Part No. 302702-B Rev 00
January 2000
4401 Great America Parkway
Santa Clara, CA 95054
E1/FE1 Adapter Module
Supplement
Copyright © 2000 Nortel Networks
All rights reserved. Printed in the USA. January 2000.
The information in this document is subject to change without notice. The statements, configurations, technical data,
and recommendations in this document are believed to be accurate and reliable, but are presented without express or
implied warranty. Users must take full respo nsib ility fo r th e ir app lica tio ns o f a ny products specified in this d ocume nt .
Trademarks
NORTEL NETWORKS is a trademark of Nortel Networks.
Bay Networks, ACE, AFN, AN, BCN, BLN, BN, BNX, CN, FRE, LN, Optivity, Optivity Policy Services, and PPX
are regi ster ed t rade mark s an d Advanced Remo te N ode, ANH, ARN, ASN , BayR S, B aySec ure, Bay Stac k, B aySt ream ,
BCC, BCNX, BLNX, Centillion, EtherSpeed, FN, IP AutoLearn, Passport, SN, SPEX, Switch Node, System 5000,
and TokenSpeed are trademarks of Nortel Networks.
Microsoft, MS, MS-DOS, Win32, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
All other trademarks and registered trademarks are t he property of their respective owners.
Statement of Conditions
In the interest of improvi ng internal design, operational function, and/o r relia bi lity, Nortel Network s NA Inc. reserves
the right to make changes to the products described in this document without notice.
Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s)
or circuit layout(s) described her ein.
USA Requirements Only
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC rules. These l im its are designed to provide reasonable protection again st harmful interference
when the equipment is operated in a commercial environment. This equipment ge nerates, uses, and can radiate radio
frequency energy. If it is not installed and used in accordance with the instruction manual, it may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case users will be required to take whatever measures may be necessary to correct the
interference at their own expense.
European Requirements Only
EN 55 022 Statement
This is to certify that the Nortel Networks E1/FE1 Adapter Module is shielded against the generation of radio
interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared
by the application of EN 55 022 Class A (CISPR 22).
Warning: This is a Class A product. In a domestic env iron m ent, this product may cause radio interference, in which
case, the user may be required to take appropriate measures.
Achtung: Dieses ist ein Gerät der Funkst örgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes
Rundfunkstörungen auftreten, in welchen Fällen der Benutzer für entsprechende Gegenmaßnahmen verantwortlich
ist.
Attention: Ceci est un produit de Classe A. Dans un environnement domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l’utilisateur de prendre les mesures spécifiques appropriées.
ii
302702-B Rev 00
Japan/Nippon Requirements Only
Voluntary Control Council for Interference (VCCI) Statement
Taiwan Requirements
Bureau of Standards, Metrology and Inspection (BSMI) Statement
Canada Requirements Only
Canadian Department of Communications Radio Interference Regulations
This digital apparatus (E1/FE1 Adapter Module) does not exceed the Class A limits for radio-nois e emi ssions from
digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
Règlement sur le brouillage radioélectrique du ministère des Communications
Cet appareil numérique (E1/FE1 Adapter Module) respecte les limites de bruits radioélectriques visant les appareils
numériques de classe A prescrites dans le Règlement sur le brouillage rad ioélectrique du ministère des
Communications du Canada.
Nortel Networks NA Inc. Software License Agreement
NOTICE: Please carefully read this license agre ement before copying or using the accompanying software or
installing the hardware unit with pre-enabled software (each of which is referred to as “Software” in this Agreement).
BY COPYING OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE TERMS AND CONDITIONS OF
THIS LICENSE AGREEMENT. THE TERMS EXPRESSED IN THIS AGREEMENT ARE THE ONLY TERMS
UNDER WHICH NORTEL NETWORKS WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept
these terms and conditions, return the product, unused and in the original shipping container, within 30 days of
purchase to obtain a credit for the full purchase price.
1. License Grant. Nortel Networks NA Inc. (“Nortel Networks”) grants the end user of the Software (“Licensee”) a
personal, nonex clusive, nontransferable license : a) to us e the So ftw are eit her on a single c omputer o r, if applicable, on
a single authorized device identified by host ID, for which it was originally acquired; b) to copy the Software solely
for backup purposes in support of authorized use of the Software; and c) to use and copy the associated user manual
solely in support of authoriz ed use of th e Softwa re b y Licen see. Thi s license applies t o the So ftware o nly and d oes not
extend to Nortel Networks Agent software or other Nortel Networks software products. Nortel Networks Agent
302702-B Rev 00
iii
software or other Nortel Networks software products are licensed for use under the terms of the applicable N ortel
Networks NA Inc. Software License Agreement that accompanies such software and upon payment by the end user of
the applicable license fees for such software.
2. Restrictions on use; reservation of rights. The Software and user manuals are protected under copyright laws.
Nortel Networks and/or its licensors retain all title and ownership in both the Software and user manuals, including
any revisions made by Nortel Networks or its licensors. Th e copyright notice must be r e produced and incl uded with
any copy of any portion of the Software or user manuals. Licensee may not modify, translate, decompile, disassemble,
use for any competitive analysis, reverse engineer, distribute, or create derivative works from the Software or user
manuals or any copy , in whole or in part. Except as expressly provided in this Agreement, Licensee may not copy or
transfer the Software or user manuals, in whole or in part. The Software and user manuals embody Nortel Networks’
and its licensors’ confidential and proprietary intellectu al pro p erty. Licensee shall n ot sub lic ense, assign, or otherwise
disclose to any third party the Software, or any information about the operation, design, performance, or
implementation of the Software and user manuals that is confidential to Nortel Networks and its licensors; however,
Licensee may grant permission to its consultants, subcontractors, a nd agents to use the Softw are at Licensee’s facility,
provided they have agreed to use the Software only in accordance with the terms of this license.
3. Limited warranty . Nortel Networks warrants each item of Software, as delivered by Nortel Networks and properly
installed and operated on Nortel Networks hardware or other equipment it is originally licensed for, to function
substantially as described in its accompanying user m anual during its warranty period , which begins on the date
Software is first shipped to Licensee. If an y item of S oftware f ails to so function d uring its w arranty period, as the sole
remedy Nortel Networks will at its discretion provide a suitable fix, patch, or workaround for the problem that may be
included in a future Software release. Nortel Networks further warrants to Licensee that the media on which the
Software is provided will be free from defec ts in materials and wo rkman ship under no rmal use for a peri od of 90 da ys
from the date Software is first shipped to Licensee. Nortel Networks will replace defective media at no charge if it is
returned to Nortel Netw orks during the warranty period along with proof of the date of sh ipment. This warrant y does
not apply if the media has been damaged as a result of accident, misuse, or abuse. The Licensee assumes all
responsibility for selection of the Software to achieve Licensee’s intended results and for the installation, use, and
results obtained from the Software. Nortel Networks does not warrant a) that the functions contained in the software
will meet the Licensee’s requirements, b) that the Software will operate in the hardware or software combinations that
the Licensee may select, c) that the operation of the Software will be uninterrupted or error free, or d) that all defects
in the operation of the Softw are will be corrected . Nortel Network s is not obligate d to remedy an y Software defect that
cannot be reproduced with the latest Software release. These warranties do not apply to the Software if it has been (i)
altered, except by Nortel Networks or in accordance with i ts instructions; (ii) used in conj unction with another
vendor’s product, resulting in the de fect; or (iii) damaged by improper environment, abuse, misuse , accident, or
negligence. THE FOREGOING WARRANTIES AND LIMITATIONS ARE EXCLUSIVE REMEDIES AND ARE
IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Licensee is responsib le
for the security of its own data and information and for maintaining adequate procedures apart from the Software to
reconstruct lost or altered files, data, or programs.
4. Limitation of liability. IN NO EVENT WILL NOR TEL NETW ORKS OR ITS LICENS ORS BE LIABLE FOR
ANY COST OF SUBSTITUTE PROCUREMENT; SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES; OR ANY DAMAGES RESULTING FROM INACCURATE OR LOST DATA OR LOSS OF USE OR
PROFITS ARISING OUT OF OR IN CONNECTION WITH THE PERFORMANCE OF THE SOFTWARE, EVEN
IF NORTEL NETWORKS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT
SHALL THE LIABILITY OF NORTEL NETWORKS RELATING TO THE SOFTWARE OR THIS AGREEMENT
EXCEED THE PRICE PAID TO NORTEL NETWORKS FOR THE SOFTWARE LICENSE.
5. Government Licensees. This provision applies to a ll Softwa re and docum entation acquired d irectly or i ndirectly by
or on behalf of the United States Government. The Software and documentation are commercial products, licensed on
the open market at market prices, and were developed entirely at private expense and without th e use of any U.S.
Government funds. The license to the U.S. Government is granted only with restricted rights, and use, duplication, or
disclosure by the U.S. Government is subject to the restrictions set forth in subparagraph (c)(1) of the Commercial
Computer Software––Restricte d Rig hts cla u se o f FAR 52.227-19 and the limitations set out in this license for civilian
iv
302702-B Rev 00
agencies, and subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause of DFARS
252.227-7013, for agencies of t he Department of Defense or their successors, whichever is applicable.
6. Use of Software in the European Community. This provision applies to all Software acquired for use within the
European Community. If Licensee uses the Software within a country in the European Community, the Software
Directive enacted by the Council of European Communities Directive dated 14 May, 1991, will apply to the
examination of the Software to facilitate interoperability. Licensee agrees to notify Nortel Networks of any such
intended examination of the Software an d may procure support and assista nce from Nortel Networks.
7. Term and termination. This license is effective until terminated; howeve r, all of the restrictions with respect to
Nortel Networks’ copyright in the Software and user manuals will cease being effective at the date of expiration of the
Nortel Networks copyright; those restrictions relating to use and disclosure of Nortel Networks’ confidential
information shall continue in effect. Licensee may terminate this license at any time. The license will automatically
terminate if Licensee fails to comply with any of the terms and conditions of the license. Upon termination for any
reason, Licensee will immediat ely destroy or return to Nortel Networks the Software, user manuals, and all copies.
Nortel Networks is not liable to Licensee for damages in any form solely by reason of the termination of this license.
8. Export and Re-export. Licensee agrees not to export, directly or indirectly, the Software or related technical data
or information without first obtaining any required export licenses or other governmental approvals. Without limiting
the foregoing, Licensee, on behalf of itself and its subsidiaries and affiliates, agrees that it will not, without first
obtaining all export licenses and approvals required by the U.S. Government: (i) export, re-export, transfer, or divert
any such Software or technical data, or any direct product thereof, to any country to which such exports or re-exports
are restricte d or em b argoed under United State s e x port control laws and re gulations, or to any nation al or re sident of
such restricted or embargoed countries; or (ii) provide the Software or related technical data or information to any
military end user or for any military end use, including the design, development, or production of any chemical,
nuclear, or biological weapons.
9. General. If any provision of this Agreement is held to be invalid or unenf orceable by a court of competent
jurisdiction, the remainder of the provisions of this Agreement shall remain in full force and effect. This Agreement
will be governed by the laws of the state of California.
Should you have any questions concerning this Agreement, contact Nortel Netw orks, 4401 Great America Parkway,
P.O. Box 58185, Sant a Clara, California 95054-8185.
LICENSEE ACKNOWLEDGES THAT LICENSEE HAS READ THIS AGREEMENT, UNDERSTANDS IT, AND
AGREES TO BE BOUND BY ITS TERMS AND CONDITIONS. LICENSEE FURTHER AGREES THAT THIS
AGREEMENT IS THE ENTIRE AND EXCLUSIVE AGREEMENT BETWEEN NORTEL NETWORKS AND
LICENSEE, WHICH SUPERSEDES ALL PRIOR ORAL AND WRITTEN AGREEMENTS AND
COMMUNICATIONS BETWEEN THE PARTIES PERTAINING TO THE SUBJECT MATTER OF THIS
AGREEMENT. NO DIFFERENT OR ADDITIONAL TERMS WILL BE ENFORCEABLE AGAINST NORTEL
NETWORKS UNLESS NORTEL NETWORKS GIVES ITS EXPRESS WRITTEN CONSENT, INCLUDING AN
EXPRESS WAIVER OF THE TERMS OF THIS AGREEMENT.
302702-B Rev 00
v
Contents
Preface
Before You Begin .............................................................................................................xiii
How to Use This Supplement ..........................................................................................xiv
Text Conventions .............................................................................................................xiv
Acronyms ........................... .......................... .......................... ......................... .................xiv
Hard-Copy Technical Manuals ............................................... ...................................... .... xv
How to Get Help .............................................................................................................. xv
Chapter 1
Using the E1/FE1 WAN Adapter Module in a BayStack AN or ANH Router
Verifying AN/ANH Router Requ irem ents ........... ....... ...... ....... ...... ...... ....... ...... ....... .........1-1
Attaching Cables ............................................................................................................1-2
E1/FE1 Connections .......................................................................................................1-4
Interpreting LEDs ...........................................................................................................1-4
Completing Software Configuration ................................................................................1-6
Chapter 2
Using the E1/FE1 WAN Adapter Module in a BayStack ARN Router
Verifying ARN Router Requirements ..............................................................................2-1
Attaching Cables ............................................................................................................2-2
E1/FE1 Connections .......................................................................................................2-2
Interpreting LEDs ...........................................................................................................2-3
Completing Software Configuration ................................................................................2-4
Chapter 3
Using the E1/FE1 WAN Adapter Module in a Passport 5430 Multiservice Access Switch
WAN Adapter Module Placement Considerations ..........................................................3-1
Attaching Cables ............................................................................................................3-4
E1/FE1 Connections .......................................................................................................3-5
Interpreting LEDs ...........................................................................................................3-5
302702-B Rev. 00
vii
Completing Software Configuration ................................................................................3-6
Chapter 4
Using the E1/FE1 WAN Adapter Module in a Passport 2430 Multiservice Access Switch
Attaching Cables ............................................................................................................4-1
E1/FE1 Connections .......................................................................................................4-2
Interpreting LEDs ...........................................................................................................4-3
Completing Software Configuration ................................................................................4-4
viii
302702-B Rev. 00
Figures
Figure 1-1. E1/FE1 WAN Adapter Module Connector on an AN or 12-Port ANH ......1-2
Figure 1-2. E1/FE1 WAN Adapter Module Connector on an 8-Port ANH ..................1-3
Figure 1-3. Cable Connection for the E1/FE1 WAN Adapter Module .........................1-3
Figure 1-4. E1/FE1 WAN Adapter Module LEDs ........................................................1-5
Figure 2-1. E1/FE1 WAN Adapter Module Connector on an ARN .............................2-2
Figure 2-2. E1/FE1 WAN Adapter Module LEDs ........................................................2-3
Figure 3-1. E1/FE1 WAN Adapter Module Connector on a Passport 5430 ................3-4
Figure 3-2. E1/FE1 WAN Adapter Module LEDs ........................................................3-6
Figure 4-1. E1/FE1 WAN Adapter Module Connector on a Passport 2430 ................4-2
Figure 4-2. E1/FE1 WAN Adapter Module LEDs ........................................................4-3
302702-B Rev. 00
ix
Tables
Table 1-1. PROM Diagnostic and Boot Code for AN/ANH Routers ..........................1-1
Table 1-2. RJ-48C Connector Pinouts ......................................................................1-4
Table 1-3. E1/FE1 WAN Adapter Module LEDs ........................................................1-5
Table 2-1. PROM Diagnostic and Boot Code for ARN Routers ................................2-1
Table 2-2. RJ-48C Connector Pinouts ......................................................................2-3
Table 2-3. E1/FE1 WAN Adapter Module LEDs ........................................................2-4
Table 3-1. Example WAN Adapter Module Combinations ........................................3-3
Table 3-2. RJ-48C Connector Pinouts ......................................................................3-5
Table 3-3. E1/FE1 WAN Adapter Module LEDs ........................................................3-6
Table 4-1. RJ-48C Connector Pinouts ......................................................................4-3
Table 4-2. E1/FE1 WAN Adapter Module LEDs ........................................................4-4
302702-B Rev. 00
xi
The E1/FE1 Adapter Module provides high speed connectivity to E1 digital data
services. It operates at fractional rates up to full E1 speed, and supports both the
G.703 and G.704 standards.
Before You Begin
This guide is intended for qualified service personnel who are installing the
E1/FE1 Adapter Module in an AN/ANH, ARN, Passport 5430, or Passport 2430
for the first time or who need to install or replace any customer-replaceable unit
(CRU). A qualified service person should have appropriate technical training and
experience and be aware of the hazards involved in installing and replacing
CRUs.
Preface
302702-B Rev 00
xiii
E1/FE1 Adapter Module
Supplement
How to Use This Supplement
This WAN adapter module can be used with several different platforms. Refer to
the table belo w to f ind the chapter that cont ains the infor mation appr opriate for t he
platform you are using.
Platform Refer to
AN or ANH Chapter 1
ARN Chapter 2
Passport 5430 Chapter 3
Passport 2430 Chapter 4
Text Conventions
This guide uses the following text conventions:
Acronyms
bold text
Indicates command names and options and text that
you need to enter.
diags
Example: Enter the
command.
italic text Indicates new terms, book titl es, and variables in
command syntax descriptions.
This guide uses the following acronyms:
CRU customer-replaceable unit
ESD electrostatic discharge
FE1 fractional E1
PROM programmable read-only memory
WAN wide area network
xiv
302702-B Rev 00
Hard-Copy Technical Manuals
You can print selected technical manuals and release notes free, directly from the
Internet. Go to support.baynetworks.com/library/tpubs/. Find the product for
which you need documentation. Then locate the specific category and model or
version for your hardw are or soft ware product . Usi ng Adobe Ac robat Re ader, you
can open the manuals and releas e notes, search for the sections you ne ed, and print
them on most standard printers. You can download Acrobat Reader free from the
Adobe Systems Web site, www.adobe.com.
You can purchase selected documentation sets, CDs, and technical publications
through the collateral catalog. The catalog is located on the World Wide Web at
support.baynetworks.com/catalog.html and is divided into sections arranged
alphabetically:
• The “CD ROMs” section lists available CDs.
• The “Guides/Books” section lists books on technical topics.
• The “Technical Manuals” section lists available printed documentation sets.
How to Get Help
Preface
302702-B Rev 00
If you purchased a service contract for your Nortel Networks product from a
distributor or authorized reseller, contact the technical support staff for that
distributor or reseller for assistance.
If you purchased a Nort el Net wor ks ser vice pr ogram, c ontact one of the f ollowing
Nortel Networks Technical Solutions Centers:
Technical Solutions Center Telephone Number
Billerica, MA 800-2LANWAN (800-252-6926)
Santa Clara, CA 800-2LANWAN (800-252-6926)
Valbonne, France 33-4-92-96-69-68
Sydney, Australia 61-2-9927-8800
Tokyo, Japan 81-3-5740-1700
xv
Chapter 1
Using the E1/FE1 WAN Adapter Module in a
BayStack AN or ANH Router
This chapter supplements Installing a WAN Adapter Module in a BayStack AN or
ANH Router. Follow the hardware installation steps in that manual, then refer to
this document for information specific to the E1/FE1 WAN adapter module.
Warning:
AN, ANH, ARN BayStack routers and the Passport 5430 and Passport 2430.
Attempting to use the E1/FE1 WAN adapter module in any other product may
be hazardous and invalidates the regulatory approval.
The E1/FE1 WAN adapter module is designed to operate only in
Verifying AN/ANH Router Requirements
Table 1-1 shows the version and location of programmable read-only memory
(PROM) boot and diagnostic code required for the E1/FE1 WAN adapter module.
Table 1-1. PROM Diagnostic and Boot Code for AN/ANH Routers
Code Type Version Directory File Name
Boot 9.00c
Diagnostic 7.32
For information about upgrading PROM code, see the BayRS™ Upgrading
Routers guide.
an_proms anboot.exe
an_proms andiag.exe
302702-B Rev 00
1-1
E1/FE1 Adapter Module
Supplement
Attaching Cables
Connect the communications cable to the RJ-48C connector on the installed
adapter module.
You install the E1/FE1 adapter module in an open adapter module slot on the
router as follows:
• AN or 12-port ANH -- the back-panel WAN module slot 3 (Figure 1-1).
• 8-port ANH -- the back-panel COM3 slot (Figure 1-2).
See Installing a WAN Adapter Module in a BayStack AN or ANH Router for
complete installation instructions.
U
L
U
L
XCVR
UTP
E1/FE1
G.703
TX
RX
CL
Remote Alarm
Local Alarm
CONSOLE
RST
RLSD2
Loop
Sync
COM 2
COM 1
RLSD1
Figure 1-1. E1/FE1 WAN Adapter Module Connector on an AN or 12-Port ANH
100-240V
50-60 Hz
1.0-0.5A
AN0123B
1-2
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a BayStack AN or ANH Router
Loop
Sync
COM 3/Expansion
Remote Alarm
Local Alarm
E1/FE1
G.703
COM 2
COM 1
Figure 1-2. E1/FE1 WAN Adapter Module Connector on an 8-Port ANH
Connect the E1/FE1 cable to the connector on the installed adapter module
(Figure 1-3).
Note:
The E1/FE1 input port shall operate with an interconnecting cable loss
within the range of 0 to 6 decibels (dB), measured at 1024 kilohertz (kHz).
AN0124B
302702-B Rev 00
ARN front panel
1
2
E1/FE1
G.703
ARN0090B
Figure 1-3. Cable Connection for the E1/FE1 WAN Adapter Module
1-3
E1/FE1 Adapter Module
Supplement
E1/FE1 Connections
The BayStack route rs support the c onversion of data (HDLC protocol ) from a n E1
line using an optional E1/FE1 adapter module. The integrated DSU/CSU
functionality allows direct connection to the E1 network, as opposed to
connecting via an external adapter. This solution reduces equipment costs and
simplifies c onnection to an E1 carrier.
The E1/FE1 implementation supports dynamic reconfiguration, Fractional E1
loopback, and an integrated Bit Error Rate Test (BERT) line tester. Configuring
WAN Line Services describes these services and how to configure them for
connection to an E1 network.
Table 1-2 lists the E1/FE1 connector pinouts.
Table 1-2. RJ-48C Connector Pinouts
Pin Assignment Pin No. Signal
12345678
1 Receive Data TIP
2 Receive Data RING
3 Chassis Ground
4 Send Data TIP
5 Send Data RING
6 Chassis Ground
7 No Connect
8 No Connect
Interpreting LEDs
The E1/FE1 WAN adapter module has four LEDs (Figure 1-4).
1-4
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a BayStack AN or ANH Router
Local
Alarm
E1/FE1
G.703
Loop
Remote
Alarm
Sync
ARN0109A
Figure 1-4. E1/FE1 WAN Adapter Module LEDs
Table 1-3 describes the function of each E1/FE1 LED.
Table 1-3. E1/FE1 WAN Adapter Module LEDs
Label Color Meaning
Local Alarm Amber Lights when the E1 port is in a local alarm state.
Remote Alarm Amber Lights when the E1 port has re ceived a remote
alarm from the E1 network.
Loop Amber Lights when the E1 interface is placed in loopback
mode.
Sync Green Lights when the E1 port is synchronized with the
E1 network.
302702-B Rev 00
1-5
E1/FE1 Adapter Module
Supplement
Completing Software Configuration
Once you have successfully installed the adatper module, complete the following
software configuration tasks using instructions found in your BayRS
documentation:
Configuration Task Location of Instructions
Connect the AN or ANH to the network. • Installing and Operating BayStack AN
Modify the configuration file to add the E1/
FE1 module and enable default E1/FE1
software services.
Configure E1/FE1 services. One of the following:
For the latest information, be sure to review the release notes and documentation
change notice for your version of BayRS software.
and ANH Routers
One of the following:
• Configuring and Managing Routers with
Site Manager
• Using the Bay Command Console
(BCC)
• Configuring WAN Line Services
• Configuring BayStack Remote Acces
1-6
Note:
The only boot/startup methods you can use from the E1/FE1 WAN
adapter module interface are Local Boot and EZ-Install. The E1/FE1 WAN
adapter module does not support Netboot or Directed Netboot.
Note:
Adding software for the WAN adapter module may increase th e router’s
memory requirements beyond its current capacity. If the BayStack router
experiences a memory problem, see the section “Memory or Buffer Problem”
in Troubleshooting Routers. For information about changing the router image,
see Configuring and Managing Routers with Site Manager.
302702-B Rev 00
Chapter 2
Using the E1/FE1 WAN Adapter Module in a
BayStac k ARN Router
This chapter supplements Installing and Operating BayStack ARN Routers
(Chapter 4, “Installing a WAN Adapter Module.”). Follow the hardware
installation steps in tha t manual, then refer to this d ocument for in formation
specific to the E1/FE1 WAN adapter module.
Warning:
AN, ANH, and ARN BayStack routers and the Passport 5430 and Passport
2430. Attempting to use the E1/FE1 WAN adapter module in any other
product may be hazardous and invalidates the regulatory approval.
The E1/FE1 WAN adapter module is designed to operate only in
Verifying ARN Router Requirements
Table 2-1 shows the version and location of programmable read-only memory
(PROM) boot and diagnostic code required for the E1/FE1 WAN adapter module.
Table 2-1. PROM Diagnostic and Boot Code for ARN Routers
Code Type Version Directory File Name
Boot 1.20
Diagnostic 2.06
For information about upgrading PROM code, see the BayRS™ Upgrading
Routers guide.
arn_proms arnboot.exe
arn_proms arndiag.exe
302702-B Rev 00
2-1
E1/FE1 Adapter Module
Supplement
Attaching Cables
Connect the communications cable to the RJ-48C connector on the installed
adapter module.
You install the E1/FE1 adapter module in one of the two front-panel WAN adapter
module slots (Figure 2-1). See Installing and Operating BayStack ARN Routers
for complete installation instructions.
ARN front panel
1
2
Figure 2-1. E1/FE1 WAN Adapter Module Connector on an ARN
E1/FE1
G.703
Connect the E1/FE1 cable to the connector on the installed adapter module
(Figure 2-1).
Note:
The E1/FE1 input port shall operate with an interconnecting cable loss
within the range of 0 to 6 decibels (dB), measured at 1024 kilohertz (kHz).
E1/FE1 Connections
The BayStack ARN supports the conversion of data ( HDLC protocol) from an E1
line using an optional E1/FE1 adapter module. The integrated DSU/CSU
functionality allows direct connection to the E1 network, as opposed to
connecting via an external adapter. This solution reduces equipment costs and
simplifies c onnection to an E1 carrier.
ARN0090B
2-2
The E1/FE1 implementation supports dynamic reconfiguration, Fractional E1
loopback, and an integrated Bit Error Rate Test (BERT) line tester.
WAN Line Services
describes these services and how to configure them for
Configuring
connection to an E1 network.
302702-B Rev 00
Table 2-2 lists the E1/FE1 connector pinouts.
Table 2-2. RJ-48C Connector Pinouts
Pin Assignment Pin No. Signal
12345678
Interpreting LEDs
The E1/FE1 WAN adapter module has four LEDs (Figure 2-2).
Using the E1/FE1 WAN Adapter Modul e in a BayStack ARN Router
1 Receive Data TIP
2 Receive Data RING
3 Chassis Ground
4 Send Data TIP
5 Send Data RING
6 Chassis Ground
7 No Connect
8 No Connect
302702-B Rev 00
Local
E1/FE1
G.703
Alarm
Remote
Alarm
Loop
Sync
Figure 2-2. E1/FE1 WAN Adapter Module LEDs
ARN0109A
2-3
E1/FE1 Adapter Module
Supplement
Table 2-3 describes the function of each E1/FE1 LED.
Table 2-3. E1/FE1 WAN Adapter Module LEDs
Label Color Meaning
Local Alarm Amber Lights when the E1 port is in a local alarm state.
Remote Alarm Amber Lights when the E1 port has re ceived a remote
alarm from the E1 network.
Loop Amber Lights when the E1 interface is placed in loopback
mode.
Sync Green Lights when the E1 port is synchronized with the
E1 network.
Completing Software Configuration
Once you have successfully installed the adatper module, complete the following
software configuration tasks using instructions found in your BayRS
documentation.
2-4
Configuration Task Location of Instructions
Connect the ARN to the network. One of the following:
• Installing and Operating BayStack ARN
Routers
• Configuring BayStack Remote Access
Modify the ARN conf igur ation f ile to a dd the
E1/FE1 module and enable default E1/FE1
software services.
Configure E1/FE1 services. One of the following:
One of the following:
• Configuring and Managing Routers with
Site Manager
• Using the Bay Command Console
(BCC)
• Configuring WAN Line Services
• Configuring BayStack Remote Access
302702-B Rev 00
Using the E1/FE1 WAN Adapter Modul e in a BayStack ARN Router
For the latest information, be sure to review the release notes and documentation
change notice for your version of BayRS software..
Note: The only boot/startup methods you can use from the E1/FE1 WAN
adapter module interface are Local Boot and EZ-Install. The E1/FE1 WAN
adapter module does not support Netboot or Directed Netboot.
Note: Adding softwar e for the WAN adapter module may incr ease the rou ter’s
memory requirements beyond its current capacity. If the BayStack router
experiences a memory problem, see the section “Memory or Buffer Problem”
in Troubleshooting Routers. For information about changing the router image,
see Configuring and Managing Routers with Site Manager.
302702-B Rev 00
2-5
Chapter 3
Using the E1/FE1 WAN Adapter Module in a
Passport 5430 Multiservice Access Switch
This chapter supplements Installing and Operating the Passport 5430
Multiservice Access Switc h . F ol lo w the ha rdw are insta llat ion st eps in tha t manual ,
then refer to this document for information specific to the E1/FE1 WAN adapte r
module.
Warning:
AN, ANH, and ARN BayStack routers, and the Passport 5430 and Passport
2430. Attempting to use the E1/FE1 WAN adapter module in any other
product may be hazardous and invalidates the regulatory approval.
The E1/FE1 WAN adapter module is designed to operate only in
WAN Adapter Module Placement Considerations
When installing WAN adapter modules in the Passport 5430 Module slots, note
the following:
• Each WAN adapter module you install is automatically assigned a circuit,
even if the WAN adapter module has not been configured. This prevents
disruption of active circuits if you reconfigure the module at a later time.
• ISDN BRI adapter modules can use two circuits (one for each of the 2 B
channels).
• You can configure a total of 4 circuits.
• Circuit allocations are prioritized according to which Module slot is being
used by the WAN adapter modules. Module slot 3 has priority over Module
slot 4, and Module slot 4 has priority over Module slot 5.
302702-B Rev 00
3-1
E1/FE1 Adapter Module
• When there are more than the 4 possible circuits to be configured, for example
if there are 2 ISDN BRI adapter modules and a serial adapter module (5
circuits in all), circuit allocation becomes an issue.
In the example above, the first ISDN BRI module (in Module slot 3) has the
resources to bring up a sec ond B channel (thus usin g 2 circui ts). The s erial adapt er
in Module slot 4 uses a third circuit. The second ISDN BRI adapter module (in
Module slot 5), can have only 1 B channel configured because the serial adapter
module (in Module slot 4) has priority and is allocated a circuit over anything in
Module slot 5. In this case, there are not enough circuits left to utilize the second
B channel on the ISDN BRI adapter in Module slot 5. In this example, if you
wanted to have both B channels on both ISDN BRI adapters configured, you
would have to remove the serial card from Module slot 4.
Table 3-1 lists examples of valid WAN adapter module combinations.
Supplement
3-2
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a Passport 5430 Multiservice Access Switch
Table 3-1. Example WAN Adapter Module Combinations
Module 3 Module 4 Module 5
T1/FT1 or E1/FE1 T1/FT1 or E1/FE1 T1/FT1 or E1/FE1
T1/FT1 or E1/FE1 T1/FT1 or E1/FE1 Serial or V.34 modem
T1/FT1 or E1/FE1 Serial or V.34 modem Serial or V.34 modem
T1/FT1 or E1/FE1 T1/FT1 or E1/FE1 ISDN 2 B-channels plus 1
D-channel
T1/FT1 or E1/FE1 ISDN BRI 1 B-channel plus 1
D-channel
T1/FT1 or E1/FE1 Serial or V.34 modem Serial or V.34 modem
Serial or V.34 modem Serial or V.34 modem Serial or V.34 modem
Serial or V.34 modem Serial or V.34 modem ISDN BRI 1 B-channel plus 1
Serial or V.34 modem Serial or V.34 modem ISDN BRI 2 B-channels plus 1
Serial or V.34 modem ISDN BRI 2 B-channels plus 1
D-channel
ISDN BRI
2 B-channels plus
1 D-channel
ISDN BRI
2 B-channels plus
1 D-channel
ISDN BRI
2 B-channels plus
1 D-channel
ISDN BRI
2 B-channels plus
1 D-channel
ISDN BRI
2 B-channels plus
1 D-channel
ISDN BRI 2 B-channels p lus 1
D-channel
ISDN BRI 1 B-channel plus 1
D-channel
ISDN BRI 1 B-channel plus 1
D-channel
Serial or V.34 modem ISDN BRI 1 B-channel plus 1
T1/FT1 or E1/FE1 ISDN BRI 1 B-channel plus 1
Serial or V.34 modem
D-channel
D-channel
ISDN BRI 1 B-channel plus 1
D-channel
Empty
Serial or V.34 modem
T1/FT1 or E1/FE1
D-channel
D-channel
302702-B Rev 00
3-3
E1/FE1 Adapter Module
Supplement
Attaching Cables
Connect the communications cable to the RJ-48C connector on the installed
adapter module.
You install the E1/FE1 adapter module in one of the three front-panel Module
slots (Figure 3-1). See Installing and Operating the Passport 5430 Multiservice
Access Switch for the complete installati on procedure.
Note:
The slot labeled Remote Console is reserved for the V.34 modem
adapter module. Do not install the E1/FE1 adapter module in the Remote
Console slot.
Module 3
Module 4
Module 5
To
FE1 device
Remote
Console
U
ISDN BRI
with NT1
DDS
156K/64K
DSU/CSU
Telco
V.34 Modem
COM
FBR0061A
Figure 3-1. E1/FE1 WAN Adapter Module Connector on a Passport 5430
Connect the E1/FE1 cable to the connector on the installed adapter module
(Figure 3-1).
Note:
The E1/FE1 input port shall operate with an interconnecting cable loss
within the range of 0 to 6 decibels (dB), measured at 1024 kilohertz (kHz).
3-4
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a Passport 5430 Multiservice Access Switch
E1/FE1 Connections
The Passport 5430 supports the conversion of data (HDLC protocol) from an E1
line using an optional E1/FE1 adapter module. The integrated DSU/CSU
functionality allows direct connection to the E1 network, as opposed to
connecting via an external adapter. This solution reduces equipment costs and
simplifies c onnection to an E1 carrier.
The E1/FE1 implementation supports dynamic reconfiguration, Fractional E1
loopback, and an integrated Bit Error Rate Test (BERT) line tester. Configuring
WAN Line Services describes these services and how to configure them for
connection to a E1 network.
Table 3-2 lists the E1/FE1 connector pinouts.
Table 3-2. RJ-48C Connector Pinouts
Pin Assignment Pin No. Signal
12345678
1 Receive Data TIP
2 Receive Data RING
3 Chassis Ground
4 Send Data TIP
5 Send Data RING
6 Chassis Ground
7 No Connect
8 No Connect
Interpreting LEDs
The E1/FE1 WAN adapter module has four LEDs (Figure 3-2).
302702-B Rev 00
3-5
E1/FE1 Adapter Module
Supplement
E1/FE1
G.703
Local
Alarm
Loop
Remote
Alarm
Figure 3-2. E1/FE1 WAN Adapter Module LEDs
Table 3-3 describes the function of each E1/FE1 LED.
Table 3-3. E1/FE1 WAN Adapter Module LEDs
Label Color Meaning
Local Alarm Amber Lights when the E1 port is in a local alarm state.
Remote Alarm Amber Lights when the E1 port has re ceived a remote
alarm from the E1 network.
Loop Amber Lights when the E1 interface is placed in loopback
mode.
Sync Green Lights when the E1 port is synchronized with the
E1 network.
Completing Software Configurat ion
Sync
ARN0109A
3-6
Once you have successfully installed the adatper module, complete the following
software configuration tasks using instructions found in your BayRS
documentation:
Configuration Task Location of Instructions
Modify the Passport 5430 configuration file
to add the E1/FE1 module and enable
default E1/FE1 software services.
Configure E1/FE1 services.
• Configuring and Managing Routers with
Site Manager
• Using the Bay Command Console
(BCC)
• Configuring WAN Line Services
• Configuring BayStack Remote Access
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a Passport 5430 Multiservice Access Switch
For the latest information, be sure to review the release notes and documentation
change notice for your version of BayRS software.
Note: The only boot/startup methods you can use from the E1/FE1 WAN
adapter module interface are Local Boot and EZ-Install. The E1/FE1 WAN
adapter module does not support Netboot or Directed Netboot.
302702-B Rev 00
3-7
Chapter 4
Using the E1/FE1 WAN Adapter Module in a
Passport 2430 Multiservice Access Switch
This chapter supplements Installing and Operating the Passport 2430
Multiservice Access Switc h. F ol low the hardware ins tall ation steps in tha t ma nual,
then refer to this document for information specific to the E1/FE1 WAN adapte r
module.
Warning:
AN, ANH, and ARN BayStack routers and the Passport 5430 and Passport
2430. Attempting to use the E1/FE1 WAN adapter module in any other
product may be hazardous and invalidates the regulatory approval.
Attaching Cables
Connect the communications cable to the RJ-48C connector on the installed
adapter module.
You install the E1/FE1 adapter module in one of the two rear-panel WAN adapter
module slots (Figure 4-1). See Installing and Operating the Passport 2430
Multiservice Access Switch for the complete installatio n procedure.
The E1/FE1 WAN adapter module is designed to operate only in
302702-B Rev 00
4-1
E1/FE1 Adapter Module
Figure 4-1. E1/FE1 WAN Adapter Module Connector on a Passport 2430
Connect the E1/FE1 cable to the connector on the installed E1/FE1 adapter
module (Figure 4-1).
Supplement
Passport 2430
12
U
E1/FE1
G.703
10/100
Link TX/RX
VLK0026A
Note:
The E1/FE1 input port shall operate with an interconnecting cable loss
within the range of 0 to 6 decibels (dB), measured at 1024 kilohertz (kHz).
E1/FE1 Connections
The Passport 2430 supports the conversion of data (HDLC protocol) from an E1
line using an optional E1/FE1 adapter module. The integrated DSU/CSU
functionality allows direct connection to the E1 network, as opposed to
connecting via an external adapter. This solution reduces equipment costs and
simplifies c onnection to an E1 carrier.
The E1/FE1 implementation supports dynamic reconfiguration, Fractional E1
loopback, and an integrated Bit Error Rate Test (BERT) line tester.
WAN Line Services
connection to an E1 network.
4-2
Configuring
describes these services and how to configure them for
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a Passport 2430 Multiservice Access Switch
Table 4-1 lists the E1/FE1 connector pinouts.
Table 4-1. RJ-48C Connector Pinouts
Pin Assignment Pin No. Signal
12345678
Interpreting LEDs
The E1/FE1 WAN adapter module has four LEDs (Figure 4-2). Table 4-2
describes the function of each E1/FE1 LED.
1 Receive Data TIP
2 Receive Data RING
3 Chassis Ground
4 Send Data TIP
5 Send Data RING
6 Chassis Ground
7 No Connect
8 No Connect
302702-B Rev 00
Local
E1/FE1
G.703
Alarm
Remote
Alarm
Loop
Sync
Figure 4-2. E1/FE1 WAN Adapter Module LEDs
ARN0109A
4-3
E1/FE1 Adapter Module
Supplement
Table 4-2. E1/FE1 WAN Adapter Module LEDs
Label Color Meaning
Local Alarm Amber Lights when the E1 port is in a local alarm state.
Remote Alarm Amber Lights when the E1 port has re ceived a remote
alarm from the E1 network.
Loop Amber Lights when the E1 interface is placed in loopback
mode.
Sync Green Lights when the E1 port is synchronized with the
E1 network.
Completing Software Configurat ion
Once you have successfully installed the adatper module, complete the following
software configuration tasks using instructions found in your BayRS
documentation:
4-4
Configuration Task Location of Instructions
Connect the Passport 2430 to the network. One of the following:
• Installing and Operating the Passpor t
2430 Multis ervice Access Switch
• Configuring BayStack Remote Access
Modify the configuration file to add the
E1/FE1 module and enable default E1/FE1
software services.
Configure E1/FE1 services. One of the following:
One of the following:
• Configuring and Managing Routers with
Site Manager
• Using the Bay Command Console
(BCC)
• Configuring WAN Line Services
• Configuring BayStack Remote Access
302702-B Rev 00
Using the E1/FE1 WAN Adapter Module in a Passport 2430 Multiservice Access Switch
For the latest information, be sure to review the release notes and documentation
change notice for your version of BayRS software.
Note: The only boot/startup methods you can use from the E1/FE1 WAN
adapter module interface are Local Boot and EZ-Install. The E1/FE1 WAN
adapter module does not support Netboot or Directed Netboot.
302702-B Rev 00
4-5
Loading...
