AT&T EL52100, EL52110 User Manual

User’s manual

EL52100/EL52110 DECT 6.0 cordless

telephone/answering system with caller ID/ call waiting

Congratulations

on purchasing your new AT&T product. Before using this AT&T product, please read Important safety information on pages 65-66 of this user’s manual. Please thoroughly read the user’s manual for all the feature operations and troubleshooting information you need to install and operate your new AT&T

product. You can also visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Model number: EL52100/EL52110

Type: DECT 6.0 cordless telephone with answering system

Serial number:

Purchase date:

Place of purchase:

Both the model and serial number of your AT&T product can be found on the bottom of the telephone base.

Telephones identified with this logo have reduced noise and interference when used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083 Compliant Logo is a trademark of the Telecommunications Industry Association. Used under license.

The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the use of products that save energy and help protect our environment. We are proud to mark this product with the ENERGY STAR® label indicating it meets the latest energy efficiency guidelines.

© 2009-2011 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China.

Parts checklist

Your telephone package contains the following items. Save your sales receipt and original packaging in the event warranty service is necessary.

User’s manual

EL52100/EL52110 DECT 6.0 cordless telephone/answering system with caller ID/ call waiting

Quick start guide

Cordless handset

Battery for cordless handset

Telephone base

Power adapter for

telephone base

Wall mount bracket

Telephone line cordBattery compartment cover

User’s manual

EL52100/EL52110 DECT 6.0 cordless telephone/

answering system with caller ID/ call waiting

Table of contents

Getting started

Quick reference guide ..................................................2

Telephone base installation .......................................4

Battery installation and charging ............................5

Battery installation ..................................................5

Battery charging .......................................................6

Wall mount installation ................................................7

Tabletop to wall mount installation................7

Wall mount to tabletop installation ...............9

Telephone settings

Menu overview...............................................................10

Handset settings ...........................................................11

Ringer volume .........................................................11

Ringer tone...............................................................11

LCD language ..........................................................11

Voicemail waiting (visual message

waiting) indicator ..................................................12

Clear voicemail indication ................................12

Key tone .....................................................................13

Set date/time ..........................................................13

Home area code .................................................... 14

Dial mode ..................................................................14

Answering system settings ......................................15

Announcement ....................................................... 15

Answering mode ....................................................16

Call screening setup ............................................17

Number of rings .....................................................17

Remote access code............................................18

Message alert tone...............................................18

Telephone base ringer volume ..............................19

Telephone operation

Making, answering and ending a call .................20

Making a call ...........................................................20

Temporary ringer silencing ...............................20

Answering a call .................................................... 21

Speakerphone ......................................................... 21

Ending a call ............................................................21

Redial..................................................................................22

To review numbers in the redial list ............22

To call a number from the redial list ..........22

To copy a number from the redial list

to the directory ...................................................... 22

To delete a number in the redial list .......... 23

Options while on calls ............................................... 24

Volume control .......................................................24

Mute .............................................................................24

Flash/call waiting .................................................24

Temporary tone dialing ......................................25

Chain dialing ............................................................25

Handset locator .............................................................27

Directory

Directory overview .......................................................28

Directory memory capacity ..............................28

Exiting the directory ............................................28

Speed dial overview .............................................28

Creating directory entries ........................................ 29

To create a new directory entry ....................29

To add a predialed telephone number

to the directory ...................................................... 30

Reviewing the directory ............................................ 31

To review directory entries ...............................31

To search by name ...............................................31

Dialing, deleting and editing

a directory entry ........................................................... 32

To dial a directory number ............................... 32

To delete a directory entry .............................. 32

To edit a directory entry .................................... 32

Speed dial locations ...................................................33

To assign or reassign a directory entry

to a speed dial location .....................................33

To clear a speed dial location ........................ 33

To dial a speed dial number ............................34

Caller ID

About caller ID ..............................................................35

Information about caller ID with call

waiting ........................................................................ 35

About home area code ......................................35

Caller ID history ............................................................ 36

How caller ID history (call log) works ........36

Memory match ........................................................ 36

Caller ID operation ...................................................... 37

Missed (new) calls indicator ............................37

Reasons for missing caller ID

information ...............................................................37

To review the caller ID history ....................... 38

To view the dialing options .............................. 38

To dial a caller ID history number ................39

To delete caller ID history entries ................39

Saving a caller ID history entry

in the directory ....................................................... 40

Answering system

Answering system and voicemail .........................41

Answering system new message

indication ...................................................................41

Answering system overview ...................................42

Voice prompts .........................................................42

Message capacity .................................................. 42

Call screening .........................................................42

Call intercept ...........................................................43

Temporarily turning off the message

alert tone ..................................................................43

Message playback ........................................................44

To listen to messages .........................................44

Options during playback ...................................45

To delete all old messages .............................. 46

Recording and playing memos ..............................47

To record a memo ................................................ 47

To play back memos ...........................................47

Message window displays ........................................48

Remote access ............................................................... 49

To remotely access the answering

system ......................................................................... 49

Appendix

Screen icons, indicator lights and

alert tones .......................................................................51

Screen icons ............................................................51

Handset indicator lights ..................................... 51

Telephone base indicator lights.....................52

Handset alert tones .............................................52

Telephone base alert tones ............................. 52

Handset display screen messages .......................53

Troubleshooting ............................................................ 55

Maintenance....................................................................64

Important safety information .................................65

Safety information ................................................ 65

Especially about cordless telephones ........65

Precautions for users of implanted

cardiac pacemakers ............................................. 66

Pacemaker patients .............................................66

Especially about telephone answering

systems ...................................................................... 66

FCC Part 68 and ACTA............................................... 67

FCC Part 15 .....................................................................68

Limited warranty ...........................................................69

Technical specifications ............................................71

DECT 6.0 digital technology ............................71

Telephone operating range .............................. 71

Index ................................................................................... 72

Remote access wallet card ..................................... 74

You must install and charge the battery before using the cordless handset.

See pages 5 and 6 for easy instructions.

Install the telephone base close to a telephone wall jack and an electrical outlet not controlled by a wall switch. The telephone base can be placed on a flat surface or vertically mounted on the wall (page 7). For optimum range and better reception, place the telephone base in a central and open location.

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (page 4). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the handset or telephone base display - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as: television sets, VCRs, or other

• cordless telephones.

Excessive heat sources.

• Noise sources such as a window with traffic outside, motors, microwave

• ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

• Excessive moisture.

• Extremely low temperature.

• Mechanical vibration or shock such as on top of a washing machine or

• work bench.

Getting started

Quick reference guide

REDIAL/PAUSE

Press repeatedly to view the last 20 numbers dialed (page 22).

While entering numbers, press and hold to insert a dialing pause (pages 20 and 29).

PHONE/FLASH

Press to make or answer a call (page 20).

During a call, press to answer an incoming call when you receive a call waiting alert (page 24).

While reviewing a caller ID history entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in the directory (page 38).

While entering names in the directory, press to add a space (page 29).

MUTE

During a call, press to mute the microphone (page 24).

TONE

During a call, press to send touch-tone signals (page 25).

SPEAKER

Press to turn on the handset speakerphone. Press again to resume normal handset use (pages 15, 21 and 45).

DELETE

While predialing, press to delete digits (page 20).

While reviewing the redial list, directory, speed dial list or caller ID history, press to delete an individual entry (pages 23, 32, 33 and 39).

DIR/VOLUME

Press to scroll up while in menus (page 10).

Press to increase the listening volume (pages 24 and 45).

Press to show directory entries when the handset is not in use (page 31).

While entering names or numbers in the directory, press to move the cursor to the right (page 29).

CID/VOLUME

Press to scroll down while in menus (page 10).

Press to decrease the listening volume (pages 24 and 45).

Press to show the caller ID history when the handset is not in use (page 38).

While entering names or numbers in the directory, press to move the cursor to the left (page 29).

MENU/SELECT

Press to display the menu (page 10).

Once in the menu, press to select an item or save an entry or setting (page 10).

OFF/CLEAR

During a call, press to hang up (page 21).

While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display (page 10).

Press and hold while the handset is not in use to erase the missed calls indicator (page 37).

When reviewing a caller ID history entry, press repeatedly to view the dialing options (page 38).

Getting started

Quick reference guide

The > symbol indicates the feature to select.

>PLAY MESSAGES

ANSWERING SYS

Main menu

PLAY MESSAGES (page 44)

ANSWERING SYS (page 15)

DIRECTORY (page 29)

CALL LOG (page 38)

RINGERS (page 11)

SETTINGS (pages 11-14)

ANSWER ON/OFF

Press to turn the built-in answering system on or off (page 16).

Message window

Displays the number of messages. During playback, displays the message number currently playing (page 48).

PLAY/STOP

Press to start or stop message playback (page 44).

While call screening, press to temporarily turn call screening on or off (page 42).

DELETE

Press to delete the message currently playing (page 45).

Press twice to delete all old messages when the telephone is not in use (page 46).

Using menus

Press MENU/SELECT to enter the main menu.

Press DIR or CID to scroll through menu items.

Press MENU/SELECT to select or modify an item.

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display.

VOLUME

While the telephone is not in use, press to adjust the telephone base ringer volume (page 19).

During call screening or message playback, press to adjust the listening volume (pages 42 and 44).

SKIP

Press to skip a message (page 45).

REPEAT

After the answering system plays the day and time the current message was received, press to repeat the message currently playing (page 45).

While the answering system is playing the day and time the current message was received, press to listen to the previous message (page 45).

HANDSET LOCATOR

Press to make the handset beep so you can locate it (page 27).

Getting started

Telephone base installation

If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack. The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

The telephone base comes ready for tabletop use. If you want to mount your telephone on a wall, refer to Wall mount installation on page 7 for details.

Electrical outlet not controlled by a wall switch

Plug the large end of the power adapter into an electrical outlet not controlled by a wall switch.

Plug the small end of the power adapter into the power jack on the bottom of the telephone base.

Telephone wall jack

Plug the other end of the telephone line cord into a telephone wall jack.

A DSL filter (not included) is required if you have DSL high-speed Internet service.

Telephone line cord

Route the cords through the slots.

Plug one end of the telephone line cord into the TEL. LINE jack on the bottom of the telephone base.

IMPORTANT INFORMATION:

Use only the power adapter provided with this product. To obtain a replacement, visit our website at www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Getting started

Battery installation and charging

Battery installation

Install the battery as shown below.

1. Insert the supplied battery connector securely into the socket inside the handset battery compartment, matching the color-coded label.

with the label THIS SIDE UP facing up as indicated.

Align the cover flat against

3.Plug the battery the battery compartment, then slide it upwards until it clicks into place.

CHARGE light

Charge the handset by placing it face up in

the telephone base. The CHARGE light is on when charging.

IMPORTANT INFORMATION:

Use only the supplied rechargeable battery or replacement battery (model BT166342). To order, visit our website at www.telephones.att.com, or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

To replace the battery, press the tab and slide the battery compartment cover downwards. Lift out the old battery and disconnect it from the handset. Follow the instructions above to install and charge the new battery.

Getting started

Battery installation and charging

Battery charging

Once you have installed the battery, the screen indicates the battery status (see the table below). If necessary, place

HANDSET 1

16 MISSED CALLS

the handset in the telephone base to charge the battery. For best performance, keep the handset in the telephone base when not in use. See Technical specifications on page 71 for battery charging and operating times.

10:30

Battery status icon

11/20

If the screen is blank, you need to charge the handset without interruption for at least 30 minutes to give the handset enough charge to use the telephone for a short time. The screen shows LOW BATTERY until you have charged the battery without interruption for at least 30 minutes. The following table summarizes the battery charge indicators and actions to take.

Battery indicators Battery status Action

The screen is blank or shows PLACE IN CHARGER.

The screen shows

LOW BATTERY and flashes.

The screen shows HANDSET 1 and the battery icon shows

, or .

Battery has no or very little charge. The handset cannot be used.

Battery has enough charge to be used for a short time.

Battery is charged. To keep the battery charged,

Charge without interruption until the screen shows LOW BATTERY or HANDSET 1 (at least 30 minutes).

Charge without interruption until the screen shows HANDSET 1 (at least 30 minutes).

place it in the telephone base when not in use.

NOTES:

If you are on a call in low battery mode, you hear four short beeps every 50 seconds.

•

When you place the handset in the telephone base, if no battery is installed in that handset,

•

the CHARGE light is off and the screen shows NO BATTERY. Follow the instructions in Battery installation on page 5 to install the battery.

Getting started

Wall mount installation

The telephone base comes ready for tabletop use. If you want to mount your telephone on a wall, use the provided wall mount bracket to connect with a standard dual-stud telephone wall mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronics retailers. Professional assistance may be required to install the mounting plate.

Tabletop to wall mount installation

To change the telephone base from the tabletop installation to wall mount installation, make sure you first unplug the power adapter from the electrical outlet and unplug the telephone line cord from the telephone wall jack.

Plug one end of the telephone line cord into the TEL. LINE jack on the

1. bottom of the telephone base. Plug the small end of the larger power adapter into the power jack on the bottom of the telephone base.

Position the telephone base as shown below. Insert the extended tabs of

2. the wall mount bracket into the slots on the back of the telephone base. Push the telephone base down until it clicks securely in place.

Route the telephone line cord through the wall mount bracket hole. Route

3. the power cord out of the bottom of the telephone.

Slots for wall mount

bracket installation

A DSL filter (not included) is required if you have DSL highspeed Internet service.

Getting started

Wall mount installation

Plug the other end of the telephone line cord into the telephone wall jack.

4. Plug the large end of the larger power adapter into an electrical outlet not controlled by a wall switch.

A DSL filter (not included) is required if you have DSL highspeed Internet service.

Align the holes on the wall mount bracket with the mounting studs of the

5. wall mounting plate and slide the bracket down until it locks securely. Bundle the telephone line cord and power adapter cord neatly with twist ties.

DSL filter

Getting started

Wall mount installation

Wall mount to tabletop installation

To change the telephone base from the wall mount installation to tabletop installation, follow the steps below.

Unplug the large end of the larger power adapter from the electrical outlet.

1. If the telephone line cord and power adapter cord are bundled, untie

2. them first. Slide the wall mount bracket up and remove it from the wall mounting plate. Unplug the end of the telephone line cord from the telephone wall jack.

Lift the telephone base up to detach it from the wall mount bracket.3.

Refer to Telephone base installation on page 4 to install the telephone base.4.

Telephone settings

Menu overview

Use the menu to change the telephone settings.

Press MENU/SELECT in idle mode (when the handset is

1. not in use) to enter the main menu.

Press DIR or CID to scroll until the > symbol is next to

2. the feature you want to select.

Press MENU/SELECT to select or save the indicated item.

-OR- Press OFF/CLEAR to cancel an operation, back up to the previous menu or exit the menu display.

-OR- Press and hold OFF/CLEAR to cancel an operation and return to idle mode.

-OR- If no key is pressed within 30 seconds, the handset automatically cancels an operation and returns to idle mode.

Menu structure

PLAY MESSAGES

ANSWERING SYS

Directory

Directory overview

Directory memory capacity

The directory can store up to 100 entries, with a maximum of 15 alphanumeric characters (including spaces) for the names and 30 digits for the telephone numbers. A convenient search feature can help you find and dial numbers quickly (see To search by name on page 31).

If there are already 100 entries, the screen shows DIRECTORY FULL. You cannot store a new number until you delete one.

If the directory is empty, when you access it, the screen shows DIRECTORY EMPTY.

Exiting the directory

Press OFF/CLEAR to cancel an operation, back up to the previous menu, or exit the menu display. Press and hold

OFF/CLEAR to return to idle mode.

Speed dial overview

This telephone has 10 speed dial locations where you can assign telephone numbers from the directory you wish to dial numbers using only two key presses. For more details, refer to Speed dial locations on page 33.

Charlie Johnson

888-883-2445

DIRECTORY FULL

>0: Charlie John

1: Robert Brown

Directory

Creating directory entries

To create a new directory entry

Press MENU/SELECT in idle mode.

1. Press DIR or CID to scroll to >DIRECTORY, then press MENU/SELECT.

2. Press DIR or CID to scroll to >ADD CONTACT.

3. Press MENU/SELECT.

4. Enter the telephone number when prompted.

Copy a number from redial:

•

Press REDIAL/PAUSE.

Press DIR or CID or press REDIAL/PAUSE repeatedly to locate the

number to copy. Press MENU/SELECT to copy the number.

-OR-

Use the dial pad keys to enter a number (up to 30 digits).

• Press DIR or CID to move the cursor to the right or left.

–

Press and hold REDIAL/PAUSE to enter a three-second dialing pause

–

(a P appears). Press DELETE to erase digits.

–

Press and hold DELETE to erase all digits.

–

Press MENU/SELECT to save the number in the display.

6. Enter the name when prompted. Use the dial pad keys and refer to the

7. character chart (page 30) to enter a name (up to 15 characters). Each time you press a key, the character on that key appears. Additional key presses produce other characters on that key.

Press 0 to add a space.

• Press DIR or CID to move the cursor to the right or left.

• Press DELETE to erase characters.

• Press and hold DELETE to erase all characters.

•

ENTER NUMBER

888-883-2445_

ENTER NAME Charlie Johnson_

Directory

Creating directory entries

The first letter of every word is capitalized. The remaining letters in a

•

word start as lower case letters as shown in the character chart below:

Dial Key

Press MENU/SELECT to store your new directory entry. The handset shows

1 2 3 4 5 6 7 8 9 10 11

1 1 . - ‘ ( ) # & / ,

2 a b c A B C 2

3 d e f D E F 3

4 g h i G H I 4

5 j k l J K L 5

6 m n o M N O 6

7 p q r s P Q R S 7

8 t u v T U V 8

9 w x y z W X Y Z 9

0 space 0

Characters by number of key press

SAVED and a confirmation tone sounds.

NOTE S:

The screen shows NUMBER ALREADY SAVED if the number is already in the directory. You

• cannot save the same number more than once.

If you pause for too long while creating an entry, the procedure times out and you have to

• begin again.

To add a predialed telephone number to the directory

While the handset is in idle mode, use the dial pad keys

1. to enter the telephone number (up to 30 digits).

Press and hold REDIAL/PAUSE to insert a three-second

•

dialing pause (a P appears). Press DELETE to make corrections.

•

Press MENU/SELECT to edit the telephone number. Refer

2. to Step 5 in To create a new directory entry on page 29.

Press MENU/SELECT to edit the name. Refer to Step 7 in

3. To create a new directory entry on page 29.

Press MENU/SELECT to store your new directory entry. The

4. handset shows SAVED and sounds a confirmation tone.

888-883-2445

EDIT NUMBER

888-883-2445_

EDIT NAME Charlie Johnson_

Directory

Reviewing the directory

To review directory entries

Press DIR when in idle mode to show the first entry in

1. the directory. DIRECTORY EMPTY appears if there are no directory entries.

-OR- You can also show the first entry in the directory by pressing MENU/SELECT when in idle mode. Press DIR or

CID to scroll to >DIRECTORY, then press MENU/SELECT

twice to select >REVIEW. Press DIR or CID to browse through the directory. Entries

2. appear alphabetically by the first letter in the name.

NOTES:

If the telephone number in the directory exceeds 15 digits, < appears in front of the

• telephone number. Press TONE to move towards the end of the telephone number or press # to move towards the beginning of the telephone number.

If you pause for too long while reviewing an entry, the procedure times out and you have to

• begin again.

To search by name

Press DIR when in idle mode to show the first entry in

1. the directory.

When an entry appears, press the dial pad keys (0-9) to

2. start a name search (alphabetical search).

The directory shows the first name beginning with the first letter associated with the dial pad key if there is an entry in the directory that begins with that letter. Press DIR or CID to scroll through the entries beginning with that letter.

To see other names that start with the letters on the same dial pad key,

3. keep pressing the key until the desired letter is shown. The names appear in alphabetical order.

Charlie Johnson

888-883-2445

Christine Smith

888-722-7702

Charlie Johnson

888-883-2445

For example, if you have the names Jennifer, Jessie, Kevin and Linda in your directory:

If you press 5 (JKL) once, J and then Jennifer display.

• If you press 5 (JKL) once, J displays. Press CID. Jessie displays.

• If you press 5 (JKL) twice, K and then Kevin display.

• If you press 5 (JKL) three times, L and then Linda display.

• If you press 5 (JKL) four times, 5 displays.

• If you press 5 (JKL) five times, J displays and then Jennifer displays again.

•

NOTE: If you press a key (0-9) and no name starts with the letters on that key, the

directory shows the entry that matches the next letter in the directory.

Directory

Dialing, deleting and editing a directory entry

You can dial, delete or edit the displayed directory entry.

See To review directory entries or To search by name on page 31 to show an entry from the directory first.

To dial a directory number

While reviewing a directory entry, press PHONE/FLASH

• or SPEAKER to dial the displayed telephone number from the directory (known as Display Dial).

To delete a directory entry

While reviewing a directory entry, press DELETE. The

1. screen shows DELETE CONTACT?

Press MENU/SELECT to delete the displayed entry from

2. the directory. The handset shows DELETING... and then CONTACT DELETED with a confirmation tone. Once deleted, you cannot retrieve that entry.

-OR- Press OFF/CLEAR to exit and leave the entry intact.

NOTE: If the directory entry you deleted is also in the speed dial location, the telephone will automatically clear the speed dial location that entry occupied.

To edit a directory entry

Robert Brown 800-360-4121

PHONE 0:00:20

Robert Brown

10:30

Robert Brown

DELETE CONTACT?

CONTACT DELETED

11/20

While reviewing a directory entry, press MENU/SELECT.

The screen shows EDIT NUMBER with the current number of the entry.

Follow Step 5 in To create a new directory entry on

page 29 to edit the digits. Press MENU/SELECT to save the number in the display.

The screen shows EDIT NAME with the current name of the entry.

Follow Step 7 in To create a new directory entry on

page 29 to edit the characters. Press MENU/SELECT to confirm. The handset shows SAVED with a

confirmation tone and then shows the updated entry.

EDIT NUMBER

360-4121_

EDIT NAME Robert_

Directory

Speed dial locations

To assign or reassign a directory entry to a speed dial location

Press MENU/SELECT in idle mode.

Press DIR or CID to scroll to >DIRECTORY. Press

MENU/SELECT.

Press DIR or CID to scroll to >SPEED DIAL. Press

MENU/SELECT.

To assign a speed dial location, press DIR or CID to

scroll to an empty speed dial location.

-OR- To reassign a speed dial location, press DIR or CID to scroll to the desired speed dial location.

Press MENU/SELECT to show the directory.

Press DIR or CID to browse through the directory and

find the desired entry.

-ORUse the alphabetical search to find the desired entry. Refer to Steps 2 and 3 in To search by name on page 31.

Press MENU/SELECT to confirm. The name (up to 12

characters) of the desired directory entry appears in the selected speed dial location.

>SPEED DIAL

>0: <EMPTY>

>0: Charlie John

REVIEW

1: Robert Brown

Charlie Johnson

888-883-2445

1: Robert Brown

NOTE S:

If the directory is empty, when you press MENU/SELECT in Step 5, the screen shows

•

DIRECTORY EMPTY.

If the speed dial location you selected is occupied, the new directory entry you selected

•

replaces the old one. Take caution not to replace entries you do not wish to delete from the speed dial locations.

To clear a speed dial location

Follow Steps 1 through 3 in To assign or reassign a

directory entry to a speed dial location on this page to

Charlie John

UNASSIGN?

enter the speed dial list. Press DIR or CID to scroll to a speed dial location.

Press DELETE to clear the selected speed dial location.

<EMPTY> appears in that speed dial location.

NOTE: Clearing the speed dial locations does not affect the entries in the directory.

>0: <EMPTY>

1: Robert Brown

Directory

Speed dial locations

To dial a speed dial number

When in idle mode, press and hold a dial pad key

(0 through 9) to choose the desired speed dial entry. Press PHONE/FLASH or SPEAKER to dial the displayed

telephone number (known as Display Dial).

NOTE: If the speed dial location you selected is empty, the screen shows the speed dial list.

Caller ID

About caller ID

This product supports caller ID services offered by most telephone service providers. Caller ID allows you to see the name, number, date and time of calls. The available caller ID information will appear after the first or second ring.

Information about caller ID with call waiting

Caller ID with call waiting lets you see the name and telephone number of the caller before answering the call, even while on another call.

It may be necessary to change your telephone service to use this feature. Contact your telephone service provider if:

You have both caller ID and call waiting, but as separate

•

services (you may need to combine these services). You have only caller ID service, or only call waiting

•

service. You don’t subscribe to caller ID or call waiting services.

•

There are fees for caller ID services. In addition, services may not be available in all areas.

This product can provide information only if both you and the caller are in areas offering caller ID service and if both telephone service providers use compatible equipment. The time and date are sent by the telephone service provider along with the call information.

Christine Smith

888-722-7702

10:30

11/20

The caller ID information may not be available for every incoming call. The callers may intentionally block their names and/or telephone numbers.

NOTE: You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to either caller ID or combined caller ID with call waiting service.

About home area code

See Home area code on page 14 to determine if you should enter your area code. Entering the area code changes how numbers are displayed in the caller ID history and how to return a call from the caller ID history (see To view the dialing options on page 38).

Caller ID

Caller ID history

How caller ID history (call log) works

The telephone stores caller ID information about the last 50 incoming calls in the telephone base. Each entry may have up to 24 digits for the telephone number and 15 characters for the name. Entries are stored in reverse chronological order. The telephone deletes the oldest entry when the log is full to make room for new calls. If you answer a call before the information appears on the screen, it does not show in the caller ID history.

NOTE: The caller ID information might not be available for every incoming call. The callers might intentionally block their names and/or telephone numbers (see Reasons for missing

caller ID information on page 37).

Memory match

If the incoming telephone number matches the last seven digits of a telephone number in your directory, the name that

Chris

888-722-7702

appears on the screen matches the corresponding name in your directory.

10:30

11/20

For example, if Christine Smith calls, her name appears as Chris if this is how you entered it into your directory.

NOTE: The number shown by your caller ID is in the format sent by the telephone service provider. The telephone ser vice provider usually delivers 10-digit telephone numbers (area code plus telephone number). If the telephone number of the caller does not match a number in your directory, the name appears as it is delivered by the telephone service provider. For example, if the telephone service provider includes the area code and the directory number does not, the name appears as delivered by the telephone service provider.

Caller ID

Caller ID operation

Missed (new) calls indicator

When you have calls that have not been reviewed, the handset idle screen shows XX MISSED CALLS.

HANDSET 1

16 MISSED CALLS

All entries that have not been reviewed are counted as missed (new) calls. Each time you review a caller ID history entry

10:30

marked NEW, the number of missed calls decreases by one.

If you do not want to review the missed (new) calls one by

HANDSET 1

one, but still want to keep them in the caller ID history, you can press and hold OFF/CLEAR for four seconds when

the handset is idle. All the entries in the caller ID history are

10:30

considered old (reviewed), and the missed calls message goes away.

Reasons for missing caller ID information

There are occasions when other information or no information shows for various reasons:

Screen message Reason

PRIVATE NAME The caller prefers not to show the name.

PRIVATE NUMBER The caller prefers not to show the telephone number.

PRIVATE CALLER The caller prefers not to show the name and telephone number.

11/20

UNKNOWN NAME Your telephone service provider cannot determine the

UNKNOWN NUMBER Your telephone service provider cannot determine the

UNKNOWN CALLER Your telephone service provider cannot determine the

caller’s name.

caller’s telephone number.

caller’s name and telephone number. Calls from other countries may also generate this message.

Caller ID

Caller ID operation

To review the caller ID history

Review the caller ID history to find out who called, to return the call or to copy the caller’s name and number into your directory. CALL LOG EMPTY appears if there are no records in the caller ID history.

When a handset is in idle mode, press CID to review the caller ID history

in reverse chronological order starting with the most recent call.

-OR- When a handset is in idle mode, you can also review the caller ID history by pressing MENU/SELECT. Press DIR or CID to scroll to >CALL LOG, then press MENU/SELECT twice to select >REVIEW.

Press DIR or CID to scroll through

the list. A double beep sounds when the list reaches the beginning or end

Christine Smith

888-722-7702

of the caller ID history. Press OFF/CLEAR to exit the caller

10:30

11/20

ID history.

NOTE: If the telephone number has more than 15 digits, only the last 15 digits appear in the caller ID history.

Caller’s name

Caller’s number

Appears when the call is missed and not reviewed.

Date of callTime of call

To view the dialing options

Although the caller ID history entries received typically have 10 digits (the area code plus the seven-digit number), in some areas, you might need to dial only the seven digits, or 1 plus the seven digits, or 1 plus the area code plus the seven digits. You can follow the steps below to change the number of digits that you dial from or store in the directory:

Follow Steps 1 and 2 in To review the caller ID

history on this page to find the entry. Before dialing or saving the telephone number in

the directory, press # repeatedly to show different dialing options for local and long distance numbers.

-OR- Before dialing or saving the telephone number in the directory, press 1 repeatedly if you need to add or remove 1 in front of the telephone number.

NOTE: If you do not need to dial the area code for local calls, make sure to program your home area code (see Home area code on page 14).

Robert Brown 800-360-4121

10:45

Press # 1-800-360-4121 Press # 360-4121 Press # 1-360-4121 Press # 800-360-4121

Press 1 1-800-360-4121 Press 1 800-360-4121

11/20

-OR-

Caller ID

Caller ID operation

To dial a caller ID history number

While reviewing the caller ID history, press DIR or CID

to browse through the caller ID history and find the entry. Press PHONE/FLASH or SPEAKER to dial the

displayed telephone number from the caller ID history (known as Display Dial).

NOTE S:

If the telephone number has more than 15 digits, only the last 15 digits

•

appear in the caller ID history. The telephone can still dial out all digits (up to 24 digits) of that telephone number.

You might need to change how a caller ID number is dialed if the entry

•

does not appear in the correct format. Caller ID numbers might appear with an area code that might not be necessary for local calls, or without a 1 that might be necessary for long distance calls. For details, see To view the dialing options on page 38.

To delete caller ID history entries

To delete a caller ID history entry:

While reviewing the caller ID history, press DIR or CID

to browse through the caller ID history and find the entry. Press DELETE to delete the displayed entry from the

caller ID history. The screen shows DELETING... with a confirmation tone. Once an entry is deleted, you cannot retrieve it.

Christine Smith

888-722-7702

10:30

PHONE 0:01:30

Christine Smith

10:40

DELETING...

11/20

To delete all caller ID history entries:

Press MENU/SELECT in idle mode.

Press DIR or CID to scroll to >CALL LOG. Press MENU/SELECT.

Press DIR or CID to scroll to >DEL ALL CALLS. Press

MENU/SELECT. The screen shows DELETE ALL CALLS?

Press MENU/SELECT to delete all entries from the

caller ID history. The screen shows DELETING... with a confirmation tone. Once entries are deleted, you cannot retrieve them.

-OR- Press OFF/CLEAR to exit and leave all entries in the caller ID history intact.

>DEL ALL CALLS

REVIEW

DELETE

ALL CALLS?

Caller ID

Caller ID operation

Saving a caller ID history entry in the directory

While reviewing the caller ID history, press DIR or

CID to browse through the caller ID history and find the

desired entry. Press MENU/SELECT. The screen shows EDIT NUMBER.

Use the dial pad keys to modify the telephone number

(up to 24 digits).

Press DIR or CID to move the cursor to the right or left.

•

Press and hold REDIAL/PAUSE to enter a three-second

•

dialing pause (a P appears). Press DELETE to erase digits.

•

Press and hold DELETE to erase all digits.

•

Press MENU/SELECT to save the number in the display.

The screen shows EDIT NAME. Use the dial pad keys and refer to the character chart

(page 30) to modify the name (up to 15 characters).

Press 0 to add a space.

• Press DIR or CID to move the cursor to the right or left.

• Press DELETE to erase characters.

• Press and hold DELETE to erase all characters.

•

Press MENU/SELECT to confirm. The screen shows SAVED with a

6. confirmation tone.

Christine Smith

888-722-7702

10:30

EDIT NUMBER

722-7702_

EDIT NAME Chris_

11/20

NOTE S:

The screen shows NUMBER ALREADY SAVED if the number is already in the directory. You

• cannot save the same number more than once.

If the directory is full, the screen shows DIRECTORY FULL.

• If you try to save a caller ID history entry to the directory without a number, UNABLE TO SAVE

• displays.

If the telephone number has more than 15 digits, only the last 15 digits appear in the

• caller ID history. The telephone can still save all digits (up to 24 digits) of that telephone number from the caller ID history in the directory.

You might need to change how a caller ID number is saved in the directory if the entry

• does not appear in the correct format. Caller ID numbers might appear with an area code that might not be necessary for local calls, or without a 1 that might be necessary for long distance calls. For details, see To view the dialing options on page 38.

Answering system

Answering system and voicemail

Your telephone has separate indicators for two different types of voice messages: those left on its built-in answering system and those left at your service provider’s voicemail (fees may apply). Your telephone’s builtin answering system messages and voicemail messages are separate. Each alerts you to new messages differently.

If and NEW VOICEMAIL display on the handset, your telephone service provider is indicating that it has new voicemail for you. To listen to your voicemail, you typically dial an access number provided by your telephone service provider, followed by a security code or PIN.

Some service providers bundle or combine multiple services like voicemail and call waiting, so you may not be aware that you have voicemail. To check what services you have and how to access them, contact your telephone service provider.

To use your voicemail service rather than your answering system, turn off your answering system. To use your answering system rather than your voicemail service, contact your telephone service provider to deactivate your voicemail service. You can also use your telephone answering system and voicemail together by setting your built-in answering system to answer before voicemail answers as described below. To learn how to program your voicemail settings, contact your telephone service provider. Then, if you are on a call, or if the answering system is busy recording a message and you receive another call, the second caller can leave a voicemail message.

If you have voicemail provided by your telephone service provider, we recommend setting your answering system to answer calls at least two rings earlier than your voicemail is set to answer. For example, if your voicemail answers after six rings, set your answering system to answer after four rings. Some voicemail providers may program the delay before answering calls in seconds instead of rings. In this case, allow six seconds per ring when determining the appropriate setting.

Answering system new message indication

When there are new messages (including memos) on the answering system, the number of new messages stored

HANDSET 1

16 NEW MESSAGES

flashes in the message window on the telephone base, and the icon and XX NEW MESSAGES appear on the screen of the system handset. If the new message alert tone is

10:30

11/20

turned on, the telephone base beeps every 10 seconds when there are new messages.

To listen to messages recorded on your digital answering system, use the PLAY MESSAGES menu from the handset or press PLAY/STOP on the telephone base (see Message playback on page 44).

Answering system

Answering system overview

Voice prompts

The system provides voice prompts to guide you through recording announcements and remote access.

Message capacity

The answering system can record up to 99 messages, depending on the length of each message. Individual messages can be up to four minutes, and the approximate recording time is 14 minutes. The actual recording time depends on individual message characteristics. Messages remain available for replay until you delete them.

If the answering system has less than three minutes of recording time left, the remaining time is announced at the end of messages playback.

If the memory is full, the answering system announces, “Memory is full.” The number of messages and F flash alternately in the message window, and REC MEM FULL appears on the handset screen. You must delete some messages before recording new ones.

Call screening

If the answering system and call screening are on, the announcement and the incoming message broadcast at the telephone base when a call arrives.

You can turn call screening on or off using the handset (see Call screening setup on page 17). When call screening is off, you can temporarily turn on call screening by pressing PLAY/STOP or

VOLUME on the telephone base. Call screening will be off for the next

incoming call.

If call screening is on and you want to adjust the playback volume to a comfortable level (1-8) while it is recording messages, press VOLUME on the telephone base. This volume setting is shared with message playback, so when you play messages at volume 1, they play at a very low volume. If you turn up the volume for playback, the call screening for the next incoming message plays at the same volume level.

If call screening is on and you want to silence the telephone base while it is recording messages, press PLAY/STOP on the telephone base. Call screening will be on for the next incoming call.

Answering system

Answering system overview

Call intercept

While call screening, you can press PHONE/FLASH or

SPEAKER on the handset to stop recording and speak

to the caller.

Temporarily turning off the message alert tone

Follow the step below to temporarily silence the message alert tone:

When the telephone base is in idle mode, press any

• telephone base key (except HANDSET LOCATOR).

The message alert tone is activated again with the next incoming message.

NOTE S:

When the telephone base is in idle mode, if you press DELETE

• to temporarily silence the message alert tone, there is a voice prompt to direct you to press DELETE again to delete all old messages (see To delete all old messages at the telephone base on page 46). If you are not going to delete all old messages, wait at least 5 seconds to allow the telephone base to return to idle mode.

To turn off the message alert tone, see Message alert tone on page 18.

•

Answering system

Message playback

To listen to messages

You can use the handset or the telephone base to play messages. If there are new messages, the system plays back only the new messages (oldest first). If there are no new messages, the system plays back all old messages (oldest first).

When playback begins, the total number of messages is announced. Before each message, you hear the day and time it was received. After the last message, you hear “End of messages.” If the system has less than three minutes of recording time left, you hear the remaining time. If the memory of the answering system is full, you hear “Memory is full.”

NOTE S:

If the date and time is not set when a message is recorded, the system announces, “Time and

• date not set” before the message is played. To set the date and time, see Set date/time on page 13.

Only one handset or the telephone base can access the answering system at a time.

•

While the handset is on a call, you cannot play messages.

•

To listen to messages at the telephone base:

Press PLAY/STOP on the telephone base.

1. The system announces the number of messages, then

2. begins playback. The message sequence is shown on the message window.

Press PLAY/STOP to stop the playback.

NOTE: If there are no messages in the answering system, when in Step 1 above, the

system announces, “You have no message.”

To listen to messages at the handset:

>PLAY MESSAGES

Press MENU/SELECT when in idle mode to enter the

ANSWERING SYS

main menu. Press MENU/SELECT to select >PLAY MESSAGES.

2. The system announces the number of messages, then

3. begins playback. The message sequence is shown on the handset’s screen.

Press 5 to stop the playback.

NOTE: If there are no messages in the answering system, the handset

shows NO MESSAGE and announces, “You have no message.”

16 NEW MESSAGES 03 OLD MESSAGES

3-DELETE 5-STOP 4-REPEAT 6-SKIP

10:30

MSG #

1/16

Answering system

Message playback

Options during playback

When a message is playing, you can adjust the playback volume, skip, repeat, or delete the message.

When messages are playing on the telephone base:

Press VOLUME to adjust the message playback

• volume (1-8).

To repeat the message currently playing, press

•

REPEAT after the answering system plays the day

and time the current message was received. To listen to the previous message, press REPEAT

• while the answering system is playing the day and time the current message was received.

Press SKIP to skip to the next message.

• Press DELETE to delete the message. The telephone base announces,

• “Message deleted.”

Press PLAY/STOP to stop the playback.

•

When messages are playing on the handset:

Press DIR/VOLUME to increase or press CID/VOLUME to decrease the

• message playback volume.

Press SPEAKER to switch between speakerphone and handset earpiece.

• To repeat the message currently playing, press 4 after the answering

• system plays the day and time the current message was received.

To listen to the previous message, press 4 while the

• answering system is playing the day and time the current message was received.

Press 6 to skip to the next message.

• Press 3 to delete the message. The handset announces,

• “Message deleted.”

Press 5 to stop the playback.

•

Answering system

Message playback

To delete all old messages

Use this feature to delete all old messages. Once messages are deleted, you cannot retrieve them. New (unheard) messages cannot be deleted until you have listened to them.

NOTE: If there are no old messages and you press DELETE on the telephone base, the

system announces, “You have no old message.” On the handset, when you select

DELETE ALL OLD, the screen shows NO MESSAGE.

To delete all old messages at the telephone base:

Press DELETE on the telephone base. The system

1. announces, “To delete all old messages, press DELETE again.”

Press DELETE within three seconds. The system

2. announces, “All old messages deleted.”

To delete all old messages at the handset:

Press MENU/SELECT when in idle mode to enter the main menu.

1. Press DIR or CID to scroll to >ANSWERING SYS, then

2. press MENU/SELECT.

Press DIR or CID to scroll to >DELETE ALL OLD.

3. Press MENU/SELECT. The screen shows DELETE ALL OLD

MESSAGES?

Press MENU/SELECT to confirm. The screen shows DELETING... and then

ALL OLD MSGS DELETED! with a confirmation tone.

-ORPress OFF/CLEAR to exit and leave all old messages intact.

>DELETE ALL OLD

RECORD MEMO

Answering system

Recording and playing memos

Memos are messages you record yourself. They are saved, played back and deleted exactly like incoming messages. You can record a memo as a reminder to yourself, or leave a message for someone else using the same telephone.

To record a memo

Press MENU/SELECT when in idle mode to enter the main menu.

1. Press DIR or CID to scroll to >ANSWERING SYS, then

2. press MENU/SELECT.

Press DIR or CID to scroll to >RECORD MEMO.

3. Press MENU/SELECT. The system announces, “Record

4. after the tone. Press 5 when you are done.”

Speak towards the microphone on the handset after a long beep. You can

5. record a memo up to four minutes. Memos shorter than two seconds are not recorded.

Press 5 to stop recording. The system announces, “Recorded“ to confirm

6. the recording has finished.

NOTE: If the answering system memory is full, when you press MENU/SELECT in Step 4,

the answering system announces, “Memor y is full.”

To play back memos

RECORD MEMO... 5-STOP

Memos are stored as messages. See Message playback on page 44 for instructions on playback and deletion.

Answering system

Message window displays

The message window on the telephone base displays the total number of messages. See the table below for other message window displays.

0 There are no messages in the answering system.

(flashing)

1-99 Total number of messages and memos.

1-99

(flashing)

1-99 and F

(alternating)

-- The answering system is being programmed by the handset.

0-5 Telephone base ringer volume while adjusting.

1-8 Telephone base speaker volume while adjusting.

After a power failure, this flashes to indicate that you need to set the date and time.

•

Current message number during old message playback.

•

Total number of new messages and memos. The number flashes when

• there are new messages that have not been reviewed.

Current message number during new message playback.

•

After a power failure, the number in the message window flashes to

• indicate the date and time need to be set.

Memory is full. Messages must be deleted before new messages can be recorded.

•

The answering system is answering a call or recording a memo

• or announcement.

The answering system is being accessed remotely.

•

Answering system

Remote access

You can access the answering system remotely by dialing your home telephone number from any touch-tone telephone.

To remotely access the answering system

Dial your telephone number from any touch-tone telephone.

When the answering system answers, enter the two-digit remote access code (19, unless you have changed it; refer to Remote access code on page 18). The answering system automatically announces the number of messages (new or old) if there are any.

If there are new messages, the answering system automatically begins to play new messages only.

-OR- If there are no new messages, the answering system automatically begins to play all old messages.

You can also enter the remote commands:

Play all messages

Play new messages

Delete a message

Delete all old messages 33Press to delete all old messages.

Press to listen to all messages. If there are new messages, the system plays back only the new messages (oldest first). If there are no new messages, the system plays back all old messages (oldest first).

Press to listen to new messages only.

Press during message playback to delete the current message.

Replay current message or previous message

Stop

Play help menu

* 5

Skip to next message

Record a announcement

* 7

Turn system on or off

Exit 8 or hang up

To repeat the message currently playing, press 4 after the answering system plays the day and time the current message was received.

To listen to the previous message, press 4 while the answering system is playing the day and time the current message was received.

Press to stop playback and recording.

Press to listen to a list of remote commands.

Press during playback to skip the current message and advance to the next message.

Press to record a new announcement. Begin speaking after the long beep.

Press to turn the answering system on or off.

Press to end remote access (the call is terminated).

Answering system

Remote access

Hang up to end the call and save all messages.

There is a wallet card listing the remote commands at the back of this user’s manual. Cut it out and keep it in your wallet for quick reference.

NOTE S:

If you do not enter a valid remote access code, the system answers the call automatically.

•

If the date and time is not set when a message is recorded, the system announces, “Time and

• date not set” before the answering system announces the number of messages.

If there are no messages in the answering system, the system announces,

• “You have no message.”

If there are no new messages in the answering system, when you press 2 to play back new

• messages, the system announces, “You have no new message.”

If you pause for more than four seconds during remote access, you hear a help menu listing

• all features and commands. If there is no command for another 20 seconds, the call ends automatically.

If the memory is full, the answering system answers after 10 rings and announces, “Memory

• is full. Enter the remote access code.” Enter your remote access code to access the messages and announcements.

When the answering system is turned off, the telephone answers after 10 rings and

• announces, “Please enter your remote access code.”

Appendix

Screen icons, indicator lights and alert tones

Screen icons

HANDSET 1

16 MISSED CALLS

10:30

MSG #

10/16

(flashing)

or or

Low battery; place the handset in the telephone base to recharge.

Indicates the battery voltage level.

Battery is charging.

(animated display)

The speakerphone is in use.

The handset ringer is turned off.

New voicemail received from the telephone service provider.

ANS ON Answering system is turned on.

New message in the answering system.

NEW While reviewing the caller ID history,

missed calls that have not been reviewed.

MUTE Microphone is muted.

MSG #

10/16

While playing messages, the sequence of the message currently playing. (XX/YY; XX is the sequence of the message currently playing; YY is the total number of all new or old messages.)

Handset indicator lights

CHARGE light

On when the handset is charging in the telephone base.

Backlight (lighted display and dial pad)

On when a call is coming in.

On when a key is pressed.

SPEAKER light

On when the speakerphone is in use.

Appendix

Screen icons, indicator lights and alert tones

Telephone base indicator lights

ANS ON/OFF light

On when the built-in answering system is on.

IN USE light

On when the handset is in use or when the answering system is answering an incoming call or when the answering system is being accessed remotely.

Flashes when another telephone on the same line is in use.

Flashes quickly when there is an incoming call.

Handset alert tones

One short beep (Key tone or playback confirmation tone)

One long beep (Recording or playback confirmation tone)

Two short beeps (Error tone)

Three short beeps (Out-of-range or no-power-atbase warning tone)

Three short high-pitched beeps (Confirmation tone)

Four short beeps (Low-battery warning tone)

Telephone base alert tones

One short beep (Playback confirmation tone)

Beeps every 10 seconds (Message alert tone)

One long beep (Recording or playback confirmation tone)

A key is pressed.

Plays at the end of each message.

Start or end recording.

Plays at the end of all messages.

Command has failed.

You have reached the beginning or end of the list.

You have reached the minimum or maximum listening volume.

The handset is out of range or there is no power at the telephone base.

The telephone has completed the command successfully.

Low battery warning.

Plays at the end of each message.

Message alert.

The answering system starts recording a message if call screening is on.

Plays at the end of all messages.

Appendix

Handset display screen messages

CALL LOG EMPTY You are accessing an empty caller ID history.

DIRECTORY EMPTY There are no directory entries.

DIRECTORY FULL The directory is full. You cannot save any new entries unless

ENDED You have just ended a call.

INCOMING CALL There is a call coming in.

LINE IN USE An extension telephone on the same line or the handset is

LOW BATTERY The battery needs to be charged.

MICROPHONE ON Mute is off so the other party can hear your voice.

MUTED The microphone is off.

NEW VOICEMAIL There are new voicemail messages from your telephone

NO BATTERY You have placed the handset in the telephone base without

NO LINE There is no telephone line connected.

NO MESSAGE There are no messages in the answering system.

NOT AVAILABLE

AT THIS TIME

NUMBER

ALREADY SAVED

OUT OF RANGE OR

NO PWR AT BASE

PAGING The telephone base is paging the handset.

you delete some current entries.

in use.

service provider.

installing a battery in that handset.

Someone else is already using the answering system on the telephone base.

The telephone number you have entered is already stored in the directory.

The handset has lost communication with the telephone base.

PHONE The handset is on a call.

PLACE IN

CHARGER

REC MEM FULL The answering system memory is full.

RINGER MUTED The ringer is muted temporarily during an incoming call.

SAVED The entry is now in the directory.

SPEAKER The handset speakerphone is in use.

UNABLE TO CALL.

TRY AGAIN

The battery is very low. The handset should be placed in the telephone base.

While the handset is on a call, it is out of range or there is no power at the telephone base.

Appendix

Handset display screen messages

UNABLE TO SAVE You cannot save a caller ID history entry without a number

XX MISSED CALLS There are new calls in the caller ID history.

XX NEW MESSAGES There are new messages in the answering system.

to the directory.

Appendix

Troubleshooting

If you have difficulty with your telephone, please try the suggestions below. For customer service, or to purchase accessories or replacement parts, visit

our website at www.telephones.att.com, or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. When you call customer service, you

will need the serial number or model number found on the bottom of the telephone base.

My telephone doesn’t work at all.

Make sure the power cord is securely plugged in.

• Make sure that the battery connector is securely plugged into the

• cordless handset.

Make sure the telephone line cord is securely and firmly plugged into the

• telephone base and the telephone wall jack.

Make sure the battery is fully charged. See Technical specifications on

• page 71 for battery charging times. For optimum daily performance, return the cordless handset to the telephone base when not in use.

If the battery is depleted, it may take approximately 30 minutes to charge

• the handset before it shows LOW BATTERY. Refer to Battery charging on page 6 for details.

Reset the telephone base. Unplug the electrical power. Wait for

• approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

You may need to purchase a new battery. Please refer to Battery installation

• on page 5.

I cannot get a dial tone.

First try all the suggestions above.

• Move the cordless handset closer to the telephone base. You might have

• moved out of range.

If the previous suggestions don’t work, disconnect the telephone base from the

• telephone wall jack and connect the jack to a different telephone. If there is no dial tone on that telephone either, the problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

Your telephone line cord might be defective. Try installing a new telephone

• line cord.

I cannot dial out.

First try all the suggestions in the item I cannot get a dial tone on this page.

• Make sure you have a dial tone before dialing. The cordless handset may

• take a second or two to find the telephone base and produce a dial tone. This is normal. Wait an extra second before dialing.

Appendix

Troubleshooting

Check that all the telephones connected to the same telephone line are

• hung up.

Make sure to set the dial mode to the correct setting (pulse dialing or tone

• dialing) for the service in your area (see Dial mode on page 14).

Eliminate any background noise. Noise from a television, radio or other

• appliances may cause the telephone to not dial out properly. If you cannot eliminate background noise, first try muting the cordless handset before dialing, or dialing from another room in your home with less background noise.

If the other telephones in your home are having the same problem, the

• problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

My cordless handset isn’t performing normally.

Make sure the power cord is securely plugged into the telephone base.

• Plug the power adapter into a different, working electrical outlet not controlled by a wall switch.

Move the cordless handset closer to the telephone base. You might have

• moved out of range.

Reset the telephone base. Unplug the electrical power. Wait for 15

• seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

Other electronic products can cause interference to your cordless telephone.

• Try installing your telephone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

OUT OF RANGE OR NO PWR AT BASE appears on my cordless handset.

Ensure that the telephone base is powered up.

• Place the cordless handset in the telephone base for one minute to allow

• the cordless handset and base to synchronize.

Move the cordless handset closer to the telephone base. You might have

• moved out of range.

Reset the telephone base. Unplug the electrical power. Wait for 15

• seconds then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

Other electronic products can cause interference to your cordless telephone.

• Try installing your telephone as far away from these types of electronic devices as possible: television sets, VCRs, or other cordless telephones.

Appendix

Troubleshooting

The batteries do not hold a charge.

If the cordless handset is in the telephone base and the charge light does not

• come on, refer to the item The charge light is off on this page.

Make sure the battery is fully charged. See Technical specifications on

• page 71 for battery charging times. For optimum daily performance, return the cordless handset to the telephone base when not in use.

If the battery is depleted, it may take approximately 30 minutes to charge

• the handset before it shows LOW BATTERY. Refer to Battery charging on page 6 for details.

You may need to purchase a new battery. Please refer to Battery installation

• on page 5.

The charge light is off.

Make sure the power cord is plugged in correctly and securely.

• Make sure the battery is installed correctly in the handset. Follow the

• instructions in Battery installation on page 5 to install the battery.

Unplug the electrical power. Wait for 15 seconds, then plug it back in. Allow

• up to one minute for the cordless handset and telephone base to reset.

Clean the cordless handset and telephone base charging contacts each

• month using a pencil eraser or cloth.

I get noise, static, or weak signals even when I’m near the telephone base.

If you subscribe to high-speed Internet service (DSL - digital subscriber line)

• through your telephone line, you must install a DSL filter between the telephone line cord and the telephone wall jack (see Telephone base installation on page 4). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

Other electronic products, such as computers, wireless routers, microwave

• ovens and other cordless telephones can interfere with the performance of your cordless telephone. You may be able to improve the performance of your telephone by installing the telephone base as far away as possible from other electronic devices.

Do not install this telephone near a microwave oven or on the same

• electrical outlet. You may experience decreased performance while the microwave oven is operating.

If your telephone is plugged in with a modem or a surge protector, plug

• the telephone (or modem/surge protector) into a different location. If this doesn’t solve the problem, relocate your telephone or modem farther apart from one another, or use a different surge protector.

Appendix

Troubleshooting

Move your telephone to a higher location. The telephone will likely have

• better reception when installed in a high area.

If the other telephones in your home are having the same problem, the

• problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

I experience poor sound quality when using the speakerphone.

For increased sound quality while using the speakerphone, place the

• handset on a flat surface with the dial pad facing up.

When using a speakerphone, controlling background noise in your

• environment is essential. While you are listening to your party, press MUTE to temporarily turn your microphone off. When it is your turn to speak, remember to press MUTE again to turn the microphone on.

Excessive background noise will cause a speakerphone to fade in and out.

• Try controlling the background noise by turning off any audio devices near the speakerphone. Also, try to avoid interrupting the person at the other end of the conversation while the person is speaking. If background noise cannot be controlled, you should terminate speakerphone operation and return to normal handset mode.

I hear other calls while using my telephone.

Disconnect the telephone base from the telephone wall jack, and plug in

• a different telephone. If you still hear other calls, the problem is probably in your wiring or telephone service. Call your telephone service provider (charges may apply).

My calls cut in and out while I’m using my cordless handset.

Other electronic products can cause interference to your cordless

• telephone. Try installing your telephone as far away as possible from electronic devices such as wireless routers, or other cordless telephones.

Move the handset closer to the base. The operating range may vary with

• environmental conditions and time of use. There may be places within your environment that a cordless telephone will not work well. If the problem only occurs in certain areas of your environment, you can conclude that there is nothing wrong with the telephone.

Do not install this telephone near a microwave oven or on the same

• electrical outlet. You may experience decreased performance while the microwave oven is operating.

If your telephone is plugged in with a modem or surge protector, plug

Appendix

Troubleshooting

Move your telephone base to a higher location. The telephone will have

• better reception when installed in a high area.

If the other telephones in your home are having the same problem, the

• problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

If you subscribe to high-speed Internet service (DSL - digital subscriber line)

My cordless handset does not ring when I receive a call.

Make sure that the ringer is not turned off. Refer to Ringer volume on

• page 11.

Make sure the telephone line cord is plugged securely into the telephone

• base and the telephone wall jack. Make sure the power cord is securely plugged in.

The cordless handset may be too far from the telephone base.

• Make sure the battery is fully charged. See Technical specifications on

• page 71 for battery charging times. For optimum daily performance, return the cordless handset to the telephone base when not in use.

You may have too many extension telephones on your telephone line to

• allow all of them to ring simultaneously. Try unplugging one telephone at a time until the telephone starts ringing.

The layout of your home or office might be limiting the operating range. Try

• moving the telephone base to another location, preferably on an upper floor.

If the other telephones in your home are having the same problem, the

• problem is in your wiring or telephone service. Contact your telephone service provider (charges may apply).

Test a working telephone at the telephone wall jack. If another telephone

• has the same problem, the problem is the telephone wall jack. Contact your telephone service provider (charges may apply).

Other electronic products can cause interference to your cordless

• telephone. Try installing your telephone as far away as possible from electronic devices such as wireless routers, or other cordless telephones.

Completely remove then replace the battery. Place the cordless handset

• in the telephone base. Wait for the cordless handset to reestablish its connection with the telephone base. Allow up to one minute for this to take place.

Appendix

Troubleshooting

Your telephone line cord might be defective. Try installing a new telephone

• line cord.

My caller ID isn’t working.

Caller ID is a subscription service. You must subscribe to this service from

• your telephone service provider for this feature to work on your telephone.

Your caller must be calling from an area that supports caller ID.

• Both your and your caller’s telephone service providers must use caller ID

• compatible equipment.

Make sure the home area code is set correctly in the telephone (see

• Home area code on page 14).

If you subscribe to high-speed Internet service (DSL - digital subscriber line)

• through your telephone line, you must install a DSL filter between the telephone line and the telephone wall jack (see Telephone base installation on page 4). The filter prevents noise and caller ID problems caused by DSL interference. Please contact your DSL service provider for more information about DSL filters.

My telephone does not receive caller ID when on a call.

Make sure you subscribe to caller ID with call waiting features provided by

• your telephone service provider. Caller ID features work only if both you and the caller are in areas offering caller ID service, and if both telephone service providers use compatible equipment.

A icon shows on the display and I don’t know why.

Your telephone has voicemail indication that is separate from the built-in

• answering system. If appears on the display, then your telephone has received a signal from your telephone service provider that you have a voicemail message waiting for you to retrieve from your telephone service provider. Contact your telephone service provider for more information on how to access your voicemail.

I cannot retrieve voicemail messages.

Your telephone has both a built-in answering system and voicemail

• indication. They are independent features and each alerts you to new messages differently (see Answering system and voicemail on page 41). If you subscribe to voicemail service from your telephone service provider (charges may apply), contact your telephone service provider for more information on how to access your voicemail.

Incomplete messages.

If a caller leaves a very long message, part of it may be lost when the

• answering system disconnects the call after four minutes.

Appendix

Troubleshooting

If the caller pauses for longer than seven seconds, the answering system

• stops recording and disconnects the call.

If the answering system’s memory becomes full during a message, the

• answering system stops recording and disconnects the call.

If the caller’s voice is very soft, the answering system may stop recording

• and disconnects the call.

If someone picks up the call at a telephone on the same line during a

• message, the answering system stops recording and disconnects the call. Part of the message may be lost.

Difficulty hearing messages.

Press VOLUME to adjust the speaker volume on the telephone base.

• Press DIR/VOLUME to increase the message playback volume on a handset.

•

The answering system does not answer after correct number of rings.

Make sure the answering system is on. When the answering system is on,

• ANS ON should show on the handset and the ANSWER ON/OFF light is lit on the telephone base (see Answering mode on page 16).

If toll saver is selected, the number of rings changes to two when there

• are new messages (see Number of rings on page 17).

If the memory is full or the answering system is off, the answering system

• answers after 10 rings.

In some cases, the answering system is affected by the ringing system

• used by the telephone service provider.

If you subscribe to voicemail service, change the number of rings so

• that your answering system answers before your voicemail answers (see Answering system and voicemail on page 41). To determine how many rings activate your voicemail, contact your telephone service provider.

If there is a fax machine connected to the same telephone line, try

• disconnecting the fax machine. If that solves the problem, consult your fax machine documentation for information on compatibility with answering systems.

The answering system announces, “Time and date not set.”

You need to reset the date and time (see Set date/time on page 13).

•

The answering system does not respond to remote commands.

Make sure to enter your remote access code correctly (see Remote access

• on page 49).

Make sure you are calling from a touch-tone telephone. When you dial a

• number, you should hear tones. If you hear clicks, the telephone is not a touch-tone telephone and cannot activate the answering system.

Appendix

Troubleshooting

The answering system may not detect the remote access code while your

• announcement is playing. Try waiting until the announcement is over before entering the code.

There may be interference on the telephone line you are using. Press dial

• pad keys firmly.

The answering system does not record messages.

Make sure the answering system is on (see Answering mode on page 16).

• Make sure the memory of the answering system is not full. When the

• answering machine memory is full, it does not record new messages until some old messages are deleted.

If you subscribe to voicemail service, change the number of rings so

If there is a fax machine connected to the same telephone line, try

• disconnecting the fax machine. If that solves the problem, consult your fax machine documentation for information on compatibility with answering systems.

Announcement is not clear.

When you record your announcement, make sure you speak in a normal

• tone of voice, towards the microphone on the handset.

Make sure there is no background noise (TV, music, etc.) while recording.

•

I subscribe to a nontraditional telephone service that uses my computer to establish connections, and my telephone doesn’t work.

Make sure your computer is powered on.

• Make sure your Internet connection is working properly.

• Make sure that the software is installed and running for your nontraditional

• telephone service.

Make sure to plug your USB telephone adapter into a dedicated USB

• port on your computer. Do not plug it into a multiple port USB hub (USB splitter) that is not powered.

In a few rare instances, the USB port on your computer may not have

• enough power. In these instances, try using a USB hub with its own external power supply.

If you are using a firewall, it may prevent access to your nontraditional

• telephone service. Contact your service provider for more information.

Appendix

Troubleshooting

Common cure for electronic equipment:

If the telephone is not responding normally, try resetting it. Do the following in the order listed:

Disconnect the power to the telephone base.

1. Disconnect the cordless handset battery.

2. Wait a few minutes.

3. Connect power to the telephone base.

4. Completely remove then replace the battery. Place the cordless handset

5. into the telephone base.

Wait for the cordless handset to reestablish its connection with the

6. telephone base. Allow up to one minute for this to take place.

Appendix

Maintenance

Taking care of your telephone

Your cordless telephone contains sophisticated electronic parts, so it must

• be treated with care.

Avoid rough treatment.

• Place the handset down gently.

• Save the original packing materials to protect your telephone if you ever

• need to ship it.

Avoid water

Your telephone can be damaged if it gets wet. Do not use the handset in

• the rain, or handle it with wet hands. Do not install the telephone base near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause power surges harmful to electronic

• equipment. For your own safety, take caution when using electric appliances during storms.

Cleaning your telephone

Your telephone has a durable plastic casing that should retain its luster for

• many years. Clean it only with a soft cloth slightly dampened with water or mild soap.

Do not use excess water or cleaning solvents of any kind.

•

Remember that electrical appliances can cause serious injury if used when you are wet or standing in water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE POWER CORD AND TELEPHONE LINE CORDS FROM THE WALL. Then pull the telephone out by the unplugged cords.

Appendix

Important safety information

This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.

Safety information

Read and understand all instructions in the user’s manual. Observe all markings on

•

the product.

Avoid using a telephone during a thunderstorm. There might be a slight chance of electric

•

shock from lightning.

Do not use a telephone in the vicinity of a gas leak. Under certain circumstances, a spark

•

may be created when the adapter is plugged into the power outlet, or when the handset is replaced in its cradle. This is a common event associated with the closing of any electrical circuit. The user should not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the phone is located in an environment containing concentrations of flammable or flame-supporting gases, unless there is adequate ventilation. A spark in such an environment could create a fire or explosion. Such environments might include: medical use of oxygen without adequate ventilation; industrial gases (cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.

Do not use this product near water, or when you are wet. For example, do not use it in a

•

wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquids, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly.

Install this product in a protected location where no one can trip over any line or power

•

cords. Protect cords from damage or abrasion.

If this product does not operate normally, read Troubleshooting starting on page 55 in

•

this user’s manual. If you cannot solve the problem, or if the product is damaged, refer to Limited warranty starting on page 69. Do not open this product except as may be directed

in your user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks.

Replace batteries only as described in Battery installation and charging on page 5 in

•

your user’s manual. Do not burn or puncture batteries — they contain caustic chemicals.

The power adapter is intended to be correctly oriented in a vertical or floor mount

•

position. The prongs are not designed to hold the plug in place if it is plugged into a ceiling

or an under-the-table or cabinet outlet.

CAUTION: Use only the power adapter provided with this product. To obtain a replacement, visit our website at www.telephones.att.com, or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Especially about cordless telephones

Privacy: The same features that make a cordless telephone convenient create some

•

limitations. Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset. For this

reason, you should not think of cordless telephone conversations as being as private as those on corded telephones.

Appendix

Important safety information

Electrical power: The telephone base of this cordless telephone must be connected to a

•

working electrical outlet which is not controlled by a wall switch. Calls cannot be made from the handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.

Potential TV interference: Some cordless telephones operate at frequencies that may

•

cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the telephone base of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.

Rechargeable batteries: This product contains nickel-metal hydride rechargeable batteries.

•

Exercise care in handling batteries in order not to create a short circuit with conductive material such as rings, bracelets, and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner.

•

Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in an industry program to collect and recycle nickel-metal hydride rechargeable batteries when taken out of service within the United States. These batteries may be taken to a participating local retailer of replacement batteries or recycling center. Or you may call 1 (800) 8-BATTERY for locations accepting spent Ni-MH batteries.

Precautions for users of implanted cardiac pacemakers

Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology

Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at least six inches from the pacemaker.

•

Should NOT place wireless telephones directly over the pacemaker, such as in a breast

•

pocket, when it is turned ON.

Should use the wireless telephone at the ear opposite the pacemaker.

•

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless telephones.

Especially about telephone answering systems

Two-way recording: This unit does not sound warning beeps to inform the other party that the

call is being recorded. To ensure that you are in compliance with any federal or state regulations regarding recording a telephone call, you should start the recording process and then inform the other party that you are recording the conversation.

SAVE THESE INSTRUCTIONS

Appendix

FCC Part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX. This identifier must be provided to your telephone service provider upon request.

The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with the applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual.

The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your telephone service provider.

This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable the alarm equipment, consult your telephone service provider or a qualified installer.

If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty.

If this equipment is causing harm to the telephone network, the telephone service provider may temporarily discontinue your telephone service. The telephone service provider is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone service provider is required to inform you of your right to file a complaint with the FCC. Your telephone service provider may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone service provider is required to notify you if such changes are planned.

If this product is equipped with a corded or cordless handset, it is hearing aid compatible.

If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please:

Remain on the line and briefly explain the reason for the call before hanging up.

•

Perform such activities in off-peak hours, such as early morning or late evening.

•

Industry Canada

Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

The term ‘’IC:‘’ before the certification/registration number only signifies that the Industry Canada technical specifications were met.

The Ringer Equivalence Number (REN) for this terminal equipment is 0.1B. The REN is an indication of the maximum number of devices allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices does not exceed five.

This product meets the applicable Industry Canada technical specifications.

Appendix

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules.

These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver

•

is connected.

Consult the dealer or an experienced radio/TV technician for help.

•

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this telephone.

To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The telephone base shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20cm (8 inches) or more.

This Class B digital apparatus complies with Canadian ICES-003.

Appendix

Limited warranty

The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to our website at

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

What does this limited warranty cover?

The manufacturer of this AT&T branded product warrants to the holder of a valid proof of purchase (“CONSUMER” or “you”) that the product and all accessories provided in the sales package (“PRODUCT”) are free from defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with the PRODUCT operating instructions. This limited warranty extends only to the CONSUMER for products purchased and used in the United States of America and Canada.

What will be done if the PRODUCT is not free from defects in materials and workmanship

during the limited warranty period (“materially defective PRODUCT”)?

During the limited warranty period, the manufacturer’s authorized service representative repairs or replaces at the manufacturer’s option, without charge, a materially defective PRODUCT. If the manufacturer repairs the PRODUCT, they may use new or refurbished replacement parts. If the manufacturer chooses to replace the PRODUCT, they may replace it with a new or refurbished PRODUCT of the same or similar design. The manufacturer retains the defective parts, modules, or equipment. Repair or replacement of the PRODUCT, at the manufacturer’s option, is your exclusive remedy. The manufacturer returns the repaired or replacement products to you in working condition. You should expect the repair or replacement to take approximately 30 days.

How long is the limited warranty period?

The limited warranty period for the PRODUCT extends for ONE (1) YEAR from the date of purchase. If the manufacturer repairs or replaces a materially defective PRODUCT under the terms of this limited warranty, this limited warranty also applies to repaired or replacement PRODUCT for a period of either (a) 90 days from the date the repaired or replacement PRODUCT is shipped to you or (b) the time remaining on the original one-year limited warranty; whichever is longer.

What is not covered by this limited warranty?

This limited warranty does not cover:

PRODUCT that has been subjected to misuse, accident, shipping or other physical damage,

• improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or

PRODUCT that has been damaged due to repair, alteration, or modification by anyone

• other than an authorized service representative of the manufacturer; or

PRODUCT to the extent that the problem experienced is caused by signal conditions,

• network reliability or cable or antenna systems; or

PRODUCT to the extent that the problem is caused by use with non-AT&T accessories; or

•

PRODUCT whose warranty/quality stickers, PRODUCT serial number plates or electronic

• serial numbers have been removed, altered or rendered illegible; or

PRODUCT purchased, used, serviced, or shipped for repair from outside the United States

• of America or Canada, or used for commercial or institutional purposes (including but not limited to products used for rental purposes); or

PRODUCT returned without a valid proof of purchase (see item 6 below); or

•

Charges for installation or setup, adjustment of customer controls, and installation or

• repair of systems outside the unit.

Appendix

Limited warranty

How do you get warranty service?

To obtain warranty service in the United States of America, visit

www.telephones.att.com or call 1 (800) 222-3111. In Canada, dial 1 (866) 288-4268. NOTE: Before calling for service, please review the user’s

manual. A check of the PRODUCT’s controls and features might save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are responsible for delivery or handling charges incurred in the transport of the PRODUCT(s) to the service location. The manufacturer will return repaired or replaced PRODUCT under this limited warranty. Transportation, delivery or handling charges are prepaid. The manufacturer assumes no risk for damage or loss of the PRODUCT in transit. If the PRODUCT failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, the manufacturer notifies you and requests that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of products that are not covered by this limited warranty.

What must you return with the PRODUCT to get warranty service?

You must:

Return the entire original package and contents including the PRODUCT to the service

location along with a description of the malfunction or difficulty; and

Include a “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased

(PRODUCT model) and the date of purchase or receipt; and

Provide your name, complete and correct mailing address, and telephone number.

Other limitations

This warranty is the complete and exclusive agreement between you and the manufacturer of this AT&T branded PRODUCT. It supersedes all other written or oral communications related to this PRODUCT. The manufacturer provides no other warranties for this PRODUCT. The warranty exclusively describes all of the manufacturer’s responsibilities regarding the PRODUCT. There are no other express warranties. No one is authorized to make modifications to this limited warranty and you should not rely on any such modification.

State/Provincial Law Rights: This warranty gives you specific legal rights, and you might also have other rights that vary from state to state or province to province.

Limitations: Implied warranties, including those of fitness for a particular purpose and merchantability (an unwritten warranty that the PRODUCT is fit for ordinary use) are limited to one year from date of purchase. Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation might not apply to you. In no event shall the manufacturer be liable for any indirect, special, incidental, consequential, or similar damages (including, but not limited to lost profits or revenue, inability to use the PRODUCT or other associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use of this PRODUCT. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion might not apply to you.

Please retain your original sales receipt as proof of purchase.

Appendix

Technical specifications

RF frequency band 1921.536MHz — 1928.448MHz

Channels 5

Operating temperature 32°F — 122°F

Telephone base voltage (AC voltage, 60Hz)

Telephone base voltage (DC adapter output)

Handset voltage 2.4 — 3.2VDC

Charger voltage (AC adapter output)

0°C — 50°C

96 — 130Vrms

6VDC @400mA

6VAC @300mA

Operating times and charging time differ depending on the capacity of the battery you are using.

Battery capacity 300mAh battery 400mAh battery

Operating times* Talk time (handset): up to

seven hours

Talk time (speakerphone): up to four hours

Standby: up to five days

Charging time 10 hours 16 hours

* Operating times vary depending on your actual use and the age of the battery.

Talk time (handset): up to seven hours

Talk time (speakerphone): up to five hours

Standby: up to seven days

DECT 6.0 digital technology

Telecommunications (DECT) 6.0 is a new frequency band that transmits your voice across multiple channels. This technology provides superior quality of voice and sound, high protection against wiretapping and better range than

2.4 GHz and 5.8 GHz phone systems, while not interfering with wireless routers.

Telephone operating range

This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.

Appendix

Index

Alert tones, 52 Alphabetical search, 31 Announcement, 15 Answer a call, 21 Answering mode, 16 Answering system, 41–50 Answering system and voicemail, 41 Answering system settings, 15–18 Any key answer, 21 Area code, 14, 35, 38 Auto off, 21

Base ringer volume (ringer volume control), 19

Base volume control, 42, 45 Battery charging, 6 Battery installation, 5

Caller ID, 35 Caller ID history (call log), 36–40 Call intercept, 43 Call screening, 17, 42 Call waiting, 24, 35 Chain dialing, 25 Character chart, 30 Clock, 13

Dial a redial list number, 22 Dial a speed dial number, 34 Dialing options, 38 Dial mode, 14 Directory, 28–32 Directory storage, 29 Display dial, 22, 32, 34, 39 Display screen messages, 53 DSL filter, 4, 7

Elapsed time, 20 End a call, 21

Flash, 24

Handset locator, 27 Handset ringer tone (selectable

ringer tone), 11 Handset ringer volume (ringer

volume control), 11 Handset volume control, 15, 24, 45

Important safety information, 65 Indicator lights, 51

Key tone, 13

Date and time, 13 Delete all entries from caller ID

history, 39 Delete messages, 45, 49 Dial a directory number, 32 Dial a number from caller ID

history, 39

Language, 11 Limited warranty, 69

Maintenance, 64 Make a call, 20 Memo, 47

Appendix

Index

Memory match, 36 Menu, 10–18 Message alert tone, 18 Message playback, 44 Message window displays, 48 Missed (new) calls indicator, 37 Mute, 24

Number of rings, 17, 41

Operation time, 71

Pause, 20, 29 Power adapter, 4 Predialing (on-hook dialing), 20

Reasons for missing caller ID information, 37

Recording time, 42 Redial, 22 Remote access, 49 Remote access code, 18 Remote commands, 49 Repeat messages, 45, 49 Ring tone, 11

Tabletop installation, 4 Technical specifications, 71 Temporary ringer silencing, 20 Temporary tone dialing, 25 Toll saver, 17 Troubleshooting, 55

Voicemail, 12, 41 Voice prompts, 42 Volume, 11, 15, 19, 24, 42, 45

Wall mount installation, 7

Screen icons, 51 Skip messages, 45, 49 Speakerphone switching, 15, 21, 45 Speed dial, 33–34

Appendix

Remote access wallet card

The wallet card below lists the commands needed to control your answering system from any touch-tone telephone.

Cut along dotted line.

Call your telephone number, then enter your two-digit remote access code (preset to 19).

Action Remote command

Play all messages .....................1

Play new messages ..................2

Delete the message .................3 (during message

playback)

Delete all old messages ........33

Fold here.

Repeat or go back ....................4

Stop ..................................................5

Help menu ....................................*5

Skip the message ......................6

Record announcement ...........*7

Turn system on or off .............0

End remote access call ..........8 (or hang up)

EL52100/EL52110 DECT 6.0 cordless telephone/answering system with caller ID/call waiting

www.telephones.att.com

AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219.

Printed in China. Issue 7 AT&T 05/11.

AT&T EL52100, EL52110 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
