EPSON
THE AFFORDABLE EXTERNAL PRINT SERVER THAT
CONNECTS EPSON INK JET PRINTERS TO YOUR
NETWORK.
Meet the AXIS®1440 print server, the easiest, most
cost-effective way to connect many Epson ink jet printers
without a type B interface to your Ethernet network.
Simply plug it into your printer’s parallel port (no
parallel cable required), connect it to your 10BaseT
network cable, plug in the external power supply, run
the installation software and you’re in business. In
minutes, everyone on your network can be churning
out attention-grabbing, Photo Quality graphics and
razor sharp black text.
The AXIS 1440 lets you run TCP/IP, IPX/SPX,
AppleTalk and NetBIOS/NetBEUI protocols (among
others) simultaneously. So your Windows
Windows 95, Windows 98, Windows 3.x, Macintosh
®
UNIX
and OS/2®workstations can all access the printer
at the same time. Plus, the AXIS 1440 supports all
familiar Novell
and PCONSOLE—making pinpointing printer errors
quick and easy.
Monitoring printer and print server status is also a
snap. Users and network administrators can monitor
directly from their Windows or Macintosh workstations,
or use any standard Web browser to monitor printer or
print server status.
The AXIS 1440 was designed and developed jointly
by AXIS and Epson specifically for Epson ink jet printers.
Its software architecture is based upon AXIS’s ultra
reliable ThinServer™ technology. And its flash memory
can be upgraded from a central point directly over your
network for access to the latest features as soon as
they’re released.
Simple set up. Effortless monitoring. And upgrades in
a flash—all at a remarkably affordable price. The
AXIS 1440 is the smart way to give all
the users on your network
access to the power
of Epson ink jet printers.
®
Netware tools, including NW Admin
®
NT™,
®
AXIS 1440
Print Server
FEATURES BENEFITS
®
External print Connects EPSON Stylus
•
server for EPSON Stylus Color 740i, EPSON Stylus Color 760,
ink jet printers EPSON Color 850, EPSON Stylus Color 860,
Supports Compatible with Windows, Novell Netware,
•
all popular Macintosh and UNIX.
environments
Powerful Offers client user interface, SNMP and
•
management Web-based tools.
software
Easy Attaches to the printer parallel port. Software
•
installation installation wizard included. Can be configured
Flash New features are integrated quickly from
•
memory a central administration point.
®
,
EPSON Stylus Color 1160, EPSON Stylus Photo 700,
EPSON Stylus Photo EX, EPSON Stylus Photo 750
and EPSON Stylus Photo 1200 printers to an
Ethernet network.
directly from a Web browser.
Color 740, EPSON
AXIS 1440 PRINT SERVER SPECIFICATIONS
Network Operating Systems
Netware: 3.x, 4.x; NDS and bindery emulation;
NPRINTER, RPRINTER, PSERVER; up to 16 file
servers and 96 print queues
Netware 5: Legacy printers
Windows: NT version 3.5 and above, Windows 95,
Windows 98 Peer-to-Peer, Windows for Workgroups
Apple Ethertalk: Appletalk Phase 2
UNIX: all computers supporting the TCP/IP suite and
LPD
Microsoft LAN Manager: 2.0c and above, running under
OS/2 ver. 1.3 and above
IBM LAN Server: ver. 1.3 and above running on OS/2
ver. 1.3 and above, OS/2 Warp Connect
Supported Protocols
Netware: IPX, SAP, RIP, SPX and NCP (extended with
NDS), LIP
Windows: NetBIOS/NetBEUI or TCP/IP, WINS
TCP/IP: LPD, FTP, BOOTP, ARP, RARP, DHCP, ICMP, IP,
TCP, UDP, HTTP, SNMP (MIB II and private
MIB), SLP
Apple EtherTalk
LAN Manager/LAN Server: NetBIOS/NetBEUI or TCP/IP
Client Operating Systems
Windows 3.1x, Windows 95, Windows 98, Windows NT
3.51, Windows NT 4.0
Macintosh: 7.x, 8.0
OS/2: 1.3 and above including OS/2 Warp connect
UNIX: all systems supporting TCP/IP with LPD
Installation Tools
Netware: AXIS NetPilot Utility
Windows: AXIS Print Utility for Windows
Apple EtherTalk: standard installation using the
Chooser
UNIX: memory resident installation script
LAN Manager/LAN Server: AXIS Print Utility for OS/2
Management and Administration
AXIS NetPilot for configuration and printer status
monitoring
SNMP MIB II and private MIB
Built-in web-server allows configuration and status
monitoring using standard Web browsers
LAN Network Manager for OS/2
NWAdmin and PCONSOLE
Network Connection
IEEE 802.3 10BaseT using straight through twisted pair
cable and RJ45 connector
IEEE 802.2/802.3/snap and Ethernet II frame types
Hardware Specifications
32-bit RISC processor with 1MB flash memory and
256KB RAM
IEEE 1284 high-speed parallel port, 36 pin Centronics
connector; bidirectional support for Apple
LED indicators for Power and Network
Push button status printout
Reliability
MTBF 180,000 hrs
Safety Approvals
EMC FCC Class A, CE EN55022/1994,
EN50082-1/1992
Safety CE EN60950
Electrical Requirements
Power consumption: 170mA at 12VDC
External AC adapter provides 9V 300mA
Environmental Characteristics
Temperature (operating): 41-104ªF (5-40ªC)
Humidity (operating): 10-95% non-condensing
Dimensions
2.2" (5.6 cm) x 4.7" (11.8 cm) x 1.1" (2.7 cm)
(W x D x H)
Weight 0.26 lb (0.12 kg)
Warranty
Three year limited in the U.S. and Canada
Product Part Number
AXIS 1440 Print Server C1440AXIS
Support–The Epson Connection
SM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Website http://www.epson.com
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806 1-562-981-3840
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Specifications are subject to change without notice. EPSON and EPSON Stylus are registered trademarks of Seiko Epson Corporation. Epson Connection is a service mark of Epson
America, Inc. AXIS is a registered trademark and ThinServer is a trademark of Axis Communications. All other products and brand names are trademarks and/or registered
trademarks of their respective companies. Epson disclaims any and all rights in these marks.
©Copyright 1999 Epson America, Inc. CPD-6958R2 8K 11/99 CL
Epson Latin America, Inc.
6303 Blue Lagoon Drive, Miami, FL 33126 1-305-265-0092
Printed on recycled paper
