AutoPage RS-750 Instruction
PROGRAMMING THE XT-75LCD TWO-WAY LCD SCREEN REMOTE TRANSMITTER
Important Note: This program mode is for XT-75LCD two-way LCD transmitter programming only; do not program
other style transmitter on this mode.
Note: This mode will only retain the last 2 remote transmitters programmed. If the transmitter memory is exceeded, the
security system will start deleting transmitters from memory in chronological order.
The two-way LCD screen remote transmitter can be program to operate this system. The two-way remote transmitter
actively gives an immediate report to the remote transmitter on any violations occurred to your vehicle both by visual
graphic icon and audio sound.
When you press a button of a two-way remote transmitter, you can make sure that your command has been correctly
delivered to the system in your vehicle. The LCD screen will display a graphic icon as well as a confirming melody sound
from your two-way remote transmitter.
Enter:
1. Turn the Ignition 'switch ‘OFF/ON’ 3 TIMES and stay in ON position. Within 15 seconds.
2. Push the Valet switch 6 times holding in on the 6th push, until long chirp is heard. Then release the valet switch. You
are now in the two-way LCD screen remote Transmitter programming mode.
Program:
1. Press the Lock button on the transmitter until the siren responds with a confirming chirp; the first transmitter is now
programmed.
2. Press the Lock button on the second transmitter until the siren responds with a confirming chirp; the second transmitter
is now programmed.
Exit:
Turn Ignition to 'OFF' position, or leave it for 15 seconds. 3 long chirps & 3 parking light flashes will confirm exit.
Note: A Maximum of (2) two-way LCD screen remote transmitters can be programmed.
XT-75LCD TWO-WAY LCD SCREEN REMOTE TRANSMITTER
Note: This mode will only retain the last 4 remote transmitters
programmed. If the transmitter memory is exceeded, the security
system will start deleting transmitters from memory in chronological
order
Programming the XT-75s Standard transmitter
Important Note: This program mode is for XT-75S remote transmitter programming only; do not program the
XT75LCD two-way transmitter on this mode.
Enter:
1. Turn the Ignition 'switch ‘OFF/ON’ 3 TIMES and stay in ON position. Within 15 seconds.
2. Push the Valet switch 3 times holding in on the 3rd push, until long chirp is heard. Then release the valet switch. You
are now in the Transmitter programming mode.
Program:
1. Press any button on transmitter one until the siren responds with a confirming chirp. The first transmitter is now
programmed.
2. Press any button on the second transmitter until the siren responds with a confirming chirp, the second transmitter is
now programmed.
3. Apply the same procedure to program 3rd and 4th
Exit:
Turn Ignition to 'OFF' position, or leave it for 15 seconds. 3 long chirps & 3 parking light flashes will confirm exit.
.
