AT&T TL92271, TL92371, TL92471, TL92321, TL92421 User Manual

Page 1

User’s manual

TL92271/TL92371/TL92471 DECT 6.0 cordless telephone/ answering system with BLUETOOTH® wireless technology

Page 2

The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.

© 2011 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Congratulations

on purchasing your new AT&T product. Before using this AT&T product, please read Important safety information on pages 110-111 of this user’s manual. Please thoroughly read the user’s manual for all the feature operations and troubleshooting information you need to install and operate your new AT&T

product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

Model number: TL92271 (two handsets) TL92371 (three handsets) TL92471 (four handsets)

Type: DECT 6.0 cordless telephone/answering system with Bluetooth wireless technology

Serial number:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the bottom of the telephone base.

Page 3

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

Telephone line cord

Power adapter for

telephone base

Cordless handsets

(2 for TL92271) (3 for TL92371) (4 for TL92471)

Telephone base

Charger for cordless

handset with power

adapter installed

(1 for TL92271) (2 for TL92371) (3 for TL92471)

Wall mount bracket

Batteries for

cordless handsets

(2 for TL92271) (3 for TL92371) (4 for TL92471)

Battery compartment

covers (2 for TL92271) (3 for TL92371) (4 for TL92471)

User’s manual

Quick start guide

BY 1021

BT183342/BT283342

2.4V 400mAh Ni-MH

User’s manual

TL92271/TL92371/TL92471 DECT 6.0 cordless telephone/ answering system with BLUETOOTH®wireless technology

Quick start guide

TL92271/TL92371/TL92471 DECT 6.0 cordless telephone/ answering system with BLUETOOTH®wireless technology

Page 4

User’s manual

TL92271/TL92371/TL92471 DECT 6.0 cordless telephone/ answering system with BLUETOOTH® wireless technology

Table of contents

Getting started

Quick reference guide - telephone

base ................................................................... 1

Quick reference guide - handset ........ 2

Installation ..................................................... 5

Telephone base installation .................. 6

Charger installation ................................... 7

Battery installation and charging ....... 8

Battery charging ......................................... 9

Installation options ..................................10

Tabletop to wall mount

installation .............................................10

Wall mount to tabletop

installation .............................................11

Bluetooth

Introducing Bluetooth ............................12

Glossary of terms .....................................13

Bluetooth setup ........................................14

Add a cell phone ................................14

Add a headset ......................................16

Auto connection ..................................17

Device list and connection ............18

Review the active device list ........18

Connect/disconnect an active

device .......................................................18

Remove a device .................................19

Rename a device ................................20

Replace an active device ................21

Bluetooth connection from idle

mode .........................................................21

Download directory ...........................22

Interruption to directory

download ................................................24

View the directory download

information ............................................24

Change PIN ............................................25

Telephone settings

Handset settings .......................................26

Ringers .....................................................26

Ringer volume ......................................26

Ringer tone ............................................27

Set date and time ...............................28

Settings ....................................................29

LCD language .......................................29

Display alerts ........................................30

Missed call indicator .........................30

Voicemail indicator ............................31

No line .....................................................32

Download fail .......................................32

Use caller ID to automatically

set date and time ...............................33

Rename handset .................................33

Key tone ..................................................34

Dial mode ...............................................34

Caller ID announce ............................35

Website ....................................................35

Home area code ..................................36

Cell area code ......................................37

Telephone settings ..................................38

Telephone base ringer volume ....38

Answering system settings ............38

Telephone operation

Making, answering and ending a

call ...................................................................39

Using a handset for home

calls ...........................................................39

Page 5

Using a Bluetooth headset for

home calls ..............................................39

Call waiting on the home line .....40

Make, answer or end a cell

call ............................................................41

Call waiting on the cell line ..........41

Answer a cell call while on a

home call ................................................42

Cell phone voicemail ........................42

Answer a home call while on a

cell call ....................................................42

Conference calls .......................................43

Conference home and cell

calls ...........................................................43

Options while on calls ...........................44

Handset speakerphone ....................44

Volume control ....................................44

Silencing the ringer ...........................44

Mute ..........................................................44

Temporary tone dialing ...................45

Hold ...........................................................45

Equalizer ..................................................45

Chain dialing .........................................46

Transfer a call .......................................47

Redial..............................................................48

Review the redial list ........................48

Dial a redial entry ...............................48

Save a redial entry to the

directory ..................................................49

Delete a redial entry .........................49

Multiple handset use

Multiple handset use ..............................50

Handset locator ...................................50

Join a call in progress ......................50

Intercom ........................................................51

Answer an incoming call during

an intercom call ..................................52

Call transfer using intercom ...............53

Push-to-talk (PTT) ....................................54

PTT on/off ..............................................54

PTT to a single handset...................55

PTT to a group of handsets ...........56

Answer a PTT call ...............................57

Change a one-to-one PTT call

to an intercom call ............................57

End a PTT call .......................................58

Answer an incoming call during

PTT .............................................................58

Make an outgoing call during

PTT .............................................................58

Directory

About the directory .................................59

Create and review entries ....................60

Create a new entry in the home

directory ..................................................60

To add a predialed telephone

number to the directory ..................62

Review the directory .........................63

3-character alphabetical

search .......................................................63

Dial, edit or delete a directory ..........64

Dial a directory entry ........................64

Edit a directory entry ........................64

Edit the type of a directory

entry ..........................................................65

Delete a directory entry ..................65

Remove a downloaded

directory ..................................................65

Speed Dial ....................................................66

Assign a speed dial slot ..................66

Reassign a speed dial slot .............66

Dial a speed dial entry.....................66

Delete a speed dial entry ...............67

Caller ID

About caller ID ..........................................68

Information about caller ID with

call waiting ............................................68

Caller ID operation ..................................69

How the caller ID history

(caller ID log) works ..........................69

Memory match .....................................69

To review the caller ID log ............70

View dialing options ..........................71

Dial a caller ID log entry ................71

Save a caller ID log entry to the

directory ..................................................72

Table of contents

Page 6

To delete a single entry ..................73

To delete all entries ..........................73

Reasons for missing caller ID

information ............................................73

Answering system

Answering system settings ..................74

Answer on/off ......................................74

Announcement ....................................75

Play your announcement ...............75

Record your own

announcement .....................................75

Delete your announcement ...........76

Call screening .......................................77

Number of rings ..................................78

Remote access code .........................79

Message alert tone ............................79

Recording time .....................................80

About the answering system..............81

Answering system and

voicemail .................................................81

Using the answering system and

voicemail together .............................81

Message capacity ...............................82

Voice prompts ......................................82

Call screening .......................................82

Call intercept ........................................82

Temporarily turning off the

message alert tone ............................83

Message playback ....................................84

Delete all old messages ..................86

Record and play memos .................86

Base message counter displays ........87

Message window displays ..............87

Remote access ...........................................88

To remotely access the

answering system ...............................88

Remote commands ............................88

Appendix

Handset screen icons .............................89

Alert tones and lights ............................90

Handset alert tones ...........................90

Telephone base alert tones ...........90

Handset indicator lights ..................90

Telephone base indicator

lights .........................................................90

Screen messages ......................................91

Display screen messages ................91

Expand your telephone system .........94

Add and register a handset

(optional).................................................94

Deregister handsets ................................95

Troubleshooting ........................................96

Maintenance.............................................109

Important safety information ..........110

Especially about cordless

telephones ..........................................110

Precautions for users of

implanted cardiac pacemakers

.....111

Pacemaker patients ........................111

Especially about telephone

answering systems ..........................111

FCC Part 68 and ACTA........................112

FCC Part 15 ..............................................113

Limited warranty ....................................114

Technical specifications .....................116

DECT 6.0 digital technology .......116

Telephone operating range ........116

Extended range and clarity ........116

HD audio ..............................................116

Index ................................................ 117

Table of contents

Page 7

Getting started

Quick reference guide - telephone base

Message counter

Number of messages (or during playback, message number currently playing).

IN USE light

On when the handset is in use, when the answering system is answering an incoming call, or when you are registering a handset.

Flashes when another telephone is in use on the same line, or when you are deregistering handsets from the telephone base.

Flashes quickly when there is an incoming home call.

DEVICE1/DEVICE2 lights On when the telephone base

is paired and connected with a Bluetooth device.

Flash alternately while pairing with a Bluetooth device.

Flashes quickly when there is an incoming cell call.

X/DELETE

Press to delete the message currently playing (page 84).

When the phone is not in use, press twice to delete all previously reviewed messages (page 86).

/REPEAT

Press to repeat a message or press twice to play the previous message (page 84).

/ANS ON

Press to turn the answering system on or off (page 74).

/SKIP

Press to skip to the next message (page 84).

/HANDSET LOCATOR

Press to page all system handsets (page 50).

Press and hold to begin handset deregistration (page 95).

/PLAY/STOP

Press to play messages (page 84).

Press to stop message playback (page 84).

VOLUME

Press to adjust the volume during message playback (page 84).

When the phone is not in use, press to adjust the telephone base ringer volume (page 38).

Page 8

CHARGE light On when the handset is charging in the

telephone base or charger.

Softkeys (2) Press to select a menu item displayed above

the key. While in a menu, press to select an item or

save an entry or setting.

CELLULAR

Press to make or answer a cell call (page 41). During a cell call, press to answer an incoming

call when you hear a call waiting alert

(page 41).

Flashes quickly when there is an incoming cell call.

Flashes slowly when a cell call is on hold.

HOME/FLASH

Press to make or answer a home call (page 39).

During a home call, press to answer an incoming call when you hear a call waiting alert (page 40).

Flashes quickly when there is an incoming home call or when the answering system is recording a call.

Flashes slowly when a home call is on hold.

While reviewing a caller ID history entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in a directory (page 71).

TONE

Press to switch to tone dialing temporarily during a call if you have pulse service (page 45).

Press to toggle the name order when saving a caller ID log entry into directory (page 72).

/SPEAKER

Press to make or answer a home or cell call using the speakerphone.

Press to turn on the handset speakerphone. Press again to resume normal handset use

(page 44).

REDIAL/PAUSE

Press repeatedly to view the last 10 numbers dialed (page 48).

While entering numbers, press and hold to insert a dialing pause (page 60).

Quick reference guide - handset

Getting started

Page 9

Getting started

DIR /VOLUME

Press to scroll up while in menus. During a call or message playback, press to

increase the listening volume (page 44 and page 85).

Press to show directory entries when the telephone is not in use (page 63).

While entering names or numbers in the directory, press to move the cursor to the left (page 60).

MUTE/DELETE

During a call, press to mute the microphone (page 44).

While predialing, press to delete digits (page 39). While reviewing the redial list, directory or

caller ID history, press to delete an individual entry (pages 49, 65 and 73).

While entering or editing a directory entry, press to erase a digit or character.

While the handset is ringing, press to silence the ringer temporarily (page 44).

During message or announcement playback, press to delete a message or announcement (page 85 or page 76).

OFF/CANCEL

While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display (page 4).

Press and hold to return to idle mode. During a call, press to hang up (page 39). Press and hold while the telephone is not in use

to erase the displayed messages (XX Missed calls and Download fail) (page 30 and page 32).

While the handset is ringing, press to silence the ringer temporarily (page 44).

CID /VOLUME

Press to scroll down while in menus. During a call or message playback, press to

decrease the listening volume (page 44 and page 85).

Press to show the caller ID history when the telephone is not in use (page 70).

While entering names or numbers in the directory, press to move the cursor to the right (page 60).

# (pound key)

Press repeatedly to display other dialing options when reviewing a caller ID history entry (page 71).

During an outside call, intercom call, message or announcement playback, press to change the quality of the audio to best suit your hearing (page 45).

Quick reference guide - handset

Page 10

Getting started

Quick reference guide - handset

Feature menu

Play messages (page 85) Answering sys (page 74) Directory (page 59) Caller ID log (page 68) Intercom (page 51) Bluetooth (page 12) Ringers (page 26) Set date/time (page 28) Settings (page 29) Website (page 36)

Main menu

The selected menu item is highlighted.

PUSH TO TALK

Press to begin a one-to-one or one-togroup broadcast.

Press and hold to begin a one-to-group broadcast when the handset is not in use.

Using menus

Press MENU in idle mode (when the telephone is not in use) to enter the main menu.

Use CID or DIR to scroll through menu items.

Press SELECT to select or save the highlighted item.

-OR- Press OFF/CANCEL to cancel an

operation, back up to the previous menu, or exit the menu display.

-OR- Press and hold OFF/CANCEL to

return to idle mode.

NOTE: If no key is pressed, the handset automatically returns to idle mode after 30 seconds.

Page 11

Getting started

Install the telephone base close to a telephone jack and a power outlet not controlled by a wall switch. The telephone base can be placed on a flat surface or vertically mounted on the wall (page 10). For optimum range and better reception, place the telephone base in a central and open location.

You may hear interference if your cellular phone is too close to the telephone base during a CELLULAR call. Make sure that your Bluetooth enabled cellular phone is within 15 feet of the telephone base in order to maintain a clear and consistent connection between your Bluetooth cell phone, telephone base and cell tower.

If you subscribe to high-speed Internet service (digital subscriber line DSL) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (page 6). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as television sets, VCRs, or other cordless telephones.

Excessive heat sources. Noise sources such as a window with traffic outside, motors, microwave

ovens, refrigerators, or fluorescent lighting. Excessive dust sources such as a workshop or garage. Excessive moisture. Extremely low temperature. Mechanical vibration or shock such as on top of washing machine or

work bench.

•

You must install and charge the handset battery before using the cordless handset.

See pages 8-9 for easy instructions.

Installation

Page 12

Getting started

Telephone base installation

If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack. The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Follow the steps below to install the telephone.

NOTE: The telephone base comes ready for tabletop use. If you want to mount your telephone on a wall, refer to Installation options on pages 10-11 for details.

Plug the other end of the telephone line cord into the telephone jack on the bottom of the telephone base.

•

A DSL filter (not included) is required if you have DSL high-speed Internet service.

Telephone line cord

Route the cords through the guides.

•

Plug the small end of the larger power adapter into the power jack on the bottom of the telephone base.

•

Plug the large end of the larger power adapter into an electrical outlet not controlled by a wall switch.

• Plug one end of the telephone line cord into a telephone wall jack.

•

Raise the antenna.•

Page 13

Getting started

IMPORTANT INFORMATION:

Use only the power adapter(s) provided with this product. To obtain a replacement, visit our

website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The power adapters are intended to be correctly oriented in a vertical or floor mount position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.

Charger installation

Plug the power adapter into an electrical outlet not controlled by a wall switch.

Page 14

Getting started

Battery installation and charging

Install the battery as shown below.

IMPORTANT INFORMATION:

Use only the supplied rechargeable battery or replacement battery (model BT166342).

To order, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

If you do not use the handset for a long time, disconnect and remove the battery to prevent possible leakage.

•

To replace the battery, press the tab and slide the battery compartment cover downwards. Lift out the old battery and disconnect it from the handset. Follow the instructions above to install and charge the new battery.

CHARGE light

Step 3

Charge the handset by placing it face up in the telephone base or charger. The CHARGE light is on when charging.

After you install your telephone or power returns following a power outage, the handset will prompt you to set the date and time. For instructions, see Set date and time on page 28. To skip setting the date and time, press

OFF/CANCEL or BACK.

Step 1

Plug the battery connector securely into the socket inside the handset battery compartment, matching the color-coded label. Insert the supplied battery with the label THIS SIDE UP facing up as indicated.

Step 2

Align the cover flat against the battery compartment, then slide it upwards until it clicks into place.

SET DATE

--/--/--

MM/DD/YY

BACK

SET

SET TIME

--:-- --

BACK

SET

Page 15

Getting started

Battery charging

Once you have installed the battery, the screen indicates the battery status (see table below). If necessary, place the handset in the telephone base or charger to charge the battery. For best performance, keep the handset in the telephone base or charger when not in use. The battery is fully charged after 16 hours of continuous charging. See the table on page 116 for battery operating times.

If the screen is blank, you need to charge the handset without interruption for at least 30 minutes to give the handset enough charge to use the telephone for a short time. When the battery is low, the handset shows Low battery and a flashing . If you are on a call in low battery mode, the handset beeps every minute.

The following table summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank or shows Place in charger and flashes.

The battery has no or very little charge. The handset cannot be used.

Charge without interruption (at least 30 minutes).

The screen shows Low battery and flashes.

Battery has enough charge to be used for a short time.

Charge without interruption (at least 30 minutes).

The screen shows HANDSET X.

Battery is charged. To keep the battery charged,

place it in the telephone base or charger when not in use.

NOTE: If you are on a phone call in low battery mode, you hear four short beeps every minute.

Page 16

Getting started

Installation options

Your telephone base is ready for tabletop use. If you want to mount yourIf you want to mount your telephone on a wall, use the provided wall mount bracket to attach to a standard dual-stud telephone wall mounting plate. If you do not have this wall mounting plate, you can purchase one from many hardware or consumer electronics

retailers. You may need a professional to install the wall mounting plate.

Tabletop to wall mount installation

With the upper tabs (marked A) on top, align the holes of the wall mount bracket with the studs on the standard wall mounting plate and slide the bracket down until it locks securely.

Plug one end of the telephone line cord into the jack on the bottom of the telephone base and plug the other end into the telephone wall jack (or DSL filter). Plug the small end of the telephone base power adapter into the jack on the bottom of the telephone base and plug the other end into an electrical outlet not controlled by a wall switch. Route the telephone line cord and the power cord through the grooves at the bottom of the telephone base accordingly.

Hold the cords to the side of the telephone base. Align the upper slots

on the back of the telephone base just above the upper tabs (marked A) of the wall mount bracket. Make sure the lower slots of the telephone base are also aligned above the lower tabs (marked B) of the wall mount bracket. Push the telephone base down until it clicks securely in place.

Page 17

Getting started

Installation options

Wall mount to tabletop installation

To change the telephone base from the wall mount position to tabletop position, follow the steps below.

If the telephone line cord and power adapter cord are bundled, untie them first. Push the wall mount bracket up to remove it from the wall.

Unplug the telephone line cord (or DSL filter) from the wall. Unplug the power adapter from the power outlet. Lift the telephone base up to detach it from the wall mount bracket.

See Telephone base installation on page 6.

Bundle the telephone line cord and power adapter cord neatly with twist ties. Place the bundled cords into the space behind the telephone base.

Page 18

Introducing Bluetooth

Your new AT&T TL92271/TL92371/TL92471 telephone system with Bluetooth wireless technology has the following features:

Pair up to 4 Bluetooth enabled devices (cell phones or headsets) with the telephone base.

Connect a maximum of 2 cell phones to make and receive cell calls. Only one cell phone can be active on a call at a time.

Connect a Bluetooth enabled headset for making and receiving home calls. Conference cell and home calls. Make and receive calls using your cell phone plan with your cordless

system handsets.

IMPORTANT INFORMATION

After plugging in the telephone base, wait at least 20 seconds before connecting a Bluetooth device. The screen shows Bluetooth system busy if you try to connect too soon.

Refer to the user's manual of your Bluetooth enabled cell phone or headset for more information about how that device uses Bluetooth connectivity.

Bluetooth wireless technology operates within a short range (up to 30 feet) from the telephone base. Keep connected cell phones and headsets within this range.

If your cell phone has poor reception in your home, the TL92271/

TL92371/TL92471 cannot improve the reception. However, if you have a

location in your house with better reception, you can leave your cell phone in that location while you use the TL92271/TL92371/TL92471 cell line. In order for this to work, the cell phone must be within 15 feet of the telephone base for optimal performance.

Charge your cell phone while it is connected to the telephone base. Your cell phone's battery discharges faster while it is connected to the telephone base via Bluetooth wireless technology.

Monitor your cell phone's usage, because minutes may be deducted from your cellular plan for the duration of all cell calls, depending on the terms of your plan.

Refer to the Bluetooth setup section (pages 14-25) to learn how to set up your Bluetooth device. Refer to the Telephone operation section (page 39) on how to operate your Bluetooth devices with your new TL92271/

TL92371/TL92471 AT&T telephone system with Bluetooth wireless

technology. Refer to the Troubleshooting section (pages 96-108) if you experience difficulty when using the telephone system.

•

Bluetooth

Page 19

Bluetooth

Glossary of terms

Below are some terms used in this user’s manual to help you become familiar with using your Bluetooth devices and your new AT&T telephone system.

Active device slots - the Device list has two active slots for two cell phones, or one cell phone and one headset. When a device in the list is active it will have a D1: or D2: in front of the device name. In order to use a Bluetooth device on a call, it must be in an active slot and be connected.

Bluetooth cell phone - refers to a mobile Bluetooth enabled cellular telephone.

CELLULAR line - the telephone line associated with your cell phone service.

On your TL92271/TL92371/TL92471 handset, press CELLULAR to use

the cell line.

Connected - when you pair a Bluetooth device to the TL92271/TL92371/

TL92471 it is placed in an active slot and automatically connected. When a

device is connected, a 1 and/or 2 will display after on the handset screen and the DEVICE 1 and/or DEVICE 2 light on the telephone base will be on. If a device loses its connection to the telephone base, it must be reconnected before you can use the device with the TL92271/TL92371/TL92471.

Disconnected - when a device is disconnected, 1 and/or 2 displays after

on the handset screen and the DEVICE 1 and/or DEVICE 2 light on the

telephone base is off.

Discoverable mode - before a Bluetooth enabled device can be paired, it must be set to this mode. When pairing your cell phone, the telephone base is in this mode. When pairing a headset, the headset must be set to this mode. Depending on the manufacturer, this mode is sometimes referred to as

Find Me or Visibility.

HOME line - your conventional telephone land line. On your TL92271/

TL92371/TL92471 handset, press HOME/FLASH to use the home line.

Paired devices - Bluetooth enabled devices (cell phone or headset) that

have shared registration information with the telephone base. A total of four Bluetooth enabled devices can be paired with the telephone base. However, only two paired devices can be connected to the base at a time.

Pairing - sometimes refers to as bonding. The process of sharing registration information between two Bluetooth enabled devices. Your Bluetooth enabled cell phone or headset must first be paired to the telephone base in order to use it with this cordless phone system.

PIN - by default, the PIN is 0000 for the telephone base and for most Bluetooth devices. PIN information must be exchanged between Bluetooth devices before they can be used. This is also known as a Passkey or Passcode.

/ /

Page 20

Bluetooth

Bluetooth setup

To use a Bluetooth enabled cellular phone with your telephone, you must first pair and connect your Bluetooth cellular phone with the telephone base. All TL92271/TL92371/TL92471 handsets can be used to make or answer calls on the cell phone line.

Bluetooth wireless technology operates within a short range (up to 30 feet). When you pair a Bluetooth cell phone or Bluetooth headset to the telephone base, keep the device within 15 feet of the telephone base for optimal performance.

Add a cell phone

Before you begin, make sure that you have cellular coverage and your Bluetooth enabled cell phone is not connected to any other Bluetooth device. Refer to your cell phone user's manual to learn how to search for or add new Bluetooth devices.

To pair and connect a cell phone:

Press MENU in idle mode to enter the main menu. Press CID or DIR to highlight Bluetooth, then

press SELECT. Press SELECT to choose Add device. Press SELECT again to choose Add cellular. The screen

displays Please wait... followed by 1. If cell is connected to BT device, please disconnect it.

If there are already 4 paired devices on the device list, the 4th device on the device list will be automatically removed, regardless of whether the new device pairing is successful or not.

If there are already 2 active devices on the device list with prefix D1: or D2:, the handset shows Only 2 devices can be ready for connection. You are prompted to deactivate an active device.

Press NEXT. The screen displays 2. Place cell phone next

to base.

All devices that are connected to the telephone base are disconnected until the pairing process is completed.

Press NEXT to turn on the telephone base discoverable mode. The screen displays Set cell to search base: AT&T DECT 6.0 discoverable PIN: 0000. Promptly turn on the Bluetooth feature of your cell phone and search for or add new devices.

•

BLUETOOTH

Add device

Device list Download dir

BACK

SELECT

ADD DEVICE

Add cellular

Add headset

BACK

SELECT

Set cell to

search base:

AT&T DECT 6.0

discoverable

PIN:0000

Directory Caller ID log Intercom

Bluetooth

BACK

SELECT

Page 21

Bluetooth

Bluetooth setup

Your cell phone may require a passcode. In this case the handset screen displays Check cellular. ENTER PASS CODE. Enter the cell phone passcode into the handset and press SET to save.

Enter the PIN of the telephone base (the default PIN is 0000) into your cell phone to continue the pairing process. The handset displays Adding Cell Phone A to

device list...

When a device is successfully connected, the handset displays Cell Phone A is added and connected to base. You hear a confirmation tone. The corresponding status icon ( 1 or 2) displays. The corresponding device light on the telephone base (DEVICE 1 or DEVICE 2) turns on.

If you have trouble pairing your cell phone, it may not be compatible with your TL92271/TL92371/TL92471. Check the Bluetooth compatibility list at www.telephones.att.com.

NOTES:

The pairing process may take up to one minute. If the pairing process fails, try again. If you put the handset back in the telephone base or charger while pairing, the process

is cancelled and the handset returns to idle mode. If a device fails to connect, the handset displays Cell Phone A is added into the device

list, and then displays Please use cell to connect to base.

•

Adding

Cell Phone A

to device

list...

Cell Phone A

is added

and connected

to base.

Page 22

Bluetooth

Bluetooth setup

Add a headset

Before you begin, make sure that your Bluetooth enabled headset is not connected to any other Bluetooth device. Refer to your headset user's manual to learn how to search for or add new Bluetooth devices.

To pair and connect a headset:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Bluetooth, then press SELECT.

Press SELECT to choose Add device. Press CID or DIR to highlight Add headset, then

press SELECT. The screen displays Please wait... followed by If headset is connected to cell, please disconnect it.

If there is another headset already active, the screen shows Only 1 headset in device list can be ready for connection and prompt you to replace an existing paired device (page 21).

When you already have 2 active devices, the handset shows Only 2 devices can be ready for connection. The telephone base will deactivate another headset from an active slot automatically.

Press NEXT. The screen displays Pls set headset to

discoverable mode. Set your headset to discoverable mode (refer to the user’s manual of your headset), then press NEXT.

All devices that are connected to the telephone base are temporarily disconnected.

The screen displays Searching for Bluetooth headsets... When the screen displays the found devices, press CID

or DIR to highlight your headset and then press SELECT.

Enter the PIN of your headset. The PIN for most Bluetooth devices is 0000 (refer to the user’s manual of your headset). Then press NEXT.

•

FOUND DEVICES

Headset A

Headset B

BACK

SELECT

Pls set headset to discoverable mode

BACK

ADD DEVICE Add cellular

Add headset

BACK

SELECT

BLUETOOTH

Add device

Device list Download dir

BACK

SELECT

Play messages

Answering sys Directory Caller ID log

BACK

SELECT

Searching for

Bluetooth

headsets...

Directory Caller ID log Intercom

Bluetooth

BACK

SELECT

If headset is connected to cell, please disconnect it.

Page 23

Bluetooth

Bluetooth setup

The screen displays Adding Headset A to device list... when the base is connecting to your headset.

When a device is successfully connected, the handset displays Headset A is added and connected to base and the corresponding status icon ( 1 or 2). You hear a confirmation tone. The corresponding light on the telephone base (DEVICE 1 or DEVICE 2) turns on.

If you have trouble pairing your headset, it may not be compatible with your TL92271/TL92371/TL92471. Check the Bluetooth compatibility list at

www.telephones.att.com.

NOTES:

The pairing process may take up to one minute. If the pairing process fails, try again. If you put the handset back in the telephone base or charger while pairing, the process

discontinues and the handset returns to idle mode. If a device fails to connect, the handset displays Headset A is added into the device

list, and then displays Please use headset to connect to base. When a connected headset is charging, it may disconnect from the telephone base and

the corresponding light on the telephone base (DEVICE 1 or DEVICE 2) turns off. For some headset models, you may need to turn on the headset and reconnect it to the telephone base again.

Auto connection

An active device may be disconnected from the telephone base when:

The Bluetooth feature of your cell phone is turned off. The power of your device is turned off. Your Bluetooth device is not within range of the telephone base.

When the Bluetooth or power on the device is turned on or it moves within range of the base, the base will try to reconnect to the Bluetooth device. If you disconnect the device through the device list, the base will not attempt to reconnect unless your device is moved out of range and then goes back in range again.

10.

•

Adding Headset A to device

list...

Headset A

is added

and connected

to base.

Page 24

Bluetooth

Bluetooth setup

Device list and connection

Up to 4 devices can be paired to the telephone base. All paired devices are shown on the device list. To use a paired device, it must be connected and in an active slot (DEVICE 1 or DEVICE 2) on the device list. Only one Bluetooth cell phone or a headset can be on a call at a time.

Once you have paired a device with the telephone base, you do not need to repeat the pairing procedure again unless you delete the device from the device list.

NOTE:

When connecting a Bluetooth device to the device list, all connected devices will be temporarily disconnected until the procedure is complete. It may take up to 2 minutes to reconnect.

Review the active device list

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Bluetooth, then press SELECT. Press CID or DIR to highlight Device list, then press SELECT.

Connect/disconnect an active device

While in the active devices menu, you may connect or disconnect your active device.

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Bluetooth, then

press SELECT. Press CID or DIR to highlight Device list, then

press SELECT. Press CID or DIR to highlight a device, then

press OPTION. Press

CID or DIR

to highlight Connect/Disconnect (whichever is applicable), then press SELECT to confirm. The handset displays Device connected/Device disconnected. You hear a confirmation tone.

NOTE: When your active device is connected, you are prompted to select Disconnect. When your active device is disconnected, you are prompted to select Connect.

BLUETOOTH Add device

Device list

Download dir

BACK

SELECT

Directory Caller ID log Intercom

Bluetooth

BACK

SELECT

DEVICE LIST

D1:Headset A

D2:Cell Phone A Cell Phone B

BACK

OPTION

Headset A

Connect

Remove Rename

BACK

SELECT

Page 25

Bluetooth

Bluetooth setup

Remove a device

When you already have the maximum of 4 paired devices on the device list and you want to add another device, you must first delete a device from the device list.

To remove a device:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Bluetooth, then press SELECT.

Press CID or DIR to highlight Device list, then press SELECT.

Press CID or DIR to highlight a selected device, then press MUTE/DELETE.

-OR-

Press CID or DIR to highlight a selected device, then press OPTION.

Press CID or DIR to highlight Remove, then press SELECT.

The handset displays Remove Headset A? Press YES to confirm. The handset displays Device removed from

device list. You hear a confirmation tone.

•

BLUETOOTH Add device

Device list

Download dir

BACK

SELECT

Device removed

from

device list.

DEVICE LIST

D1:Headset A

D2:Cell Phone A Cell Phone B

BACK

OPTION

Headset A Connect

Remove

Rename

BACK

SELECT

Remove

Headset A

YES

Page 26

Bluetooth

Bluetooth setup

Rename a device

You can change the name of a paired device on the paired devices list.

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Bluetooth, then

press SELECT. Press CID or DIR to highlight Device list, then

press SELECT. Press CID or DIR to highlight a device when

necessary, then press OPTION. Press CID or DIR to highlight Rename, then press

SELECT. The screen displays ENTER NEW NAME.

Use the dialing keys to edit the name (page 61).

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right

or left. Press SAVE. The handset displays Device renamed. You

hear a confirmation tone.

NOTE: Only the first 11 characters of the device name are shown on the device list.

•

BLUETOOTH Add device

Device list

Download dir

BACK

SELECT

DEVICE LIST

D1:Headset A

D2:Cell Phone A Cell Phone B

BACK

OPTION

Headset A Connect Remove

Rename

BACK

SELECT

ENTER NEW NAME

Headset A _

BACK

SAVE

Page 27

Bluetooth

DEVICE LIST D1:Headset A D2:Cell Phone A

Cell Phone B

BACK

OPTION

Bluetooth setup

Replace an active device

If you already have 2 active devices on the device list and you want to activate a different device, you must deactivate one of the two active devices.

To replace an active device:

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Bluetooth, then

press SELECT. Press CID or DIR to highlight Device list, then

press SELECT. Press

CID or DIR

to highlight the device you want to

activate, without a prefix D1: or D2:, then press OPTION. Press CID or DIR to highlight Connect, then press

SELECT. The handset displays Only 2 devices can be ready

for connection and then a list of devices for deactivation.

Press CID or DIR to highlight the device to be deactivated, then press NEXT. The handset displays Cell Phone A is deactivated and you hear a confirmation tone. The screen then displays Connecting Cell Phone B to the base...

Depending on your cell phone settings, you may need to press a key on your cell phone to confirm the connection. When the new device is successfully activated and connected, the handset displays Device connected. You hear a confirmation tone.

Bluetooth connection from idle mode

When you have active devices that are not connected,

CONNECT appears on the idle handset. Press CONNECT

to start connecting an active device. When there are two active devices, the handset will prompt you to choose one before connection.

BLUETOOTH Add device

Device list

Download dir

BACK

SELECT

Connecting

Cell Phone B

to the base...

HANDSET

--:-- --/--

CONNECT MENU

DEACTIVATE

D1:Headset A

D2:Cell Phone A

BACK

DEVICE LIST

D1:Cell Phone B

D2:Cell Phone A Headset A

BACK

SELECT

Page 28

Bluetooth

Bluetooth setup

Download directory

You can download up to 4 cell phone directories (phonebooks) to your

TL92271/TL92371/TL92471 telephone system via Bluetooth wireless

technology. Each downloaded directory can store up to 1,500 entries with up to 30 digits for each phone number and 15 characters for each name.

Before downloading a directory, make sure the cell phone is paired, active, and connected to your TL92271/TL92371/TL92471. Make sure the handset battery is charged for at least 30 minutes.

Place your cell phone next to the telephone base when you download a cell phone directory to your TL92271/TL92371/TL92471.

To download a cell phone directory:

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Bluetooth, then

press SELECT. Press CID or DIR to highlight Download dir, then

press SELECT.

If there is no cell phone paired to the system, the handset displays Device list is empty. Press OK to return to the Bluetooth menu.

Press CID or DIR to select a desired device, then press SELECT.

If the selected device is active but disconnected, the handset displays Cellular phone not connected. Press CONNECT.

Press CID or DIR to highlight one of the following options:

Phone memory - download all contacts stored in your phone memory. SIM card only - download all contacts stored in your SIM card. Phone and SIM - download all contacts stored in both your phone

memory and SIM card.

Press SELECT. During the download, the handset displays the progress. All other idle system handsets display Downloading dir.

Your cell phone may require a passcode. In this case the screen displays Check cellular. ENTER PASS CODE. Enter the cell phone passcode into the handset and press SET to save.

•

BLUETOOTH Add device Device list

Download dir

BACK

SELECT

Directory Caller ID log Intercom

Bluetooth

BACK

SELECT

DOWNLOAD DIR

D1:Cell Phone A

D2:Cell Phone B

BACK

SELECT

Page 29

Bluetooth

Bluetooth setup

If the selected device’s directory has already been downloaded to TL92271/TL92371/TL92471 before, the handset displays the date of the last download from your cell phone. The directory stored on the TL92271/TL92371/TL92471 for that cell phone will be erased and replaced with the current cell phone directory. If you have edited the downloaded entries (page 64), those changes will be lost. Press NEXT to start the download, the screen displays Erasing

directory...

If you already have 4 downloaded directories, the handset displays Memory is full. Replace existing directory? Press YES if you want to replace an existing directory. Highlight the cell phone directory to be replaced and press SELECT. The screen displays Replace Cell Phone A directory? Press YES to confirm.

When the downloading process is complete, the handset displays Download ended XXXX entries saved. You hear a confirmation tone. Press OK to return to the download directory menu.

NOTES:

With certain cell phones, downloading from the SIM card is not supported. If this is the case, try transferring the contacts from your SIM card to your cell phone memory first, then download from your cell phone memory. For more information on how to transfer contacts from your SIM card to your cell phone memory, see the user’s manual of your cell phone.

If Phone memory is chosen but with no entries saved, the handset displays No entries found. Download from SIM only? Press YES to confirm. If SIM card only is chosen but with no entries saved, the handset displays No entries found. Download from Phone only? Press YES to confirm. If Phone and SIM are chosen but with no entries saved in either or both directories, the handset display No entries found. Download from Phone only? Press YES to confirm.

When downloading the directory from your Bluetooth enabled cell phone, some data may not transfer. For example, if you have home, mobile and work numbers for a particular

contact, the three categories may not transfer to your TL92271/TL92371/TL92471. On certain cell phones, you may need to press a key to confirm the directory download.

•

DOWNLOAD FROM

Phone memory

SIM card only Phone and SIM

BACK

SELECT

Cell Phone A

Downloading entry #0001...

STOP

Download ended

XXXX

entries saved

Page 30

Bluetooth

Bluetooth setupsetup

Interruption to directory download

If you are downloading a directory from a cell phone and the phone receives a call, the download process stops and all handsets display Download fail. When you try to view the downloaded directory, the handset displays Last Download failed: MM/DD/YY. You need to download the directory again (see page 22).

If you are downloading a directory from a cell phone and the telephone base loses power, the download process stops. When the telephone base regains power, the handset only displays the Home directory. You need to download the directory again (see page 22).

The download progress screen may be replaced with Cell line in use. To go back to the downloading progress screen, do Steps 1-5 on page 22. The download process continues even if any of the following occur:

You place the handset in the telephone base or charger. You access your cell phone menu features. The handset battery becomes depleted or the handset loses connection

with the telephone base.

NOTE: During the download process, do not attempt to make changes to your cell phone directory.

View the directory download information

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Directory, then press SELECT.

Press CID or DIR to choose the desired downloaded directory, then press OPTION.

Press CID or DIR to highlight Last update, then press SELECT. The directory download information appears on the screen. Press OK to exit.

•

Cell Phone A Last update: 12/12/09 Total #0159

Page 31

Bluetooth

Bluetooth setup

Change PIN

You are required to enter a PIN when establishing a Bluetooth connection. The default PIN of your telephone base is 0000.

To change the PIN:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Bluetooth, then press SELECT.

Press CID or DIR to highlight Change PIN, then press

SELECT. The handset displays ENTER NEW PIN and the

existing PIN. Use the dialing keys to enter a new 4-digit code.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits.

Press CID or DIR to move the cursor to the right or left.

Press SET to save. You hear a confirmation tone.

•

BLUETOOTH Device list Download dir

Change PIN

BACK

SELECT

ENTER NEW PIN

----

BACK

SET

Page 32

Handset settings

Ringers

In the ringers menu, you can select the ringer tones and adjust the ringer volume for incoming calls to the home and cell lines.

Ringer volume

You can select the ringer volume for the incoming home and cell calls.

To adjust the handset ringer volume:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Ringers, then press SELECT.

Press SELECT to choose Ringer volume. Press CID or DIR to select All lines, Home, Cell-D1

or Cell-D2, then press SELECT. Press CID or DIR to adjust the ringer volume. You hear

a sample of each volume level while adjusting. Press SET to save. You hear a confirmation tone.

-OR-

Press OFF to turn off the ringer, then press SET to save. The handset displays Caller ID won’t be announced. You hear a confirmation tone.

NOTES:

Changing the handset ringer volume does not affect base ringer volume. For more information on base ringer volume, see page 38.

When the ringer volume for all calls (home and cellular) is set to off, a ringer off icon

appears steady. When only one or two of the ringer volume settings are set to off, a

ringer off icon flashes. The ringer volume level also determines the ringer levels of intercom calls (page 51).

•

RINGERS

Ringer volume

Ringer tone

BACK

SELECT

RINGERS VOLUME

All lines

Home Cell-D1

BACK

SELECT

RINGERS VOLUME

OFF

SET

Telephone settings

Page 33

Telephone settings

Handset settings

Ringer tone

You can select the ringer tones for the incoming home and cell calls.

To select a ringer tone:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Ringers, then press SELECT.

Press CID or DIR to highlight Ringer tone, then press SELECT.

Press CID or DIR to highlight All lines, Home, Cell-D1 or Cell-D2, then press SELECT.

Press CID or DIR to sample each ringer tone. Press SET to save your preference. You hear a

confirmation tone.

NOTE: When you turn off the ringer volume, you will not hear ringer tone samples.

RINGERS Ringer volume

Ringer tone

BACK

SELECT

RINGERS TONE

All lines

Home Cell-D1

BACK

SELECT

RINGERS TONE

Tone 2

Tone 3 Tone 4

BACK

SET

Page 34

Telephone settings

Handset settings

Set date and time

The answering system announces the day and time of each message prior to playing it. If you subscribe to caller ID service, the day, month and time are set automatically with each incoming call. If you do not want to set the date and time automatically with caller ID information, turn this feature off (see Use caller ID to automatically set date and time on page 33). However, the year must be correct so that the day of the week can be calculated from the caller ID information. Before using the answering system, set the date and time as follows.

After handset registration or a power failure, the handset

will prompt you to set the date and time (see page 8).

To set the date and time:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Set date/time, then press SELECT.

Press CID or DIR to select the month, then press SET, or enter the 2-digit number (01-12) using the dialing keys (0-9).

Press CID or DIR to select the day, then press SET, or enter the 2-digit number (01-31) using the dialing keys (0-9).

Press CID or DIR to select the year, then press SET, or enter the 2-digit number (00-99) using the dialing keys (0-9),then press SET.

Press CID or DIR to select the hour, then press SET, or enter the 2-digit number (01-12) using the dialing keys (0-9).

Press CID or DIR to select the minute, then press SET, or enter the 2-digit number (00-59) using the dialing keys (0-9).

Press

CID or DIR

to highlight AM or PM, or press 2 for AM or 7 for PM.

Press SET to save. You hear a confirmation tone.

NOTE: If the date and time are not set when a message is recorded, the system announces,

“Time and day not set,” before each message plays.

Intercom Bluetooth Ringers

Set date/time

BACK

SELECT

SET DATE

09/30/10

MM/DD/YY

BACK

SET

SET TIME

05:41PM

BACK

SET

Page 35

Telephone settings

Handset settings

Settings

In the settings menu, you can change and edit the settings for LCD language, display alerts, CID time synchronization, handset name, key tone, dial mode and caller ID announce.

LCD language

You can select English, Français or Español to be used in all screen displays.

To select a language:

Press MENU in idle mode to enter the main menu. Press CID or DIR to highlight Settings, then

press SELECT. Press SELECT to choose LCD language. Press CID or DIR to choose from English, Français or

Español, then press SET to save. You hear a confirmation tone.

SETTINGS

LCD language

Display alerts CID time sync

BACK

SELECT

LCD LANGUAGE

English

Fran

ais

Espanol

BACK

SET

Page 36

Telephone settings

Handset settings

Display alerts

In the display alerts menu, you can change and edit the settings for the display of alerts on the idle screen.

Missed call indicator

When there are missed calls that have not been reviewed in the caller ID log, the handsets show XX Missed calls.

Each time you review a caller ID log entry marked NEW, the number of missed calls decreases by one. When you have reviewed all the missed calls, the missed call indicator goes away.

If you do not want to review the missed calls one by one, you can reset the missed call indicator. All the entries are then considered old and kept in the caller ID log.

To reset the missed call indicator:

Press MENU in idle mode to enter the main menu. Press CID or DIR to highlight Settings, then press

SELECT.

Press CID or DIR to highlight Display alerts, then press SELECT.

Press CID or DIR to highlight Home line or Cell line, then press SELECT.

Press CID or DIR to highlight Missed calls, then press SELECT to confirm. The screen displays Reset missed call indication? Press YES to confirm. You hear a confirmation tone.

You can also press and hold OFF/CANCEL to erase the missed call indicator when the telephone is not in use.

SETTINGS LCD language

Display alerts

CID time sync

BACK

SELECT

HOME ALERTS

Missed calls

Voicemail No line

BACK

SELECT

Page 37

Telephone settings

Handset settings

Voicemail indicator

If you subscribe to voicemail service offered by your telephone service provider, New voicemail and

appear on the handsets when you have new voicemail messages. Contact your telephone service provider for more information and assistance about using your voicemail service.

After you have listened to all new voicemail messages, the indicators on the handsets turn off automatically.

Reset the voicemail indicators when the telephone indicates that there is new voicemail but there is none (for example, when you have accessed your voicemail while away from home). Clearing the voicemail waiting indicators only turns off the indicators; it does not delete your voicemail messages. As long as you have new voicemail messages, your telephone service provider continues to send the signal to turn on the indicators.

To reset the voicemail indicator:

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Settings, then

press SELECT.

Press CID or DIR to highlight Display alerts, then press SELECT.

Press CID or DIR to highlight Home line, then press SELECT.

Press CID or DIR to highlight Voicemail, press SELECT. The handset displays Reset voicemail indication?

Press YES to confirm. You hear a confirmation tone.

HOME ALERTS Missed calls

Voicemail

No line

BACK

SELECT

DISPLAY ALERTS

Home line

Cell line

BACK

SELECT

Page 38

Telephone settings

Handset settings

No line

If there is no telephone line connected to the telephone base, the handsets show No home line. If you do not want to display the message on the handset screens (for example, if you use the cell line only), you can turn off the no line alert.

To turn the no line alert on or off:

Press MENU in idle mode to enter the main menu. Press CID or DIR to highlight Settings, then

press SELECT. Press CID or DIR to highlight Display alerts, then

press SELECT. Press CID or DIR to highlight Home line, then

press SELECT.

Press CID or DIR to highlight No line, then press SELECT.

Press CID or DIR to choose On or Off, then press

SET to save. When you choose Off, the handset displays

If the line is not connected, an alert will not appear. You hear a

confirmation tone.

Download fail

If the directory download process is interrupted, the handsets display

Download fail. You can reset the download fail indication on the handset.

To reset the download fail indication:

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Settings, then

press SELECT. Press CID or DIR to highlight Display alerts, then

press SELECT. Press CID or DIR to highlight Cell line, then

press SELECT.

Press CID or DIR to highlight Download fail, then press SELECT.

The handset displays Reset download failure indication? Press YES to confirm. You hear a confirmation tone.

You can also press and hold OFF/CANCEL to erase the download fail indicator when the telephone is not in use.

HOME ALERTS Missed calls Voicemail

No line

BACK

SELECT

NO LINE ALERT

On

Off

BACK

SET

CELL ALERTS Missed calls

Download fail

BACK

SELECT

Reset

download

failure

indication?

YES

Page 39

Telephone settings

Handset settings

Use caller ID to automatically set date and time

If you subscribe to caller ID service, the date and time will be set automatically by the caller ID information. You can turn off this feature if you want to set the date and time manually.

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Settings, then press SELECT.

Press CID or DIR to select CID time sync, then press SELECT.

Press CID or DIR to select On or Off, then press

SET to save. You hear a confirmation tone.

Rename handset

You can change the name of each handset, the new name of each handset cannot exceed 11 characters.

To rename a handset:

Press MENU on the handset when it is not use. Press CID or DIR to highlight Settings, then

press SELECT. Press CID or DIR to highlight Rename handset, then

press SELECT. The screen displays RENAME HANDSET. Use the dialing keys to edit the name. Press MUTE/DELETE

to erase a character.

Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right

or left.

Press SAVE. You hear a confirmation tone.

•

CID TIME SYNC

On

Off

BACK

SET

SETTINGS LCD language Display alerts

CID time sync

BACK

SELECT

SETTINGS Display alerts CID time sync

Rename handset

BACK

SELECT

RENAME HANDSET

Room A _ __ _ _

BACK

SAVE

Room A

12:31PM 12/31

Page 40

Telephone settings

Handset settings

Key tone

The handset is set to beep with each key press. If you turn off the key tone, there are no beeps when you press keys.

To change the setting:

Press MENU on the handset in idle mode to enter the main menu.

Use CID or DIR to scroll to Settings, then press SELECT.

Press CID or DIR to scroll to Key tone, then press SELECT.

Press CID or DIR to adjust the key tone volume. You hear a sample of each key tone volume while adjusting. Press SET to save your preference.

-OR-

Press OFF to turn off, then press SET to save. You hear a confirmation tone.

Dial mode

The dial mode is preset to tone dialing. If you have pulse (rotary) service, you must change the dial mode to pulse dialing before using the telephone.

To change the setting:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Settings, then press SELECT.

Press CID or DIR to highlight Dial mode, then press SELECT.

Press CID or DIR to choose Tone or Pulse, then press SET to save. You hear a confirmation tone.

SETTINGS CID time sync Rename handset

Key tone

BACK

SELECT

SETTINGS Rename handset Key tone

Dial mode

BACK

SELECT

DIAL MODE

Tone

Pulse

BACK

SET

KEY TONE VOLUME

OFF

SET

Page 41

Telephone settings

Handset settings

Caller ID announce

The caller ID announce feature lets you know who’s calling without having to look at the display. When you have an incoming call, the handset and/or base speaks “Call from...” and the name of the caller based on the directory or caller ID information. If the caller’s name is private or unknown, the phone number up to the last 11 digits will be announced. If the caller’s phone number is also private or unknown, no information will be announced. By default, the caller ID announce feature is programmed On.

To change the setting:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Settings, then press SELECT.

Press CID or DIR to highlight Caller ID Annc, then press SELECT.

Press CID or DIR to highlight Handset or Base, then press SELECT. Press CID or DIR to choose On or Off, then press SET to save. You hear

a confirmation tone.

NOTES:

To use the caller ID announce feature, you must subscribe to caller ID service from your telephone service provider.

When there are up to 5 handsets registered, the telephone system supports caller ID announce for all handsets. If six or more handsets are registered, the system supports caller ID announce for the first four registered handsets only.

This feature is not supported with headsets. This feature does not announce information for call waiting calls. If both home and cell lines are ringing, only the caller ID information of the first ringing

line will be announced. Caller ID announce is available in English only. It takes at least 2 rings for the phone to receive caller ID information and announce it.

If the phone is answered before the end of the second ring, the phone won’t have time to announce the caller ID information.

Pronunciation of names may vary with this feature. Not all names may be pronounced correctly.

•

SETTINGS Key tone Dial mode

Caller ID Annc

BACK

SELECT

CALLER ID ANNC

On

Off

BACK

SET

CALLER ID ANNC

Handset

Base

BACK

SELECT

Page 42

Telephone settings

Handset settings

Website

You can use this feature to view the AT&T website address.

Press MENU on the handset in idle mode to enter the main menu.

Use CID or DIR to scroll to Website, then press

SELECT. The handset screen shows the AT&T

website address. Press OK to exit.

Home area code

If you dial 7 digits to make a local call (area code not required), enter your area code into the telephone as the home area code. When you receive a

call from within your home area code, the caller ID history only displays the 7 digits of the telephone number.

This feature makes it easy for you to place a call from the caller ID log. If you dial 10 digits to make a local phone call, do not use this home area code feature. If you do, you cannot place local calls from your caller ID log, as they will have only 7 digits.

To set the home area code:

Press MENU on the handset in idle mode to enter the main menu. Press CID or DIR to highlight Directory, then press SELECT. Press OPTION to choose Home. Press CID or DIR to highlight Home area code, then press SELECT.

The screen displays Only for 7 digits dialing from Caller ID log. Use the dialing keys to enter the desired home area code.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits.

Press CID or DIR to move the cursor to the right or left.

Press SET to save. The handset displays Area code will not show in Caller ID log. You hear a confirmation tone.

NOTE: If, in the future, your telephone service provider requires you to dial 10 digits to make a local call (area code + telephone number), you will need to delete your home area code. With the home area code displayed, press and hold MUTE/

DELETE

, and then press

SET. The home area code is now restored to its default setting of _ _ _ (empty).

•

HOME AREA CODE

-- -

BACK

SET

Ringers Set date/time Settings

Website

BACK

SELECT

www.telephones .att.com

Page 43

Telephone settings

Handset settings

Cell area code

Most cell phone entries are stored in a 10-digit format. If all of your cell phone entries are stored this way, you do not need to program your cell area code.

If your cell phone stores entries in a 7-digit format, we recommend that you program your cell area code so that your 7-digit directory entries can be dialed correctly using your home line.

To set the cell area code:

Press MENU on the handset in idle mode to enter the main menu. Press CID or DIR to highlight Directory, then press SELECT. Press CID or DIR to highlight a desired downloaded directory, then

press OPTION. Press SELECT to choose Cell area code. The handset displays Only for 7

digits dialing from Caller ID log. Use the dialing keys to enter the desired cell area code.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits. Press CID or DIR to move the cursor to the right or left.

Press SET to save. The handset screen displays Area code will not show in Caller ID log. You hear a confirmation tone.

•

Page 44

Telephone settings

Telephone base ringer volume

Press VOLUME on the telephone base to adjust the ringer volume when the telephone is not in use. When you set the ringer volume to zero, the base ringer is off and the system announces, “Base ringer is off.”

Press /VOLUME during an incoming call to mute the ringer temporarily.

Answering system settings

Go to Answering system settings starting on page 74 for instructions on how to use a system handset to modify the answering system settings shown below.

Setting Page

Answer on/off 74

Announcement (play, record and delete) 75-76

Call screening 77

Number of rings 78

Remote access code 79

Message alert tone 79

Recording time 80

Page 45

Making, answering and ending a call

Using a handset for home calls

To make a home call:

Press HOME/FLASH or /SPEAKER, then enter the telephone number.

To predial a home call:

Enter the telephone number, then press HOME/FLASH or /SPEAKER.

To answer a home call:

Press HOME/FLASH or /SPEAKER.

To end a home call:

Press OFF/CANCEL or put the handset in the telephone base or charger.

NOTES:

The screen shows the elapsed time as you talk (in hours, minutes and seconds).

When predialing (preview numbers before dialing), press MUTE/DELETE to backspace and delete; press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

You cannot answer a home call using your connected cell phone.

Using a Bluetooth headset for home calls

You can use a Bluetooth headset on home calls. However, you need to keep the device within 15 feet of the telephone base for optimal performance. Please see the user’s manual of your Bluetooth headset for more information.

To answer a home call using a Bluetooth headset:

Press the call key on your headset.

To end a home call you answered from a Bluetooth headset:

Press the call key on your headset.

If you make or answer a home call on a handset, you can transfer the call to your headset. The handset remains active, but the handset earpiece and microphone are muted. If you hang up the handset, the call ends.

•

Telephone operation

Page 46

Telephone operation

Making, answering and ending a call

To transfer a call from a handset to a Bluetooth headset:

Press OPTION. Press CID or DIR to highlight Use BT headset, then press SELECT

twice. The screen displays Transferring audio to Headset A, the message disappears if the call is successfully transferred to the Bluetooth headset.

NOTES:

If you answer a call from the headset, that call cannot be transferred to a handset. You will not see Use BT headset when the Bluetooth headset is already in use, or there

are no active Bluetooth headsets in the device list. While using the cell line, you cannot choose Use BT headset.

To transfer a call from the Bluetooth headset back to the handset:

Press OPTION, then press CID or DIR to highlight Use handset and press SELECT.

To end a call that started at the handset:

Press OFF/CANCEL or put the handset in the telephone base or charger.

NOTES:

If you answer a call using a headset, and you lose the Bluetooth connection or the battery is depleted, the call is lost.

If you are using a headset for a call which is transferred from a TL92271/TL92371/

TL92471 handset, and you lose the Bluetooth connection or the battery of the headset

is depleted, the call is transferred back to the originating handset.

Call waiting on the home line

If you subscribe to call waiting service with your telephone service provider, you hear a tone in the handset earpiece if someone calls while you are already on a call.

Press HOME/FLASH on the handset to put your current call on hold and take the new call.

Press HOME/FLASH on the handset at any time to switch back and forth between calls.

•

Page 47

Telephone operation

Making, answering and ending a call

Make, answer or end a cell call

You can connect a maximum of 2 Bluetooth enabled cell phones to the telephone base, but only one cell phone can be used on a cell call at a time. All TL92271/TL92371/TL92471 handsets can be used to make or answer calls on the cell phone line.

To make a cell call:

Enter the telephone number, then press CELLULAR.

-OR-

Press

CELLULAR.

Enter the telephone number, then press DIAL.

If you have only one cell phone connected to the telephone base, it is automatically selected to make cell calls. If you have two cell phones connected to the telephone base, the telephone system prompts you to select a cell phone before you make a cell call.

To answer a cell call:

Press CELLULAR.

NOTE: You can also use your cell phone to answer the call. If you answer with your cell

phone, it disconnects from the telephone base.

To end a cell call:

Press OFF/CANCEL or put the handset in the telephone base or charger.

Call waiting on the cell line

If you subscribe to call waiting service with your cell phone service provider, you hear a call waiting tone if someone calls while you are already on a call.

Press CELLULAR on the handset to put your current call on hold and take the new call.

Press CELLULAR on the handset at any time to switch back and forth between calls.

-OR-

Press SWAP to switch. To switch back, press OPTION. Press CID or DIR to highlight Swap, then press SELECT.

•

Page 48

Telephone operation

Making, answering and ending a call

Answer a cell call while on a home call

If you are on a home call and you receive an incoming cell call, you hear a beep and 1 or 2 displays on the handset you are using. The telephone

base and all other handsets ring.

To answer the incoming cell call:

Press CELLULAR on the handset. The home call is automatically placed on hold and all other handsets display Home call on hold and

Cell line in use alternately.

To end the cell call:

Press OFF/CANCEL on the handset. The home line is still on hold. All handsets display Home call on hold.

To resume the home call on hold:

Press HOME/FLASH on the handset.

Cell phone voicemail

If you have voicemail service active on your cell phone, and you do not answer the incoming cell call, the call is answered by your cell phone’s voicemail. Contact your cell phone service provider for more information about voicemail service.

Answer a home call while on a cell call

If you are on a cell call and you receive an incoming home call, you hear a beep and displays on the handset you are using. The telephone base and all other handsets will ring.

To answer the incoming home call:

Press HOME/FLASH on the handset. The cell call is automatically placed on hold and all other handsets display Cell call on hold and

Home line in use alternately.

To end the home call:

Press OFF/CANCEL on the handset. The cell line is still on hold. All handsets display Cell call on hold.

To resume the cell call on hold:

Press CELLULAR on the handset.

NOTE: If you have turned on your answering system and you do not answer the incoming

home call, the call is answered by your answering system.

•

Page 49

Telephone operation

Conference calls

Conference home and cell calls

When you have calls established on the home and cell lines, you can create a 3-way conference.

To conference both home and cell calls:

Press OPTION. Press CID or DIR to highlight Conference. Press SELECT. The screen displays Lines now in conference.

To select an option while on a conference call:

Press

OPTION.

Press CID or DIR to select one of the following options:

End Home line End Cell line End Conference Directory

Press SELECT.

To end a conference call:

Press OFF/CANCEL or put the handset back in the telephone base or charger.

-OR-

Press OPTION, then press CID or DIR to highlight End Conference. Press SELECT to end the conference.

Using the home and cell lines together:

You can be on two different calls using the cell line and home line at the same time using two handsets.

You cannot be on a call using the cell line and a Bluetooth headset via the home line at the same time. These are both Bluetooth devices and only one can be used at a time.

If you are on a call using the cell line, you cannot join the call using your paired cell phone. However, you can join the call using another TL92271/

TL92371/TL92471 handset. Your cell phone is being used for the phone

call so only features that are normally available during a call can be used.

•

Page 50

Telephone operation

Options while on calls

Handset speakerphone

During a call or message playback, press /SPEAKER to switch between speakerphone and normal handset use.

Volume control

During on a call or message playback, press /VOLUME to increase or press

/VOLUME to decrease the listening volume. You hear a beep from the

handset earpiece while adjusting. If you turn off the key tone, the beep will not be heard.

If this is a cell call and the volume is too loud or quiet, try changing the volume on your cell phone. On some cell phones, changing the volume on the cell phone affects your cell call volume on the TL92271/TL92371/

TL92471 handset.

Silencing the ringer

When the telephone is ringing, you can temporarily silence the ringer of the handset or telephone base without disconnecting the call. The next call rings normally at the preset volume.

To silence the ringer:

Press SILENCE, OFF/CANCEL or MUTE/DELETE on the handset and Ringer muted appears.

Mute

Use the mute function to turn off the microphone. You can hear the caller, but the caller does not hear you.

To mute a call:

While on a call, press MUTE/DELETE. When mute is on, the handset screen shows Microphone off for a few seconds and the MUTE icon appears until the mute function is turned off.

To take a call off mute:

Press MUTE/DELETE and resume speaking. When mute is off, Microphone on appears temporarily on the handset screen.

Mute is automatically canceled when you end the call.

•

Home 0:00:15

10:06am 8/10

HOLD

OPTION

Microphone off

Home 0:00:15

10:06am 8/10

HOLD

OPTION

MUTE

Page 51

Telephone operation

Options while on calls

Temporary tone dialing

If you have pulse (rotary) service only, you can switch from pulse to touch-tone dialing temporarily during a call. This is useful if you need to send touch-tone signals to access your telephone banking or long distance services.

During a call:

Press TONE . Use the dialing keys to enter the relevant number. The telephone sends

touch-tone signals. The telephone automatically returns to pulse dialing mode after you end

the call.

Hold

You can place a home or cell call on hold. You hear an alert tone if you have not taken the call off of hold after 14 minutes. You hear another alert tone 30 seconds later. At 15 minutes on hold, the call on hold automatically disconnects.

To place a home call on hold:

Press HOLD. Home call on hold appears and HOME/FLASH flashes.

To resume a home call on hold:

Press HOME/FLASH.

To place a cell call on hold:

Press HOLD. Cell call on hold appears and CELLULAR flashes.

To resume a cell call on hold:

Press CELLULAR.

Equalizer

The equalizer feature on the handset enables you to change the quality of the handset audio to best suit your hearing.

While on a call, or listening to a message or announcement, press EQ to select the equalizer setting Treble 1, Treble 2, Bass or Natural (the default setting) for the handset. The current setting is shown on the handset for two seconds.

NOTES:

The equalizer feature does not apply to the speakerphone on the telephone base or the connected Bluetooth headset.

If you switch the call between the handset and speakerphone by pressing /SPEAKER, the audio setting remains unchanged.

The current equalizer setting remains unchanged until a new setting is selected.

•

Page 52

Telephone operation

Options while on calls

Chain dialing

Use this feature to initiate a dialing sequence from numbers stored in the directory, caller ID log or redial list while you are on a call.

Chain dialing can be useful if you wish to access other numbers (such as bank account numbers or access codes) from the directory, caller ID log or redial list.

To access a number in the directory while on a call:

Press OPTION. Press CID or DIR to highlight Directory, then press SELECT. Press CID or DIR to highlight the desired directory, then press REVIEW. Press CID or DIR to highlight to the desired entry or perform an

alphabetical search (page 63). Press DIAL to dial the displayed number.

To access a number in the caller ID log while on a call:

Press OPTION. Press CID or DIR to highlight Caller ID log, then press SELECT. Press CID or DIR to highlight the desired directory, then press REVIEW. Press CID or DIR to scroll to the desired entry. Press DIAL to dial the displayed number.

To access the redial list while on a call:

Press REDIAL/PAUSE. Press CID , DIR, or REDIAL/PAUSE until the desired number displays,

then press DIAL to dial the displayed number.

NOTES:

You cannot edit a directory entry while on a call. For more details about the directory, see page 59.

You cannot copy a caller ID log entry into the directory while on a call. For more details about caller ID log, see page 69.

You can only view the numbers in the directory, caller ID log or redial list while on a call and cannot edit, delete or save entries.

Press OFF/CANCEL to exit redial list, directory or caller ID log while on a call.

•

Page 53

Telephone operation

Options while on calls

Transfer a call

While on an outside call, you can transfer the call from one handset to another.

Press OPTION, then press SELECT to highlight Transfer.

If you have two handsets, your handset displays Transferring call

to HANDSET X. The destination handset rings and displays Home Transfer from other handset.

If you have three or more handsets, your handset displays TRANSFER TO: and a list of registered handsets. Press CID or DIR to highlight the destination handset and then press SELECT. Your handset displays Transferring call to HANDSET X, or Transferring call to all... when you choose All handsets. The destination rings and displays Home Transfer from HANDSET X to all.

Your handset displays Call transferred when the other handset picks up the call. You hear a confirmation tone.

NOTE: If the destination handset does not answer within 30 seconds, the caller handset displays No response to transfer and rings. If the caller handset does not answer the call on hold within 30 seconds, the call will end automatically.

•

Page 54

Telephone operation

Redial

Each handset stores the last 10 dialed numbers (up to 30 digits each) in the redial list. The redial entries are not shared by all the system handsets.

Review the redial list

Press REDIAL/PAUSE in idle mode.

Press

CID , DIR

or REDIAL/PAUSE repeatedly to

browse the list. The handset beeps twice at the end of the list.

Press OFF/CANCEL to exit.

Dial a redial entry

Press

REDIAL/PAUSE

in idle mode.

Press

CID , DIR

or REDIAL/PAUSE repeatedly to browse

until the desired number displays. The handset beeps twice at the end of the list.

Press HOME/FLASH or /SPEAKER to use the home line.

-OR-

Press CELLULAR to use the cell line.

1/2

REDIAL

888-883-2445

SAVE

Page 55

Telephone operation

Redial

Save a redial entry to the directory

Press REDIAL/PAUSE in idle mode. Press

CID , DIR

or REDIAL/PAUSE repeatedly to browse until the desired

number displays. Press SAVE. The handset displays EDIT NUMBER. Use the dialing keys to edit the

number, if necessary.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits. Press CID or DIR to move the cursor to the right or left.

Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

Press NEXT. Press CID or DIR to select one of the following types:

Home Cell Work Other

Press NEXT. The handset displays ENTER NAME. Use the dialing keys (page 61) to enter a name.

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right or left.

Press SAVE and then Saved displays. You hear a confirmation tone.

Delete a redial entry

Press REDIAL/PAUSE when the handset is not in use. Press

CID , DIR

or REDIAL/PAUSE repeatedly to browse until the desired

number displays. Press MUTE/DELETE to delete the displayed number. You hear a

confirmation tone.

•

Page 56

Multiple handset use

Handset locator

This feature helps you find a misplaced handset.

To start paging:

Press /HANDSET LOCATOR on the telephone base when it is not in use. All idle handsets ring and display ** Paging **.

To end paging:

Press /HANDSET LOCATOR on the telephone base.

-OR-

Press HOME/FLASH, /SPEAKER, CELLULAR, PUSH TO TALK, REDIAL/ PAUSE, EQ

or any dialing key (0-9, #,

TONE

) on the handset.

NOTES:

If the handset ringer volume is set to off, the handset still rings when paged.

If there is no response after 60 seconds, paging ends.

Join a call in progress

Another handset can join you on an outside call. That call continues until all people hang up. You can share an outside call with up to 4 system handsets.

Press HOME/FLASH or /SPEAKER on another handset to join the call.

-OR-

Press OPTION during an intercom, then press CID or DIR to highlight Share call. Press SELECT.

•

Multiple handset use

Page 57

Multiple handset use

Intercom

Use the intercom feature for conversations between two system handsets.

You can buy additional expansion handsets (AT&T model TL90071, sold separately) for this telephone system. You can register up to 12 handsets to the telephone base.

To initiate an intercom call:

Press MENU on the handset in idle mode.

Press CID or DIR to highlight Intercom, then press SELECT.

If you have two handsets, your handset displays Calling other handset. The destination handset rings and displays Other handset is calling.

If you have three or more handsets, your handset displays INTERCOM and a list of registered handsets.

Press CID or DIR to select a destination handset and then press SELECT. Your handset displays Calling HANDSET X, or Calling all handsets when you choose All handsets.

-OR-

Press 1-9 for HANDSET 1-9, TONE and 0 for HANDSET 10,

TONE and 1 for HANDSET 11 or TONE and 2 for HANDSET 12.

Your handset displays Calling HANDSET X. The other handset rings and displays HANDSET X is calling.

-OR-

Press TONE and then # (pound key) to call all handsets.

The destination handset(s) rings and displays HANDSET X is calling, or

HANDSET X is calling all when you choose all handsets.

To answer an intercom call at the destination handset:

Press

HOME/FLASH or

/SPEAKER

. Both handsets show Intercom.

•



•

Answering sys Directory Caller ID log

Intercom

BACK

SELECT

INTERCOM HANDSET 2 HANDSET 3

All handsets

BACK

SELECT

Page 58

Multiple handset use

Intercom

To silence an intercom call:

Press OFF/CANCEL, MUTE/DELETE or SILENCE on the destination handset. Its screen displays Ringer muted for a few seconds.

To end an intercom call:

Press OFF/CANCEL, END or place either handset back in the telephone base or charger. Both handsets display Intercom ended.

NOTES:

You can cancel the intercom call before it is answered by pressing OFF/CANCEL or

END on your originating handset.

If you are calling all handsets, only the first handset to pick up can answer the intercom call.

If the destination handset does not answer the intercom call within 100 seconds, is in the directory or caller ID log, or is out of range, the originating handset displays No

answer. Try again. and returns to idle mode.

Answer an incoming call during an intercom call

When you receive an incoming home call during an intercom call, the two handsets on the intercom call hear an alert tone, and their screens display Home Incoming call and then the caller ID. The telephone base and all other handsets ring.

Press HOME/FLASH to answer the home call and the intercom call ends automatically.

Press OFF/CANCEL to end the intercom call without answering the incoming call. The telephone continues to ring.

When you receive an incoming cell call during an intercom call, the two handsets on the intercom call hear an alert tone, and their screens display Cell Incoming call and then the caller ID. The telephone base rings and all other handsets ring.

Press CELLULAR to answer the cell call and the intercom call ends automatically.

Press OFF/CANCEL to end the intercom call without answering the incoming call. The telephone continues to ring.

•

Page 59

Multiple handset use

Call transfer using intercom

Use the intercom feature to transfer an outside call to another system handset without first notifying the other party.

When on an outside call, press OPTION.

Press CID or DIR to highlight Intercom, then press

SELECT. The call is automatically put on hold.

If you have a two-handset system, the outside call is put on hold and your handset displays Calling other

handset. The other handset rings and displays Other handset is calling.

If you have three or more handsets, your handset displays INTERCOM TO:.

Press CID or DIR to select a destination handset and then press

SELECT. Your handset displays Calling HANDSET X, or Calling all

handsets when you choose All handsets.

-OR-

Press 1-9 for HANDSET 1-9, TONE and 0 for HANDSET 10,

TONE and 1 for HANDSET 11 or TONE and 2 for HANDSET 12.

-OR-

Press TONE and then # (pound key) to call all handsets.

The destination handset rings and displays HANDSET X is calling, or HANDSET X is calling all when you choose all handsets.

To answer the call on the other handset, press HOME/FLASH or

/SPEAKER. The outside call is still on hold and both handsets now

show Intercom. From this intercom call, you have the following options:

You can transfer the call. Press OPTION and then press

SELECT to choose Transfer on the calling handset.

Your screen shows Call transferred. The other handset automatically connects to the outside call.

You can let the other handset join you on the outside call in a three-way conversation. Press OPTION, highlight Share call, and press SELECT.

Either person can press the appropriate line key (

HOME/FLASH or

CELLULAR) on the handset to

take the held outside call, or press OFF/CANCEL or

END to hang up the intercom call (the outside call will

automatically go off hold for the handset that did not hang up).

NOTES:

If you want to cancel an intercom call and reconnect to the outside call before the destination handset answers, press OFF/CANCEL or END on the originating handset.

If the other handset does not answer the intercom call within 100 seconds, or if the other handset is in the directory or caller ID log, or is out of range, the calling handset shows No answer. Try again. and returns to the outside call.

•



•

Transfer

Intercom

Directory Caller ID log

BACK

SELECT

INTERCOM HANDSET A 2 HANDSET B 3

All handsets

BACK

SELECT

Intercom

END

OPTION

Transfer

Share call

BACK

SELECT

Page 60

Multiple handset use

Push-to-talk (PTT)

You can directly broadcast messages from one handset to the speakerphone of one or all other handsets. Any handset called can respond by pressing PUSH TO TALK to begin a two-way communication. If only one handset is available or registered, the handset screen shows PTT requires two handsets when you press PUSH TO TALK.

Only one handset can talk at a time. To do so, press and hold the PUSH TO TALK button.

You must release PUSH TO TALK, so the other person can respond.

Only one PTT can be active at a time.

While PTT is in use between handsets, other handsets cannot use the intercom feature but can access the answering system.

When you attempt to place a PTT call to another handset which is accessing the answering system, your handset displays Not available at

this time.

PTT on/off

You can turn PTT on or off on each handset.

When on, the handset can begin and receive PTT calls.

When off, the handset can begin PTT calls but will not receive PTT calls from other handset(s). The idle handset displays No Incoming PTT.

When you attempt to place a PTT call to another handset that has the PTT feature turned off, your handset displays

Not available at this time.

To turn PTT on or off:

Press PUSH TO TALK when the handset is not in use. The PUSH TO TALK menu displays.

Press CID or DIR to highlight PTT On/Off, then press SELECT.

Press CID or DIR to highlight On or Off, then press

SELECT to save. You hear a confirmation tone.

•

PUSH TO TALK HANDSET A 2 HANDSET B 3

Group

BACK

SELECT

INCOMING PTT

On

Off

BACK

SELECT

Page 61

Multiple handset use

Push-to-talk (PTT)

PTT to a single handset

You have 2 ways to begin a PTT call:

If you have two handsets, press and hold PUSH TO TALK when the handset is not in use.

-OR-

If you have three or more handsets, press PUSH TO TALK when the handset is not in use. Then use the dialing keys to enter a handset number (1-9 for handsets 1-9, TONE and 0 for handset 10, TONE and 1 for handset 11 or TONE and 2 for handset 12), or press CID or DIR to scroll to the desired handset then press

SELECT or PUSH TO TALK to create the push-to-talk session.

Your handset displays Connecting to HANDSET X... for a few seconds. When the connection is made, both your and the destination handsets display Press and hold [PTT] to talk and beep once.

Press and hold PUSH TO TALK on your handset. A chirp indicates your microphone is on. Speak towards the handset. Your voice is broadcast to the destination handset. While you are speaking, the handset displays PTT To HANDSET X (X represents the destination handset number).

Release PUSH TO TALK after speaking. Both handsets beep once again. After the handsets beep, you can press and hold PUSH TO TALK to continue speaking or the destination handsets can respond (see Answer a PTT call on page 57).

To end the PTT call, press OFF/CANCEL or END. The handset displays

Push to talk Ended for a few seconds.

-OR-

Place the handset in the telephone base or charger to end the PTT call.

NOTE: After PUSH TO TALK is released, the PTT call remains open for a short time. If no one presses PUSH TO TALK within 10 seconds, the PTT call ends automatically.

•

Page 62

Multiple handset use

Push-to-talk (PTT)

PTT to a group of handsets

When there are multiple handsets registered to the phone system, PTT supports one-to-group calls. PTT supports a maximum of one-to-four calls when two to five handsets are registered, and a maximum of one-to-three calls when six or more handsets are registered. The first 4 registered handsets will be able to use this feature. Other handsets can only use PTT for one-to-one calls.

To begin a PTT call to a group of handsets:

Press and hold PUSH TO TALK when the handset is not in use.

-OR-

Press PUSH TO TALK when the handset is not in use. Press TONE and #, or press CID or DIR to highlight Group then press SELECT or PUSH TO TALK.

Your handset displays Connecting to group... for a few seconds. When the connection is made, both your and the destination handsets display Press and hold [PTT] to talk and beep once.

Press and hold PUSH TO TALK on your handset. A chirp indicates your microphone is on. Speak towards the handset. Your voice is broadcast to the destination handset. While you are speaking, the handset displays PTT To handset X (X represents the destination handset numbers).

Release PUSH TO TALK after speaking. All handsets beep once again. After the handsets beep, you can press and hold PUSH TO TALK to continue speaking or the destination handsets can respond (see Answer a PTT call on page 57).

Press OFF/CANCEL or END to end the PTT call. The handset displays

Push to talk Ended for a few seconds.

-OR-

Place the handset in the telephone base or charger to end the PTT call.

NOTE: After PUSH TO TALK is released, the PTT call remains open for a short time. If no one presses PUSH TO TALK within 10 seconds, the PTT call ends automatically.

•

Page 63

Multiple handset use

Push-to-talk (PTT)

Answer a PTT call

You can respond to a PTT call whenever the speakerphone light is off, as described below.

When your handset receives a PTT call, the handset beeps and displays Press and hold [PTT] to talk.

When someone else is speaking, your speakerphone light is on, and you handset displays PTT From HANDSET X To handset: Y (the first X represents the initiating handset number and Y represents your handset number; a maximum of 4 handset numbers appear).

When your speakerphone light is off (the handset displays Press and hold [PTT] to talk), you hear a beep. Press and hold PUSH TO TALK on your handset. When you hear a chirp, speak towards the handset.

While you are speaking, your handset displays PTT To handset X (X represents the handset numbers of one or more destination handsets; a maximum of 4 handset numbers appear).

Your voice is broadcast to all destination handsets.

Release PUSH TO TALK when you finish speaking. Your handset will beep. After the beep, if your speakerphone light is off, you can press and hold

PUSH TO TALK to continue speaking or the destination handsets can respond.

Change a one-to-one PTT call to an intercom call

You can convert a one-to-one PTT conversation to an intercom call.

When your handset displays Press and hold [PTT] to talk, press INTCOM. Your handset displays Switch to Intercom? Press SELECT to confirm.

If you have a two-handset system, your handset displays Calling other

handset. The destination handset temporarily displays Push to talk Ended and then Other handset is calling.

If you have three or more handsets, your handset displays Calling HANDSET Y (Y represents the destination handset number). The destination handset temporarily displays Push to talk Ended and then HANDSET X is calling (X represents the originating handset number).

On the destination handset, press HOME/FLASH or /SPEAKER to answer the intercom call. Both handsets now display Intercom.

To end the intercom call, press OFF/CANCEL or place the handset in the telephone base or charger. Both handsets display Intercom ended.

•

Page 64

Multiple handset use

Push-to-talk (PTT)

End a PTT call

For a one-to-one PTT call, both the originating and destination handsets can end the PTT call.

For one-to-group PTT calls, the initiating handset can end the PTT call for the group of handsets on that PTT call. If any one of the destination handsets leaves the PTT call, the call continues until all participants or the initiator hangs up.

To end or leave PTT:

Press OFF/CANCEL or place the handset in the telephone base or charger. The handset displays Push to talk Ended.

NOTES: After PUSH TO TALK is released, the PTT call remains open for a short time. If no one presses PUSH TO TALK within 10 seconds, the PTT call ends automatically.

Answer an incoming call during PTT

When you receive an incoming outside call during PTT, there is a call waiting tone. The caller ID is displayed with PTT screen alternately.

During a one-to-one PTT call, press HOME/FLASH or CELLULAR on the originating or destination handset. The PTT call ends automatically and the outside call is answered.

During a one-to-group PTT call, press HOME/FLASH or CELLULAR on the originating handset. The PTT call ends automatically and the outside call is answered.

During a one-to-group PTT call, press HOME/FLASH or CELLULAR on any one of the destination handsets and that handset answers the outside call. The PTT call continues for the rest of the PTT participants.

To leave the PTT call without answering the incoming call, press

OFF/CANCEL. The telephone continues to ring.

Make an outgoing call during PTT

During a one-to-one PTT call, press HOME/FLASH or CELLULAR to get a dial tone. The PTT call ends automatically.

During a one-to-group PTT call, press HOME/FLASH or CELLULAR on the originating handset. The PTT call ends automatically and you get a dial tone.

During a one-to-group PTT call, press HOME/FLASH or CELLULAR on any one of the destination handsets and that handset gets a dial tone. The PTT call continues for the rest of the PTT participants.

•

Page 65

About the directory

The home directory stores up to 200 entries with up to 30 digits for each phone number and 15 characters for each name. Each of the downloaded directories stores up to 1,500 entries with up to 30 digits for each phone number and 15 characters for each name.

Directory entries are stored at the telephone base and shared by all system handsets. Any changes made on one handset apply to all.

Only one handset can review the directory at a time. If another handset tries to enter the directory, its screen shows Not available at this time.

When there are no records in the directory, the screen shows Directory empty.

When the directory is full and you try to save an entry, the screen shows Directory full.

When you try to save a number already stored in the directory, the screen shows Already saved.

All of the instructions on pages 60-67 for the directories apply to the home directory and all downloaded directories. Creating a new entry on page 60 only applies to the home directory.

You cannot create new entries in your downloaded directories from the TL92271/TL92371/TL92471 handset. Entries must be downloaded from your cell phone (see Download directory on pages 22-23).

•

Directory

Page 66

Directory

Create and review entries

Create a new entry in the home directory

Press MENU on the handset in idle mode to enter the main menu. Press CID or DIR to highlight Directory, then press SELECT. Press OPTION to select Home. Press SELECT to choose Add contact. The screen displays

ENTER NUMBER. Use the dialing keys to enter a telephone number.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits. Press CID or DIR to move the cursor to the right or left. Press and hold REDIAL/PAUSE to insert a dialing pause (a p appears).

-OR-

Copy a number from the redial list.

Press REDIAL/PAUSE and then CID , DIR or REDIAL/PAUSE repeatedly to browse for a number. Press INSERT to copy the displayed number.

Press NEXT. Press CID or DIR to select one of the following types:

Home Cell Work Other

Press NEXT. The screen displays ENTER NAME. Use the dialing keys (see page 61) to enter the name.

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right or left.

Press SAVE to confirm and the screen shows Saved. You hear a confirmation tone.

NOTE: You cannot create new entries in your downloaded directories from your TL92271/ TL92371/TL92471 handsets. Entries must be downloaded from your cell phone (see Download directory on pages 22-23).

•

10.

Page 67

Directory

Create and review entries

NOTE:

When entering a name in the directory, the first letter of each word is

automatically capitalized.

Dialing

keys

Characters by number of key presses

1 2 3 4 5 6 7 8 9 10 11

1 1 . -

( ) * # & / ,

2 A B C a b c 2

3 D E F d e f 3

4 G H I g h i 4

5 J K L j k l 5

6 M N O m n o 6

7 P Q R S p q r s 7

8 T U V t u v 8

9 W X Y Z w x y z 9

Space

Page 68

Directory

Create and review entries

To add a predialed telephone number to the directory

You can save a predialed telephone number to the directory.

Enter the telephone number in idle mode (see Step 5 in Create a new entry in the home directory on page 60).

Press SAVE to move on to the number (see Step 3 in Edit a directory entry on page 64) and then press NEXT.

Press CID or DIR to select one of the following types:

Home Cell Work Other

Press NEXT. The screen displays ENTER NAME.

Use the dialing keys (see page 61) to enter the name.

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right

or left.

Press SAVE and the screen shows Saved. You hear a

confirmation tone.

•

Saved

888-883-2445

--:-- --/--

BACK

SAVE

EDIT NUMBER

888-883-2445

BACK

SELECT LABEL

Home

Cell Work

BACK

ENTER NAME

BACK

SAVE

Page 69

Directory

Create and review entries

Review the directory

Entries are sorted alphabetically.

Press DIR in idle mode. Press CID or DIR to highlight a directory, then press REVIEW. Press CID or DIR to browse.

-OR-

Press MENU on the handset in idle mode to enter the main menu. Press CID or DIR to highlight Directory, then press SELECT. Press CID or DIR to highlight a directory, then press REVIEW. Press CID or DIR to browse.

-OR-

Press OPTION while on call. Press CID or DIR to highlight Directory, then press SELECT. Press CID or DIR to highlight a directory, then press REVIEW. Press CID or DIR to browse.

NOTE:

When the desired entry displays, press # repeatedly to show different dialing options.

3-character alphabetical search

You can use the enhanced 3-character search to find your contacts quickly and efficiently.

To start the search:

Follow the steps in Review the directory above to enter the directory.

When an entry appears, use the dialing keys to enter the letters associated with the name (see page 61). You can enter up to 3 letters for the search. The letters will show in the top left hand corner of the screen. If there is no name matching the letters entered, the next closest match in alphabetical order appears. If necessary, use CID or DIR to browse.

NOTE:

The cursor automatically moves to the next position two seconds after you enter a letter. If you do not enter another letter in the coming two seconds, the handset starts searching in the directory.

Charlie Johnson

Home

888-883-2445

LABEL

EDIT

1/45

Rob

Charlie Johnson

Home

888-883-2445

LABEL

EDIT

1/45

Searching...

Charlie Johnson

Home

888-883-2445

LABEL

EDIT

Robert Brown

Home

888-360-4121

LABEL

EDIT

9/45

Page 70

Directory

Dial, edit or delete a directory

Dial a directory entry

You can dial a directory entry on either a home or cell line.

To dial a directory entry:

Search for the desired entry in the directory (see

Review the directory or 3-character alphabetical search on page 63).

When the desired entry appears, press # (pound key) repeatedly to show different dialing options.

When the displayed number is in the correct format, press HOME/FLASH or /SPEAKER to use the home line, or CELLULAR to use the cell line.

Edit a directory entry

You may edit any directory entry. However, be aware that if you download from a cell phone again, the directory is erased and replaced with the current cell phone directory. If you have edited the downloaded entries on the TL92271/TL92371/TL92471, those changes are lost. To avoid losing changes made to the downloaded directory, we suggest that you edit the number in your cell phone, then download the directory.

Search for the desired entry in the directory (see Review the directory or 3-character alphabetical search on page 63).

When the desired entry appears, press EDIT. The handset shows EDIT NUMBER.

Use the dialing keys to edit the number.

Press NEXT. Press CID or DIR to select one of the following types:

Home Cell Work Other

Press NEXT. The screen displays EDIT NAME. Use the dialing keys (see page 63) to enter the name.

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right or left.

Press SAVE to confirm and the handset shows Saved.

•

888-883-2445

1-888-883-2445

883-2445

1-883-2445

Page 71

Directory

Dial, edit or delete a directory

Edit the type of a directory entry If you only want to edit the type of a directory entry:

Search for the desired entry in the directory (see Review the directory or 3-character alphabetical search on page 63).

When the desired entry appears, press LABEL. Enter the corresponding shortcut keys shown in the below table.

Type: Press: Home 1 Cell 2 Work 3 Other 4

-OR-

Press CLEAR to erase the assigned label.

Delete a directory entry To delete an entry:

Search for the desired entry in the directory (see Review the directory or 3-character alphabetical search on page 63).

When the desired entry appears, press MUTE/DELETE. The screen displays Delete contact? and the name of the entry. Press YES to confirm.

The screen displays Contact deleted and then the next alphabetical entry in the directory. You hear a confirmation tone.

NOTE: Once a directory entry is deleted, it cannot be retrieved.

Remove a downloaded directory

Search for the desired downloaded directory in the directory menu (see Review the directory on page 63).

When the desired downloaded directory is chosen, press OPTION, then press CID or DIR to highlight Remove dir.

Press SELECT. The screen displays Directory Cell Phone A will be erased. Press YES to confirm.

The handset displays Erasing directory... and then Directory removed. You hear a confirmation tone.

Page 72

Directory

Speed Dial

You can assign 10 of your directory entries to a speed dial location (0-9). The speed dial entries are shared by all handsets.

Assign a speed dial slot

Up to 10 speed dial entries can be stored. The speed dial number must be created from an existing entry in the Home or Bluetooth directory.

Press MENU on handset when it is not in use. Press CID or DIR to highlight Directory, then press SELECT. Press CID or DIR to highlight Speed dial, then press REVIEW. Press CID or DIR to highlight an empty slot, then press ASSIGN. Press CID or DIR to highlight the desired directory, then press REVIEW. Search for the desired entry in the directory (see Review the directory

or 3-character alphabetical search on page 63). When the desired entry appears, press ASSIGN. You hear a confirmation tone.

Reassign a speed dial slot

Press MENU in idle mode. Press CID or DIR to highlight Directory and then press SELECT. Press CID or DIR to highlight Speed dial, then press REVIEW. Press CID or DIR to highlight the desired slot. Press ASSIGN. The handset displays the directory at the current

assigned entry. Search for the desired entry in the directory (see Review the directory

or 3-character alphabetical search on page 63). When the desired entry appears, press ASSIGN.

The handset displays Entry B replaces Entry A Accept? Press YES to confirm. You hear a confirmation tone.

Dial a speed dial entry

Press and hold a desired speed dial slot (0-9). Press HOME/FLASH or /SPEAKER to use the home line, or CELLULAR

to use the cell line.

Page 73

Directory

Speed Dial

Delete a speed dial entry

Press MENU in idle mode. Press CID or DIR to highlight Directory and then press SELECT. Press CID or DIR to highlight Speed dial, then press REVIEW. Press CID or DIR to highlight assigned slot, then press MUTE/DELETE. The handset displays Delete Entry A speed dial assignment? Press YES

to confirm. You hear a confirmation tone.

NOTE: Deleting speed dial entries does not affect the directory entries.

Page 74

About caller ID

This product supports caller ID services provided by most telephone service providers. Caller ID allows you to see the name, number, date and time of calls. The available caller ID information will appear after the first or second ring. Caller ID from the home line allows you to see the name, number, date and time of the incoming calls. The caller ID may appear differently if the caller is matched to a directory entry (see Memory match on page 69).

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the caller before answering the telephone, even while on another call.

It may be necessary to change your telephone service to use this feature. Contact your telephone service provider if:

You have both caller ID and call waiting, but as separate services (you may need to combine these services).

You have only caller ID service, or only call waiting service. You don’t subscribe to caller ID or call waiting services.

There are fees for caller ID services. In addition, services may not be available in all areas.

Caller ID information is available only if both you and the caller are in areas offering caller ID service, and if both telephone service providers use compatible equipment.

The caller ID information may not be available for every incoming call. The callers may intentionally block their names and/or telephone numbers. A caller ID log entry can show a maximum number of 24 digits.

NOTE: You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to caller ID or combined caller ID with call waiting service.

•

Caller ID

Charlie Johnson

888-883-2445

5:32am 8/06

NEW

SAVE

Page 75

Caller ID operation

How the caller ID history (caller ID log) works

The telephone stores caller ID information about the last 50 incoming calls in the telephone base. Entries are stored in reverse chronological order. The phone deletes the oldest entry when the log is full to make room for new calls. This information is common to all handsets, so changes made using any handset are reflected in all other handsets. If you answer a call before the information appears on the screen, it does not show in the caller ID history.

NOTE: If the phone number has more than 24 digits, it will not be

saved or shown in the caller ID log.

Memory match

If the incoming telephone number matches the last 7 digits of a telephone number in your directory, the name that appears on the screen matches the corresponding name in your directory.

For example, if Christine Smith calls, her name appears as Chris if this is how you entered it into your directory.

NOTE:

The number you see on your caller ID is in the format sent by the telephone service provider. It usually delivers 10-digit telephone numbers (area code plus telephone number). If the last 7 digits of the incoming telephone number do not match a number in your directory, the name appears as it is delivered by the telephone service provider.

Home

CHRISTINE SMITH

888-722-7702

5:32am 8/06

SILENCE

Home

Chris

888-722-7702

5:32am 8/0 6

SILENCE

Caller ID

Page 76

Caller ID

Caller ID operation

To review the caller ID log

Review the caller ID history to find out who called, to easily return a call, or to copy the caller’s name and number into your directory. Caller ID log empty appears if there are no records in the caller ID log.

When a handset is in idle mode, press CID to review the caller ID history in reverse chronological order starting with the most recent call.

-OR-

You can also review the caller ID history by pressing

MENU, then press CID or DIR to scroll to Caller ID log,

then press SELECT.

Press CID or DIR to highlight the desired line (home or cell), then press REVIEW.

Press CID or DIR to browse.

NOTE: Only one handset can review the caller ID history at time. If another handset tries to enter the directory or caller ID history, it shows Not available at this time.

Charlie Johnson

888-883-2445

7:45am 8/06

BACK

SAVE

Play messages Answering sys Directory

Caller ID log

BACK

SELECT

HANDSET 1

6 Missed calls

7:45am 8/06

BACK

Charlie Johnson

888-883-2445

7:45am 8/06

BACK

SAVE

NEW

Caller’s name

Caller’s number

Appears when there are new or missed calls.

Time of call

Date of call

Page 77

Caller ID

Caller ID operation

View dialing options

Although the caller ID log entries may contain 10 digits (the area code plus the 7-digit number), in some areas, you may need to dial only the 7 digits, or 1 plus the seven digits, or 1 plus the area code plus the seven digits. You can change the number of digits that you dial from the caller ID log or store to the directory.

While reviewing the caller ID log, press # repeatedly to show different dialing options for local and long distance numbers before dialing or saving the telephone number in the directory.

Press 1 repeatedly if you need to add or remove 1 in front of the telephone number before dialing or saving it in the directory.

When the number shows in the correct format for dialing, press HOME/FLASH or /SPEAKER to call the number using the home line.

-OR-

Press CELLULAR to call the number using the cell line.

Dial a caller ID log entry

Search for the desired entry in the caller ID log (see To review the caller ID log on page 70).

When the desired entry is displayed and is in the correct format for dialing, press HOME/FLASH or /SPEAKER to use the home line, or

CELLULAR to use the cell line.

888-883-2445

1-888-883-2445

883-2445

1-883-2445

888-883-2445

1-888-883-2445

883-2445

1-883-2445

Press #

Press 1

Page 78

Caller ID

Caller ID operation

Save a caller ID log entry to the directory

Caller ID log entries can only be saved to the Home directory.

Select a desired entry in the caller ID log (see To review the caller ID log on page 70).

When the desired entry appears, press # repeatedly to show different dialing options.

When the number is in the correct format, press SAVE. The handset shows EDIT NUMBER.

Use the dialing keys to edit the number.

Press NEXT.

Press CID or DIR to highlight one of the following types:

Home Cell Work Other

Press NEXT. The screen displays EDIT NAME and [*]-Order.

Use the dialing keys (see page 61) to edit the name.

Press MUTE/DELETE to erase a character. Press and hold MUTE/DELETE to erase all characters. Press CID or DIR to move the cursor to the right or left. Press TONE to toggle the name order. For example, Robert Brown

becomes Brown Robert when you press TONE .

Press SAVE to confirm and the screen shows Saved. You hear a confirmation tone.

NOTES:

If the name received from the telephone service provider is in all capital letters, the first letter of every word remains a capital letter. However, the next letter after the prefix “Mac”, “Mc”, or “O’”, is kept as a capital letter. For example, the “D” in “MacDonald” is kept as a capital letter.

When you try to save a caller ID entry without any caller ID information, the handset displays Unable to save.

When you try to save a number already stored in the directory, the screen shows Already saved.

•

Page 79

Caller ID

Caller ID operation

To delete a single entry

Select a desired entry in the caller ID log (see To review the caller ID log on page 70).

When the desired entry is displayed, press MUTE/DELETE. The handset shows the previous caller ID log entry. You hear a confirmation tone.

To delete all entries

Press CID on the handset in idle mode.

Press ERASE. If you choose the home caller ID log, the handset displays Delete all Home Calls?. If you choose a cell phone caller ID log, the handset displays Delete all Cell phone A calls?. Press YES to confirm. You hear a confirmation tone.

-OR-

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Caller ID log, then press SELECT.

Reasons for missing caller ID information

There are occasions when other information or no information shows for various reasons:

On-screen message Reason

It is a long distance call.

Private name

The caller prefers not to show the name.

Private number

The caller prefers not to show the phone number.

Private caller

The caller prefers not to show the phone number and name.

Unknown name

Your telephone service provider cannot determine the caller’s name.

Unknown number

Your telephone service provider cannot determine the caller’s number.

Unknown caller

No information is available about this caller.

CALLER ID LOG

Home

ERASE

REVIEW

Page 80

Answering system

Answering system settings

Answer on/off

If you turn the answering system on, it answers calls and records messages only on the home line. If your paired cell phone has voicemail, callers can leave messages with that voicemail service.

If your answering system is turned off and you change any of its settings, the answering system automatically turns on again and the handset displays Calls will be answered.

When the answering system is turned on, the /ANS ON light on the telephone base is on and the handsets display

ANS ON.

To turn the answering system on or off:

Using the telephone base:

Press /ANS ON to turn the answering system on or off. When the answering system is turned on, it announces, “Calls will be answered.” When the answering system is turned off, it announces, “Calls will not be answered.”

NOTES:

If there is no remaining recording time, the answering system announces “Calls will not be answered.” and cannot be turned on.

If the total recording time is less than three minutes, the answering system announces “Less than three minutes to record.” and your handsets display Rec mem low.

If the answering system is off, you may press /ANS ON on the telephone base to turn on the answering system during an incoming call. The answering system answers the call immediately if there is remaining time.

Using a handset:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Answering sys, then press SELECT.

Press CID or DIR to highlight Answer ON/OFF, then press SELECT.

Press CID or DIR to highlight On or Off, then press

SET to save. You hear a confirmation tone.

•

Play messages

Answering sys

Directory Caller ID log

BACK

SELECT

ANSWERING SYS Delete all old Record memo

Answer ON/OFF

BACK

SELECT

ANSWER ON/OFF

On

Off

BACK

SET

Page 81

Answering system

Answering system settings

Announcement

An announcement is the greeting callers hear when calls are answered by the answering system.

The telephone is preset with a greeting that answers calls with

“Hello, please

leave a message after the tone.”

You can use this default announcement, or

replace it with your own.

Play your announcement

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Answering sys, then press SELECT.

Press SELECT again to select Announcement.

The handset displays ANNOUNCEMENT. Press PLAY.

Record your own announcement

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to scroll to Answering sys, then press SELECT.

Press SELECT again to select Announcement.

The handset displays ANNOUNCEMENT. Press RECORD.

The handset announces, “Record after the tone. Press STOP when you are done.” After the tone, speak towards the microphone of the handset.

Press STOP when you finish recording.

The handset automatically plays back the newly recorded announcement. Press STOP to stop the playback at any time. After the announcement playback, press PLAY to replay the recorded announcement, or RECORD to record again if desired.

NOTES:

Your announcement can be up to 90 seconds in length. Announcements shorter than two seconds are not recorded.

•

ANSWERING SYS

Announcement

Delete all old Record memo

BACK

SELECT

ANNOUNCEMENT

PLAY

RECORD

Recording

announcement...

STOP

Announcement

playback

DELETE

STOP

Page 82

Answering system

Answering system settings

Delete your announcement

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to scroll to Answering sys, then press SELECT.

Press SELECT again to select Announcement.

The handset displays ANNOUNCEMENT, press PLAY to play the announcement.

While the announcement is playing, press DELETE to delete your own recorded announcement. The handset displays Reset announcement to default? Press YES to confirm. You hear a confirmation tone.

NOTE: When your announcement is deleted, calls are answered with the default announcement. You cannot delete the default announcement.

Announcement

playback

DELETE

STOP

ANSWERING SYS

Announcement

Delete all old Record memo

BACK

SELECT

Page 83

Answering system

Answering system settings

In the answering system setup menu, you can change the settings for call screening, number of rings, remote access code and message alert tone and recording time.

Call screening

The call screening feature lets you listen at the telephone base to a caller leaving a message. While monitoring an incoming message, you can answer the call by pressing HOME/FLASH or /SPEAKER on the handset.

To change the settings:

Press MENU on the handset in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press SELECT.

Use CID or DIR to scroll to Ans sys setup, then press SELECT twice to select Call screening.

Press CID or DIR to choose between On and Off, then press SET to save. You hear a confirmation tone.

NOTE: For more information on call screening, see page 82.

ANS SYS SETUP

Call screening

# of rings Remote code

BACK

SELECT

CALL SCREENING

On

Off

BACK

SET

Page 84

Answering system

Answering system settings

Number of rings

When the answering system is turned on, it answers all incoming home calls after the number of rings set. You can choose from 2, 3, 4, 5, or 6 rings; or toll saver. With toll saver selected, the answering system answers after 2 rings when you have new messages, and after four rings when you have no new messages.

This enables you to check for new messages and avoid paying unnecessary long distance charges if you are calling from out of your local area. The default number of rings is four.

To set the number of rings:

Press MENU on the handset in idle mode to enter the main menu.

Press CID or DIR to highlight Answering sys, then press SELECT.

Press CID or DIR to highlight Ans sys setup, then press SELECT.

Press CID or DIR to highlight # of rings, then press SELECT.

Press CID or DIR to choose from 6, 5, 4, 3, 2 or Toll saver, then press SET to save. You hear a confirmation tone.

NOTE: If you set the number of rings for the answering system as 2 or 3 rings, the caller ID announce feature may not have enough time to announce the caller’s full information.

ANS SYS SETUP Call screening

# of rings

Remote code

BACK

SELECT

# OF RINGS 6 5

4

BACK

SET

Page 85

Answering system

Answering system settings

Remote access code

A 2-digit security code is required to access the answering system remotely from any touch-tone telephone. The preset code is 19. You can change the code to any number from 00 to 99.

To change the remote code:

Press MENU on the handset in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press SELECT.

Use CID or DIR to scroll to Ans sys setup, then press SELECT.

Press CID or DIR to scroll to Remote code, then press SELECT.

Use the dialing keys (0-9) to enter a 2-digit number from 00-99.

Press MUTE/DELETE to erase a digit. Press and hold MUTE/DELETE to erase all digits.

Press CID or DIR to move the cursor to the right or left.

Press SET to save. You hear a confirmation tone.

Message alert tone

When the message alert tone is set to On, the telephone base beeps every 10 seconds to alert you to new messages. The tone stops when all new messages have been reviewed. The default message alert tone setting is Off.

To change the setting:

Press MENU on the handset in idle mode to enter the main menu.

Use CID or DIR to scroll to Answering sys, then press SELECT.

Use CID or DIR to scroll to Ans sys setup, then press SELECT.

Press CID or DIR to scroll to Msg alert tone, then press SELECT.

Press CID or DIR to choose between On and Off, then press SET to save your setting. You hear a confirmation tone.

NOTE: You cannot set the message alert tone when another handset or the telephone base is accessing the answering system.

•

ANS SYS SETUP Call screening # of rings

Remote code

BACK

SELECT

REMOTE CODE

BACK

SET

ANS SYS SETUP # of rings Remote code

Msg alert tone

BACK

SELECT

MSG ALERT TONE

On

Off

BACK

SET

Page 86

Answering system

Answering system settings

Recording time

You can set the recording time limit for each incoming message. The default setting is 3 minutes.

To change the setting:

Press MENU on the handset when it is not in use. Press CID or DIR to highlight Answering sys, then

press SELECT. Press CID or DIR to highlight Ans sys setup, then

press SELECT. Press CID or DIR to highlight Recording time, then

press SELECT. Press CID or DIR to choose from 3 minutes,

2 minutes, or 1 minute, then press SET to save. You hear a confirmation tone.

ANS SYS SETUP Remote code Msg alert tone

Recording time

BACK

SELECT

RECORDING TIME

3 minutes

2 minutes 1 minute

BACK

SET

Page 87

About the answering system

Answering system and voicemail

Your telephone has separate indicators for two different types of voice messages: those recorded on its built-in answering system and those recorded in your service provider’s voicemail (fees may apply). Your telephone’s built-in answering system messages and voicemail messages are separate. Each alerts you to new messages differently.

If and XX New messages display on the handsets and the message window on the telephone base flashes, there are new messages in the built-in answering system. To listen to messages recorded on your digital answering system, press /PLAY/STOP on the telephone base. To listen to messages with a handset, see To listen to messages with a handset on page 85.

If and New voicemail display on the handsets, your telephone service provider is indicating that it has new voicemail for you. To listen to your voicemail, you typically dial an access number provided by your telephone service provider, followed by a security code or PIN.

Some service providers bundle or combine multiple services like voicemail and call waiting, so you may not be aware that you have voicemail. To check what services you have and how to access them, contact your telephone service provider.

To use your voicemail service rather than your answering system, turn off your answering system. To use your answering system rather than your voicemail service, contact your telephone service provider to deactivate your voicemail service.

Using the answering system and voicemail together

You can also use your telephone answering system and voicemail together by setting your built-in answering system to answer before voicemail answers as described below. To learn how to program your voicemail settings, contact your telephone service provider. Then, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

Set your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, if your voicemail answers after six rings, set your answering system to answer after four rings. Some voicemail providers may program the delay before answering calls in seconds instead of rings. In this case, allow six seconds per ring when determining the appropriate setting.

Answering system

Page 88

Answering system

About the answering system

Message capacity

The answering system can record and store up to 99 messages. Each message can be up to 3 minutes in length depending on the message length set (see Recording time on page 80). The total storage capacity for the announcement, messages and memos is approximately 14 minutes. The actual recording time depends on individual message characteristics. Messages remain available for replay until you delete them.

Voice prompts

The system provides voice prompts to guide you through the setup procedures at the telephone base, message playback, remote access and recording outgoing announcements.

Call screening

Call screening at the telephone base

If the answering system and call screening are on (see Call screening on page 77), the announcement and the incoming message broadcast at the telephone base when a call arrives.

During message recording, press /PLAY/STOP repeatedly to turn call screening on and off for this call. Press VOLUME on the telephone base to adjust the message volume. To change the call screening setting for all calls, see page 77.

During call screening, press /PLAY/STOP on the telephone base to turn off the call screening. If the call screening is off and the answering system has answered a call, press /PLAY/STOP or VOLUME to turn on the call screening.

Call screening at the handset:

If the answering system is on and your answering system is recording a message, press SCREEN to screen the call on your handset and the screen displays the caller ID information. If you do not subscribe to caller ID service, the handset shows Incoming call.

NOTE: The call screening setting does not affect the call screening on the handset.

Call intercept

When a caller is leaving a message on your answering system, you can stop recording and talk to the caller by pressing HOME/FLASH or

/SPEAKER on the handset.

Page 89

Answering system

About the answering system

Temporarily turning off the message alert tone

Pressing any telephone base key (except /HANDSET LOCATOR) temporarily silences the message alert tone.

The message alert tone plays with the next incoming message.

If you press X/DELETE when in idle mode to temporarily turn off the message alert tone, there is a voice prompt directing you to press X/DELETE again to delete all old messages. The message alert tone is temporarily off. Only press X/DELETE a second time if you wish to erase all old messages in your answering system.

The message alert tone resumes when you receive a new message.

Page 90

Answering system

Message playback

On the telephone base, if you have new messages, the telephone plays only the new messages in chronological order. If there are no new messages, the telephone plays back all messages in chronological order.

On the handset, if you have both new and old messages, you can play either new or old messages. The caller ID information displays on the handset screen when you play messages and you can call back the caller.

When playback begins, the handset screen displays the message status, caller ID information, and time and date of the message recorded. You hear the total number of messages followed by the day and time of the message. After the last message, the telephone announces, “End of messages.” and the screen displays End of messages.

To listen to messages with the telephone base:

Press /PLAY/STOP to listen to messages. Options during playback:

Press VOLUME to adjust the speaker volume. Press /SKIP to skip to the next message. Press /REPEAT to repeat the message currently playing.

Press /REPEAT twice to listen to the previous message. Press X/DELETE to delete the current message. The system advances

to the next message. Press /PLAY/STOP to stop.

•

Page 91

Answering system

Message playback

To listen to messages with a handset:

Press MENU in idle mode. Press SELECT to select Play messages. If you have either new or old

messages, the messages play automatically. If you have both new and old messages:

To play new messages, press SELECT to select Play new msgs. To play old messages, press

CID or DIR

to highlight Play old msgs,

then press SELECT.

When the handset is playing a message, its screen shows [2]-Call info and the caller’s name or number. If the caller’s information is unavailable, the handset shows No caller info.

Options during playback:

Press EQ button to adjust the message playback audio quality. Press /SPEAKER to play the messages through the handset earpiece. Press

CID /

VOLUME/

DIR

to adjust the speakerphone volume.

Press SKIP to skip to the next message. Press REPEAT to repeat the message currently playing. Press REPEAT

twice to listen to the previous message. Press MUTE/DELETE to delete the current message. The handset displays

Message deleted briefly and the system advances to the next message. Press 2 to pause the playback and show the caller ID information. If

necessary, press # (pound key) or 1 to show different dialing options. Press HOME/FLASH, DIAL or /SPEAKER to use the home line, or press CELLULAR to use the cell line to call back the caller. Press OFF/CANCEL or BACK to resume the playback. If you do not call back within 10 seconds, message playback resumes.

Press HOME/FLASH or CELLULAR to pause the message playback. The handset displays Call back? with the caller ID information. Press

YES to call back the caller, or NO to resume the message playback.

If the dialing format used is not correct, then use the option above to choose the correct dialing format before calling back the caller.

Press OFF/CANCEL to stop.

NOTES:

When the answering system has less than three minutes of recording time left, it announces, “Less than three minutes to record.” and the handset displays Rec mem low.

When the telephone is not in use, if F and the number of messages are flashing alternately in the message window, or the handset displays Rec mem full, the memory is full. Delete some messages to make room for more.

•

Page 92

Answering system

Message playback

Delete all old messages Using the telephone base:

Press X/DELETE when the phone is not in use. The telephone announces,

“To delete all old messages, press DELETE again.” Press X/DELETE again. All previously reviewed messages are erased and the telephone announces, “All

old messages deleted.”

Using a handset:

Press MENU on the handset in idle mode to enter the main menu. Press CID or DIR to highlight Answering sys, then press SELECT. Press CID or DIR to highlight Delete all old, then press SELECT. The handset displays Delete all old messages? Then press YES to confirm. The handset displays Deleting... and then All old messages deleted! You

hear a confirmation tone.

NOTE: You can only delete old messages, which are messages you have previously reviewed.

Record and play memos

Memos are messages you record as reminders for yourself or others using the same answering system. You can record your own memos using a system handset. Play and delete them the same way as incoming messages.

To record a memo:

Press MENU on the handset in idle mode to enter the

main menu.

Press CID or DIR to highlight Answering sys, then press SELECT.

Press CID or DIR to highlight Record memo, then press SELECT.

The system announces, “

Record after the tone. Press

STOP when you are done

.” After the tone, speak towards

the microphone. Press STOP when you finish recording. The handset

announces, “

Recorded

” and then returns to the

previous menu.

NOTES:

The system announces “Memory is full,” if you attempt to record a memo when the memory is full.

Each memo can be up to 4 minutes in length. Memos shorter than two second are not recorded.

•

ANSWERING SYS Announcement Delete all old

Record memo

BACK

SELECT

Play messages

Answering sys

Directory Caller ID log

BACK

SELECT

Recording

memo...

STOP

Page 93

Answering system

Base message counter displays

Message window displays

No messages.

0 (flashing)

The time and date need to be set.

0-6

The telephone base ringer level while adjusting.

1-8

The telephone base speaker volume level while adjusting.

1-99

Total number of old messages and memos recorded. The message number currently playing.

0-99 (flashing)

Total number of messages and memos. The number flashes when there are new or missed messages.

After a power failure, the number in the message counter flashes to indicate that you need to set the clock.

1-99 & F

(alternating)

The answering system memory is full with total number of messages recorded.

- -

The system is answering a call, or recording a memo or announcement.

The telephone is being accessed remotely.

The answering system is being programmed.

Page 94

Answering system

Remote access

You can access the answering system remotely by dialing your home telephone number from any touch-tone telephone.

To remotely access the answering system

Dial your telephone number from any touch-tone telephone. When the system plays your announcement, enter the 2-digit remote

access code (19 is the preset code, see page 79 to change it). You can also enter the remote commands (see Remote commands below). Hang up or press 8 to end the call and save all undeleted messages.

Remote commands

NOTES:

If you do not press any keys after you enter the remote access code, all new messages play. If there are no new messages, all old messages play.

Once the new messages have played, the telephone announces the help menu options. If you do not press any key within 20 seconds, the remote access call automatically disconnects.

When the answering system is turned off, the telephone answers after 10 rings, and announces, “Please enter your remote access code.”

When the memory is full, the answering system answers incoming calls after 10 rings and announces, “Memory is full. Enter the remote access code.”

•

Press to listen to all messages.

Press to listen to new messages only.

Press to delete the current message (during playback).

Press twice to delete all old messages.

Press to repeat the current message (during playback).

Press twice to listen to the previous message.

Press to stop.

Press to listen to a list of remote commands.

Press to skip to the next message (during playback).

Press to record a new announcement.

Press to hang up the call.

Press to turn the answering system on or off.

Page 95

Handset screen icons

HOME line - On steadily when the home line is in use or there is an incoming home call.

1 2

CELL line- On steadily when a cell line is in use or there is an incoming cell call.

1 2

Bluetooth connected devices - There are Bluetooth connected devices on the active devices list.

1 2

Bluetooth disconnected devices - There are Bluetooth disconnected devices on the active devices list.

1 2

Wireless Bluetooth headset - On steadily when a wireless Bluetooth headset is in use on the home line.

(flashing)

Battery status - Battery is low; place handset in telephone base or charger to recharge.

Battery status - Battery is charging.

Speakerphone - The speakerphone is

in use.

Ringer off - On steadily if the home and cell ringers are turned off. Flashes if only

one ringer is turned off.

New voicemail - New voicemail received from your telephone service provider.

ANS

Answering system on - The answering system is turned on.

New answering system message - New message in the answering system.

NEW

New caller ID log - Missed and new calls.

MUTE

Mute - Microphone is muted.

Appendix

Home

CHRISTINE SMITH

888-722-7702

5:32am 8/06

SAVE

1 2

ANS

Page 96

Appendix

Alert tones and lights

Handset alert tones

Two short beeps

You are pressing CID or DIR when the volume is already at its highest or lowest setting.

-OR- You have reached the end of the caller ID history.

Three short high-pitched beeps The telephone has completed the command successfully.

Four short beeps Low battery warning.

-OR-

Out of range while the handset is on a call.

Telephone base alert tones

Beeps once every 10 seconds Message alert.

Two short beeps Registration slots are full.

Four short beeps Registration failure.

Handset indicator lights

Telephone base indicator lights

CHARGE light

On when the handset is charging in the telephone base or charger.

Backlight (lighted display and dial pad)

On when the handset is lifted from the telephone base or charger.

On when a key is pressed.

/SPEAKER light

On when the speakerphone is in use.

IN USE light On when the handset is in use,

or when the answering system is answering an incoming call, or when you are registering a handset.

Flashes when another telephone is in use on the same line, or when you are deregistering handset(s) from the telephone base.

Flashes quickly when there is an incoming home call.

/ANSWER ON light

On when the answering system is on.

DEVICE1/DEVICE2 lights On when the telephone base

is paired and connected with a Bluetooth device.

Flash alternately while pairing a Bluetooth device.

Flashes quickly when there is an incoming cell call.

Page 97

Appendix

Screen messages

Display screen messages

Already saved

The telephone number you have entered is already stored in the directory.

Bluetooth system busy

You are trying to make a cell call or access the Bluetooth menu when the Bluetooth link is already being used.

Caller ID log empty

There are no entries in the caller ID history.

Call transferred

An outside call from one handset is transferred to another handset.

Calling HANDSET X

(For models with more than two

handsets)

The handset is calling another handset (for intercom calls).

Calling other handset

(For models with two handsets only)

The handset is calling the other handset (for intercom calls).

The handset is going to transfer an outside call to the other handset.

Cell

The cell line is on a call.

Cell call on hold

A call on the cell line has been put on hold.

Cell line in use

Another system handset is using the cell line.

Connecting...

The telephone base is trying to establish connection with a Bluetooth device.

Connection failed

A Bluetooth device in the paired or active devices list fails to establish connection with your telephone system.

Directory empty

There are no directory entries.

Directory full

The directory is full. You cannot save any new entries unless you delete some current entries.

Downloading dir

The system is downloading a directory from a cell phone.

Ended

You have just ended a call.

HANDSET X is calling

(For models with more than two

handsets)

Another system handset is calling.

Home

The home line is on a call.

Home call on hold

A call on the home line has been put on hold.

Home & cell

calls on hold

Calls on the home and cell lines have been put on hold.

Home & cell

lines in use

Calls on the home and cell lines are being used.

Page 98

Appendix

Home line in use

A system handset or another telephone on the same home line is in use.

Incoming call

There is a call coming in.

Intercom

The handset is on an intercom call.

Intercom ended

The intercom call has just ended.

Low battery

The battery needs to be charged.

Microphone off

The handset microphone is off. The other party cannot hear you but you can hear the other party.

Microphone on

The handset microphone is on.

New voicemail

There are new voicemail messages from your telephone service provider.

No answer. Try again.

You tried to make an intercom call, but the handset you are calling is busy or out of range.

No battery

The battery is not properly installed and the handset is in the telephone base or charger.

No caller info

The caller information is not available.

No entries

found.

Download from

SIM only ?

There are no entries found when you download a cell phone directory from the cell memory.

No entries

found.

Download from

Phone only ?

There are no entries found when you download a cell phone directory from your SIM card.

There are no entries found in either the cell or SIM card when you download a cell phone directory from both memories.

No connected cellular

phones

There is no cellular phone connected to the base.

No home line

There is no telephone line connected.

No Incoming PTT

The incoming PTT function is turned off. The handset will not receive PTT calls.

No message

There is no message recorded on the answering system.

No signal, call ended

The phone lost connection with the telephone base or does not have a strong enough signal and the phone call ended.

Not available

at this time

Someone else is already using the directory or caller ID history on another handset.

Screen messages

Page 99

Appendix

Other handset

is calling

(For models with two handsets only)

The other handset is calling.

Out of range

No power at

base

The handset has lost communication with the telephone base.

There is no power connected to the telephone base.

** Paging **

The telephone base is paging all handsets.

Place

in charger

The battery is very low. The handset should be placed in the telephone base or charger.

PTT From

HANDSET X

handset Y

One handset has started a PTT session to another handset.

PTT To

HANDSET X

You have started the PTT process.

Push to talk

Ended

The PTT session is ended.

Put handset

on BASE

to register

Your handset is not registered to the telephone base.

Rec mem full

The answering system has no recording time left.

Ringer muted

The ringer is muted temporarily during an incoming call.

Rec mem low

The answering system has less than three minutes to record.

Registration

slots are full

The telephone base already has the maximum of 12 handsets registered to it.

Saved

The entry is now saved in the directory.

Unable to save

You are trying to save an entry with no name and number from the caller ID history.

XX Missed calls

There are new calls in the caller ID history.

XX New messages

There are new messages recorded in the answering system.

Screen messages

Page 100

Appendix

Expand your telephone system

Your telephone can support up to 12 cordless handsets. The handset must be registered to the telephone base before use. You must register each handset separately.

The handsets provided within your product box are already registered as HANDSET 1 and so forth. Additional handsets are assigned numbers in the sequential order they are registered (up to HANDSET 12).

Add and register a handset (optional)

You can add new handsets (TL90071, purchased separately) to your telephone system, but each handset must be registered with the telephone base before use. When first purchased, each expansion handset shows

Put handset on BASE to register

after a battery is installed.

Each handset should be charged without interruption for at least 30 minutes before registering to the telephone base. For more details on battery charging, see the table on page 9.

To register a handset:

Make sure the handset shows Put handset on BASE to register.

Put the handset you wish to register on the telephone base cradle.

The handset displays Registering handset... on the handset and the red IN USE light on the telephone base turns on. It takes about 90 seconds to complete the registration process. The handset displays HANDSET X Registered (X represents the registered handset number). The IN USE light turns off and the handset beeps when registration completes.

If registration fails, it will automatically try to register again. If it fails after the third try, the handset shows

Registration failed, then Put handset on BASE to register. This may take up to 5 minutes to occur. When

the handset displays Put handset on BASE to register, please start again from Step 1 above.

NOTES:

You cannot register a handset if any other system handset is in use.

If you try to register more than 12 handsets to the telephone base, the telephone base shows Registration slots are full and sounds 2 beeps.

•

For registration, put the handset on the telephone base, not the handset charger.

AT&T TL92271, TL92371, TL92471, TL92321, TL92421 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
