User’s manual

TL92278/TL92328/TL92378 DECT 6.0 cordless telephone/answering system with BLUETOOTH® wireless technology

Congratulations

Compatible with

Hearing Aid T-Coil

TIA-1083

on your purchase of this AT&T product. Before using this AT&T product, please read the Important safety information on pages 86-88 of this manual. Please thoroughly read this user’s manual for all the feature operations and troubleshooting information necessary to install and operate your new AT&T product. You can also visit our website at

www.telephones.att.com 1 (866) 288-4268

Model #: TL92278 (two handsets) TL92328/TL92378 (three handsets)

Type: DECT 6.0 cordless telephone/answering system with Bluetooth wireless technology

Serial #:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the bottom of the telephone base.

Save your sales receipt and original packaging in case it is necessary to return your telephone for warranty service.

or call

1 (800) 222-3111

. In Canada, dial

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STARR program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STARR label indicating it meets the latest energy efficiency guidelines.

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.

© 2008-2009 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Parts checklist

Your telephone package contains the following items.

User’s manual

TL92278/TL92328/TL92378 DECT 6.0 cordless telephone/answering system with BLUETOOTH® wireless technology

Quick start guide

TL92278/TL92328/TL92378 DECT 6.0 cordless telephone/answering system with BLUETOOTH® wireless technology

User's manual Quick start guide

Charger for cordless handset with power adapter installed (1 for TL92278) (2 for TL92328/ TL92378)

Cordless handset (2 for TL92278) (3 for TL92328/ TL92378)

Battery for cordless handset (2 for TL92278) (3 for TL92328/ TL92378)

Telephone base

Battery compartment cover (2 for TL92278) (3 for TL92328/ TL92378)

Wall mount bracket

Telephone line cord

Power adapter for telephone base

User’s manual

TL92278/TL92328/TL92378 DECT 6.0 cordless answering system with Bluetooth® wireless technology

Table of contents

Getting started

Quick reference guide

handsethandset ............................................1

telephone base ............................3

Handset status icons .......................4

Installation ............................................ 5

Telephone base installation .........6

Charger installation .......................... 7

Battery installation &

charging ........................................... 8

Installation options ...............................10

Bluetooth

Introducing Bluetooth ...................15

Glossary of terms ............................16

Bluetooth setup ...............................17

Handset settings

Handset main menu .......................19

Handset settings ..............................20

Telephone operation

Handset operation ..........................25

Options while on calls ..................31

Chain dialing ......................................34

Intercom ...............................................35

Call transfer using intercom ......37

Directory

About the directory ........................39

Creating directory entries ...........40

Directory review ...............................42

Directory search ...............................43

To dial, delete or

edit entries ...................................44

Caller ID

Caller ID operation ..........................45

To review the caller ID

history ..............................................49

Answering system

About the answering system.....51

Day & time announcement .........53

Answering system mode .............55

Outgoing announcements ..........56

Answering system setup ..............58

Message playback ...........................62

Recording & playing memos ......64

Message counter displays ...........65

Remote access ..................................66

Table of contents

Appendix A,

Alert tones & lights ........................68

Appendix B,

Handset display screen

messages ......................................69

Appendix C,

Expansion handset ..........................72

Adding and registering

handsets ........................................73

Replacing a handset ......................74

Appendix D,

Troubleshooting ...............................75

Appendix E,

Maintenance.......................................85

Appendix F,

Important safety information ....86

Appendix G,

FCC Part 68 and ACTA..................89

Appendix H,

FCC Part 15 ........................................91

Appendix I,

Limited warranty ..............................92

Appendix J,

Technical specifications ...............95

Index ...................................................96

Getting started

Quick reference guide - handset

CHARGE indicator

On when the handset is charging in the telephone base or charger.

DIR / CID

Press DIR to display directory entries (page 42). Press to scroll up while in menus. While entering names or numbers, press to move the cursor to the right. Press to increase the listening volume when on a call.

Press CID to display caller ID history (page 49). Press to scroll down while in menus. While entering names or numbers, press to move the cursor to the left. Press to decrease the listening volume when on a call.

REDIAL/PAUSE

Press to view redial memory (page 29). While entering numbers, press and hold to insert a dialing pause (page 40).

HOME/FLASH

Press to make or answer a HOME call. Flashes rapidly when there is rapidly when there is an incoming HOME call. Flashes slowly when a HOME call is on hold. During a HOME call, press to receive an incoming call if call waiting is activated (page 25).

SPEAKER

Press to turn on the handset speakerphone. Press again to resume normal handset (page 29).

MENU/SELECT

Press to display the menu. While in the menu, press to

select an item or save an entry or setting.

DELETE/MUTE

During a call, press to mute microphone (page 32). While reviewing the caller ID history, press to delete an individual entry, or press and hold to clear the caller ID history (page 50). While predialing, press to delete digits (pages 25 & 27).

OFF/CLEAR

During a HOME or CELLULAR line call, press to end the call. While in a menu, press to cancel an operation, back up to the previous menu, or exit the menu display.

CELLULAR

Press to make or answer a CELLULAR call. Flashes rapidly when there is an incoming CELLULAR call. Flashes slowly when a CELLULAR call is on hold. During a CELLULAR call, press to receive an incoming call if call waiting is activated (page 27).

HOLD

Press to put the HOME or CELLULAR call on hold

(page 33).

Getting started

Quick reference guide - handset

Feature menu

The > symbol highlights a menu item.

>DIRECTORY

CALL LOG

Feature menu

DIRECTORY (page 39) CALL LOG (page 45) INTERCOM (page 35) RINGER VOLUME (page 20) RINGER TONE (page 21) KEY TONE (page 22) LANGUAGE (page 22) CLR VOICEMAIL (page 23) HOME AREA CODE (page 24)

Using menus

Press or to scroll

through menu items. Press MENU/SELECT to

select or save changes to a highlighted menu item.

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display.

Getting started

Quick reference guide - telephone base

IN USE indicator

On when the handset is in use, when the answering system is answering an incoming call or when you are registering a handset.

Flashes when another telephone is in use on the same line, or when you are deregistering handset(s) from the telephone base.

Flashes quickly when there is an incoming call.

MESSAGE COUNTER

Number of messages (or during playback, message number currently playing).

ANSWER ON

Press to turn the answering system on or off (page 55).

X/DELETE

Press to delete the message currently playing (page 62). Press twice to delete all old messages when the phone is not in use (page 63).

Answering system functions

VOICEMAIL indicator

Flashes when you have new voicemail. Voicemail is a service offered by your local telephone company, and is different from answering system messages (page 23).

HANDSET LOCATOR

Press to make handsets beep so you can locate them (page 30).

PLAY/STOP

Press to start or stop message playback (page 62).

/REPEAT

Press to repeat a message. Press twice to play the previous message (page 62).

/SKIP

Press to skip a message (page 62).

Bluetooth

Press and hold to enable the Bluetooth feature on the telephone base (page 17). On when the telephone base is paired and connected with a cellular phone. Flashes when the Bluetooth feature is activated and waiting for pairing and connection.

CLOCK

Press to review or set the clock (page 53).

SETUP

Press to hear and change setup options (page 58).

RECORD

Press to record a memo (page 64) or, after pressing ANNC. to record an outgoing announcement (page 56).

ANNC.

Press to review or record the outgoing announcement. Press again to end announcement playback or recording (page 56).

Getting started

Handset status icons

HANDSET 1

25 MISSED CALLS

NEW

MUTE

10:21

HOME line - on steady when the HOME line is in use.

CELLULAR line - on steady when the CELLULAR line is in use.

BLUETOOTH - on steady when a cellular phone is connected with

the telephone base.

NEW VOICEMAIL - new voicemail received from the local telephone company.

SPEAKERPHONE - the speakerphone is in use.

Ringer off - the handset ringer is turned off.

Battery status - battery is charging (animated display).

Battery status - low battery (flashing); place handset in telephone

base or charger to recharge.

Microphone is muted.

11/23

NEW

Missed and unreviewed calls.

Getting started

Installation

You must install and charge the handset battery before using the cordless handset.

Install the telephone base close to a telephone jack and a power outlet not controlled by a wall switch. The telephone base can be placed on a flat surface or vertically mounted on the wall (see page 10). For optimum range and better reception, place the telephone base in a central and open location.

You may hear interference if your cellular phone is too close to the telephone base during a CELLULAR call. Make sure that your Bluetooth enabled cellular phone is between one to 12 feet away from the telephone base in order to maintain a clear and consistent connection between your Bluetooth cell phone, telephone base and cell tower.

If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone line(s), you must install a DSL filter between the telephone base and the telephone wall jack (see the following page). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

STOP!

See pages 8-9 for easy instructions.

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

• Communication devices such as: television sets, VCRs, or other cordless telephones.

• Excessive heat sources.

• Noise sources such as a window with traffic outside, motors, microwave ovens, refrigerators, or fluorescent lighting.

• Excessive dust sources such as a workshop or garage.

• Excessive moisture.

• Extremely low temperature.

• Mechanical vibration or shock such as on top of the washing machine or workbench.

Getting started

Telephone base installation

Install the telephone base as shown below. Make sure that the electrical outlet is not controlled by a wall switch.

If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone line(s), you must install a DSL filter between the telephone base and the telephone wall jack. The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

The telephone base is set for desktop use. If you want to change to wallIf you want to change to wall mounting position, you will need to install the supplied wall mount bracket to the telephone base, see page 10- for details.

2. Route the power cord through the

slot next to the telephone jack.

1. Plug the small

end of the power adapter into the power jack at the bottom of the telephone base.

3. Plug one end of

the telephone line cord into the telephone jack at the bottom of the telephone base.

6. Plug the large

end of the power adapter into a power outlet not controlled by a wall switch.

Power adapter

7. Raise the antenna.

Telephone line cord

DSL filter (not included), required if you have DSL high-speed Internet service.

4. Place the cords

into the bracket channels.

5. Plug the other

end of the telephone line cord into a telephone jack.

Getting started

Charger installation

Plug the power adapter into an electrical outlet not controlled by a wall switch.

IMPORTANT INFORMATION

Use only the power adapter(s) supplied with this product. To order a replacement

1. power adapter, visit our website at www.telephones.att.com, or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The power adapters are intended to be correctly oriented in a vertical or floor

2. mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

Getting started

Battery installation & charging

Install the battery as shown on the next page. Once you have installed the battery, the screen indicates the battery status (see table below). If necessary, place the handset in the telephone base or charger to charge the battery. For best performance, keep the handset in the charger when not in use. The battery is fully charged after 16 hours of continuous charging. See the table on page 95 for battery operating times.

If the screen is blank, you need to charge the handset without interruption for at least 10 minutes to give the handset enough charge to use the telephone for a short time. The screen shows LOW BATTERY and the backlight is off until you have charged the battery without interruption for at least one hour. The following table summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank. Battery has no charge and the

The screen shows PLACE IN CHARGER and flashes.

The screen shows LOW BATTERY and flashes.

The screen shows HANDSET X. Battery is charged. To keep the battery charged,

handset cannot be used.

Battery has very little charge and the handset cannot be used.

Battery has enough charge to be used for a short time.

Charge without interruption until the screen shows LOW BATTERY (at least 10 minutes).

Charge without interruption until the screen shows LOW BATTERY (at least four minutes).

Charge without interruptionwithout interruption until the screen shows HANDSET X (at least one hour).

place it in the telephone base or charger when not in use.

NOTE: If you are on a phone call in low battery mode, you hear four short beeps

every minute.

Getting started

Battery installation & charging

Step 1

Press the depression and slide the battery compartment cover downwards (if necessary).

Step 2

Plug the battery securely into the connector inside the handset battery compartment, matching the color-coded label. Insert the supplied battery with the label THIS SIDE UP facing up as indicated.

Step 3

Align the cover flat against the battery compartment cover, then slide it upwards until it clicks into place.

Step 4

Charge the handset by placing it face up in the telephone base or charger. The CHARGE light will be on when charging.

IMPORTANT INFORMATION

Use only the supplied rechargeable battery or replacement battery (model BT8001). To order, visit our website at www.telephones.att.com or call 1 (800) 222-

3111. In Canada, dial 1 (866) 288-4268.

Getting started

Installation options

The telephone base is set for desktop use. It is possible to change to wall mounting position by installing the wall mount bracket provided. Wall mounting requires a telephone outlet wall mounting plate with mounting studs that may require professional installation. You can purchase the mounting plate from many hardware or consumer electronics retailers.

Desktop to wall mount installation

To change the telephone base to the wall mount position, make sure that you first unplug the telephone line cord and power adapter cord from the wall outlets before you begin. In addition, to prevent possible damage, remove the handset from the telephone base.

1. Position the telephone base as shown below, and insert the extended tabs of the bracket into the slots under the telephone base.

2. Push the telephone base down until it clicks into place on both sides of the bracket.

Getting started

Installation options

Desktop to wall mount installation

3. Bundle the telephone line cord and power adapter cord, and secure them withBundle the telephone line cord and power adapter cord, and secure them with a twist tie before placing them behind the telephone base as shown below.

4. Align the holes on the bracket with the standard wall plate and slide the bracket until the telephone is secured as shown below. Plug the telephone line cord into a telephone wall jack. Plug the power adapter into a power outlet not controlled by a wall switch.

DSL filter (not included), required if you have DSL high-speed Internet service.

Getting started

Installation options

Desktop to wall mount installation

5. Make sure the telephone is securely positioned as shown below.

Getting started

Installation options

Wall mount to desktop installation

To change the telephone base to the desktop position, make sure that you firstmake sure that you first unplug the telephone line cord and power adapter cord from the wall outlets before you begin. In addition, to prevent possible damage, remove the handset from the telephone base.

1. Remove the telephone base from the wall and untie the bundled telephoneuntie the bundled telephone line cord and power adapter cord.

2. Press on the catches on both sides of the bracket (indicated by arrows below) to unlock the telephone base from the bracket.

The catch on the side of the telephone base.

3. Pull the telephone base up to detach it from the bracket.

Getting started

Installation options

4. Plug the telephone line cord into a telephone wall jack, and plug the power adapter cord into a power outlet not controlled by a wall switch. Route the cords through the bracket channels.

Power outlet not controlled by a wall switch.

Telephone line cord

Power adapter

DSL filter (not included), required if you have DSL high-speed Internet service.

Bluetooth

Introducing Bluetooth

Your new AT&T TL92278/TL92328/TL92378 telephone system with BluetoothTL92278/TL92328/TL92378 telephone system with Bluetoothtelephone system with Bluetooth wireless technology has the following features:

• Pair a Bluetooth enabled cell phone with the telephone base. Pair a Bluetooth enabled cell phone with the telephone base.

• Connect a cell phone to make and receive Connect a cell phone to make and receive CELLULAR calls. Only one cell

phone can be paired and connected on a call at a time.

• Make and receive calls using your cell phone plan while benefiting from the Make and receive calls using your cell phone plan while benefiting from the ease and comfort of your home telephone system.

IMPORTANT INFORMATION

• Refer to your cell phone user's manual for more information about itsRefer to your cell phone user's manual for more information about its Bluetooth function.

• Make sure that your Bluetooth enabled cellular phone is between one toMake sure that your Bluetooth enabled cellular phone is between one to 12 feet away from the telephone base in order to maintain a clear and consistent connection between your Bluetooth cell phone, telephone base and cell tower.

• Make sure that your cellular phone has sufficient signal strength. You mayMake sure that your cellular phone has sufficient signal strength. You may need to move the cellular phone and telephone base to a location where the cellular signal may be stronger.

• Charge your Bluetooth cell phone while it is connected to the telephoneCharge your Bluetooth cell phone while it is connected to the telephone base because your cell phone's battery will discharge faster while it is connected wirelessly to the telephone base.

• Monitor your cell phone's usage because airtime is deducted from yourMonitor your cell phone's usage because airtime is deducted from your cellular plan for the duration of the CELLULAR calls.

Refer to the Bluetooth setup section (pages 17-18) to learn how to set up your Bluetooth device. Refer to the Handset operation section (pages 25-

30) on how to operate your Bluetooth devices with your new AT&T telephone

system with Bluetooth wireless technology. Refer to the Troubleshooting section (pages 75-84) if you experience difficulty when using the telephone system.

Bluetooth

Glossary of terms

Below are some terms used in this user’s manual to help you become familiar with using your Bluetooth devices and your new AT&T telephone system.

Bluetooth cell phone - Refers to a mobile Bluetooth enabled cellular telephone.

CELLULAR line - The communications service provided through your Bluetooth enabled cellular telephone.

HOME line - Your conventional telephone land line.Your conventional telephone land line.

Connected - A Bluetooth device can only be used when it is connected to

the telephone base.

Paired devices - Once a Bluetooth device has been paired with the telephone base, it will be identified as registered to the telephone base. Only one Bluetooth cellular phone can be paired with the telephone base.

Pairing - This refers to the process of two Bluetooth devices registering device information with each other. The telephone base must be paired with a Bluetooth cellular phone before the Bluetooth device can be used. Depending on the manufacturer, this is also referred to as bonding.

PIN - By default, the PIN is 0000 for the telephone base and for most Bluetooth devices. PIN information must be exchanged between Bluetooth devices before they can be used. This is also known as a passkey or passcode.

Bluetooth

NOTE: Bluetooth device can be paired with the telephone base at a time.

HANDSET 1

Only one

Bluetooth setup

To use a Bluetooth-enabled cellular phone with your telephone, you must first pair and connect your Bluetooth cellular phone with the telephone base.

Pairing a device

Before you begin, make sure that your Bluetoothenabled cellular phone is not connected to any other Bluetooth device. Refer to your cellular phone user's manual to learn how to search for or add new Bluetooth devices.

To pair and connect a cellular phone:

1. Press and hold the Bluetooth button on the

telephone base until it is flashing. The Bluetooth feature will be activated.

2. Using your cellular phone, turn on the Bluetooth feature and search for a new device.

3. Once your cellular phone has found the AT&T DECT 6.0 telephone base, select it.

4. Using your cellular phone, enter the PIN of the telephone base (the default PIN is 0000) to continue the pairing process.

When a device is successfully connected, the

status icon will display on the cordless handset

screen, and the light of the Bluetooth button on the telephone base will be on steadily.

Auto connection

Once you have paired a device with the telephone base, the pairing information is stored in the telephone base. If the paired device becomes disconnected, the telephone base will automatically search and re-connect to that device. If the connection does not resume in a minute, you will need to re-connect to that device manually, refer to the section below for details.

Manual connection

To manually re-connect a paired device, make sure the Bluetooth feature is turned on in your cellular phone, select AT&T DECT 6.0 from the paired device list in your cellular phone. Once the connection is established again, the Bluetooth button on the telephone base will turn back on.

Bluetooth

NOTE: If the connection between the paired device and the telephone base does not resume by manually connecting the device on the paired device list, you will need to unpair or deregister the device from the cellular phone. Make sure the device is no longer on the paired list after deregistration; then follow the steps in Pairing a device on page 17 to start the pairing procedures again.

Bluetooth setup

Turning off the auto connection

If you do not want the telephone base to reconnect to a paired device automatically after it is disconnected, you can turn off the auto connection feature manually. In order to turn off the auto connection, you will need to initiate a disconnection from the paired cellular phone; this will transmit a signal to the telephone base and disable the auto connection.

While the cellular phone is connected to the telephone base, find the cellular phone’s Bluetooth device list and select AT&T DECT 6.0 to manually disconnect the device. (If disconnection is not an option on your cellular phone, you may need to disable Bluetooth or unpair the telephone base.) Refer to your cellular phone’s user’s manual for instructions. The telephone base will not search and re-connect to this cellular phone until this feature is activated again.

To resume the auto connection

To resume the auto connection between the paired device and the telephone base, you will need to connect the device manually. Make sure the Bluetooth feature is turned on in your cellular phone. Select AT&T DECT 6.0 from the paired device list in your cellular phone to reconnect. If the connection is successfully resumed, the status icon will display on the cordless handset screen, and the light of the Bluetooth button on the telephone base will be on steadily.

Replace a paired device

If you want to pair and connect a new device when there is already a device paired with the telephone base, press and hold the Bluetooth button on the telephone base until it is flashing, then start with step two of Pairing a device on page 17. If you do not pair a new device within two minutes, the Bluetooth light on the telephone base will turn off and the system will return to idle mode.

Handset settings

Handset main menu

To enter the main menu:

1. Press Press MENU/SELECT when the handset is in idle mode.

2. Press DIR / CID to select a handset feature menu, then press

MENU/SELECT to enter that menu.

To return to the idle mode, press and hold OFF/CLEAR.

CALL LOG allows you to view caller ID history (page 45).

CALL LOG

INTERCOM

HOME AREA CODE allows you to set your home area code (page 24).

HOME AREA CODE

DIRECTORY

LANGUAGE allows you to set your handset display language (page 22).

CLR VOICEMAIL allows you to turn off the new voicemail indication (page 23).

CLR VOICEMAIL

HOME AREA CODE

INTERCOM allows you to intercom with other handsets (page 35).

INTERCOM

RINGER VOLUME

RINGER TONE allows you to set the ringer for the HOME and CELLULAR lines (page 21).

DIRECTORY allows you to store and search for names and numbers (page 39).

DIRECTORY

CALL LOG

KEY TONE allows you to turn the keypad tones on or off (page 22).

KEY TONE

LANGUAGE

RINGER VOLUME allows you to set the ringer volume (page 20).

LANGUAGE

CLR VOICEMAIL

RINGER TONE

KEY TONE

RINGER VOLUME

RINGER TONE

Handset settings

DIRECTORY

CALL LOG

DIRECTORY

CALL LOG

Handset settings

Using the feature menu, you can customize many of the telephone’s settings.

1. Press MENU/SELECT when in idle mode (when

the phone is not in use) to enter the feature menu.

2. Use DIR / CID to scroll to the feature

to be changed. When scrolling through the menu, the top menu item is always highlighted with a > symbol.

3. Press MENU/SELECT to select the highlighted

item.

NOTE:

Press OFF/CLEAR to cancel an operation, back

up to the previous menu or exit the menu display. Press and hold OFF/CLEAR to return to idle mode.

Ringer volume

Using this menu, you can set the ringer volume level (1-6), or turn the ringer off. When the ringer is turned off, appears on the handset screen. The volume setting applies to both HOME and CELLULAR calls.

To adjust the RINGER VOLUME:

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

RINGER VOLUME

RINGER TONE

RINGER VOLUME

Use DIR / CID to scroll to >RINGER VOLUME, then press MENU/SELECT.

3. Press DIR / CID to sample each volume

level.

4. Press MENU/SELECT to save your preference and

return to the feature menu.

NOTE: The ringer volume also determines the ringer

volume of the intercom calls (pages 35-36) and the paging tone for the handset locator feature (page 30). If the handset ringer volume is set to off, that handset is silenced for all incoming calls and paging.

Handset settings

DIRECTORY

CALL LOG

RINGER TONE

KEY TONE

Handset settings

Ringer tone

You can select different ringer tones for the HOME and CELLULAR calls. You may choose one of 10 ringer tones.

To choose a ringer tone for the HOME line:

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

HOME TONE

CELLULAR TONE

HOME TONE 1

DIRECTORY

CALL LOG

RINGER TONE

KEY TONE

CELLULAR TONE

HOME TONE

2. Use DIR / CID to scroll to >RINGER

TONE,

then press MENU/SELECT.

3. Press MENU/SELECT to select HOME TONE.

4. Press

DIR / CID

to get to the next ringer

tone and to hear a sample of it.

5. Press MENU/SELECT to save your preference and

return to the feature menu.

To choose a ringer tone for the CELLULAR line:

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

2. Use DIR / CID to scroll to >RINGER

TONE,

then press MENU/SELECT.

3. Press

DIR / CID

scroll to

CELLULAR

TONE, then press MENU/SELECT.

4. Press

DIR / CID

to get to the next ringer

tone and to hear a sample of it.

5. Press MENU/SELECT to save your preference and

return to the feature menu.

CELLULAR TONE 1

Handset settings

DIRECTORY

CALL LOG

Handset settings

Key tone

The handset is factory programmed to beep with each key press. If you turn off the KEY TONE, there will be no beeps when you press keys.

To turn the KEY TONE on or off:

KEY TONE

LANGUAGE

KEY TONE ON

DIRECTORY

CALL LOG

LANGUAGE

CLR VOICEMAIL

LANGUAGE ENGLISH

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

2. Use

DIR / CID

to scroll to >KEY TONE,

then press MENU/SELECT.

3. Press

DIR / CID

to select ON or OFF.

4. Press MENU/SELECT to save your preference

and return to the feature menu.

Language

In this menu, you can select the language used for all screen displays.

To select a language:

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

2. Use

DIR / CID

to scroll to

>LANGUAGE, then press MENU/SELECT.

3. Press

FRANÇAIS

DIR / CID

or ESPAÑOL.

to select ENGLISH,

4. Press MENU/SELECT to save your preference and

return to the feature menu.

Handset settings

Visual message waiting (voicemail) indicator

If you subscribe to a voicemail service offered by your local telephone company, the voicemail waiting indicator feature will provide a visual indication when you have new voicemail messages. The VOICEMAIL light on the telephone base will flash, and NEW VOICEMAIL and the icon will appear on the handset screen(s).

NOTES:

1. This feature does not indicate new answering system messages recorded on your phone.

2. For more information about the difference between your answering system and voicemail, see page 51.

Clear voicemail indication

DIRECTORY

CALL LOG

CLR VOICEMAIL

HOME AREA CODE

TURN OFF

INDICATOR?

NOTES:

1. Telephone company voicemail may alert you to new messages with stutter (broken) dial tone. Contact your telephone company for more details.

2. For information about using your voicemail service, contact your telephone company for assistance.

Use this feature when the telephone indicates there is new voicemail but there is none (for example, when you have accessed your voicemail while away from home). This feature only turns off the displayed NEW VOICEMAIL message, icon and VOICEMAIL light; it does not delete your voicemail message(s). As long as you have new voicemail messages, your local telephone company will continue to send the signal to activate the visual message waiting indicator.

To manually turn off the new voicemail indicator:

1. Press MENU/SELECT when in idle mode to enter

the feature menu.

2. Use DIR / CID to scroll to

>CLR VOICEMAIL, then press MENU/SELECT.

3. Press MENU/SELECT again to turn the voicemail indication off, or press OFF/CLEAR to cancel the procedure.

Handset settings

DIRECTORY

CALL LOG

HOME AREA CODE

DIRECTORY

Handset settings

Home area code

If you dial seven digits to make a local call (no area code required), program your area code into the telephone as the home area code. After setting, if you receive a call from within your home area code, the caller ID history will only display the seven digits of the telephone number.

1. Press MENU/SELECT in the idle mode to enter

the handset main menu.

HOME AREA CODE

___

2. Use

DIR / CID

to scroll to

>HOME AREA CODE, then press MENU/SELECT.

3. Press the dial pad keys to enter a three-digit

home area code. Press DELETE/MUTE to delete digit while entering.

4. Press MENU/SELECT to save and return to the

main menu.

NOTE: If, in the future, your telephone service provider requires you to dial 10 digits to make a local call (area code + phone number), re-program the home area code by following the steps above. With the home area code displayed, press and hold DELETE/MUTE to remove the contents. The home area code will now be restored to its default setting of

_ _ _

Telephone operation

HOME 0:00:30

NOTE:

Pressing

HOME/FLASH to

access services from your local telephone service provider will not affect the elapsed time.

Elapsed time

Handset operation

Making a HOME call

To make a HOME call:

• Press HOME/FLASH or SPEAKER, then enter the telephone number.

To end a HOME call:

• Press OFF/CLEAR or return the handset to the telephone base or charger.

The screen displays the elapsed time as you talk (in hours, minutes and seconds).

On-hook dialing (predialing)

• Enter the telephone number. Press DELETE/MUTE or OFF/CLEAR to make corrections when entering the phone number.

• Press HOME/FLASH or SPEAKER to dial.

Answering a HOME call

To answer a HOME call:

• Press HOME/FLASH or SPEAKER.

To end a HOME call:

• Press OFF/CLEAR or return the handset to the telephone base or charger.

Call waiting on the HOME line

If you subscribe to call waiting service with your local telephone service provider, you will hear a beep if someone calls while you are already on a call.

Press HOME/FLASH to put your current call on hold and take the new call. You can press

HOME/FLASH at any time to switch back and

forth between calls.

+ 74 hidden pages
