Welcome to the Interactive Projects Guide

Welcome to the Interactive Projects Guide from
®
Avid
. This guide gives you 10 workflows based on the Interactive Projects video tutorials pro­vided with Avid Pro Tools
We recommend you watch the videos first to learn about basic recording and mixing. Then if needed, you can use the workflows in this guide to accomplish basic recording and mixing on your own.
Like the video tutorials, each workflow is in 10 easy steps that let you follow along at your own pace.
The video tutorials can be accessed in Pro Tools SE (choose “Tutorials” from the Quick Start dialog). They’re also available online at: http://www.m-audio.com/ptseFAQ
®
SE.
To use Pro Tools SE, a qualified version of Adobe Flash Player must be installed.
Welcome to the Interactive Projects Guide 1

IP 1: Using Software Instruments

Let’s try out some of the high-quality software instruments included with Pro Tools SE.
Features Used:
• Quick Start dialog
• Instrument Track Recording and Editing
• MIDI keyboard or Pencil tool
Project Workflow
Connect a MIDI keyboard:
1 Make sure your MIDI keyboard is connected
directly to your computer with a USB cable, then launch Pro Tools.
Create the session:
2 From the Quick Start dialog, choose “Key-
boards.”
Create some software sounds:
3 If you don’t have a MIDI keyboard, you can
also draw notes in the MIDI Editor. To create notes in this way, click Window > MIDI Editor and then choose the Pencil tool in the MIDI Editor.
Record yourself playing:
6 Click the Track Record Enable button on the In-
strument track so it is ready to record. Now when you play your connected MIDI keyboard you can see the meters flickering on that track.
7 Record by using the Transport controls. Click
the Record Enable circle so that it flashes red, then click the Play triangle. When you are fin­ished playing, click the Stop square.
8 On the Instrument track, you see MIDI data
for the performance you just recorded. Click the Track Record Enable button on the track again to take Pro Tools out of record mode.
Edit the performance:
9 Clean up the durations of our MIDI notes by
adjusting the start and end with the “Trimmer” tool. This is automatically chosen when you move the mouse near to either end.
10 Click on a MIDI note and drag it up or down
to change its pitch or hit Delete on the keyboard to remove it.
4 Click one of the Instrument tracks and play
your MIDI keyboard to hear that track's software instrument. You hear the sound from whichever track is highlighted.
5 Choose different instruments by clicking on
the Instrument track’s drop-down and selecting from its list.
Interactive Projects Guide2

IP 2: Recording a Vocal

Let’s record a sung vocal track with Pro Tools SE.
Features used:
• Quick Start dialog
• Audio Track Recording and Editing
• Compressor and Reverb effects
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Vocals.”
Record the singing:
2 Click the Track Record Enable button on the
“Voice 1” track so it is ready to record. Now when you sing into the microphone that’s con­nected you can see the meter flickering on that track.
3 You record by using the Transport controls.
Click the Record Enable circle so that it flashes red, then click the Play triangle. When you fin­ish singing, click the Stop square.
Adjust the effects:
8 Click one of the Effects to access its controls.
While the audio plays back, move the Less/More Reverb control to hear how it changes the sound.
9 Click Compressor and move the controls to
smooth the track’s dynamics.
10 Try out different effect presets by clicking on
the Compressor’s settings drop-down and select­ing from its list.
4 On the “Voice 1” track, you see a waveform for
the sound we just recorded. Click the Track Re­cord Enable button on the track again to take
Pro Tools out of record mode.
Edit the performance:
5 You can listen back to your performance by
using the Transport controls. Click Return to Zero and then click the Play triangle.
6 Clean up the voice recording by using the
“Standard Trimmer” tool to trim the end and be­ginning.
7 Use the “Selector” tool to select any unwanted
sounds, then hit Delete on the keyboard to re­move them.
Welcome to the Interactive Projects Guide 3

IP 3: Creating a Podcast

Let’s create a 30-second podcast with one spo­ken voice track and loops with Pro Tools SE.
Features used:
• Quick Start dialog
• Audio Track Recording and Editing
• Loops
7 Use the “Selector” tool to select any unwanted
sounds, then hit Delete on the keyboard to re­move them.
Add a background music track using Loops:
8 Now preview a couple of Loops (select the
“Loop” button to open the Loop dialog in the Toolbar) to find one for a background “Music” track. Drag it on to the existing Music track and loop it to make it longer.
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Pod-
cast.”
Record the spoken voice:
2 Click the Track Record Enable button on the
“Voice 1” track so it is ready to record. Now when you speak into the microphone that’s con­nected you can see the meter flickering on that track.
3 You record by using the Transport controls.
Click the Record Enable circle so that it flashes red, then click the Play triangle. When you fin­ish speaking, click the Stop square.
4 On the “Voice 1” track, you see a waveform for
the sound you just recorded. Click the Track Re­cord Enable button on the track again to take
Pro Tools out of record mode.
Edit the performance:
5 You can listen back to your performance by
using the Transport controls. Click Return to Zero and then click the Play triangle.
9 Click with the “Grabber” tool to move your
voice region until after the music starts.
10 Click File > Export > Audio to create the final
podcast by exporting it.
6 Clean up the voice recording by using the
Standard Trimmer tool to trim the end and be­ginning.
Interactive Projects Guide4

IP 4: Recording Electric Guitar

Let’s try out some of the high-quality Guitar Amp sounds that are included with Pro Tools SE.
Features used:
• Quick Start dialog
• Audio Track Recording and Editing
• Guitar Amp and Reverb effects
7 Use the “Selector” tool to select any mistakes,
then hit Delete on the keyboard to remove them.
Adjust the effects:
8 Click one of the Effects to access its controls.
While the audio plays back, move the Less/More Reverb control to hear how it changes the sound.
9 Click “Guitar Amp” and move the controls in
a similar way to that on a real guitar amp.
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Guitar.”
Record the guitar:
2 Click the Track Record Enable button on the
“Clean Electric” track so it is ready to record. Now when you play the guitar that’s connected you can see the meter flickering on that track.
3 You record by using the Transport controls.
Click the Record Enable circle so that it flashes red, then click the Play triangle. When you fin­ish playing, click the Stop square.
4 On the “Clean Electric” track, you see a wave-
form for the sound you just recorded. Click the Track Record Enable button on the track again to take Pro Tools out of record mode.
Edit the performance:
5 You can listen back to your performance by
using the Transport controls. Click Return to Zero and then click the Play triangle.
10 Try out different effect presets by clicking on
the Guitar Amp’s settings drop-down and select­ing from its list.
6 Clean up the guitar recording by using the
Standard Trimmer tool to trim the end and be­ginning.
Welcome to the Interactive Projects Guide 5

IP 5: Creating a Movie Soundtrack

Let’s add some music to a Movie with Pro Tools SE.
Features used:
• Quick Start dialog
• Editing Movies
• Using Loops
• Controlling the Master volume
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Movie
Soundtrack.”
Edit the Movie:
2 Replace the current movie by importing a dif-
ferent one. Click File > Import > Movie and choose the video file you want to use.
8 Repeat a loop by using the Standard Trimmer
tool. Click in the upper half of the drum loop and the bass loop and drag to the right to make both of them repeat several times.
Control the Master volume:
9 Make the audio fade in and out by using the
Pencil tool to create volume automation. Click on the Master track to draw in the fades.
Finish the Movie:
10 Click File > Export > Movie to create the final
movie by exporting it.
3 Shorten your movie by using the “Standard
Trimmer” tool to trim the end.
Choose some Loops:
4 Make sure the Loops dialog is visible. To hide
or show the Loops dialog click the Loops button in the Toolbar.
5 Preview a loop by clicking on it and drag it
into your session. Choose a drum loop, bass loop and a sound effect loop.
6 Arrange loops with the Grabber tool. Move
your loops so the drums start before the bass.
7 Trim a loop by using the Standard Trimmer
tool. Click in the lower half of the sound effect loop and drag to the left to shorten it.
Interactive Projects Guide6

IP 6: Making a Mix

Let’s combine multiple sounds into one mix with Pro Tools SE.
Features used:
• Quick Start dialog
• Fader and Pan Automation
• Effects Automation
• Mute Automation and Solo
Project Workflow
Control the effects:
7 Make the effects’ controls change over time.
Click the Automation Lane View selector and choose one of the effects’ controls. Use the Pencil tool again to have that control change automatically.
Control the stereo field:
8 Make the sound move from left to right and
back again over time. Click the Automation Lane View selector and choose Pan. Use the Pen­cil tool again to have that control change auto­matically.
Create the session:
1 From the Quick Start dialog, choose a Demo
Song.
Control the faders:
2 Listen back to your session by using the Trans-
port controls. Click Return to Zero and then click the Play triangle.
3 Click the “Solo” button on a track to hear that
track on its own. Click it again to hear all the tracks together.
4 Click the “Mute” button on a track to silence
that track so that you can hear how the session sounds without it. Click it again to hear all the tracks together.
5 Make the tracks’ volumes change over time by
using the Pencil tool to create volume automa­tion. Click on the Show/Hide automation lane triangle on a track and draw in a few volume changes.
6 Mute and unmute tracks over time. Click the
Automation Lane View selector and choose Mute. Use the Pencil tool again to mute/unmute auto­matically where you draw with the Pencil tool.
9 Listen back to your session by using the Trans-
port controls. Click Return to Zero and then click the Play triangle.
Finish the mix:
10 Click File > Export > Audio to create the final
mix by exporting it.
Welcome to the Interactive Projects Guide 7

IP 7: Exploring Effects

Let’s hear how effects can transform your sounds with Pro Tools SE.
Features used:
• Quick Start dialog
• Using Loops
• Using Effects
•Solo
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Loops.”
Choose some Loops:
2 Make sure the Loops dialog is visible. To hide
or show the Loops dialog click the Loops button in the Toolbar.
3 Preview a loop by clicking on it and drag it
into the session. Choose a few that will sound good together. You can sort Loops by key and by other ways.
7 Click the Solo button on a track to hear that
track on its own and click it again to hear all the tracks together.
8 Click one of the effect’s drop-downs to choose
an effect. While the audio plays back, choose different effects to hear how they change the sound.
9 Try out different effect presets by clicking on
the effect’s settings drop-down and selecting from its list.
10 Use the Effect On/Off button to hear how the
audio sounds with or without each effect.
4 Arrange loops with the Grabber tool. Move
your loops so they start at different positions. You can make your loops align with the Grid by enabling Snap to Grid.
5 Repeat a loop by using the Standard Trimmer
tool. Click in the upper half of some of the loops and drag to the right to make them repeat sev­eral times.
Adjust the effects:
6 Listen back to your session by using the Trans-
port controls. Click Return to Zero and then click the Play triangle.
Interactive Projects Guide8

IP 8: Recording an Acoustic Instrument

7 Use the Selector tool to select any unwanted
sounds, then hit Delete on the keyboard to re­move them.
Let’s record an instrument using a microphone with Pro Tools SE.
Features used:
• Quick Start dialog
• Audio Track Recording and Editing
• Gate, Compressor and Equalizer effects
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Acoustic
Instrument.”
Record the instrument:
2 Click the Track Record Enable button on the
“Acoustic 1” track so it is ready to record. When you play your acoustic instrument into the mi­crophone that’s connected you can see the me­ter flickering on that track.
3 Start to record by clicking the Record Enable
circle so that it flashes red, and then the Play tri­angle. When you finish playing, click the Stop square.
Adjust the effects:
8 Click one of the effects to access its controls.
While your audio plays back, move the Gate’s Threshold control to silence signals that fall be­low the level you set.
9 Now click “Compressor” and move the con-
trols to smooth your track’s dynamics.
10 Try out different presets by clicking on the
Equalizer’s settings drop-down menu and select­ing from its list.
4 On the Acoustic 1 track, you can see a wave-
form for the sound you just recorded. Click the Track Record Enable button on the track again to take Pro Tools out of record mode.
Edit the performance:
5 Listen back to your performance by using the
Transport controls. Click Return to Zero and then click the Play triangle.
6 Clean up your recording by using the Stan-
dard Trimmer tool to trim the end and begin­ning.
Welcome to the Interactive Projects Guide 9

IP 9: Using Loops

Let’s try out some of the high-quality sound samples that are included with Pro Tools SE.
Features used:
• Quick Start dialog
• Using Loops
• Using Effects
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Loops.”
Choose some Loops:
2 Make sure the Loops dialog is visible. To hide
or show the Loops dialog click the Loops button in the Toolbar.
3 Preview a loop by clicking on it and drag it
into the session. Choose a few that will sound good together. You can sort Loops by key and by other ways.
8 Click one of the effect’s drop-downs to choose
an effect from its list. While the audio plays back, choose different effects to hear how they change the sound.
9 Try out different effect presets by clicking on
the effect’s settings drop-down and selecting from its list.
10 Use the Effect On/Off button to quickly hear
how the audio sounds with or without each ef­fect.
4 Arrange loops with the Grabber tool. Move
your loops so they start at different positions. You can make your loops align with the Grid by enabling Snap to Grid.
5 Repeat a loop by using the Standard Trimmer
tool. Click in the upper half of some of the loops and drag to the right to make them repeat sev­eral times.
Adjust the effects:
6 Listen back to your session by using the Trans-
port controls. Click Return to Zero and then click the Play triangle.
7 Click the Solo button on a track to hear that
track on its own and click it again to hear all the tracks together.
Interactive Projects Guide10

IP 10: Starting from Scratch

Let’s build a customized session with Pro Tools SE.
Features used:
• Quick Start dialog
•Creating Tracks
• Instrument Track Recording
• Audio Track Recording
Project Workflow
Create the session:
1 From the Quick Start dialog, choose “Empty
Session.”
2 Create a rhythmic backing track using a loop.
Make sure the Loops dialog is visible. To hide or show the Loops dialog click the Loops button in the Toolbar.
3 Preview a loop by clicking on it, then drag it
into the session (choose one with a strong rhythm).
7 You can also draw notes in the MIDI Editor. To
create notes, click Window > MIDI Editor, then choose the Pencil tool in the MIDI Editor.
8 Create more tracks if you need them.
Click Track > New and choose either an Instru­ment or an Audio track.
9 Try out different effect presets by clicking on
the effect’s settings drop-down and selecting from its list.
10 Listen to your session by using the Transport
controls. Click Return to Zero and then click the Play triangle.
Record some audio:
4 Click the Track Record Enable button on the
“Audio” track so it is ready to record. Now when an audio signal is detected, you can see the me­ter flickering on that track.
5 Start to record by clicking the Record Enable
circle so it flashes red, and then click the Play tri- angle. When you finish playing click the Stop square.
Create some software sounds:
6 With Instrument tracks, make sure your MIDI
keyboard is connected directly to your com­puter with a USB cable so you can play (trigger) the sounds with your keyboard.
Welcome to the Interactive Projects Guide 11
Avid
2001 Junipero Serra Boulevard Daly City, CA 94014-3886 USA
Technical Support (USA)
Visit the Online Support Center at www.avid.com/support
Product Information
For company and product information, visit us on the web at www.avid.com
Loading...
