BCM 4.0 Device Configuration Guide
BCM
Business Communications Manager
Document Status: Standard
Document Number: N0060600
Document Version: 01.13
Date: May 2009
Copyright © 2006–2009 Nortel Networks
All rights reserved.
The information in this document is subject to change without notice. The statements, configurations, technical data, and
recommendations in this document are believed to be accurate and reliable, but are presented without express or implied
warranty. Users must take full responsibility for their applications of any products specified in this document. The
information in this document is proprietary to Nortel Networks.
Trademarks
Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks.
Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
All other trademarks and registered trademarks are the property of their respective owners.
Task List
Getting started with BCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Welcome panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
System schedule settings and services scheduling . . . . . . . . . . . . . . . . . 29
System features and feature codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DN records parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Common procedures: copying and renumbering DNs . . . . . . . . . . . . . . . 71
To copy telephone configurations..................................................................................71
To change telephone DNs .............................................................................................72
Global telephony settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
3
Chapter 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Telephony system and device programming . . . . . . . . . . . . . . . . . . . . . . . 85
Configuring system speed dial numbers . . . . . . . . . . . . . . . . . . . . . . . . . . 87
DMC Feature List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
To arrange the DMC Feature list using Element Manager ............................................92
Setting up central answering positions . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
To create CAP stations..................................................................................................95
To program module buttons ..........................................................................................95
Creating ring groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Configuring Hunt Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Monitoring Hunt Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
To use a silent monitor ................................................................................................109
Configuring Hospitality services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
To set up hospitality service ........................................................................................114
To set up call restrictions .............................................................................................115
To set up wake-up services .........................................................................................115
To assign a room to a telephone.................................................................................115
To delete a room assignment from a telephone..........................................................116
Configuring analog telephones and devices . . . . . . . . . . . . . . . . . . . . . . 117
BCM 4.0 Device Configuration Guide
4 Task List
To assign a pause for external dialing.........................................................................120
Configuring telephones: Digital telephones . . . . . . . . . . . . . . . . . . . . . . . 121
To assign a line to a telephone....................................................................................123
To add line assignments..............................................................................................126
To configure capabilities and preferences...................................................................127
To configure telephone capabilities .............................................................................129
To configure preferences for a telephone....................................................................131
To program telephone buttons ....................................................................................133
To program user speed dials .......................................................................................134
To program outgoing call restrictions ..........................................................................134
To set restrictions ........................................................................................................135
To set line/set restrictions ............................................................................................135
Configuring telephones: IP telephones . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Global VoIP features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
To use the Services button to access features............................................................143
To define a key label ...................................................................................................144
To set up a password and allow Hot desking ..............................................................146
To reset the Hot Desking password field for a specific IP telephone ..........................147
To use the Hot desking feature to divert an IP telephone configuration ......................147
To cancel Hot desking .................................................................................................148
To configure a new time zone on a remote IP telephone ............................................148
To force a firmware download to a Nortel IP telephone ..............................................149
Default memory button programming for telephones . . . . . . . . . . . . . . . 151
To enable Bluetooth® on an IP Phone 1140E.............................................................172
Programming telephone sets: Desktop Assistant portfolio . . . . . . . . . . 183
To label a button..........................................................................................................190
Telephony features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
To move line buttons ...................................................................................................193
Feature configuration: Answering calls . . . . . . . . . . . . . . . . . . . . . . . . . . 197
To configure handsfree and handsfree answerback ...................................................198
To add a telephone to a pickup group .........................................................................199
To allow trunk answer..................................................................................................199
To block user access...................................................................................................199
To assign an Answer DN .............................................................................................200
To program a telephone for DND on Busy ..................................................................202
To program privacy on a line .......................................................................................203
To automatically enable privacy on a line....................................................................203
To set intrusion controls ..............................................................................................204
To program full autohold on a line...............................................................................205
To program auto hold on a telephone .........................................................................205
To program Exclusive Hold .........................................................................................205
To use the transfer feature ..........................................................................................206
To transfer unanswered calls ......................................................................................207
To redirect lines from the system ................................................................................207
To allow redirect ..........................................................................................................207
N0060600N0060600
Task List 5
To set a redirect tone...................................................................................................208
To redirect lines at the telephone ................................................................................208
To program call forward on the system .......................................................................208
To use Call Forward at the telephone .........................................................................209
To block user access...................................................................................................209
To use Camp-on..........................................................................................................210
To park a call ...............................................................................................................210
To retrieve a parked call ..............................................................................................211
To configure the SWCA system controls.....................................................................211
To allow call display.....................................................................................................213
To reset call log space.................................................................................................214
Feature configuration: Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
To block user access to feature programming ............................................................217
To allow a telephone to make priority calls..................................................................218
To configure system settings for page.........................................................................220
To configure telephone settings for page ....................................................................220
To make a page announcement ..................................................................................221
To make a voice announcement .................................................................................221
To set up a 3-party conference call .............................................................................222
To set up an Ad-hoc multiparty conference call ..........................................................222
To allow last number redial..........................................................................................225
To program speed dials in the DN record....................................................................226
To program user speed dials at the telephone ............................................................226
To view the feature that is currently assigned to a button ...........................................227
To configure memory buttons for features...................................................................227
To erase a memory button ..........................................................................................227
To store more than one number or code on one button ..............................................227
Using telephones for special features . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Display prompts and messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
About System-Wide Call Appearance (SWCA) keys . . . . . . . . . . . . . . . . 251
To add SWCA keys to your telephone ........................................................................252
To receive a call and assign it to a SWCA key ............................................................252
To retrieve a call from a SWCA key ............................................................................254
To conference a call parked on a SWCA key..............................................................255
Market profile attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Configuring the music source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283
To select the music source ..........................................................................................284
To open the Music Manager Administration application..............................................287
To load music onto the BCM .......................................................................................288
To delete an audio file from BCM ................................................................................289
To add a sound file to the Play List .............................................................................289
To remove a sound file from the Play List ...................................................................289
To access the BcmAmp Player ...................................................................................291
To configure a Network Device to be the IP Music source..........................................292
BCM 4.0 Device Configuration Guide
6 Task List
N0060600N0060600
Contents
Chapter 1
Getting started with BCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
About BCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
BCM key hardware elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Symbols and conventions used in this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
How to get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Getting Help from the Nortel Web site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Getting Help over the telephone from a Nortel Solutions Center . . . . . . . . . . . . . 22
Getting Help through a Nortel distributor or reseller . . . . . . . . . . . . . . . . . . . . . . . 22
7
Chapter 2
Welcome panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chapter 3
System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting clock control to local system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 4
System schedule settings and services scheduling . . . . . . . . . . . . . . . . . 29
Configuring schedule names and timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Default time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
About start and stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring scheduled service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Chapter 5
System features and feature codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
BCM feature codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Button programming features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Chapter 6
DN records parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Main panel tabs: common fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Line Access tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
BCM 4.0 Device Configuration Guide
8 Contents
Capabilities and Preferences main tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Restrictions main tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Line Access - Properties tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Line Access - Line Assignment tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Line Access - Line Pool Access tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Line Access - Answer DNs tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Capabilities and Preferences - Properties tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Capabilities and Preferences - Capabilities tab . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Capabilities and Preferences - SWCA Call Group tab . . . . . . . . . . . . . . . . . . . . . 57
Capabilities and Preferences - Preferences tab . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Capabilities and Preferences - Button Programming table . . . . . . . . . . . . . . . . . . 60
Capabilities and Preferences - Button Programming tab . . . . . . . . . . . . . . . . . . . 60
Capabilities and Preferences - User Speed Dial tab . . . . . . . . . . . . . . . . . . . . . . . 63
Capabilities and Preferences - ATA Settings tab . . . . . . . . . . . . . . . . . . . . . . . . . 64
Capabilities and Preferences - IP Terminal Details tab . . . . . . . . . . . . . . . . . . . . . 66
Restrictions - Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Restrictions - Set Restrictions tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Restrictions - Line/Set Restrictions tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Chapter 7
Common procedures: copying and renumbering DNs . . . . . . . . . . . . . . . 71
Copying settings to other DNs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Renumbering DNs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Chapter 8
Global telephony settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Feature Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Feature Settings panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Answer DN answer key levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Advanced Feature Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
System Wide Call Appearances Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
ONN Blocking (North American systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Silent Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Reset logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Chapter 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Telephony system and device programming . . . . . . . . . . . . . . . . . . . . . . . 85
Chapter 10
Configuring system speed dial numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . 87
System Speed Dial panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
N0060600N0060600
Contents 9
Chapter 11
DMC Feature List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Arranging the DMC Feature list using Element Manager . . . . . . . . . . . . . . . . . . . . . . 92
Chapter 12
Setting up central answering positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Configuring CAP assignments (eCAPs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Programming CAP/KIM buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Managing lines on a KIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Chapter 13
Creating ring groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Ring Groups - Members . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Ring Groups - Line Settings tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Chapter 14
Configuring Hunt Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Hunt Groups system setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Configuring the Hunt Group general settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Hunt Group members and lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Chapter 15
Monitoring Hunt Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Monitoring external hunt group calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Chapter 16
Configuring Hospitality services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Hospitality - General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Hospitality - Rooms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Setting up your hospitality system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Chapter 17
Configuring analog telephones and devices. . . . . . . . . . . . . . . . . . . . . . . 117
Configuring an analog telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Chapter 18
Configuring telephones: Digital telephones . . . . . . . . . . . . . . . . . . . . . . . 121
Using the DN panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
System DNs - Line Access tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Job aid: Notes about assigning lines to telephones . . . . . . . . . . . . . . . . . . . . . . 123
Line Assignment and Line Pools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Job aid: Answer DN notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Configuring Capabilities and Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Job aid: Assigning intercom (I/C) buttons (keys) . . . . . . . . . . . . . . . . . . . . . . . . . 128
BCM 4.0 Device Configuration Guide
10 Contents
Configuring telephone capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Job aid: Line redirection notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Configuring Preferences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Job aid: Call log notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Telephone memory button programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Job aid: Notes about button programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
User speed dials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Outgoing call restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Chapter 19
Configuring telephones: IP telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Configuring an IP telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
PVQM - Proactive Voice
Chapter 20
Global VoIP features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
IP feature list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
IP telephone
Hot desking IP telephone configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Using the Hot desking feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Configuring a new time zone on a remote IP telephone . . . . . . . . . . . . . . . . . . . . . . 148
Download firmware to a Nortel IP telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Quality Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
feature display labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Chapter 21
Default memory button programming for telephones . . . . . . . . . . . . . . . 151
Rules of default button assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
7316E digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
7316 digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
7208 digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
7100 digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
7000 digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
7406 digital phone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
IP telephone button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
IP telephone 2007 button defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
IP audio conference phone 2033 button defaults . . . . . . . . . . . . . . . . . . . . . . . . 164
IP Phone 1110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
IP Phone 1120E and IP Phone 1140E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
WLAN handset 2210/2211/2212 button defaults . . . . . . . . . . . . . . . . . . . . . . . . 175
WLAN handset display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Status area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Information area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Feature options area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
DMC Portables (413X/414X) (Europe only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
N0060600N0060600
Contents 11
Chapter 22
Programming telephone sets: Desktop Assistant portfolio . . . . . . . . . . 183
Introduction to Desktop Assistant Pro — Administrator Edition . . . . . . . . . . . . . . . . . 187
Desktop Assistant Pro — Administrator Edition main window . . . . . . . . . . . . . . . . . . 187
Menu bar commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Button programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Button labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
Chapter 23
Telephony features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Features to set up telephone set features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Moving line buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Receiver volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Programming distinctive ringing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Ring volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Auxiliary ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Chapter 24
Feature configuration: Answering calls. . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Answering calls directed to your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Configuring handsfree and handsfree answerback . . . . . . . . . . . . . . . . . . . . . . . 197
Answering calls not directed to your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Call Queuing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Directed Pickup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
Pickup Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Answer DNs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
Configuring privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Do Not Disturb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
DND on Busy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Turn Privacy on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Intrusion controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Holding calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Using Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Hold automatically (autohold) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Hold a call exclusively . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Parking or transferring calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Transfer (answered) calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Transfer (unanswered) calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Line redirection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Call forward (unanswered) calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Call Forward and voice mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Camp-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
BCM 4.0 Device Configuration Guide
12 Contents
Call Park . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
Callback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Sharing calls by parking on SWCA buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Call information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Call display information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Call duration timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Time and date display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Malicious Caller ID (MCID) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Call log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
LogIt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Chapter 25
Feature configuration: Making calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Blocking user access to feature programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Protecting outgoing call privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Managing a busy signal on an internal call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Priority Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Ring Again . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Other ways of communicating with internal users . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Leaving a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Making announcements to individuals (Voice Call) . . . . . . . . . . . . . . . . . . . . . . . 221
Create a conference call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
Dialing shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Last Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
Saved Number Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Autodial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Speed dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Programming memory buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Chapter 26
Using telephones for special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Special feature telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Setting up a central answering position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
N0060600N0060600
Supervisor telephone for silent monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
Hospitality services telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
Prime line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Direct dial telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Creating an enhanced CAP station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Hunt groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Ringing groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Contents 13
Chapter 27
Display prompts and messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Common display prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Viewing active services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
Call log prompts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Report and record alarm codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Chapter 28
About System-Wide Call Appearance (SWCA) keys. . . . . . . . . . . . . . . . . 251
Managing calls using SWCA keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Other features that affect how you use SWCA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Chapter 29
Market profile attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Media bay module availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
FEM MBM–Norstar trunk cartridge combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Time zones and language information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Time and date format based on language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Language support for South America and Central America . . . . . . . . . . . . . . . . 260
Caller ID display formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Core parameters for market profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Global analog trunk parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
GASM8 parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
ISDN line services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Analog and digital trunk types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
Chapter 30
Configuring the music source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283
Selecting the music source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Configuring Music Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
Opening the Music Manager Administration application . . . . . . . . . . . . . . . . . . . 287
Loading music onto the BCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Deleting music from BCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
Adding music to the Play List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
Removing music from the Play List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
Using the BcmAmp Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Configuring a Network Device to be the IP Music Source . . . . . . . . . . . . . . . . . . . . . 292
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
BCM 4.0 Device Configuration Guide
14 Contents
N0060600N0060600
Chapter 1
Getting started with BCM
Refer to the following topics for general BCM information:
• “About BCM” on page 16
• “Symbols and conventions used in this guide” on page 18
• “Related publications” on page 20
• “How to get Help” on page 21
About this guide
The BCM 4.0 Device Configuration Guide describes how to configure and assign features to
telephony devices through Telset and through Element Manager.
15
Purpose
The concepts, operations, and tasks described in this guide relate to the BCM software. This guide
provides task-based information about how to assign features and provide basic programming for
the Business Communications Manager.
Use Element Manager, Startup Profile, and Telset Administration to configure various BCM
parameters.
In brief, the information in this guide explains:
• global telephony settings
• steps to configure DNs
• product features and how to assign them
Audience
The BCM 4.0 Device Configuration Guide is directed to installers who install, configure, and
maintain BCM systems.
To use this guide, you must:
• be an authorized BCM installer or administrator within your organization
• know basic Nortel BCM terminology
• be knowledgeable about telephony and IP networking technology
BCM 4.0 Device Configuration Guide
16 Chapter 1 Getting started with BCM
Acronyms
The following is a list of acronyms used in this guide.
Table 1 Acronyms
Acronym Description
ASM Analog station module
ATA analog terminal adapter
BRI Basic Rate Interface
BCM Business Communications Manager
CAP Central Answering Position
CC Contact Center
CLID Calling Line Identification
CoS Class of Service
DPNSS Digital Private Network Signaling System
ISDN Integrated Services Digital Network
KIM Key Indicator Module
MCDN Meridian Customer Defined Networking
MCID malicious call identification
MWI message wait indicator
OLI outgoing line identification
ONN outgoing name and number
PVQM proactive voice quality monitoring
SM silent monitor
SWCA system-wide call appearance
Organization
This guide is organized for easy access to information that explains the concepts, operations, and
procedures associated with the BCM system.
About BCM
The BCM system provides private network and telephony management capability to small and
medium-sized businesses.
The BCM system:
• integrates voice and data capabilities, VoIP gateway functions, and QoS data-routing features
N0060600N0060600
into a single telephony system
Chapter 1 Getting started with BCM 17
• enables you to create and provide telephony applications for use in a business environment
BCM key hardware elements
BCM includes the following key elements:
• BCM200 main unit
• BCM400 main unit
• BCM1000 main unit
• BCM expansion unit (compatible with BCM400 main unit)
• BCM400 expansion gateway
• BCM media bay modules (MBM):
— 4x16
— ASM8, ASM8+
— BRIM
—CTM4, CTM8
— DDIM
— DSM16+, DSM32+
—DTM
—FEM
— GASM
—GATM4, GATM8
BCM features
BCM supports the complete range of IP telephony features offered by existing BCM products:
Note: You enable the following features by entering the appropriate keycodes (no
additional hardware is required).
• VoIP Gateway: Up to 12 VoIP trunks
• VoIP Telephony Clients: Up to 64 VoIP Telephony clients, supporting the range of Nortel
IP Phones.
BCM applications
BCM supports many applications provided on the existing BCM platforms.
Note: You enable the following features by entering the appropriate keycodes (no
additional hardware is required).
BCM 4.0 Device Configuration Guide
18 Chapter 1 Getting started with BCM
• Voice Messaging for standard voice mail and auto-attendant features
• Unified Messaging providing integrated voice mail management between voice mail and
common e-mail applications
• Fax Suite providing support for attached analog fax devices
• Voice Networking features
• LAN CTE (computer telephony engine)
• VEWAN (Voice Enabled WAN)
• IVR (Integrated Voice Response)
•IP Music
• Intelligent Contact Center
Symbols and conventions used in this guide
These symbols are used to highlight critical information for the BCM system:
Caution: Alerts you to conditions where you can damage the equipment.
Danger: Alerts you to conditions where you can get an electrical shock.
Warning: Alerts you to conditions where you can cause the system to fail or work
improperly.
Note: Alerts you to important information.
Tip: Alerts you to additional information that can help you perform a task.
N0060600N0060600
Chapter 1 Getting started with BCM 19
Security Note: Indicates a point of system security where a default should be
changed, or where the administrator needs to make a decision about the level of
!
security required for the system.
Warning: Alerts you to ground yourself with an antistatic grounding strap
before performing the maintenance procedure.
Warning: Alerts you to remove the BCM main unit and expansion unit power
cords from the ac outlet before performing any maintenance procedure.
The following conventions and symbols are used to represent the Business Series Terminal display
and dialpad.
Convention Example Used for
Word in a special font (shown
in the top line of the display)
Underlined word in capital
letters (shown in the bottom
line of a two-line display
telephone)
Dialpad buttons Buttons you press on the dialpad to select a
Pswd: Command line prompts on display telephones.
PLAY
Display option. Available on two line display
telephones
option on the display to proceed.
particular option.
. Press the button directly below the
The following text conventions are used in this guide to indicate the information described:
Convention Description
bold Courier
text
italic text Indicates book titles.
plain Courier
text
FEATURE
HOLD
RELEASE
Indicates command names and options and text that you must enter.
Example: Use the info command.
Example: Enter show ip {alerts|routes}.
Indicates command syntax and system output (for example, prompts
and system messages).
Example: Set Trap Monitor Filters
Indicates that you press the button with the coordinating icon on
whichever set you are using.
BCM 4.0 Device Configuration Guide
20 Chapter 1 Getting started with BCM
Related publications
This section provides a list of additional documents referred to in this guide. There are two types
of publications: Technical Documents on page 20 and User Guides on page 21.
Technical Documents
BCM 4.0 System Overview (N0060607)
System Installation
BCM 4.0 for BCM1000 Installation and Maintenance Guide Addendum (N0060603)
BCM200/400 BCM 4.0 Installation and Maintenance Guide (N0060612)
Keycode Installation Guide (N0060625)
System Programming
BCM 4.0 Administration Guide (N0060598)
BCM 4.0 Networking Configuration Guide (N0060606)
BCM 4.0 Telset Administration Guide (N0060610)
Telephones and Peripherals
BCM 4.0 Telephony Device Installation Guide (N0060609)
BST Doorphone Installation and Configuration Guide (P1013654)
T24 KIM Installation Card (P0603481)
IP Key Expansion Module (KEM) User Guide
Digital Mobility
DECT Deployment and Demonstration Tool
Digital Mobility System Installation and Configuration Guide (N0000623)
T7406 Cordless Handset Installation Guide (P0606142)
IP Telephony
i2050 Software Phone Installation Guide (N0022555)
IP Phone 1120E User Guide (NN-10300-062)
IP Phone 1140E User Guide (NN-10300-064)
IP Audio Conference Phone 2033 User Guide (N0060623)
WLAN IP Telephony Installation and Configuration Guide (N0060634)
N0060600N0060600
Chapter 1 Getting started with BCM 21
User Guides
Telephones and Peripherals
BCM 4.0 Telephone Features User Guide (N0060608)
BST Doorphone User Guide (P0605668)
Central Answering Position (CAP) User Guide (P0603480)
Hospitality Features Card (N0027326)
System-wide Call Appearance (SWCA) Features Card (N0027186)
T7000 Telephone User Card (P0912061)
T7100 Telephone User Card (P0609621)
T7208 Telephone User Card (P0609622)
T7316 Telephone User Card (P0935248)
T7316E Telephone User Card (P0609623)
Digital Mobility
DECT 413X/414X Handset User Guide (N0028550)
Digital Mobility Phone 7420 User Guide (N0000635)
Digital Mobility Phone 7430/7440 User Guide (N0028550)
T7406 Cordless Telephone User Card (P0942259)
IP Telephony
IP Audio Conference Phone 2033 User Guide (N0060623)
IP Phone 2001 User Guide (N0027313)
IP Phone 2002 User Guide (N0027300)
IP Phone 2004 User Guide (N0027284)
IP Phone 2007 User Guide (N0064498)
BCM WLAN 2210/2211/2212 Handset User Guide (N0009103)
How to get Help
This section explains how to get help for Nortel products and services.
Getting Help from the Nortel Web site
The best source of support for Nortel products is the Nortel Support Web site:
BCM 4.0 Device Configuration Guide
22 Chapter 1 Getting started with BCM
http://www.nortel.com/support
This site enables customers to:
• download software and related tools
• download technical documents, release notes, and product bulletins
• sign up for automatic notification of new software and documentation
• search the Support Web site and Nortel Knowledge Base
• open and manage technical support cases
Getting Help over the telephone from a Nortel Solutions Center
If you have a Nortel support contract and cannot find the information you require on the
Nortel Support Web site, you can get help over the telephone from a Nortel Solutions Center.
In North America, call 1-800-4NORTEL (1-800-466-7835).
Outside North America, go to the Web site below and look up the telephone number that applies
in your region:
http://www.nortel.com/callus
When you speak to the telephone agent, you can reference an Express Routing Code (ERC) to
more quickly route your call to the appropriate support specialist. To locate the ERC for your
product or service, go to:
http://www.nortel.com/erc
Getting Help through a Nortel distributor or reseller
If you purchased a service contract for your Nortel product from a distributor or authorized
reseller, you can contact the technical support staff for that distributor or reseller.
N0060600N0060600
Chapter 2
Welcome panel
The Welcome panel displays information for the current account logged on the system. The
administrator is prompted to change the password before any programming menus are accessible.
This panel will be displayed on the first login to the BCM by nnadmin, when the administrator has
selected the forced password change option on an account, or if the password has expired. See
Figure 1.
Figure 1 Initial welcome panel
23
Table 2 Initial Welcome panel fields
Attribute Value Description
User ID <read-only> User ID you used to log on to the system.
Password <alphanumeric> To change password, select the field and enter new
password. The password must satisfy the password
policy requirements for the system. See the BCM 4.0
Administration Guide (N0060598) for more
information on password requirements.
Once the password has been changed the entire navigation tree is accessible. See Figure 2.
BCM 4.0 Device Configuration Guide
24 Chapter 2 Welcome panel
Figure 2 Welcome panel
Table 3 Welcome panel fields
Attribute Value Description
Current Account
Account Notifications <read-only> Displays BCM administrative messages or notifications
User ID <read-only> User ID you used to log on to the system.
Telset User ID <read-only> User ID used to logon to the telset configuration interfaces for
Last successful login <read-only> Date and time that this user account was last logged in the
regarding the current user.
telephony and CallPilot applications.
system.
N0060600N0060600
Chapter 3
System Software
The system software identity.
The following path indicates where to access the system identification settings in Element
Manager:
• Element Manager: System > Identification
Figure 3 System Identification panel
25
Table 1 describes each field on this panel.
Table 1 System Identification fields
Attribute Value Description
Model <read-only> This is the system hardware release currently running on this
System name <alphanumeric> It is easier to manage a group of systems if each system is
Version <read-only> The version of software running on the BCM Main Unit.
Country or region <read-only> This setting defines internal system settings for default values,
device.
provided with a unique name or identification number.
available languages, and hardware and functional availability
for a specific country or region.
Setting Date and Time
How you set the Date and Time feature for your system depends on whether your system receives
this information from a network server.
The following path indicates where to access the date and time settings in Element Manager:
• Element Manager: Configuration > System > Date and Time
BCM 4.0 Device Configuration Guide
26 Chapter 3 System Software
Click the following link to connect with the type of information you want to view:
Panel Task
Click the navigation tree heading to access general information about Date and Time management.
Figure 4 Date and time panel
“Setting clock control to local system” on page 28
Table 2 describes each field on the Date and Time panel.
Table 2 Date and Time panel fields (Sheet 1 of 2)
Attribute Value Description
Date and Time Source NTP
Tr unk
Manual
Network Time Protocol Settings
(Settings are active only if Clock Control Type is set to Network Time Protocol.)
NTP server address <IP address> The IP address of the server that controls the network time and
N0060600N0060600
Set to NTP (Network Time Protocol) if the system uses a
network server to determine the correct time and date.
Set to Trunk to use time and date settings from a CO through
an analog or ISDN line.
Set to Manual if you want to be able to manually configure the
time and date for your system.
date.
Table 2 Date and Time panel fields (Sheet 2 of 2)
Attribute Value Description
Chapter 3 System Software 27
Synch every (s) NA (not applicable)
1-XXXX
NTP security mode Secured
Unsecured
Raise Alarm if Clock differs
by at least (s)
NTP key ID <1-65,534> ID for accessing the NTP.
NTP key string <8 characters> Control key corresponding to ID for accessing the NTP.
Current Date and Time
Date and time <country/
Year <numeric> The current year in yyyy format.
Time zone <drop-down list> The appropriate time zone for the location of this system. The
Daylight Savings Time <read-only> The appropriate mode for the Time zone.
<seconds> The number of discrepancy seconds specified that must occur
region-specific date
and time format>
The number of seconds specified to elapse between contacts
with the NTP server.
NA: Appears if you chose Manually in the Synch with Server
field.
1-XXXX: Number of seconds between contacts with the NTP
server.
Select whether the NTP security mode is secured or
unsecured.
before the system notifies you of a time difference from the
NTP server, if the system automatically checks with the NTP
server.
The current date and time.
Time zone must be set for software updates to be applied.
Selected: The system automatically updates the time twice a
year.
Cleared: The system never updates the time for Daylight
Savings Time.
Note: North American Daylight Savings Time rules change in 2007.
Four time zones have been added to support regions that do not want to
switch to the new time zone rules. The time zones are identified
“pre-2007 DST”.
If the system is to synchronize with an NTP Server or trunk, check the following:
1 Set Date and Time Source to NTP or Trunk.
2 In the NTP server address field enter the IP address of the NTP server.
3 Set the number of seconds between synchronizations in normal operations (Synch Every).
BCM 4.0 Device Configuration Guide
28 Chapter 3 System Software
4 In the bottom frame, ensure that the Time zone is correct for the location of the local system.
5 If Trunk was selected in the Date and Time Source drop-down list, enter the year in the Ye a r
field.
Note: Only time and date info are updated when NTP and Trunk
settings are selected. Year information is not updated. You also have full
control over time and date settings using telset admin even if NTP or
Trunk are selected. Any setting applied through telset admin are
over-written by the external source if NTP or Trunk are selected. Time
zones need to be set for software updates to be applied.
Setting clock control to local system
If you want the clock to be controlled locally:
1 Ensure that Clock Control Type is set to local.
2 In the bottom frame:
• In the Time Zone field, select the Time zone the system uses.
• In the Date field, enter the month, day and year.
• In the Time field, enter the hours and minutes and time of day.
• In the Daylight Savings Time field, choose whether the system updates the time twice a
year for daylight savings time.
N0060600N0060600
Chapter 4
System schedule settings and services scheduling
Use scheduled services to control how calls are answered in off-hours (Ringing Groups), how calls
are routed at various times of the day, and how restrictions are applied on lines and telephones at
specific times of the day.
The following paths indicate where to access scheduled services in Element Manager and through
Telset Administration:
• Element Manager: Configuration > Telephony > Scheduled Services
• Telset interface: **CONFIG > Services
The Scheduled Services - Settings and Schedules panel has three distinct areas for configuration.
• The table in the top frame allows you to determine which schedules are active for the system
for routing, restriction, and ringing schedules.
• The table in the top frame to the right sets the time periods within each schedule for each day
of the week.
• The table in the bottom frame allows you to rename schedules.
29
Click one of the following links to connect with the type of information you want to view:
Panels Related panels or tasks Feature
“Configuring scheduled service”
on page 32
“Configuring schedule names and
timers” on page 30
Click the navigation tree heading to access general information about Ring Group management.
Alternate routes for routing
schedules in the BCM 4.0
Networking Configuration Guide
(N0060606)
“Ring Groups - Line Settings tab”
on page 99
Restriction filters in the BCM 4.0
Networking Configuration Guide
(N0060606)
“Restrictions (Line and Remote) in
the BCM 4.0 Networking
Configuration Guide (N0060606)
“Restrictions main tab” on page 67
Class of Service table in the
BCM 4.0 Networking Configuration
Guide (N0060606)
“Control telephone” on page 229
Schedules are activated and deactivated through control telephones. Refer to “Control telephone”
on page 229.
BCM 4.0 Device Configuration Guide
30 Chapter 4 System schedule settings and services scheduling
Restriction and Routing services require a service control password before users are allowed to
change scheduling on a control telephone. The Service Control Password field on this panel allows
you to delete a current entry, and add a new password. Make a note of the password; the panel
displays only asterisks.
Configuring schedule names and timers
The tables on this panel allow you to change the names of the schedules, and to determine when
the schedules, which are set to automatically execute, are deployed. Any changes to these settings
affect all services that use schedules.
Figure 5 Schedule names and timers
Table 3 describes the fields on the subpanel tables.
Table 3 Schedule common settings
Attribute Value Description
Schedules
Schedule <alphanumeric> Double-click the field, and enter a descriptive name for the schedule.
Schedule Times
For each schedule, there are timers for the seven days of the week.
Day <seven days>
Start Time 00:00 to 12:00
a.m.-p.m./24:00
Stop Time 00:00 to 12:00
a.m.-p.m./24:00
This is the time when the schedule starts, and any previously-running schedules
stop.
Use a 12-hour or 24-hour format. If the entry is less than 12:00, the system
prompts for a day period setting.
00:00 = schedule is off
start and stop are the same = schedule runs for 24 hours
start: 22:00/stop: 06:00 = schedule starts at midnight, runs until 6 a.m., then
starts again at 10 p.m. (22:00).
This is the time when the schedule stops.
N0060600N0060600
Chapter 4 System schedule settings and services scheduling 31
Default time settings
Table 4 provides a list of the default times for each schedule.
Table 4 Default schedule times
Schedule Start Time Stop Time Schedule Start Time Stop Time
Schedule 1: Night 23:00 07:00 Schedule 4: 00:00 00:00
Schedule 2: Evening 17:00 23:00
Schedule 3: Lunch 12:00 13:00 Schedule 6: 00:00 00:00
Schedule 5: 00:00 00:00
About start and stop times
Here are some general rules about setting start and stop times:
• It is only necessary to program start and stop times for schedules that are activated
automatically.
• The time may be entered in either 12 or 24-hour format. If the display is in English, and the
hour entered is less than 13, the display prompts you to specify AM or PM.
• If you assign identical start and stop times for a schedule, for example, 04:00 start and 04:00
stop, the schedule is in effect all day. The only exception to this is a start and stop time of
00:00; in this case the schedule is off for the day.
• You may assign overlapping times. For example, if schedule 1 is assigned from 9:00 a.m. to
4:00 p.m. and schedule 2 is assigned from 1:00 p.m. to 5:00 p.m., then the start time of the
second schedule is treated as a stop time for the first schedule. This is also true if two
schedules have the same start time but different stop times. The stop time of the shorter
schedule is treated as the start time of the longer schedule.
• If one schedule starts and stops within the times of another schedule, the first service
temporarily ends when the second service starts. The first service then resumes when the
second service has ended.
• Some schedules start and stop at the same times each day: use COPY to copy the start and
stop times from one day to the next.
Warning: Start and stop times do not span days. When you program a
schedule to start in the evening and stop in the morning, it does not carry
over into the next day. For example, if you program Night service for Friday
(22:00 to 6:00), the system turns on Night service from midnight to 6 am on
Friday, and then again from 10 p.m. to midnight on Friday, as shown in the
diagram below.
BCM 4.0 Device Configuration Guide
32 Chapter 4 System schedule settings and services scheduling
Configuring scheduled service
The table in the top frame lists all schedules available on the system. Configure the settings for the
schedules that you are using for your system.
Figure 6 Services table
Table 5 describes the fields under Scheduled Services.
Table 5 Service settings (Sheet 1 of 2)
Attribute Value Description
Service control
password
N0060600N0060600
<alphanumeric> Restriction and Routing schedules require the user to enter a password on the
control telephone before scheduling can be changed.
If you forget the password, enter a new password.
Chapter 4 System schedule settings and services scheduling 33
Table 5 Service settings (Sheet 2 of 2)
Attribute Value Description
Schedule <read-only> These are the schedules that are available on the system.
Routing Svc Off
Manual
Auto
Overflow <check box> If all the lines used by a route are busy when a call is made, you can program
Off prevents the service from being activated.
Manual allows you to turn the service on and off at any time from a control
telephone. This setting overrides any automatically-running schedules.
Auto allows you to program a stop and start time for a service under the
Common Settings heading. These times are then automatically executed when
the service is active.
Default: Off
Routing service to overflow to the route used for normal mode. If the call is
routed to use the normal mode, the telephone sounds a warning tone and
displays the message
call to avoid the toll charges or can continue.
Expensive route. The caller then can release the
Tips: A schedule must be active for overflow routing to be in effect. Overflow
routing is not available in normal mode.
You must create an overflow route to be used with each routing code. In this way,
every route used with a scheduled mode that has overflow service must have an
alternate route in normal service.
Default: Cleared
Ringing Svc Off
Manual
Auto
Trunk Answer <check box> Trunk answer enables you to answer, from any telephone, an external call that is
Extra Dial Set None
DN <XX>
DN <control set>
Restriction Svc Off
Manual
Auto
Off prevents the service from being activated.
Manual allows you to turn the service on and off at any time from a control
telephone. This setting overrides any automatically-running schedules.
Auto allows you to program a stop and start time for a service under the
Common Settings heading. These times are then executed automatically when
the service is active.
Default: Off
For details about setting up ring groups, refer to “Creating ring groups” on
page 97.
ringing at another telephone in your office, if the Ringing Service is active on that
line at the time of the call. If the service is not active, you cannot answer the call.
Trunk answer is useful if the other telephones are not assigned the same lines
as the telephone you are using to answer the call.
Note: You can change the Trunk Answer setting only if Ringing service is set to
Manual or Auto.
Default: Selected
The Extra dial set attribute allows you to assign an additional telephone to
receive calls for each schedule.
Note: The extra dial set is activated during a schedule by entering the Ringing
service feature code from the assigned direct dial telephone. This does not
activate the Ringing service, unless the direct dial telephone is also a control
set.
Off prevents the service from being activated.
Manual allows you to turn the service on and off at any time from a control
telephone. This setting overrides any automatically-running schedules.
Auto allows you to program a stop and start time for a service under the
Common Settings heading. These times are then executed automatically when
the service is active.
Default: Off
BCM 4.0 Device Configuration Guide
34 Chapter 4 System schedule settings and services scheduling
N0060600N0060600
Chapter 5
System features and feature codes
• “BCM feature codes” on page 35 provides a complete list of the feature codes that can be
accessed from digital and IP telephones.
• “Button programming features” on page 38 provides a list of the features that are
programmable under the DN record Button Programming heading.
BCM feature codes
The following provides a quick reference for BCM features available by pressing the FEATURE
button on M-series telephones, Business Series Terminals (BST series), and IP telephones. Table 6
provides feature names sorted alphabetically, and numerically by feature code.
Refer to the user documentation for the specific product to find out how to use the codes on each
type of telephone.
35
Table 6 Features sorted by feature name and by activation code (Sheet 1 of 4)
Sorted by feature name Sorted by activation code
FEATURE<
Feature name
Alarm time (room set) 875
Alarm time - Cancel #875 *0 Button inquiry
Alarm time (HS admin set) 877
Autodial - External *1 #1 Messages - Cancel Send
Autodial - Internal *2
Auto Hold 73 2 Ring Again
Auto Hold - Cancel #73
Background Music 86 *2 Autodial - Internal
Background Music - Cancel #86
Button inquiry *0 *3 Memory buttons - Program
Contact Center agent login/log out 904
Contact Center agent make busy/ready 908 #4 Call Forward - Cancel
Contact Center queue status 909
Call Charge Indication 818 5 Last Number Redial
Call Duration Timer 77
Call Forward 4 *502 Language - Alternate
Call Forward - Cancel #4 *503 Language - Alternate 2
Call Forward to Voice Mail 984 *504 Language - Alternate 3
Call Information 811 *510 Time zone readjust (IP telephones)
code>
FEATURE
<code>
0 Speed Dial - Activate
1 Messages - Send
*1 Autodial - External
#2 Ring Again - Cancel
3 Conference Call
4 Call Forward
*4 Speed Dial - Add, change
*501 Language - Primary
Feature name
BCM 4.0 Device Configuration Guide
36 Chapter 5 System features and feature codes
Table 6 Features sorted by feature name and by activation code (Sheet 2 of 4)
Sorted by feature name Sorted by activation code
FEATURE<
Feature name
Call Log - Delete items (autobumping) 815
Call Log - Manual 813
Call Log - View information 812
Call Log options *84 *538 Find newest SWCA
Call Log password *85
Call Park 74 *6 Ring Type
Call Queuing 801
Camp-on 82 61 Page - Internal (telephone speakers)
Class of Service 68 62 Page - External (external speakers)
Conference Call 363
Contrast adjustment *7 64 Line Pool
Dialing Mode *82 65 Messages - View
Directed Pickup 76
Display Voice Mail DN, skillset or IVR DN 985 67 Saved Number Redial
Do not Disturb 85
Do not Disturb - Cancel #85 69 Priority Call
Exclusive Hold 79
Voice Mail Leave Message 980 70 Transfer
Group Listening 802
Group Listening - Cancel #802 71 Link
Group Pickup 75
IP Services list *900 #73 Auto Hold - Cancel
IP Hot desking *999
Language - Primary *501 75 Group Pickup
Language - Alternate *502
Language - Alternate 2 *503 77 Call Duration Timer
Language - Alternate 3 *504
Last Number Redial 5 79 Exclusive Hold
Line buttons - Move *81
Line Pool 64 *81 Line buttons - Move
Line Redirection 84
Line Redirection - Cancel #84 *82 Dialing Mode
Link 71
Long tones 808 84 Line Redirection
Malicious call identification (MCID) 897
Memory buttons - Program *3 *84 Call Log options
Messages - Send 1
code>
FEATURE
<code>
*521 to *536
*537 Find oldest SWCA
*550 Silent Monitor
60 Page
66 Voice Call
68 Class of Service
*7 Contrast adjustment
#70 Transfer - Cancel
73 Auto Hold
74 Call Park
76 Directed Pickup
78 Pause
*80 Ring Volume
82 Camp-on
83 Privacy (on/off)
#84 Line Redirection - Cancel
85 Do not Disturb
Feature name
System Wide Call Appearance
(SWCA)
Page - Combined (internal and
external)
N0060600N0060600
Chapter 5 System features and feature codes 37
Table 6 Features sorted by feature name and by activation code (Sheet 3 of 4)
Sorted by feature name Sorted by activation code
Feature name
FEATURE<
code>
FEATURE
<code>
Feature name
Messages - Cancel Send #1 #85 Do not Disturb - Cancel
Messages - View 65 *85 Call Log password
Name and number blocking 819 86 Background Music
Name and number blocking - Cancel #819 #86 Background Music - Cancel
Page 60 88 Voice Call Deny
Page - Combined (internal and external) 63 #88 Cancel Voice Call Deny
Page - External (external speakers) 62 800 Trunk Answer
Page - Internal (telephone speakers) 61 801 Call Queuing
Pause 78 802 Group Listening
Priority Call 69 #802 Group Listening - Cancel
Privacy (on/off) 83 803 Time
Record call 989 804 Wait for dial tone
Ring Again 2
805 Test telephone display
Ring Again - Cancel #2 806 Static Time
Ring Type *6
#806 Static Time - Cancel
Ring Volume *80 807 Ringing (Signal) Call
Ringing (Signal) Call 807
808 Long tones
Room condition (Room set) 876 811 Call Information
Room condition (HS admin set) 878
812 Call Log - View information
Room occupancy 879 813 Call Log - Manual
Run/Stop *9
815
Call Log - Delete items
(autobumping)
Saved Number Redial 67 818 Call Charge Indication
Silent Monitor *550
819 Name and number blocking
Speed Dial - Add, change *4 #819 Name and number blocking - Cancel
Speed Dial - Activate 0
870 View active services
Static Time 806 871 Turn Ringing service on
Static Time - Cancel #806
System Wide Call Appearance (SWCA) *521 to
*536
Find available SWCA *520
#871 Turn Ringing service off
872 Turn Restriction service on
#872 Turn Restriction service off
873 Turn Routing service on
1
Find oldest SWCA *537 #873 Turn Routing service off
Find newest SWCA *538
875 Alarm time
Test telephone display 805 #875 Alarm time - Cancel
Time 803
876 Room condition (Room set)
Time zone adjust (IP telephones) *510 877 Alarm time (HS admin)
Transfer 70
878 Room condition (HS admin)
Transfer - Cancel #70 879 Room occupancy
BCM 4.0 Device Configuration Guide
38 Chapter 5 System features and feature codes
Table 6 Features sorted by feature name and by activation code (Sheet 4 of 4)
Sorted by feature name Sorted by activation code
FEATURE<
Feature name
Transfer to mailbox 986 897 Malicious call identification (MCID)
Tr unk A n swer 800 *9 Run/Stop
Turn Restriction service off #872 *900 IP Services list
Turn Restriction service on 872 904 Contact Center agent login/log out
Turn Ringing service off #871 908 Contact Center agent make busy/
Turn Ringing service on 871 909 Contact Center queue status
Turn Routing service off #873 980 Voice Mail Leave Message
Turn Routing service on
View active services 870 982 Voice Mail Operator settings
Voice Call 66 984 Call Forward to Voice Mail
Voice Call Deny 88 985 Display Voice Mail DN, skillset, or
Voice Call Deny - Cancel #88
Voice Mail direct 988
Voice Mail Interrupt 987 987 Voice Mail Interrupt
Voice Mail login 981 988 Voice Mail direct
Voice Mail Operator settings 982 989 Record call
Wait for dial tone 804 *999 IP Hot desking
Note
1
Contact your System Administrator for the service control password.
1
code>
873 981 Voice Mail login
FEATURE
<code>
986 Transfer to mailbox
Feature name
ready
IVR DN
Button programming features
The following describes the features available for Button Programming (Configuration >
Telephony > Sets > All DNs > Capabilities and Preferences > Button Programming).
Note that some of these features require other system settings in order to work.
• Some of the buttons are controlled by features under Configuration > Telephony > Sets >
Active Sets > Capabilities. Paging is an example of a feature that requires other settings.
N0060600N0060600
Chapter 5 System features and feature codes 39
• Some features also require that the service be available on the line from your telephone service
provider. The types of lines provided are also determined by the region chosen for your
system. MCID (malicious call identification) is an example of this type of feature.
Table 7 Button Programming Feature settings (Sheet 1 of 4)
Set command
(FEATURE
<code>)
Feature Description
None Indicates a button that is configured for button programming, but nothing
0 Speed dial Activates the speed dial feature. The telephone prompts the user for a
1 Send message Allows the user to send a message to another DN on the system.
#1 Cancel send message Allows the user to cancel a message that was sent to another set within
2 Ring again Turns on the Ring again feature.
3 Conference/Transfer Initiates a conference between user and two parties.
4 Call forward Allows the user to enter a number to forward all calls.
5 Last number redial Causes set to redial the last number that was dialed.
*5 Language choice Allows the user to select the language in which prompts are displayed.
60 Page - general Initiates a page.
61 Page - Internal Allows the user to page internal to a specific zone, which is identified
62 Page - External Allows the user to page through the speaker on a specific telephone.
63 Page - speaker and zone Allows the user to page through both the internal sets, and externally
64 Line pool Allows the user to access a line pool. The pool this button accesses is
65 Reply message Allows the user to access messages, and send a reply to the message
#65 Cancel message waiting Allows the user to cancel the message waiting indicator.
66 Voice call Allows the user to make an announcement, or begin a call through the
67 Saved number redial Allows the user to redial a number that was saved while on a call.
68 Restriction override Allows the user to override any restrictions on the set or line with a CoS
69 Priority call Allows the user to priority call an internal DN that is currently busy.
*7 Contrast Allows the user to adjust the contrast of the display screen.
70 Transfer Allows the user to transfer an existing call to another telephone or
has been entered.
speed dial code.
the network.
Note: Allow redirect must be selected to forward calls outside of the
system.
within the Button programming. (For example F611 internal zone 1, F610
page internal all zones.)
connected paging equipment to a specific zone, which is identified within
Button programming.
specified during Button Programming for this feature.
sender.
speaker of another telephone.
password.
external number.
BCM 4.0 Device Configuration Guide
40 Chapter 5 System features and feature codes
Table 7 Button Programming Feature settings (Sheet 2 of 4)
Set command
(FEATURE
<code>)
71 Link Activates the Link command, which allows the user to access special
74 Call park Allows the user to park a call.
*520 Find available SWCA key System searches for a free SWCA key among the SWCA keys that are
*521 *536 System Wide Call
*537 Find oldest SWCA call System searches among the SWCA keys assigned to the telephone, and
*538 Find newest SWCA call System searches among the SWCA keys assigned to the telephone, and
*550 Silent monitor Allows the user to monitor hunt group calls. (Telephone must be
75 Group pickup Allows the user to answer a call ringing telephone within the Pickup
76 Directed pickup Allows the user to answer any ringing telephone within the same system.
77 Call timer Allows the user to see the call duration timer.
78 Pause Allows the user to insert a pause during a dialing sequence.
79 Exclusive hold Allows the user to place a call on hold at the current telephone. All
800 Trunk answer Allows the user to answer a ringing line while in a ringing service. (If
801 Call queuing Allows the user to answer calls in order when several calls arrive in rapid
802 Group listening Activates the speaker on the set to allow a group of people to hear a call.
803 Time Briefly displays the current time.
804 Wait for dialtone Places a pause in a dialing string that holds the following digits until a
806 Static date and time First line displays the date and time.
807 Ringing (Signal) call Directly rings another telephone inside the system when an extension is
808 Long tones Allows the user to send long DTMF tones.
811 Call information Allows the user to view information about a current call.
812 Call log - view
813 Call LogIt Allows the user to add the current call to the call log manually.
Feature Description
features on a remote PBX system.
assigned to the current telephone.
Non-intercom calls are associated with an available SWCA key when the
Appearance (1 to 16)
information
call is answered, originated, or placed on Hold.
Features that interact with this feature: Hold, telephone keys, outgoing
and incoming calls.
unparks the call that has been parked the longest.
unparks the most recently parked call.
assigned with SM supervisor.)
group.
appearances of the call on other telephones indicate the line is busy.
enabled).
succession. Calls are presented in this order: incoming calls, timed-out
forwarded calls, then camped calls.
But the user must talk to the caller through the handset.
dialtone is perceived on the line.
entered after the feature is selected. This is the same process as
pressing an intercom button and dialing an extension.
Allows the user to view call log information.
N0060600N0060600
Chapter 5 System features and feature codes 41
Table 7 Button Programming Feature settings (Sheet 3 of 4)
Set command
(FEATURE
<code>)
815 Call logs autobumping Allows the user to select if the system will remove the oldest log item
818 Call charge indication Allows the user to view the charges for a call (available on DASS2 and
819 ONN blocking Allows the user to block the call information from the telephone for an
82 Camp-on Allows the user to transfer and camp an external call on another
83 Privacy control Allows the user to change the line privacy setting on the current call.
84 Line redirection Allows the user to redirect a line on their telephone to an external
85 Do not disturb Allows the user to block incoming calls from ringing on the telephone.
86 Background music Allows the user to play music provided by a background music source
870 Service mode status Allows the user to view the current service mode being used.
871 Ringing service Allows the user to change the ringing service mode.
872 Restriction service Allows the user to change the restriction service mode.
873 Routing Service Allows the user to change the routing service mode.
88 Voice call deny Allows the user to deny other users from Voice Calling their set.
897 MCID (Malicious Call Identification)
*501 Language choice Provides a menu that allows you to choose the language for the display
*7 Contrast Digital telephones only.
904 CC agent login/log out Allows the user to log in or out of ACD.
905 CC supervise Allows the CC supervisor to monitor CC agent calls.
906 CC supervisor help Allows the CC agent to request help from a CC supervisor.
907 CC activity code Allows the CC agent or supervisor to enter activity codes for reporting.
908 CC agent make Not
909 CC skillset status Allows the user to view the status of queued calls on ACD.
980 Voice mail Leave
981 Voice mail login Opens your mailbox to play your messages and to access mailbox
982 Voice mail operator
984 Call forward to voice mail Forwards all calls to your voicemail.
Feature Description
manually when the log space fills.
ETSI Euro trunks only).
outgoing call.
telephone in the system.
number.
through the speaker on the telephone.
Allows the user to query the system for information about a call within 25
seconds after the user hangs up, but before the caller hangs up.
prompts on the telephone.
Sets the level of contrast for the telephone display.
Allows the user to indicate ready or Not ready status on ACD.
ready/ready
Allows the user to log into voice mail box to leave a message.
Message
options.
Allows the user to set the parameters for the voice mail operator.
settings
BCM 4.0 Device Configuration Guide
42 Chapter 5 System features and feature codes
Table 7 Button Programming Feature settings (Sheet 4 of 4)
Set command
(FEATURE
<code>)
985 Display voice mail DN Displays the voice mail, skillset, or IVR DN.
986 Transfer to mailbox Transfers an external call directly to a mailbox on the CallPilot system.
987 Voice mail interrupt Intercepts a caller who is listening to your mailbox greeting or leaving a
988 Voice mail direct Dial an internal user via the name in the voice mail directory.
989 Record call Record the call to your voice mail box. Must be enabled by the system
*900 IP services list IP telephones only.
*999 IP Hot desking IP telephones only.
Feature Description
message.
administrator.
Allows the user to access a feature menu. This is the same menu that is
accessed by pressing the Services key.
Allows the user to access the Hot desking feature. This feature allows
calls to be diverted from one IP telephone to another.
N0060600N0060600
Chapter 6
DN records parameters
The DN record defines the specific function of each telephone within the system.
The following paths indicate where to access DN record parameters in Element Manager and
through Telset Administration:
• Element Manager: Configuration > Telephony > Sets > All DNs
• Telset interface: **CONFIG > Terminals and Sets
Other areas of programming that affect how each telephone functions include:
• system settings (“Global telephony settings” on page 73)
• telephone model
The DN records panel is a multilayered panel with multiple tabs. Although all panels show up for
all models, not all models require configuration for all panels. Refer to the task and feature
programming links to determine specific configuration. For information on programming a
Doorphone refer to the BST Doorphone documentation.
43
The panel tabs links provide a general description of each panel and definitions of each panel field.
Click one of the following links to connect with the type of information you want to view:
Panel tabs Tasks Features
“Main panel tabs: common fields” on
page 44
“Line Access tab” on page 46 “Configuring telephones: Digital
“Line Access - Line Assignment
tab” on page 48
“Line Access - Line Pool Access
tab” on page 50
“Line Access - Answer DNs tab”
on page 51
“Capabilities and Preferences main tab”
on page 52
“Capabilities and Preferences Capabilities tab” on page 54
“Capabilities and Preferences Preferences tab” on page 58
“Capabilities and Preferences ATA Settings tab” on page 64
“Capabilities and Preferences - IP
Terminal Details tab” on page 66
“Common procedures: copying and
renumbering DNs” on page 71
telephones” on page 121
“Configuring analog telephones and
devices” on page 117
“Configuring telephones: IP
telephones” on page 137
“Feature configuration: Answering
calls” on page 197
“Feature configuration: Making
calls” on page 217
“Hotline telephone” on page 229
“Control telephone” on page 229
“Supervisor telephone for silent
monitoring” on page 231
“Features to set up telephone set
features” on page 191
“Auxiliary ringer” on page 194
“Global VoIP features” on page 141
BCM 4.0 Device Configuration Guide
44 Chapter 6 DN records parameters
Panel tabs Tasks Features
“Capabilities and Preferences Button Programming tab” on
page 60 (includes CAP/KIM
button programming)
“Capabilities and Preferences User Speed Dial tab” on page 63
“Restrictions main tab” on page 67 “Call security: Restriction filters” in
“Restrictions - Set Restrictions
tab” on page 68
“Restrictions - Line/Set
Restrictions tab” on page 69
Click the navigation tree heading to access general information about DN records.
“Default memory button
programming for telephones” on
page 151
“Creating an enhanced CAP station”
on page 233
“System features and feature
codes” on page 35
the BCM 4.0 Networking
Configuration Guide (N0060606)
“Configuring remote access
packages” in the BCM 4.0
Networking Configuration Guide
(N0060606)
“Restrictions (Line and Remote)” in
the BCM 4.0 Networking
Configuration Guide (N0060606)
Main panel tabs: common fields
The Line Access, Capabilities and Preferences, and Restrictions tabs included in the Main panel,
all display the same four columns as shown in Table 8.
N0060600N0060600
Figure 7 Main Panel tabs
Table 8 Common columns for the main panels (Sheet 1 of 2)
Attribute Value Description
Chapter 6 DN records parameters 45
DN <numeric> This number is unique to each telephone record. The number
identifies the telephone to the system. DN start digits and DN length
are configured during system setup.
Digital and analog telephone DNs map one-to-one with ports on
module connections. IP telephone DNs do not map to specific ports;
however, a keycode is required to activate the feature.
Model Analog
7000
7100
7208
7310/7316
7316E
7324
2004/2050
2002
2001
2007
2033
2050
DMC prtb
1110
1120E, 1140E
Other
Name <up to seven alphanumeric
characters>
This heading appears for telephones in the digital DN range, from
the Start DN (default: 221) up to DN 433. Choose the setting that is
appropriate for the telephone you want to configure.
This field is read-only if the telephone is already attached or
registered to the system.
• 7310/7316: also 7406 cordless digital phone
• 7316E: also for 7316E digital phone with KIMs
(Model 7000 phones are supported in Europe only)
Use this field to provide a more specific description of the telephone,
such as the last name of the user, the location, or the actual
extension number if it is different than the DN number.
Also refer to “Programming name display (outgoing)” in the BCM 4.0
Networking Configuration Guide (N0060606).
BCM 4.0 Device Configuration Guide
46 Chapter 6 DN records parameters
Table 8 Common columns for the main panels (Sheet 2 of 2)
Attribute Value Description
Port <port number> This number indicates the port number to which this DN
corresponds.
A group of port numbers relates to a specific station module
installed in your BCM. If you change the DN for a telephone, the port
number remains the same.
If you physically move a telephone with the relocation feature turned
on, the DN transfers to the new port, and the DN for that port
transfers to the vacated location.
Line Access tab
The Line Access tab displays the DNs table. Line access programming is performed using the four
tabs that appear in the details panel when a DN is selected. Refer to Figure 8.
• “Line Access - Properties tab” on page 46
• “Line Access - Line Assignment tab” on page 48
• “Line Access - Line Pool Access tab” on page 50
• “Line Access - Answer DNs tab” on page 51
Line Access - Properties tab
The administrator can use the properties tab to identify the public and private OLI of the selected
DN. You also identify where, and when, calls are forwarded.
N0060600N0060600
Figure 8 Properties tab
Table 9 describes these fields.
Table 9 Line Access tab fields (Sheet 1 of 2)
Chapter 6 DN records parameters 47
Attribute Value Description
Pub. OLI <up to 12 digits> This setting defaults to the DN of the device. The Public Network
Code concatenates to the beginning of this number to create the
entire public network number. The length of this number is
dependent on the country requirements.
This line identification number (OLI) appears on the telephone called
from this telephone over the public network. Also refer to “Public
network settings” in the BCM 4.0 Networking Configuration Guide
(N0060606).
North America: If the OLI contains the public network code, the
information in the Public Network code field is ignored. Therefore, it
is recommended that OLIs be programmed to the public received
number length, only. This allows a global change if the Public
Network Code is changed.
Also refer to “Configuring CLID on your system” in the BCM 4.0
Networking Configuration Guide (N0060606).
Priv. OLI <numeric> Define the originating line identification number (OLI) that appears
on the telephone being called from this telephone over a private
network.
Note: On systems running DID, this field is populated automatically
with the DN.
If the DN length or the Received # length are changed to be different
from each other, this field is cleared.
Also refer to “Configuring CLID on your system” in the BCM 4.0
Networking Configuration Guide (N0060606).
*If your system allows outgoing name and number blocking, the telephone must have a valid OLI.
BCM 4.0 Device Configuration Guide
48 Chapter 6 DN records parameters
Table 9 Line Access tab fields (Sheet 2 of 2)
Attribute Value Description
Fwd No
Answer
Fwd Delay 2, 3, 4, 6, 10 Define the number of rings before the system forwards an
Fwd Busy up to 24 digits Redirect incoming calls when this telephone is busy with another
Fwd All up to 24 digits This setting is the same as using FEATURE 4 at a telephone. When
up to 24 digits Enter the number to which you want to redirect unanswered
incoming calls.
unanswered call.
This heading only appears after you enter a Call Forward No Answer
number and press Enter.
Default: 4
call.
this feature is active, all calls to this telephone are forwarded to the
destination entered in this field.
If you are forwarding calls to a remote location, ensure that you
include the required destination/access codes.
A user can press FEATURE #4 to cancel this feature.
Line Access - Line Assignment tab
Use the line assignment settings to assign physical trunks and target lines to each telephone. Target
lines are used as incoming only. Other lines can be used to both place and answer calls, if they are
configured to do so.
Figure 9 Line Access - Line Assignment tab
N0060600N0060600
Chapter 6 DN records parameters 49
Table 10 describes the fields on this panel.
Table 10 Telephone line assignment fields (Sheet 1 of 2)
Attribute Values Description
Line <read-only> These are the lines on which this telephone can receive calls. If the
line is a two-way line (DID), the user can also use the line to make
calls.
Also refer to “Configuring Lines” in the BCM 4.0 Networking
Configuration Guide (N0060606).
Appearance Type Ring only, Appr&Ring,
Appr only
Appearances
(for target lines, only)
Caller ID set <check box> This prompt only appears for target lines, and for any analog lines
Vmsg Set <check box> Select whether an indicator shows on the telephone for a voice
<1-255> Select the number of appearances of a target line.
Note: Contact your voice message service provider to find out if your voice message service
works with BCM, or if you have any problems with your service.
Select how a call on this line appears on the telephone.
If you choose Appr&Ring or Appr only, you can have as many
simultaneous DID calls as there are target line button appearances.
If you choose Ring only, you can have as many simultaneous DID
calls as you have intercom buttons.
Note: The BCM does not support a mixture of Appr only and Ring
only appearances for the same line.
7000 or 7100 digital phones default to Ring only.
(Model 7000 phones are supported in Europe only)
Note: The number of appearances that can be assigned to a
telephone depends on how many buttons with indicators are
available. Target line appearances cannot overwrite other line
appearances, Answer DNs, Intercom buttons, or assigned
Handsfree button.
that provide CLID through an GATM (not all markets).
When enabled, the telephone displays call information when it is
available for a call before answer.
When disabled, no call information is displayed for this line. Choose
this setting if the telephone does not have a display, or if you do not
want call information displayed to the user. Disabling this function
can reduce system resource requirements.
Note: Only 30 telephones can have this field enabled for any given
line.
message waiting on an external voice message system.
The line must appear on the receiving telephone.
Note: The Message Waiting Indicator (MWI) is currently supported
exclusively by Meridian Mail and CallPilot and SL-100, and
DMS-100.
MCDN note: If your system is part of an MCDN network connected
to a Meridian 1 system, and you are using the voice mail system off
the Meridian 1, you must enable this field.
Analog lines connected to legacy analog ASM station modules, and
analog telephones attached to an ATA device, do not provide visible
message waiting indication. Analog telephones connected to a
GASM8 support message indicators, if the telephone is set up to
receive them.
BCM 4.0 Device Configuration Guide
50 Chapter 6 DN records parameters
Table 10 Telephone line assignment fields (Sheet 2 of 2)
Attribute Values Description
Priv. Received #
(Target lines only)
Pub. Received #
(Target lines only)
Actions
Add To add a line to a telephone:
Delete 1. On the System DNs table (Line access tab), choose the DN record where you want to
These fields reflect the settings defined under target lines.
These are the digit strings that the system uses to identify a call for this telephone.
Refer to “Trunk/Line Data, main panel” in the BCM 4.0 Networking Configuration Guide
(N0060606).
1. On the System DNs table (Line Access tab), choose the DN record where you want to
add lines.
2. Under the Assigned Lines table in the bottom panel, click Add.
3. Enter a line number in the dialog box.
4. Click OK to save the line to the list.
delete lines.
2. On the Assigned Lines table in the bottom panel, select a line you want to delete.
3. Click Delete.
4. Click OK to confirm the selection.
Line Access - Line Pool Access tab
Use the Line Pool Access tab to add line pools to a telephone record.
Figure 10 Line Access - Line Pool Access tab
These shared pools of lines enables many users to use fewer lines for connections, where dedicated
lines are not practical or not desirable. If all lines in the pool are taken, the user receives a busy
signal.
Some trunks, such as PRI and VoIP, must be put into line pools. For outgoing calls, the line pools
are assigned to the telephones that call out over these trunks.
N0060600N0060600
Chapter 6 DN records parameters 51
All lines except PRI and BRI ETSI-QSIG lines are configured in line pools A to O. PRI and BRI
ETSI-QSIG lines can be configured into line pools BLOC-A to BLOC-F.
Table 11 describes the access fields on this panel.
Table 11 Line Pool Access fields
Attribute Values Description
Line Pool <read-only> This is a list of available line pools. Choose the ones that provide the
outgoing call access you want for the telephone.
Actions
Add 1. On the Line Access tab, choose the DN record, to which, you want to add line pools.
2. On the Line Pools Access tab in the bottom panel, click Add.
3. Enter a line pool in the dialog box.
4. Click OK on the dialog box to save the line pool to the list.
Delete 1. On the Line Access tab, choose the DN record, of which, you want to delete line pools.
2. On the Line Pools Access tab in the bottom panel, select a line pool you want to delete.
3. Click Delete.
4. Click Yes .
Line Access - Answer DNs tab
Program a telephone to provide automatic call alerting and call answering for other telephones in
the system. The DNs of the other telephones are referred to as Answer DNs.
Figure 11 Line Access - Answer DNs tab
BCM 4.0 Device Configuration Guide
52 Chapter 6 DN records parameters
Table 12 describes the access fields on this panel.
Table 12 Line Pool Access Fields - Answer DNs
Attribute Values Description
DN <DN number> From the main panel DN list.
Appearance Type Appr&Ring, Appr only,
Ring only
Notes:
Every answer DN you assign to a telephone automatically designates an appearance on the answer telephone
beside a button with an indicator, if one is available. Answer DNs overwrite feature assignments to buttons with
indicators. They do not overwrite line, Hunt group, intercom, or handsfree assignments.
If no buttons are available on the telephone, ensure that you program the Answer DN as Ring only. In that case, when
a call comes in to the other telephone, the user receives a ring tone.
Actions
Add You can add a maximum of eight Answer DNs per telephone.
1. On the Line Access tab, choose the DN record where you want to add Answer DNs.
2. Under the Answer DNs tab, click Add.
3. Enter the appropriate DN in the dialog box.
4. Click OK to save the entry.
5. On the Answer DNs tab, select the Appearance type field beside the Answer DN you just
entered, and choose the appropriate appearance type.
Programming Note: If the telephone has memory buttons with display designators, the
system automatically assigns Answer DNs to buttons starting at the bottom right row of
buttons. If the telephone has Handsfree assigned to a memory button, the Answer DNs start
above that button. If the telephone has no memory buttons with display, ensure that you
choose Ring only as the Appearance type.
Delete 1. On the Line Access tab, choose the DN record where you want to delete Answer DNs.
1. On the Answer DNs tab, select the Answer DN line you want to delete.
2. Click Delete.
3. Click Yes .
Define how calls to the Answer DN will present on this telephone:
Appr&Ring: Call prompt appears beside the Answer DN button, and
the telephone rings.
Appr only: Call prompt appears beside the Answer DN button.
Ring only: Telephone rings.
Capabilities and Preferences main tab
Capabilities settings control how the system interacts with individual telephones, and how the
telephones receive calls.
Preferences control how the telephone itself works. These settings also can be set by users at the
telephones using feature codes.
Modify the Capabilities and Preferences for a particular DN by changing the values on the
following subpanels.
• “Capabilities and Preferences - Properties tab” on page 53
• “Capabilities and Preferences - Capabilities tab” on page 54
• “Capabilities and Preferences - SWCA Call Group tab” on page 57
N0060600N0060600
Chapter 6 DN records parameters 53
• “Capabilities and Preferences - Preferences tab” on page 58
• “Capabilities and Preferences - Button Programming table” on page 60
• “Capabilities and Preferences - Button Programming tab” on page 60
• “Capabilities and Preferences - ATA Settings tab” on page 64
• “Capabilities and Preferences - IP Terminal Details tab” on page 66
Capabilities and Preferences - Properties tab
The Properties settings control how calls are displayed, as well as assignment of control sets to
individual telephones.
Figure 12 Capabilities and Preferences - Properties tab
Table 13 describes the fields shown on the main Capabilities and Preferences tabbed panel.
Table 13 Capabilities and Preferences tabbed panel (Sheet 1 of 2)
Attribute Values Description
Prime Line None, Pool (A to O),
I/C (intercom),
Line: <line number>
Intercom Keys 0 to 8 Assign the number of intercom buttons to a telephone.
Control Set DN: <any telephone
DN>
None
DN:221<start DN>*
Choose the first line that the telephone selects when a call is made. PRI
Bloc pools are not valid selections for a Prime line.
When you assign a line pool as a prime line, the system searches
automatically for an idle line in the pool.
Intercom buttons provide a telephone with access to internal and external
lines, and to line pools.
The Control telephone attribute allows you to define a DN that acts as a
control telephone.
A control telephone is used to enable/disable Scheduled Services, such
as Restriction Services, for the telephones to which it is assigned. For
more information about services, see “System schedule settings and
services scheduling” on page 29.
You can assign several control sets for your system, but you can only
assign one control telephone per DN.
* If you change the Start DN, this number reflects that change.
BCM 4.0 Device Configuration Guide
54 Chapter 6 DN records parameters
Table 13 Capabilities and Preferences tabbed panel (Sheet 2 of 2)
Attribute Values Description
First Display Name
Number
Line
Tips: The Call Information feature displays and toggles between the name and line number for
Call Display information.
Alpha tagging: If you are using the alpha tagging feature, choose Name. Refer to “Using alpha
tagging for name display (incoming)” in the BCM 4.0 Networking Configuration Guide (N0060606).
Auto Called ID <check box> Select whether you want to see on your display the extension number and
Determine the call display information that appears first.
This feature depends on the services to which you subscribe. Call Display
information can contain the name of the caller, the number of the caller,
the name of the line in your BCM where the call enters. For each
telephone, you can determine the call display information that appears
first.
See also “Programming incoming CLID” in the BCM 4.0 Networking
Configuration Guide (N0060606).
name of the telephone you call.
The Auto Called ID set for target lines is the same telephone that has an
appearance on that target line.
Capabilities and Preferences - Capabilities tab
Capabilities settings control how the system interacts with individual telephones, and how the
telephones receive calls.
Note: Not all the fields shown below necessarily appear for any one type
of telephone. Some fields relate to specific models of telephones.
N0060600N0060600
Chapter 6 DN records parameters 55
Figure 13 Capabilities and Preferences - Capabilities tab
Table 14 describes the fields on this panel.
Table 14 Capabilities and Preferences - Capabilities tab (Sheet 1 of 3)
Attribute Values Description
Handsfree None
Standard
Auto
Pickup group None
1 to 9
Page zone Page zone
(1 to 6)
None
Direct dial Set 1 to Set 5
None
None: The handsfree feature is not available on all telephone models (7000
and 7100 digital phones, 2001 IP phones, DMC portables).(Model 7000
phones are supported in Europe only)
Standard: The handsfree feature is activated by pressing a button on the
telephone.
Auto: The handsfree feature is activated when the telephone receives a call.
Note: Handsfree must be enabled on any telephone that allows headsets.
For 7316E digital phones, set Handsfree to Auto.
7406 digital cordless phone: Handsfree must be enabled for this handset to
work.
Speaker volume: Note that the speaker volume returns to the telephone
default setting for each new handsfree call.
Default: Auto
Assigns this telephone to a pickup group (a group where all telephones ring
until one is answered).
Default: None
Assigns this telephone to a page zone.
A zone is any group of telephones that you want to group together for
paging, regardless of their location. You can assign one of six zones to each
telephone.
The maximum number of digital telephones in a page zone is 50.
The maximum number of digital and IP telephones in a page zone is 60.
Default: 1
Defines whether you can call the direct dial telephone from this telephone
using the direct dial digit.
Default: 1
BCM 4.0 Device Configuration Guide
56 Chapter 6 DN records parameters
Table 14 Capabilities and Preferences - Capabilities tab (Sheet 2 of 3)
Attribute Values Description
Intrusion protection
level
HF answerback <check box> Defines whether you can answer automatically a voice call without lifting the
DND on Busy <check box> Defines whether an incoming call rings if you are already on another call.
Paging <check box> Defines whether you can make paging announcements from this telephone.
Auto hold for incoming
page
None
Low
Med
High
<check box> Not selected - If the telephone is active when a page comes in, the page
If the break-in feature is allowed on any private network MCDN lines (PRI
SL-1) assigned to the telephone, you must define the level of intrusion for
each telephone. This determines if the user can use the feature, and to what
degree.
None: feature is turned off, user cannot break in on any calls
Low: user can only break into calls on other telephones with low level
protection
Med: user can break into calls on other telephones with low and
medium-level protection
High: user can break into calls on all other telephones with this feature
Default: None
receiver, or pressing the Handsfree button.
Note: The feature is not available on models 2001, 7000 and 7100
telephones. (Model 7000 phones are supported in Europe only)
Speaker volume: Note that the speaker volume on the telephone returns to
the default volume setting determined by the telephone for each new
handsfree call.
Default: Selected
Default: Cleared
Default: Selected
does not come through the telephone set.
Selected - If the telephone is active when a page comes in, the call is
placed automatically on hold and the page continues.
Note - 7XXX digital phones:
• Condition - When this setting is enabled, an active call is on mute when
the page comes in.
• Results after page - The call is taken off hold, but is no longer muted.
Default: Cleared
Priority call <check box> Defines whether this telephone can interrupt calls or override Do Not
Auto hold <check box> This setting determines if the system automatically places an active call on
Disturb at another telephone.
Default: Cleared
hold if you answer or initiate another call.
If you do not select this box, the system drops the active call, unless you
press the HOLD button first, when you answer a call or initiate another call.
The user can change the Auto hold setting at their telephones by pressing
FEATURE 73.
SWCA note: Ensure this setting is selected for any telephones with
configured System Wide Call Appearance (SWCA) keys. Refer to “Sharing
calls by parking on SWCA buttons” on page 211.
Default: Selected
N0060600N0060600
Chapter 6 DN records parameters 57
Table 14 Capabilities and Preferences - Capabilities tab (Sheet 3 of 3)
Attribute Values Description
Allow redirect <check box> Define whether this telephone allows assigned lines to be redirected.
This must be selected to allow call forwarding outside the network (external
call forward), including calls to a centralized voice mail system over a private
network.
Default: Cleared
Redirect ring <check box> Define whether the telephone rings briefly when a call on one of its lines is
redirected by the Line Redirection feature (FEATURE 84).
Also refer to “Trunk/Line Data, main panel” in the BCM 4.0 Networking
Configuration Guide (N0060606).
Default: Selected
Receive short tones <check box> Analog equipment, which is connected to the system with an internal or
external analog terminal adapter (ATA2), responds only to tone dialing
signals.
Select this setting only if you have analog equipment connected to a station
port.
Default: Cleared
Silent monitor
supervisor
<check box> On two-line display telephones only, you can choose whether the telephone
can be used to allow the Silent Monitor feature. Select the check box to
allow this feature on this telephone.“Silent Monitor” on page 83“Monitoring
Hunt Groups” on page 109.
Default: Cleared
Capabilities and Preferences - SWCA Call Group tab
Although System-wide Call Appearance (SWCA) assignments are meant to be assigned to buttons
with indicators, you can assign SWCA assignments to a telephone without assigning them to
buttons using the fields on this panel. This is useful if you want to use the full range of SWCA
assignments.
Use the SWCA Call Group tabbed panel to enable or disable Call 1 to Call 16 assignments for
each sets. The administrator can configure the 16 SWCA feature codes on all the sets through
administration.
Users can park or retrieve calls on any SWCA assignment, even if the call is not directly assigned
to their telephone. However, the SWCA support codes (FEATURE *520, FEATURE *537 and
FEATURE *538) only search for SWCA assignments that are assigned to the telephone where the
feature is invoked. These codes are required for users who do not have buttons with indicators.
BCM 4.0 Device Configuration Guide
58 Chapter 6 DN records parameters
Figure 14 Capabilities and Preferences - SWCA Call Group tab
Capabilities and Preferences - Preferences tab
The Preferences headings allow you to program the same settings that users can perform at their
telephones, and the settings for configuring a telephone as a hotline. The telset admin options are
available only to digital telephones and IP telephones.
Figure 15 Capabilities and Preferences - Preferences tab panel
Table 15 describes the headings on the Preferences panel.
Table 15 Capabilities and Preferences - Preferences panel fields (Sheet 1 of 3)
Setting Values Description
Language Languages displayed
are based on
telephone capabilities
and system software.
Dialing options Standard dial
Automatic dial
Pre-dial
N0060600N0060600
Choose the language for the telephone display prompts.
Determine how the telephone handles dialed information.
Standard: Lift the receiver and dial.
Automatic dial: Use for devices, such as fax machines where you
want the number to dial out without external cues.
Pre-dial: Dial the numbers, then lift the handset to allow the
telephone to dial the number.
Note: Not all devices show all three options.
Default: Standard dial
Chapter 6 DN records parameters 59
Table 15 Capabilities and Preferences - Preferences panel fields (Sheet 2 of 3)
Setting Values Description
Contrast 1 through 9 Adjust the contrast of the display.
Default: 4
Ring type 1, 2, 3, or 4 Select a distinctive ring pattern type for the telephone.
Default: 1
Distinct rings in use <read-only> This field indicates the distinct ring patterns, if any, are currently in
effect on any lines, telephones, or Hunt groups on the system. Refer
to the Warning below.
Warning:
If you assign a distinctive ring pattern to a telephone, and that distinctive ring pattern has
already been assigned to a line, all lines with that ring pattern will be reset to None.
If you assign a distinctive ring pattern to a line, and that distinctive ring pattern has already
been assigned to a telephone, all telephones with that ring pattern are reset to pattern 1.
You also can assign a distinctive ring pattern to a Hunt group.
Aux. ringer <check box> Determine whether an auxiliary ringer (if installed) rings for
Call log options No autologging
No one answered
Unanswered by me
Log all calls
Log space <numeric> Allocate a number of Call log spaces from a system-wide pool of
Log space <numeric> Allocate a number of Call log spaces form a system-wide pool or
Available log space <read-only> This setting indicates the total amount of space available for call
Reset Call Log
Password
Hotline type None
• Internal DN:*
<button> This button resets the password for the call log if users forget their
Internal
External
Direct dial set
incoming calls at this telephone.
Default: Cleared
Select how you want the telephone to handle logging calls.
No autologging: No calls are logged automatically.
No one answered: Unanswered calls are logged.
Unanswered by me: Unanswered calls are logged.
Log all calls: All calls are noted in the call log.
Also refer to “Call log” on page 214.
Default: No one answered
spaces to the telephone. Also refer to “Setting call log space for the
system” on page 214.
spaces to the telephone. Also refer to “Setting call log space for the
system” on page 214.
logging on the system.
password.
This feature allows you to define a telephone number that
automatically dials when you lift the handset or press the Handsfree
button, on a telephone.
Default: None
Define the internal telephone you want to access.
DN:* The DN of the telephone that is automatically dialed when the
user lifts the handset.
Direct dial set: Automatically dials a telephone on the system
defined as a direct dial telephone (direct dial access code).
Note: If the direct dial telephone is on a remote node of the
network, ensure that the correct line pools are assigned to the
telephone to properly route the call.
BCM 4.0 Device Configuration Guide
60 Chapter 6 DN records parameters
Table 15 Capabilities and Preferences - Preferences panel fields (Sheet 3 of 3)
Setting Values Description
• External External number Enter the complete call number for the external telephone you want
to access.
Pool:A
Use prime line
Use routing table
Enter the line you want the call to use. (This cannot be a target line.)
Pool:A Refer to the line pool assignment for this telephone.
Use prime line: Refer to the General record for this telephone.
Use routing table: Refer to the routing tables. The routing code for
that table must be part of the External number.
Also refer to:
• “Moving IP telephones” in the BCM 4.0 Telephony Device Installation Guide (N0060609).
Capabilities and Preferences - Button Programming table
Figure 16 Capabilities and Preferences - Button Programming Table
Capabilities and Preferences - Button Programming tab
The Button Programming and CAP/KIM Button Programming tab panels allow you to program
the buttons on a telephone with internal and external autodialers, and with programmed feature
keys.
You also can use these panels to remove programming from a button, making it blank.
N0060600N0060600
Chapter 6 DN records parameters 61
Figure 17 Button Programming and CAP/KIM Button Programming tabbed panels
Assigned lines, Hunt group designators, Answer DNs buttons, Intercom buttons, and Handsfree
buttons cannot be changed through these panels. They appear in read-only format.
BCM 4.0 Device Configuration Guide
62 Chapter 6 DN records parameters
Table 16 describes the possible settings for telephone buttons.
Table 16 Button programming fields (Sheet 1 of 2)
Setting Values Description
Model 7100
7208
7310/7316
7316E
7324
2004/2050
2001
2002
2007
2033
DMC prtb
1110
1120E, 1140E
2210
2211
2212
ISDN These telephones have their own set of DN records.
Other This heading is used for the following types of devices:
Button Number (1-24) <1-XX> Use the telephone buttons to choose the features you want to
Function Blank
Feature
Internal autodial
External autodial
Val ue
Feature <feature code> Use the arrow to choose the feature you want to program on
If you have not yet connected a telephone, choose the model
of the telephone. This creates a number of defaults based on
the telephone capabilities.
This setting reflects whatever you set on the main table.
This field is read-only if the telephone is already attached or
registered to the system.
• 7310 also refers to the cordless 7406 cordless digital
phones.
• 7316E indicates both a stand-alone 7316E digital phone
and a 7316E digital phone connected to one or more Key
Indicator Modules (KIMs)
• 2002, 2004, IP phones connect to the Key Expansion
Module (KEM)
• ISDN refers to any ISDN equipment
• analog telephones
• Intl set (European only) is used for other types of
compatible telephones used in specific non-North
American markets, such as the 7000 digital phone.
program.
Blank means that nothing is programmed on the button.
Example: New KIM modules have all blank buttons when they
are first installed.
Choose the type of feature that you want to program on the
telephone buttons.
Blank means that nothing is programmed on the button.
Example: New KIM modules have all blank buttons when they
are first installed.
Note: If nothing is programmed, the Business Series Terminals
(BST series) set shows a BLF on the associated internal
autodial key when off hook.
the button.
Internal autodial <Internal DN> Enter the DN number for the internal telephone you want the
Digits
Feature <feature digits> Includes digits for such features as system speed dial codes.
telephone to dial by pressing this button.
N0060600N0060600
Table 16 Button programming fields (Sheet 2 of 2)
Setting Values Description
Chapter 6 DN records parameters 63
External autodial <dialing codes plus dialout
Option
Feature <feature options> Includes settings such as page zone.
External autodial
facility
string>
Use prime line
Pool
Use routing table
Use line
Enter the complete dial sequence for the external call. This
sequence depends on what you chose for the route in the
Value field.
Choose the route through which the telephone dials.
Prime line: the prime line assigned to the telephone.
Pool X: one of the pools assigned to the telephone.
Routing table: enter the routing code with the external
telephone number.
Use line X: one of the lines assigned to the telephone.
Capabilities and Preferences - User Speed Dial tab
The speed dial numbers enables users to dial a number with fewer button presses than dialing the
entire dial string.
Note: User speed dials are only available from that users DN number.
Figure 18 Capabilities and Preferences - User Speed Dial tab
Table 17 describes the fields on this panel.
Table 17 Capabilities and Preferences - User Speed Dial panel fields (Sheet 1 of 2)
Setting Values Description
Speed Dial
Number
External
Number
<71-94> The number the user enters to dial the number entered in the External #
<external telephone
number>
field. To increase the number of speed dials refer to “Configuring system
speed dial numbers” on page 87.
Enter the number the telephone automatically dials when the user speed
dial code is entered.
Note: Include the access codes for the route you choose.
BCM 4.0 Device Configuration Guide
64 Chapter 6 DN records parameters
Table 17 Capabilities and Preferences - User Speed Dial panel fields (Sheet 2 of 2)
Setting Values Description
Facility Use prime line
Use routing table
Actions
Add 1. On the Capabilities and Preferences tab, choose the DN record where you want to add User
Speed dials.
2. Under the User Speed Dial Numbers table, click Add.
3. Enter the appropriate speed dial number.
4. Click OK.
5. On the User Speed Dial, click the External Number field beside the number you entered.
6. Enter an external number to dial.
7. Click the Facility field beside the number you entered.
8. Enter how the number must be routed out of the system.
Delete 1. On the Capabilities and Preferences tab, choose the DN record where you want to delete User
Speed dial entries.
2. On the User Speed Dial Numbers table, click the user speed dial code or codes that you want to
delete.
3. Click Delete.
4. Click Yes .
Select the route you want the dialed number to take out of your system.
Note: Any line numbers or line pool codes that you specify must be
assigned to the telephone where the code is entered.
If you choose prime line, a prime line must be assigned to the telephone
where the code is entered.
Refer to “Line Access - Line Assignment tab” on page 48.
Capabilities and Preferences - ATA Settings tab
Analog telephones have some settings that are specific to the analog connection. An analog
telephone can be connected to the system directly through an analog station port, either on the
Main Unit (in countries that support Main Unit Analog Stations) or through Analog Station Media
Bay Modules. These settings apply only when the DN record Model field is set to analog.
Analog telephones can also be connected by using an Analog Terminal Adapter (ATA2). The
digital station port can be on the main unit, or on a Digital Station Media Bay Module.
N0060600N0060600
Figure 19 Capabilities and Preferences - ATA Settings panel fields
Use the information in Table 18 to configure ATA settings.
Table 18 ATA settings
Attribute Values Description
Chapter 6 DN records parameters 65
ATA answer
timer
ATA tones <check box> Not selected: No tones occur when a message is received (use for data equipment).
ATA use On site
Msg indicate None
ATA device Modem
Disconnect
supervision
3, 5, 7, 10 Select the length of delay between the time you dial the last digit and when the
Off site
Tone
Lamp
Telephon
<check box> If you have a modem or fax machine that does not disconnect automatically when
analog device is ready to receive DTMF tone.
Default: 7
Selected: Tones occur when a message is received (use for analog telephones).
Default: Cleared
Select the location of the ATA2.
Note: Set the field to On site for all installations, except devices on a long loop. Set
the field to Off site to increase the audio level to devices that are remote to the
ATA2. This field has no effect for ASM and ASM8+ devices.
Note: OPX connections are not supported.
Default: On site
Select Tone to send a Message Tone through the telephone receiver when you
receive a message.
Select Lamp to turn on the Message Lamp when you receive a message.
Default: None
Devices connected to the system through an ATA can have connectivity issues over
BRI/PRI lines. To alleviate this, you can specify the type of device attached to the
analog line.
Modem supports 3.1 kHz audio, which requires a higher quality of service on the
ISDN trunks that modems and FAX machines require for reliable information
transfer. If the trunks cannot provide the higher level of service, the call fails.
Telephon supports speech paths, which require less quality on the trunk; if used for
FAX and/or modem, information transfer is unreliable.
Default: Modem
the caller disconnects, you can select this feature; the system then disconnects the
line from the device when it receives the disconnect signal from the far end. This
feature is supported only by ASM8+ modules.
Note: The line must be configured as supervised/guarded. Refer to “Properties” in
the BCM 4.0 Networking Configuration Guide (N0060606).
Default: Cleared
BCM 4.0 Device Configuration Guide
66 Chapter 6 DN records parameters
Capabilities and Preferences - IP Terminal Details tab
This is a single-terminal display of the terminal information that is also shown in the Telephony
Resources IP Terminal panel. Refer to “IP telephone set details” in the BCM 4.0 Networking
Configuration Guide (N0060606) for a detailed description of the fields and buttons on this panel.
Figure 20 Capabilities and Preferences - IP Terminal Details panel
The field is described in Table 19.
Table 19 Capabilities and Preferences - IP Terminal Details
Keep DN alive <check box> This feature is relevant only to the Nortel IP telephones.
When selected, the system retains the IP telephone DN record, even if the IP
telephone becomes disconnected. Retention occurs as long as the IP
telephone has completed the bootup process. It allows DN-specific features,
such as Call Forward No Answer and Call Forward on Busy, to continue to
function even if the telephone is disconnected.
WAR NING: If the system is reset, and the IP telephone is disconnected, the
feature remains inactive until the telephone is reconnected.
Note: A delay of about 40 seconds occurs between the time when the IP
telephone is disconnected and when Keep DN alive becomes active. During
this period, incoming calls receive a ring back tone, or are rerouted to the
prime set, depending on system programming. The delay also occurs when
the IP telephone is reconnected to the system.
If Keep DN alive is not selected, and the IP telephone is disconnected, the
DN record becomes inactive. In this case, a
produced when special features, such as Call Forward, are invoked.
Default: Cleared
Not in Service prompt is
N0060600N0060600
Restrictions main tab
Use the Restrictions settings to control callouts of certain number combinations. These restriction
filters are then assigned to lines and DN records, as required to prevent callers from making certain
kinds of calls from a specific telephone, or from lines available at the telephone.
Modify the restrictions settings by changing the values in the following subpanels:
• Restrictions - Properties
• “Restrictions - Set Restrictions tab” on page 68
• “Restrictions - Line/Set Restrictions tab” on page 69
Restrictions - Properties
You can assign restrictions to individual DNs. Select the permission level of the DN user to
modify features.
Figure 21 Restrictions - Properties
Chapter 6 DN records parameters 67
Table 20 describes the fields on this panel.
Table 20 Restriction - Set Restrictions tab (Sheet 1 of 2)
Setting Values Description
Set Lock None
Partial
Full
Allow Last Number <check box> Allow or disallow access to the Last Number Redial feature.
Choose the option that sets the amount of programming and customizing the
user can do with this telephone.
None allows access to all features.
Partial prevents:
• programming autodial buttons
• programming user speed dial
numbers
• programming feature buttons
• moving line buttons
• changing the display language
• changing dialing modes
(Automatic, Pre-, and Standard
Dial)
• using Voice Call Deny
• saving a number with Saved
Number Redial
Full restricts all the Partial settings,
plus:
• changing background music
• changing Privacy
• changing Do Not Disturb
• using Ring Again
• using Call Forward all calls
• using Send Message
• using Trunk Answer
• activating Services
BCM 4.0 Device Configuration Guide
68 Chapter 6 DN records parameters
Table 20 Restriction - Set Restrictions tab (Sheet 2 of 2)
Setting Values Description
Allow Saved
Number
Allow Link <check box> Select to allow access to the Link feature, which is a host signaling option.
<check box> Select to allow access to the Saved Number Redial feature.
Restrictions - Set Restrictions tab
You can assign restrictions that apply to a specific telephone record. You also can assign a
different restriction filter for Normal service, and for one or more of six other schedules that
enables the user to have different access at different times of the day. See “System schedule
settings and services scheduling” on page 29for more information about schedules.
Figure 22 Restrictions - Set Restrictions tab
Table 21 describes the fields on this panel.
Table 21 Restrictions - Set Restrictions tab fields
Setting Values Description
Schedule Normal
<Sched 1-6>
Use Filter <XX> Enter the restriction filter you want to be active for each schedule that you
The Normal schedule runs when no other schedules are active.
If schedules are being used, select the relevant schedule, and enter the
required filter.
use.
N0060600N0060600
Chapter 6 DN records parameters 69
Table 22 provides a list of default restriction filters.
Table 22 Schedule filter defaults
Schedule Restriction filter (defaults) Schedule Restriction filter (defaults)
Normal 02 Schedule 4 00
Schedule 1 (Night) 11 Schedule 5 00
Schedule 2 (Evening) 12 Schedule 6 00
Schedule 3 (Lunch) 13
Restrictions - Line/Set Restrictions tab
Use the Line/Set Restrictions settings to assign a restriction filter to a specific line for outgoing
calls at a specific telephone. This type of filter replaces any line or set restriction filters that can
otherwise apply. Line/Set restrictions restrict the numbers the user can dial on a line, but only from
that telephone. The same line on another telephone can have different restrictions.
You can apply a different line restriction for normal service, and for each of the six schedules.
Figure 23 Restrictions - Line/Set Restrictions panel
Table 23 describes the fields on this panel.
Table 23 Restrictions - Line/Set Restrictions fields (Sheet 1 of 2)
Setting Values Description
Line <XXX> A list of lines assigned to this telephone. Define a restriction filter for each line
under the schedules that you intend to use.
Restriction filters are defined under Call Security. Refer to “Defining restriction
filters” in the BCM 4.0 Networking Configuration Guide (N0060606).
BCM 4.0 Device Configuration Guide
70 Chapter 6 DN records parameters
Table 23 Restrictions - Line/Set Restrictions fields (Sheet 2 of 2)
Setting Values Description
Schedule Normal
Night
Evening
Lunch
Sched 4
Sched 5
Sched 6
Use Filter <XX> Enter the restriction filter you want activated for this set on this line for each
Always configure a Normal filter, as this schedule runs if there are no other
schedules running.
If your system is using schedules (for example, if you require different
restrictions on lines at different times of the day), choose an alternate
schedule that coordinates with the other programmed schedules on your
system.
schedule that you use.
N0060600N0060600
Chapter 7
Common procedures: copying and renumbering DNs
Task: Understanding common tasks
• “Copying settings to other DNs” on page 71
• “Renumbering DNs” on page 72
Copying settings to other DNs
The Copy command allows you to duplicate programming for a telephone, and apply it to another
telephone, a range of telephones, or to all the telephones on the system. If information is copied to
a record with an assigned telephone, the copy information replaces the existing settings.
Note: Unique configurations, such as the Name, do not copy over.
71
To copy telephone configurations
1 Select Configuration > Telephony > Sets > All DNs.
2 Click the DN number for the record that has the settings you want to copy.
3 Click Copy.
4 Select the DN to which you want to apply the selected settings.
Note: Select multiple DNs by holding down the control or shift key, and
clicking multiple records.
5 Click Paste. The following panel appears:
BCM 4.0 Device Configuration Guide
72 Chapter 7 Common procedures: copying and renumbering DNs
Figure 24 Paste Set Data dialog box
6 Select the check boxes for the properties that you want to copy to the new DN.
7 Click OK.
Renumbering DNs
Your system auto-assigns DNs based on the hardware for digital telephones. In the case of IP
telephones, you can choose to auto-assign DNs when the telephones register to the system.
When you change a DN, the DN record retains the same port number, because the telephone is not
being moved physically. The original DN then assigns to the port vacated by the DN that you
assign as the new DN. If you fill the DN/Port record in the Programming Records, remember to
change the entries.
Change telephone DNs using the Element Manager
There are two panels in Element Manager from which you can change the DN setting:
• Element Manager: Configuration > Telephony > Sets > Active Sets
• Element Manager: Configuration > Telephony > Dialing Plan
The procedure is the same in both panels.
To change telephone DNs
1 Double-click the DN you want to change.
2 Type the number of the DN you want to assign to the set.
3 Press Tab, or click in another field, to apply the selection.
N0060600N0060600
Chapter 8
Global telephony settings
There are a number of settings that define telephony operation for the entire system. These have
been gathered on one panel, separated into sections.
The following paths indicate where to access global telephony settings in Element Manager and
through Telset Administration:
• Element Manager: Configuration > Telephony > Global Settings > Feature Settings
• Telset interface: **CONFIG > System Prgrming
Click one of the following links to connect with the type of information you want to view:
Panels and Details Panels Configure Features
“Feature Settings” on page 74
“Feature Settings panel” on page 75 “Selecting the music source” on page 284
“Timers” on page 78 “Camp-on” on page 209
“Advanced Feature Settings” on page 80
“ONN Blocking (North American systems)” on
page 82
“Silent Monitor” on page 83 “Capabilities and Preferences - Capabilities tab”
“Reset logs” on page 84 “Capabilities and Preferences main tab” on
73
“Programming Business name display
(outgoing)” in the BCM 4.0 Networking
Configuration Guide (N0060606)
“Call Park” on page 210
“Directed Pickup” on page 198
“Holding calls” on page 204
“Transfer (unanswered) calls” on page 206
“Paging” on page 219
“Receiver volume” on page 193
“Answer DNs” on page 200
“External call codes” on page 227
“Call Park” on page 210
“Callback” on page 211
“Configuring an analog telephone” on page 118
“Sharing calls by parking on SWCA buttons” on
page 211
“Blocking outgoing name display at the
telephone” in the BCM 4.0 Networking
Configuration Guide (N0060606)
on page 54 (Supervisor sets)
“Monitoring external hunt group calls” on
page 109
page 52 (Set log space)
“Call log” on page 214
Click the navigation tree heading to access general information about user management.
BCM 4.0 Device Configuration Guide
74 Chapter 8 Global telephony settings
The global telephony settings affect a number of different telephony features.
• Business Name: This is part of the CLID feature. It displays the business name on outgoing
calls for all system telephones, on which CLID is allowed and activated.
• Feature settings: These affect different aspects of how various features act, or if they are
allowed on the system.
• Timers provides timeout parameters for different types of telephony features.
• System wide call appearance (SWCA) fields determine how the telephones will relate calls to
SWCA assignments.
Note: The Enhanced BLF_UPDATE message is broadcast to support
more than 256 stations. The message is broadcast to all stations but is
accepted only by Juniper sets.
Feature Settings
Refer to the following for a description of the fields in each segment of this panel.
• “Feature Settings panel” on page 75
• “Timers” on page 78
• “System Wide Call Appearances Control” on page 80
• “ONN Blocking (North American systems)” on page 82
N0060600N0060600
Feature Settings panel
These settings affect all telephones. They determine whether the listed features are allowed, or
how they function.
Figure 25 System feature settings
Table 24 describes each field.
Chapter 8 Global telephony settings 75
Table 24 Feature settings (Sheet 1 of 3)
Attribute Value Description
Business Name <Maximum of 8
alphanumeric
characters>
Feature Settings
Background music <check box> Select to enable the caller to listen to music through your telephone
Page tone <check box> Select to sound a tone before a page begins. Also refer to “Paging” on
*Conference Tone <check box> Select to enable a conference tone that is heard by participants at the
Enter a maximum of eight alphanumeric characters.
Refer to “Programming Business name display (outgoing)” in the
BCM 4.0 Networking Configuration Guide (N0060606).
speaker after pressing FEATURE 86 on your telephone. A music
source must be connected to system. Refer to the BCM200/400 4.0
Installation and Maintenance Guide (N0060612) for information about
installing an external music source.
Also refer to “Selecting the music source” on page 284.
page 219.
Note: This tone is not heard over external page ports.
beginning of the conference.
*Only available in certain profiles, UK, Germany, and Italy.
BCM 4.0 Device Configuration Guide
76 Chapter 8 Global telephony settings
Table 24 Feature settings (Sheet 2 of 3)
Attribute Value Description
Message reply
enhancement
Force auto/speed dial
over ic/conf
On hold Silence
Held line reminder Immediate
Delayed ring transfer Off
<check box> Select to enable users to automatically deactivate the message
<check box> Determine if autodial and speed dial codes can be transmitted during
Tones
Music
After 30 seconds
After 60 seconds
After 90 seconds
After 120 seconds
After 150 seconds
After 180 seconds
Off
After 1 ring
After 2 rings
After 3 rings
After 4 rings
After 6 rings
After 10 rings
waiting indicator on analog telephones connected to an analog
station media bay module (ASM), if the reply call from the analog
telephone to the direct dial telephone is answered. Any telephone can
answer the call.
This feature also functions if the user invokes the Call pickup feature
to answer the reply call from the analog telephone. However, it does
not work with the Retrieve parked call feature.
Note: ASM (analog station modules) are not supported in all
countries.
Tips: Only direct dial telephones can send messages (using F1) to
analog telephones connected to an
ASM/GASM. The direct dial set must be the designated direct dial
telephone for the analog telephone receiving a message.
an active call. This feature works during either a one-to-one call, or
during a conference call.
If selected: When the user presses a programmed autodial or speed
dial key, the system dials out the number while maintaining the
current call.
If not selected: When the user presses a memory key for a speed
dial, the current call is automatically placed on Hold, and the second
call is dialed.
Note: This feature cannot be used for an ad hoc multi-party
conference.
Select what a caller hears on an external line when the line is put on
hold.
Silence provides no audio feedback.
Ton es provides a periodic tone.
Music provides any signal from a source such as a radio connected
to BCM or streaming audio. See “Selecting the music source” on
page 284.
Reminds you that an external call at your telephone is still on Hold.
You periodically hear two tones from your telephone until you take the
call off Hold.
Note: These tones can be heard by the caller.
Defines whether unanswered external calls are forwarded
automatically to a prime telephone after this timer expires.
You must assign a prime telephone for this feature to operate. Refer
to the BCM 4.0 Networking Configuration Guide (N0060606) for
information on how to assign a prime telephone.
Default: After 4 rings
N0060600N0060600
Table 24 Feature settings (Sheet 3 of 3)
Attribute Value Description
Chapter 8 Global telephony settings 77
Park mode Lowest
Cycle
Maximum CLI per line 30 (read-only) This setting indicates the maximum number of telephones that
Answer keys Basic
Enhanced
Extended
Receiver volume Use sys volume
Use set volume
Directed pickup <check box> If selected: allows anyone to answer any calls by specifying the
Set relocation <check box> If selected: Set relocation, after you perform the telephone installation
Alarm set DN: <number> Assign a device on which alarm messages appear when a problem is
Determine how the system assigns a retrieval code to parked calls.
Lowest, the system chooses the lowest code that is available when
the call is parked.
Cycle, the system chooses the codes in a sequence, from lowest to
highest, until all the codes have been used, then start at the lowest
code again.
Also refer to “Common dialing plan settings” in the BCM 4.0
Networking Configuration Guide (N0060606) (Call Park access code)
and “Timers” on page 78 (Park timeout).
Default: Lowest
displays CLID simultaneously for an incoming call.
The Answer keys setting allows you to determine what types of calls
alert at a telephone that has answer DNs assigned. Answer key
changes do not apply to portables.
Warning: Do not change the default setting (Basic) if you have
Contact Center active on your system.
Refer to “Answer DN answer key levels” on page 78 for attributes of
each setting.
Also refer to “Line Access - Answer DNs tab” on page 51.
Default: Basic
Specify if the volume level of a receiver or headset returns to the
system default level when a call ends or is put on hold, or if it remains
at the volume level set at the individual telephone.
Default: Use sys volume
internal number (DN) where the call is ringing.
Directed pickup is useful when not all the telephones have the same
lines, but you want to allow co-workers to answer a call on any
external line.
Note: Do not confuse Directed pickup with the Group pickup feature.
Group pickup allows you to answer a call at any telephone within a
specific group, without specifying the internal number (DN) of the
ringing telephone.
Default: Selected
and programming, for more flexibility in testing equipment. You can
move any digital telephone to a new location without losing the
directory number, autodial settings, personal speed dial codes, and
any programming for that telephone.
Not selected: Set relocation while moving a telephone, the internal
number and programming data remain with the physical port on BCM.
When you connect the telephone somewhere else, it does not receive
the original programming. A telephone that is plugged into the original
jack downloads the programming. If the new telephone is a different
model, it downloads the part of the programming that is the same for
both models.
Default: Cleared
detected in the system.
BCM 4.0 Device Configuration Guide
78 Chapter 8 Global telephony settings
Answer DN answer key levels
You can determine what type of calls alert at an assigned Answer DN key. This is a system setting,
so all Answer DNs behave the same.
There are three answer key levels: Basic, Enhanced, and Extended. If your system supports
overflow routing of calls (for example, Hunt groups), the setting is Enhanced or Extended.
Alternatively, if Contact Center telephones are assigned Answer DNs, this setting must be Basic.
Do not change this setting unless you understand the impact on the other telephone groups in your
system.
In Table 25, the X indicates the type of calls that are handled at Answer DNs for each answer key
level.
Table 25 DN answer key levels
Answer DN call response for: Basic Enhanced Extended
Prime set call capture X
Overflow call routing calls X X
Call forwarded calls X
Ringing service calls X
Callbacks X
Blind transferred calls X X
Other answer key calls
Priority calls
Voice calls
All other calls X X X
Also refer to:
• “Line Access - Answer DNs tab” on page 51
• “Telephony features” on page 191
Timers
Various system features require timeout parameters to close the feature.
N0060600N0060600
Figure 26 System Timers
Table 26 describes the timers.
Table 26 Timer values
Attribute Values Description
Chapter 8 Global telephony settings 79
Camp timeout 30, 45, 60, 90, 120, 150,
or 180
Park timeout 30, 45, 60, 90, 120, 150,
180, 300, or 600
Page timeout 15, 30, 60, 120, 180,
300, 600, or 2700
Transfer
callback
timeout
*Network
Callback
Host delay 200, 400, 600, 800,
Link time 100, 200, 300, 400, 500,
After 3 rings
After 4 rings
After 5 rings
After 6 rings
After 12 rings
Off
<XX seconds> Determine the timeout value when a transfer attempt stops and then
1000, 1200, 1400, 1600,
1800 or 2000
600, 700, 800, 900, or
1000 milliseconds
Assign the number of seconds before an unanswered camped call returns
to the telephone that camped the call. Also refer to “Camp-on” on
page 209.
Default: 45 seconds
Assign the number of seconds before a parked call on an external line
returns to the telephone which parked the call. This interval is used for
SWCA lines as well. Also refer to “Call Park codes” in the BCM 4.0
Networking Configuration Guide (N0060606).
Default: 45 seconds
Define the period of time after which the paging feature automatically
disconnects. Also refer to “Paging” on page 219.
Default: 180 seconds
Specify the number of rings before a callback occurs on a transferred call.
You can estimate the delay in seconds, if you multiply the number of rings
by six.
Note: This setting can affect transferred calls from voicemail and must be
configured accordingly.
Also refer to “Line Access tab” on page 46(Call forward).
Default: After 4 rings
attempt a retry of the transfer.
*Not available in all region profiles.
Assign the delay between the moment an outgoing line is selected to make
an external call (for example, by lifting the receiver) and the moment that
BCM sends dialed digits or codes on the line.This ensures that a dial tone
is present before the dialing sequence is sent. Minimizing this delay
provides faster access to the requested features.
Default: 1000 milliseconds
Specify the duration of a signal required to access a feature through a
remote system.
Link time depends on the requirements of the host switching system. For
example, to program external dialing through a Centrex system, a Link
time of 400 ms is required.
Note: Link is another name for recall or flash.
Default: 600 milliseconds
BCM 4.0 Device Configuration Guide
80 Chapter 8 Global telephony settings
Advanced Feature Settings
The following path indicates where to access advanced feature settings in Element Manager:
• Element Manager: Configuration > Telephony > Global Settings > Advanced Feature
Settings
The Advanced Feature Settings panel enables administrators to modify the following features:
• System Wide Call Appearances Control
• “ONN Blocking (North American systems)” on page 82
• “Silent Monitor” on page 83
• “Reset logs” on page 84
System Wide Call Appearances Control
There are a number of ways that calls can be parked on System Wide Call Appearance (SWCA)
assignments. Use this panel to set the system feature function.
Figure 27 System Wide Call Appearances controls
Table 27 describes the fields on this panel.
Table 27 SWCA controls (Sheet 1 of 2)
Attribute/Value Description
Auto-associate SWCA key to call
Manually - while parked
Manually - life of call
Automatically - life of call
Manually - while parked: The user either presses a free SWCA key on the
telephone, or dials the feature code for a free key. Once the call is retrieved, it is
unassigned from the SWCA key.
Manually - life of call: The user either presses a free SWCA key on the telephone, or
dials the feature code for a free key. When the call is retrieved, it remains assigned
to the SWCA key. The key is freed only after the call is terminated.
Automatically - life of call: When a call is answered, it is automatically assigned to a
free SWCA key, starting with the lowest available number. When the call is retrieved,
it remains assigned to the SWCA key. The key is freed when the call is terminated.
Include I/C calls when auto-associating
<check box>
Select how a call is parked on a SWCA key.
Default: Manually - while parked.
Decide if you want intercom calls to automatically park on
SWCA keys.
N0060600N0060600
Table 27 SWCA controls (Sheet 2 of 2)
Attribute/Value Description
If you select the check box...
Auto-associate SWCA key to call must be set to Automatically - Life of call
for this feature to work.
When the user makes a call using the intercom button, the call automatically
associates with a free SWCA key, and remains assigned for the duration of the
call.
If you do not select the check box...
The user must assign manually an intercom call to a SWCA key.
The call will behaves otherwise by the rules of the choice made for Associate
SWCA key to call.
Invoke SWCA parking by Hold
<check box>
If you select the check box...
When the user presses Hold, the system attempts to repark the call on the
current SWCA key assigned to the call, or on a free SWCA key programmed on
the telephone.
If no SWCA is currently associated with the call (Automatically - life of call is not
turned on), and there is no free SWCA key to assign to the call, the call remains
on Hold on the line on which it enters.
Note: In this case, the call is not available to other telephones in the group until
it can be assigned to a SWCA key, or unless they have the same line
appearance as the held call.
If you do not select the check box...
There is no interaction with SWCA keys. The call remains on Hold on the line on
which it enters, and is not available to other telephones in the SWCA group,
unless the user manually assigns the call to a SWCA key, or unless those
telephones have the same line appearance as the held call.
Include I/C calls when invoking by Hold
<check box>
If you select the check box...
Invoke SWCA parking by Hold must be checked to activate this feature.
When the user makes an intercom call, and puts it on Hold, the call works in the
same manner as described in Invoke SWCA parking by Hold, selected.
If you do not select the check box...
Intercom calls are held on the local line, regardless of whether you select the
Invoke SWCA parking by Hold.
If the intercom call is assigned to a SWCA key automatically, you can press the
SWCA key to repark the call, and make it available to other telephones in the
group.
If you manually assign the intercom call to a SWCA key, the call is parked
automatically, and it becomes available to the rest of the group.
Choose whether calls that are placed on hold are assign
automatically to a SWCA key.
Choose whether intercom calls put on Hold are assigned
automatically to a SWCA key.
Chapter 8 Global telephony settings 81
Also refer to:
• “Common dialing plan settings” in the BCM 4.0 Networking Configuration Guide
(N0060606)(Call Park codes)
• “Timers” on page 78 (Park timeout)
BCM 4.0 Device Configuration Guide
82 Chapter 8 Global telephony settings
• “Sharing calls by parking on SWCA buttons” on page 211
• System Wide Call Appearance (SWCA) Features Card
ONN Blocking (North American systems)
The outgoing name and number blocking codes for Analog and BRI lines can vary between
service providers. This panel allows you to enter the code provided, so this feature works correctly
over the network.
Figure 28 ONN Blocking codes for Tone, Pulse and BRI trunks
Table 28 describes these trunks.
Table 28 ONN Blocking values
Attribute Values Description
Tone <feature digits> Specify a code that allows users to block outgoing name and number
Pulse <feature digits> Specify a code that allows users to block outgoing name and number
BRI <feature digits> Specify a code that allows users to block outgoing name and number
display over an analog tone line.
display over an analog pulse line.
display over a BRI trunk.
Also refer to:
• “Protecting outgoing call privacy” on page 217.
N0060600N0060600
Silent Monitor
The features in this dialog box provide the parameters that determine how you can use supervisor
terminals on your system to monitor Hunt group members (“Monitoring external hunt group calls”
on page 109).
Figure 29 Silent Monitor settings
Table 29 describes the fields in this dialog box.
Table 29 Silent Monitor system settings
Field Values Description
Chapter 8 Global telephony settings 83
Monitoring mode Non silent
Silent
Number of SM sets <1 to 30> Indicate the number of two-line telephones in your system that you
SM password XXXXXX Enter a six-digit password that must be entered after the supervisor
Choose Non silent if you want the hunt group member and the
caller to hear a conference tone when a supervisor breaks into a
hunt group conversation.
Choose Silent if you want supervisors to be able to break into a hunt
group conversation without giving an indicator of their presence.
Note: Initial monitoring is muted at the supervisor set. If the
supervisor wants to speak within the conversation, a display key on
the two-line display becomes available, once the connection is
established.
The default changes based on country profile.
will allow to be used as supervisory telephones. Default: 5
presses FEATURE *550. To maintain system security, change this
password frequently.
Default: 745368 (SILENT)
BCM 4.0 Device Configuration Guide
84 Chapter 8 Global telephony settings
Reset logs
You can reset the log cache on the system by using the button on the Advanced Features Settings
panel.
Figure 30 System log reset
Table 30 describes the fields in this box.
Table 30 Silent Monitor system settings
Field Values Description
Reset Logs button Opens Reset Call Log Space dialog box.
Reset Call Log Space dialog box
Space per log <Space=number of calls> Enter amount of space each telephone that supports logs
has.
# of sets with logs <digits> Indicate the number of telephones that will create call logging.
Also refer to:
• “Monitoring Hunt Groups” on page 109
N0060600N0060600
Chapter 9
Telephony system and device programming
The following list provides links to the telephone and telephony system programming areas of the
system.
Within the context of the network, system telephones act as call end points or call initiation
devices.
• To make or receive calls, telephones must be set up with the correct line assignments.
• To make calls, users must know the correct destination codes and dial strings to reach other
internal or external devices.
Refer to the BCM 4.0 Networking Configuration Guide (N0060606) for connections to the
sections that describe line setup and numbering plans.
How telephones handle incoming and outgoing call traffic is determined by telephone features.
Some telephone features are set up for the entire system, while other parameters are configured on
a per-device basis.
85
System-wide telephony feature configuration
The system telephony settings must be set correctly to ensure that telephones can be
programmed correctly.
• “Global telephony settings” on page 73
Telephone record configuration
When the system features are determined, the telephone DN records allow you to refine how
each telephone interacts with the system. DN record configuration can depend on what
features you want to allow users to access, or what features the type of telephone can support.
• “DN records parameters” on page 43
• “Common procedures: copying and renumbering DNs” on page 71
• “Configuring telephones: Digital telephones” on page 121
• “Configuring analog telephones and devices” on page 117
• “DN records: ISDN devices” in the BCM 4.0 Networking Configuration Guide (N0060606)
• “Configuring telephones: IP telephones” on page 137
• “Download firmware to a Nortel IP telephone” on page 149
Optional system features:
There are also several optional telephony system features that you can use to enhance the
telephone system.
— “Configuring system speed dial numbers” on page 87
— “Creating ring groups” on page 97
BCM 4.0 Device Configuration Guide
86 Telephony system and device programming
— “System schedule settings and services scheduling” on page 29
— “Configuring Hunt Groups” on page 101
— “Configuring Hospitality services” on page 111
— Voice mail, if applicable
Also refer to:
• “Telephony features” on page 191
N0060600N0060600
Chapter 10
Configuring system speed dial numbers
System speed dial codes are assigned to external numbers. You can use then the two- or three-digit
code to dial the number, or assign the code to a memory button, instead of dialing the entire string.
These assignments are the same for all users in the system.
The following paths indicate where to access system speed dial programming in Element Manager
and through Telset Administration:
• Element Manager: Configuration > Telephony > Global Settings > System Speed Dial
• Telset interface: **CONFIG > System Speed dials
Panels/Subpanels Configuring features and tasks
“System Speed Dial panel” on page 87 “Using alpha tagging for name display (incoming)” in the
BCM 4.0 Networking Configuration Guide (N0060606)
“Capabilities and Preferences - Button Programming tab” on
page 60
“Programming memory buttons” on page 226
“Speed dialing” on page 225
Click the navigation tree heading to access general information about Hospitality services.
87
System Speed Dial panel
This panel allows you to determine the number of speed dial codes on the system, and what each
code dials.
BCM 4.0 Device Configuration Guide
88 Chapter 10 Configuring system speed dial numbers
Figure 31 System Speed Dial table
Table 31 describes each field on this panel.
Table 31 System Speed Dial (Sheet 1 of 2)
Attribute Values Description
Number of speed
dials
CLID match length <3-8>
System Speed Dials table
Speed Dial
Number
External Number <dial string (max. 24
70
255
None
<001-070 or 001-255> Displays dial codes for the System Speed Dial list.
digits)>
Choose the number of speed dial codes you want available to your
system users.
If you are using alpha tagging, you can choose the larger list to
accommodate your incoming call requirements. Also refer to “Using
alpha tagging for name display (incoming)” BCM 4.0 Networking
Configuration Guide (N0060606).
Indicate the number of digits, starting from the right of the dial
string, that the system needs to match between an incoming call
and a system speed dial listing to prompt the alpha tagging display.
When a match is made, the system provides a name or number
display for any calls coming in over analog lines that allow number
CLID.
Also refer to “Using alpha tagging for name display (incoming)”
BCM 4.0 Networking Configuration Guide (N0060606).
Default: 8
Displays the number the system dials when the code is entered.
Remember to include required destination codes.
N0060600N0060600
Table 31 System Speed Dial (Sheet 2 of 2)
Chapter 10 Configuring system speed dial numbers 89
Facility Use prime line
Use line
Pool code
Use routing table
Display Digits, Name Digits = the speed dial number displays
Name <alphanumeric> Enter a descriptive name for the owner or business code dials.
Bypass restrictions <check box> Disabled = the dialed number uses the line and set restrictions
Select the route you want the dialed number to remove from your
system.
Note: Any lines or pool codes that you specify must be assigned to
the telephone where the code is entered.
If you choose prime line, a prime line must be assigned to the
telephone where the code is entered.
Refer to “Line Access tab” on page 46.
Name = the first 16 characters of the name defined for the speed
dial displays
Note: For alpha tagging, this is the name that the system displays if
there is a number match with an incoming call.
Enabled = the dialed number bypasses any line and set restrictions
Notes about the System Speed Dial list
The following provides general notes about using the System Speed Dial panel.
Choose the size of the speed dial list
• The default list consists of 70 speed dial codes from 01 to 70.
• If you set Number of speed dials to 255, the codes are 001 to 255.
If you want to use alpha tagging (see “Using alpha tagging for name display (incoming)” in
the BCM 4.0 Networking Configuration Guide (N0060606)), you can increase the number of
codes to allow for more matching possibilities for incoming calls.
Note: If the number of speed dial numbers is increased from 70 to 255,
the system speed dial codes are three digits. For example speed dial
numbers 01-40 become, 001-040. The user speed dial numbers remain
two digits.
Programming System speed dials
System speed dials are programmed under Configuration > Telephony > Global Settings >
System Speed Dial, where you specify the internal or external dialed number, a name, and
whether you want the system to ignore dialing restrictions.
System Speed Dials:
• Provide a list of codes and numbers to your users.
BCM 4.0 Device Configuration Guide
90 Chapter 10 Configuring system speed dial numbers
Working with speed dial list entries
To add, change, or delete System Speed Dial records, click the field you want to alter, and type in
the change required.
Caution: Resource issue
Entering a large number of system speed dials at one time can impact system performance.
Therefore, it is best to perform this activity during low-user periods, whenever possible.
Next steps
Speed dial codes can be programmed onto memory keys by the installer during button
programming. Refer to “Capabilities and Preferences - Button Programming tab” on page 60.
Also, each user can assign speed dial codes directly to memory buttons on the telephone. Refer to
the “Programming memory buttons” on page 226 for instructions on using memory keys.
For information on using speed dials, and for programming speed dial codes at the telephone, refer
to “Speed dialing” on page 225.
Ensure that you publish a list of system speed dial codes for the users. The Programming Records
( **session save selected data) allow you to keep a record of these codes.
Also refer to:
• “User speed dials” on page 134
N0060600N0060600
Chapter 11
DMC Feature List
The Digital Mobility Controller (DMC) Feature list enables you to arrange the order of the features
that appear as soft keys on a Digital Mobility 7420/7430/7440 handset. This is a system-wide
feature that enables users to access frequently used features.
The following paths indicate where to access the DMC Feature List in Element Manager and in
telset administration:
• Element Manager: Configuration > Telephony > Global Settings > DMC Feature List
•Telset Admin: **CONFIG > System Programming > DMC Feat List
The following features are available in the following default positions:
• Position 1: PARK (Call Park, F74)
• Position 2: PAGE (General Page, F60)
• Position 3: VM (Voicemail login, F981)
• Position 4: CFAC (Call Forward, F4)
• Position 5: PKUP (Group Pickup, F75)
91
BCM 4.0 Device Configuration Guide
92 Chapter 11 DMC Feature List
Arranging the DMC Feature list using Element Manager
Figure 32 DMC Feature List panel
To arrange the DMC Feature list using Element Manager
1 Click Configuration > Telephony > Global Settings > DMC Feature List.
The Digital Mobility Controller Feature List panel appears.
2 In the Position 1 field, select the feature from the list.
Note: The feature currently in that position swaps positions with the
selected feature.
3 Select the order of the features in Positions 2 through 5.
Note: If you do not want to program all five features, None is also an
option.
N0060600N0060600
Chapter 12
Setting up central answering positions
A CAP (Central Answering Position) station acts as a central answering and monitoring point for a
group or a business.
The following paths indicate where to set up a CAP in Element Manager and through Telset
Administration:
• Element Manager: Configuration > Telephony > Global Settings > CAP Assignment
• Telset interface: **CONFIG > System programing > CAP/KIM assignment
Click one of the following links to connect with the type of information you want to view:
Panels Tasks
“Configuring CAP assignments (eCAPs)” on page 94 “Programming CAP/KIM buttons” on page 95
“Managing lines on a KIM” on page 96
93
“DN records parameters” on page 43
“Moving line buttons” on page 193
See also:
Click the navigation tree heading to access general information about user management.
CAPs become enhanced CAPs (eCAPs) when you identify the telephone DN under the CAP/KIM
assignment. You can configure a maximum of 12 CAPs as eCAPs on the system.
All CAPs can be programmed with quick dial numbers that allow the person at this station to
monitor and answer call traffic into the group. If you program the CAP to be an eCAP, lines, hunt
group appearances, and line appearances can also be moved to the module.
Also refer to the following topics:
• “Configuring CAP assignments (eCAPs)” on page 94
• “Managing lines on a KIM” on page 96
• “Programming CAP/KIM buttons” on page 95
“Hunt Group members and lines” on page 105
BCM 4.0 Device Configuration Guide
94 Chapter 12 Setting up central answering positions
Figure 33 7316E with KIM
7316E digital phone
with one KIM
Configuring CAP assignments (eCAPs)
Use the CAP Assignment panel to designate 7316E+KIM units as eCAPs. The following
procedures describe how to use the fields on the CAP Assignment panel.
Figure 34 CAP Assignment panel
N0060600N0060600
Chapter 12 Setting up central answering positions 95
To create CAP stations
1 Ensure that the telephone you want to use is configured and working on the system.
Note: CAPs are available only on T7316E and M7324 digital sets and
2002, 2004, and 2007 IP sets.
2 Ensure that the KIM is installed on the appropriate telephone.
Refer to the installation user card that came with the module, if necessary.
3 On the CAP Assignment table, click the line for the CAP you want to configure as an eCAP.
4 Select the Set DN field and type the DN for the telephone.
CAP notes
• If CAPs are not designated as eCAPs, the system can support as many CAPs as the system
resources can support. The modules on these caps are referred to as ordinary KIMs (OKIMs),
and the buttons on the module support only memory button programming.
• A Station Auxiliary Power Supply (SAPS) is not required for 7316E digital phones attached to
four or fewer KIMs. If the KIMs are designated as eKIMs, you can only attach a maximum of
four modules to a 7316E. If the KIMs are designated as OKIMs, you can attach up to nine
modules to the 7316E. You must add a SAPS if more than four KIMs are added to the 7316E.
Note also that the line loop to the CAP cannot be greater than 304.8 m (1000 feet).
• If a KIM module is relocated with the telephone, the settings are retained on the module.
• Replacing CAPs: If you replace a legacy eCAP (7324+CAP) with a 7316E+eKIM, the line
assignments are copied to the new telephone, but not to the eKIM. The telephone
programming reverts to the default settings for other buttons. Also, if you move an eKIM from
one 7316E to another, programming does not follow.
If you move an OKIM from one 7316E to another, the KIM retains memory button
programming.
• Legacy equipment notes: A SAPS is required for 7324 digital phones that have one or more
CAP modules attached.
Programming CAP/KIM buttons
Designating features or autodial numbers to the eKIM buttons can be performed using the
CAP/KIM Button Programming panel.
To program module buttons
1 Click Configuration > Telephony > Sets > Active Sets:
2 Click the Capabilities and Preferences tab.
3 Select the DN for the CAP you want to configure.
BCM 4.0 Device Configuration Guide
96 Chapter 12 Setting up central answering positions
4 In the lower panel, click the CAP/KIM Button Programming tab.
5 Select the line for the button number that you want to program.
6 Configure the feature or autodial on the button.
For a detailed description of each field, refer to “Capabilities and Preferences - Button
Programming tab” on page 60.
Note: You cannot assign lines, target lines, or Hunt group indicators using button
programming. These must be performed through assigning lines to the telephone (“Line
Access - Line Assignment tab” on page 48), and, for hunt groups, configuring the
telephone as a Hunt group member (“Hunt Group members and lines” on page 105). These
lines are either moved to the modules, or overflow to the module, if the telephone buttons
cannot accommodate the new settings.
You cannot assign Hunt group DNs as an autodial button on the KIM modules.
Managing lines on a KIM
If the 7316E+KIM is configured as an eCAP, you can move lines onto the module using
FEATURE *81 on the telephone. You can also reassign Hunt group designators to the KIM
module by using the same feature.
You can also force lines onto the KIM by assigning more lines than the telephone buttons can
support. Extra lines automatically flow over to the module; however they flow sequentially,
starting on the top left at button 01. Also, they overwrite any existing programming on the KIM,
except existing line or hunt group (KIM) assignments.
Any of the buttons, without assigned lines, can be programmed to dial internal or external numbers
automatically, or to access a feature. Refer to “Programming CAP/KIM buttons” on page 95.
N0060600N0060600
Chapter 13
Creating ring groups
Assigning telephones to ringing groups provides a way to ensure that all calls can be answered,
regardless of the time of day, or day of the week. The most common use of this feature is when a
security desk telephone rings for incoming lines after 5:00 p.m., a practice often called night
service.
The following paths indicate where to configure ring groups in Element Manager and through
Telset Administration:
• Element Manager: Configuration > Telephony > Ring Groups
• Telset interface: **CONFIG > Services > Ringing service > Ringing Groups
Click one of the following links to connect with the type of information you want to view:
Panels Configure Tasks or Features
“Ring Groups - Members” on page 98 “Configuring scheduled service” on page 32
“Ring Groups - Line Settings tab” on page 99
Click the navigation tree heading to access general information about Ring Group management.
97
Each non-auto-answer line and target line can be assigned a ringing group for each schedule. If no
schedule is set for ringing services, lines ring at any telephones with the lines assigned.
Note: VoIP trunking lines and PRI lines are set automatically to auto-answer
and, therefore, require target lines. BRI lines set to auto-answer also ring at
target lines. Therefore, by specifying target lines in a ring group, all
auto-answer lines can be forwarded to the telephones indicated.
BCM 4.0 Device Configuration Guide
98 Chapter 13 Creating ring groups
Ring Groups - Members
The Ring Groups table on the Group Membership tab in the top frame of this panel is a read-only
list of the 100 ring groups available to the system.
When you click a ring group in the table, the Members table appears in the bottom panel.
The Group Membership panel allows you to define which telephones belong to each ring group.
A DN can be associated with multiple ring groups.
Figure 35 Adding members to ring groups
Table 32 describes the fields on this panel.
Table 32 Ring groups panel (Sheet 1 of 2)
Attribute Value Description
Ring Groups
Ring Group <read-only> This is a list of the available ring groups for the system.
Members
DN <DN digits> These are the DNs for the telephones that are part of the ringing group selected
in the table in the top frame.
N0060600N0060600
Chapter 13 Creating ring groups 99
Table 32 Ring groups panel (Sheet 2 of 2)
Attribute Value Description
Actions
Add 1. In the top panel, click the ring group where you want to add telephones.
2. In the bottom panel, click Add.
The Add Member dialog box appears.
3. Enter a DN that you want to associate with the ring group.
4. Click OK to save the new members setting.
Delete 1. In the top panel, click the ring group where you want to delete telephones.
2. On the Members table, click one or more DNs that you want to delete from the group.
3. Click Delete.
4. Click Yes .
Ring Groups - Line Settings tab
The Line Settings tab allows you to schedule where calls coming in on a specific line, or target
line, ring during a scheduled period.
The following paths indicate where to configure line settings for ring groups in Element Manager
and through Telset Administration:
• Element Manager: Configuration > Telephony > Ring Groups
• Telset interface: **CONFIG > Lines
There are two frames on this panel:
• The top panel displays all lines that are available for programming as part of the ring group.
This does not include VoIP trunks and PRI lines. For both these types of lines, you would use
target lines.
• When you select a line on the top panel, the Lines Settings panel appears in the bottom of the
panel. Use this table to specify schedule settings for each line.
BCM 4.0 Device Configuration Guide
100 Chapter 13 Creating ring groups
Figure 36 Ring Group lines
Table 33 describes the headings on both these panels.
Table 33 Ringing group schedule line values
Attribute Value Description
Lines Settings tab:
Line XXX This list includes all analog and digital lines plus the target lines (PRI and
Line Settings panel:
Schedules <read-only> You only need to configure the schedules that you use for your system.
Ring Group Ring Group <XXX> Type in a ring group number (001-100).
Aux. Ringer <check box> This variable indicates whether the auxiliary ringer (if installed) also rings
VoIP lines). Program only those that are active on the system.
Only one ring group can be assigned to a line for each schedule. To combine
groups of ringing sets, you must create a new Ring Group that contains all the
sets you want to ring, and assign it to the line.
when Ringing service is on.
Tips:
• The default ringing telephone is 221 (Start DN). This means that all lines
ring at telephone 221 when Ringing service is on.
• If you have an auxiliary ringer programmed to ring for calls on an external
line, and you transfer a call on that line without announcing the transfer,
the auxiliary ringer rings for the call transfer.
Also refer to:
• “Configuring scheduled service” on page 32
N0060600N0060600
Loading...
