Configuration Note

AudioCodes Mediant™ Family of Media Gateways & Session Border Controllers

Connecting AudioCodes' SBC with Analog Device to Microsoft Teams Direct Routing Enterprise Model

Version 7.2

Page 2

Page 3

Configuration Note Contents

1 Introduction ......................................................................................................... 7

1.1 About Microsoft Teams Direct Routing .................................................................... 7

1.2 About AudioCodes SBC Product Series .................................................................. 7

1.3 Validated AudioCodes SBC Version ........................................................................ 8

2 Topology Example .............................................................................................. 9

2.1.1 Enterprise Model Implementation .............................................................................. 9

2.1.2 Environment Setup .................................................................................................. 11

2.1.3 Infrastructure Prerequisites ..................................................................................... 11

3 Configuring Teams Direct Routing .................................................................. 13

3.1 Prerequisites .......................................................................................................... 13

3.2 SBC Domain Name in the Teams Enterprise Model .............................................. 13

3.3 Configuration Example of Office 365 Tenant Direct Routing ................................. 14

3.3.1 Online PSTN Gateway Configuration ...................................................................... 14

3.3.2 Online PSTN Usage Configuration .......................................................................... 14

3.3.3 Online Voice Route Configuration ........................................................................... 15

3.3.4 Online Voice Routing Policy Configuration .............................................................. 15

3.3.5 Enable Online User .................................................................................................. 15

3.3.6 Assigning Online User to the Voice Route .............................................................. 15

3.3.7 Analog Device Voice Route Configuration .............................................................. 16

3.3.8 Configure with User Management Pack 365 (Optional) .......................................... 16

4 Configuring AudioCodes SBC ......................................................................... 17

4.1 SBC Configuration Concept in Teams Direct Routing ........................................... 17

4.2 IP Network Interfaces Configuration ...................................................................... 18

4.2.1 Configure VLANs ..................................................................................................... 18

4.2.2 Configure Network Interfaces .................................................................................. 19

4.3 SIP TLS Connection Configuration ........................................................................ 20

4.3.1 Configure the NTP Server Address ......................................................................... 20

4.3.2 Create a TLS Context for Teams Direct Routing ..................................................... 21

4.3.3 Configure a Certificate ............................................................................................. 22

4.3.4 Method for Generating and Installing the Wildcard Certificate ................................ 25

4.3.5 Deploy Baltimore Trusted Root Certificate .............................................................. 26

4.4 Configure Media Realms ........................................................................................ 27

4.5 Configure SIP Signaling Interfaces ........................................................................ 28

4.6 Configure Proxy Sets and Proxy Address .............................................................. 29

4.6.1 Configure Proxy Sets ............................................................................................... 29

4.6.2 Configure a Proxy Address ...................................................................................... 30

4.7 Configure Coders ................................................................................................... 32

4.8 Configure IP Profiles .............................................................................................. 35

4.9 Configure IP Groups .............................................................................................. 39

4.10 Configure SRTP ..................................................................................................... 41

4.11 Configuring Message Condition Rules ................................................................... 42

4.12 Configure Classification Rules ............................................................................... 43

4.13 Configure IP-to-IP Call Routing Rules .................................................................... 45

4.14 Configure Firewall Settings .................................................................................... 47

Version 7.2 3 AudioCodes Mediant SBC

Page 4

Teams Direct Routing & Analog Devices

5 Verify the Pairing Between the SBC and Direct Routing ............................... 49

6 Verify ATA Registered Users in the SBC ........................................................ 51

A Configuring MP-1xx ATA for Connecting Analog Devices ............................ 53

A.1 Configure Proxy Server and Registration ............................................................... 53

A.2 Configure the Endpoint Phone Number Table ....................................................... 54

A.3 Configure the Hunt Group ...................................................................................... 55

A.4 Configure IP-to-Hunt Group Routing ...................................................................... 55

A.5 Configure SIP UDP Transport Type and Fax Signaling Method ............................ 56

B Configuring MP-20x ATA for Connecting Analog Devices ............................ 57

B.1 Configure SIP Interface Settings ............................................................................ 57

B.2 Configure Media Streaming Parameters ................................................................ 58

B.3 Configuring Line Settings ....................................................................................... 59

C Syntax Requirements for SIP Messages 'INVITE' and 'OPTIONS' ................. 61

C.1 Terminology ........................................................................................................... 61

C.2 Syntax Requirements for 'INVITE' Messages ........................................................ 61

C.3 Requirements for 'OPTIONS' Messages Syntax .................................................... 62

C.4 Connectivity Interface Characteristics .................................................................... 63

AudioCodes Mediant SBC 4 Document #: LTRT-33426

Page 5

Configuration Note Notices

Notice

Information contained in this document is believed to be accurate and reliable at the time of printing. However, due to ongoing product improvements and revisions, AudioCodes cannot guarantee accuracy of printed material after the Date Published nor can it accept responsibility for errors or omissions. Updates to this document can be downloaded from

https://www.audiocodes.com/library/technical-documents.

This document is subject to change without notice.

Date Published: August-13-2020

WEEE EU Directive

Pursuant to the WEEE EU Directive, electronic and electrical waste must not be disposed of with unsorted waste. Please contact your local recycling authority for disposal of this product.

Customer Support

Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service Partner. For more information on how to buy technical support for AudioCodes products and for contact information, please visit our website at

https://www.audiocodes.com/services-support/maintenance-and-support

Stay in the Loop with AudioCodes

Abbreviations and Terminology

Each abbreviation, unless widely used, is spelled out in full when first used.

Version 7.2 5 AudioCodes Mediant SBC

Page 6

Teams Direct Routing & Analog Devices

(added note for Baltimore

Document Revision Record

LTRT Description

33421 Initial document release for Version 7.2. Teams Enterprise Model.

33422 Modified Section: Deploy Baltimore Trusted Root Certificate

Trusted Root Certificate and MTLS implementation).; Configure SIP Signaling Interfaces; Configure IP Groups

33423 Note removed regarding external firewall.

33424 Licenses consolidated into one section.

33425

33426 Update to the “Related Documentation” table to include the Mediant 1000B Gateway

Update to topology figures and correction for parameter “Remote Update Support” to “SIP UPDATE Support”.

& E-SBC product.

Documentation Feedback

AudioCodes continually strives to produce high quality documentation. If you have any comments (suggestions or errors) regarding this document, please fill out the Documentation Feedback form on our website at https://online.audiocodes.com/documentation-feedback

AudioCodes Mediant SBC 6 Document #: LTRT-33426

Page 7

Configuration Note 1. Introduction

1 Introduction

This Configuration Note describes an example setup of the AudioCodes Enterprise Session Border Controller (hereafter, referred to as SBC) for interworking between Company's SIP Trunk, ATA device and Microsoft's Teams Direct Routing environment. For configuring the Office 365 side, please refer to

us/microsoftteams/direct-routing-configure.

This document is intended for IT or telephony professionals.

1.1 About Microsoft Teams Direct Routing

Teams Direct Routing allows connecting a customer-provided SBC to the Microsoft Phone System. The customer-provided SBC can be connected to almost any telephony trunk, or connect with third-party PSTN equipment. The connection allows:

 Using virtually any PSTN trunk with Microsoft Phone System

 Configuring interoperability between customer-owned telephony equipment, such as

third-party PBXs, analog devices, and Microsoft Phone System

1.2 About AudioCodes SBC Product Series

https://docs.microsoft.com/en-

AudioCodes' family of SBC devices enables reliable connectivity and security between the Enterprise's and the service provider's VoIP networks.

The SBC provides perimeter defense as a way of protecting Enterprises from malicious VoIP attacks; mediation for allowing the connection of any PBX and/or IP-PBX to any service provider; and Service Assurance for service quality and manageability.

Designed as a cost-effective appliance, the SBC is based on field-proven VoIP and network services with a native host processor, allowing the creation of purpose-built multiservice appliances, providing smooth connectivity to cloud services, with integrated quality of service, SLA monitoring, security and manageability. The native implementation of SBC provides a host of additional capabilities that are not possible with standalone SBC appliances such as VoIP mediation, PSTN access survivability, and third-party value-added services applications. This enables Enterprises to utilize the advantages of converged networks and eliminate the need for standalone appliances.

AudioCodes SBC is available as an integrated solution running on top of its field-proven Mediant Media Gateway and Multi-Service Business Router platforms, or as a software-only solution for deployment with third-party hardware. The SBC can be offered as a Virtualized SBC, supporting the following platforms: Hyper-V, AWS, AZURE, AWP, KVM and VMWare.

Version 7.2 7 AudioCodes Mediant SBC

Page 8

Teams Direct Routing & Analog Devices

AudioCodes sales

1.3 Validated AudioCodes SBC Version

Microsoft has successfully conducted validation tests with AudioCodes' Mediant SBC Ver. 7.20A.250. Previous firmware versions may run successfully; however, Microsoft did not test such versions. For updated list refer to

for Direct Routing.

Note: For implementing Microsoft Teams Direct Routing based on the configuration

described in this document, AudioCodes SBC must be installed with a License Key that includes the following features:

• MSFT (general Microsoft license)

Note: By default, all AudioCodes media gateways and SBCs are shipped with this license (except MSBR products, Mediant 500 SBC, and Mediant 500 Media Gateway).

• SW/TEAMS (Microsoft Teams license)

• Number of SBC sessions (based on requirements)

• Transcoding sessions (only if media transcoding is needed)

• Coders (based on requirements)

For more information about the License Key, contact your representative.

List of Session Border Controllers certified

AudioCodes Mediant SBC 8 Document #: LTRT-33426

Page 9

Configuration Note 2. Topology Example

SIP Trunk

Enterprise Network

DMZ

Manag ement

Stat ion (OAMP)

ITSP

IP-PBX

Anal og D evice s

ATA

Session Bor der Controller

LAN

PSTN

Internet

Phone System

Firew all

2 Topology Example

Teams Direct Routing can be implemented in the Enterprise or Hosting Models.

2.1.1 Enterprise Model Implementation

The interoperability example between AudioCodes SBC and Company SIP Trunk with Teams Direct Routing Enterprise Model assume the following topology setup:

 Enterprise deployed with ATA, connected analog devices and the administrator's

management station, located on the LAN

 Enterprise deployed with Teams Phone System Direct Routing Interface located on

the WAN for enhanced communication within the Enterprise

 Enterprise wishes to offer its employees enterprise-voice capabilities and to connect

the Enterprise to the PSTN network using Company's SIP Trunking service

 AudioCodes SBC is implemented to interconnect between the SIP Trunk and Teams

Direct Routing located in the WAN

The figure below illustrates this topology example:

Figure 2-1: Connection Topology with SIP Trunk on the LAN

Version 7.2 9 AudioCodes Mediant SBC

Page 10

Teams Direct Routing & Analog Devices

SIP Trunk

Enterprise Network

DMZ

Manag ement

Stat ion (OAMP)

ITSP

IP-PBX

Anal og D evice s

ATA

Session Bor der Controller

LAN

PSTN

Internet

Phone System

Firew all

Figure 2-2: Connection Topology with SIP Trunk on the WAN

AudioCodes Mediant SBC 10 Document #: LTRT-33426

Page 11

Configuration Note 2. Topology Example

Company SIP Trunk operates with RTP media type

2.1.2 Environment Setup

The example topology includes the following environment setup:

Table 2-1: Environment Setup

Area Setup

Network

 Teams Direct Routing environment is located on the Enterprise'

(or Service Provider’s) WAN

 Company SIP Trunk is located on the LAN

Signaling Transcoding

Codecs Transcoding

 Teams Direct Routing operates with SIP-over-TLS transport type  Company SIP Trunk operates with SIP-over-UDP transport type

 Teams Direct Routing supports G.711A-law, G.711U-law, G.729

and SILK (NB and WB) coders

 Company SIP Trunk supports G.711A-law, G.711U-law, and

G.729 coders

Media Transcoding

 Teams Direct Routing operates with SRTP media type



2.1.3 Infrastructure Prerequisites

The table below shows the list of infrastructure prerequisites for deploying Teams Direct Routing.

Table 2-2: Infrastructure Prerequisites

Infrastructure Prerequisite Details

Certified Session Border Controller (SBC)

SIP Trunks connected to the SBC

Office 365 Tenant

Domains

Public IP address for the SBC

Fully Qualified Domain Name (FQDN) for the SBC

Public DNS entry for the SBC

Public trusted certificate for the SBC

Firewall ports for Direct Routing Signaling

Firewall IP addresses and ports for Direct Routing Media

Media Transport Profile

Firewall ports for Teams Clients Media

See Microsoft's document Plan Direct Routing

Version 7.2 11 AudioCodes Mediant SBC

Page 12

Teams Direct Routing & Analog Devices

This page is intentionally left blank.

AudioCodes Mediant SBC 12 Document #: LTRT-33426

Page 13

Configuration Note 3. Configuring Teams Direct Routing

3 Configuring Teams Direct Routing

This section describes an example of Teams Direct Routing configuration to operate with AudioCodes SBC.

3.1 Prerequisites

Before you begin configuration, make sure you have the following for every SBC you want to pair:

 Public IP address

 FQDN name matching SIP addresses of the users

 Public certificate, issued by one of the supported CAs

3.2 SBC Domain Name in the Teams Enterprise Model

The SBC domain name must be from one of the names registered in 'Domains' of the tenant. You cannot use the *.onmicrosoft.com tenant for the domain name. For example, in Figure 3-1, the administrator registered the following DNS names for the tenant:

Table 3-1: DNS Names Registered by an Administrator for a Tenant

DNS name

ACeducation.info Yes Valid names:

adatumbiz.onmicrosoft.com No

hybridvoice.org Yes Valid names:

Users can be from any SIP domain registered for the tenant. For example, you can provide users user@ACeducation.info names are registered for this tenant.

Can be used

for SBC FQDN

with the SBC FQDN sbc1.hybridvoice.org so long as both

Examples of FQDN names

 sbc.ACeducation.info  ussbcs15.ACeducation.info  europe.ACeducation.info

Invalid name: sbc1.europe.ACeducation.info (requires

registering domain name europe.atatum.biz in 'Domains' first)

Using *.onmicrosoft.com domains is not supported for SBC names

 sbc1.hybridvoice.org  ussbcs15.hybridvoice.org  europe.hybridvoice.org

Invalid name: sbc1.europe.hybridvoice.org (requires registering

domain name europe.hybridvoice.org in 'Domains' first

Version 7.2 13 AudioCodes Mediant SBC

Page 14

Teams Direct Routing & Analog Devices

Figure 3-1: Example of Registered DNS Names

During creation of the Domain you will be forced to create public DNS record (sbc1.hybridvoice.org in our example.)

3.3 Configuration Example of Office 365 Tenant Direct Routing

Note: This section shows an example only. For more detailed information please refer

to Microsoft Site: https://docs.microsoft.com/en-us/microsoftteams/direct-routing-

configure

3.3.1 Online PSTN Gateway Configuration

Use following PowerShell command for creating new Online PSTN Gateway:

New-CsOnlinePSTNGateway -Identity sbc1.hybridvoice.org -SipSignallingPort 5068 ForwardCallHistory $True -ForwardPai $True -MediaBypass $True -Enabled $True

3.3.2 Online PSTN Usage Configuration

Use following PowerShell command for creating an empty PSTN Usage: Set-CsOnlinePstnUsage -Identity Global -Usage @{Add="Interop"}

AudioCodes Mediant SBC 14 Document #: LTRT-33426

Page 15

Configuration Note 3. Configuring Teams Direct Routing

3.3.3 Online Voice Route Configuration

Use following PowerShell command for creating new Online Voice Route and associate it with PSTN Usage:

New-CsOnlineVoiceRoute -Identity "audc-interop" -NumberPattern "^\+" OnlinePstnGatewayList sbc1.hybridvoice.org -Priority 1 -OnlinePstnUsages "Interop"

3.3.4 Online Voice Routing Policy Configuration

Use following PowerShell command for assigning the Voice Route to the PSTN Usage:

New-CsOnlineVoiceRoutingPolicy "audc-interop" -OnlinePstnUsages "Interop"

Use the following command on the Teams Direct Routing Management Shell after reconfiguration to verify correct values:

Get-CsOnlinePSTNGateway

Identity : sbc1.hybridvoice.org Fqdn : sbc1.hybridvoice.org SipSignallingPort : 5068 CodecPriority : SILKWB, SILKNB, PCMU, PCMA ExcludedCodecs :

FailoverTimeSeconds : 10 ForwardCallHistory : True ForwardPai : True SendSipOptions : True MaxConcurrentSessions : Enabled : True MediaBypass : True

Note: The commands specified in Sections 3.3.5 and 3.3.6, should be run for each

Teams user (excluding ATA device users) in the company tenant.

3.3.5 Enable Online User

Use following PowerShell command for enabling online user:

Set-CsUser -Identity user1@company.com -EnterpriseVoiceEnabled $true - HostedVoiceMail $true -OnPremLineURI tel:+12345678900

3.3.6 Assigning Online User to the Voice Route

Use following PowerShell command for assigning online user to the Voice Route:

Grant-CsOnlineVoiceRoutingPolicy -PolicyName "audc-interop" -Identity user1@company.com

Note: The command specified in Section 3.3.7 does not need to be run for each ATA

device user, if the number pattern already points to the PSTNGateway and has been associated with PSTN Usage (see Section 3.3.3).

Version 7.2 15 AudioCodes Mediant SBC

Page 16

Teams Direct Routing & Analog Devices

3.3.7 Analog Device Voice Route Configuration

Use the following PowerShell command for creating a new Online Voice Route and associating it with PSTN Usage:

New-CsOnlineVoiceRoute -Identity "audc-interop" -NumberPattern "^\+12345678901" OnlinePstnGatewayList sbc1.hybridvoice.org -Priority 1 -OnlinePstnUsages "Interop"

3.3.8 Configure with User Management Pack 365 (Optional)

As an alternative to PowerShell commands, AudioCodes recommend using User Management Pack 365 (UMP365). UMP365 provides a simple web-portal user interface for configuring and managing the Online Voice Route and associating it with PSTN Usage and PSTN Gateway. See examples below:

Figure 3-2: Example of Adding new Voice Route

Figure 3-3: Example of Voice Routes Table

AudioCodes Mediant SBC 16 Document #: LTRT-33426

Page 17

Configuration Note 4. Configuring AudioCodes SBC

Ana log

Device s

SI P

Trunk

Pro xy Set IP Group

SIP

Interface

SIP

Interface

IP Group Proxy Set

SIP

Interface

IP Group

SBC

Phone System

4 Configuring AudioCodes SBC

This section provides example of step-by-step procedures on how to configure AudioCodes SBC for interworking between Teams Direct Routing and the Company SIP Trunk. These configuration procedures are based on the topology example described in Section 2.1.1 on page 9, and includes the following main areas:

 SBC LAN interface – ATA devices environment

 SBC WAN interface - Company SIP Trunking and Teams Direct Routing environment

This configuration is done using the SBC's embedded Web server (hereafter, referred to as Web interface).

Notes:

• For implementing Teams Direct Routing based on the configuration described in

this section, AudioCodes SBC must be installed with a License Key. For more information, see Section 1.3 on page 8.

• The scope of this document does not cover all security aspects for configuring this

topology. Comprehensive security measures should be implemented per your organization's security policies. For security recommendations on AudioCodes’ products, refer to the Recommended Security Guidelines document, which can be found at AudioCodes web site

4.1 SBC Configuration Concept in Teams Direct Routing

The diagram below represents AudioCodes’ device configuration concept.

Figure 4-1: SBC Configuration Concept

Version 7.2 17 AudioCodes Mediant SBC

Page 18

Teams Direct Routing & Analog Devices

ITSP

Management

Stat ion (OAMP )

LAN

WAN

DMZ

LAN Port

Vlan ID 1

Vlan ID 2

Session B order Controll er

Phone System

Firew all

ATA

IP-PBX

4.2 IP Network Interfaces Configuration

This section describes how to configure the SBC's IP network interfaces. There are several ways to deploy the SBC; however, this example employs the following deployment method:

 SBC interfaces with the following IP entities:

• Teams Direct Routing and Company SIP Trunk, located on the WAN

• IP-PBX and/or ATA, located on the LAN

 SBC connects to the WAN through a DMZ network

 Physical connection: The type of physical connection depends on the method used to

connect to the Enterprise's network. In the example topology, SBC connects to the LAN and DMZ using dedicated ethernet ports (i.e., two ports and two network cables are used).

 SBC also uses two logical network interfaces:

• LAN (VLAN ID 1)

• DMZ (VLAN ID 2)

Figure 4-2: Network Interfaces in the Example Topology

4.2.1 Configure VLANs

This section describes how to configure VLANs for each of the following interfaces:

 LAN VoIP (assigned the name "LAN_IF")

 WAN VoIP (assigned the name "WAN_IF")

 To configure the VLANs:

1. Open the Ethernet Device table (Setup menu > IP Network tab > Core Entities folder

> Ethernet Devices).

2. There will be one existing row for VLAN ID 1 and underlying interface GROUP_1.

3. Add another VLAN ID 2 for the WAN side

Figure 4-3: Configured VLAN IDs in Ethernet Device

AudioCodes Mediant SBC 18 Document #: LTRT-33426

Page 19

Configuration Note 4. Configuring AudioCodes SBC

Prefix

Length

According to your Internet

4.2.2 Configure Network Interfaces

This section describes how to configure the IP network interfaces for each of the following interfaces:

 LAN Interface (assigned the name "LAN_IF")

 WAN Interface (assigned the name "WAN_IF")

 To configure the IP network interfaces:

1. Open the IP Interfaces table (Setup menu > IP Network tab > Core Entities folder >

IP Interfaces).

2. Configure the IP interfaces as follows (your network parameters might be different):

Table 4-1: Configuration Example of the Network Interface Table

Index

Application

Types

OAMP+ Media +

Control

Media + Control (as this interface points

to the internet,

enabling OAMP is

not recommended)

The configured IP network interfaces are shown below:

Interfac

e Mode

IPv4

Manual

IPv4

Manual

IP Address

10.15.77.77 16 10.15.0.1 10.15.27.1 LAN_IF vlan 1

195.189.192.157

(DMZ IP address of

SBC)

Gateway DNS I/F Name

195.189.192.129 (router's IP

address)

provider's

instructions

Figure 4-4: Configured Network Interfaces in IP Interfaces Table

Ethernet

Device

WAN_IF vlan 2

Version 7.2 19 AudioCodes Mediant SBC

Page 20

Teams Direct Routing & Analog Devices

4.3 SIP TLS Connection Configuration

This section describes how to configure the SBC for using a TLS connection with the Teams Direct Routing Phone System. This configuration is essential for a secure SIP TLS connection. The configuration instructions example in this section are based on the following domain structure that must be implemented as part of the certificate which must be loaded to the host SBC:

 CN: sbc1.hybridvoice.org

 SAN: sbc1.hybridvoice.org

This certificate module is based on the Service Provider's own TLS Certificate. For more certificate structure options, see Microsoft Teams Direct Routing documentation.

The Phone System Direct Routing Interface allows only TLS connections from SBCs for SIP traffic with a certificate signed by one of the Trusted Certification Authorities.

Currently, supported Certification Authorities can be found in the following link:

https://docs.microsoft.com/en-us/microsoftteams/direct-routing-plan#public-trustedcertificate-for-the-sbc

4.3.1 Configure the NTP Server Address

This section describes how to configure the NTP server's IP address. It is recommended to implement an NTP server (Microsoft NTP server or another global server) to ensure that the SBC receives the current date and time. This is necessary for validating certificates of remote parties. It is important, that NTP Server will locate on the OAMP IP Interface (LAN_IF in our case) or will be accessible through it.

 To configure the NTP server address:

1. Open the Time & Date page (Setup menu > Administration tab > Time & Date).

2. In the 'Primary NTP Server Address' field, enter the IP address of the NTP server

(e.g., 10.15.28.1).

Figure 4-5: Configuring NTP Server Address

3. Click Apply.

AudioCodes Mediant SBC 20 Document #: LTRT-33426

Page 21

Configuration Note 4. Configuring AudioCodes SBC

media. You might want to configure additional parameters according to your company's policies. For example, you might want to configure Online Certificate

4.3.2 Create a TLS Context for Teams Direct Routing

This section describes how to configure TLS Context in the SBC. AudioCodes recommends implementing only TLS to avoid flaws in SSL.

 To configure the TLS version:

1. Open the TLS Contexts table (Setup menu > IP Network tab > Security folder > TLS

Contexts).

2. Create a new TLS Context by clicking New at the top of the interface, and then configure

the parameters using the table below as reference:

Table 4-2: New TLS Context

Index Name TLS Version

1 Teams (arbitrary descriptive name) TLSv1.2

All other parameters can be left unchanged with their default values.

Note: The table above exemplifies configuration focusing on interconnecting SIP and

Status Protocol (OCSP) to check if SBC certificates presented in the online server are still valid or revoked. For more information on the SBC's configuration, see the User's Manual, available for download from https://www.audiocodes.com/library/technical-

documents.

Figure 4-6: Configuring TLS Context for Teams Direct Routing

3. Click Apply.

Version 7.2 21 AudioCodes Mediant SBC

Page 22

Teams Direct Routing & Analog Devices

4.3.3 Configure a Certificate

This section describes how to request a certificate for the SBC and to configure it based on the example of DigiCert Global Root CA. The certificate is used by the SBC to authenticate the connection with Teams Direct Routing.

The procedure involves the following main steps:

a. Generating a Certificate Signing Request (CSR). b. Requesting Device Certificate from CA. c. Obtaining Trusted Root/ Intermediate Certificate from CA. d. Deploying Device and Trusted Root/ Intermediate Certificates on SBC.

 To configure a certificate:

1. Open the TLS Contexts page (Setup menu > IP Network tab > Security folder > TLS

Contexts).

2. In the TLS Contexts page, select the required TLS Context index row, and then click

the Change Certificate link located below the table; the Context Certificates page appears.

3. Under the Certificate Signing Request group, do the following:

a. In the 'Subject Name [CN]' field, enter the SBC FQDN name

(based on example above, sbc1.hybridvoice.org).

b. In the ‘1

enter the SBC FQDN name (based on example above, sbc1.hybridvoice.org).

Subject Alternative Name [SAN]’ field, change the type to ‘DNS’ and

Note: The domain portion of the Common Name [CN] and 1st Subject Alternative

Name [SAN] must match the SIP suffix configured for Office 365 users.

c. Change the 'Private Key Size' based on the requirements of your Certification

Authority. Many CAs do not support private key of size 1024. In this case, you must change the key size to 2048.

d. To change the key size on TLS Context, go to: Generate New Private Key and

Self-Signed Certificate, change the 'Private Key Size' to 2048 and then click Generate Private-Key. To use 1024 as a Private Key Size value, you can click Generate Private-Key without changing the default key size value.

e. Fill in the rest of the request fields according to your security provider's

instructions.

f. Click the Create CSR button; a textual certificate signing request is displayed in

the area below the button:

AudioCodes Mediant SBC 22 Document #: LTRT-33426

Page 23

Configuration Note 4. Configuring AudioCodes SBC

Figure 4-7: Example of Certificate Signing Request – Creating CSR

4. Copy the CSR from the line "----BEGIN CERTIFICATE" to "END CERTIFICATE

REQUEST----" to a text file (such as Notepad), and then save it to a folder on your

computer with the file name, for example certreq.txt.

5. Send certreq.txt file to the Certified Authority Administrator for signing.

Version 7.2 23 AudioCodes Mediant SBC

Page 24

Teams Direct Routing & Analog Devices

6. After obtaining an SBC signed and Trusted Root/Intermediate Certificate from the CA,

in the SBC's Web interface, return to the TLS Contexts page and do the following:

a. In the TLS Contexts page, select the required TLS Context index row, and then

click the Change Certificate link located below the table; the Context Certificates page appears.

b. Scroll down to the Upload certificates files from your computer group, click

the Choose File button corresponding to the 'Send Device Certificate...' field, navigate to the certificate file obtained from the CA, and then click Load File to upload the certificate to the SBC.

Figure 4-8: Uploading the Certificate Obtained from the Certification Authority

7. Confirm that the certificate was uploaded correctly. A message indicating that the

certificate was uploaded successfully is displayed in blue in the lower part of the page.

8. In the SBC's Web interface, return to the TLS Contexts page, select the required TLS

Context index row, and then click the Certificate Information link, located at the bottom of the TLS. Then validate the Key size, certificate status and Subject Name:

Figure 4-9: Certificate Information Example

AudioCodes Mediant SBC 24 Document #: LTRT-33426

Page 25

Configuration Note 4. Configuring AudioCodes SBC

9. In the SBC's Web interface, return to the TLS Contexts page.

a. In the TLS Contexts page, select the required TLS Context index row, and then

click the Trusted Root Certificates link, located at the bottom of the TLS Contexts page; the Trusted Certificates page appears.

b. Click the Import button, and then select all Root/Intermediate Certificates

obtained from your Certification Authority to load.

10. Click OK; the certificate is loaded to the device and listed in the Trusted Certificates

store:

Figure 4-10: Example of Configured Trusted Root Certificates

4.3.4 Method for Generating and Installing the Wildcard Certificate

To use the same certificate on multiple devices, you may prefer using 3rd party application (e.g. DigiCert Certificate Utility for Windows Certificate Authority on another machine, with this utility installed.

After you've processed the certificate request and response using the DigiCert utility, test the certificate private key and chain and then export the certificate with private key and assign a password.

 To install the certificate:

1. Open the TLS Contexts page (Setup menu > IP Network tab > Security folder > TLS

Contexts).

2. In the TLS Contexts page, select the required TLS Context index row, and then click

the Change Certificate link located below the table; the Context Certificates page appears.

3. Scroll down to the Upload certificates files from your computer group and do the

following:

a. Enter the password assigned during export with the DigiCert utility in the 'Private

key pass-phrase' field.

b. Click the Choose File button corresponding to the 'Send Private Key...' field and

then select the SBC certificate file exported from the DigiCert utility.

) to process the certificate request from your

Version 7.2 25 AudioCodes Mediant SBC

Page 26

Teams Direct Routing & Analog Devices

4.3.5 Deploy Baltimore Trusted Root Certificate

Note: Loading Baltimore Trusted Root Certificates into AudioCodes' SBC mandatory

for implementing MTLS connection with Microsoft.

The DNS name of the Teams Direct Routing interface is sip.pstnhub.microsoft.com. In this interface, a certificate is presented which is signed by Baltimore Cyber Baltimore CyberTrust Root with Serial Number: 02 00 00 b9 and SHA fingerprint: d4:de:20:d0:5e:66:fc: 53:fe:1a:50:88:2c:78:db:28:52:ca:e4:74.

To trust this certificate, your SBC must have the certificate in Trusted Certificates storage. Download the certificate from https://cacert.omniroot.com/bc2025.pem above to import the certificate to the Trusted Root storage.

Note: Before importing the Baltimore Root Certificate into AudioCodes' SBC, make

sure it's in .PEM or .PFX format. If it isn't, you need to convert it to .PEM or .PFX format. Otherwise, you will receive a 'Failed to load new certificate' error message. To convert to PEM format, use the Windows local store on any Windows OS and then export it as 'Base-64 encoded X.509 (.CER) certificate'.

and follow the steps

AudioCodes Mediant SBC 26 Document #: LTRT-33426

Page 27

Configuration Note 4. Configuring AudioCodes SBC

4.4 Configure Media Realms

This section describes how to configure Media Realms. Media Realms allow the dividing of UDP port ranges for use on different interfaces. The simplest configuration is to create Media Realms for internal (ATA) and external (Teams and SIP Trunk) traffic.

 To configure Media Realms:

1. Open the Media Realms table (Setup menu > Signaling & Media tab > Core Entities

folder > Media Realms).

2. Configure Media Realms as follows (you can use the default Media Realm (Index 0),

but modify it):

Table 2-3: Configuration Example Media Realms in Media Realm Table

Index Name

SIPTrunk

(arbitrary name)

Teams (arbitrary

name)

MRLan (arbitrary

name)

The configured Media Realms are shown in the figure below:

Figure 4-11: Configured Media Realms in Media Realm Table

Topology

IPv4 Interface

Location

Up WAN_IF

Name

LAN_IF

Port Range

Start

6000

7000

6000

Number of Media

Session Legs

100 (media sessions

assigned with port range)

100 (media sessions

assigned with port range)

100 (media sessions

assigned with port range)

Version 7.2 27 AudioCodes Mediant SBC

Page 28

Teams Direct Routing & Analog Devices

4.5 Configure SIP Signaling Interfaces

This section describes how to configure SIP Interfaces. A SIP Interface defines a listening port and type (UDP, TCP, or TLS) for SIP signaling traffic on a specific logical IP network interface (configured in the Interface Table above) and Media Realm. Note that the configuration of a SIP interface for the SIP Trunk and ATA device shows an example, which may be different to your configuration. For specific configuration of interfaces relating to SIP trunks and/or a third-party PSTN environment connected to the SBC, see the trunk / environment vendor documentation.

 To configure SIP Interfaces:

1. Open the SIP Interfaces table (Setup menu > Signaling & Media tab > Core Entities

folder > SIP Interfaces).

2. Configure SIP Interfaces. You can use the default SIP Interface (Index 0), however,

modify it as shown in the table below. The table below shows an example of the configuration. You can change some of the parameters according to your requirements.

Note: The Direct Routing interface can only use TLS for a SIP port. It does not support

using TCP due to security reasons. The SIP port might be any port of your choice. When pairing the SBC with Office 365, the chosen port is specified in the pairing command.

Index Name

SIPTrunk

(arbitrary

name)

Teams

(arbitrary

name)

ATA

(arbitrary

name)

Table 4-4: Configuration Example of SIP Signaling Interfaces

Network Interface

WAN_IF SBC

LAN_IF SBC

Application

Type

UDP Port

5060

(according

to Service

Provider

requirement)

(Phone

System

does not

use UDP or

TCP for SIP

signaling)

5060

(according

to Service

Provider

requirement)

TCP Port

TLS Port

0 0

configured

0 0

5061 (as

in the Office

365)

Enable

TCP

Keepalive

Disable

(leave

default

value)

Enable

Disable

(leave

default

value)

Classification

Failure

Response Type

500 (leave

default value)

(Recommended

to prevent DoS

attacks)

500 (leave

default value)

Note: For implementing an MTLS connection with the Microsoft Teams network,

configure ‘TLS Mutual Authentication’ to “Enable” for Teams SIP Interface.

Media

Realm

SIPTrunk -

Teams Teams

ATA -

TLS

Context

Name

Note: Loading Baltimore Trusted Root Certificates to AudioCodes' SBC is mandatory

for implementing an MTLS connection with the Microsoft Teams network . Refer to Section 4.3.5 on page 26.

AudioCodes Mediant SBC 28 Document #: LTRT-33426

Page 29

Configuration Note 4. Configuring AudioCodes SBC

The configured SIP Interfaces are shown in the figure below:

Figure 4-12: Configured SIP Interfaces in SIP Interface Table

4.6 Configure Proxy Sets and Proxy Address

4.6.1 Configure Proxy Sets

This section describes how to configure Proxy Sets. The Proxy Set defines the destination address (IP address or FQDN) of the IP entity server. Proxy Sets can also be used to configure load balancing between multiple servers.

For the example topology, Proxy Sets need to be configured for the following IP entities:

 Company SIP Trunk

 Teams Direct Routing

The Proxy Sets will later be applied to the VoIP network by assigning them to IP Groups.

 To configure Proxy Sets:

1. Open the Proxy Sets table (Setup menu > Signaling & Media tab > Core Entities

folder > Proxy Sets).

2. Configure Proxy Sets as shown in the table below:

Table 4-5: Configuration Example Proxy Sets in Proxy Sets Table

Index Name

SIPTrunk

(arbitrary name)

Teams

(arbitrary name)

SBC IPv4

SIP

Interface

SIPTrunk Default

Teams Teams

TLS Context

Name

Proxy

Keep-Alive

Using

Options

Using

Options

Proxy Hot

Swap

- -

Enable

Proxy

Load

Balancing

Method

Random

Weights

Version 7.2 29 AudioCodes Mediant SBC

Page 30

Teams Direct Routing & Analog Devices

Proxy Random

The configured Proxy Sets are shown in the figure below:

Figure 4-13: Configured Proxy Sets in Proxy Sets Table

4.6.2 Configure a Proxy Address

This section shows how to configure a Proxy Address for the SIP Trunk and Teams entities..

 To configure a Proxy Address for SIP Trunk:

1. Open the Proxy Sets table (Setup menu > Signaling & Media tab > Core Entities folder

> Proxy Sets) and then click the Proxy Set SIPTrunk, and then click the Proxy Address link located below the table; the Proxy Address table opens.

2. Click +New; the following dialog box appears:

Figure 4-14: Configuring Proxy Address for SIP Trunk

3. Configure the address of the Proxy Set according to the parameters described in the

table below:

Table 4-6: Configuration Proxy Address for SIP Trunk

Index Proxy Address

4. Click Apply.

SIPTrunk.com:5060

(SIP Trunk IP / FQDN and port)

Transport

Type

UDP 0 0

Proxy

Priority

Weight

AudioCodes Mediant SBC 30 Document #: LTRT-33426

Page 31

Configuration Note 4. Configuring AudioCodes SBC

Proxy Random

 To configure a Proxy Address for Teams:

1. Open the Proxy Sets table (Setup menu > Signaling & Media tab > Core Entities

folder > Proxy Sets) and then click the Proxy Set Teams, and then click the Proxy Address link located below the table; the Proxy Address table opens.

2. Click +New; the following dialog box appears:

Figure 4-15: Configuring Proxy Address for Teams Direct Routing Interface

3. Configure the address of the Proxy Set according to the parameters described in the

table below:

Table 4-7: Configuration Proxy Address for Teams Direct Routing

Index Proxy Address

0 sip.pstnhub.microsoft.com:5061 TLS 1 1

1 sip2.pstnhub.microsoft.com:5061 TLS 2 1

2 sip3.pstnhub.microsoft.com:5061 TLS 3 1

4. Click Apply.

Transport

Type

Proxy

Priority

Weight

Version 7.2 31 AudioCodes Mediant SBC

Page 32

Teams Direct Routing & Analog Devices

G.729

4.7 Configure Coders

This section describes how to configure coders (termed Coder Group). As Teams Direct Routing supports the SILK and OPUS coders while the network connection to Company SIP Trunk may restrict operation with a dedicated coders list, you need to add a Coder Group with the supported coders for each leg, the Teams Direct Routing and the Company SIP Trunk.

Note that the Coder Group ID for this entity will be assigned to its corresponding IP Profile in the next step.

 To configure coders:

1. Open the Coder Groups table (Setup menu > Signaling & Media tab > Coders &

Profiles folder > Coder Groups).

2. Configure a Coder Group for Teams Direct Routing:

Parameter Value

Coder Group Name AudioCodersGroups_1

Coder Name

Figure 4-16: Configuring Coder Group for Teams Direct Routing

3. Click Apply, and then confirm the configuration change in the prompt that pops up.

 SILK-NB  SILK-WB  G.711 A-law  G.711 U-law



AudioCodes Mediant SBC 32 Document #: LTRT-33426

Page 33

Configuration Note 4. Configuring AudioCodes SBC

The procedure below describes how to configure an Allowed Coders Group to ensure that voice sent to the Company SIP Trunk uses the dedicated coders list whenever possible. Note that this Allowed Coders Group ID will be assigned to the IP Profile belonging to the Company SIP Trunk in the next step.

 To set a preferred coder for the Company SIP Trunk:

1. Open the Allowed Audio Coders Groups table (Setup menu > Signaling & Media tab

> Coders & Profiles folder > Allowed Audio Coders Groups).

2. Click New and configure a name for the Allowed Audio Coders Group for Company SIP

Trunk.

Figure 4-17: Configuring Allowed Coders Group for Company SIP Trunk

3. Click Apply.

4. Select the new row that you configured, and then click the Allowed Audio Coders link

located below the table; the Allowed Audio Coders table opens.

5. Click New and configure an Allowed Coders as follows:

Parameter Value

Index 0

Coder G.729

Figure 4-18: Configuring Allowed Coders for Company SIP Trunk

Version 7.2 33 AudioCodes Mediant SBC

Page 34

Teams Direct Routing & Analog Devices

6. Open the Media Settings page (Setup menu > Signaling & Media tab > Media folder

> Media Settings).

Figure 4-19: SBC Preferences Mode

7. From the 'Preferences Mode' drop-down list, select Include Extensions.

8. Click Apply.

AudioCodes Mediant SBC 34 Document #: LTRT-33426

Page 35

Configuration Note 4. Configuring AudioCodes SBC

Coders first and then

4.8 Configure IP Profiles

This section describes how to configure IP Profiles. The IP Profile defines a set of call capabilities relating to signaling (e.g., SIP message terminations such as REFER) and media (e.g., coder and transcoding method).

In this example topology, IP Profiles need to be configured for the following IP entities:

 Company SIP trunk – to operate in non-secure mode using RTP and SIP over UDP

 Teams Direct Routing – to operate in secure mode using SRTP and SIP over TLS

 ATA device – to operate in non-secure mode using RTP and SIP over UDP

 To configure an IP Profile for the Company SIP Trunk:

1. Open the IP Profiles table (Setup menu > Signaling & Media tab > Coders & Profiles

folder > IP Profiles).

2. Click New, and then configure the parameters as follows:

Parameter Value

General

Index 1

Name SIPTrunk

Media Security

SBC Media Security Mode Not Secured

SBC Media

Allowed Audio Coders SIPTrunk Allowed Coders

Allowed Coders Mode Preference (lists Allowed

original coders in received SDP offer)

SBC Signaling

P-Asserted-Identity Header Mode Add (required for anonymous calls)

SBC Forward and Transfer

Remote REFER Mode Handle Locally

Remote Replaces Mode Handle Locally

Remote 3xx Mode Handle Locally

Version 7.2 35 AudioCodes Mediant SBC

Page 36

Teams Direct Routing & Analog Devices

Figure 4-20: Configuration example: Company SIP Trunk IP Profile

3. Click Apply.

 To configure IP Profile for the Teams Direct Routing:

1. Open the IP Profiles table (Setup menu > Signaling & Media tab > Coders & Profiles

folder > IP Profiles).

2. Click New, and then configure the parameters as follows:

Parameter Value

General

Index 2

Name Teams (arbitrary descriptive name)

Media Security

SBC Media Security Mode Secured

SBC Early Media

Remote Early Media RTP Detection Mode

By Media (required, as Teams Direct Routing does not send RTP immediately to remote side when it sends a SIP 18x response)

SBC Media

Extension Coders Group AudioCodersGroups_1

RTCP Mode

ICE Mode Lite (required only when Media Bypass enabled on

AudioCodes Mediant SBC 36 Document #: LTRT-33426

Generate Always (required, as some ITSPs do not send RTCP packets during while in Hold mode, but Microsoft expected to them)

Teams)

Page 37

Configuration Note 4. Configuring AudioCodes SBC

SBC Signaling

SIP UPDATE Support Not Supported

Remote re-INVITE Support Supported Only With SDP

Remote Delayed Offer Support

SBC Forward and Transfer

Remote REFER Mode Handle Locally

Remote 3xx Mode Handle Locally

SBC Hold

Remote Hold Format Inactive (some SIP Trunk may answer with a=inactive

All other parameters can be left unchanged at their default values.

Figure 4-21: Configuration example: Teams Direct Routing IP Profile

Not Supported

and IP=0.0.0.0 in response to the Re-Invite with Hold request from Teams. Microsoft Media Stack doesn’t support this format. So, SBC will replace 0.0.0.0 with its IP address)

3. Click Apply.

 To configure an IP Profile for the ATA device:

1. Open the IP Profiles table (Setup menu > Signaling & Media tab > Coders & Profiles

folder > IP Profiles).

Version 7.2 37 AudioCodes Mediant SBC

Page 38

Teams Direct Routing & Analog Devices

2. Click New, and then configure the parameters as follows:

Parameter Value

General

Index 3

Name ATA

Media Security

SBC Media Security Mode Not Secured

SBC Forward and Transfer

Remote REFER Mode Handle Locally

Remote Replaces Mode Handle Locally

Remote 3xx Mode Handle Locally

Figure 4-22: Configuration example: ATA device IP Profile

3. Click Apply.

AudioCodes Mediant SBC 38 Document #: LTRT-33426

Page 39

Configuration Note 4. Configuring AudioCodes SBC

4.9 Configure IP Groups

This section describes how to configure IP Groups. The IP Group represents an IP entity on the network with which the SBC communicates. This can be a server (e.g., IP PBX or ITSP) or it can be a group of users (e.g., LAN IP phones). For servers, the IP Group is typically used to define the server's IP address by associating it with a Proxy Set. Once IP Groups are configured, they are used to configure IP-to-IP routing rules for denoting source and destination of the call.

In this example topology, IP Groups must be configured for the following IP entities:

 Company SIP Trunk located on WAN

 Teams Direct Routing located on WAN

 ATA device located on LAN

 To configure IP Groups:

1. Open the IP Groups table (Setup menu > Signaling & Media tab > Core Entities folder

> IP Groups).

2. Configure an IP Group for the Company SIP Trunk:

Parameter Value

Index 1

Name SIPTrunk

Type Server

Proxy Set SIPTrunk

IP Profile SIPTrunk

Media Realm MR-SIPTrunk

SIP Group Name (according to ITSP requirement)

All other parameters can remain unchanged with their default values.

3. Configure an IP Group for the Teams Direct Routing:

Parameter Value

Index 2

Name Teams

Topology Location Up

Type Server

Proxy Set Teams

IP Profile Teams

Media Realm MR-Teams

Classify By Proxy Set Disable

Local Host Name < FQDN name of the SBC in the enterprise Teams

tenant > (For example, sbc.ACeducation.info)

Always Use Src Address Yes

Proxy Keep-Alive using IP Group settings

All other parameters can be left unchanged with their default values.

Version 7.2 39 AudioCodes Mediant SBC

Enable

Page 40

Teams Direct Routing & Analog Devices

4. Configure an IP Group for the ATA device:

Parameter Value

Index 3

Name ATA

Topology Location Up

Type User

IP Profile ATA

Media Realm MRLan

SIP Group Name (according to ITSP requirement)

All other parameters can remain unchanged with their default values.

The configured IP Groups are shown in the figure below:

Figure 4-23: Configured IP Groups in IP Group Table

AudioCodes Mediant SBC 40 Document #: LTRT-33426

Page 41

Configuration Note 4. Configuring AudioCodes SBC

4.10 Configure SRTP

This section describes how to configure media security. The Direct Routing Interface needs to use of SRTP only, so you need to configure the SBC to operate in the same manner.

 To configure media security:

1. Open the Media Security page (Setup menu > Signaling & Media tab > Media folder

> Media Security).

2. From the 'Media Security' drop-down list, select Enable to enable SRTP.

Figure 4-24: Configuring SRTP

3. Click Apply.

Version 7.2 41 AudioCodes Mediant SBC

Page 42

Teams Direct Routing & Analog Devices

4.11 Configuring Message Condition Rules

This section describes how to configure the Message Condition Rules. A Message Condition defines special conditions (pre-requisites) for incoming SIP messages. These rules can be used as additional matching criteria for the IP-to-IP routing rules in the IP-to-IP Routing table.

The following condition verifies that the Contact header contains Microsoft Teams FQDN.

 To configure a Message Condition rule:

1. Open the Message Conditions table (Setup menu > Signaling & Media tab > Message

Manipulation folder > Message Conditions).

2. Click New, and then configure the parameters as follows:

Parameter Value

Index 0

Name Teams-Contact (arbitrary descriptive name)

Condition header.contact.url.host contains 'pstnhub.microsoft.com'

Figure 4-25: Configuring Condition Table

3. Click Apply.

AudioCodes Mediant SBC 42 Document #: LTRT-33426

Page 43

Configuration Note 4. Configuring AudioCodes SBC

4.12 Configure Classification Rules

This section describes how to configure Classification rules. A Classification rule classifies incoming SIP dialog-initiating requests (e.g., INVITE messages) to a ‘source’ IP Group. The source IP Group is the SIP entity that sent the SIP dialog request. Once classified, the device uses the IP Group to process the call (manipulation and routing).

You can also use the Classification table for employing SIP-level access control for successfully classified calls, by configuring Classification rules with whitelist and blacklist settings. If a Classification rule is configured as a whitelist ("Allow"), the device accepts the SIP dialog and processes the call. If the Classification rule is configured as a blacklist ("Deny"), the device rejects the SIP dialog.

 To configure a Classification rule:

1. Open the Classification table (Setup menu > Signaling & Media tab > SBC folder >

Classification Table).

2. Click New, and then configure classification rule for messages from Teams as follows:

Parameter Value

Index 0

Name Teams

Source SIP Interface Teams

Source IP Address 52.114.*.*

Destination Host sbc.ACeducation.info

Message Condition Teams-Contact

Action Type Allow

Source IP Group Teams

Figure 4-26: Configuring Classification Rule for Teams

3. Click Apply.

Version 7.2 43 AudioCodes Mediant SBC

Page 44

Teams Direct Routing & Analog Devices

4. Click New, and then configure classification rule for messages from ATA device as

follows:

Parameter Value

Index 1

Name ATA Users

Source SIP Interface ATA

Source Username Pattern +12345678901

Action Type Allow

Source IP Group ATA

Figure 4-27: Configuring Classification Rule for ATA users

5. Click Apply.

AudioCodes Mediant SBC 44 Document #: LTRT-33426

Page 45

Configuration Note 4. Configuring AudioCodes SBC

4.13 Configure IP-to-IP Call Routing Rules

This section describes how to configure IP-to-IP call routing rules. These rules define the routes for forwarding SIP messages (e.g., INVITE) received from one IP entity to another. The SBC selects the rule whose configured input characteristics (e.g., IP Group) match those of the incoming SIP message. If the input characteristics do not match the first rule in the table, they are compared to the second rule, and so on, until a matching rule is located. If no rule is matched, the message is rejected. The routing rules use the configured IP Groups (as configured in Section 4.9 on page 39) to denote the source and destination of the call.

For the example topology, the following IP-to-IP routing rules need to be configured to route calls between Teams Direct Routing and Company SIP Trunk:

 Terminate SIP OPTIONS messages on the SBC that are received from any entity

 REGISTER requests from ATA device

 Re-Route REFER messages to Teams Direct Routing

 Calls from Teams Direct Routing to Company SIP Trunk

 Calls from Company SIP Trunk to ATA device

 Calls from Company SIP Trunk to Teams Direct Routing

 Calls from ATA device to Teams Direct Routing

 Calls from ATA device to Company SIP Trunk

 To configure IP-to-IP routing rules:

1. Open the IP-to-IP Routing table (Setup menu > Signaling & Media tab > SBC folder >

Routing > IP-to-IP Routing).

2. Configure routing rules as shown in the table below:

Table 4-8: Configuration Example: IP-to-IP Call Routing Rules

Index Name

Terminate

OPTIONS

3 To ATA Any

ATA

Registration

Refer re-

routing

(arbitrary

name)

Teams to SIP

Trunk

SIP Trunk to

Teams

ATA to Teams

ATA to SIP

Trunk

Source

IP Group

Any OPTIONS

ATA REGISTER

Any

Teams

SIPTrunk

ATA

Request

Type

Dest

Username

Pattern

+12345678

12345xxxxx

Call

Triger

REFER Teams

ReRoute

IP Group

Internal

All Users

IP Group ATA

IP Group SIPTrunk

IP Group Teams

IP Group SIPTrunk

Dest Type

Request

URI

Dest

IP Group

Teams

Internal Action

Reply(Response

='200')

Version 7.2 45 AudioCodes Mediant SBC

Page 46

Teams Direct Routing & Analog Devices

The configured routing rules are shown in the figure below:

Figure 4-28: Configured IP-to-IP Routing Rules in IP-to-IP Routing Table

Note: The routing configuration may change according to your specific deployment

topology.

AudioCodes Mediant SBC 46 Document #: LTRT-33426

Page 47

Configuration Note 4. Configuring AudioCodes SBC

4.14 Configure Firewall Settings

As a security measure, there is an option to configure traffic filtering rules (access list) for incoming traffic on AudioCodes SBC. For each packet received on the configured network interface, the SBC searches the table from top to bottom until the first matching rule is found. The matched rule can permit (allow) or deny (block) the packet. Once a rule in the table is located, subsequent rules further down the table are ignored. If the end of the table is reached without a match, the packet is accepted. Please note that the firewall is stateless. The blocking rules will apply to all incoming packets, including UDP or TCP responses.

 To configure a firewall rule:

1. Open the Firewall table (Setup menu > IP Network tab > Security folder> Firewall).

2. Configure the following Access list rules for Teams Direct Rout IP Interface:

Table 2-9: Firewall Table Rules

Index Source IP

1 52.114.148.0 32 0

2 52.114.132.46 32 0

3 52.114.75.24 32 0

4 52.114.76.76 32 0

5 52.114.7.24 32 0

6 52.114.14.70 32 0

49 0.0.0.0 0 0

(e.g. 8.8.8.8)

Subnet

Prefix

32 0

Note: Be aware that if in your configuration, connectivity to SIP Trunk (or other entities)

is performed through the same IP Interface as Teams (WAN_IF in our example), you must add rules to allow traffic from these entities.

Start

Port

End

Port

65535

Use

Protocol

Specific

Interface

Any Enable WAN_IF Allow

TCP Enable WAN_IF Allow

Any Enable WAN_IF Block

Interface

Allow

Type

Version 7.2 47 AudioCodes Mediant SBC

Page 48

Teams Direct Routing & Analog Devices

This page is intentionally left blank.

AudioCodes Mediant SBC 48 Document #: LTRT-33426

Page 49

Configuration Note 5. Verify the Pairing Between the SBC and Direct Routing

5 Verify the Pairing Between the SBC and

Direct Routing

After you have paired the SBC with Teams Direct Routing using the NewCsOnlinePSTNGateway PowerShell command, validate that the SBC can successfully

exchange OPTIONS with Direct Routing.

 To validate the pairing using SIP OPTIONS:

1. Open the Proxy Set Status page (Monitor menu > VoIP Status tab> Proxy Set Status).

2. Find the Direct SIP connection and verify that 'Status' is online. If you see a failure, you

need to troubleshoot the connection first, before configuring voice routing.

Figure 5-1: Proxy Set Status

Version 7.2 49 AudioCodes Mediant SBC

Page 50

Teams Direct Routing & Analog Devices

This page is intentionally left blank.

AudioCodes Mediant SBC 50 Document #: LTRT-33426

Page 51

Configuration Note 6. Verify ATA Registered Users in the SBC

6 Verify ATA Registered Users in the SBC

You can view SBC users that are registered with the device. For each user, the Address of Record (AOR) and the corresponding contacts are shown.

 To view registered SBC users:

1. Open the SBC Registered Users page (Monitor menu > Monitor tab > VoIP Status

folder > SBC Registered Users).

Figure 6-1: SBC Registered Users

Version 7.2 51 AudioCodes Mediant SBC

Page 52

Teams Direct Routing & Analog Devices

This page is intentionally left blank.

AudioCodes Mediant SBC 52 Document #: LTRT-33426

Page 53

Configuration Note A. Configuring MP-1xx ATA for Connecting Analog Devices

of the

A Configuring MP-1xx ATA for Connecting

Analog Devices

This section describes how to configure AudioCodes MediaPack™ Series (MP-1xx) VoIP Gateways for connecting analog devices. The ATA device must be configured to send all calls to the AudioCodes SBC.

Note: This section shows partial configuration. For detailed configuration

MediaPack MP-1xx Series refer to the device's User's Manual (https://www.audiocodes.com/library/technical-documents?query=MP-11x).

A.1 Configure Proxy Server and Registration

This section describes how to configure the proxy server and registration. The configuration below uses the example of an ATA device registered to the SBC device (10.15.17.55).

 To configure Proxy Server and Registration:

1. Open the Proxy & Registration page (Configuration tab > VoIP menu > SIP

Definitions sub-menu > Proxy & Registration).

Figure A-1: Proxy and Registration

2. From the 'Use Default Proxy' drop-down list, select Yes.

3. In the 'Proxy Name' field, enter the SBC IP address.

Version 7.2 53 AudioCodes Mediant SBC

Page 54

Teams Direct Routing & Analog Devices

4. From the 'Enable Registration' drop-down list, select Enable.

5. In the 'Gateway Name' field, enter the SBC IP address.

6. Click the Proxy Set Table button, the following page is displayed:

Figure A-2: Default Proxy Sets Table

7. In the 'Proxy Address' field, enter the SBC IP address.

8. Click the Apply button.

A.2 Configure the Endpoint Phone Number Table

The 'Endpoint Phone Number Table' page allows you to activate the MP-1xx ports (endpoints) by defining telephone numbers. The configuration below uses the example of ATA destination phone number ‘+12345678901’ with all routing directed to the SBC device (10.15.17.55).

 To configure the Endpoint Phone Number table:

1. Open the Endpoint Phone Number Table page (Configuration tab > VoIP menu > GW

and IP to IP submenu > Hunt Group sub-menu > Endpoint Phone Number).

Figure A-3: Endpoint Phone Number Table Page

AudioCodes Mediant SBC 54 Document #: LTRT-33426

Page 55

Configuration Note A. Configuring MP-1xx ATA for Connecting Analog Devices

A.3 Configure the Hunt Group

This section describes how to configure the Hunt Group.

 To configure Hunt Group:

1. Open the Hunt Group Settings page (Configuration tab > VoIP menu > GW and IP to

IP sub-menu > Hunt Group > Hunt Group Settings).

Figure A-4: Hunt Group Settings

2. From the 'Channel Select Mode' drop-down list, select By Dest Phone Number.

3. From the 'Registration Mode' drop-down list, select Per Endpoint.

4. Click the Apply button.

A.4 Configure IP-to-Hunt Group Routing

This section describes how to configure the IP-to-Hunt Group routing rules.

 To configure the IP to Hunt Group Routing table:

1. Open the Tel to IP Routing page (Configuration tab > VoIP menu > GW and IP to IP

sub-menu > Routing > IP to Hunt Group Routing).

Figure A-5: IP to Hunt Group Routing Page

2. Configure the entry as shown in the screen above.

3. Click the Apply button.

Version 7.2 55 AudioCodes Mediant SBC

Page 56

Teams Direct Routing & Analog Devices

2 3 5

A.5 Configure SIP UDP Transport Type and Fax

Signaling Method

In most cases ATA device is used for interconnection fax devices. This step describes how to configure the fax signaling method for the MP-1xx device.

 To configure the fax signaling method:

1. Open the SIP General Parameters page (Configuration tab > VoIP menu > SIP

Definitions submenu > General Parameters).

Figure A-6: SIP General Parameters Page

2. From the ‘FAX Signaling Method’ drop-down list, select G.711 Transport for G.711 fax

support and select T.38 Relay for T.38 fax support.

3. From the ‘SIP Transport Type’ drop-down list, select UDP.

4. In the ‘SIP UDP Local Port’ field, enter 5060 (corresponding to the SBC configuration).

5. In the ‘SIP Destination Port’, enter 5060 (corresponding to the SBC configuration).

AudioCodes Mediant SBC 56 Document #: LTRT-33426

Page 57

Configuration Note B. Configuring MP-20x ATA for Connecting Analog Devices

of the

B Configuring MP-20x ATA for Connecting

Analog Devices

This section describes how to configure AudioCodes MediaPack™ Series (MP-20x) Telephony Adapter for connecting analog devices. The ATA device must be configured to send all calls to the AudioCodes SBC.

Note: This section shows partial configuration. For detailed configuration

MediaPack MP-20x Series refer to the device's User's Manual (https://www.audiocodes.com/library/technical-documents?query=MP-20x).

B.1 Configure SIP Interface Settings

This section describes how to configure SIP Signaling Protocol.

 To configure SIP Interface Settings:

1. Click the Voice Over IP menu in the side menu bar; the Voice Over IP screen appears.

Figure B-1: Signaling Protocol Page

Version 7.2 57 AudioCodes Mediant SBC

Page 58

Teams Direct Routing & Analog Devices

2. On the Signaling Protocol page, the following parameters enable configuration:

a. From the ‘SIP Transport Type’ drop-down list, select UDP. b. In the ‘Local SIP Port’ field, enter 5060 (corresponding to the SBC configuration) c. In the ‘Use SIP Proxy’ check the check box. d. In the ‘Host Name or Address’ field, set the IP address of the SBC. e. In the ‘Use SIP Proxy IP and Port for Registration’ check the check box.

B.2 Configure Media Streaming Parameters

The section describes how to configure Media Streaming Parameters.

 To configure Media Streaming Parameters:

1. Click the Media Streaming tab. The Media Streaming screens opens, which enables

you to configure the following:

• Supported Codecs

• Codecs Priority

• Packetization Time

Figure B-2: Media Streaming Page

AudioCodes Mediant SBC 58 Document #: LTRT-33426

Page 59

Configuration Note B. Configuring MP-20x ATA for Connecting Analog Devices

B.3 Configuring Line Settings

Before you can make phone calls, you need to configure lines. Lines are logical SIP ID numbers (i.e., telephone numbers) which are registered to a SIP proxy server and for which you are charged for calls you make on it. With a MP-20x line setting configuration, you can associate any phone extension to any line.

 To configure lines:

1. On the 'Voice Over IP' screen, click the Line Settings tab; the following screen appears.

Figure B-3: Line Settings Tab Screen

2. For each line, click the corresponding Edit icon to configure the line; the following

screen appears:

Figure B-4: Line Settings Screen for a New Line

3. In the ‘User ID’ field, enter phone's VoIP user ID used for identification to initiate and

accept calls.

4. To hide the phone’s ID from the remote party, select the ‘Block Caller ID’ check box.

5. In the ‘Display Name’ field, enter a name to intuitively identify the line. This is also

displayed to remote parties as your caller ID.

6. Click OK to save your settings.

Version 7.2 59 AudioCodes Mediant SBC

Page 60

Teams Direct Routing & Analog Devices

This page is intentionally left blank.

AudioCodes Mediant SBC 60 Document #: LTRT-33426

Page 61

Configuration Note C. Syntax Requirements for SIP Messages 'INVITE' and 'OPTIONS'

C Syntax Requirements for SIP Messages

'INVITE' and 'OPTIONS'

The syntax of SIP messages must conform with Teams Direct Routing requirements. This section covers the high-level requirements for the SIP syntax used in 'INVITE' and

'OPTIONS' messages. You can use the information presented here as a first step when troubleshooting unsuccessful calls. AudioCodes has found that most errors are related to incorrect syntax in SIP messages.

C.1 Terminology

Must

Strictly required. The deployment does not function correctly without the correct configuration of these parameters.

C.2 Syntax Requirements for 'INVITE' Messages

Figure C-1: Example of an 'INVITE' Message

 Contact header

• MUST: When placing calls to the Direct Routing interface, the 'CONTACT' header

must have the SBC FQDN in the URI hostname

• Syntax: Contact: <phone number>@<FQDN of the SBC>:<SBC Port>;<transport

type>

• If the parameter is not configured correctly, calls are rejected with a '403

Forbidden' message.

Version 7.2 61 AudioCodes Mediant SBC

Page 62

Teams Direct Routing & Analog Devices

C.3 Requirements for 'OPTIONS' Messages Syntax

Figure C-2: Example of 'OPTIONS' message

 Contact header

• MUST: When placing calls to the Direct Routing interface, the 'CONTACT' header

must have the SBC FQDN in the URI hostname

• Syntax: Contact: <phone number>@<FQDN of the SBC>:<SBC Port>;<transport

type>

• If the parameter is not configured correctly, the calls are rejected with a '403

Forbidden' message

The table below navigates to the path in the Web interface where the parameters are configured and refers to the relevant location in this document including the configuration instructions.

Table C-1: Syntax Requirements for an 'OPTIONS' Message

Parameter Where Configured How to Configure

Contact

Setup > Signaling and Media > Core Entities > IP Groups > <Group Name> >

See Section 4.9 Configure IP Groups

Local Host Name In IP Groups, 'Contact' must be configured.

In this field

('Local Host Name'), define the

local host name of the SBC as a string, for example, sbc.ACeducation.info. The name changes the host name in the call received from the IP group.

AudioCodes Mediant SBC 62 Document #: LTRT-33426

Page 63

Configuration Note C. Syntax Requirements for SIP Messages 'INVITE' and 'OPTIONS'

C.4 Connectivity Interface Characteristics

The table below shows the technical characteristics of the Direct Routing interface. In most cases, Microsoft uses RFC standards as a guide during development, but does not

guarantee interoperability with SBCs - even if they support all the parameters in the table below - due to the specifics of the implementation of the standards by SBC vendors.

Microsoft has a partnership with some SBC vendors and guarantees their devices' interoperability with the interface. All validated devices are listed on Microsoft's website. Microsoft only supports devices that are validated in order to connect to the Direct Routing interface.

AudioCodes is one of the vendors who are in partnership with Microsoft. AudioCodes' SBCs are validated by Microsoft to connect to the Direct Routing interface.

Table C-2: Teams Direct Routing Interface - Technical Characteristics

Category Parameter Value Comments

Ports and IP ranges

Transport and Security

SIP Interface FQDN Name

IP Addresses range for SIP interfaces

SIP Port 5061 -

IP Address range for Media

Media port range on Media Processors

Media Port range on the client

SIP transport TLS -

Media Transport SRTP -

SRTP Security Context DTLS, SIPS

See Microsoft's document Deploying

Direct Routing Guide.

See Microsoft's document Deploying Direct Routing Guide.

Note: Support for DTLS is pending. Currently, SIPS must be configured. When support for DTLS will be announced, it will be the recommended context.

https://tools.ietf.org/html/rfc5763

Crypto Suite AES_CM_128_HMAC_

SHA1_80, non-MKI

Control protocol for media transport

Supported Certification Authorities

Version 7.2 63 AudioCodes Mediant SBC

SRTCP (SRTCP-Mux recommended)

See the Deployment Guide

Using RTCP MUX helps reduce the number of required ports

Page 64

Teams Direct Routing & Analog Devices

- Not required

Category Parameter Value Comments

Transport for Media Bypass (of configured)

Audio codecs

Codecs Other codecs

 ICE-lite (RFC5245)

– recommended

 Client also has

Transport Relays

 G711  Silk (Teams clients)  Opus (WebRTC

clients) - only if Media Bypass is used

 G729

 CN  Required

narrowband and wideband

 RED - Not required  DTMF - Required  Events 0-16  Silence Suppression

AudioCodes Mediant SBC 64 Document #: LTRT-33426

Page 65

Configuration Note C. Syntax Requirements for SIP Messages 'INVITE' and 'OPTIONS'

This page is intentionally left blank.

Version 7.2 65 AudioCodes Mediant SBC

Page 66

Page 67

International Headquarters

1 Hayarden Street,

Airport City

Lod 7019900, Israel

Tel: +972-3-976-4000

Fax: +972-3-976-4040

AudioCodes Inc.

200 Cottontail Lane

Suite A101E

Somerset NJ 08873

Tel: +1-732-469-0880

Fax: +1-732-469-2298

https://www.audiocodes.com/corporate/offices-worldwide

website: https://www.audiocodes.com

©2020 AudioCodes Ltd. All rights reserved. AudioCodes, AC, HD VoIP, HD VoIP Sounds Better, IPmedia, Mediant, MediaPack, What’s Inside Matters, OSN, SmartTAP, User Management Pack, VMAS, VoIPerfect, VoIPerfectHD, Your Gateway To VoIP, 3GX, VocaNom, AudioCodes One Voice, AudioCodes Meeting Insights, AudioCodes Room Experience and CloudBond are trademarks or registered trademarks of AudioCodes Limited. All other products or trademarks are property of their respective owners. Product specifications are subject to change without notice.

Document #: LTRT-33426

AudioCodes Mediant User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Configuration Note

Table of Contents

Configuration Note Notices

WEEE EU Directive

Customer Support

Abbreviations and Terminology

Related Documentation

Document Revision Record

Documentation Feedback

1 Introduction

1.1 About Microsoft Teams Direct Routing

1.2 About AudioCodes SBC Product Series

1.3 Validated AudioCodes SBC Version

2 Topology Example

2.1.1 Enterprise Model Implementation

2.1.2 Environment Setup

2.1.3 Infrastructure Prerequisites

3 Configuring Teams Direct Routing

3.1 Prerequisites

3.2 SBC Domain Name in the Teams Enterprise Model

3.3 Configuration Example of Office 365 Tenant Direct Routing

3.3.1 Online PSTN Gateway Configuration

3.3.2 Online PSTN Usage Configuration

3.3.3 Online Voice Route Configuration

3.3.5 Enable Online User

3.3.6 Assigning Online User to the Voice Route

3.3.7 Analog Device Voice Route Configuration

3.3.8 Configure with User Management Pack 365 (Optional)

4 Configuring AudioCodes SBC

4.1 SBC Configuration Concept in Teams Direct Routing

4.2 IP Network Interfaces Configuration

4.2.1 Configure VLANs

4.2.2 Configure Network Interfaces

4.3 SIP TLS Connection Configuration

4.3.1 Configure the NTP Server Address

4.3.2 Create a TLS Context for Teams Direct Routing

4.3.3 Configure a Certificate

4.3.4 Method for Generating and Installing the Wildcard Certificate

4.3.5 Deploy Baltimore Trusted Root Certificate

4.4 Configure Media Realms

4.5 Configure SIP Signaling Interfaces

4.6 Configure Proxy Sets and Proxy Address

4.6.1 Configure Proxy Sets

4.6.2 Configure a Proxy Address

4.7 Configure Coders

4.8 Configure IP Profiles

4.9 Configure IP Groups

4.10 Configure SRTP

4.11 Configuring Message Condition Rules

4.12 Configure Classification Rules

4.13 Configure IP-to-IP Call Routing Rules

4.14 Configure Firewall Settings

Configuration Note 5. Verify the Pairing Between the SBC and Direct Routing

6 Verify ATA Registered Users in the SBC

A.1 Configure Proxy Server and Registration

A.2 Configure the Endpoint Phone Number Table

A.3 Configure the Hunt Group

A.4 Configure IP-to-Hunt Group Routing

B.1 Configure SIP Interface Settings

B.2 Configure Media Streaming Parameters

B.3 Configuring Line Settings

C.1 Terminology

C.2 Syntax Requirements for 'INVITE' Messages

C.3 Requirements for 'OPTIONS' Messages Syntax

C.4 Connectivity Interface Characteristics
