Licence Server User Guide
Edition 7.0
July 2011
Licence Server User Guide written by Daniel Spreadbury.
See the About Sibelius dialog for a full list of the
software development team and other credits.
We would like to thank all those (too numerous to list)
who have provided helpful comments and suggestions for
Sibelius and its documentation.
Legal Notices
This product is subject to the terms and conditions of a
software license agreement.
This guide is copyrighted © 2011 by Avid Technology
Inc., (hereafter “Avid”), with all rights reserved. Under
copyright laws, this guide may not be duplicated in whole
or in part without the written consent of Avid.
Avid, Sibelius and Scorch are registered trademarks of
Avid Technology, Inc. in the USA, UK and other countries.
All other trademarks are acknowledged as the property of
their respective owners.
Product features, specifications, system requirements,
and availability are subject to change without notice.
Document Feedback
We are always looking for ways to improve our
documentation. If you have comments, corrections, or
suggestions regarding our documentation, please email
us at docs@sibelius.com.
Contents
Introduction to network site licences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing and upgrading 5
Installation on Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation on Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Upgrading on Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Upgrading on Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing Sibelius . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Configuring and using the Licence Server 19
Configuring the Licence Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Registering the Licence Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Testing the Licence Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Access Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting up Classroom Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Checking out licences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Working with clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Reading logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Maintaining the Licence Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Appendices 45
Appendix A: Starting or stopping the Licence Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Appendix B: Manually locating Licence Server logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Appendix C: Licence Server error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Appendix D: Useful command line commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
3
Sibelius Licence Server User Guide
Introduction to network site licences
Two types of Sibelius site licence are available: stand-alone site licences and network site licences. You
have purchased a network site licence for a fixed number of copies.
Sibelius’s network version operates on a client-server model. The client is the Sibelius program itself,
which is installed on the local hard drive of each of the student workstations, and the server is the
separate Licence Server program, which is installed on a single designated server.
The Licence Server enables the designated number of licenced client copies to run on the network
simultaneously. These are known as floating licences, because they are not tied to any particular
computer on the network: any computer with the software installed can connect to the Licence
Server, assuming the Licence Server has seats available. It also lets you send messages to users of the
client copies, and close copies down from the server machine.
With supported products, it even allows you to specify that students can temporarily move licences
from the Licence Server to their own machines so that they can run the software when not connected
to the Licence Server. These are known as check out licences, because the student checks out the
licence from the Licence Server, which reduces the number of floating licences available by one until
the student either checks it back in, or it expires, at which point the licence is automatically returned
to the pool of floating licences so that it can be used on a different computer.
The Licence Server itself does not have a graphical user interface, because it runs in the background,
listening to requests from client copies of Sibelius on the network. The server is therefore configured
and managed using the graphical Licence Server Control Panel, which you can run either on the
computer on which the Licence Server is installed, or from another workstation.
The Licence Server and Licence Server Control Panel programs are supplied on the main Sibelius
DVD-ROM, but must be installed separately from Sibelius itself.
Requirements
The Sibelius Licence Server and the Licence Server Control Panel will run on the following operating
systems:
Windows:
Mac OS X: Mac OS X 10.6.8, Mac OS X 10.6.8 Server, Mac OS X 10.7.
The software has been tested both on Apple Mac workstations and on Apple Xserve servers.
Sibelius requires a network using the TCP/IP protocol. (Your network may use other protocols in
addition to TCP/IP, but TCP/IP must be present in order for the Licence Server to communicate with
the client copies.) If you use a firewall on your network, ensure that port 7312 is open both for TCP/IP
and UDP traffic.
If you use a Novell network, note that you cannot install the Sibelius Licence Server onto a server
running Novell Netware. The Licence Server can only be run on Windows or Mac OS X servers or
workstations. To run Sibelius on a Novell network, you will need to install the Licence Server
program on a suitable Windows or Mac OS X workstation.
Windows Vista 32-bit, Windows 7 32-bit or 64-bit, Windows 2008 Server.
4
Installing
and upgrading
Sibelius Licence Server User Guide
6
Installation on Windows
Installation on Windows
If you are upgrading your Licence Server from any earlier version of Sibelius, see Upgrading on
Windows
Installing the Licence Server
Insert your Sibelius 7 Program Disc DVD-ROM.
When the on-screen menu appears, click Browse this disc.
In the Windows Explorer window that opens, double-click the Network Licence Users Only
folder, then double-click LicenceServerInstaller.msi to start the installation.
You will see the following window:
on page 13.
Click Next.
Next you will be asked if you want to install the Windows service:
Unless you are intending to install the Control Panel only on this computer (because you have
already installed the Licence Server itself on another machine), you should leave the
Windows service for Licence Server
option switched on, then click Next.
Install
7
Sibelius Licence Server User Guide
Now you will be prompted to choose an installation folder:
By default, the Licence Server will be installed to the folder
7 Licence Server
change this if you wish by clicking
(on a 64-bit system, this will be in C:\Program Files (x86)\) but you can
Browse. Make sure that the Administrator group of users has
C:\Program Files\Avid\Sibelius
full read and write access to the folder you have chosen. If your chosen folder does not exist, the
installer will create it for you.
Once you have determined where the Licence Server should be installed, click
You are told that the installer is ready:
Click
Next.
You will see a progress bar as the Licence Server and Control Panel are installed. If you have a
firewall active, you may see a window appear telling you that
LicenceServerV6.exe is trying to
Next.
access the Internet: this is normal and happens when the Windows service is started for the first
time. Choose whichever option tells your firewall that this program is safe to access the Internet.
Depending on the specific firewall you are using, you may not receive a notification at this point,
in which case you should now go to your firewall’s control panel and open port 7312 for both
TCP and UDP traffic.
After a few moments, you will be told that installation has completed successfully. Click Close
to exit the installer.
Configuring and using the Licence Server
Now see
Configuring the Licence Server on page 21.
8
Installation on Windows
Installing Sibelius on the client computers
Once you have installed and configured the Licence Server, you need to install the Sibelius client
application on each client machine you want to use with the Licence Server: see
Installing Sibelius
on page 17.
Uninstalling the Licence Server
If you need to uninstall the Licence Server (e.g. to upgrade it, or to install it on another computer),
do so as follows:
Choose Start Control Panel, then double-click Programs and Features.
In the list of installed programs, select Sibelius 7 Licence Server, and click Uninstall.
Follow the on-screen prompts to uninstall the Sibelius Licence Server.
Once the Licence Server has been uninstalled, the registration data is also removed, and if you
subsequently reinstall the Licence Server on the same computer, you will have to re-register and
reconfigure it.
9
Sibelius Licence Server User Guide
Installation on Mac OS X
If you are upgrading your Licence Server from any earlier version of Sibelius, see Upgrading on
Mac OS X
Installing the Licence Server
The Licence Server and the associated Control Panel application should be installed to the
Applications folder on your Mac’s system volume, and scripts are installed in the /Library/
StartupItems
up.
The provided installer will install all the files to the correct locations, and you are strongly
recommended to accept the default locations. If you want to install the Licence Server to another
location on your computer, you will have to manually edit the scripts in
and /Applications/Sibelius 7 Licence Server after installation. This is not something that
inexperienced network administrators should attempt!
To perform the standard, recommended installation:
Insert your Sibelius 7 Program Disc DVD-ROM. A window should appear showing a number of
icons: first, open the
Licence Server
The following window will appear:
on page 15.
folder so that the Licence Server starts automatically when your computer starts
/Library/StartupItems
Network Licence Users Only folder, then double-click Install Sibelius
to begin.
10
Continue to proceed.
Click
Installation on Mac OS X
You are asked to select the destination volume for the software to be installed. Choose your Mac’s
start-up volume, then click
Next, you are told that the installer will perform a standard installation:
You are now prompted to provide an administrator username and password: do so, and click OK.
Next you will see a progress bar as the files are installed to your Mac’s hard disk:
Continue.
After a few moments, you will be told that the installation has completed successfully.
Click Close to exit the installation.
Configuring and using the Licence Server
Now see
Configuring the Licence Server on page 21.
11
Sibelius Licence Server User Guide
Installing Sibelius on the client computers
Once you have installed and configured the Licence Server, you need to install the Sibelius client
application on each client machine you want to use with the Licence Server: refer to
Sibelius
on page 17.
Installing
Uninstalling the Licence Server
To uninstall the Licence Server:
Run Terminal, which you can find in /Applications/Utilities.
In a Finder window, go to the Sibelius 7 Licence Server folder inside your Applications
folder.
Drag the uninstall.sh file onto the Terminal window.
You will see /Applications/Sibelius\ 7\ Licence\ Server/uninstall.sh appear in the
Termina l w indow: hit
You will be prompted to provide your administrator password: do so and hit Return.
You will see a few messages output to the Terminal window as the Licence Server is shut down
Return.
and deleted.
Once the Licence Server has been uninstalled, the registration data is also removed, and if you
subsequently reinstall the Licence Server on the same computer, you will have to re-register and
reconfigure it.
12
Upgrading on Windows
Upgrading on Windows
To upgrade your network site licence from Sibelius 1.4, Sibelius 2, Sibelius 3 or Sibelius 4, Sibelius 5
or Sibelius 6 to Sibelius 7, you will need to upgrade both the Licence Server and all the client
machines.
Upgrading previous versions of the Licence Server
Quit the Licence Server on the computer on which it is installed, referring to the appropriate
booklet.
If you have the Licence Server installed as a Windows service, uninstall it:
For Sibelius 1, 2 and 3: go to the Licence Server console and type uninstall
For Sibelius 4: open a command window (by clicking Start, typing cmd and hitting Return),
navigate to the folder that contains the Licence Server and type:
LicenceServerV4 –v –uninstall
For Sibelius 5.0: open a command window (by clicking Start, typing cmd and hitting
Return), navigate to the folder that contains the Licence Server and type:
LicenceServerV5 –v –uninstall
For Sibelius 5.1 or later: uninstall Sibelius Licence Server via Programs and Features.
This will stop and uninstall the service, and remove all the necessary files.
For Sibelius 6: uninstall Sibelius 6 Licence Server via Programs and Features. This will
stop and uninstall the service, and remove all the necessary files.
It is very important to uninstall the service in the correct way to avoid leaving a service that can’t
be removed.
Delete the folder containing the old Licence Server to avoid confusion with the later version.
Upgrading the client machines
To upgrade each of the client machines, use the Sibelius 7 DVD-ROM and follow the instructions
in the supplied printed Quick Start Guide.
When you first run Sibelius 7, the splash screen will say
UNREGISTERED COPY as the program
is loading (because at that point it has not yet been registered by the Licence Server over the
network), and will then change to say
Registered to Network User once the program is given
permission to run by the Licence Server.
Running multiple Licence Servers
The Sibelius 7 Licence Server can coexist with licence servers for previous versions of Sibelius
between Sibelius 6 and Sibelius 3, and may be run simultaneously and installed concurrently on
the same server.
If you need to do this, it will be necessary to change the port number used by at least one of the
licence servers. It may be simplest to change the port number used by the new Sibelius 7 Licence
Server, in which case:
Temporarily stop your existing Licence Server, consulting the documentation that was supplied
with that version of the Licence Server.
13
Sibelius Licence Server User Guide
Install the Sibelius 7 Licence Server, following the instructions in Installation on Windows
on page 7.
Change the port number used by the Sibelius 7 Licence Server, following the instructions in
Changing the port used by the Licence Server on page 40.
Restart your existing Licence Server, consulting the documentation that was supplied with that
version of the Licence Server.
When signing on a client copy for the first time to a licence server with a different port number,
the syntax for the server IP address will be, for example,
192.168.1.183:8989 (where 8989 is
whatever new port you have chosen).
If you do not have the most up-to-date Sibelius 3 or 4 Licence Server, visit:
http://www.sibelius.com/helpcenter/upgrades.html#network
to download the latest version.
14
Upgrading on Mac OS X
Upgrading on Mac OS X
To upgrade your network site licence from Sibelius 1.4, Sibelius 2, Sibelius 3 or Sibelius 4, Sibelius
5 or Sibelius 6 to Sibelius 7, you will need to upgrade both the Licence Server and all the client
machines.
Upgrading the Licence Server
For Sibelius 1, 2, 3, 4 and 5.0:
Run Terminal, change to the root user (sudo bash -login), navigate to the folder that
contains the Licence Server (
stop_licence_server (./stop_licence_server).
If you have set the old version of the Licence Server to run on start-up, e.g. by specifying that
it should run in
tion simply by adding a
/etc/rc.local, you should also disable this. You can disable the line in ques-
# character at the start of the line. If you followed the instructions
supplied with the previous version, the line probably looks like this:
/usr/local/bin/start_licence_server
so edit it so that it looks like this:
# /usr/local/bin/start_licence_server
You should also delete the old Licence Server executable and the three associated scripts.
Again, these will normally be found in
For Sibelius 5.1:
Run Terminal, which you can find in /Applications/Utilities.
Ty pe sudo /Applications/Sibelius\ Licence\ Server/uninstall.sh and hit Return.
You will be prompted to provide your administrator password: do so and hit Return.
You will see a few messages output to the Terminal window as the Licence Server is shut
down and deleted.
For Sibelius 6:
Run Terminal, which you can find in /Applications/Utilities.
Ty pe sudo /Applications/Sibelius\ 6\ Licence\ Server/uninstall.sh and hit Return.
You will be prompted to provide your administrator password: do so and hit Return.
You will see a few messages output to the Terminal window as the Licence Server is shut
down and deleted.
Install, register, configure and run the Sibelius 7 Licence Server according to the instructions in
Installation on Mac OS X on page 10.
cd /usr/local/bin) and run the script called
/usr/local/bin.
Upgrading the client machines
To upgrade each of the client machines, use the Sibelius 7 DVD-ROM and follow the instructions
in the separate printed Quick Start Guide.
When you first run Sibelius 7, the splash screen will say
UNREGISTERED COPY as the program
is loading (because at that point it has not yet been registered by the Licence Server over the
network), and will then change to say
Registered to Network User once the program is given
permission to run by the Licence Server.
15
Sibelius Licence Server User Guide
Running multiple Licence Servers
The Sibelius 7 Licence Server can coexist with licence servers for previous versions of Sibelius
between Sibelius 6 and Sibelius 3, and may be run simultaneously and installed concurrently on
the same server.
If you need to do this, it will be necessary to change the port number used by at least one of the
licence servers. It may be simplest to change the port number used by the new Sibelius 7 Licence
Server, in which case:
Temporarily stop your existing Licence Server, consulting the documentation that was supplied
with that version of the Licence Server.
Install the Sibelius 7 Licence Server, following the instructions in Installation on Mac OS X
on page 10.
Change the port number used by the Sibelius 7 Licence Server, following the instructions in
Changing the port used by the Licence Server on page 40.
Restart your existing Licence Server, consulting the documentation that was supplied with that
version of the Licence Server.
When signing on a client copy for the first time to a licence server with a different port number,
the syntax for the server IP address will be, for example,
192.168.1.183:8989 (where 8989 is
whatever new port you have chosen).
If you do not have the most up-to-date Sibelius 3 or 4 Licence Server, visit:
http://www.sibelius.com/helpcenter/upgrades.html#network
to download the latest version.
16
Installing Sibelius
Installing Sibelius
Example scores
Before you install Sibelius, you should liaise with your music staff or network administrators about
the best place to install Sibelius’s example scores.
On Windows, Sibelius installs the example scores into a folder called Example Scores inside
the
Sibelius 7 program folder, and creates a shortcut to this folder inside the My Documents
folder belonging to the current user. If you want to make these files available to all users, you
should manually copy the
On Mac, Sibelius installs the example scores into a folder called
inside
/Users/Shared/Documents
Installing Sibelius on your client machines
It is essential that Sibelius or Sibelius Student be installed on the local hard disk of each client
machine. It cannot be installed on a network drive or a virtual disk.
You can install on all the client computers using the same serial number; as long as all your
computers are connected on the same network via TCP/IP and can thus see the machine running
the Licence Server, they can share the same licence.
You can install Sibelius or Sibelius Student on as many computers as you like, but the Licence
Server will only allow as many copies as are licenced to be run simultaneously; you could, say,
install Sibelius on 30 computers, but if you only have a licence for 10 copies, only 10 copies will be
able to run simultaneously.
Example Scores folder to an appropriate location on the network.
Sibelius Example Scores
, which will be accessible to all users on that client machine.
Note that, regardless of how many copies you have bought, you will only receive one installation
DVD-ROM and serial number, valid for the appropriate number of licences purchased.
Install Sibelius on each of your client machines following the instructions in your Handbook, using
the same serial number (starting
SCEM, SCEW, SWEW, or SCEG) that you used to install and
register the Licence Server (you don’t need to register the client copies).
Alternatively, you can install Sibelius 7 on each client machine using a special command that will
automatically set the serial number and Licence Server address at installation time, rather than
when running the client for the first time. To do this:
Insert the Sibelius 7 DVD-ROM in the client machine. When the main installation menu
appears, click
Open a command window: on Windows XP, choose Start Run, then type cmd and hit Return;
on Windows Vista, click
Type t h e foll owing c omman d:
D:\Sibelius\InstallSibelius.exe /SERIAL=serialno /LSINFO=ip:port /SILENT
Exit.
Start, type cmd and hit Return.
where you should replace:
D with the drive letter corresponding to your DVD-ROM drive
serialno with your serial number, without spaces, e.g. SCEM700123456123456
17
Sibelius Licence Server User Guide
ip:port with the IP address (or hostname) and port number of the Licence Server, e.g.
192.168.1.10:7812
The Sibelius installer will then run without requiring any further intervention from you.
When you first run Sibelius 7, the splash screen will say
UNREGISTERED COPY as the program
is loading (because at that point it has not yet been registered by the Licence Server over the
network), and will then change to say
Registered to Network User once the program is given
permission to run by the Licence Server.
Running for the first time
When you run each client copy of Sibelius for the first time, you will be prompted for the location
of the machine running the Licence Server. You should supply this information as an IP address
(e.g.
192.168.1.100) or you can specify the server name (e.g. server).
You can also enter the port on which the Licence Server is running (e.g. 192.168.1.100:8989)
(although there is no need to do this unless you have explicitly changed it when setting up the
Licence Server – see
Configuring the Licence Server on page 21).
This information is stored on the client computer and does not need to be entered again.
Sibelius will then contact the server in order to get permission to run. If the maximum number of
licenced copies has not been exceeded, it will start up and run normally. If the maximum number
of copies has been reached, a message will inform you of this and Sibelius will quit.
As the networked copies of Sibelius run, they remain in contact with the server, which maintains a
list of copies running. Should a client machine crash or become disconnected for some reason, the
Licence Server will remove that copy from the list. If a copy of Sibelius cannot contact the Licence
Server, it will quit, allowing the user to save their work first.
Note about subnet masks
A subnet mask is used on a TCP/IP network to determine which IP addresses belong to the
individual network, or subnet. For example, a typical network uses IP addresses in the range
192.168.1.n (where n is an integer from 0-255); in this case, the subnet mask would be
255.255.255.0, signifying that only the last digit of the IP address of each client machine on the
network may be variable. The final digit of the subnet mask address varies according to the precise
range of the subnet: a value of 0 allows the full range of 0-255 to be used in the IP addresses of the
client machines.
In some cases, particularly where a network uses dynamically-assigned IP addressing (via DHCP),
the subnet mask on the machine running the Sibelius Licence Server may not be correctly
configured to allow access by all client machines on the network.
The symptoms of this problem are as follows:
Sibelius cannot find the Licence Server on the network, but;
it is possible to ping the server machine from the client machine and vice versa.
If you experience the above problem, review the subnet mask settings on both machines. If your
network uses a router to control access from one subnet to another, the router will take precedence
over the subnet mask setting.
18
Configuring and
using the Licence
Server
Sibelius Licence Server User Guide
20
Configuring the Licence Server
Configuring the Licence Server
Termi n o l ogy
Before we get into the details of how to configure the Licence Server, some important terms are
defined here:
Server: this is the Licence Server program itself, as opposed to a service (see below).
Service: a process on your computer that runs in the background performing one or more
specific tasks. Many services are started automatically when your computer runs, or when a
specific user logs in. The Licence Server is intended to be run as a service, meaning that it will be
started automatically when the computer is started.
Licence Server states
When the Sibelius Licence Server is running, it can be in one of four different states, which are
normally passed through in order, as follows:
Installed. Simply running the installer achieves this state.
Running the service. The installer also automatically starts the service.
Registered. You have to provide the Licence Server with its registration information (the Sibelius
serial number and Registration Number) in order to move into the final state.
Running the server. As soon as the Licence Server is registered, it becomes fully operational, and
can authorize client copies of Sibelius.
You can stop and restart the Licence Server at any time using the Licence Server Control Panel;
when you restart it, it will return to the same state as when you stopped it.
Once the Sibelius Licence Server reaches the fourth and final state (running the server), it is ready
to use.
Running the Licence Server Control Panel
In order to see the status of the Licence Server and make changes to its configuration, you use the
Licence Server Control Panel. You can run the Control Panel either on the same machine that the
Licence Server is installed, or on another workstation. To run the Control Panel:
On Windows, choose Start Control Panel, then double-click Sibelius 7 Licence Server. If
you don’t see the icon in your Control Panel, you can also find it in your Start menu, in
Programs Sibelius Software Sibelius 7 Licence Server Control Panel.
On Mac, navigate to the Sibelius 7 Licence Server folder inside Applications, then double-
click the
LicenceServerControlPanel icon.
21
Sibelius Licence Server User Guide
The following window will appear:
As you can see, there are six pages in the Control Panel:
Server Status shows the status of the server at a glance, and allows you to perform the essential
configuration tasks: locating the server; starting and stopping the service (Windows only);
starting and stopping the server; and setting the teacher’s password for Sibelius’s Classroom
Control feature.
Licences is where you register your Licence Server, allowing you to specify how many floating
licences of Sibelius or Sibelius Student you can run simultaneously, and how many (if any)
copies can be temporarily checked out onto student computers disconnected from the network.
Server Options allows you to set some more advanced properties of the server, including log
verbosity (i.e. how detailed the logs should be), how long the client time-out should be, and what
port the server should run on. You can also run some very useful diagnostics on the Licence
Server from this page.
Access Control determines which computers can connect to the Licence Server, both for
authorizing Sibelius clients and for determining which machines can be used to run the Control
Panel to configure the server.
Clients shows details of the clients that are currently connected to the server, and allows you to
send messages to them, or close the clients down.
Log shows the Licence Server log file, useful for diagnostics.
The options on each of these pages are discussed in detail in the following pages.
22
Registering the Licence Server
Registering the Licence Server
Connecting to the Licence Server
At the top of the
Licence Server that the Control Panel is connected to:
By default, the Control Panel assumes that the Licence Server is running on the same machine,
which is represented by the special IP address
You can tell whether or not the Control Panel has successfully connected to the Licence Server by
reading the status message in the
If the Control Panel has successfully connected to the Licence Server, you will see the following
status message:
Server Status page of the Control Panel, you can see the IP address of the
127.0.0.1, on the default port (7312).
Server Status group at the bottom of the page.
If you see this message, skip down to
Unable to connect?
If the Control Panel is unable to connect to the Licence Server, you will see the following status
message:
If you see
Click the Find button at the top of the page. The Control Panel will then search your local
Check your firewall rules. Make sure that port 7312 is open for both TCP and UDP traffic, then
Licence Server is not responding:
network for running Licence Servers. If multiple running servers are found, you will be
prompted to choose which Licence Server to connect to. If, on the other hand, you are told that
No Licence Servers were found on your subnet, or if one or more servers appears, but not
the one you expect to see, read on.
click
Find again.
Adding a licence to the Licence Server on page 25.
23
Sibelius Licence Server User Guide
If Find reports no licence servers, click Set and the following dialog will appear:
If the Licence Server is running on the same machine from which you are running the Control
Panel, make sure that
Server is running on this machine (localhost) is switched on.
If the Licence Server is running on another machine, type the IP address of the machine.
If you still can’t connect, check that the Licence Server process is running:
On Windows, run the Services management console (choose Start, then type
services.msc and hit Return). In the list of services, look for Sibelius Licence Server V7:
check that
Status is set to Started:
Status is empty, then the service is not running, and you should try starting it manually – see
If
Appendix A: Starting or stopping the Licence Server on page 47.
24
Registering the Licence Server
On Mac, run Activity Monitor (from /Applications/Utilities), and make sure that the
Show drop-down at the top of the window is set to All Processes. Type licence into the
Filter edit box, and you should see the LicenceServer process listed:
Don’t worry if the
LicenceServer process is colored red and says (Not Responding). This is
a quirk of how the Licence Server process appears in Activity Monitor; provided the CPU
usage for the process is at a low level (e.g. below 10%), chances are everything is working fine.
If the
LicenceServer process does not appear in the list, you should try starting it manually
– see
Appendix A: Starting or stopping the Licence Server on page 47.
If all else fails, refer to the further troubleshooting steps in Troubleshooting on page 42.
Adding a licence to the Licence Server
Before any of your client computers can connect to the Licence Server, you need to add a licence
and register it. Switch to the Licences page, which looks like this:
25
Sibelius Licence Server User Guide
The
Licences page allows you to add licences for multiple products so that you can, for example,
run separate licences for both Sibelius and Sibelius Student on the same network (as provided in
the Sibelius Student Network Pack). Each product can have one or more licences, identified by an
individual serial number, and appears as a separate row in the table on the
Licences page.
The columns in this table are as follows:
Product shows the name of the licenced product. Normally this will say either Sibelius or
Sibelius Student, as appropriate.
Serial number shows the serial number of the licenced product. This will typically begin with
SCEW for Sibelius, or ZCEW for Sibelius Student.
Registered shows whether or not the licence is currently registered: if this says No, then client
copies will not be able to obtain a licence from the Licence Server.
Total licences is the total number of seats for which your licence is registered: if this says e.g.
25, then a total of 25 client copies can connect to the Licence Server concurrently.
Licences available is the number of licences that are not currently in use by clients connected
to the Licence Server.
Max. check outs is the total number of licences from the Total licences number that are
allowed to be checked out by students so that they can disconnect their computers from the
network and continue to use the software for a time, e.g. at home.
Checked out now is the total number of licences that are currently checked out to students.
Licences that are checked out to students are not available on your network while they are
checked out: so if you have a 25-seat licence, and five seats are checked out to students, only 20
client computers will be able to connect to your Licence Server until those copies are checked
back in.
For more information on checking out licences, see
For now, simply click
will normally begin
Click
OK, and the serial number is added to the list of licences:
Add. A dialog appears into which you should type your serial number, which
SCMM for Sibelius, or ZCEW for Sibelius Student:
26
Checking out licences on page 33.
Registering the Licence Server
Notice that
Server, so click
Click Generate Computer Number to generate your Computer Number. Now you should
Registered says No, which means that client copies cannot yet connect to the Licence
Register. The following dialog appears:
contact Sibelius registration with your serial number and Computer Number. (If you have
multiple licences to add, it makes sense to add each of them and send all pairs of serial numbers
and Computer Numbers together, so you will receive all the Registration Numbers together.)
When you receive your Registration Number from Sibelius registration, type it into the
Registration Number edit box.
Type the number of seats in your license into the Number of copies edit box.
Once you have typed both the number of copies and the Registration Number correctly, the OK
button will become enabled.
Click OK to complete the registration: after a few moments you will be told that your
registration was successful.
In the table on the
number. If you switch to the
Licences page, the Registered column will now read Yes for that serial
Status page, you will now see the following status messages near the
bottom of the page:
Congratulations! Your Licence Server is now registered and running. Notice that you are told the
total number of copies in your license (in the above example, 25 clients), and how many clients are
connected at the moment (in the above example, none).
If you have another licence to add and register, e.g. for the copies of Sibelius Student in your
Sibelius Student Network Pack, follow the steps above again.
The next step is to test client-server communication with the Licence Server using the built-in
testing feature.
27
Sibelius Licence Server User Guide
Testing the Licence Server
Once you have registered the Licence Server, you can test client connections to the server using the
Licence Server Control Panel. Choose the
Server Options page:
To test client connections, simply choose one of your registered products from the
combo box, set the Number of clients to simulate, then click Run Test Now. The Licence
Server Control Panel will spawn the specified number of windows (so be careful not to set too high
a number!), each of which pretends to be a running client copy of Sibelius or Sibelius Student.
Each window has a colored background:
A green background means that the test client is running successfully. You can see a log of the
communication the client has received from the server in the pane at the bottom of the test client
window.
Serial number
28
Testing the Licence Server
If a test client fails to connect for whatever reason, it shows a red background:
Again, you can see the reason why the test client failed to connect in the pane at the bottom of the
window. In the above example, the Licence Server already had the maximum number of allowed
clients connected, so it refused authorisation (hence the message
not enough licences).
To close all the test client windows, click Close All Test Clients.
If no test clients can connect
If no test clients are able to connect to the Licence Server, consider the following:
Is the Licence Server running, and if so, is it correctly registered? Check the read-out under
Server Status on the Status page of the control panel.
Is your firewall blocking communication between the Licence Server and the test clients? Make
sure that the correct port (
Is the Licence Server prevented from accepting client connections from the IP address of the
computer you are using to test the connection? See
7312 by default) is open for both the TCP and UDP protocols.
Access Control on page 30.
If all else fails, consult
Troubleshooting on page 42.
29
Sibelius Licence Server User Guide
Access Control
On the Access Control page of the Licence Server Control Panel, you can set up rules about
which computers on your network can connect to the Licence Server in order to authorize client
copies of Sibelius or change settings for the Licence Server itself.
Clients and Managers
By now you will be familiar with the term client, meaning a computer on which Sibelius is
installed, and which will be connecting to the Licence Server for authorization. Clients are
specified by IP addresses, or ranges of IP addresses.
A manager is a computer from which it is possible to change settings for the Licence Server. As
with clients, managers are specified by IP addresses.
Typically, you would need somewhat permissive access control for clients (because you may have
Sibelius installed on every computer in the school, for example) and less permissive access control
for managers (because only, say, the network administrator and the teacher’s workstation should
be able to change Licence Server settings).
Allow or Block
Simply put, a machine at a given IP address can connect to the Licence Server if it is set to allow,
and cannot connect to the Licence Server if it is set to block.
Setting up access controls
By default, only the local machine’s IP address (
a manager, but any machine (
typically don’t need to configure anything in order for client machines to connect to the Licence
Server.
*.*.*.*) can connect to the server as a client. This means that you
127.0.0.1) is given access to the Licence Server as
30
Access Control
However, you may want to specify particular ranges of IP addresses for clients and managers, in
which case read on.
Local area networks usually use one of three specially designated ranges of IP addresses (
10.255.255.255, 172.16.0.0 – 172.31.255.255 or 192.168.0.0 – 192.168.255.255). If you are
10.0.0 –
not sure what range of IP addresses is used by your network, contact your network administrator
before you proceed.
Normally you will want to grant client access to your whole subnet. For example, if the IP
addresses of all your clients are in the range
172.16.0.0 –172.16.1.255, you would type 172.16.*.*
into the boxes provided, as follows:
then click the
Server. An asterisk (
Allow button next to Client, then click Apply to send your changes to the Licence
*) means that the Licence Server should accept any value in the range 0–255.
You may need to block client access to a particular IP address or a range of machines, in which case
enter the IP address as above, and click
Block, then Apply.
To grant manager access, enter the IP address as above, then click the Allow button next to
Manager, then Apply. You are recommended to limit manager access to only those machines that
absolutely require it.
To remove a specific access control restriction, select the appropriate row in the table at the top of
the page, then click
Delete.
If at any point you want to reset the access control settings to their defaults, click Restore
Defaults
. You will be asked to confirm that you want to proceed: click Yes.
31
Sibelius Licence Server User Guide
Setting up Classroom Control
Sibelius’s Classroom Control feature allows you to perform simple classroom management tasks
directly from within Sibelius, including sending files to student workstations, getting files from
student workstations, “freezing” the client copies of Sibelius so that you can attract the attention of
the students in the classroom, and more.
Setting the teacher password
To ensure that only the teacher has access to the
change the password, go to the
Change teacher’s password. The following dialog appears:
Status page of the Licence Server Control Panel, and click
File Classroom Control dialog in Sibelius. To
Type the default password (
password into the
Server Control Panel will warn you if the passwords don’t match, or if the new password is the
same as the current password. Make sure you keep your password secure, and try to make it
difficult for students to guess.
For more information,
Classroom Control for multiple products on the same network
If you have the Sibelius Student Network Pack, you will have at least one copy of Sibelius, and at
least 20 copies of Sibelius Student, which are all connected to the same network. As such, when the
teacher uses
Sibelius Student that are currently running on the network.
Client copies of Sibelius and Sibelius Student behave identically with regard to Classroom Control,
though the
not in Sibelius Student.
New password and Confirm password fields, and click OK. The Licence
File Classroom Control in Sibelius, he or she will see all copies of both Sibelius and
File Classroom Control dialog for the teacher is only available in full Sibelius, and
sibelius) into the Current password field, then type your new
5.3 Classroom Control in Sibelius Reference.
32
Checking out licences
Checking out licences
If students at your institution have their own laptop computers that they bring to school, you may
find it useful to allow students to take copies of Sibelius or Sibelius Student home with them for a
time, e.g. for the duration of a semester, or over a weekend or the summer vacation.
Such a temporary licence is a check out licence, because the student “checks it out” of the Licence
Server when he or she wants to take his or her computer away from the school network, and then
“checks it back in” when he or she next connects to the school network once more. If the student
does not check the licence back in, it eventually expires, after which the student is no longer able to
run the software on his or her computer until it is reconnected to the school network.
When a licence is checked out from the Licence Server, the pool of available licences remaining for
use on the school network decreases by one seat for the duration of the check out period, so it is
important to specify a limit to how many of the total seats in your licence can be checked out by
students at once.
You may even find it useful to purchase additional seats, or indeed a separate licence, specifically
for the purpose of checking out licenses for students: you can run multiple licences on the same
licence server, so you could earmark one licence for use on the school network, and another licence
for check our licences for your students.
Setting up check out licences
The first step for setting up check out licences is to decide how many of the total number of seats
available in your licence should be allowed to be checked out at any one time. If you have a 25 seat
licence, you may want to limit the number of check out licences to, say, 10 copies, so that there are
always at least 15 seats available for use on your school computers.
By default, no licences are made available for checking out, so you have to choose how many to
allow. Go to the
you want to allow check out licences, and click
appears:
To enable check out licences, switch on the
By default, the number of licenses to be checked out defaults to half of the total number of licences
available, but you can change this to as many or as few of the available licences as you like.
Licences page of the Licence Server Control Panel, select the licence for which
Check Out Settings. The following dialog
Allow x of y licences to be checked out checkbox.
33
Sibelius Licence Server User Guide
Check out licences are by their nature temporary, so next you must choose how long to allow the
licences to be used for. You can choose between allowing licences to be checked out for a certain
number of days, which is useful for allowing students to routinely check out licences for short
periods, e.g. weekends, or until a particular date, allowing students to check out licences for an
extended period, e.g. up until the end of the semester or the academic year.
To allow a licence to be checked out for a certain number of days, choose the
button, and specify the number of days. To specify a fixed expiry date, choose the
in n days radio
on this date
radio button and type the date using the format dd/mm/yyyy, e.g. 31/07/2010 (31 July 2010).
When you are happy with your settings, click OK. The Max. check outs column in the table on
the
Licences page of the Licence Server Control Panel reflects the number of check out licences
that you have specified.
Monitoring check out licences
You can see the number of licences that are currently checked out at a glance in the
now
column of the Licences page of the Licence Server Control Panel.
Checked out
For more detailed information, look at the Clients page of the Licence Server Control Panel, where
you can see details of which users currently have licences checked out: the Licence Server records
the user account name and the machine name (if available), and shows when the check out licence
will automatically expire.
Revoking check out licences
There may be circumstances in which you need to revoke a check out licence to return that seat to
the pool of floating licences before the licence is checked back in by the student, or before its
automatic expiry time. For example, if the student’s laptop is lost or stolen, or if the student leaves
the institution.
When you revoke a check out licence, it is returned immediately to the pool of floating licences,
but that licence will nevertheless remain active on the computer on which it was checked out until
it expires, at which point the client copy of Sibelius will no longer run on the client.
To prevent abuse of this system, the number of times you can revoke check out licences is limited
to the total number of seats in your licence: if you have a 30 seat licence, you may revoke check out
licences 30 times, but once you reach this limit, you will need to contact Sibelius to re-register your
Licence Server to reset this limit. At the point at which the check out licence would have expired,
the record of the revocation is removed, increasing the number of available revocations by one. To
help you keep track of this limit, Sibelius will tell you how many revocations you have available
when you revoke a check out licence.
To revoke a check out licence, go to the
client in the list, and click
revoke the licence: click
Revoke Licence. You are asked to confirm that you do indeed want to
Yes . The client disappears from the list, and the Checked out now
Clients page of the Licence Server Control Panel, select the
column is reduced by one on the Licences page of the Licence Server Control Panel for that
licence.
34
Checking out licences
Checking out a licence
Before they can check out a licence from the Licence Server, your students should install Sibelius
(version 6.1.5 or later) or Sibelius Student (version 6.1.5 or later) on their laptops in the usual way.
To make this easy for them, you could copy the installer to a suitable shared location on your
school network, and provide a text file alongside the installer that contains the serial number for
that copy of Sibelius or Sibelius Student, together with the host name or IP address of the computer
on which the Sibelius Licence Server is running.
Once the student has Sibelius or Sibelius Student installed on his or her computer, he or she should
connect to the school network and run the program as normal. After entering the serial number
and Licence Server address, the software will run connected to the Licence Server, using one of the
available floating licences.
To check out a licence, the student chooses
Help Check Out Licence from within Sibelius or
Sibelius Student. If the Licence Server is not configured to allow check out licences, the student
will receive a message to that effect. If the Licence Server is configured to allow check out licences,
however, the student will see the following dialog:
The student can choose when the check out licence will expire, up to the maximum duration
specified by the Licence Server. When he or she clicks
OK, Sibelius disconnects from the Licence
Server, and the student can then disconnect from the school network. For the duration of the
check out period, the student can run Sibelius on his or her computer without reconnecting to the
school network. In the last few days before the check out licence is due to expire, the student will
be warned each time he or she starts Sibelius so that work can be planned effectively.
Once the licence has expired, the student will receive a message when he or she starts Sibelius
informing him or her that the program cannot run unless it is reconnected to the Licence Server.
Checking in a licence
If a student wants to check a licence back in before it expires, he or she must reconnect his or her
computer to the school network, run Sibelius or Sibelius Student as usual, then choose
Check In Licence
. Sibelius then tries to contact the Licence Server and return the licence to the
pool of floating licences, at which point Sibelius will once again only run on that computer when
connected to the school network.
Help
If for any reason Sibelius or Sibelius Student cannot contact the Licence Server, the student will
receive a message to that effect, and should try again later.
35
Sibelius Licence Server User Guide
Working with clients
The Clients page of the Licence Server Control Panel shows real-time information about the client
copies of Sibelius currently connected to the Licence Server:
Address shows the IP address from which the client is connected. It is possible for multiple
clients to appear to connect from the same IP address if your Licence Server is located on the
opposite side of a firewall or router from your client machines, or in other situations where your
network uses Network Address Translation (NAT).
Client ID is a numeric identifier given to each client machine when it first connects to the
Licence Server. This identifier remains associated to that client machine as long as it is
connected to the server for that session, and when the client disconnects and reconnects (e.g.
because a student quits and restarts Sibelius), it will be assigned a new identifier. Similarly, when
the Licence Server is restarted, the client IDs are simply reassigned from 1 again. (Client IDs are
used by the Licence Server to ensure that it can tell each client apart, especially when your
network employs NAT.)
User name shows the username of the account currently logged in to that particular computer.
Machine name shows the host name of the client computer.
Time connected shows how long each client has been connected for, in hours, minutes and
seconds.
Last polled shows when the Licence Server last polled the client and received a reply. Typically,
clients will be polled every few seconds, and only when you suffer a network outage of some
kind (or when the client computer crashes) will the client not be able to respond to the Licence
Server’s poll message.
Licence expires shows the date on which the client’s checked out licence expires in the form
dd/mm/yyyy, or shows
N/A if the licence is a standard floating licence.
36
Working with clients
In addition to seeing real-time information about the clients currently connected, you can perform
some simple operations on the client machines, namely sending a message to one or more clients,
closing one or more clients, or revoking a checked out licence.
Sending messages to clients
If you need to send a message to one or more clients, e.g. to inform them that the lesson ends in a
few minutes, or that the computer lab will be closing shortly, you can select the client (by clicking)
or clients (by
then click
Shift-clicking or using Ctrl+click or -click) from the list at the top of the dialog,
Send Message. A simple dialog appears:
Type y our me ssage and cli ck
OK. Your message will appear within a few moments on the screens
of each of the clients to whom you chose to send it.
Closing clients
To close one or more client, select the client (by clicking) or clients (by
Ctrl+click or -click) from the list at the top of the dialog, then click Close Selected Clients.
Shift-clicking or using
Within a few moments, each of the client machines will prompt the student to save their work, and
then shut down.
Revoking licences
If a client has a checked out licence, and you urgently need to restore that licence to the network
pool so that it can be allocated to another client, select the client and click
Revoke Licence. You
can only revoke licences a limited number of times, so use this capability sparingly. For more
information, see
Checking out licences on page 33.
37
Sibelius Licence Server User Guide
Reading logs
The Logs page of the Licence Server Control Panel shows the log messages generated by the
Licence Server:
Time shows the timestamp at which a given event occurred.
Client Address either shows the IP address of the client machine, or if it is an informational
message generated by the Licence Server itself, this will read
Message shows the text of the message itself. Some of the common messages you will see:
Adding client id: n (x of y): when a client first connects to the Licence Server, it is assigned
(Status).
client ID n, and you are informed that this is copy number x of the number of concurrent copies allowed, y.
Client add request version: this means that a client has asked the Licence Server for
authorization.
Client alive: this means that a client has been successfully authorized.
Poll response from client id n: this is the response of the client to the Licence Server’s poll
request.
Poll count -1 for id n: this means that client ID n has stopped responding to the Licence
Server’s poll requests.
Removed client from list: this means that a client has closed.
The buttons at the bottom of the page allow you to perform various operations on the log:
Save As: if you encounter problems with the Licence Server, it is very useful to send your log
file to Sibelius technical support. Simply click
Save As to save a text file suitable for attaching to
an email.
38
Reading logs
Clear will empty the log. Note that this not only clears the display in the Licence Server Control
Panel: it deletes the existing log altogether. (The log is also deleted each time you start the
Licence Server.)
Refresh forces the display of the log file to be updated. The display is automatically updated
every few seconds, but if you want to force an update, you can do so.
Mark inserts a marker line in the log file, which can be useful when trying to diagnose what the
Licence Server is doing while it’s running.
Status inserts a status report message into the log, including important bits of configuration
information (including the Licence Server’s serial number, IP address and port, number of
registered copies, client and manager access control lists, and so on) that can help Sibelius
technical support to diagnose any problems you may encounter.
Comment shows a simple dialog into which you can type a comment to be inserted in the log
file. You can use this to annotate a sequence of events in the log; again, this can be very useful in
helping Sibelius technical support to diagnose problems.
Log verbosity
You can control how detailed the Licence Server logs are by adjusting the slider on the
Options
page of the Licence Server Control Panel:
Server
While you are configuring and testing your Licence Server, you may find it helpful to drag the
slider to the right to increase the verbosity. Once your Licence Server is running smoothly, you can
safely drag the slider back to the left in order to make the logs more concise.
39
Sibelius Licence Server User Guide
Maintaining the Licence Server
There are a handful of other maintenance tasks that can be performed from the Licence Server
Control Panel, described below.
Changing the port used by the Licence Server
The Licence Server’s default port is
recommend that you leave this setting at its default.
7312. There is normally no need to change this, and we
If, however, you need to change the port, click
Licence Server Control Panel. The following dialog appears:
As the message in the dialog makes clear, changing the port after you have already set up your
Licence Server can be very inconvenient, because you need to reconfigure each client machine to
use the new port afterwards.
Changing the number of copies in an existing site licence
If you decide to increase the number of copies in your Sibelius network site licence by purchasing
additional seats for one of your existing serial numbers, you will need to unregister your Licence
Server and obtain a new Registration Number from Sibelius registration.
To unregister your Licence Server, select the appropriate serial number in the table on the
Licences page, then click Unregister. You will be asked if you are sure you want to unregister the
Licence Server: if you click
be able to authorize any client copies of Sibelius or Sibelius Student.
Yes, that serial number will become unregistered, and it will no longer
Change Port on the Server Options page of the
To re-register your Licence Server with a larger number of copies, follow the procedure described
in
Registering the Licence Server on page 23.
Unexpected exits
In the unlikely event that a copy of Sibelius running on a client machine exits unexpectedly (e.g. if
it crashes), or if the computer on which Sibelius is running crashes or requires a reboot, when the
student runs Sibelius again, the Licence Server will attempt to identify that the same client is
reconnecting, and re-authorize it immediately. If, however, the Licence Server is unable to
recognize the client, the student may see the error message
server already has a copy registered on this address
for the designated time-out period, and he or she will then be able to successfully restart Sibelius.
40
Sibelius cannot run because the
. In this situation, the student can wait
Maintaining the Licence Server
By default, the time-out period is three minutes, but you can change this on the
Server Options
page of the Licence Server Control Panel:
Simply drag the slider to the right to increase the time-out period, or to the left to reduce it.
41
Sibelius Licence Server User Guide
Troubleshooting
Error codes
For a complete list of the error codes that can be returned by the Licence Server, see
Licence Server error codes
on page 50.
Error 0005 Access Denied
If the Licence Server service in Windows fails to start automatically, you may get an
Access Denied
when you try to start it manually. This usually means that the folder in which the
Licence Server is installed has restricted access.
Licence Server is apparently installed correctly but the clients cannot “see” the Licence Server
Open a command window (Windows) or Terminal window (Mac) and use ping to contact the
server from the client and vice versa to establish basic connectivity. If
ping is successful in both
directions, network traffic is able to be routed between the two machines. If
possible that another device on the network (e.g. a programmable switch) is blocking the traffic
between the Licence Server and the client. Check the logs to see if you are getting an “extra slave
alive” message.
Review your access settings using the Access Control page of the Licence Server Control Panel
– see
Access Control on page 30.
This can also be caused by your firewall. Try this trick: if you are running the Control Panel on
the same machine as the Licence Server, add the server’s IP address to the list of allowed
managers, then connect to the server by IP address (or use the
Find button). If you are unable to
connect or test the server in this way, it suggests that the firewall on your local machine is not
allowing connections through on the Licence Server’s port. If you are able to test the server but
other clients still can’t connect, then check the settings of any other firewalls or routers on your
network.
Appendix C:
Error 0005
ping fails, it’s
Error message ‘Could not bind the IP socket to the correct port’
If you see the error message
Could not bind the IP socket to the correct port when running
the Licence Server, you may be running another application on this port already. You may even be
running the Licence Server already: perhaps you are running an earlier version of the Sibelius
Licence Server at the same time as the Sibelius 7 Licence Server, or perhaps the Licence Server has
crashed and the crashed process needs to be killed before it can be restarted.
If you legitimately have another application using the same port, you can solve this problem
changing the Licence Server’s port (see
Changing the port used by the Licence Server on
page 40).
Client copies of Sibelius on Mac lose contact with the Licence Server
Make sure that your server is not allowed to go to “sleep” as this will stop the Licence Server from
responding. You should also ensure that your server does not install software updates
automatically, as this will also stop the Licence Server from responding.
42
Troubleshooting
Licence Server fails to test successfully
Did you forget to include the localhost, 127.0.0.1 in your clients allowed access control list?
Using the log to troubleshoot
The log can be very informative when investigating a client that fails to be authorized.
For example, you will see Bad serial number in the log if a client attempts to connect using a
different serial number than the one in use by the Licence Server.
You will see
connect to the Licence Server, e.g. you will see
Bad version number if a copy of an older or newer version of Sibelius attempts to
Bad version number 6 if a copy of Sibelius
6attempts to connect to the Sibelius 7 Licence Server.
You will see
Blocked client, no copies left if a new client attempts to connect to the Licence
Server, but the Licence Server has already authorized the number of copies in your licence.
43
Sibelius Licence Server User Guide
44
Appendices
Sibelius Licence Server User Guide
46
Appendix A: Starting or stopping the Licence Server
Appendix A:
Starting or stopping the Licence Server
Normally you should use the Licence Server Control Panel to start and stop the Licence Server. But
should you need to start or stop the Licence Server without using the Control Panel, you can do so
as follows:
Starting the Licence Server on Windows
First, open a command prompt window: click Start, type cmd and hit Return.
This opens a command shell window:
Navigate to the folder where you installed the Licence Server using cd:
cd \Program Files\Avid\Sibelius 7 Licence Server
Make sure you type the line above exactly, with spaces in all the right places. You will be
returned to the command prompt in the above directory. (On 64-bit Windows, substitute
Program Files (x86) for Program Files.)
Now, to install the service, type:
LicenceServerV7 -install
You will see the following response from the Licence Server:
You will again be returned to a command prompt.
47
Sibelius Licence Server User Guide
Stopping the Licence Server on Windows
First, open a command prompt window: click Start, type cmd and hit Return.
This opens a command shell window. Navigate to the folder where you installed the Licence
Server using
cd \Program Files\Avid\Sibelius 7 Licence Server
cd:
Make sure you type the line above exactly, with spaces in all the right places. You will be
returned to the command prompt in the above directory.
Now, to install the service, type:
LicenceServerV7 -uninstall
You will again be returned to a command prompt.
Starting the Licence Server on Mac OS X
Open a Terminal window and log in as root by typing:
sudo bash -login
Type the root password when prompted, and hit Return.
Now type the following command:
/sbin/SystemStarter -v start "Sibelius 7 Licence Server Service"
Stopping the Licence Server on Mac OS X
Open a Terminal window and log in as root by typing:
sudo bash -login
Type the root password when prompted, and hit Return.
Now type the following command:
/sbin/SystemStarter -v stop "Sibelius 7 Licence Server Service"
48
Appendix B: Manually locating Licence Server logs
Appendix B:
Manually locating Licence Server logs
Normally you should view the Licence Server’s logs using the Licence Server Control Panel, but
should you need to do this manually, do so as follows.
Logging on Windows
The Licence Server creates a log file called
C:\Users\LocalService\AppData\Roaming\Avid\Logs
The exact location depends on your computer’s settings, so it may be necessary to search for the
folder. The logs are updated with every event.
Logging on Mac OS X
The Licence Server creates a log file in /var/log called LicenceServer.log (unless you have
changed its name and location in the
the log, open a Terminal window and navigate to the
specified for the log file. Assuming you are using the default filename, type:
tail -f LicenceServer.log
To qu it the tail command, type Control-C. To view the whole log, use the less command:
LicenceServerV7.log
start_licence_server script). To see the last few entries in
, normally located in:
/var/log folder or the folder you have
less LicenceServer.log
Quit the less command by typing q.
49
Sibelius Licence Server User Guide
Appendix C: Licence Server error codes
Error code Internal error message Explanation
301 ERR_LS_CANT_CONNECT_TO_SERVER The service is not yet running
302 ERR_LS_AUTH_NO_MORE_COPIES No more licences left on server
303 ERR_LS_AUTH_ALREADY_RUNNING_THI
S_IP
304 ERR_LS_AUTH_DENIED Can’t authoize this client
305 ERR_LS_SHUTDOWN Server has requested that we shut down
306 ERR_LS_INCORRECT_SIB_VERSION Licence Server is for a different version of
307 ERR_LS_OLD_LS_VERSION Using the wrong version of the Licence Server
308 ERR_LS_CLIENT_COMM_ERROR Can’t communicate with client
309 ERR_LS_INVALID_SERIAL Invalid serial number
310 ERR_LS_NO_ACCESS No access control has been set up
311 ERR_LS_SOCKET_FAIL Can’t create or bind network sockets
312 ERR_LS_SERVICE_CANT_FIND_MODULE Can’t find LicenceServerV7 executable to
313 ERR_LS_SERVICE_CANT_OPEN_SERVICE
MAN
314 ERR_LS_SERVICE_CANT_CREATE_SERVICECan’t create the service (Windows only)
A version is already running at this address
Sibelius.
install as a service (Windows only)
Can’t open the service manager (Windows
only)
315 ERR_LS_SERVICE_CANT_START Error starting the service (Windows only)
316 ERR_LS_SERVICE_CANT_OPEN Error opening the service (Windows only)
317 ERR_LS_GENERAL_ERROR General error from the Licence Server
50
Appendix D: Useful command line commands
Appendix D:
Useful command line commands
Useful Mac OS X Terminal commands
chmod – used to change the attributes of a file
ls -al – lists all the files in a directory with their attributes
ps -a – lists running processes, which will include the Licence Server
ps -ax – lists all running processes, including hidden ones.
mkdir -m 775 name makes a directory called name with full read/write access for the owner
and their group (typically the admin group), but prevents write access for other users.
tail -f logfilename will display the last 10 lines of the log file logfilename continually; useful for
monitoring client messages.
less logfilename will display the whole log file logfilename from beginning to end; quit by
typing
q.
cd changes the current directory
pico starts the Pico text editor (if installed)
logout will log out from the current user, e.g. root. (You can also type Control-D.)
./filename will run an executable or script called filename in the current directory, provided you
are using bash or a bash-compatible shell (as suggested earlier). Once unique characters have
been typed, the
To quit a running command, type Control-C.
Tab key will auto-complete the rest of the file name for you.
Useful Windows/DOS commands
cd – change directory (the old name for folder).
cd .. – moves to the next higher directory. If you repeat this enough times, you will get back to
the root of the hard disk.
cd \ – moves you to the root directory.
cd \directoryname – takes you to the directory called directoryname. If you copied the Licence
Server program to a folder named
dir – lists the contents of a directory. Use this to check that you are in the right directory.
exit – closes a command prompt window.
To quit a running command, type Ctrl+C.
LSV6 (for example) then cd \LSV6 will get you there.
51
Loading...
