
conditions
-40 °C to 75 °C (-40 °F to 167 °F)
Storage
conditions
-40 °C to 75 °C (-40 °F to 167 °F)
Dimensions 178 x 102 x 38 mm (7” x 4” x 1.2”)
Multi-connector cable
2 RJ-45
Power in
2 I/O ports
2 SFP slots
(ber)
Daisy-chain/bus topology
*IGMP ltering not supported
Page 4
www.axis.com
©2012 Axis Communicat ions AB. A XIS COMMUNICATIO NS, AXI S, ETR AX, AR TPEC and VAPIX are registered tr ademark s or trademark applications of Axis A B
in variou s jurisdict ions. All other company names and products are tr ademark s or registered trademarks of their respec tive companies. We reserve the right
to introduce modications without notice.
48 072/ EN/R7/ 1212
Technical specications – AXIS Q60-C PTZ Dome Network Cameras
Cameras
Models AXIS Q6032-C 60 Hz, AXIS Q6032-C 50 Hz
AXIS Q6034-C 60 Hz, AXIS Q6034-C 50 Hz
AXIS Q6035-C 60 Hz, AXIS Q6035-C 50 Hz
Image sensor AXIS Q6032-C: 1/4” ExView HAD progressive scan CCD
AXIS Q6034-C: 1/3” progressive scan CCD
AXIS Q6035-C: 1/2.8” progressive scan CMOS
Lens AX IS Q6032-C:
f=3.3 – 119 mm, F1.4 – 4.2, autofocus, automatic day/night
Horizontal angle of view: 57.2° - 1.7°
AXIS Q6034-C:
f=4.7 - 84.6 mm, F1.6 - 2.8, autofocus, automatic day/night,
horizontal angle of view: 55.2° - 3.2°
AXIS Q6035-C:
f=4.7 - 94 mm, F1.6 - 3.5 autofocus, automatic day/night
horizontal angle of view: 54.1° - 2.9° in HDTV 1080p
horizontal angle of view: 37.6° - 2° in HDTV 720p
Minimum
illumination
AXIS Q6032-C:
Color: 0.5 lux at 30 IRE F1.4; B/W: 0.008 lux at 30 IRE F1.4
AXIS Q6034-C:
Color: 0.74 lux at 30 IRE F1.6; B/W: 0.04 lux at 30 IRE F1.6
AXIS Q6035-C:
Color: 0.8 lux at 30 IRE F1.6; B/W: 0.04 lux at 30 IRE F1.6
Shutter time AXIS Q6032-C:
1/30000 s to 0.5 s (60 Hz), 1/30000 s to 1.5 s (50 Hz)
AXIS Q6034-C: 1/10000 s to 1/4 s
AXIS Q6035-C: 1/30000 s to 1/4 s
Pan/tilt/zoom E-flip, 100 preset positions
Pan: 360° endless, 0.05° – 450°/s
Tilt: 220°, 0.05° – 450°/s
AXIS Q6032-C:
36x optical zoom and 12x digital zoom, total 432x zoom
AXIS Q6034-C:
18x optical zoom and 12x digital zoom, total 216x zoom
AXIS Q6035 -C:
20x optical zoom and 12x digital zoom, total 240x zoom
Pan/tilt/zoom
functionalities
Tour recording, guard tour, control queue
On-screen directional indicator
Video
Video compression H.264 (MPEG-4 Part 10/AVC); Motion JPEG
Resolutions AXIS Q6032-C: Extended D1 752x480 to 176x120 (60 Hz),
Extended D1 736x576 to 176x144 (50 Hz)
AXIS Q6034-C: HDTV 720p 1280x720 to 320x180
AXIS Q6035-C: HDTV 1080p 1920x1080 to 320x180,
HDTV 720p 1280x720 to 320x180
Frame rate AXIS Q6032-C/Q6034-C:
H.264: Up to 30/25 fps (60/50 Hz) in all resolutions
Motion JPEG: Up to 30/25 fps (60/50 Hz) in all resolutions
AXIS Q6035 -C:
H.264: Up to 30/25 fps (60/50 Hz) in all resolutions; up to
60/50 fps (60/50 Hz) in HDT V 720p
Motion JPEG: Up to 25 fps (60/50 Hz) in HDTV 1080p; up to
50 fps (60/50 Hz) in HDTV 720p
Video streaming Multiple, individually configurable streams in H.264 and
Motion JPEG; controllable frame rate and bandwidth;
VBR/CBR H.264
Image settings Wide dynamic range (WDR), manual shutter time, compression,
color, brightness, sharpness, white balance, exposure control,
exposure zones, backlight compensation, fine tuning of behavior
at low light, rotation, text and image overlay, 32 individual 3D
privacy masks, image freeze on PTZ
AXIS Q6032-C: Electronic image stabilization (EIS)
Network
Security Password protection, IP address filtering, HTTPS encryption*,
IEEE 802.1X network access control*, digest authentication,
user access log
Supported
protocols
IPv4/v6, HT TP, HTTPS*, SSL/TLS*, QoS L ayer 3 DiffServ, FTP, CIFS/
SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS,
Dyn DNS, N TP, R T SP, R TP, T CP, UD P, IG MP, R TCP, ICM P, DHC P, AR P,
SOCKS
System integration
Application
Programming
Interface
Open API for software integration, including VAPIX® and
AXIS Camera Application Platform from Axis Communications;
specifications available at www.axis.com
ONVIF, specifications available at www.onvif.org
AXIS Video Hosting System (AVHS) with One-Click Camera
Connection
Intelligent video Video motion detection, autotracking, Active Gatekeeper,
AXIS Camera Application Platform enabling installation of
additional applications
Event triggers Video motion detection, autotracking, AXIS Camera
Application Platform, external input, PTZ preset, temperature,
memory card full
Event actions File upload: FTP, HTTP, network share and email
Notification: email, HTTP and TCP
PTZ preset, guard tour, autotracking, external output,
video recording to edge storage
Pre- and post-alarm video buffering
Data streaming Event data
Installation aid Pixel counter
General
Casing IP66- and NEMA 4X-rated metal casing (aluminum),
polycarbonate (PC) clear dome, sunshield (PC/ASA)
Memory 256 MB RAM, 128 MB Flash
Power See specifications under AXIS T8605 Media Converter Switch
Connectors IP66-rated multi-connector for DC power, Ethernet
10BASE-T/100BASE-TX and I/O, including 5 m (16 ft.) cable
Edge storage SD/SDHC/SDXC slot supporting memor y card up to 64 GB (card
not included); support for recording to network share (networkattached storage or file server)
Operating
conditions
-20 °C to 75 °C (-4 °F to 167 °F) with active cooling
Humidity 10 - 100% RH (condensing)
Approvals EMC
EN 55022 Class A, EN 61000-3-2, EN 61000-3-3,
EN 61000-6-1, EN 61000-6-2, EN 55024, EN 50121-4,
IEC 62236-4, FCC Part 15 Subpart B Class A, ICES-003 Class A,
VCCI Class A, C-tick A S/NZS CISPR 22, KCC Class A
Safety
IEC/EN/UL 60950-1, IEC/EN/UL 60950-22
Environmental
IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6,
IEC60068-2-14, IEC 60068-2-27
Camera compartment: IEC 60529 IP66, NEMA 250 Type 4X
MIL-ST D- 810G
500.5 Low pressure
502.5 Low temperature
505.5 Solar radiation
507.5 Humidity
510.5 Sand and dust**
501.5 High temperature
503.5 Temperature shock
506.5 Rain
509.5 Salt fog
514.6 Vibration
**Protected against entr y of sand and dust. Clear/smoked dome
cover may need to be replaced if exposed to sandblasts.
Weight 5.6 kg (12.4 lb.)
Included
accessories
AXIS T8605 Media Converter Switch with 2xRJ-45, 2xSFP,
2x1/O, power in, Bracket Mount DIN Clip, 5 m (16 ft.) IP66-rated
multi-connector cable, Installation Guide, Installation and
Management Software CD including AXIS Camera Companion,
Windows decoder 1-user license
Optional
accessories
AXIS T8008 PS12, AXIS T91A Mounting Accessories, A XIS T90A
Illuminators, AXIS P8221 Network I/O Audio Module, AXIS T8310
Video Surveillance Control Board, AXIS Camera Station,
smoked dome cover
Spare part Clear dome cover
* This product includes software developed by the OpenSSL Project for use in the
OpenSSL Toolkit. (www.openssl.org)
More information is available at www.axis.com
Loading...
